DEVA Broadcast DB7012 User manual

MAINTENANCE AND OPERATION
INSTRUCTION MANUAL
Publish Date: 18-Dec-2020
DB7012
Professional DSP-based DAB/DAB+
Monitoring Receiver

Contents
Introduction........................................................................................................................................ 5
Typographic conventions .................................................................................................................. 6
General Information.......................................................................................................................... 7
Product Features ................................................................................................................................ 8
Technical Specications .................................................................................................................. 9
Block Diagram .............................................................................................................................. 10
Safety Precautions............................................................................................................................ 11
Panel Indicators, Switches and Connectors................................................................................... 12
OLED Display............................................................................................................................... 12
LED Meters ................................................................................................................................... 12
Context-sensitive soft buttons........................................................................................................ 12
Navigational buttons ..................................................................................................................... 12
Rear Panel..................................................................................................................................... 13
Rear Panel Alarm Terminal .......................................................................................................... 14
Before you start ................................................................................................................................ 15
Safety warning............................................................................................................................... 15
Operating recommendations ......................................................................................................... 15
Unpacking and inspection............................................................................................................. 16
Radio Frequency Interference....................................................................................................... 16
Mounting........................................................................................................................................... 17
Rack requirements ......................................................................................................................... 17
Heat Dissipation............................................................................................................................ 17
AC Mains Power .............................................................................................................................. 18
Fuse holder.................................................................................................................................... 18
Mains Voltage Selector.................................................................................................................. 18
Power cord .................................................................................................................................... 18
Ground Loops................................................................................................................................ 18
Getting Started ................................................................................................................................ 19
Connection .................................................................................................................................... 19
Network Settings............................................................................................................................ 20
Network Discovery ........................................................................................................................ 20
Basic Setup........................................................................................................................................ 21
OLED Display............................................................................................................................... 21
How to change device parameters ................................................................................................ 21
Set-up menu title ...................................................................................................................... 21
Navigation area ....................................................................................................................... 21
Home Screen.................................................................................................................................. 25
Main Screen working area ............................................................................................................ 27
Soft Buttons ................................................................................................................................... 27
Navigation Buttons........................................................................................................................ 27
Menu Pages................................................................................................................................... 28
Tuner ............................................................................................................................................. 28
Output............................................................................................................................................ 29
Setup.............................................................................................................................................. 29
Security.......................................................................................................................................... 30

Keyboard lock........................................................................................................................... 30
Keyboard unlock....................................................................................................................... 30
Monitoring..................................................................................................................................... 31
Alarms set-up – Option 1.......................................................................................................... 32
Alarms set-up – Option 2.......................................................................................................... 32
Status ............................................................................................................................................. 33
WEB Interface menu pages............................................................................................................. 34
Device control interface ................................................................................................................ 34
Main .............................................................................................................................................. 36
Loudness........................................................................................................................................ 37
Ensemble ....................................................................................................................................... 38
Service ........................................................................................................................................... 39
Band Scan...................................................................................................................................... 40
Status ............................................................................................................................................. 41
Log................................................................................................................................................. 42
General Settings ............................................................................................................................ 43
Tuner settings ................................................................................................................................ 44
Logger ........................................................................................................................................... 45
Logger Service Settings (Service 1) .............................................................................................. 46
Communication Settings................................................................................................................ 48
Outputs settings............................................................................................................................. 50
Other settings ................................................................................................................................ 51
APPENDIX A ................................................................................................................................... 52
Alarm Triggers .............................................................................................................................. 52
Alarm Notications ....................................................................................................................... 54
APPENDIX B ................................................................................................................................... 55
GSM Modem Option - Features and Usage.................................................................................. 55
Remote Status Request .................................................................................................................. 56
Initialization procedure for Sierra Wireless AirLink FXT009 GSM modem ................................ 57
1. Setting up the modem............................................................................................................ 57
2. Connecting with DEVA Unit................................................................................................. 59
APPENDIX C................................................................................................................................... 60
How should I congure the connection between my DEVA Device and an FTP Client? 60
WARRANTY TERMS AND CONDITIONS................................................................................. 62
Product Registration Card.............................................................................................................. 63

