Desa VTD-18N-JHB Quick start guide

Save this manual for future reference.
For more information, visit www.desatech.com
WARNING: If the information in this manual is not fol-
lowed exactly, a re or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re
department.
— Installation and service must be performed by a quali-
ed installer, service agency or the gas supplier.
VENTED DECORATIVE NATURAL GAS LOG HEATER
OWNER’S OPERATION AND INSTALLATION MANUAL
MODELS VTD-18N-JHB,
VTD-24N-JHB AND
VTD-30N-JHB
TESTED AND
LISTED BY
RGA 2-72
APPROVED

www.desatech.com 114370-01D2
WARNING: Improper installation, adjustment, altera-
tion, service or maintenance can cause injury or prop-
erty damage. Refer to this manual for correct installation
and operational procedures. For assistance or addi-
tional information consult a qualied installer, service
agency or the gas supplier.
WARNING: This appliance is for installation only in
a solid-fuel burning masonry or UL127 factory-built
replace, constructed of noncombustible material and
connected to a working ue. (See page 6 for minimum
ue opening.)
WARNING: This is a gas-red heater. It uses air (oxy-
gen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be
provided. Refer to the National Fuel Gas Codes, ANSI
Z233.1/NFPA 54, Section 5.3, Air for Combustion and
Ventilation.
This appliance may be installed in an aftermarket,* per-
manently located, manufactured (mobile) home, where
not prohibited by local codes.
This appliance is only for use with the type of gas indi-
cated on the rating plate. This appliance is not convert-
ible for use with other gases.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
State of Massachusetts: The installation must be made
by a licensed plumber or gas tter in the Commonwealth
of Massachusetts.
TABLE OF CONTENTS
Safety Information ............................................... 3
Local Codes......................................................... 4
Unpacking............................................................ 4
Product Identication........................................... 5
Optional Product Features................................... 5
Installation ........................................................... 5
Operating Appliance .......................................... 10
Cleaning and Maintenance................................ 10
Troubleshooting..................................................11
Service Hints ..................................................... 13
Technical Service............................................... 13
Replacement Parts............................................ 13
Accessories ....................................................... 13
Illustrated Parts Breakdown and Parts List........ 14
Warranty Information ...........................Back Cover

www.desatech.com
114370-01D 3
SAFETy INFORMATION
WARNING: This product con-
tains and/or generates chemicals
known to the State of California
to cause cancer or birth defects
or other reproductive harm.
WARNING: Keep ue open
when operating unit.
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, operate
or service this log set. Improper use
of this log set can cause serious
injury or death from burns, re,
explosion, electrical shock and
carbon monoxide poisoning.
DANGER: Carbon monoxide
poisoning may lead to death!
Carbon Monoxide Poisoning: Early signs of carbon
monoxide poisoning resemble the u, with head-
aches, dizziness or nausea. If you have these signs,
the log set may not be working properly. Get fresh
air at once! Have log set serviced. Some people
are more affected by carbon monoxide than others.
These include pregnant women, people with heart
or lung disease or anemia, those under the inuence
of alcohol and those at high altitudes.
Natural Gas: Natural gas is odorless. An odor-
making agent is added to the gas. The odor helps
you detect a gas leak. However, the odor added to
the gas can fade. Gas may be present even though
no odor exists.
Make certain you read and understand all warnings.
Keep this manual for reference. It is your guide to
safe and proper operation of this log set.
WARNING: Any change to
this log set or its controls can
be dangerous.
WARNING: Do not use a blow-
er insert, heat exchanger insert or
other accessory not approved for
use with this appliance.
WARNING: This appliance is
equipped for natural gas. Field
conversion is not permitted.
WARNING: Do not allow fans
to blow directly into the replace.
Avoid any drafts that alter burner
ame patterns.
Due to high temperatures, the
appliance should be located out
of trafc and away from furniture
and draperies.
Do not place clothing or other
ammable material on or near
the appliance. Never place any
objects on the heater.
Log set becomes very hot when
running. Keep children and adults
away from hot surface to avoid
burns or clothing ignition. Log
set will remain hot for a time after
shutdown. Allow surface to cool
before touching.
Carefully supervise young chil-
dren when they are in the room
with log set.
You must operate this log set with
a replace screen in place. Make
sure replace screen is closed
before running log set.
Keep the log set area clear and
free from combustible materials,
gasoline and other ammable
vapors and liquids.
Children and adults should be
alerted to the hazard of high tem-
perature and should stay away to
avoid burns or clothing ignition.

