Desa TC25 User manual

PROPANE CONSTRUCTION
CONVECTION HEATER
OWNER’S MANUAL
Save this manual for future reference.
Save this manual for future reference.
For more information, visit www.desatech.com
For more information, visit www.desatech.com
IMPORTANT: Read and understand this manual before assembling, starting, or servicing
heater.Improperuseofheatercancauseseriousinjury.Keepthismanualforfuturereference.
Variable 15,000, 20,000,
and 25,000 Btu/Hr
GENERAL HAZARD WARNING:
FAILURETOCOMPLYWITHTHEPRECAUTIONSANDINSTRUCTIONSPROVIDEDWITHTHIS
HEATER, CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR
DAMAGEFROMHAZARDSOFFIRE,EXPLOSION,BURN,ASPHYXIATION,AND/ORCARBON
MONOXIDE POISONING.
ONLYPERSONSWHOCANUNDERSTANDANDFOLLOWTHEINSTRUCTIONSSHOULDUSE
OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTIONS
MANUAL, LABELS, ETC. CONTACT THE MANUFACTURER.
TABLE OF CONTENTS
SAFETY INFORMATION ............................................................ 2
PRODUCT IDENTIFICATION ..................................................... 3
UNPACKING ............................................................................... 3
THEORY OF OPERATION ......................................................... 3
PROPANE SUPPLY .................................................................... 3
VENTILATION............................................................................. 3
INSTALLATION ........................................................................... 4
OPERATION ............................................................................... 4
STORAGE................................................................................... 5
MAINTENANCE .......................................................................... 5
SPECIFICATIONS ...................................................................... 5
REPLACEMENT PARTS ............................................................ 5
TECHNICAL SERVICE ............................................................... 5
TROUBLESHOOTING ................................................................ 6
INSPECTING BURNER .............................................................. 6
OWNER'S REGISTRATION FORM ............................................ 7
ILLUSTRATED PARTS BREAKDOWNAND PARTS LIST ........ 9
WARRANTY INFORMATION...................................... Back Cover
Model TC25

101857-01H
2
For more information, visit www.desatech.com
For more information, visit www.desatech.com
SAFETY INFORMATION
WARNING:FIRE,BURN,INHALATION,ANDEXPLO-
SION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH
ASBUILDINGMATERIALS,PAPERORCARDBOARD,A
SAFE DISTANCE AWAY FROM THE HEATER AS REC-
OMMENDEDBYTHEINSTRUCTIONS.NEVERUSETHE
HEATER IN SPACES WHICH DO OR MAY CONTAIN
VOLATILEORAIRBORNECOMBUSTIBLES,ORPROD-
UCTS SUCH AS GASOLINE, SOLVENTS, PAINT THIN-
NER, DUST PARTICLES OR UNKNOWN CHEMICALS.
WARNING:NOTFOR HOME ORRECREATIONAL
VEHICLE USE.
WARNINGS
SAFETY INFORMATION
We cannot foresee every use which may be made of our heaters.
Checkwithyourlocalfiresafetyauthorityifyouhavequestions
about heater use.
Carbon Monoxide Poisoning: Some people are more affected by
carbon monoxide than others. Early signs of carbon monoxide
poisoning resemble the flu, with headaches, dizziness, and/or nau-
sea.Ifyouhavethesesigns,theheatermaynotbeworkingproperly.
Get fresh air at once! Have heater serviced.
Propane Gas: Propane gas is odorless. An odor-making agent is
addedto propanegas.The odorhelpsyou detectapropanegas leak.
However,the odoradded topropane gascan fade.Propane gasmay
be present even though no odor exists.
Make certain you read and understand all warnings. Keep this
manual for reference. It is your guide to safe and proper operation
of this heater.
• Install and use heater with care. Follow all local ordinances and
codes. In the absence of local ordinances and codes, refer to the
Standard for Storage and Handling of Liquefied Petroleum Gas,
ANSI/NFPA 58 This instructs on the safe storage and handling
of propane/LP gases.
• Use only the hose and factory preset regulator provided with
the heater.
• Use only propane gas set up for vapor withdrawal.
• For indoor and outdoor use. When used indoors, use only in
well-vented areas. Provide at least 120 square inches (774.2 cm2)
of fresh, outside air before using heater.
• Donotuse heaterin occupieddwellings, sleepingquarters,camp-
ers, tents, or any type of unvented or enclosed area.
• Do not use heater in basement or below ground level. Propane
gas is heavier than air. If a leak occurs, propane gas will sink to
the lowest possible level.