THIS PAGE
IS INTENTIONALLY
LEFT BLANK

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 5 -
Introduction
DEVA Broadcast Ltd. is an international communications and high-technology manufacturing
organization, its corporate headquarters and facility located in Burgas, Bulgaria. The company
serves the broadcast and corporate markets worldwide – from consumers and small businesses to
the largest global organizations. It is dedicated to the research, design, development and provision
of advanced products, systems and services. DEVA launched its own brand back in 1997 and has
nowadays evolved to become known as a market leader and internationally reputed manufacturer
of user-friendly, cost-effective and innovative broadcast products.
Creativity and innovation are deeply woven into DEVA corporate culture. Through successful
engineering, marketing and management our team of dedicated professionals creates future-
oriented solutions to improve customers’ performance. You may rely that all issues communicated
to our crew would be addressed accordingly. We pride ourselves on our pre and post-sales support
and purchase services, which along with the outstanding quality of our radio gear have won us due
respect and the market authority position.
DEVA best-of-breed solutions have become the best sellers for our partners. The strategic
partnerships which have been formed with industry leaders during all these years that we have been
operating on the broadcasting market, have proved us a reliable business partner and a valuable
asset, as our dealers worldwide would conrm. In constant pursuit of precision and long-term
satisfaction, DEVA enhances the reputation of our partners and clients alike. Furthermore, we have
already a proven merit as a credible partner provider.
Our portfolio offers complete line of high quality and competitive products for FM and Digital
Radio, Radio Networks, Telecommunication Operators and regulation authorities. For almost
two decades of intensive software and hardware development, we have achieved a unique price-
performance and endurance of our product lines. Our company’s multitude of equipment and
services is in line with the latest technologies and key trends. The most recognizable characteristics
attributed to DEVA products are their clear-cut, streamlined design, easiness of use and cost-
effectiveness: simplicity of forms but multiplicity of functions.
For us there is no stage when we deem that we have reached the most satisfactory level in our
work. Our engineers are in constant pursuit of new ideas and technologies to be captured in DEVA
solutions. Simultaneously, a strict control is being exercised at each step of any new development.
Experience and hard work are our fundament but the continuous improving process is what we
never leave aside. DEVA participates on a regular basis in all landmark broadcasting events, not
only to promote its products, but to exchange valuable know-how and experience. We are also
engaged in international large-scale projects involving radio and audio solutions which makes us
even more competitive on the global market.
All DEVA products are developed and produced in accordance with the latest ISO 9001 quality
control standards.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 6 -
Typographic conventions
The following table describes important conventions used in the manual.
Convention and Style Description Examples
Menu > Sub Menu >
Menu Command
A menu item(s) and menu
command that you need to click
in sequence
Click Settings > General
[Button] Interface Interactive buttons Press [OK] to save the changes
NOTE Important notes and
recommendations
NOTE: The notication will appear
only once
“Reference Name” on
Page XXX
References and links refer to “New Connection”
(see “Monitoring” on page 56)
Example Used when example text is cited Example for E-mail Notication:
Date: 04 Nov 2013, 07:31:11

