Desa VI33NR Quick start guide

Save this manual for future reference.
WARNING: If the information in this manual is not
followedexactly,afireorexplosionmayresultcaus-
ing property damage, personal injury, or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Donottouchanyelectricalswitch;donotuse
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• Ifyoucannotreachyourgassupplier,callthe
fire department.
— Installation and service must be performed by
aqualifiedinstaller,serviceagency,orthegas
supplier.
WARNING:Improperinstallation,
adjustment, alteration, service,
ormaintenancecancauseinjury
orpropertydamage.Refertothis
manual for correct installation
andoperationalprocedures. For
assistance or additional infor-
mation consult a qualified in-
staller, service agency, or the
gas supplier.
WARNING: This is an unvented
gas-fired heater. It uses air (oxy-
gen) from the room in which it is
installed.Provisionsforadequate
combustion and ventilation air
mustbeprovided.Referto Airfor
CombustionandVentilation sec-
tion on page 4 of this manual.
VI33NR
REMOTE READY
GAS FIREPLACE
INSERT Shown with GS38
Surround Kit and
G8010 Brick Liner
Accessories
Patent Pending
UNVENTED (VENT-FREE)
NATURAL GAS
FIREPLACE INSERT
OWNER’S OPERATION AND INSTALLATION MANUAL
®

2
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
SAFETY
INFORMATION
DANGER: Carbon monoxide
poisoning may lead to death!
CarbonMonoxidePoisoning:Earlysignsof
carbon monoxide poisoning resemble the flu,
with headaches, dizziness, or nausea. If you
havethesesigns,thefireplaceinsertmaynotbe
workingproperly.Getfreshairatonce!Have
fireplaceinsertserviced.Somepeoplearemore
affectedbycarbonmonoxidethanothers.These
includepregnant women, peoplewithheartor
lung disease or anemia, those under the influ-
ence of alcohol, and those at high altitudes.
Natural Gas: Natural gas is odorless. An
odor-making agent is added to the gas. The
odor helps you detect a gas leak. However,
theodor addedtothe gascanfade. Gasmay
be present even though no odor exists.
Make certain you read and understand all
warnings.Keepthismanualforreference.It
isyourguidetosafeandproperoperationof
this fireplace insert.
WARNINGS
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, oper-
ate, or service this fireplace in-
sert. Improper use of this fire-
place insert can cause serious
injury or death from burns, fire,
explosion, electrical shock, and
carbon monoxide poisoning.
1. This appliance is only for use with the
type of gas indicated on the rating plate.
Thisappliance is notconvertible foruse
with other gases.
2. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do
not use any phone in your building
• immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions
• if you cannot reach your gas supplier,
call the fire department
3. Thisfireplaceinsert shall notbeinstalled
in a bedroom or bathroom.
4. Do not use this fireplace insert as a
wood-burning fireplace. Use only the
logs provided with the fireplace insert.
5. Do not addextra logsor ornamentssuch
aspinecones,vermiculite, or rock wool.
Usingthese added items cancause soot-
ing. Do not add lava rock around base.
Rock and debris could fall into the con-
trol area of fireplace insert.
6. This fireplace insert is designed to be
smokeless.Iflogsever appear to smoke,
turn off fireplace insert and call a quali-
fied service person. Note: During ini-
tial operation, slight smoking could oc-
cur due to log curing and burning of
manufacturing residues.
7. To prevent the creation of soot, follow
the instructions in Cleaning and Main-
tenance, page 21.
8. Before using furniture polish, wax, car-
pet cleaner, or similar products, turn
heater off. If heated, the vapors from
these products may create a white pow-
der residue within burner box or on ad-
jacent walls or furniture.
9. This fireplace insertneedsfresh air ven-
tilation to run properly. This fireplace
insert has an Oxygen Depletion Sens-
ing (ODS) safety shutoff system. The
ODS shuts down the fireplace insert if
not enough fresh air is available. See
Air for Combustion and Ventilation,
pages 4 through 6. If fireplace insert
keeps shutting off, see Troubleshoot-
ing, pages 17 through 19.
10. Do not run fireplace insert
• whereflammableliquidsorvapors are
used or stored
• under dusty conditions
11. Do not use this fireplace insert to cook
food or burn paper or other objects.
WARNING: Any change to
this heater or its controls can be
dangerous.
WARNING: Do not allow fans
to blow directly into the fireplace
insert. Avoid any drafts that alter
burnerflamepatterns.Ceilingfans
cancreatedrafts thatalterburner
flamepatterns.Alteredburnerpat-
terns can cause sooting.
WARNING:Donotuseablower
insert, heat exchanger insert, fire-
placehood,orotheraccessorynot
approvedforusewiththisfireplace.
Due to high temperatures, the
appliance should be located out
oftrafficand awayfrom furniture
and draperies.
Do not place clothing or other
flammable material on or near
the appliance. Never place any
objects on the heater.
Fireplace insert front and screen
becomes very hot when running
fireplaceinsert.Keepchildrenand
adults away from hot surfaces to
avoid burns or clothing ignition.
Fireplaceinsertwillremainhotfor
atimeaftershut-down.Allowsur-
faces to cool before touching.
Carefully supervise young chil-
dren when they are in the room
with fireplace. When using the
hand-held remote accessory,
keep selector switch in the OFF
positiontopreventchildrenfrom
turning on burners with remote.
You must operate this fireplace
insert with the fireplace insert
screen and hood in place. Make
sure fireplace insert screen and
hood are in place before running
fireplace insert.
Keeptheapplianceareaclearand
free from combustible materials,
gasoline,andotherflammableva-
pors and liquids.
WARNING: Any outside air
ductsand/orashdumpsinthefire-
placemustbepermanentlyclosed
before installing fireplace insert.
WARNING: Before installing
in a solid fuel burning fireplace,
the chimney flue and fireplace
must be cleaned of soot, creo-
sote, ashes, and loose paint by a
qualified chimney cleaner.

3
105647
OWNER’S MANUAL
For more information, visit www.desatech.com
PRODUCT
IDENTIFICATION
LOCAL CODES
Install and use fireplace insert with care.
Followalllocalcodes.Intheabsenceoflocal
codes, use the latest edition of The National
Fuel Gas Code ANSI Z223.1/NFPA 54*.
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
UNPACKING
CAUTION: Donotremovethe
warning and instruction labels
attached to the heater base as-
sembly. These markings contain
important warranty information.
1. With utility knife, cut the carton all the
way around above the staples on the
bottom tray. Lift the carton off the
heater. Remove packing. Note: The
hood is located in the packing on the
right hand side of the heater front. Lift
the heater off the bottom tray.
2. Locate two screws above top corners
of the fireplace insert screen. Remove
and discard these screws. Lift fireplace
insert screen up and pull out to remove.
3. Remove protective packaging applied
to logs, log base assembly, and fire-
place insert.
4. Remove fireplace inserthood from car-
ton insert.
5. Check all items for any shipping dam-
age.Ifdamaged,promptlyinformdealer
where you bought fireplace insert.
REMOTE CONTROL
ACCESSORIES
Therearefour optional remotecontrols that
can be purchased separately for this fire-
place insert:
• wall switch
• wall thermostat
• hand-held ON/OFF remote
• hand-held thermostat remote
See Accessories, page 26.
Figure 1 - Log Base Assembly
Figure 2 - Fireplace Insert
Top Louver
Assembly
Firebox
Hood
Bottom Louver Assembly
Screen
Assembly
Top Outer
Casing
Firebox
Support
Blower
Assembly
Gas Line
Access
AUTO
ON
OFF
COOLER
WARMER
TEMP
O
F
F
P
I
L
O
T
O
N
H
I
L
O
One Piece
Log Set
Remote Selector
Switch (Optional)
Piezo
Ignitor
Optional
Remote
Control
Control
Knobs
SAFETY
INFORMATION
Continued
12. Do not use fireplace insert if any part has
been exposed to or under water. Immedi-
atelycall a qualifiedservice technicianto
inspect the fireplace insert and to replace
any part of the control system and any
gas control which has been under water.
13. Do not operate fireplace insert if any log
isbroken. Donotoperate fireplaceinsert
if a log is chipped (dime-sized or larger).
14. Turn fireplace insert off and let cool
before servicing. Only a qualified ser-
vice person should service and repair
fireplace insert.
15. Operating fireplace insert above eleva-
tions of 4,500 feet could cause pilot
outage.

