Dermapen Pro User manual

Caution before use:

• Before inserting needle to Dermapen™ handle, check the needles condition

1. Grip the needles tail and push several times

2. Check needles spring and make sure the needle’s smooth movement.

To insert needle:

1. Holding the depth controller, Insert needle turning in a clockwise direction

2. Do not squeeze or over turn

To separate needle:

1. Hold the depth controller, remove needle tip and turning counter-clockwise till needle comes out

2. Separate needle.

Warranty:

1. This product is manufactured under strict quality control and inspection processes.

2. Warranty is to cover the operating defaults after the purchase during the warranty period (12 months after the purchase)

3. If this product goes out of order under the normal customer use, we will repair it free of charge during the

warranty period.

5. The damages (defaults) prescribed below are NOT to be covered by warranty.

• Users faults by lack of care, keep out of water,

• Unauthorised electric currency connection defaults

• Faults by the users own intention or unauthorised repair

• Damages caused by natural disaster. (Fire, Flood, Earthquake, lightning etc)

• Replacement to new parts

6. Validate your warranty by visiting www.dermapenworld.com

DermapenTM is a trademark of Equipmed. 283 Mona Vale Road Enter via 56A Myoora Road Terrey Hills

NSW 2084 Australia. www.equipmed.com. Equipmed hold no responsibility for treatment outcomes as

individual patient results may vary. The Dermapen device is to be used only as directed.

Dermapen is certied 1023 and registered. EQUD3P1002. 12/13

USER MANUAL

AOVNTM

PRO

PURPOSE OF USE:

“Dermapen™” is intended to stimulate the skin for natural collagen induction. It helps with absorption of active ingredients,

skin tightening, lifting and rejuvenation, acne scars and promotes wound healing, improves wrinkles and ne lines, mini-

mises pore size, improves stretch mark appearance, improves alopecia and more.

USER ACKNOWLEDGMENT:

We have been advised by Equipmed or the local representative that the National Recommendations for Standard

Dermal Rolling Treatments which could apply to the Dermapen™ Procedures, is that only qualied health professionals

should operate this procedure to the depth over 1mm. It is the responsibility of the user/purchaser to be aware of local

recommendations and restrictions. It is the responsibility of the user to obtain appropriate insurance cover, if

applicable.

ORDER OF TREATMENT:

Step 1. Cleansing:

• Thoroughly cleanse the skin with an appropriate cleansing product, suitable to the type of skin being treated.

• For an optimal e󱐯ect, it is advisable to remove dead cells of the stratum corneum with an exfoliating product such as DP

Dermaceuticals™ MD Exfoliant (peeler, microderm, exfoliation treatment) before starting the treatment with Dermapen™.

• Remove all residue of the cleanser followed by a suitable antiseptic toner or wipe.

Step 2. Spread anaesthetic ointment on the treatment region:

• (It is important to read the user’s manual of the anaesthetic cream before its application.)

• Leave on surface of skin for about 15-50 minutes (depending on product used) before removing it. Best to occlude with

plastic wrap for the duration waiting period.

• Remove all residue of anaesthetic ointment followed by a suitable antiseptic toner or wipe.

Step 3. Treatment with Dermapen™:

1. Plug in adaptor and insert sterilised needle into the Dermapen™ tip

2. Turn on using speed setting. (Face speed :1~4<Thin, Sensitive skin 1~3><Thick skin 3~4>, Body speed :3~4)

3. Select the needle depth and speed of the Dermapen that best suits the treatment area. See below as a guide:

Step 4. Active Ingredients application:

• Visually section the treatment area into 5 regions; ie. forehead, right cheek, left cheek, chin/upper lip & nose

• 4. Apply a uniform layer of DP Dermaceuticals™ HylaActive on one treatment region at a time. The numerous micro holes

obtained due to the needles action will favour the deep penetration of the active ingredients into the skin.

5. With the free hand that is not holding the Dermapen™ handle, gently hold the skin or scalp taught. With the other hand

holding the Dermapen™ handle:

• Start with Stripe-like motions, from left to right, lifting the needle-tip between each stripe instead of zip zag motion to

avoid unnecessary reinsertions. Oscillation or depth may be adjusted mid procedure.

