ineo 40P
Product Guide
11.02.09

2
Product Guide – ineo 40P
Table of contents
Product Basic ...........................................................................3
Product Configuration .............................................................4
System Specifications .............................................................7
Printer Specifications...............................................................9
Consumables..........................................................................11
Article Numbers......................................................................12
Service Part.............................................................................13
Appendix.................................................................................14

3
Product Guide – ineo 40P
Product Basic
MODEL DEVELOPMENT CODE OPAL-P-H
MODEL NAME ineo 40P
SUCCESSOR MODEL FOR N/A
ESTIMATED SALES START 01/09
ALSO AVAILABLE AS KM bizhub 40P
(KM pagepro 5650EN for the open market)
TYPE desktop A4 b/w laser beam printer
MAX (PEAK) MONTHLY PAGE VOLUME 200k prints
MAX. AVERAGE/PERMANENT MONTHLY
PAGE VOLUME 16.6 k prints
MACHINE LIFE 1 Mill. prints or 5 years whichever comes first
MPBF
(Mean Prints Between Failure) 300k prints
MTTR (Mean Time To Repair) 15 minutes or less
SAFETY & ENVIRONMENT
English/German Data Sheets dBox / Marketing / Safety and Environment
PLEASE NOTICE
Standard paper weight for systems is 80 g/m2for monochrome machines and 90 g/m2for full colour ones. Since using these
standards result in optimum system performance, all specifications on performance, reliability, maintenance and replacement
based on those standard papers. Using thick papers, labels, transfer and polyester films continuously can increase the wear
and tear on replacement parts and consumables – meaning your servicing costs will go up.
Use the bypass or the lower tray from the paper feed unit when working with materials having such characteristics as
polyester films, textile transfer films and labels. Otherwise, you may be faced with double feeding or a higher number of
feeding jams.
If possible use subtray when working with materials having such characteristics as polyester films, textile transfer films and
labels. Roller-marks on the copy or print may appear or increased jams can occur. Standard paper weights yield the best
possible copy and print results. Using higher grammage may influence the quality of the output. Using standard paper weights
also guarantees that double sided copies and prints are made reliably. Different characters of films as well as thick, thin and
coated papers may increase the jam rate for double

4
Product Guide – ineo 40P
Product Configuration
SYSTEM DIMENSION

5
Product Guide – ineo 40P
SYSTEM DIMENSION
Front View
Front View

6
Product Guide – ineo 40P
SYSTEM CONFIGURATION
128/256 MB Memory
Flash Card Adapter
Hard Disk Kit
Offset Stacker
Lower Paper Feeder
Duplex Unit
Copy Desk (Cabinet)
(
onl
y
for ineo 40P
)

7
Product Guide – ineo 40P
System Specifications
FEED TRAY Standard
Paper Size A4 lengthwise, A5 lengthwise, A6 lengthwise, Custom Size
(width: 76.2 – 215.9 mm, length: 127 – 355.6 mm) – up to 900
mm,
Paper Weight 64 – 216 g/m²
Tray Capacity 150 sheets (80 g/m²)
Media Types Plain paper, recycled paper, transparency, labels, thick paper,
envelopes
CASSETTE Standard
Paper Size A4 lengthwise, A5 lengthwise. A6 lengthwise,
Paper Weight 64 – 216 g/m²
Capacity 550 sheets (80 g/m²)
Media Types Plain paper, recycled paper, transparency, labels, thick paper,
envelopes
LOWER PAPER FEEDER Option
Paper Size A4 lengthwise, A5 lengthwise. A6 lengthwise
Paper Weight 64 – 216 g/m²
Capacity 550 sheets (80 g/m²)
Media Types Plain paper, recycled paper, transparency, labels, thick paper,
envelopes
Remark up to 2 cassettes can be installed
DUPLEX UNIT Option
Paper Size A4 lengthwise, A5 lengthwise, A6 lengthwise
Paper Weight 64 – 216 g/m²
Media Types Plain paper, recycled paper, thick paper
Remark Additional 128 MB DIMM is required when the Duplex Unit is
installed.

8
Product Guide – ineo 40P
SIMPLE CABINET Option
Remark As storage for consumables and paper. Recommended, if one
or two additional cassettes are attached.
Only for ineo 40P available
OFFSET STACKER Option
Modes sort, group
Number of Bins 1
Bin Capacity 500 sheets (80 g/m²)
Paper Size Width: 89 to 216mm
Length: 140 to 356mm
Remark For sorting function hard disk or CF card is required
Hard disk kit Option
Capacity 40 GB
Remark
Hard Disk Kit enables Secure printing, Proof-then-Print & Hold,
Job Storing and XPS support in addition to all extra functions
with CF Flash card.
Either HDD kit or Flash Card adapter can be connected.
Compact Flash Card Local Procurement
Capacity 512MB/1GB or more
Recommended Supplier Kingston
Remark Flash Card can be used instead of HDD Kit for PDF Direct
Printing, JPEG/TIFF Direct Print and sorting
MEMORY EXPANSION Option
Capacity 128 MB
Remark Required if Duplex Unit is installed.
MEMORY EXPANSION Option
Capacity 256 MB
Remark Either the 128MB or the 256MB memory expansion can be
connected. The memory capacity is 384MB max.