www.desatech.com 114370-01D4
1. This appliance, as supplied, is for use with
NATURAL GAS ONLY. This appliance is
NOT convertible for use with other gases.
2. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do not use
any phone in your building
• immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions
• if you cannot reach your gas supplier, call
the re department
3. Never install the log set
• in a recreational vehicle
• where curtains, furniture, clothing or other
ammable objects are less than 42" from the
front, top or sides of the log set.
• in high trafc areas
• in windy or drafty areas
4. Before installing in a solid fuel burning re-
place, the chimney ue and rebox must be
cleaned of soot, creosote, ashes and loose paint
by a qualied chimney cleaner. Creosote will
ignite if highly heated. Inspect chimney ue
for damage. If damaged, repair ue before
operating appliance.
5. You must operate this log set with replace
screen in place and fully closed.
6. This log set is designed to be smokeless. If
logs ever appear to smoke, turn off appliance
and call a qualied service person. Note:
During initial operation, slight smoking could
occur due to log curing and the burning of
manufacturing residues. You may wish to add
more ventilation by opening a window.
7. To reduce the creation of soot, follow the instruc-
tions in Cleaning and Maintenance, page 10.
8. The installation and provisions for combustion
and ventilation air must conform with the Na-
tional Fuel Gas Codes, ANSI Z233.1/NFPA 54,
Section 5.3, Air for combustion and Ventilation.
9. Do not run log set
• where ammable liquids or vapors are used
or stored
• under dusty conditions
10. Do not burn solid fuel in the replace after
installing the log set. Do not use this log set
to cook food or burn paper or other objects.
SAFETy INFORMATION
Continued
11. To help prevent breakage, new logs must be
broken-in (see Curing Logs, page 10)
12. Do not use heater if any part has been exposed
to or under water. Immediately call a qualied
service technician to inspect the room heater
and to replace any part of the control system and
any gas control which has been under water.
13. Turn log set off and let cool before servicing,
installing or repairing. Only a qualied service
person should install, service or repair log set.
14. Provide adequate clearances around air
openings.
LOCAL CODES
Install and use log set with care. Follow all local
codes. In the absence of local codes, use the lat-
est edition of the National Fuel Gas Code ANSI
Z223.1/NFPA 54*
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Battery march park
Quincy, MA 02269
UNPACkING
CAUTION: Do not remove the
data plates from the grate as-
sembly. The data plates contain
important warranty and safety
information.
1. Remove logs, hearth kit, pan materials and
hardware from carton.
2. Remove all protective packaging applied to logs
and base for shipment.
3. Check all items for any shipping damage. If
damaged, promptly inform dealer where you
bought appliance.

www.desatech.com
114370-01D 5
PRODUCT
IDENTIFICATION
WARNING: Failure to posi-
tion the parts in accordance
with these diagrams or failure
to use only parts specically
approved with this appliance
may result in property damage
or personal injury.
Figure 1 - Product Identication (Ramp
Pan Burner)
Log Set
Assembly
Grate
Chassis
INSTALLATION
WARNING: Before installing
in a solid fuel burning replace,
the chimney ue and rebox
must be cleaned of soot, creo-
sote, ashes and loose paint by a
qualied chimney cleaner. Creo-
sote will ignite if highly heated. A
dirty chimney ue may create and
distribute soot within the house.
Inspect chimney ue for damage.
If damaged, repair ue damper
before operating appliance.
NOTICE: Installation, service and
repair of this appliance must be
performed by a qualied installer,
service agency, company or
gas supplier experienced with
this type of gas appliance. Only
factory authorized components
listed in these instructions may
be used in accordance with the
manufacturer's instructions and
all codes and requirements of
the authority having jurisdiction.
Any modications to or use of
unauthorized components or
accessory items will void the
manufacturer’s warranty and may
result in a hazardous condition.
CHECK GAS TYPE
Use only natural gas. If your gas supply is not
natural gas, DO NOT install this gas log set.
If the replace does not have a gas supply shutoff
valve, one must be installed.
WARNING: This appliance is
equipped for natural gas. Field
conversion is not permitted.
FLUE OPENING SPECIFICATIONS
Note: This vented appliance must be installed
only in a solid-fuel burning replace constructed
of noncombustible material.
The charts in Figure 2, page 6 indicate technical
information regarding the installation of your gas
log set. Please make sure that all of the specica-
tions shown are applicable before installation is
attempted.
The replace must include a ue and venting
system with the minimum openings shown in
Figure 2, page 6.
Ceramic
Burner