4
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
AIR FOR
COMBUSTION AND
VENTILATION
Today’s homes are built more energy effi-
cient than ever. New materials, increased
insulation, and new construction methods
helpreduceheatlossinhomes.Homeowners
weather strip and caulk around windows and
doorstokeepthecoldairoutandthewarmair
in. During heating months, home owners
want their homes as airtight as possible.
While it is good to make your home energy
efficient,yourhomeneedstobreathe.Fresh
air must enter your home. All fuel-burning
appliances need fresh air for proper com-
bustion and ventilation.
Exhaustfans,fireplaces,clothesdryers,and
fuel burning appliances draw air from the
house to operate. You must provide ad-
equate fresh air for these appliances. This
will insure proper venting of vented fuel-
burning appliances.
PROVIDING ADEQUATE
VENTILATION
The following are excerpts from National
Fuel Gas Code NFPA 54/ANSI Z223.1, Sec-
tion5.3,AirforCombustionandVentilation.
Allspacesinhomesfallintooneofthethree
following ventilation classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on pages 4 through 6 will
help you classify your space and provide
adequate ventilation.
Unusually Tight Construction
The air that leaks around doors and win-
dows may provide enough fresh air for
combustion and ventilation. However, in
Confined and Unconfined Space
The National Fuel Gas Code ANSI Z223.1/
NFPA 54 defines a confined space as a
space whose volume is less than 50 cubic
feet per 1,000 Btu per hour (4.8 m3per kw)
of the aggregate input rating of all appli-
ances installed in that space and an uncon-
fined space as a space whose volume is not
less than 50 cubic feet per 1,000 Btu per
hour (4.8 m3per kw) of the aggregate input
rating of all appliances installed in that
space.Roomscommunicatingdirectlywith
the space in which the appliances are in-
stalled*, through openings not furnished
with doors, are considered a part of the
unconfined space.
*Adjoiningroomsarecommunicatingonly
iftherearedoorlesspassagewaysorventila-
tion grills between them.
PRODUCT
FEATURES
OPERATION
This vent-free fireplace insert is clean burn-
ing.Itrequiresnooutsideventing.Thereisno
heat loss out a vent or up a chimney. Heat is
generated by both realistic flames and glow-
ing embers. When used without the blower,
the fireplace insert requires no electricity
making it ideal for emergency backup heat.
SAFETY DEVICE
This fireplace insert has a pilot with an
Oxygen Depletion Sensing (ODS) safety
shutoffsystem. The ODS/pilotisa required
featureforvent-freeroomheaters.TheODS
system shuts off the fireplace insert if there
is not enough fresh air.
PIEZO IGNITION SYSTEM
Thisfireplaceinserthasapiezoignitor.This
system requires no matches, batteries, or
other sources to light fireplace insert.
BLOWER ASSEMBLY
This fireplace insert is equipped with a
blower assembly. The blower operates
thermostatically and has a variable control.
The blower circulates heated air from the
fireplaceinsertintotheroom.Useofblower
is optional.
WARNING: This heater shall
notbeinstalledinaconfinedspace
or unusually tight construction
unless provisions are provided
foradequatecombustionandven-
tilation air. Read the following in-
structions to insure proper fresh
air for this and other fuel-burning
appliances in your home.
buildings of unusually tight construction,
you must provide additional fresh air.
Unusually tight construction is de-
fined as construction where:
a. walls and ceilings exposed to the
outside atmosphere have a con-
tinuous water vapor retarder with
a rating of one perm (6 x 10-11 kg
per pa-sec-m2) or less with open-
ings gasketed or sealed
and
b. weather stripping has been
added on openable windows and
doors and
c. caulking or sealants are applied
to areas such as joints around
window and door frames, be-
tween sole plates and floors,be-
tween wall-ceiling joints, be-
tween wall panels, at penetra-
tionsforplumbing,electrical,and
gas lines, and at other openings.
If your home meets all of the three
criteria above, you must provide ad-
ditional fresh air. See Ventilation Air
From Outdoors , page 6 .
If your home does not meet all of the
threecriteriaabove,proceedto Deter-
mining Fresh-Air Flow for Fireplace
Location on page 5.

5
105647
OWNER’S MANUAL
For more information, visit www.desatech.com
AIR FOR
COMBUSTION AND
VENTILATION
Continued
DETERMINING FRESH-AIR FLOW FOR FIREPLACE LOCATION
Determining if You Have a Confined or Unconfined Space
Use this work sheet to determine if you have a confined or unconfined space.
Space: Includes the room in which you will install fireplace plus any adjoining rooms with doorless passageways or ventilation grills
between the rooms.
1. Determine the volume of the space (length x width x height).
Length x Width x Height = _________________cu. ft. (volume of space)
Example: Space size 22 ft. (length) x 18 ft. (width) x 8 ft. (ceiling height) = 3168 cu. ft. (volume of space)
If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of
the space.
2. Multiply the space volume by 20 cubic feet to determine the maximum Btu/Hr the space can support.
_________________ (volume of space) x 20 cu. ft. = (Maximum Btu/Hr the space can support)
Example: 3168 cu. ft. (volume of space) x 20 cu. ft. = 63.3 or 63,360 (maximum Btu/Hr the space can support)
3. Add the Btu/Hr of all fuel burning appliances in the space.
Vent-free fireplace ___________________ Btu/Hr
Gas water heater* ___________________ Btu/Hr
Gas furnace ___________________ Btu/Hr
Vented gas heater ___________________ Btu/Hr
Gas fireplace logs ___________________ Btu/Hr
Other gas appliances* +___________________ Btu/Hr
Total = ___________________ Btu/Hr
* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.
4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.
_____________ Btu/Hr (maximum the space can support)
_____________ Btu/Hr (actual amount of Btu/Hr used)
Example: 63,360 Btu/Hr (maximum the space can support)
73,000 Btu/Hr (actual amount of Btu/Hr used)
ThespaceintheaboveexampleisaconfinedspacebecausetheactualBtu/HrusedismorethanthemaximumBtu/Hrthespacecansupport.
You must provide additional fresh air. Your options are as follows:
A. Rework work sheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoin-
ing room or add ventilation grills between rooms. See Ventilation Air from Inside Building, page 6.
B. Vent room directly to the outdoors. See Ventilation Air from Outdoors, page 6.
C. Install a lower Btu/Hr fireplace, if lower Btu/Hr size makes room unconfined.
If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no
additional fresh air ventilation.
Continued
Example:
Gas water heater 40,000 Btu/Hr
Vent-free fireplace +33,000 Btu/Hr
Total =73,000 Btu/Hr
WARNING:Iftheareainwhichtheheatermaybeoperatedissmallerthanthatdefinedasanunconfinedspace
or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of
themethodsdescribedinthe NationalFuelGasCode,ANSIZ223.1/NFPA54,Section5.3 orapplicablelocalcodes.