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 7 -
General Information
DEVA’s DB7012 – Professional DAB/DAB+ Monitoring Receiver is an elegant and smart
monitoring solution specically developed by our engineers to fully comply with the Digital Audio
Broadcasting standard while strictly adhering to the signature features underlying the company’s
products. A highly practical design coupled with a wide range of features makes this device a
guarantee of slick and smooth performance.
As a leading manufacturer of advanced broadcasting technology, it is DEVA’s aim to constantly
supply top-of-the-range gear in keeping with the major industry trends, which is why our team
has created a top-quality line of products dedicated to Digital Radio Broadcasting. As part of that
line, the DB7012 fully meets the ETSI EN 300 401 DAB standard. Additionally, it offers support
for Program Associated Data (PAD), as well as all standard bitrates and VBR and automatically
displays live metadata. While the signal is being monitored and logged, the DB7012 measures the
following DAB signals: RSSI, SNR, CNR, FIC Quality, FIB Errors, FFT Offset and the Left &
Right Audio level values and stores them, thereby allowing for future analysis. The collected data
can easily be downloaded via a standard FTP client. As an additional feature, the tool guarantees
that there is no interruption of the broadcast signal. This is achieved through the provided local
alarm options and online notications via rear-panel alarm GPOs, E-mail and SNMP in case
there is audio loss or change in the DAB signal and the Left and Right Audio Levels. Therefore,
maintenance staff can be quick to respond and prevent prolonged signal loss.
The BandScan function of the DB7012 presents an overview of all DAB/DAB+ signals
available, plus their RF signal strength. BandScans are possible within any section of Band III.
The generated spectrum diagram shows the RF Level vs. the channels.
In addition to its wide array of features, the DB7012 receiver is easy to control and setup. The
unit can be programmed through the front-panel menu or remotely through your PC, tablet or
smart phone via a standard web browser; iOS and Android devices are also supported. The design
of the DB7012 incorporates a high-resolution OLED graphical display and three ultra-bright LED
bar graph indicators which allow for easy reading of the main signal parameters. A user-friendly
front panel menu in addition to the set of four soft buttons provides easy navigation through the
menus and quick access to each function.
Based on our engineers’ relentless pursuit of improvement and their vast experience with
delivering high-end gear to a demanding and competitive market, the DB7012 offers a successful
combination of top monitoring performance and user-friendly operation.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 8 -
Product Features
• DAB/DAB+ compliant receiver
• Support for Program Associated Data (PAD)
• Predened DAB channels scan or manual tune
• Detailed DAB component information
• High-end digital tuner
• Wide angle, easy to read OLED display
• Very Intuitive Navigational Menu
• Quick Service access via 4 Presets
• Real Time Audio Program Streaming
• Built-in easy to use WEB and FTP server
• Apple and Android devices support
• Protected access to the device settings
• Wide operating voltage range: 100-240V AC
• Bright bar graph LED metering of the RF and Audio Levels
• Headphone output with front panel level control
• SNTP for automatic synchronization of the built-in clock
• Level Adjustable, Balanced Analog Audio Outputs on XLR Connectors
• Professional AES/EBU Digital audio output
• LAN port for full TCP/IP remote control and monitoring
• Adjustable MIN/MAX alarms for RF, Left & Right Audio Levels
• Alarm dispatch via E-mail, SNMP ver.2C and GPO
• Firmware updates will ensure improved operation

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 9 -
TECHNICAL SPECIFICATIONS
DAB/DAB+ RADIO
RF frequency range 168 - 240 MHz
DAB/DAB+ Band III Channels 5A - 13F
Sensitivity 18 dBµV
Input connector BNC 50Ω
In compliance with ETSI EN 300 401
Ensemble acquisition Time 940 ms
L&R Audio 1%, +5.0 to -50.0 dB, 0.1 dB resolution
DAB/DAB+ METERING
Quality indicators RSSI, SNR, CNR, FIC Quality, FIB Errors, FFT Offset
PAD DLS, MOT
Metadata Displayed Ensemble Label, Component List & ID, Service List & ID,
Dynamic Label, PTY, Sample Rate, Bit Rate, Gain, Mode,
Service Mode, Protection Info, Current CU & Address, Country,
Language, Time & Date
OUTPUTS
Analog Audio Outputs (L, R) +10 dBu, balanced XLR Connector
AES/EBU Output (L,R) 5.0 Vp-p, 110Ω, balanced XLR Connector
Alarms Programmable terminals on rear panel, Optoisolated
Headphone 6,3mm (1/4”) Phone Jack
NETWORK
Connector RJ-45
Type Ethernet
Device discovery UPnP support
MEASUREMENTS AND LOG STORAGE
Storage 2GB Build-in Memory Card
Data format Text, CSV
POWER
Voltage 100-240V / 50-60 Hz
Power Consumption 20VA
Connector IEC320, Fused and EMI-suppressed
SIZE AND WEIGHT
Dimensions (W;H;D) 485 x 44 x 300 mm
Shipping Weight 540 x 115 x 300 mm / 2.660kg
HS Code 8527212000