www.desatech.com 114370-01D6
Figure 3 - Attaching Damper Clamp
Manufactured
Fireplace
Masonry
Fireplace
Damper
Damper
Clamp
Damper
Damper
Clamp Damper
VENTING SPECIFICATIONS FOR
INSTALLATION
The replace chimney ue and vent must be draft-
ing properly. To check the vent for proper drafting:
Light a tightly rolled newspaper on one end and
place it at the inside front edge of the replace.
Observe the smoke and be sure the vent is properly
drawing it up the chimney. If the smoke spills out
into the room, extinguish the ame and remove any
obstruction until proper venting is achieved.
The chimney ue must remain open a minimum of 3"
at all times during the operation of this log set.
INSTALLING DAMPER CLAMP
Secure the damper stop clamp to the edge of the
damper as shown in Figure 3. If for any reason this
clamp doesn't work on your replace, another suit-
able clamp or permanent stop must be installed, or
the damper blade must be cut or removed.
MODEL
BURNER
DESCRIPTION
BTU
INPUT
MINIMUM VENT
OPENING
VTD-18N-JHB 18" Ramp 59,000 8" dia.
VTD-24N-JHB 24" Ramp 69,000 8" dia.
VTD-30N-JHB 30" Ramp 74,000 8" dia.
INSTALLATION
Continued
MINIMUM FIREBOX SIZES
MODEL FRONT WIDTH BACK WIDTH* DEPTH HEIGHT
VTD-18N-JHB 28" 16" 14" 18"
VTD-24N-JHB 29 3/4" 17" 15 1/2" 18"
VTD-30N-JHB 36" 27" 18" 18"
*At depth indicated
BURNER ORIFICE
LOG SIZE
NATURAL
INCHES NUMBER
18" 0.1495 25
24" 0.1570 22
30" 0.1660 19
FUEL INLET PRESSURE
SPECIFICATIONS (W.C.)
MIN. MAX.
NG 5.5" 10.5"
Figure 2 - Technical Information Charts

www.desatech.com
114370-01D 7
INSTALLATION
Continued
CONNECTING TO GAS SUPPLY
WARNING: A qualied ser-
vice person must connect heater
to gas supply. Follow all local
codes.
WARNING: Never connect
natural gas replace to private
(non-utility) gas wells. This
gas is commonly known as
wellhead gas.
Installation Items Needed
Before installing log set, make sure you have the
items listed below.
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve*
• test gauge connection*
• adjustable (crescent) wrench or pliers
• sediment trap
• tee joint
• pipe wrench
* A CSA design-certied equipment shutoff valve
with 1/8" NPT tap is an acceptable alternative to
test gauge connection. Purchase the optional CSA
design-certied equipment shutoff valve from your
dealer. See Accessories, page 15.
CAUTION: Use only new, black
iron or steel pipe. Internally-tinned
copper tubing may be used in
certain areas. Check your local
codes. Use pipe of 1/2" diameter
or greater to allow proper gas vol-
ume to heater. If pipe is too small,
undue loss of volume will occur.
Installation must include an equipment shutoff
valve, union and plugged 1/8" NPT tap. Locate NPT
tap within reach for test gauge hook up. NPT tap
must be upstream from log set (see Figure 4).
IMPORTANT: Install equipment shutoff valve
in an accessible location. The equipment shutoff
valve is for turning on or shutting off the gas to
the appliance.
Apply pipe joint sealant lightly to male NPT
threads. This will prevent excess sealant from
going into pipe. Excess sealant in pipe could result
in clogged heater valves.
WARNING: Use pipe joint
sealant that is resistant to liquid
petroleum (LP) gas.
We recommend that you install a sediment trap in
supply line as shown in Figure 4. Locate sediment
trap where it is within reach for cleaning. Install in
piping system between fuel supply and appliance.
Locate sediment trap where trapped matter is not
likely to freeze. A sediment trap traps moisture and
contaminants. This keeps them from going into
heater controls. If sediment trap is not installed or
is installed wrong, heater may not run properly.
CAUTION: Avoid damage to
gas control. Hold gas control
with wrench when connecting it
to gas piping and/or ttings.
Figure 4 - Gas Connection
* Purchase the optional CSA design-certied shutoff
valve from your dealer. See Accessories, page 13.
** Minimum inlet pressure for purpose of input
adjustment.
Approved Flexible
Gas Hose (If
allowed by local
codes)
CSA Design-
Certied
Equipment
Shutoff Valve
with 1/8" NPT
Tap*
From Gas
Meter (5" W.C.**
to 10.5" W.C.
Pressure)
3" Min.
Pipe Cap Tee
Nipple Joint
Sediment Trap

