DEVA Broadcast DB3011 User manual

MAINTENANCE AND OPERATION
INSTRUCTION MANUAL
Publish Date: 03-Jan-2018
DB3011
FM/HD Radio™ & IP Audio
Condence Monitoring Receiver

Contents
Legal Notice ........................................................................................................................................ 6
Introduction........................................................................................................................................ 7
Typographic conventions .................................................................................................................. 8
General Information.......................................................................................................................... 9
Product Features .............................................................................................................................. 10
Technical Specications ................................................................................................................ 11
Panel Indicators, Switches and Connectors................................................................................... 13
OLED Display............................................................................................................................... 13
LED Meters ................................................................................................................................... 13
Context-sensitive soft buttons........................................................................................................ 13
Navigational buttons ..................................................................................................................... 13
Rear Panel..................................................................................................................................... 14
Rear Panel Alarm Terminal .......................................................................................................... 15
Before you start ................................................................................................................................ 16
Safety warning............................................................................................................................... 16
Operating recommendations ......................................................................................................... 16
Unpacking and inspection............................................................................................................. 17
Radio Frequency Interference....................................................................................................... 17
Mounting........................................................................................................................................... 18
Rack requirements ......................................................................................................................... 18
Heat Dissipation............................................................................................................................ 18
AC Mains Power .............................................................................................................................. 19
Fuse holder.................................................................................................................................... 19
Mains Voltage Selector.................................................................................................................. 19
Power cord .................................................................................................................................... 19
Ground Loops................................................................................................................................ 19
Basic Setup........................................................................................................................................ 20
OLED Display............................................................................................................................... 20
How to change device parameters ................................................................................................ 20
Set-up menu title ...................................................................................................................... 20
Navigation area ....................................................................................................................... 20
Numerical parameter........................................................................................................... 21
Enumerated parameter ........................................................................................................ 21
IP address ............................................................................................................................ 21
IP port.................................................................................................................................. 21
Date...................................................................................................................................... 21
Time...................................................................................................................................... 21
Timer .................................................................................................................................... 22
String.................................................................................................................................... 22
Home screen.................................................................................................................................. 24
When FM Tuner is chosen and analog FM radio station is received....................................... 24
When FM Tuner is chosen and analog HD Radio station is received...................................... 25
When Internet Radio is chosen................................................................................................. 26
Main Screen working area ............................................................................................................ 27
Soft buttons.................................................................................................................................... 27
Navigation Buttons........................................................................................................................ 27

Menu Pages................................................................................................................................... 28
Soft buttons assigned functions ................................................................................................ 28
FM/HD Radio alarms .......................................................................................................... 29
IP Audio alarms ................................................................................................................... 29
Tuner ............................................................................................................................................. 30
HD Test Mode........................................................................................................................... 30
Presets ........................................................................................................................................... 31
How to create a preset.............................................................................................................. 31
Output............................................................................................................................................ 32
Setup.............................................................................................................................................. 33
Security.......................................................................................................................................... 33
Keyboard lock........................................................................................................................... 33
Keyboard unlock....................................................................................................................... 33
Monitoring..................................................................................................................................... 34
Alarms....................................................................................................................................... 34
Status ............................................................................................................................................. 36
WEB Interface.................................................................................................................................. 37
Manual IP address Identication .................................................................................................. 37
Network Discovery ........................................................................................................................ 37
Access............................................................................................................................................ 38
WEB Interface Menu pages ............................................................................................................ 39
Main .............................................................................................................................................. 39
HD Radio Reception................................................................................................................. 39
FM Radio.................................................................................................................................. 40
Internet Radio........................................................................................................................... 40
HD Radio Reception ..................................................................................................................... 41
RDS ............................................................................................................................................... 43
Total groups received indicator ................................................................................................ 43
BER........................................................................................................................................... 43
Log................................................................................................................................................. 44
Settings .......................................................................................................................................... 45
General Settings ....................................................................................................................... 45
Security ................................................................................................................................ 45
General ................................................................................................................................ 45
WEB Log.............................................................................................................................. 45
Date & Time......................................................................................................................... 45
SNTP Internet Time.............................................................................................................. 46
Average & Peak Adjustments............................................................................................... 46
WEB Audio Stream .............................................................................................................. 46
Tuner ............................................................................................................................................. 47
Tuner Frequency Step and De-emphasis ............................................................................. 47
RDS/RBDS Mode ................................................................................................................. 47
Audio Processing ................................................................................................................. 47
Internet radio ................................................................................................................................ 48
Presets ........................................................................................................................................... 49
How to make an FM Radio preset ....................................................................................... 49
How to make an Internet Radio preset ................................................................................ 49