• Do not use heater as a cooking device. Do not place objects on
top of heater.
• Keepapplianceareaclearandfreefromcombustiblematerials,gaso-
line, paint thinner, and other flammable vapors and liquids. Dust is
combustible. Do not use heater in areas with high dust content.
• Minimum heater clearances from combustibles:
Sides: 3 feet (1 meter); Top: 6 feet (1.8 meters).
• Keep heater at least six feet from propane tank(s).
• Keep propane tank(s) below 100ºF (38°C).
• Before each use, check heater for leaks. Never use an open flame
to check for a leak.Apply a mixture of liquid soap and water to
all joints. Bubbles forming show a leak. Correct all leaks at once.
• Check heater for damage before each use. Do not use a dam-
aged heater.
• Check hose before each use of heater. If highly worn or cut, re-
placewith hosespecifiedbythemanufacturer beforeusing heater.
• Do not alter heater. Keep heater in its orginal state.
• Do not use heater if altered.
• Locate heater on stable and level surface if heater is hot or
operating.
• Never block air inlet (top of base) or air outlet (around top of
shell) of heater.
• Keep heater away from strong drafts, wind, water spray, rain, or
dripping water.
• Never operate heater while sleeping or unattended.
• Keep children and animals away from heater.
• Before connecting heater to propane tank, make sure the heater
requlator knob is in the “OFF” position. Always connect and
operate heater in areas free of open flames.
• Never move, handle, or service a hot or operating heater. Severe
burnsmay result.You mustwait15minutesafter turningheater off.
• To prevent injury, wear gloves when handling heater.
• Always remove heater from propane tank after each use.Always
store propane tank outdoors in a well ventilated space out of the
reach of children. Never store propane tank in a building, garage,
or any other enclosed area. Never store propane tank near high
heat, open flame, or where temperatures exceed 49° C (120° F).
• Turn off propane supply to heater when not in use.
• Use only original replacement parts. This heater must use de-
sign-specific parts. Do not substitute or use generic parts. Im-
proper replacement parts could cause serious or fatal injuries.
• Keep all connections and fittings clean. Make sure propane tank
valve outlet is clean. Check the rubber “O” ring on the heater
inlet fuel connector for damage before each use. Replace if worn
or damaged.
WARNING:Thisproductcontainsand/orgenerates
chemicals known to the State of California to cause
cancer or birth defects, or other reproductive harm.

101857-01H
3
3
For more information, visit www.desatech.com
For more information, visit www.desatech.com
PRODUCT IDENTIFICATION
UNPACKING
THEORY OF OPERATION
PROPANE SUPPLY
VENTILATION
PRODUCT IDENTIFICATION
Piezo Ignitor
Button
Gas Inlet
Connector
Shell
Top
Base
Automatic Control
Valve Button
Figure 1 - Product Identification
UNPACKING
1. Remove all packing items applied to heater for shipment. Keep
plastic cover caps (attached to inlet connector and hose/regu-
lator assembly) for storage.
2. Remove all items from carton.
3. Check all items for shipping damage. If heater is damaged,
promptly inform dealer where you bought heater.
THEORY OF OPERATION
The Fuel System: The hose/regulator assembly attaches to the
propane gas supply. This provides fuel to the heater.
The Ignition System: The piezo ignitor lights the burner.
The Automatic Control System: This system causes the heater to
shut down if the flame goes out.
NOTICE: Because of the metal lubricant used in this
product, you may notice some smoking upon initial
startup and shut down. This condition is normal and
should not occur beyond the first several (5-10)
minutes of operation. If you have questions, please
call 1-866-672-6040.
PROPANE SUPPLY
Propane gas and propane tank(s) are to be furnished by the user.
Use this heater only with a propane vapor withdrawal supply
system. See Chapter 5 of the Standard for Storage and Handling of
LiquefiedPetroleumGas, ANSI/NFPA58. Yourlocal libraryorfire
department will have this booklet.
Theamountofpropanegasreadyforusefrompropanetanksvaries.
Two factors decide this amount:
1. The amount of propane gas in tank(s)
2. The temperature of tank(s)
This heater is designed to operate with a minimum 20 lb. (9 kg) tank.
Youmayneedtwoormoretanksoronelargertankincolderweather.
Usea100lb.(45kg)tankforlongeroperationorinverycoldweather.
Less gas is vaporized at lower temperatures. Your local propane gas
dealer will help you select the proper supply system.