www.desatech.com 114370-01D8
INSTALLATION
Continued
CHECKING GAS CONNECTIONS
WARNING: Test all gas piping
and connections, internal and
external to unit, for leaks after
installing or servicing. Correct
all leaks at once.
WARNING: Never use an
open ame to check for a leak.
Apply a noncorrosive leak detec-
tion uid to all joints. Bubbles
forming show a leak. Correct all
leaks at once.
PRESSURE TESTING GAS SUPPLY
PIPING SYSTEM
Test Pressures In Excess Of 1/2 PSIG
(3.5 kPa)
1. Disconnect log set with its individual equip-
ment shutoff valve from gas supply piping
system.
2. Cap off open end of gas pipe where equipment
shutoff valve was connected.
3. Pressurize supply piping system by either us-
ing compressed air or opening main gas valve
located on or near gas meter.
4. Check all joints of gas supply piping system.
Apply noncorrosive leak detection uid to gas
joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Reconnect log set and equipment shutoff valve
to gas supply. Check reconnected ttings for
leaks.
Test Pressures Equal To or Less Than
1/2 PSIG (3.5 kPa)
1. Close equipment shutoff valve (see Figure 5).
2. Pressurize supply piping system by either us-
ing compressed air or opening main gas valve
located on or near gas meter.
3. Check all joints from gas meter to equip-
ment shutoff valve (see Figure 6). Apply
noncorrosive leak detection uid to all joints.
Bubbles forming show a leak.
4. Correct all leaks at once.
Figure 5 - Equipment Shutoff Valve
Equipment
Shutoff
Valve
Open
Closed
Figure 6 - Checking Gas Joints
HEARTH KIT ASSEMBLY AND
INSTALLATION
1. Determine which side the gas line will be
coming into the replace.
NOTICE: Unit comes preassembled with gas
inlet on right side. If your replace gas supply
is on the left, gas inlet should be repositioned
to left side of unit.
2. If gas supply line in your replace is on the right
side, continue to step 3. If not, see Reposition-
ing the Gas Inlet to the Left Side of Unit.
3. Install adapter tting that comes with log set
into replace gas supply pipe (see Figure 7).
Seal using thread sealant.
Figure 7 - Connecting Adapter to Gas
Supply
Gas
Connector
Tube
Adapter
Fitting
Gas Inlet
Fitting
Equipment
Shutoff Valve
Gas Meter

