Detection Systems SE88 User manual

Copyright © 2002 Detection Systems, Inc. SE88 Transmitters User’s Guide PN 48058E 06/02
Users Guide
for the
SE88 Security Escort Watch/Pendant
Panic Transmitter
Introduction
The SE88 is a personal transmitter
designed to work with the Security
Escort System. When initiated, a
signal identifying you and your
location is sent to the security office.
The SE88 may also be tested within
sight of a Receiver or Siren/Strobe by
the user.
The water resistant SE88 may be
worn like a watch, as a neck pendant
or it may be attached to a solid
surface with the optional mounting
bracket.
The Security Escort system is NOT a substitute for safe
behavior. System users should not take personal risks
under the misconception that the system will provide pro-
tection that will compensate for taking such risks.
Specifications
SE88-10S: Provides a supervisory transmission to the
Security Escort system every 11 seconds.
SE88-30S: Provides a supervisory transmission to the
Security Escort system every 32 seconds.
SE88-60M: Provides a supervisory transmission to the
Security Escort system every 65 minutes.
Battery: Lithium coin cell battery.
Duracell DL2032
Eveready CR2032
Panasonic CR2032
Operating Temperature: -4°F to +140°F (-20°C to +60°C)
Transmitting an Alarm
Use your transmitter to transmit an alarm only when you are in
danger, seriously injured, or feel threatened.
NOTE: Your personal transmitter is an emergency communication
device and should not be used
for routine communications
with the staff.
Transmitting an alarm alerts a
computer located in the security
office that you require emergency
assistance. A display on the
computer screen indicates your
identity and approximate location,
and someone is dispatched to
assist you. In some facilities, flashing strobes and audible sirens
will be activated in the vicinity of your location.
To transmit an alarm simply press the “Alarm” button for 1
second.
The LED indicator will blink to indicate an alarm has been sent.
Once the Alarm button has been pressed, the transmitter will
continue to send a signal every 7 seconds for 15 minutes. The
alarm transmission can be stopped by pressing the “Test” button
at any time.
NOTE: You do not have to point the transmitter at a Receiver, nor do
you need to be in sight of a Receiver to activate an alarm.
Testing the Transmitter
Test the transmitter weekly. To verify the transmitter’s operation:
1. You must be in sight of a Security Escort Siren/Strobe or a
Security Escort Receiver. Receivers are located inside
buildings usually within sight of an exit door. They are
mounted on walls in light beige, rectangular enclosures
bearing the Security Escort logo. Siren/Strobes are typically
mounted on outside building walls and on light poles.
Siren/Strobe and Receiver
2. Press the “Test” button on your SE88 Security Escort
Transmitter for about one second. Release after the LED
blinks.
3. Look for a flashing strobe on a Siren/Strobe or a flashing
green light on a Receiver.Aflashing green light on a Receiver
or a flashing strobe on an Siren/Strobe confirms that the
entire system is working. If you do not see the flashing light
or flashing strobe, the test was not successful.
NOTE: There may be a brief delay of two or three seconds before the
flashing light appears.
If there is no response, try the test again. If there is no response
the second time, your transmitter may not be working. Take the
transmitter to the security office.
Battery Life
Depending on the model and assuming normal usage (such
as weekly testing), the battery life should be:
Model SE88-10S = Approximately 100 days
Model SE88-30S = Approximately 200 days
Model SE88-60M = Approximately 3 years
If the battery is weak, a special signal is sent to the security
office during any test, alarm or supervisory transmission. Tests
will not produce a flashing light on a Receiver or Siren/Strobe
when your transmitter has a weak battery.
LED Indicator
Test Butto
n
Alarm Butto
n
by Detection Systems
byDetectionSystems,Inc.

Copyright © 2002 Detection Systems, Inc. SE88 Transmitters Users Guide P/N48058E
Installing (Changing) the Batteries
NO STATIC
This equipment may be damaged by static electricity.
You should use a ground strap or grounded
workstation when changing batteries.
You will need a #8 TORX®wrench to replace the batteries.
Tapping the case will make the circuit board fall out.
Insert the battery. The + (positive) side of the battery must face away
from the circuit board.
Place the circuit board into the case. Be sure the gasket is in place.
Replace the case cover. Do not overtighten the screws.
The SE88 should then be tested for proper operation.
Accessories
The following accessories are available for your SE88 Watch/Pen-
dant Transmitter:
SE88-Shortband: 8¼ in. (21 cm) wrist band.
SE88-Longband: 9¾ in. (25 cm) wrist band.
SE88-Neckband: 34 in. (86 cm) neck band.
SE88-Wallmount: Wallmount Bracket for storage or mounting the
SE88 to any solid surface.
Important Information for all Users of the Security
Escort System
Protected Areas
Check with the security department to verify the exact areas of
the facility that are protected by the system and those that are
not.
Use of Transmitter by Others
Your personal transmitter is assigned specifically to you and is
for your use only. It should not be transferred, loaned, or shared
with another individual. Before letting anyone handle your
transmitter, be sure to inform them that it is an emergency
communication device that, when activated, transmits your
identity. An officer will be dispatched to the location of the
transmitter when it is activated.
Lost or Stolen Transmitters
In the event your transmitter is lost or stolen, report the incident
immediately to the staff office so that a replacement can be
issued to you and the original transmitter can be deleted from
the system.
Tips for Better Transmission
As with all radio equipment, the signal strength from your Security
Escort Personal Transmitter will be reduced by metal and wet
surfaces. To ensure proper transmission of an alarm, hold the
transmitter away from your body and other objects, press the
alarm button for 1 second. In a vehicle, hold the transmitter close
to a window when transmitting. Do not hesitate to retransmit.
Exposure to Moisture
You should test your transmitter a few times (several hours apart)
afterithas beenexposed tomoisture toverify itis workingproperly.
Accidental Alarms
Ifyou accidentallysetoff analarm, STAY WHEREYOUARE! Wait
for the security official who responds to your alarm. Explain that
you inadvertently set off your transmitter and make it clear that
you are not experiencing an emergency.
FCC Statement
This device complies with Part 15 of the FCC Rules and with
RSS-210 of Industry and Science Canada. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept
any interference received including interference that may
cause undesired operation.
Warranty Disclaimer
Any changes or modifications to the Security Escort personal
transmitter not expressly approved by Detection Systems, Inc.
will void the product warranty.
Remove 4
screws to
replace batter
y.
Be sure the
gasket unde
r
the cover is
in place.
The circuit board
fits under this tab.
The notch in
the circuit board
must align with
this tab.