6
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
AIR FOR
COMBUSTION AND
VENTILATION
Continued
VENTILATION AIR
Ventilation Air From Inside
Building
Thisfreshairwouldcomefromanadjoining
unconfined space. When ventilating to an
adjoining unconfined space, you must pro-
vide two permanent openings: one within
12" of the ceiling and one within 12" of the
floor on the wall connecting the two spaces
(seeoptions1and2,Figure3).Youcanalso
remove door into adjoining room (see op-
tion 3, Figure 3). Follow the National Fuel
Gas Code NFPA 54/ANS Z223.1, Section
5.3, Air for Combustion and Ventilation for
required size of ventilation grills or ducts.
Figure 4 - Ventilation Air from Outdoors
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two per-
manent openings: one within 12" of the
ceiling and one within 12" of the floor.
Connecttheseitemsdirectlytotheoutdoors
orspacesopentotheoutdoors.Thesespaces
include attics and crawl spaces. Follow the
National Fuel Gas Code NFPA 54/ANS
Z223.1, Section 5.3, Air for Combustion
and Ventilation for required size of ventila-
tion grills or ducts.
IMPORTANT: Do not provide openings
for inlet or outlet air into attic if attic has a
thermostat-controlled power vent. Heated
air entering the attic will activate the power
vent.Anyoutsideairductsand/orashdumps
in the fireplace shall be permanently closed
at the time of appliance installation.
Figure 3 - Ventilation Air from Inside Building
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills
Into Adjoining
Room,
Option 1
12"
12"
Outlet
Air Ventilated
Attic
Outlet
Air
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
WARNING: Before installing
in a solid fuel burning fireplace,
thechimneyflueandfireboxmust
be cleaned of soot, creosote,
ashes,andloosepaintbyaquali-
fied chimney cleaner.

7
105647
OWNER’S MANUAL
For more information, visit www.desatech.com
INSTALLATION
Note: Your Vanguard fireplace insert is de-
signed to be used in zero clearance installa-
tions.Wallorframingmaterialcanbeplaced
directly against any exterior surface on the
rear, sides, or top of your fireplace insert,
except where standoff spacers are integrally
attached. If standoff spacers are attached to
your insert, these spacers can be placed di-
rectly against wall or framing materials.
IMPORTANT: Vent-freeheatersaddmois-
ture to the air. Although this is beneficial,
installingfireplaceinroomswithoutenough
ventilation air may cause mildew to form
from too much moisture. See Air for Com-
bustion and Ventilation, pages 4 through 6.
IMPORTANT: Make sure the fireplace in-
sert is level. If fireplace insert is not level,
log set will not work properly.
CHECK GAS TYPE
Use only natural gas. If your gas supply is
not natural gas, do not install fireplace in-
sert.Calldealerwhereyoubought fireplace
insert for proper type fireplace insert.
ELECTRICAL HOOKUP
(Blower Accessory)
This fireplace insert includes a blower assem-
bly with an electrical cord. The electrical cord
isfivefeetinlength.Youmustlocatefireplace
insert within reach of a 120 volt grounded
electrical outlet. If not, install and properly
ground GA3555, three-prong 120 volt electri-
cal outlet, in fireplace insert. Follow instruc-
tionsincludedinkit(seeAccessories,page26).
CAUTION:Thisfireplaceinsert
creates warm air currents. These
currents move heat to wall sur-
faces next to fireplace insert. In-
stalling fireplace insert next to vi-
nylorclothwallcoveringsoroper-
ating fireplace insert where impu-
rities(suchastobaccosmoke,aro-
matic candles, cleaning fluids, oil
or kerosene lamps, etc.) in the air
exist, may discolor walls.
WARNING: A qualified ser-
vicepersonmustinstallfireplace
insert. Follow all local codes.
WARNING: Never install the
fireplace insert
•in a bedroom or bathroom
•in a recreational vehicle
•where curtains, furniture,
clothing, or other flammable
objectsarelessthan42inches
from the front, top, or sides of
the fireplace insert
•in high traffic areas
•in windy or drafty areas
NOTICE: This heater is intended
for use as supplemental heat.
Use this heater along with your
primary heating system. Do not
install this heater as your pri-
mary heat source. If you have a
centralheatingsystem, youmay
run system’s circulating blower
whileusingheater.Thiswillhelp
circulatetheheatthroughoutthe
house. In the event of a power
outage, you can use this heater
as your primary heat source.
Continued
CAUTION: Close masonry
fireplacedampersecurelybefore
installingfireplaceinsert.Ifchim-
ney does not have a damper,
blockorcaptopofchimney.Fail-
uretocapanopenchimneycould
cause drafts that can affect the
heater’s performance and in-
crease surface temperatures.
INSTALLING SURROUND KIT
(GS38 or GS43)
Shoulder
Screw
Screen Mounting
Shoulder Screw (4)
Figure 5 - Removing Screws and Screen
CAUTION: A GS38 or GS43
surround kit accessory must be
installed on this fireplace insert
before installing into your ma-
sonry fireplace or wall opening.
Note: Use the accessory which best covers
the existing masonry fireplace opening or
wall opening.
• Model GS38 Surround Kit (for use with
fireplaces with an opening smaller than
30" H and 38" W)
• Model GS43 Surround Kit (for use with
fireplaceswithan opening 30" to36 3/4" H
and 38" to 43" W)
1. Using a 5/16" nut driver, remove two
shoulder screws and screen (see Fig-
ure 5). Remove 5/16" screen mount-
ing shoulder screws (do not discard).
2. Remove log packaging from firebox
cavity.
3. Alignholesinleftsurroundsidepanelwith
screenmounting screwholes. Replace5/
16" screen mounting shoulder screws re-
moved in step 1 (see Figure 6). Do not
tighten. Install Phillips screws in bottom
(see Figure 6). Repeat for right side.
Figure 6 - Attaching Left Surround Side
Panel
Surround Side
5/16" Screws
Phillips Screws

8
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
INSTALLATION
CLEARANCES
WARNING:Maintainthemini-
mum clearances. If you can, pro-
vide greater clearances from
floor, ceiling, and adjoining wall.
INSTALLATION
Continued
4. Using Phillips screwdriver, remove
four screws attaching brass louver. In-
stall one Phillips head screw (included
with kit) in each side (see Figure 7).
5. Align top panelscrew holes.Install four
Phillips screws, do not tighten.
6. For model GS43, align six screw holes
in side panels with holes in top panel
(see Figure 9). For model GS38, align
two screw holes in side panels with
holes in top panel (see Figure 9). Insert
and tighten screws.
7. Carefully inspect fireplacesurroundas-
sembly. Make sure each part fits prop-
erly. Firmly tighten all screws installed
during assembly.
CAUTION:Donotovertighten.
Metal can bend, warp, or break
under excessive strain.
8. Remove three piecesof brass trimfrom
packaging.
9. Locate four brass screws, two adjust-
ing plates with set screws, and two
shims in the brass hardware packet.
10. Align shim under adjusting plate as
shown in Figure 10.
11. Slide one end of adjusting plate/shim
in slot of top brass trim (see Figure 10).
12. Slide other end of adjusting plate/shim
in slot on mitered edge of side brass
trim (see Figure 10).
13. While firmly holding edges of brass
trim together, tighten both set screws
on the adjusting plate with slotted
screwdriver.
14. Repeat for other side.
15. Line up holes in brass trim with holes
on side panels of fireplace surround
assembly. Attach with brass-plated
screws.
16. Move fireplace insert and surround as-
sembly to masonry fireplace opening.
Makesure fireplace insertandsurround
assembly fit properly.
Figure 7 - Remove Brass Louver
Brass Louver
Phillips Screws
Top Surround Panel
Louver Screw Holes
Figure 9 - Attaching Side Panels to Top
Panel (GS43 Pictured)
Top Panel
Side Panel
Figure 8 - Attaching Top Surround Panel
Phillips
Screws (4)
Top Brass
Trim
Figure 10 - Assembling Brass Trim
Slot
Side Brass
Trim
Set Screws
Adjusting
Plate
Slot Mitered
Edge
Shim
Figure 11 - Installing Hood to Firebox
INSTALLING HOOD
Install hood to top of firebox as shown in
Figure 11. Use 7 Phillips screws provided.
Screws
Carefullyfollowtheinstructionsbelow.This
will ensure safe installation.
Minimum Clearances For Side
Combustible Material, Side Wall,
and Ceiling
A. Clearances from the sideof the fireplace
cabinetto any combustiblematerial and
wallshouldfollowdiagraminFigure12.
Example: Thefaceofamantel,bookshelf,
etc. is made of combustible material and
protrudes 3 1/2" from the wall. This com-
bustiblematerialmust be 4" fromthe side
of the fireplace opening (see Figure 12).
B. Clearancesfrom thetopof thefireplace
openingto the ceilingshouldnot be less
than 42 inches.
Figure 12 - Minimum Clearance for
Combustible to Wall
*Minimum 16 inches from Side Wall
*
Example