Alarms ........................................................................................................................................... 51
Alarm notications .............................................................................................................. 52
RF, HD DAAI, HD CDNR, FM/IP Left Audio, FM/IP Right Audio Alarms ........................ 52
HD Radio Loss, Stereo Loss, IP Link, Internet Stream Alarms ........................................... 52
Communication ............................................................................................................................. 53
Network................................................................................................................................ 53
Network Status ..................................................................................................................... 53
HTTP Server ........................................................................................................................ 53
FTP Server........................................................................................................................... 54
SNMP Agent......................................................................................................................... 54
SNMP MIB File ................................................................................................................... 54
E-mail .................................................................................................................................. 54
Outputs ......................................................................................................................................... 55
Other ............................................................................................................................................. 56
Firmware Update .................................................................................................................... 56
Storage ..................................................................................................................................... 56
System Log ............................................................................................................................... 56
Factory Defaults ...................................................................................................................... 56
Reboot Device........................................................................................................................... 56
WARRANTY TERMS AND CONDITIONS................................................................................. 57
Product Registration Card.............................................................................................................. 58
APPENDIX A ................................................................................................................................... 59
Alarm Triggers .............................................................................................................................. 59
Alarm Notication......................................................................................................................... 61
Example Stereo Recover........................................................................................................... 61
Example Stereo Loss................................................................................................................. 61
Example RF .............................................................................................................................. 62
APPENDIX B ................................................................................................................................... 63
Download les via FTP................................................................................................................. 63
FTP Server Settings.................................................................................................................. 63
IP Router and Port Translation Settings .................................................................................. 63
Example of FTP Client (FileZilla) Settings.............................................................................. 64

THIS PAGE
IS INTENTIONALLY
LEFT BLANK

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 6 -
Legal Notice
HD Radio technology manufactured under license from iBiquity Digital Corporation. U.S. and
Foreign Patents. HD Radio™ and the HD, HD Radio and “Arc” logos are proprietary trademarks of
iBiquity Digital Corp.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 7 -
Introduction
DEVA Broadcast Ltd. is an international communications and high-technology manufacturing
organization, its corporate headquarters and facility located in Burgas, Bulgaria. The company
serves the broadcast and corporate markets worldwide – from consumers and small businesses to
the largest global organizations. It is dedicated to the research, design, development and provision
of advanced products, systems and services. DEVA launched its own brand back in 1997 and has
nowadays evolved to become known as a market leader and internationally reputed manufacturer
of user-friendly, cost-effective and innovative broadcast products.
Creativity and innovation are deeply woven into DEVA corporate culture. Through successful
engineering, marketing and management our team of dedicated professionals creates future-
oriented solutions to improve customers’ performance. You may rely that all issues communicated
to our crew would be addressed accordingly. We pride ourselves on our pre and post-sales support
and purchase services, which along with the outstanding quality of our radio gear have won us due
respect and the market authority position.
DEVA best-of-breed solutions have become the best sellers for our partners. The strategic
partnerships which have been formed with industry leaders during all these years that we have been
operating on the broadcasting market, have proved us a reliable business partner and a valuable
asset, as our dealers worldwide would conrm. In constant pursuit of precision and long-term
satisfaction, DEVA enhances the reputation of our partners and clients alike. Furthermore, we have
already a proven merit as a credible partner provider.
Our portfolio offers complete line of high quality and competitive products for FM and Digital
Radio, Radio Networks, Telecommunication Operators and regulation authorities. For almost
two decades of intensive software and hardware development, we have achieved a unique price-
performance and endurance of our product lines. Our company’s multitude of equipment and
services is in line with the latest technologies and key trends. The most recognizable characteristics
attributed to DEVA products are their clear-cut, streamlined design, easiness of use and cost-
effectiveness: simplicity of forms but multiplicity of functions.
For us there is no stage when we deem that we have reached the most satisfactory level in our
work. Our engineers are in constant pursuit of new ideas and technologies to be captured in DEVA
solutions. Simultaneously, a strict control is being exercised at each step of any new development.
Experience and hard work are our fundament but the continuous improving process is what we
never leave aside. DEVA participates on a regular basis in all landmark broadcasting events, not
only to promote its products, but to exchange valuable know-how and experience. We are also
engaged in international large-scale projects involving radio and audio solutions which makes us
even more competitive on the global market.
All DEVA products are developed and produced in accordance with the latest ISO 9001 quality
control standards.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 8 -
Typographic conventions
This manual uses the following typographic conventions:
Style Used for
NOTE Important notes and recommendations
Example Used when example text is cited
“Menu” on page XX. References
[OK] Interface Interactive buttons.
Settings Menu paths are represented as follows: Settings> General> Backup