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 10 -
BLOCK DIAGRAM
A simplied block diagram of DB7012 is shown below
Metering
DAB
Tuner DSP L / R
Control and
Communication
CPU
Ethernet Front panel
LED
GPO
GSM Modem
Because of the all-digital, minimalist-discrete-component nature of device circuitry, we have
not provided schematic diagrams of the DB7012 in this Manual. Please, note that:
NO USER-SERVICEABLE COMPONENTS INSIDE.
REFER ALL SERVICING TO
QUALIFIED TECHNICAL PERSONNEL.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 11 -
Safety Precautions
IMPORTANT: Carefully read this paragraph as it contains important instructions concerning
operator safety and directions regarding the installation, operation and maintenance of the
equipment. Failure to observe the safety instructions and information given in this manual
constitutes an infringement of the safety rules and design specications provided for this piece
of equipment. DEVA Broadcast Ltd. declines all responsibility if any one of the safety rules given
herein is not observed. DEVA Broadcast Ltd. declines all responsibility if the end-user resells the
product. The equipment is to be used by people capable of operating it in a trouble-free manner
and it is assumed that they are aware of the following safety rules.
◊ Keep this manual with the utmost care and close at hand so that it can be consulted whenever
needed
◊ After unpacking the equipment, check its condition.
◊ Avoid banging the equipment.
◊ The packing material (plastic bags, polystyrene, nails, etc.) must never be left within reach of
children, as these items are potential sources of danger.
◊ Do not use the equipment in places where the temperature is not within the recommended
range, as specied by the manufacturer.
◊ Before connecting the equipment, make sure the nameplate specications correspond to the
mains electricity supply (the nameplate is located on the equipment enclosure).
◊ Do not remove the sticker from the equipment as it contains important specications and the
relevant serial number.
◊ To join the equipment to the mains supply, use the power cord purchased with the equipment.
◊ The equipment must be used only for the purposes it was designed for.
◊ Abuse or misuse of the equipment is extremely dangerous for people, pets and property. The
manufacturer declines all responsibility for damage and injury resulting from improper use and
mishandling.
◊ Certain basic safety rules must be observed when using electrical equipment, in particular:
- Never touch the equipment with wet and/or damp hands or other parts of the body.
- Keep the equipment away from drops of water or sprinkling systems.
- Never use the equipment near high heat sources or explosive material.
- Do not introduce any extraneous matter into the equipment.
- Do not allow children or untrained people to use the equipment.
◊ Before cleaning or servicing the equipment outside, disconnect its power supply and wait at
least 2 seconds before working on it, as recommended by current safety regulations.
◊ In the event of faults and/or improper operation, turn off the equipment, shut off the electrical
power and call your dealer.
◊ Do not attempt to make repairs and/or adjustments when covers/guards or circuit boards are to
be removed.
◊ Call your dealer for any repairs and be certain original spare parts are used. Failure to observe
this rule may adversely affect the safety level of your equipment.
◊ The equipment is to be connected to the mains supply and provided with adequate and efcient
earth conductors.
◊ When installing, leave a clearance of at least 1 cm around the equipment to allow air to pass
freely.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 12 -
Panel Indicators, Switches and Connectors
OLED DISPLAY
DB7012 has easy to read, high-resolution OLED graphical display that visualizes all
measurements of the received signal and DB7012’s settings.
LED METERS
The full-time LED meters allow quick and easy monitoring of the metering, making the setup,
adjustment and programming easy.
CONTEXT-SENSITIVE SOFT BUTTONS
Used for navigation through the menus, quick access to the parameters, modes, functions and to
alter their values. The soft buttons indicators are placed on the bottom side of the OLED display.
Depending on the currently selected menu context the indicators change their function. The soft
buttons will be referred as (left-to-right) [SB1], [SB2], [SB3] and [SB4].
NAVIGATIONAL BUTTONS
[UP], [DOWN], [LEFT], [RIGHT] and [OK] buttons, are used to navigate through the menus
selecting various functions and parameters of DB7012.

- 13 -
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
REAR PANEL
LEFT RIGHT AES/EBU ALARM OUT LAN
GSM MODEM
100-240VAC
50-63Hz, 25VA
GND
ww w.devabroadcast.com
MADE IN BULGARIA
ANTENNA
MAX RF LEVEL
90 dB Vµ
PATENT PENDING DESIGN
CAUTION: TO PREVENT ELECTRICAL SHOCK,
DISCONNECT POWER BEFORE SERVICING 1
2
3
4
5
678
9
10
1. Mains connector, 110-240VAC, IEC-320 C14 type;
2. Fuse holder;
3. GPO – Opto-isolated, Female D-Sub 15 pins.
4. Ethernet T-BASE10/100 RJ45;
5. GSM Modem – Male D-Sub 15 pins High Density;
6. Audio AES/EBU Output - XLR;
7. Audio Right Output - XLR;
8. Audio Left Output - XLR;
9. RF Input (Antenna) - BNC;
10. GND Pin - Chassis Earth Ground;