• Second Pass, while exerting a constant pressure as shown in the picture below – treat from top to bottom

• Third pass (if applicable) treat while exerting constant pressure – treat diagonally

• Don’t apply hard pressure

REGION THIN SKIN THICK SKIN Depth under 0.5mm: speed 1~2

Depth 0.5~0.75 mm: speed 2~3

Depth 0.75~1.00mm: speed 3~4

Depth under speed guide Treatment area guide

Step 5. Cooling, soothing and moisturising:

• Clean area with sterile guaze or DP Dermaceuticals™ DP Wipes. Re-glove. Cool area with DP Dermaceuticals™ CoolStick or facial

cooling mask (or brella cloths soaked in ice water) on the stimulated and red region.

Apply a soothing and moisturising product such as DP Dermaceuticals™ AntiOxidant Cocktail, Followed by Vitamin Rich Repair.

Step 6. Post operative treatment:

• After the treatment, take precaution against sun exposure. Since the skin’s channels are open for a period of time

after treatments, it’s recommended to use a sunscreen designed for sensitive skin and post cosmetic procedures.

For more information contact us.

• For best results it’s recommended to repeat treatment every 4-8 weeks, up to 4-8 times (individual patients will vary).

PRODUCTS THAT ARE ADVISABLE TO BE USES IN COMBINATION WITH DERMAPENTM ARE

• Products capable of stimulating the collagen and elastin and stimulation of the regeneration of cells. Products containing

essential nutrients for the epidermis and dermis such as hyluronic acid, cooper peptides, B5, B3, resversatrol, vitamin A esters.

• Dermapen™ recommends the skincare range from DP Dermaceuticals™ which have been carefully created to improve results

and support the skin pre & post Dermapen treatments. For more information see. www.dermapenworld.com

PRODUCTS THAT BE AVOIDED WITH DERMAPEN™:

• Avoid chemical additives in sunscreens

• Avoid any product that could damage the cells or tissues

• Try to avoid chemical additives including high glycolic and aha acids

• Avoid allergy causing materials

• Avoid perfumes and articial colorants

WARNING TO PROFESSIONAL USERS:

• Unseal the product just before treatment and make sure that the device does not touch other objects. (To avoid infection)

• Examine the patient’s skin before treatment. The product can provoke side e󱐯ects.

• Do not use the product if the date of validity has expired.

• Only qualied physicians who are able to judge if the treatment ts the skin condition of the patient should use the product.

They must be able to decide the appropriate use of an anaesthetic cream and choose product in combination with the

Dermapen™ treatment. For more recommendations see; www.dermapenworld.com

• Dermapen “Medical” model is sold exclusively for medical use only (public general sales are prohibited).

Dermapen needles are designed for single use only and must be disposed of in its original cap or in a sharps container

• Do not exert excessive pressure when using the Dermapen™

• Avoid contact with the lips and eye contour (mainly the eyelids) given that the skin is thinner in these particular areas.

• Do not use the product on children or animals

• In case of a rash, allergic reactions or any other undesirable e󱐯ect, stop using the product immediately.

• Be sure to check the seal, damage, or term of validity of the product before use.

• See ‘User Acknowledgement’.

SIDE EFFECTS OF THE DERMAPEN™:

• It can cause an allergic reaction on patients who su󱐯er from a cutaneous allergy to metallic products.

• It can cause acne eruption in patients su󱐯ering from advanced acne. Take into consideration acne before starting the

treatment. Pre treatment of the acne condition is recommended before proceeding with Dermapen treatment.

• It can cause pigmentation in patients with sensitive skin mainly if excessive pressure has been exerted while using

the Dermapen™ on the skin.

POSSIBLE COMPLICATIONS:

• Cutaneous eruptions

• Inammations and eythema

• Itching and burning sensations

• Cold sore eruption

STORAGE:

• Store the product in a well ventilated and dry place at room temperature

Forehead 0.25~0.5mm 0.5mm

Between Eyebrow 0.25~0.5mm 0.5mm

Nose 0.25mm 0.5mm

Eye area 0.25mm 0.25mm

Cheek bone 0.5mm 0.5~0.75mm

Cheek 0.5~0.75 0.75~1.0mm

Lips 0.25mm 0.25mm

Scar Mark 1.0mm 1.0mm

Stretch Mark 1.0mm 1.0mm