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 9 -
General Information
The transition from the traditional analog transmission service to the new digital standards has
put many stations on the road to HD Radio broadcasting. The new digital services are already
proven as ensuring exceptionally high quality sound and enhancing the listening experience.
Pacing in line with the latest technologies, DEVA has designed a device to receive and monitor
FM/HD Radio and Internet radio stream.
The unmatched in performance audio system of DB3011 is equipped with two speakers to
reproduce mid- and high-range audio frequencies, and one high-efciency bass reex speaker for
high-quality sound. The DB3011 offers brilliant acoustic characteristics with extensive feature
set. The tool supports MP3, RTP and PCM IP audio codecs. In addition, DB3011 allows users
to toggle through the FM, HD Radio broadcast and online stream of the radio station to conrm
audio presence and quality in live broadcast environments. The device is compatible with the most
popular streaming media platforms, Icecast and Shoutcast included.
The DB3011 FM/HD Radio monitor provides full delity off-air monitoring and online stream
simultaneously. Radio gear of premium class, DB3011 is DEVA competitive response to the
requirements set by the transitional environment of coexistence of HD Radio broadcasting with the
traditional broadcasting. The DB3011 could be set to work in two modes: FM and Internet radio
stream monitoring mode and HD Radio broadcast and Internet radio stream monitoring mode.
The high-selective DSP-based tuner of the device allows the HD Radio broadcast, FM and
Internet stream of the station to be selected, monitored and listened to through the top-quality
speakers or headphones. This dedicated hardware will not only allow you to constantly monitor
the sound of your station, but will also measure and store for future analysis the RF level, MPX
deviation, Left & Right Audio levels values. The rear-panel alarm GPOs, E-mail and SNMP ver.2C
provides local alarm options, and online notications in case of audio loss or change in the RF,
Left and Right Audio Levels. To enhance your performance even more, the DB3011 has a built-in
FM RDS/RBDS Decoder and HD Radio PAD Decoder.
The display of the DB3011 is easy to read, high-resolution OLED graphical one and its ultra-
bright LED bargraph indicators allow reading the main signal parameters at a glance. The received
FM RDS/RBDS and HD Radio PAD are indicated on the front-panel display, along with the
readouts of the signal quality information. The intuitive front panel navigation menu and set of
four soft buttons enable the easy navigation through the menus and quick access to DB3011’s
various functions.
The tool provides fast remote monitoring and setup. Its WEB interface is accessible with no
more than a click and you will be able to listen to the FM Station, FM/HD Radio broadcast and
Internet radio stream. The setup and control of the unit could be done through your PC, tablet or
smartphone, via a standard web browser. All operating systems are supported without a compromise.
With its extensive set of features to match the latest trends, user-friendly control options and
guaranteed 24/7 operation, DB3011 is the perfect asset for any station with HD Radio transmission.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 10 -
Product Features
• FM/HD Radio™ DSP-based Tuner 87.1 - 107.9MHz
• Up to 100 dBµV direct RF Antenna Input
• Selectable wide range IF lter bandwidth
• HD Radio™ PAD (Program-Associated Data) Information
• Provision for PAD data analysis and Logging
• Selectable De-emphasis - 50µs and 75µs
• RDS and RBDS decoder with BER meter
• Wide angle, easy to read OLED display
• Very Intuitive Navigational Menu
• Quick Station access via 4 Presets
• Real Time Audio Program Streaming
• Full delity radio program monitoring in only 1RU
• Built-in WEB and FTP server
• Easy to use WEB interface
• Apple and Android devices support
• Protected access to the device settings
• Wide operating voltage range: 100-240V AC
• Bright bar graph LED metering of the RF and Audio Levels
• Headphone output with front panel level control
• Advanced Internet Radio Monitoring Capabilities
• Automatically decodes MP3, RTP and PCM IP Audio
• Support of all standard bitrates and VBR as well
• SHOUTcast / ICEcast compatible
• Automatically displays live metadata for all standards
• Adjustable alarms for Stream Loss and Internet Loss
• DSP controlled, high efcient class-D switching amplier
• Accurate 3-way speaker system
• Two mid/high frequency speakers for excellent stereo imaging.
• Active crossover for perfect separation between mid-range and bass bands
• Magnetically shielded drivers that allows placement next to video monitors
• SNTP for automatic synchronization of the built-in clock
• Level Adjustable, Balanced Analog Audio Outputs on XLR Connectors
• Professional AES/EBU Digital audio output
• LAN port for full TCP/IP remote control and monitoring
• Adjustable MIN/MAX alarms for RF, Left & Right Audio Levels
• Alarm dispatch via E-mail, SNMP ver.2C and GPO
• Firmware updates will ensure improved operation
• Multi-point screw xings ensured 19” aluminum case