9
105647
OWNER’S MANUAL
For more information, visit www.desatech.com
35"
17 1/4"
26 1/4"
Supplied Hood Must
Be Used at All Times
Wire-mesh
Screen
Fireplace Noncombustible
Material May
Project Off this
Surface above
the Insert Hood
Mantel Shelf
13" 16" 19" 21"
2 1/2"
6"
8"
10"
;
;
;
Fireplace Insert
Note: All vertical
measurements are
from top of insert hood
opening to bottom
of mantel shelf.
Wall board or facing
material (above
fireplace) may be of
combustible material,
including decorative
mantel ornaments or
other similar projec-
tions off of the facing
material.
INSTALLATION
Continued
Continued
Figure 13 - Rough Opening for Installing
in Masonry Fireplace
FIREPLACE INSERT
INSTALLATION INTO
MASONRY FIREPLACE
Installation of this fireplace insert involves
installing fireplace insert into an existing ma-
sonry fireplace. If using a mantel above the
fireplace,youmustfollowtheclearancesshown
inFigure14. Follow theinstructions belowto
install the fireplace insert in this manner.
1. Use dimensions shown in Figure 13 for
the masonry fireplace opening.
2. Install and properly ground GA3555,
three-prong 120 volt electrical outlet, in
fireplace insert. Follow instructions in-
cludedin kit (seeAccessories, page26).
3. Installgaspipingtofireplacelocation.This
installation includes an approved flexible
gas line (if allowed by local codes) after
the equipment shutoff valve.The flexible
gas line must be the last item installed on
the gas piping. See Installing Gas Piping
to Fireplace Location, page 10.
4. Carefully set fireplace insert in front of
masonry fireplace with back of insert
inside wall opening.
5. Attach flexible gas line to gas supply.
SeeConnecting FireplaceInsert toGas
Supply, page 10.
6. Plug electrical cord into electrical out-
let installed in step 2.
7. Carefully place fireplace insert into
masonry fireplace.
8. Check all gasconnections forleaks. See
Checking Gas Connections, page 11.
9. Install brass trim after final finishing
and/or painting of wall (see Figure 11,
page 8).
Figure14-MinimumMantelClearancesforFireplaceInsertInstallation
Minimum
Fireplace
Insert Opening
Height 25 9/16" 26 1/4"
Front Width 34 5/16" 35"
Depth 16 11/16" 17 1/4"
FIREPLACE INSERT
INSTALLATION INTO
FRAMED-IN ENCLOSURE
Installation of this fireplace insert involves
installing fireplace insert into a framed-in
enclosure. If using a mantel above the fire-
place, you must follow the clearances shown
in Figure 14. Follow these instructions to
install the fireplace insert in this manner.
Insert Framing
Height 25 9/16" 26 1/4"
Front Width 34 5/16" 35"
Depth 16 11/16" 17 1/4"
1. Frame in rough opening. Use dimen-
sionsshown inFigure 15for the rough
opening.
2. Install and properly ground GA3555,
three-prong120voltelectricaloutlet, in
fireplace insert. Follow instructions in-
cludedinkit(see Accessories,page26).
35"
17 1/4"
26 1/4"
Figure 15 - Rough Opening for Installing
in Wall
3. Install gas piping into fireplace loca-
tion. This installation includes an ap-
proved flexible gas line (if allowed by
localcodes) after theequipment shutoff
valve. The flexible gas line must be the
lastitem installed onthe gaspiping.See
Installing Gas Piping to Fireplace Lo-
cation, page 10.
4. Carefully set fireplace insert in front of
rough opening with back of insert in-
side wall opening.
5. Carefully set fireplace insert into rough
opening.
6. Attach flexible gas line to gas supply.
SeeConnecting FireplaceInsert toGas
Supply, page 10.

10
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
CSA Design-
Certified Equipment
Shutoff Valve With
1/8" NPT Tap*
3" Minimum
From Gas
Meter (5"
W.C. to
10.5" W.C.
Pressure)
Supplied
Flexible Gas
Line
Cap Pipe Tee
Nipple Joint
Sediment Trap
Figure 17 - Gas Connection
* Purchase the optional CSA design-certi-
fied equipment shutoff valve from your
dealer. See Accessories, page 26.
INSTALLING GAS PIPING TO
FIREPLACE LOCATION
Installation Items Needed
Beforeinstallingfireplaceinsert,make sure
you have the items listed below.
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve *
• test gauge connection *
• sediment trap
• tee joint
• pipe wrench
• approved flexible gas line with gas connec-
tor(ifallowedbylocalcodes)(notprovided)
* ACSAdesign-certifiedequipmentshutoff
valve with 1/8" NPT tap is an acceptable
alternative to test gauge connection. Pur-
chase the optional CSA design-certified
equipment shutoff valve from your dealer.
See Accessories, page 26.
WARNING: A qualified ser-
vice person must connect fire-
place Insert to gas supply. Fol-
low all local codes.
WARNING: Never connect
fireplace insert to private (non-
utility)gaswells.Thisgasiscom-
monly known as wellhead gas.
CAUTION: Use only new,
black iron or steel pipe. Inter-
nally-tinned copper tubing may
be used in certain areas. Check
yourlocalcodes.Usepipeof1/2"
diameter or greater to allow
proper gas volume to fireplace
insert. If pipe is too small, undue
loss of pressure will occur.
CAUTION:Usepipejointseal-
ant that is resistant to liquid pe-
troleum (LP) gas.
We recommend that you install a sediment
trap in supply line as shown in Figure 17.
Locate sediment trap where it is within
reach for cleaning. Install in piping system
betweenfuelsupplyandheater.Locatesedi-
menttrap wheretrappedmatter isnotlikely
to freeze. A sediment trap traps moisture
and contaminants. This keeps them from
going into fireplace insert gas controls. If
sediment trap is not installed or is installed
wrong, fireplace may not run properly.
Installation must include an equipment
shutoff valve, and plugged 1/8" NPT tap.
Locate NPT tap within reach for test gauge
hook up. NPT tap must be upstream from
fireplace insert (see Figure 17).
IMPORTANT: Install equipment shutoff
valve in an accessible location. The equip-
ment shutoff valve is for turning on or
shutting off the gas to the appliance.
Installation Items Needed
• 5/16" hex socket wrench or nut-driver
• Phillips screwdriver
• sealant (resistant to propane/LP gas, not
provided)
1. Remove fireplace insert screen. Re-
move two screws that hold fireplace
insert screen in place for shipping.
These screws are located near top of
screen. Discard screws. Lift fireplace
insert screen up and pull out to remove.
CONNECTING FIREPLACE
INSERT TO GAS SUPPLY
INSTALLATION
Continued
NOTICE:If yourinstallationdoes
notmeettheminimumclearances
shown, you must do one of the
following:
•raise the mantel to an accept-
able height
•remove the mantel
Mantel Clearances for Insert
Installation
Ifthereisamantelabovemasonryfireplace,
youmustmeetminimumclearancebetween
mantel shelf and top of fireplace opening.
NOTICE:Surfacetemperaturesof
adjacent walls and mantels be-
comehotduringoperation.Walls
and mantels above the firebox
may become hot to the touch. If
installedproperly,thesetempera-
tures meet the requirements of
the national product standard.
Follow all minimum clearances
shown in this manual.
7. Attach fireplace to wall studs using
nails or wood screws through holes in
nailing flange (see Figure 16).
8. Check all gasconnections forleaks. See
Checking Gas Connections, pages 11
and 12.
9. Install surround kit. See Installing
Surround Kit (GS38 or GS43), pages
7 and 8.
Figure 16 - Attaching Fireplace Insert to
Wall Studs
Nails or
Wood
Screws
Nailing
Flanges
Apply pipe joint sealant lightly to male
threads. This will prevent excess sealant
fromgoing into pipe.Excess sealantinpipe
could result in clogged fireplace valves.