www.desatech.com
114370-01D 9
INSTALLATION
Continued
4. Place log set assembly in center of replace
oor. Make sure front faces forward.
5. Install gas connector tube into gas supply t-
ting. Carefully shape tube to attach to adapter
tting being careful not to kink tube.
6. Install provided gas connector tube into the
gas inlet tting (see Figure 7, page 8).
7. Test for leaks following instructions under
Testing Burner for Leaks, page 10.
Repositioning Gas Inlet to Left Side of
Unit
1. Remove venturi and gasket by unscrewing
two screws under chassis (see Figure 8).
2. Unthread elbow fitting from orifice (see
Figure 8).
3. Remove orice and brackets by unscrewing two
screws on right side of unit (see Figure 8).
4. Install orice and brackets into left side of unit
using screws removed in step 1.
5. Install venturi and gasket under bottom burner
and into repositioned orice and brackets (see
Figure 8).
6. Thread elbow tting back into orice. Apply
thread sealant to orice threads (see Figure 8).
7. Install gas connector tube that comes with log
set into gas inlet tting (see Figure 8).
8. Install supplied brass adapter tting that comes
with log set into replace gas supply pipe. Use
thread sealant (see Figure 8).
9. Place log set assembly in center of replace
oor. Make sure front faces forward.
10. Install gas connector tube into gas supply t-
ting. Carefully shape tube to attach to adapter
tting. Be careful not to cause kinks in tube.
11. Test for leaks following instructions under
Testing Burner for Leaks, page 10.
TESTING BURNER FOR LEAKS
1. Generously apply noncorrosive leak detection
uid to all connections.
WARNING: Never check for
gas leaks with open ame.
2. Light burner with shutoff valve no more than
half open and holding a match slightly in front
of the pan (see Lighting Instructions).
3. Inspect all connections for bubbles, raw gas
odors, or flame from any area other than
burner. If leaks are detected, shut off gas valve
immediately. Tighten or reassemble the loose
connections using pipe joint compound until
burner system is leak free.
4. When nished testing, turn gas shutoff valve
OFF to extinguish all ames.
Figure 8 - Repositioning Gas Inlet to Left
Side of Unit
Outer
Bracket
Gasket
Venturi
Screws Inner
Brackets Orice
Elbow
Fitting
Elbow
Fitting
Inner Brackets
Orice
Gasket
Venturi
Screws
Chassis
Chassis

www.desatech.com 114370-01D10
OPERATING APPLIANCE
FOR YOUR SAFETY
READ BEFORE LIGHTING
WARNING: Keep ue open
when operating unit.
WARNING: If you do not fol-
low these instructions exactly,
a re or explosion may result
causing property damage, per-
sonal injury or loss of life.
A. BEFORE LIGHTING smell all around the
appliance area for gas. Be sure to smell next
to the oor because some gas is heavier than
air and will settle on the oor.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
• If you cannot reach your gas supplier, call
the re department.
B. Do not use this appliance if any part has been
under water. Immediately call a qualied
service technician to inspect the appliance and
to replace any part of the control system and
any gas control which has been under water.
LIGHTING
INSTRUCTIONS
1. STOP! Read the safety information,
above.
2. Turn gas shutoff valve to OFF.
3. Wait ve (5) minutes to clear out any gas.
If you then smell gas, STOP! Follow "A"
in the safety informatio, column 1. If you
don't smell gas, go on the next step.
4. Light a match and lay it on top of pan
material about 2" from end of supply side
of pan.
5. Slowly turn gas shutoff valve ON until the
burner ignites. If burner does not ignite
within 10 seconds with the match burning,
turn shutoff valve OFF and repeat steps 1
through 4 again.
GAS SHUTOFF
VALVE OPERATION
Flame Adjustment
Adjust ame ON/OFF by turning gas shutoff
valve counterclockwise to open and
clockwise to close as necessary.
Shutting Off Appliance
Turn gas shutoff valve clockwise to OFF
position.
CURING
LOGS
During the 2-3 hour appliance break in period,
you may detect an odor from appliance as the
various paints and compounds used in the manu-
facturing of this log set cure. This is a normal
and temporary situation that is not cause for
alarm. However, you may want to provide extra
ventilation to the room during this time.
To ensure proper curing of logs:
• Ignite a 2" ame and maintain for 1 hour
• Burn logs in consecutive 1 hour periods rais-
ing ame an additional 2" to full height for
a total of 3 hours.
CLEANING AND
MAINTENANCE
• Keep area around log set clean and clear of
debris.
• Occasionally use a soft bristle brush to clean
logs.
• Once every year a qualied agency or certied
chimney sweep should examine and clean the
venting system of the replace.

