DENT Instruments ROCOIL MV User manual

CONNECTING THE ROCOIL MV
CURRENT TRANSFORMERS TO
THE LINE POWERED ELITEPRO
DENT INSTRUMENTS | 64 NW FRANKLIN AVENUE | BEND, OREGON 97701
P 541.388.4774 | 800.388.0770 | F 541.385.9333 | WWW.DENTINSTRUMENTS.COM
PERFORMANCE UPDATE
rev 072910
NOTE: DO NOT ATTACH THE VOLTAGE LEADS UNTIL THE ROCOIL MV
CURRENT TRANSFORMERS ARE CONNECTED TO THE ELITEPRO METER.
1. Open the levers on the
connector using a screw
driver.
Page 1
2. Place the RED +ve DC
power lead into one
connector and the BLACK-
ve lead into the other
connector.

DENT INSTRUMENTS | 64 NW FRANKLIN AVENUE | BEND, OREGON 97701
P 541.388.4774 | 800.388.0770 | F 541.385.9333 | WWW.DENTINSTRUMENTS.COM
PERFORMANCE UPDATE
Page 2
3. Connect the leads from
the RoCoil mV into the
corresponding connector.
4. Screw the GREEN and
leads into the 8-
Position CT Connector (p/n
*CT-CONN; green Phoenix
connector).
4. Remove the backing from
the VHB tape on the
underside of the connectors
and firmly press onto the
ELITEpro enclosure.

DENT INSTRUMENTS | 64 NW FRANKLIN AVENUE | BEND, OREGON 97701
P 541.388.4774 | 800.388.0770 | F 541.385.9333 | WWW.DENTINSTRUMENTS.COM
PERFORMANCE UPDATE
Page 3
5. The photo, right, shows
three RoCoil mVs correctly
wired and powered by a Line
Powered ELITEpro
instrument.
7. The RoCoil mVs can also
be powered by a 120 VAC US
or 100-240 VAC International
wall transformer.
