INSTRUCTION MANUAL
Safety information
Please read the safety instructions carefully
before using the product for the first time
and keep the instructions for future reference
1. This product is not a toy. Keep it out of
reach of children.
2. Warning: This product includes lithium-ion
battery.
3. Keep product out of the reach of children
and pets to avoid chewing and swallowing
4. Product operating and storage temperature
is from 0 degree Celsius to 40 degrees
Celsius. Under and over this temperature
might affect the function.
5. Never open the product. Touching the
inside electrics can cause electric shock.
Repairs or service should only be perfor
med by qualified personnel.
6. Do not expose to heat, water, dust (dusty
environment), moisture, direct sunlight!
7. Please protect your ears against loud
volume. Loud volume can damage your
ears and can cause risk of hearing loss.
8. Bluetooth wireless technology operates
within a range of about 10 m (30 feet).
ENG1

The maximum communication distance
may vary depending on the presence of
obstacles (people, metal objects, walls,
etc.) or the electromagnetic environment.
.
9. Microwaves emitting from a Bluetooth
device may affect the operation of
electronic medical devices.
10. The unit is not waterproof. If water or
foreign objects enter the unit, it may
result in fire or electric shock. If water or
a foreign object enters the unit, stop
use immediately.
11. Only charge with supplied USB cable.
12. Do not use non original accessories
together with the product as this can
make the product functionality abnormal.
13. Do not block the device’s ventilation.
Product should be able to disperse the
heat.
PLEASE READ ALL INSTRUCTIONS CAREFULLY
AND RETAIN FOR FUTURE USE
ENG2

DESCRIPTION OF PARTSAND
RETAIN FOR FUTURE USE
ENG3
1
567
8
11
9
2 3 4
10
1. Flashlight switch
2. Previous track/ Volume down
3. Next track/ Volume up
4. Mode/Play/Pause
5. Type-C charging port
6. USB thumb drive input/ USB output port (5V/500mAh max)
7. Power on/off
8. Charging indicator
9. TF card slot
10. FM pole (Can be used as a phone stand when it is
adjusted to a suitable angle)
11. Solar panel

BTG-158 Wireless Bluetooth Speaker
Package Contents:
· Speaker
· Charging cable
· Instruction Manual
· Strap
TECHNICAL SPECIFICATIONS
· Bluetooth Version: 5.0
· Bluetooth Range: 10 meters
· Battery: Built-in 1200 mAh Lithium
· Working Time: about 2-3 hours
· Type-C input charging time: about 1.5-2 hours
· Speaker Output Power: 8W (With one active
speaker and one passive speaker)
· USB port and TF card slot for MP3 playback
· LED flashlight
· Solar charging
· USB output port (5V/500mAh max)
ENG4

INSTRUCTIONS FOR USE
How it works:
1. Ensure the product is fully charged before
first use.
2. Push the switch to the ON position to turn
on the speaker.
3 Press and hold the "M" button to choose
between Bluetooth mode/ USB drive music
/ TF card music/FM radio.
4. To pair with Bluetooth devices, go to
Bluetooth settings on your phone, search for
“BTG-158” and click Connect. Once connected
you will hear a sound.
5. Press the M/Play/Pause button to play/
pause the music.
6. Press the “+” or “-” to play the next /
previous track.
7. Press and hold the “+” or “-” to increase /
decrease the volume.
TWS connection is only available when using
two BTG-158 speakers.
After turning on speakers, double click the
"+" button on both speakers to pair the two
speakers for full stereo sound.
TWS CONNECTION
ENG5

1. Press the "M" button to answer / end a
phone call.
2. Press and hold the "M" button for 2
seconds to reject a phone call.
3. Double click the "M" button to redial the
last number.
HANDLING PHONE CALL S
1. Connect one end of the supplied charging
cable to the charging port and the other
end to the charger.
2. Put the product under the sun, and make
sure the solar charging panel is facing up.
You can use the solar panel on the product
to charge the battery.
CHARGING THE SPEAKER
ENG6
BATTERY INFORMATION
SPEAKER BATTERY
WARNING: The device is equipped with an
integrated lithium battery. The battery
cannot be replaced.
Do not attempt to remove the battery from
the device.
Please note all products are subject to
change without any notice. We take
reservations
for errors and omissions in the manual.

ENG7
· ALL RIGHTS RESERVED, COPYRIGHT
DENVER A/S
Electric and electronic equipment and
batteries is marked with the crossed out trash
can symbol, seen above. This symbol signifies
that electric and electronic equipment and
batteries should not be disposed of with other
household waste, but should be disposed of
separately.

As the end user it is important that you submit
your used batteries to the appropriate and
designated facility. In this manner you make
sure that the batteries are recycled in
accordance with legislature and will not harm
the environment.
All cities have established collection points,
where electric and electronic equipment and
batteries can either be submitted free of
charge at recycling stations and other
collection sites, or be collected from the
households. Additional information is available
at the technical department of your city.
Hereby, DENVER A/S declares that the radio
equipment type BTG-158 is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the
following internet address: denver.eu and then
click the search ICON on topline of website.
Write model number: BTG-158. Now enter
product page, and RED directive is found
under downloads/other downloads.
Operating Frequency Range: 85-15KHZ
Max Output Power: 8W
Bluetooth Frequency: 2402 MHZ-2480 MHZ
Warning: Lithium battery inside
ENG8

Denver A/S
Omega 5A, Soeften
DK-8382 Hinnerup
Denmark