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 11 -
TECHNICAL SPECIFICATIONS
IP AUDIO PLAYER
Decoder/Supported formats MPEG-1 Layer 3 and raw PCM
Sample rates 32, 44.1 and 48 kHz
Bit rates All standard bit rates, including VBR
Metadata decoder Station/Streamer’s ID, Song/Title, Stream Properties and Quality
Stream client Shoutcast/Icecast compatible TCP/IP client
FM/HD RADIO TUNER
Tuning Range 87.1 to 107.9 MHz, Frequency Agile
Tuning Step 10, 20, 50, 100 kHz
Tuner Sensitivity ≤ 10µV for 50dB monaural FM S/N
Antenna Port BNC Connectors, 50Ω
Dynamic range 100 dB
FM DEMOD
IF Filter Bandwidth Adjustable from 10kHz to 150kHz
Frequency Response ±0.1 dB, 10 Hz to 86 kHz
Dynamic range 90 dB
STEREO DECODER
Frequency Response (L and R) ±0.1 dB, 10 Hz to 15 kHz
SNR (Stereo) 60 dB, 50 µs de-emphasis
THD 0.1%, 10 Hz to 15 kHz, 50 µs de-emphasis
Stereo Separation 50 dB, 50 Hz to 10 kHz, 50 µs de-emphasis
HD RADIO
Audio Programs MPS, SPS1 to SPS7
Quality Indicators DAAI, CDNR, HD Radio lock
SIS Data Station Slogan, Station Message, Station Long Name, Station
Universal Short Name, FCCID
PAD Data Artist, Title, Album, Genre
RDS DECODER
Standards European RDS CENELEC; United States RBDS NRSC
Error Correction & Counting Yes
Decoder PI, PS, PTY, AF, RT, RT+, DI, MS, TA, TP, CT, ODA
Group Analyzer Yes
BER Analyzer Yes
Group Sequence Display Yes
RDS RAW Data Display Yes
METERING ACCURACY
RF Level 1%, 0 to 100 dBµV, 1dB resolution
Audio 1%, +5.0 to -50.0 dB, 0.1 dB resolution

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 12 -
AMPLIFIER & LOUDSPEAKERS
Conguration Three-way with stereo mid/ high-frequency drivers & mono low-
frequency driver
Power Output 2 x 6W (HF) + 12W (LF) with protective limiter
Crossover 250Hz, 24dB/octave, Linkwitz-Riley
Distortion, HF Outputs < 0.1% - 1kHz, 3W output (below limit threshold)
Distortion, LF Output < 0.05% - 100Hz, 6W output (below limit threshold)
Noise Better than -72 dB below full output
Volume Control Mute to Full, Front panel, Rotary type
Balance Trim ±32dB, Front panel, Rotary type
Peak Acoustic Level 98dB SPL @ 2ft
OUTPUTS
Analog Audio Outputs (L, R) +10 dBu, balanced XLR Connector
AES/EBU Output (L,R) 5.0 Vp-p, 110Ω, balanced XLR Connector
Alarms Programmable terminals on rear panel, Optoisolated
Headphone 6,3mm (1/4”) Phone Jack
NETWORK
Connector RJ-45
Type Ethernet
Device discovery UPnP support
MEASUREMENTS AND LOG STORAGE
Storage 2GB Build-in Memory Card
Data format Text, CSV
POWER SUPPLY
Voltage 100-240V / 50-60 Hz / 25W
Connector IEC320
SIZE AND WEIGHT
Dimensions (W;H;D) 485 x 44 x 300 mm
Shipping Weight 540 x 115 x 300 mm / 4.5kg