Temperature °F (°C) Number of tanks,
at Tank Location 100 pound (45 kg)
40° (4°) 1
32° (0°) 1
20° (-6.7°) 1
10° (-12°) 1
0° (-18°) 1
-10° (-23°) 2
-20° (-29°) 2
VENTILATION
WARNING: Provide at least an 120-square-inch
(774.2cm2)openingoffresh,outsideairwhilerunning
heater. If proper fresh, outside air ventilation is not
provided,carbonmonoxidepoisoningcanoccur.Pro-
vide proper fresh, outside air ventilation before run-
ning heater.
Hose/Regulator/
Fuel Gas
connector
Assembly

101857-01H
4
For more information, visit www.desatech.com
For more information, visit www.desatech.com
INSTALLATION
WARNING:Review and understand the warnings
in the
Safety Information section, page 2. They are
needed to safely operate this heater. Follow all local
codes when using this heater.
WARNING: Test all gas piping and connections
for leaks after installation or servicing. Never use an
open flame to check for a leak. Apply a mixture of
liquid soap and water to all joints. Bubbles forming
show a leak. Correct all leaks at once.
1. Make sure heater regulator knob is in the “OFF” position.
2. Wrench tighten the fuel connector nut into the propane tank
valve (see Figure 2). Turn fuel connector nut counterclock-
wise to tighten. Threads are left-handed.
3. Connect hose to inlet connector (see Figure 3). Tighten firmly
using a wrench.
4. Open propane supply valve on propane tank(s) slowly. Note: if
not opened slowly, excess-flow check valve on propane tank
may stop gas flow. If this happens, you may hear a click inside
the regulator assembly, this is the check valve closing. To reset
the excess-flow check valve, close propane supply valve and
open it again slowly.
5. Check all connections for leaks.Apply mixture of liquid soap
and water to gas joints. Bubbles forming show a leak that must
be corrected.
6. Close propane supply valve.
Propane Tank
Regulator
Figure 2 - Connecting Heater to Propane Tank
Inlet
Connector
Hose
Figure 3 - Hose and Inlet Connector, Automatic Control Valve
Button and Piezo Ignitor Button Locations
OPERATION
WARNING: Review and understand the warnings
in the
Safety Information section,page 2. They are
needed to safely operate this heater. Follow all local
codes when using this heater.
TO START HEATER
1. Follow all installation, ventilation, and safety information.
2. Locate heater on stable and level surface. Make sure strong
drafts do not blow on heater.
3. Make sure heater regulator knob is in “OFF” position.
4. Open propane supply valve on propane tank(s) slowly.
5. Turn the heater regulator knob counterclockwise to the “HI”
position.
6. Push in and hold automatic control valve button (see Figure 3.
Push and release piezo ignitor button (see Figure 3). Keep push-
ingpiezoignitor buttonuntil theburnerlights. Hold controlknob
down for a maximum of 10 seconds while attempting ignition. If
heater does not light, release control knob and wait 30 seconds.
Repeat step 6 to start heater. Note: Keep hands and face away
from outlet (around top of shell) of heater while attempting to
start heater. After ignition, hold control knob down for approxi-
mately 30 seconds. This activates the automatic control system.
7. If burner will not light after repeated tries, do not attempt
to repair heater. Return heater to nearest authorized service
center or call DESAHeating Products' Technical Service at
1-866-672-6040.
8. When burnerremains lit, youcan turntheheater regulatorknob
clockwise to the desired heat setting (see Figure 4). If burner
goes out, turn off gas. Turn regulator knob fully clockwise to
“OFF.” Check fuel supply. If fuel supply is OK, restart heater.
Piezo Ignitor
Automatic
Control Valve
Button
Heat Settings
Figure 4 - Heater Regulator
TO STOP HEATER
1. Tightly close propane supply valve on propane tanks by turn-
ing clockwise.
2. Turn heater regulator knob to the “OFF” position.Wait 15 min-
utes for the heater to cool before handling heater.
3. Always remove the gas supply hose from the heater and the
propane tank after each use.
TO RESTART HEATER
1. Wait five minutes after stopping heater.
2. Repeat steps under To Start Heater, above.
INSTALLATION
OPERATION

101857-01H
5
5
For more information, visit www.desatech.com
For more information, visit www.desatech.com
STORAGE
CAUTION: Disconnect heater from propane sup-
ply tank(s).
1. Do not store heater while attached to propane tank. Remove
the gas supply hose from the propane tank by turning the fuel
gas connector nut clockwise.