www.desatech.com
114370-01D 11
TROUBLESHOOTING
WARNING: Turn off log set and let cool before servicing. Only a
qualied service person should service and repair log set.
Note: All troubleshooting items are listed in order of operation.
POSSIBLE CAUSE REMEDY
OBSERVED PROBLEM
1. Poor fuel quality
2. Fireplace venting system not
drafting properly
3. Improper fuel/air mix
4. Excessive gas supply or pres-
sure
1. Passage of air or gas across
irregular surfaces
1. Incorrect gas supply or pres-
sure
2. Blocked burner orifice or
burner manifold
3. Improper burner orice size
Log set is smoking/sooting ex-
cessively (Note: It is natural and
unavoidable for vented gas log
sets to produce moderate levels
of carbon (soot) where ames
contact logs.
Burner is excessively noisy
(Note: The movement and com-
bustion of gas will create low,
unavoidable levels of noise.)
Burner ame is too low or too
high
1. Contact local gas supplier
2. Adjust damper wide open and/
or have replace and venting
professionally cleaned and
checked
3. Remove any foreign items from
ame pattern and/or check for
proper orice sizing
4. Preheat flue in very cold
weather.
1. Relieve any tight bends or
kinks in gas supply line
1. Check for proper gas supply
pressure
2. Free burner orice and mani-
fold ports of any burrs, paint
or other blockage
3. Verify proper burner orice
sizing (see Figure 2, page 6)

www.desatech.com 114370-01D12
OBSERVED PROBLEM
Log set produces a clicking/tick-
ing noise just after burners are lit
or shut off
Log set produces unwanted
odors
Gas odor even when control knob
is in OFF position
Gas odor during combustion
REMEDY
1. This is common with most
appliances. If noise is
excessive, contact qualified
service person
1. Open window to ventilate
room. Stop using odor causing
products while appliance is
running
2. Locate and correct all leaks
(see Checking Gas Connec-
tions, page 8)
1. Locate and correct all leaks
(see Checking Gas Connec-
tions, page 8)
2. Replace control valve or gas
control
1. Locate and correct all leaks
(see Checking Gas Connec-
tions, page 8)
POSSIBLE CAUSE
1. Metal expanding while
heating or contracting while
cooling
1. Log set burning vapors
from paint, hair spray,
glues, cleaners, chemicals,
new carpet, etc. (See
IM PORTANT statement
above)
2. Gas leak. See Warning
statement at top of
page
1. Gas leak. See Warning
statement at top of
page
2. Control valve or gas control
defective
1. Gas leak. See Warning
statement at top of
page
TROUBLESHOOTING
Continued
WARNING: If you smell gas
• Shut off gas supply.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor’s phone. Fol-
low the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re department.
IMPORTANT: Operating log set where impurities in air exist may create odors. Cleaning supplies, paint,
paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc., create fumes. These
fumes may mix with combustion air and create odors. These odors will disappear over time.

www.desatech.com
114370-01D 13
ACCESSORIES
Purchase these appliances from your local dealer.
If they can not supply these accessories, call DESA
at 1-866-672-6040 for referral information. You
can also write to the address listed on the back
page of this manual.
SERVICE HINTS
When Gas Pressure is Too Low
• pilot will not stay lit
• burners will have delayed ignition
• heater will not produce specied heat
You may feel your gas pressure is too low. If so,
contact your local natural gas supplier.
TECHNICAL SERVICE
You may have further questions about installation,
operation or troubleshooting. If so, contact DESA’s
Technical Service Department at 1-866-672-6040.
When calling please have your model and serial
numbers of your heater ready.
You can also visit DESA’s technical services web
site at www.desatech.com.
REPLACEMENT PARTS
Note: Use only original replacement parts. This
will protect your warranty coverage for parts
replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product. If they
can’t supply original replacement part(s), call DESA’s
Technical Service Department at 1-866-672-6040.
When calling DESA, have ready
• your name and address
• model and serial numbers of your log set
• how log set was malfunctioning
• type of gas used (propane/LP or natural gas)
• purchase date
Usually, we will ask you to return the part to the
factory.
PARTS NOT UNDER WARRANTY
Contact authorized dealers of this product. If they
can’t supply original replacement part(s), call
DESA at 1-866-672-6040 for referral information.
When calling DESA, have ready
• model number of your log set
• the replacement part number
EqUIPMENT SHUTOFF VALVE
GA5010
Equipment shutoff valve with 1/8" NPT tap. Fits
1/2" pipe.
LAVA ROCK - GA6060
(Not Shown)
Order when additional rock is desired (1.8 lb. bag).