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 14 -
REAR PANEL ALARM TERMINAL
ALARM OUT
12345678
9101112131415
LAN
1 - GPO1 Collector 9 - GPO1 Emitter
2 - GPO2 Collector 10 - GPO2 Emitter
3 - GPO3 Collector 11 - GPO3 Emitter
4 - GPO4 Collector 12 - GPO4 Emitter
5 - GPO5 Collector 13 - GPO5 Emitter
6 - GPO6 Collector 14 - GPO6 Emitter
7 - GPO7 Collector 15 - GPO7 Emitter
8 - GND
LOAD
1
9
GPO1
LOAD
1
9
GPO1

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 15 -
Before you start
SAFETY WARNING
• The servicing of electronic equipment should be performed only by qualied personnel;
• Before removing the covers DB7012 must be switched off and the mains cable unplugged;
• When the equipment is open, the power supply capacitors should be discharged using a
suitable resistor;
• Never touch the wires or the electrical circuits;
• Use insulated tools only;
• Never touch the metal semiconductor. They might carry high voltages;
• For removing and installing electronic components, follow the recommendations for
handling MOS components.
ATTENTION: DB7012 has an internal Lithium battery. Do not try to re-charge this battery!
Please contact us for detailed instructions in case the battery should be changed.
OPERATING RECOMMENDATIONS
For normal operation of DB7012, we recommend following the instructions listed below.
• Install the unit in places with good air conditioning. DB7012 is designed to operate within the
ambient temperature range of 10 to 50°C. The equipment rack should be ventilated in order
for the device to keep its internal temperature below the maximum ambient temperatures;
• We do not recommend installation in rooms with high humidity, dusty places or other
aggressive conditions;
• Locate the device away from abnormally high RF elds;
• Use only checked power supply cables. We strongly recommend the usage of shielded
cables;
• Connect DB7012 only to reliable power supply sources. In case of unstable power supply,
please use Uninterruptible Power Supply (UPS);
• Use the device only with its top cover on to avoid electromagnetic anomalies. Otherwise,
this may cause problems with the normal functionality of the unit;
• For the normal remote operation of the unit, connect DB7012 to a good quality Internet
connection;
• For the normal operation of DB7012, check if the network settings past through all the
required data trafc.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 16 -
UNPACKING AND INSPECTION
Upon receipt, the equipment should be inspected for possible shipping damages. If such are
found or suspected, notify the carrier at once and contact DEVA Broadcast Ltd. The original
shipping carton box and packing materials should be kept for possible reuse, in case of return for
Warranty repair, for example. Shipping damages as a result of improper packing for return may
invalidate the Warranty!
IT IS VERY IMPORTANT that the “Product Registration Card” included in the Manual be
completed accurately and returned. This will assure coverage of the terms of the Warranty and it will
provide a means of trace in case of lost or stolen equipment. In addition, the user will automatically
receive SERVICE OR MODIFICATION INSTRUCTIONS from DEVA Broadcast Ltd.
RADIO FREQUENCY INTERFERENCE
Although we have made provision for DB7012 installation in the immediate proximity of
broadcast transmitters, please do practice some care using the unit near abnormally high RF elds.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 17 -
Mounting
RACK REQUIREMENTS
The DB7012 mounts in a standard 19-inch equipment rack and requires only 1¾ inches (1U) of
vertical rack space. In order the painted nish around the mounting holes to be protected, the use
of plastic washers is recommended.
HEAT DISSIPATION
Having very low electricity consumption, the DB7012 itself generates negligible heat. The
unit is intended for operation within an ambient temperature range, extending from freezing to
120°F/50°C. But because adjacent, less efcient equipment may radiate substantial heat, be sure
that the equipment rack is adequately ventilated to keep its internal temperature below the specied
maximum ambient.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 18 -
AC Mains Power
FUSE HOLDER
The fuse holder is placed inside the unit, next to the voltage selector. Apply downward pressure
and pull the cap outward to access the 5mm mains fuse. The reverse process will release the cap.
MAINS VOLTAGE SELECTOR
Before connecting the AC Power, make sure that the internal Power Switch and the fuse rating
are in accordance with the mains supply at your location.
DB7012 Power Supply Factory Settings are:
- 100 - 240 VAC
- 1 Amp Fuse