2. Store propane tank(s) in safe manner. Refer to Chapter 5 of
Standard for Storage and Handling of Liquified Petroleum
Gases, ANSI/NFPA 58. Follow all local codes. Always store
propane tanks outdoors. Never store propane tank in an en-
closed area.
3. Place plastic cover caps over brass fittings on inlet connector
and hose/regulator assembly.
4. Store in a dry, clean, and safe place.
MAINTENANCE
WARNING: Never attempt to service heater while
it is connected to propane supply, operating, or hot.
Severe burns can occur.
1. Keep heater clean.
2. Inspect heater before each use. Check connections for leaks.Ap-
plymixtureofliquidsoapand watertoconnections.Bubblesform-
ing show a leak that must be corrected. Correct all leaks at once.
3. Inspect hose/regulator assembly before each use. If hose is
highly worn or cut, replace.
4. Have heater inspected yearly by a qualified service person.
STORAGE
MAINTENANCE
SPECIFICATIONS
REPLACEMENT PARTS
TECHNICAL SERVICE
SPECIFICATIONS
Rating (Btu/Hr)
High ........................................25,000
Medium ..................................20,000
Low.........................................15,000
Fuel ................................................Propane Vapor Only
Fuel Consumption
Gallons (Liters)/Hour .............Min .17 (.64), Max .27 (1.02)
Pounds (kg)/Hour ...................Min .70 (.32), Max 1.16 (.53)
Supply Pressure (To Regulator)
Maximum ...............................Tank Pressure
Minimum ................................275.8 kPa (40 psi)
Regulator Outlet Pressure.............. 103.4 kPa (15 psi)
Weight
Heater .....................................3.2 kg (7 lb)
Shipping..................................4.1 kg (9 lb)
Size - L x W x H
Heater .....................................31.7 x 27.9 x 34 cm
(12.5 x 11 x 13.4 inches)
Carton .....................................33 x 30.5 x 35.6 cm
(13 x 12 x 14 inches)
REPLACEMENT PARTS
WARNING: Use only original replacement parts.
This heater must use design-specific parts. Do not
substitute or use generic parts. Improper replace-
ment parts could cause serious or fatal injuries. This
will also protect your warranty coverage for parts
replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product. If they can’t supply
original replacement part(s), either contact your nearest Parts Cen-
tralor callDESAHeatingProducts’TechnicalServiceDepartment
at 1-866-672-6040.
When calling DESA Heating Products, have ready
• your name and address
• how heater was malfunctioning
• purchase date
• model and serial numbers of your heater
In most cases, we will ask you to return the part to the factory.
PARTS NOT UNDER WARRANTY
Contact authorized dealers of this product. If they can’t supply
original replacement part(s), either contact your nearest Parts Cen-
tral listed in the Authorized Service Center booklet supplied with
heater or call DESA Heating Products at 1-866-672-6040 for
referral information.
When calling DESA Heating Products, have ready
• model number of your heater
• the replacement part number
TECHNICAL SERVICE
You may have further questions about installation, operation, or
troubleshooting. If so, contact DESA Heating Products’ Technical
Service Department at 1-866-672-6040. When calling please have
your model and serial numbers of your heater ready.
You can also visit DESA Heating Products’ technical services web
site at www.desatech.com.

101857-01H
6
For more information, visit www.desatech.com
For more information, visit www.desatech.com
INSPECTING BURNER
WARNING: Heater shell, top, and heated air from
heater is very hot during operation. Gradually move
in closer to heater to observe flame color. Do not
touch heater shell or top. Do not get too close to
heated air from heater. Severe burns could occur.
Tocheckforcorrectburnerflame,lookthroughtheventilationholes
in the top of the heater to see the burner flame. The burner flame
shouldbemostlyblue withslightyellowcoloringon theends.If the
burner flame is mostly yellow, the primary air openings on the
burner tube under the heater base may be blocked (see Figure 5).
1. Stop heater (see To Stop Heater on page 4) and let cool.
2. Turnheaterovertolocatethe primaryair openingson theburner
tube (see Figure 5). Remove any debris blocking the primary
air openings.
Burner
Tube
Primary Air
Openings
Figure 5 - Bottom View of Heater
TROUBLESHOOTING
Youmayhavefurtherquestionsaboutthisheater.Ifso,contactDESA
HeatingProducts'TechnicalServiceDepartmentat1-866-672-6040
or visit our web site at www.desatech.com.