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 13 -
Panel Indicators, Switches and Connectors
OLED DISPLAY
DB3011 has easy to read, high-resolution OLED graphical display that visualizes all
measurements of the received signal and DB3011’s settings.
LED METERS
The full-time LED meters allow quick and easy monitoring of the metering, making the setup,
adjustment and programming easy.
CONTEXT-SENSITIVE SOFT BUTTONS
Used for navigation through the menus, quick access to the parameters, modes, functions and to
alter their values. The soft buttons indicators are placed on the bottom side of the OLED display.
Depending on the currently selected menu context the indicators change their function. The soft
buttons will be referred as (left-to-right) [SB1], [SB2], [SB3] and [SB4].
NAVIGATIONAL BUTTONS
[UP], [DOWN], [LEFT], [RIGHT] and [OK] buttons, are used to navigate through the menus
selecting various functions and parameters of DB3011.

- 14 -
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
REAR PANEL
PATENT PENDING DESIGN
CAUTION: TO PREVENT ELECTRICAL SHOCK,
DISCONNECT POWER BEFORE SERVICING
100-240VAC
50-63Hz, 25VA
GND
ALARM OUT LAN
ANTENNA LEFT
RIGHT AES/EBU
ww w.devabroadcast.com
MADE IN BULGARIA
MAX RF LEVEL
110 dB Vµ1
2
3
4
5
67
8
1. Mains connector, 110-240VAC, IEC-320 C14 type;
2. Fuse holder;
3. Ethernet T-BASE10/100 RJ45;
4. GPO – Opto-isolated, Female D-Sub 15 pins.
5. Audio AES/EBU Output - XLR;
6. Audio Left Output - XLR;
7. Audio Right Output - XLR;
8. RF Input 1 (Antenna) - BNC;

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 15 -
REAR PANEL ALARM TERMINAL
ALARM OUT
AES/EBU
12345678
9101112131415
1 - GPO1 Collector 9 - GPO1 Emitter
2 - GPO2 Collector 10 - GPO2 Emitter
3 - GPO3 Collector 11 - GPO3 Emitter
4 - GPO4 Collector 12 - GPO4 Emitter
5 - GPO5 Collector 13 - GPO5 Emitter
6 - GPO6 Collector 14 - GPO6 Emitter
7 - GPO7 Collector 15 - GPO7 Emitter
8 - GND
LOAD
1
9
GPO1
LOAD
1
9
GPO1