CAUTION: Permanent damage will result if improper AC supply voltage is applied to DB7012
device. Your warranty does not cover damages caused by applying improper supply voltage, or use
of an improper fuse.
POWER CORD
The detachable IEC-type power cord is supplied with the unit. The individual cord conductors
may be color-coded in either of two ways:
1) In accordance with US standards:
BLACK = AC “HOT”
WHITE = AC NEUTRAL
GREEN = EARTH GROUND
2) To European CEE standards:
BROWN = AC “HOT”
BLUE = AC NEUTRAL
GREEN/YELLOW = EARTH GROUND
GROUND LOOPS
Because the unbalanced RF INPUT of the DB7012 is chassis-ground-referenced, a mains
frequency or RF ground loop could be formed between the input or output cable shield grounds
and the AC power cord ground. A ‘ground-lifting’ AC adapter may well remedy such a situation,
although the chassis somehow must be returned to earth ground for safety. Generally, being
screwed-down in the equipment rack will satisfy the safety requirement.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 19 -
Getting Started
In order for the normal operation of the DB7012 to be guaranteed, you will need fulll the
following conditions:
1. Standard Ethernet 10/100M connection;
2. Correctly assigned Network conguration and device settings.
To make sure that all the conditions are fullled please, follow the instructions below.
CONNECTION
1. Install the unit on its operation place;
2. Using the provided power cable, connect the unit to the power supply network;
3. Connect the antenna cable to the RF antenna input connector located on the rear panel of
the device;
4. Connect the DB7012 to the TCP/IP network using direct network cable;
5. Connect the optional GSM modem via the connection cable provided with the GSM modem.
In order for better GSM network coverage to be achieved, please select proper place for the
GSM antenna.
NOTE: The GSM antenna must be installed far enough from the monitoring devices. The
GSM modem radiates RF signal that may cause spurious emissions that will may interfere with
the accuracy of the measurements. For detailed explanation of the option, please refer to “GSM
Modem Option” on page 55.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: [phone], Fax: [phone]
E-mail: of[email protected] ,Web: www.devabroadcast.com
- 20 -
NETWORK SETTINGS
After connecting the network cable the Led ‘LAN’ located on the rear panel must be ON or
ashing. The next and most important step for conguration is the adjustment procedure of the
Network Communication. The settings shown below are Default Network Settings:
DHCP Enabled
IP Assigned by DHCP
Mask Assigned by DHCP
Gateway Assigned by DHCP
DNS Assigned by DHCP
HTTP Port 80
The DB7012 is controlled trough a build in WEB Server and a standard Web browser can be
used to monitor its status or to make some adjustments. To operate the device you need to know
its IP Address. In case you are not aware of it, you can use the Network discovery feature at Local
networks.
1. Connect the device to the local network or to the Internet by LAN cable;
2. Open a new WEB Browser and enter the device IP address in the address eld then press
[Enter]. A new WEB browser with DB7012’s Main window will appear;
3. To access the device’s settings press [Settings], the default values are username: admin and
password: pass.
NETWORK DISCOVERY
If you have already enabled this function on your computer just open a new Explorer bar and
click on Network. The device must be displayed. If not follow the instructions below.
1. Open Advanced sharing settings by clicking the Start button, and then on “Control Panel”.
In the search box, type “network”, click “Network and Sharing Center”, and then, in the left
panel click “Change advanced sharing settings”.
2. Select your current network prole.
3. Click Turn on network discovery, and then click Save changes. If you’re prompted for an
administrator password or conrmation, type the password or provide conrmation.
4. To access the device open a new Explorer bar and click on Network. If you have successfully
enabled the network discovery option, the device will be displayed. Double click on DB7012
will open a new WEB browser with the Main window.
5. To access the device’s settings press [Settings], the default values are username: admin and
password: pass.
NOTE: If the port is different than the default one (80), it is necessary to specify it, for example:
http://192.168.1.2:9000
ATTENTION: Depending on Internet Protocol Settings, the assigned IP address may not be
visible outside your local network, thus the device may be accessed only within that network.
Consult with your network administrator for the appropriate IP settings.