REMEDY
1. Open propane supply valve slowly
2. Replace burner/valve assembly
3. Assureignitorelectrodegapis.120"(3.04mm).
Check wire lead for damage. Replace piezo
ignitor and/or ignitor electrode as necessary
1. Relight, hold automatic control valve button
in 45 seconds
2. Check propane tank(s) for proper gas supply
3. Tighten connection or replace thermocouple
4. Replace automatic control valve assembly
1. Check gas supply; check regulator output
2. Consult propane gas supplier
3. Replace burner assembly
POSSIBLE CAUSE
1. Propane supply valve closed on propane
tank(s)
2. Blockage in burner/valve assembly
3. Piezo ignition system not sparking
1. Not enough warm-up time
2. Low gas pressure
3. Thermocouple loose or needs to be re-
placed
4. Automaticcontrolvalveneedstobereplaced
1. Low gas pressure
2. Low fuel supply
3. Plugged gas orifices
SYMPTOM
Burner fails to light
Burner lights but goes out when auto-
matic control valve button is released
Maximum burn rate is low
WARNING: Never attempt to service heater while it
is connected to propane supply, operating, or hot.
Severe burns can occur.
TROUBLESHOOTING
INSPECTING BURNER

101857-01H
7
7
For more information, visit www.desatech.com
For more information, visit www.desatech.com
1. Who will heater be used by? ❍ Individual ❍ Business
2. Will you use your heater in more than one location? ❍ Yes ❍ No
3. Where will the product be used? (You may select more than one.) ❍ Workshop ❍ Barn ❍ Residential Construction
❍ Commercial Construction ❍ Garage ❍ Factory ❍ Recreation ❍ Warehouse ❍ Utility Shed/Outbuilding
❍ Other ______________________________ (Specify)
4. Cost of product (excluding sales tax)? $________________________________
5. Maintenance/service work will be performed by: ❍ Self ❍ Service Center ❍ Other ___________________________________
6. If you bought this product yourself, did you plan to purchase this type of product before going into the store? ❍ Yes ❍ No
7. Type of store where product was purchased? ❍ Hardware ❍ Propane Dealer ❍ Natural Gas/Utility Co. ❍ Home Center or Builder’s Supply
❍ Farm/Ag. Supply ❍ Auto Parts ❍ Warehouse Club ❍ Industrial/Contractor Supply ❍ Rental Store
❍ Discount Store ❍ HVAC Dealer ❍ Other _________________________________________________
8. What is your primary source of heat? ❍ Propane (LP Gas) ❍ Natural Gas ❍ Kerosene ❍ Diesel ❍ Electric ❍ Other________________
9. What motivated you to buy this product? ❍ Sudden Cold Weather ❍ Replace Older Model ❍ D.I.Y. Home Project ❍ Emergency Back-Up Heat
❍ Heater on Sale ❍ Construction Project ❍ Hard to Heat Location ❍ Other ________________________________
10. How did you learn about this product brand? ❍ Advertisement ❍ Relative or Friend ❍ Co-Worker ❍ Store Representative
❍ Store Display ❍ Previously Owned a Heater ❍ Other _________________________________________________(Specify)
11. What other brands did you consider? ❍ None ❍ Master ❍ Remington ❍ All-Pro ❍ Dayton ❍ Universal ❍ Mr. Heater ❍ L.B.White Tradesman
❍ John Deere ❍ Dyna-Glo ❍ Dura-Heat ❍ Paulin ❍ Coleman ❍ Vogelzang American ❍ Other ___________________________________
12. Who selected the product? ❍Male ❍Female ❍Both
13. Level of Education of Purchaser: ❍ High School ❍ Vocation/Technical School ❍ Some College ❍ Completed College ❍ Graduate School
14. Age of Purchaser: ❍ Under 20 ❍ 20 - 29 ❍ 30 - 39 ❍ 40 - 49 ❍ 50 - 59 ❍ 60 or Over
15. Buyer’s total annual household income: ❍ Under $19,999 ❍ $20,000 to $34,999 ❍ $35,000 to $49,999
❍ $50,000 to $74,999 ❍ $75,000 to $99,999 ❍ $100,000 and Over
16. What is the population of your area? ❍ Under 10,000 ❍ 10,000 to 25,000 ❍25,000 to 50,000 ❍ 50,000 to 100,000
❍ 100,000 to 250,000 ❍ Over 250,000
17. Store where product was purchased:
Name: ______________________________________ City: _____________________________________ State: __________
18. In choosing this product, how important were the following:
Availability
Price
Brand Name
Overall Quality
Heat Output (Btu/Hr Rating)
Variable Heat Output (Btu/Hr)
Made in USA
Warranty
Local Service
Value for Price
19. This question will allow us to better understand the demographic profile of our customers.Which of the following best describes you? (not required)
❍ African American ❍ Asian American ❍ Mexican ❍ Puerto Rican ❍ Cuban ❍ Other Hispanic ❍ White ❍ Other ___________________
Brand: (Reddy Heater, Master, Remington, etc.)