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 16 -
Before you start
SAFETY WARNING
• The servicing of electronic equipment should be performed only by qualied personnel;
• Before removing the covers DB3011 must be switched off and the mains cable unplugged;
• When the equipment is open, the power supply capacitors should be discharged using a
suitable resistor;
• Never touch the wires or the electrical circuits;
• Use insulated tools only;
• Never touch the metal semiconductor. They might carry high voltages;
• For removing and installing electronic components, follow the recommendations for
handling MOS components.
•
ATTENTION: DB3011 has an internal Lithium battery. Do not try to re-charge this battery!
Please contact us for detailed instructions in case the battery should be changed.
OPERATING RECOMMENDATIONS
For normal operation of DB3011, we recommend following the instructions listed below.
• Install the unit in places with good air conditioning. DB3011 is designed to operate within the
ambient temperature range of 10 to 50°C. The equipment rack should be ventilated in order
for the device to keep its internal temperature below the maximum ambient temperatures;
• We do not recommend installation in rooms with high humidity, dusty places or other
aggressive conditions;
• Locate the device away from abnormally high RF elds;
• Use only checked power supply cables. We strongly recommend the usage of shielded
cables;
• Connect DB3011 only to reliable power supply sources. In case of unstable power supply,
please use Uninterruptible Power Supply (UPS);
• Use the device only with its top cover on to avoid electromagnetic anomalies. Otherwise,
this may cause problems with the normal functionality of the unit;
• For the normal remote operation of the unit, connect DB3011 to a good quality Internet
connection;
• For the normal operation of DB3011, check if the network settings past through all the
required data trafc.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 17 -
UNPACKING AND INSPECTION
Upon receipt, the equipment should be inspected for possible shipping damages. If such are
found or suspected, notify the carrier at once and contact DEVA Broadcast Ltd. The original
shipping carton box and packing materials should be kept for possible reuse, in case of return for
Warranty repair, for example. Shipping damages as a result of improper packing for return may
invalidate the Warranty!
IT IS VERY IMPORTANT that the “Product Registration Card” included in the Manual be
completed accurately and returned. This will assure coverage of the terms of the Warranty and it will
provide a means of trace in case of lost or stolen equipment. In addition, the user will automatically
receive SERVICE OR MODIFICATION INSTRUCTIONS from DEVA Broadcast Ltd.
RADIO FREQUENCY INTERFERENCE
Although we have made provision for DB3011 installation in the immediate proximity of
broadcast transmitters, please do practice some care using the unit near abnormally high RF elds.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 18 -
Mounting
RACK REQUIREMENTS
The DB3011 mounts in a standard 19-inch equipment rack and requires only 1¾ inches (1U) of
vertical rack space. In order the painted nish around the mounting holes to be protected, the use
of plastic washers is recommended.
HEAT DISSIPATION
Having very low electricity consumption, the DB3011 itself generates negligible heat. The
unit is intended for operation within an ambient temperature range, extending from freezing to
120°F/50°C. But because adjacent, less efcient equipment may radiate substantial heat, be sure
that the equipment rack is adequately ventilated to keep its internal temperature below the specied
maximum ambient.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 19 -
AC Mains Power
FUSE HOLDER
The fuse holder is placed inside the unit, next to the voltage selector. Apply downward pressure
and pull the cap outward to access the 5mm mains fuse. The reverse process will release the cap.
MAINS VOLTAGE SELECTOR
Before connecting the AC Power, make sure that the internal Power Switch and the fuse rating
are in accordance with the mains supply at your location.
DB3011 Power Supply Factory Settings are:
- 100 - 240 VAC
- 1 Amp Fuse
CAUTION: Permanent damage will result if improper AC supply voltage is applied to DB3011
device. Your warranty does not cover damages caused by applying improper supply voltage, or use
of an improper fuse.
POWER CORD
The detachable IEC-type power cord is supplied with the unit. The individual cord conductors
may be color-coded in either of two ways:
1) In accordance with US standards:
BLACK = AC “HOT”
WHITE = AC NEUTRAL
GREEN = EARTH GROUND
2) To European CEE standards:
BROWN = AC “HOT”
BLUE = AC NEUTRAL
GREEN/YELLOW = EARTH GROUND
GROUND LOOPS
Because the unbalanced RF INPUT of the DB3011 is chassis-ground-referenced, a mains
frequency or RF ground loop could be formed between the input or output cable shield grounds
and the AC power cord ground. A ‘ground-lifting’ AC adapter may well remedy such a situation,
although the chassis somehow must be returned to earth ground for safety. Generally, being
screwed-down in the equipment rack will satisfy the safety requirement.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 20 -
Basic Setup
OLED DISPLAY
DB3011 has an easy to read, high-resolution OLED graphical display that visualizes all
measurements of the received signal and settings. Upon switching it on, the Company Logo and
model of the device will be displayed. After a few seconds the start-up screen will disappear,
replaced by the main screen. This is the starting point of the navigation process.
DB3011’s OLED display has three function areas: header, soft buttons and main screen working
area.
HOW TO CHANGE DEVICE PARAMETERS
Set-up menu title
Shows the path to the currently selected menu. Note that the parameter should be included
in the settings menu title. For example: Setup> Communication>HTTP> Port is different from
Setup> Communication>FTP>Data Port.
Navigation area
Selection of branches / parameters is made in this area. The selected item is highlighted. All
parameters are listed on the left side of the navigational area. All parameter values are displayed
on the right side against the parameter name. As the branches have no values associated, tree dots
are shown instead. This indicates that a transition to a sub-menu is available.
Front panel buttons usage:
[OK] – Depending on the selected menu element can perform different actions:
• Menu branch – transition to selected sub-menu will be made;
• Menu parameter – when the name of a parameter is illuminated, pressing [OK] will highlight
the value and switch to edit mode;
• Menu complex parameter (such as Alarm) – the parameter editor screen will be shown.
[UP] / [DOWN] – If edit mode is active, the value of the selected parameter will be changed.
Otherwise, are used for navigation through the menu;
[LEFT] / [RIGHT] – Change the selection when the parameter value is in edit mode;
[SB4] – Return one level up or cancel edit mode.