11
105647
OWNER’S MANUAL
For more information, visit www.desatech.com
INSTALLATION
Continued
Continued
Figure18-RemovingLogBaseAssembly
From Fireplace Insert
O
F
F
P
I
L
O
T
O
N
H
I
L
O
Burners
Two Screws
Log Base Assembly
Figure 19 - Attaching Flexible Gas Lines
Together
Flexible Gas Line from
Fireplace Gas Regulator
Provided with Fireplace Insert
To Fireplace
Gas Regulator Equipment
Shutoff Valve
➞
➞
To Gas
Meter
CHECKING GAS
CONNECTIONS
WARNING: Test all gas pip-
ing and connections for leaks
after installing or servicing. Cor-
rect all leaks at once.
WARNING:Neveruseanopen
flame to check for a leak. Apply a
mixture of liquid soap and water
toalljoints.Bubblesformingshow
a leak. Correct all leaks at once.
Pressure Testing Gas Supply
Piping System
Test Pressures In Excess Of 1/2 PSIG
(3.5 kPa)
1. Disconnect appliance with its appliance
main gas valve (control valve) and equip-
ment shutoff valve from gas supply pip-
ingsystem.Pressuresinexcessof1/2psig
willdamagefireplace insert gas regulator.
2. Cap off open end of gas pipe where
equipmentshutoffvalve wasconnected.
3. Pressurizesupply piping systembyeither
usingcompressedairoropeningmaingas
valve located on or near gas meter.
4. Check all joints of gas supply piping
system. Apply mixture of liquid soap
and water to gas joints. Bubbles form-
ing show a leak.
5. Correct all leaks at once.
6. Reconnect fireplace insert and equip-
mentshutoffvalveto gassupply. Check
reconnected fittings for leaks.
Figure 20 - Equipment Shutoff Valve
Equipment
Shutoff
Valve
Test Pressures Equal To or Less Than
1/2 PSIG (3.5 kPa)
1. Close equipment shutoff valve (see
Figure 20).
2. Pressurizesupplypipingsystembyeither
usingcompressedairoropeningmaingas
valve located on or near gas meter.
3. Check all joints from gasmeterto equip-
ment shutoff valve (see Figure 21).Ap-
ply mixture of liquid soap and water to
gasjoints.Bubblesformingshow a leak.
4. Correct all leaks at once.
Pressure Testing Fireplace
Insert Gas Connections
1. Open equipment shutoff valve (see
Figure 20).
2. Open main gas valve located on or near
gas meter.
3. Make sure control knob of fireplace
insert is in the OFF position.
4. Check all jointsfrom equipmentshutoff
valve to thermostat gas valve (see Fig-
ure 21). Apply mixture of liquid soap
and water to gas joints. Bubbles form-
ing show a leak.
5. Correct all leaks at once.
6. Light fireplace insert (see Operating
Fireplace Insert, pages 14 through 16).
Checkall otherinternal joints forleaks.
7. Turn off fireplace insert (see To Turn
Off Gas to Appliance, page 15).
Equipment
Shutoff Valve
Gas
Meter
Figure 21 - Checking Gas Joints
Manual Gas Valve
3. Route gas supply line through access
opening of fireplace insert (see Figure
2, page 3).
4. Connect gas supply line to flexible gas
line attached to gas regulator of fire-
place insert (see Figure 19). Use seal-
ant on all male pipe threads.
5. Check all gasconnections forleaks. See
Checking Gas Connections.
6. Replacelogbaseassemblybackintofire-
placeinsert.Feedflexiblegaslineintofire-
place insert base area while replacing log
base assembly. Make sure the entire flex-
iblegaslineisinfireplaceinsertbasearea.
Reattach log base assembly to fireplace
insert with screws removed in step 2.
CAUTION: Do not pick up log
base assembly by burners. This
could damage burners. Only
handle base by grates.
ON
POSITION
OFF
POSITION
Open
Closed
NOTICE: Most building codes do
not permit concealed gas con-
nections. A flexible gas line is
provided to allow accessibility
fromthefireplace(seeFigure19).
The flexible gas supply line con-
nection to the equipment shutoff
valve should be accessible.
2. Removescrewsthatattachlogbaseassem-
blytofireplaceinsert(seeFigure18).Care-
fullyliftup log base assembly andremove
from fireplace insert (see Figure 18).
Note: Ifadding the G8010 seriesbrickliner
accessory, install it now. Follow instruc-
tions in G8010 accessory kit.

12
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
Figure 22 - Installing One Piece Log Set
Figure 23 - Installing One Piece Log Set (Top View)
WARNING: After installation
andperiodicallythereafter,check
to ensure that no flame comes in
contact with any log. With the
heatersettoHigh,checktoseeif
flames contact any log. If so, re-
position logs according to the
loginstallationinstructionsinthis
manual. Flames contacting logs
will create soot.
Itisveryimportanttoinstallthelogsexactly
as instructed. Do not modify logs. Only use
logs supplied with heater.
1. Place one-piece log set on grate to fit
as illustrated in Figure 22. Make sure
middle section at bottom of log set is
seated into "U"-shaped cutout in cen-
ter of chassis (see Figure 23).
IMPORTANT: Make sure log does not
cover any burner ports.
2. Install fireplace insert screen by slip-
ping notches of fireplace insert screen
over screws on front of fireplace insert
(see Figure 24).
WARNING:Youmustoperate
this fireplace insert with the fire-
placeinsertscreeninplace.Make
sure fireplace insert screen is in
place before running fireplace
insert.
WARNING:Failuretoposition
thepartsinaccordancewiththese
diagrams or failure to use only
parts specifically approved with
this heater may result in property
damage or personal injury.
INSTALLING LOGS
INSTALLATION
Continued
CAUTION: Donotremovethe
warning and instruction labels
attached to the heater base as-
sembly. These markings contain
important warranty information.
Figure 24 - Installing Fireplace Insert Screen
Notches
Screws for Mounting
Screen
One Piece Log Set
Burner
Ports
O
F
F
P
I
L
O
T
O
N
H
I
L
O
Chassis
"U"-shaped Cutout
in Chassis
One Piece
Log Set
Burner
Middle
Section at
Bottom of
Log Set