9
Product Guide – ineo 40P
Printer Specifications
WARM-UP TIME 20 sec. or less
FIRST PRINTING TIME 9.5 sec. or less (A4 or Letter from Tray 1)
PRINT SPEED 43 ppm (A4 Simplex)
26 ppm (A4 Duplex)
RESOLUTION 600 x 600dpi x 1 bit
1200 x 1200dpi x 1 bit
MAX. PRINTABLE AREA 4 mm deletion on all edges, in case of Duplex printing
6 mm on leading edge
OUTPUT CAPACITY Face down: 500 sheets
Face up: 70 sheets
POWER REQUIREMENT 120V / 220 – 240 V, 50/60 Hz
POWER CONSUMPTION 1.3 kW or less
Printing: 910 W or less
Standby: 140 W or less
PRINTER DIMENSIONS (W x D x H) mm 421.8 x 465.4 x 404.5
PRINTER WEIGHT (kg) 25 (w/o consumables)
PROCESSOR 88F5281/500MHz
MEMORY 128 MB standard, max. 384 MB
HARD DISK 40 GB (optional)
INTERFACE 100Base-TX, 10Base-T, 1000Base-T, USB2.0 (Hi-Speed
support), IEEE 1284 (ECP support only) [1284.4 is not
supported], Host USB (USB Drive Printing)
EMULATION
PostScript3 (3016)
PCL6(XL3.0)
PCL5e/c
XPS (Version 1.0)
PDF Direct Printing (Version 1.6)
JPEG/TIFF Direct Print
NETWORK Protocols
Network Service
TCP/IP, EtherTalk, IPX/SPX, UDP
TCP/IP : IPv6
IPP1.1, SNMP, HTTP
HTTPS
WSD
IEEE 802.1x

10
Product Guide – ineo 40P
SUPPORT OS
Win 2000 (Service Pack 4 or later)
Win XP (Service Pack 2 or later)
Win XP for 64bit
Win 2003 Server
Win 2003 Server for 64bit
Vista
Vista for 64bit
Mac OSX (10.2, 10.3, 10.4)
Linux Redhat v.9.0
SUSE v.8.2
Netware 4 / 5 / 6
DRIVER
Windows 2000/XP/Server 2003/Vista PostScript Level 3
Windows XP/Server2003/Vista (64bit) PCL XL Driver
Mac OSX (10.2, 10.3, 10.4) PostScript Driver
Linux Support PS3 PPD for CUPS
UTILITIES
Download Manager
Status Monitor
OWN NETWORK UTILITIES
Device Manager
Web Connection
Network Setup
EMS Plug-in
Web Jet Admin Plug-in
Plug and Print
NDPS Gateway
Direct Print (HDD or Flash Card required)
Data Administrator
SAP R/3

11
Product Guide – ineo 40P
Consumables
AIO IMAGING CARTRIDGE
Concept All-In-One Cartridge with Toner, Starter, Drum
Name Toner cartridge
Yield (according to ISO/IEC 19752) 19k (continuous print, 5% coverage)
Units per carton 1 cartridge
Remark User replaceable
19k continuous print suitable to 16k 3 pages per job
START-UP IMAGING CARTRIDGE
Yield (according to ISO/IEC 19752) 19k
Remark User replaceable
MAINTENANCE KIT
Yield 200k
Contents Fuser Unit, Pick-up Rollers, Transfer Rollers
Remark User replaceable
IMPORTANT: The values listed in the above table indicate the average life time of the AIO Imaging Cartridge.
The life time is very much depending on printing conditions (coverage, paper size, etc.), differences in the
printing method (continuous or one page printing) and type of media.

12
Product Guide – ineo 40P
Article Numbers
Article Number
MACHINE
ineo 40P 4827000061
ACCESSORIES
Optional Cassette A0FG0Y2
Duplex Unit A0FH0Y2
Offset Stacker A0FJ0Y1
Cabinet (SCD-PB1) 9960760000
128 MB Memory 9J05152
256 MB Memory 9J05151
HDD Kit (40 GB) A08D0Y1
Compact Flash Adapter A08D0Y2
2 GB CF Flash Card Local procurement (Supplier recommendation: Kingston)
CONSUMABLES
AIO Imaging Cartridge TN412K (19K) 4827000064
Maintenance Kit A0FM0Y2

13
Product Guide – ineo 40P
Service Part
Notebook recommendation for Service support (minimum configuration)
Hardware:
Notebook, 512MB RAM, 80GB HDD (at least 30 GBs free HDD space when fully configured),
Optical Drive (CD/DVD Read & Write), PCMCIA Slot, 10/100Mbit Ethernet, USB 2.0
Software:
WinXP (rather than Vista), MS-Office, Acrobat Reader, Burning Software (Nero Suite,
IBM Record Now etc.), FTP Client (Filezilla etc.)