Model: (R60, HD15, etc.)
Date Purchased: Note: Keep receipt for warranty verification.
Serial Number: 7 or 9 digit number located on product or identification tag.
First Name: Last Name:
Address:
City: State: Zip: Country:
Phone: ( ) - E-Mail:
OWNER'S REGISTRATION FORM
Please answer the following questions to register your product with DESA Heating Products:
Complete registration form and mail or complete on-line registration at www.desatech.com within 30 days after purchase.
Not Somewhat Very
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
Not Somewhat Very
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
❍
Size
Prior Brand Experience
Built-In Thermostat
Ease of Operation
Special Features
Salesperson’s Recommendation
Friend/Relative’s Recommendation
Portability
Quiet Operation

101857-01H
8
For more information, visit www.desatech.com
For more information, visit www.desatech.com
Postage
Required
TAPE
2701 Industrial Drive
P.O. Box 90004
Bowling Green, KY 42102-9004
www.desatech.com
TAPE

101857-01H
9
9
For more information, visit www.desatech.com
For more information, visit www.desatech.com
KEY PART
NO. NO. DESCRIPTION QTY.
1 101880-01 Shell Assembly 1
2 101864-01 Burner Assembly Kit 1
3 102445-01 Piezo Ignitor w/ Nut 1
4 103933-01 Thermocouple Bracket 1
5 101878-01 Electrode Ignitor 1
6 099236-01 Thermocouple Ignitor Kit 1
7 LPA3025 Hose & Regulator Assembly 1
8 LPA2025 Regulator 1
ILLUSTRATED PARTS
BREAKDOWN AND PARTS LIST
MODEL
TC25
ILLUSTRATED PARTS BREAKDOWN AND PARTS LIST
Model TC25
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 5 of this manual.
56
2
1
4
7
8
3

101857-01H
10
For more information, visit www.desatech.com
For more information, visit www.desatech.com
LIMITED WARRANTY
DESA Heating Products warrants this product and any parts thereof, to be free from defects in materials and workmanship for one (1) year from the
date of first purchase when operated and maintained in accordance with instructions. This warranty is extended only to the original retail purchaser,
when proof of purchase is provided.
This warranty covers only the cost of parts and labor required to restore the product to proper operating condition. Transportation and incidental costs
associated with warranty repairs are not reimbursable under this warranty.
Warranty service is available only through authorized dealers and service centers.
This warranty does not cover defects resulting from misuse, abuse, negligence, accidents, lack of proper maintenance, normal wear, alteration,
modification,tampering,contaminatedfuels,repairusingimproperparts,orrepairbyanyoneotherthananauthorizeddealerorservicecenter.Routine
maintenance is the responsibility of the owner.
THIS EXPRESS WARRANTY IS GIVEN IN LIEU OF ANY OTHER WARRANTY EITHER EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
DESA Heating Products assumes no responsibility for indirect, incidental or consequential damages. Some states do not allow the exclusion or
limitation of incidental or consequential damages, or limitations or exclusions may not apply to you. This Limited Warranty gives you specific legal
rights and you may also have other rights which vary from state to state.
WARRANTY AND REPAIR SERVICE
KEEP THIS WARRANTY
This warranty does not cover discoloration due to operation of heater. We reserve the right to amend these specifications at any time without notice.
The only warranty applicable is our standard written warranty. We make no other warranty, expressed or implied.
WARRANTY SERVICE
Should your heater require service, return it to your nearest authorized service center. Proof of purchase must be presented with the heater. The heater will
be inspected. A defect may be caused by faulty materials or workmanship. If so, DESA Heating Products will repair or replace the heater without charge.
REPAIR SERVICE
Returnyourheatertoyournearestauthorizedservicecenter.Repairsnotcoveredbythewarrantywillbebilledatstandardprices.EachServiceCenter
is independently owned and operated. We reserve the right to amend these specifications at any time without notice.
Model
Serial No.
Date of Purchase
101857 01
NOTA UPC
2701 Industrial Drive
P.O. Box 90004
Bowling Green, KY 42102-9004
www.desatech.com
101857-01
Rev. H
05/03