13
105647
OWNER’S MANUAL
For more information, visit www.desatech.com
INSTALLATION
Continued
OPTIONAL WIRELESS HAND-
HELD REMOTE CONTROL
ACCESSORIES
(GHRC and GHRCTA)
Installing Remote Receiver Unit
1. Disconnect switch wires from the con-
trol valve.
2. Remove screws attaching switchplate.
3. Remove switch plate (see Figure 25).
Discard after removing.
4. Install remote receiverunitonto gaslog
heater base using mounting clips.
5. Push clips firmly into place (see Fig-
ure 26).
6. Connect wires as shown in Figure 27.
Figure 25 - Switch Plate and Wiring
Harness
Figure 28 - Installing Battery in Remote
Receiver
Screw
Switch Plate Wires
Figure 26 - Installing Remote Receiver
Installing 9-Volt Battery (Not
Included) in Hand-Held Remote
Control Unit
1. Remove battery cover on back of re-
mote control unit.
2. Attach terminal wires to the battery.
Place battery into the battery housing.
3. Replace battery coveronto remote con-
trol unit.
Figure 29 - Installing Battery in Hand-
HeldRemoteControlUnit (GHRCSeries)
Battery
Cover
9-Volt
Battery
Terminal
Wires
Remote
Control Unit
Battery
Housing
Figure 27 - Connecting Wires
Red Wire From
Receiver
Valve
White Wire
From Receiver
INSTALLING 9-VOLT
BATTERIES
Two 9-volt batteries (not included) are re-
quired to operate this heater with the wire-
less hand-held remote control set. Install
one battery in the receiver and one in the
hand-held remote control unit. Note: Only
use alkaline batteries.
Installing 9-Volt Battery (Not
Included) in Receiver
1. Locate back of receiver under front
burner of heater.
2. Locate the battery clip mounted on the
back of the receiver.
3. Slide a 9-volt battery through the clip.
4. Attach the terminalwires to thebattery.
Remote Receiver
Mounting
Clips
Remote Switch
Bracket
Battery Clip
9-Volt Battery
Terminal Wires
Remote
Receiver
Ignitor
Figure30-InstallingBatteryinHand-Held
Remote Control Unit (GHRCTA Series)
Remote
Control
Unit
Battery
Cover
9-Volt
Battery Terminal Wires

14
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
LIGHTING
INSTRUCTIONS
OPERATING
FIREPLACE INSERT
FOR YOUR SAFETY
READ BEFORE
LIGHTING
WARNING: If you do not fol-
low these instructions exactly, a
fireorexplosionmayresultcaus-
ing property damage, personal
injury or loss of life.
A. Thisappliance hasa pilotwhich must
belightedby hand.Whenlightingthe
pilot,followthese instructionsexactly.
B. BEFORE LIGHTING smell all
aroundthe applianceareaforgas. Be
sureto smellnextto thefloorbecause
some gas is heavier than air and will
settle on the floor.
WHAT TO DO IF YOU SMELL
GAS
• Do not try to light any appliance.
• Do not touch any electric switch;
donotuseanyphoneinyourbuilding.
• Immediatelycall yourgas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas sup-
plier, call the fire department.
C. Useonly your handtopush inor turn
thegas controlknob.Neveruse tools.
If the knob will not push in or turn
by hand, don’t try to repair it, call a
qualified service technician or gas
supplier. Force or attempted repair
may result in a fire or explosion.
D. Do not use this appliance if any part
has been under water. Immediately
call a qualified service technician to
inspect the appliance and to replace
any part of the control system and
any gas control which has been un-
der water.
WARNING:Youmustoperate
this heater with the fireplace in-
sert screen in place. Make sure
fireplaceinsertscreenisinstalled
before running fireplace insert.
NOTICE: During initial operation
of new fireplace insert, burning
logswillgive offa paper-burning
smell. Open damper or window
to vent smell. This will only last a
few hours.
1. STOP! Read the safety information,
column 1.
2. Make sure equipment shutoff valve
is fully open.
3. Set switch to OFF position.
4. Pressinand turn controlknob clock-
wise to the OFF position.
5. Waitfive(5) minutesto clearout any
gas. Then smell for gas, including
near the floor. If you smell gas,
STOP! Follow “B” in the safety in-
formation. If you don’t smell gas, go
to the next step.
6. Pressinand turncontrolknobcoun-
terclockwise to the PILOT
position. Press in control knob for
five (5) seconds (see Figure 31).
WARNING:Burnerswillcome
on automatically within one
minutewhen theremoteselector
switch is in the ON position after
the pilot is lit.
CAUTION:Donottrytoadjust
heatinglevelsbyusingtheequip-
ment shutoff valve.
Note: You may be running this
heater for the first time after hook-
ing up to gas supply. If so, the con-
trol knob may need to be pressed in
for 30 seconds or more. This will al-
low air to bleed from the gas system.
7. With control knob pressed in, press
and release ignitor button. This will
lightpilot.Thepilotis attachedtothe
front burner. If needed, keep press-
ing ignitor button until pilot lights.
Note: If pilot does not stay lit, con-
tact a qualified service person or gas
supplierforrepairs.Until repairsare
made,light pilotwithmatch.To light
pilot with match, see Manual Light-
ing Procedure on page 15.
8. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob.
• If control knob does not pop out
when released, contact a qualified
service person or gas supplier for
repairs.
Note: If pilotgoesout,repeatsteps
4 through 8.
9. Slightly push in and turn control
knob counterclockwise to
the ON position.
10. Wait one minute and switch selector
switch to the ON position to light
burners.
11. Set flame adjustment knob to any
level between HI and LO.
O
F
F
P
I
L
O
T
O
N
L
O
I
H
AUTO
OFF
ON
Figure 31 - Control Knob and Ignitor Button Location (Shown as Supplied,
No Control Options)
Control Knob
Ignitor Button
Selector Switch
Flame Adjustment
Knob

15
105647
OWNER’S MANUAL
For more information, visit www.desatech.com
WARNING: Make sure the
selector switch is in the OFF po-
sition when you are away from
home for long periods of time.
Heater will come on automati-
cally with selector switch in the
ON position.
Ignitor
Electrode
Pilot Burner
Figure 32 - Pilot
TO TURN OFF GAS
TO APPLIANCE
MANUAL LIGHTING
PROCEDURE
1. Followsteps1 through6under Light-
ing Instructions, page 14.
2. Depress control knob and light pilot
with match.
3. Keep control knob pressed in for 30
seconds after lighting pilot.After 30
seconds, release control knob. Now
follow steps 9 through 11, page 14.
1. Afterlighting,let pilotflame burnfor
aboutone minute.Turncontrolknob
to ON position.Adjust flame adjust-
ment knob anywhere between HI
and LO. Slide the remote selector
switchto theREMOTEposition (see
Figure 33). Note: The burners may
light if hand-held remote ON button
was on when remote selector switch
waslastturned off.You cannow turn
theburnersonand offwiththehand-
held remote control unit.
IMPORTANT : Do not leave the re-
mote selector switch in the RE-
MOTE position when the pilot is not
lit. This will drain the battery.
IMPORTANT: Be sure to press the
ON/OFF buttons on the hand-held
remote control unit for up to 3 sec-
onds to assure proper operation.
GHRC Series Operation:
2a. Pressthe ON/OFFbuttontoturnthe
burner on and off. When turning
burner off, the pilot will remain lit.
NOTICE: You must light the pilot
before using the hand-held re-
mote control unit. See Lighting
Instructions on page 14.
OPERATING
FIREPLACE INSERT
Continued
Shutting Off Heater
1. Turncontrolknobclockwise
to the OFF position.
2a. SetselectorswitchintheOFFposition.
2b. If Using Optional Hand-Held Re-
mote: Set remote selector switch in
the OFF position to keep from drain-
ing battery.
Shutting Off Burners Only (pilot
stays lit)
You may shut off the burners and keep
thepilot litby doingone ofthefollowing:
• Turn control knob clockwise
to the PILOT position.
• UseremotecontrolmanualOFFbutton.
• Set remote selector switch in the OFF
position.
OPTIONAL REMOTE
OPERATION
Thermostat Control Operation
(Optional GHRCTA Series Only) The
thermostat control setting on the remote
control unit can be set to any comfort
levelbetweenWARMERandCOOLER.
The burners will turn on and off auto-
matically to maintain the comfort level
you select. The ideal comfort setting will
vary by household depending upon the
amount of space to be heated, the output
of the central heating system, etc.
For wall thermostat operation, follow in-
struction supplied with thermostat acces-
sory GWMT1. For wall switch operation
followinstructionssuppliedwithGWMS2.
Note: Allremotecontrolaccessoriesmust
bepurchasedseparately(seeAccessories,
page 26). Follow instructions included
with the remote control.
O
F
F
P
I
L
O
T
O
N
L
O
I
H
ON
OFF
REMOTE
Figure33-SettingtheRemoteSelectorSwitch,ControlKnob,and
Flame Adjustment Knob for Remote Operation
Remote Selector Switch in Remote
Position (Optional Remote Control)
Control Knob in
On Position
Flame Adjustment Knob
Continued
Figure34 -ThermostatHand-HeldRemoteControlUnitSelections(GHRCTASeriesonly)
Increases Room
Temperature in
AUTO Mode
Decreases Room
Temperature in
AUTO Mode
Turns Burners On or
Off and Allows You
to Choose the Auto
Setting
Shows Temperature Setting
The Log Heater will
Automatically Cycle
between Pilot and the
Heat Setting that has
been Selected