14
Product Guide – ineo 40P
Appendix
Media Sizes
Media Name Size (mm) 150 sheet
Input Tray 550 sheet Input Tray Lower Paper Feeder Duplex
A6 105 x 148
;;;;
A5 148 x 210
;;;;
A4 210 x 297
;;;;
B5 182 x 257 (JIS)
176 x 250 (ISO) ;;;;
B6 128 x 182
;;;;
Letter 215.9 x 279.4 ;;;;
Legal 215.9 x 355.6 ;;;;
Statement 139.7 x 215.9 ;;;;
Executive 184.2 x 267 ;;;;
Folio 210 x 330 ;;;;
Foolscap 203 x 330 ;;;;
Envelope C6 114 x 162 ;;;:
Envelope
Monarch 98.4 x 190.5 ;;;:
Envelope DL 110 x 220 ;;;:
EnvelopeC5 162 x 229 ;:::
Postcard 100 x 148 ;;;;
Custom Size 98.4 – 215.9 (w)
148 – 355.6 (l) :;;:
Custom Size 76.2 – 215.9 (w)
127 – 900 (l) ;:::
Custom Size 88.9 – 215.9 (w)
139.7 – 355.6 (l) ;::;

15
Product Guide – ineo 40P
Media Weights
Media Weight (g/m²) Input Tray
150 sheet Input Tray 550 sheet Lower Paper Feeder
Plain Paper 68 ~ 105 ;;;
Recycling Paper 68 ~ 105 ;;;
Transparency --- ;;;
Envelopes --- ;;;
Labels --- ;;;
Thick Paper I 106 ~ 159 ;;;
Thick Paper II 160 ~ 216 ;;;
Thick Paper III 106 ~ 216 ;;;
Thin Paper 64 ~ 67 ;;;
Cassette Capacity with different Media
Media Weight (g/m²) Input Tray
150 sheet Input Tray 550 sheet Lower Paper Feeder
Plain/Recycled
Paper 68 ~ 105 150 sheets 550 sheets 550 sheets
Thick Paper 216 60 sheets 160 sheets 160 sheets
Transparency --- 100 sheets 100 sheets 100 sheets
Labels --- 100 sheets 290 sheets 290 sheets
Envelopes --- 15 envelopes 80 envelopes 80 envelopes
Long Length Paper --- 1 --- ---

16
Product Guide – ineo 40P
Engine Speed (Media Size A4) ppm
Simplex
[pages per min] Duplex [images per min]
Plain Paper 43 26.4
Thick Paper I 33 24.2
Thick Paper II 13.1 13.1
Thick Paper III 21.5 ---
OHP 21.5 ---
USB Support, IEEE1284 Support
USB IEEE1284
OS Support Plug & Play OS Support Plug & Play
Windows 2000 ;;;;
Windows XP ;;;;
Windows 2003
Server ;;;;
Windows Vista ;;;;
Mac OS X
Classic mode ;;::
Mac OS X
Native Mode ;;::
Mac OS X
Server ;;::
Linux ;:;:

17
Product Guide – ineo 40P
Features/Functions requiring HDD Kit/Flash Card
HDD Kit Flash Card
PostScript Download Functions
(Font, Profile, Overlay) either or
Direct Print (PDF, JPEG, TIFF) either or
PDF Direct Printing either or
XPS yes ---
Sorting Function either or
Remark: Either the HDD Kit or the Compact Flash Adapter can be connected.
What is delivered with the machine?
ITEMS Packed at Factory Added in Europe
Start-up AIO Imaging Cartridge Yes (19k) ---
Utility & Documentation DVD Yes (multilingual) ---
Copy Tray N/A ---
Face Sheets N/A ---
Labels Pictograph labels stuck to the
machine at factory ---
Installation Guide Printed (multilingual) ---
Safety Information Guide Printed (English only) ---
Power Cable Yes (European version) ---
Connection Cables (USB, Parallel) no no

18
Product Guide – ineo 40P

19
Product Guide – ineo 40P

Note!
Since changes in technical features are
the order of the day in the world of
digital copiers and printing technology,
please note that the technical data
provided in this material was issued in
January 2009. We reserve the right to
make changes to the technical design.
Specifications refer to maximum
performance under standard conditions.
No guarantee is provided in
relation to any of the data supplied.
Your Develop Marketing
www.develop.eu