www.desatech.com 114370-01D14
ILLUSTRATED PARTS BREAkDOWN
MODELS VTD-18N-JHB, VTD-24N-JHB AND VTD-30N-JHB
1
2
3
4
5
5
6
7
8
9
10
11
12
13
13
13
13

www.desatech.com
114370-01D 15
PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 13 of this manual.
KEY
NO. PART NO. DESCRIPTION QTY.
1 112801-01 Chassis • 1
112801-02 Chassis • 1
112801-03 Chassis • 1
2 ** Grate • • • 1
3 112372-07 Venturi/Shutter • 1
112372-08 Venturi/Shutter • 1
112372-09 Venturi/Shutter • 1
4 112804-03 Bracket • • • 1
5 112804-04 Plate • • • 1
6 901057-01 Brass Elbow • • • 1
7 112371-09 Orice • 1
112371-10 Orice • 1
112371-11 Orice • 1
8 112370-01 Gasket • • • 1
9 901232-01 Flexible Connector • • • 1
10 112832-01 Ceramic Burner • 1
112832-02 Ceramic Burner • 1
112832-03 Ceramic Burner • 1
11 112833-01 Log Assembly • 1
112834-02 Log Assembly • 1
112834-03 Log Assembly • 1
12 14325 Brass Elbow • • • 1
13 111800-01 Screw, #10 Self THD • • • 6
PARTS AVAILABLE - NOT SHOWN
112363-01 Log Scrap Kit #1 • • • 1
112364-01 Log Scrap Kit #2 • • • 1
GA6060 Lava Rock • • • 1
901242-01 Damper Clamp • • • 1
114371-01 Warning Plate • • • 1
114366-02 Rating Plate • 1
114366-05 Rating Plate • 1
114366-08 Rating Plate • 1
112799-01 Ember Flakes Kit • • • 1
26839 Rock Wool • • • 1
**Not a eld replaceable part
VTD-18N-JHB
VTD-24N-JHB
VTD-30N-JHB

2701 Industrial Drive
P.O. Box 90004
Bowling Green, KY 42102-9004
www.desatech.com
NOT A UPC
Hearth Kit Model
Log Set Model
Serial No.
Date Purchased
114370-01
Rev. D
01/06
WARRANTy INFORMATION
kEEP THIS WARRANTy
Always specify model and serial numbers when communicating with the factory.
We reserve the right to amend these specications at any time without notice. The only warranty applicable is our
standard written warranty. We make no other warranty, expressed or implied.
LIMITED WARRANTy
VENTED GAS LOGS
DESA warrants this product to be free from defects in materials and components (four (4) years for the burner system
and a lifetime for the logs) from the date of rst purchase, provided that the product has been properly installed,
operated and maintained in accordance with all applicable instructions. To make a claim under this warranty the
Bill of Sale or cancelled check must be presented.
This warranty is extended only to the original retail purchaser. This warranty covers the cost of part(s) required to
restore this heater to proper operating condition and an allowance for labor when provided by a DESA Authorized
Service Center. Warranty part(s) MUST be obtained through authorized dealers of this product and/or DESA who
will provide original factory replacement parts. Failure to use original factory replacement parts voids this war-
ranty. The heater MUST be installed by a qualied installer in accordance with all local codes and instructions
furnished with the unit.
This warranty does not apply to parts that are not in original condition because of normal wear and tear or parts that
fail or become damaged as a result of misuse, accidents, lack of proper maintenance or defects caused by improper
installation. Travel, diagnostic cost, labor, transportation and any and all such other costs related to repairing a
defective heater will be the responsibility of the owner.
TO THE FULL EXTENT ALLOWED BY THE LAW OF THE JURISDICTION THAT GOVERNS THE SALE
OF THE PRODUCT; THIS EXPRESS WARRANTY EXCLUDES ANY AND ALL OTHER EXPRESSED
WARRANTIES AND LIMITS THE DURATION OF ANY AND ALL IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE TO FOUR (4)
YEARS ON BURNER SYSTEM AND A LIFETIME ON LOGS FROM THE DATE OF FIRST PURCHASE;
AND DESA’S LIABILITY IS HEREBY LIMITED TO THE PURCHASE PRICE OF THE PRODUCT AND
DESA SHALL NOT BE LIABLE FOR ANY OTHER DAMAGES WHATSOEVER INCLUDING INDIRECT,
INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of
incidental or consequential damages, so the above limitation on implied warranties or exclusion or limitation on
damages may not apply to you.
This warranty gives you specic legal rights and you may also have other rights that vary from state to state.
For information about this warranty write:
114370 01