16
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
Locatetheblowerswitchbyopeninglower
louver on fireplace insert. Blower switch
islocatedat lowerleft insidelouverdoor.
Thisthermostat-controlledblowerhasthree
settings: ON, OFF, and AUTO. In the ON
position,theblowerwilloperateconstantly.
In the OFF position, the blower will not
operate. In the AUTO position, the blower
will start when the thermostat senses a
sufficient increase in firebox temperature.
OPTIONAL BLOWER
OPERATION
OPERATING
FIREPLACE INSERT
Continued
Figure 35 - Correct Pilot Flame Pattern
Pilot Burner
Thermocouple
Figure 36 - Incorrect Pilot Flame Pattern
Check pilot flame pattern and burner flame
patterns often.
PILOT FLAME PATTERN
Figure 35 shows a correct pilot flame pat-
tern. Figure 36 shows an incorrect pilot
flame pattern. The incorrect pilot flame is
not properly heating the thermocouple.
When the thermocouple cools, the heater
will shut down.
If pilot flame pattern is incorrect, as shown
in Figure 36
• turn heater off (see To Turn Off Gas to
Appliance, page 15)
• see Troubleshooting, pages 17 through 19
Pilot Burner
Thermocouple
INSPECTING
BURNERS
GHRCTA Series Operation:
2b. PresstheAUTO/ON/OFFbuttononthe
hand-held remote control (see Figure
34, page15).The lightstothe leftofthe
button will showAUTO, ON, or OFF.
• In the ON mode, the burners will
ignite. The heater is in manual
mode when ON is lit.
• IntheAUTOmode,the thermostat
in the hand-held remote unit con-
trols the room temperature.To in-
creasethe room temperature,press
the top arrow of theTEMP button.
To lower the room temperature,
press the bottom arrow of the
TEMP button. At higher settings
the heater will run longer.
IMPORTANT: This remote control
has been specially engineered to
takean airtemperaturesample ev-
ery 5.5 minutes in the auto mode.
It will not respond immediately to
the temperature setting being
turned up or down.
IMPORTANT: The hand-held re-
mote control unit must be near the
heater. Do not keep the hand-held
remote control unit too close to the
heater.Thethermostaton thehand-
heldremotecontrolunitwillheatup
too quickly and turn the heater off.
3. To turn the burner off, press the
AUTO/ON/OFF button until OFF
lights. The pilot will remain lit.
IMPORTANT: To turn the pilot off,
manuallyturnthe controlknobonthe
heater to the OFF position.
BURNER PRIMARY AIR
HOLES
Air is drawn into the burner through the
holes in the fitting at the burner entrance.
These holes may become blocked with dust
or lint. Periodically inspect these holes for
any blockage and clean if needed. Blocked
air holes will create soot.
MAIN BURNER
Periodically inspect all burner flame holes
with the heater running. All slotted burner
flame holes should be open with yellow
flamepresent.Allroundburnerflame holes
should be open with a small blue flame
present. Some burner flame holes may be-
come blocked by debris or rust, with no
flame present. If so, turn off heater and let
cool. Either remove blockage or replace
burner. Blocked burner flame holes will
create soot.
BURNER FLAME PATTERN
Figure 37 shows a correct burner flame pat-
tern. Figure 38 shows an incorrect burner
flame pattern. If burner flame pattern is
incorrect,
• turn heater off (see To Turn Off Gas to
Appliance, page 15)
• seeTroubleshooting, pages 17 through 19
Figure 37 - Correct Flame Pattern with
Control Knob Set to High Flame.
Figure 38 - Incorrect Flame Pattern with
Control Knob Set to High Flame
Approx. 3-6" Above
Top of Logs
More Than 8"
Above Top of Logs
Note: Your gas logs and thermostat
blower will not turn on and off at the
same time. The fireplace insert may run
for several minutes before the blower
turns on. After the heater modulates to
the pilot position, the blower will con-
tinuetorun.Theblowerwillshutoffafter
the firebox temperature decreases.
Note: Itissafe tooperatefireplace insert
with blower turned off. However, the
blower helps distribute heated air from
the fireplace insert.

17
105647
OWNER’S MANUAL
For more information, visit www.desatech.com
TROUBLESHOOTING WARNING: Turn off heater
andletcoolbeforeservicing.Only
aqualifiedservicepersonshould
service and repair heater.
CAUTION: Never use a wire,
needle, or similar object to clean
ODS/pilot.ThiscandamageODS/
pilot unit.
POSSIBLE CAUSE
1. Ignitor electrode not connected to igni-
tor cable
2. Ignitor cable pinched or wet
3. Piezo ignitor nut is loose
4. Broken ignitor cable
5. Bad piezo ignitor
6. Ignitor electrode broken
7. Ignitor electrode positioned wrong
1. Gas supply turned off or equipment
shutoff valve closed
2. Control knob not in PILOT position
3. Control knob not pressed in while in
PILOT position
4. Air in gas lines when installed
5. ODS/pilot is clogged
6. Gas regulator setting is not correct
1. Control knob not fully pressed in
2. Control knob notpressed in longenough
3. Equipment shutoff valve not fully open
4. Pilot flame not touching thermocouple,
which allows thermocouple to cool,
causing pilot flame to go out. This prob-
lem could be caused by one or both of
the following:
A) Low gas pressure
B) Dirty or partially clogged ODS/pilot
5. Thermocouple connection loose at con-
trol valve
6. Thermocouple damaged
7. Control valve damaged
REMEDY
1. Reconnect ignitor cable
2. Free ignitor cable if pinched by any
metal or tubing. Keep ignitor cable dry
3. Tightennut holdingpiezo ignitor tobase
panel of log set. Nut is located behind
base panel
4. Replace ignitor cable
5. Replace piezo ignitor
6. Replace piezo ignitor
7. Replace piezo ignitor
1. Turn on gas supply or open equipment
shutoff valve
2. Turn control knob to PILOT position
3. Press in control knob while in PILOT
position
4. Continue holding down control knob.
Repeat igniting operation until air is
removed
5. Clean ODS/pilot (see Cleaning and
Maintenance, page 21) or replace ODS/
pilot assembly
6. Replace gas control
1. Press in control knob fully
2. After ODS/pilot lights, keep control
knob pressed in 30 seconds
3. Fully open equipment shutoff valve
4. A) Contact local natural gas company
B) Clean ODS/pilot (see Cleaning and
Maintenance, page 21) or replace ODS/
pilot assembly
5. Hand tighten until snug, then tighten
1/4 turn more
6. Replace thermocouple
7. Replace control valve
OBSERVED PROBLEM
When ignitor button is pressed, there is no
spark at ODS/pilot
When ignitor button is pressed, there is
spark at ODS/pilot but no ignition
ODS/pilot lights but flame goes out when
control knob is released
Note: For additional help, visit DESA
International’stechnicalservicewebsite
at www.desatech.com.
Note: Alltroubleshootingitemsarelistedin
order of operation.
www.desatech.com Continued

18
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
OBSERVED PROBLEM
Burner does not light after ODS/pilot is lit
Delayed ignition burner
Burner backfiring during combustion
Slightsmokeor odor during initialoperation
Moisture/condensationnoticedonwindows
Heater produces a whistling noise when
burner is lit
Whitepowderresidueformingwithinburner
box or on adjacent walls or furniture
Remote does not function (GHRC and
GHRCTA Series only)
REMEDY
1. Clean burner (see Cleaning and Mainte-
nance, page 21) or replace burner orifice
2. Contact local natural gas company
3. Replace burner orifice
4. Reconnect leads (see Wiring Diagram,
page 20)
5. Replace battery in transmitter and re-
ceiver
1. Contact local natural gas company
2. Clean burner (see Cleaning and Mainte-
nance, page 21) or replace burner orifice
1. Clean burner (see Cleaning and Mainte-
nance, page 21) or replace burner orifice
2. Replace damaged burner
3. Replace gas control
1. Check burner for dirt and debris. If
found, clean burner (see Cleaning and
Maintenance, page 21)
2. Replace gas control
3. Problem will stop after a few hours of
operation
1. Refer to Air for Combustion and Venti-
lation requirements (page 4)
1. Turn control knob to LO position and
let warm up for a minute
2. Operate burner until air is removed from
line. Have gas line checked by local
natural gas company
3. Observe minimum installation clear-
ances (see page 8)
4. Clean burner (see Cleaning and Mainte-
nance, page 21) or replace burner orifice
1. Turn heateroffwhen usingfurniture pol-
ish, wax, cleaners, or similar products
1. Replace 9-volt batteries in receiver and
remote control
TROUBLESHOOTING
Continued
POSSIBLE CAUSE
1. Burner orifice clogged
2. Inlet gas pressure is too low
3. Burner orifice diameter is too small
4. Thermopile leads disconnected or im-
properly connected
5. Burners will not come on in remote po-
sition
1. Manifold pressure is too low
2. Burner orifice clogged
1. Burner orifice is clogged or damaged
2. Damaged burner
3. Gas regulator defective
1. Not enough air
2. Gas regulator defective
3. Residues from manufacturing processes
and logs curing
1. Not enough combustion/ventilation air
1. Turning control knob to HI position
when burner is cold
2. Air in gas line
3. Air passageways on heater blocked
4. Dirty or partially clogged burner orifice
1. When heated, vaporsfrom furniture pol-
ish, wax, carpet cleaners, etc. turn into
white powder residue
1. Battery is not installed. Battery power
is low
www.desatech.com

19
105647
OWNER’S MANUAL
For more information, visit www.desatech.com
TROUBLESHOOTING
Continued
POSSIBLE CAUSE
1. Metal expanding while heating or con-
tracting while cooling
1. Fireplace insert burning vapors from
paint, hair spray, glues, cleaners, chemi-
cals,new carpet,etc.(see IMPORTANT
statement above)
2. Gas leak. See Warning statement
above
1. Not enough fresh air is available
2. Low line pressure
3. ODS/pilot is partially clogged
1. Gas leak. See Warning statement
above
2. Control valve defective
1. Foreign matter between control valve
and burner
2. Gas leak. See Warning statement
above
1. Improper log placement
2. Drafts or other air currents affecting
flame pattern
3. Air holes at burner inlet blocked
4. Burner flame holes blocked
OBSERVED PROBLEM
Fireplace insert produces a clicking/ticking
noise just after burners are lit or shut off
Fireplace insert produces unwanted odors
Fireplace insert shuts off in use (ODS
operates)
Gas odor even when control knob is in OFF
position
Gas odor during combustion
Dark residue on logs or inside of fireplace
insert. Note: After removing all causes of
residuedeposits,completelycleanfireplace
and appliance of all residue before reusing
appliance
REMEDY
1. This is common with most fireplaces. If
noise is excessive, contact qualified ser-
vice person
1. Open window and ventilate room. Stop
using odor causing products while fire-
place insert is running
2. Locate and correct all leaks (see Check-
ing Gas Connections, page 11)
1. Open window and/ordoor forventilation
2. Contact local natural gas company
3. Clean ODS/pilot (see Cleaning and
Maintenance, page 21)
1. Locate and correct all leaks (see Check-
ing Gas Connections, page 11)
2. Replace control valve
1. Take apart gas tubing and remove for-
eign matter
2. Locate and correct all leaks (see Check-
ing Gas Connections, page 11)
1. Properly locate logs (see InstallingLogs,
page 12)
2. Eliminate source of drafts around heater
3. Clean out air holes at burner inlet. Peri-
odically repeat as needed
4. Remove blockage or replace burner
WARNING: If you smell gas
•Shut off gas supply.
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your
building.
•Immediatelycallyourgassupplierfromaneighbor’sphone.Followthe
gas supplier’s instructions.
•If you cannot reach your gas supplier, call the fire department.
IMPORTANT: Operating fireplace insert where impurities in air exist may create odors.
Cleaningsupplies, paint,paintremover, cigarettesmoke, cementsand glues, newcarpet or
textiles, etc., create fumes. These fumes may mix with combustion air and create odors.
These odors will disappear over time.
www.desatech.com

20
105647
UNVENTED NATURAL GAS FIREPLACE INSERT
DESA INTERNATIONAL
For more information, visit www.desatech.com
Red
Variable
Fan Switch Fan Switch
(N.O.)
Green
White
On
110/115
V.A.C.
Blower
Motor
Black
Off
12
Black Blue
SPECIFICATIONS
VI33NR Remote Ready Insert
Btu (Variable) 20,000/30,000
Type Gas Natural Gas Only
Ignition Piezo
Pressure Manifold 3.5" W.C.
Inlet Gas Pressure (in. of water)
Maximum 10.5"
Minimum* 5"
* For input adjustment
REPLACEMENT
PARTS
Note: Use only original replacement parts.
Thiswillprotectyourwarrantycoveragefor
parts replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), call DESA International’s Techni-
calService Department at 1-866-672-6040.
When calling DESA International, have
ready
• your name and address
• model and serial numbers of your heater
• how heater was malfunctioning
• type of gas used (propane/LP or natural
gas)
• purchase date
Usually,wewillaskyoutoreturnthepartto
the factory.
PARTS NOT UNDER
WARRANTY
Contactauthorizeddealersofthisproduct. If
theycan’tsupplyoriginalreplacementpart(s),
call DESA International at 1-866-672-6040
forreferralinformation.WhencallingDESA
International, have ready
• model number of your heater
• the replacement part number
TECHNICAL
SERVICE
You may have further questions about in-
stallation, operation, or troubleshooting.
If so, contact DESA International’s Techni-
cal Service Department at 1-866-672-6040.
You can also visit DESA International’s
technical services web site at
www.desatech.com.
SERVICE HINTS
When Gas Pressure Is Too Low
• pilot will not stay lit
• burners will have delayed ignition
• heater will not produce specified heat
Youmayfeelyourgaspressureislow.Ifso,
contact your local natural gas supplier.
AUTO
OFF
ON
Thermopile
WIRING DIAGRAMS
Note : For proper operation of optional ac-
cessories, the wires from the switch to the
controlmustbeconnectedexactlyasshown
in Figure 39.
Figure 39 - Switch Wiring Diagram
Figure 40 - Blower Wiring Diagram
CAUTION:Labelallwiresprior
todisconnection whenservicing
controls.Wiringerrorscancause
improper and dangerous opera-
tion. Verify proper operation af-
ter servicing.
