Develop ineo+ 654 User manual

ineo
+
654/754
01.03.2012
Product Guide

Product Guide ineo+ 654/754
Table of contents
Product Basic ...............................................................................3
Product Configuration ..................................................................4
System Specifications..................................................................6
Copier Specifications .................................................................15
Printer Specifications .................................................................18
Printer Specifications (Fiery IC-414) .........................................21
Scanner Specifications ..............................................................24
Fax Specifications......................................................................26
Consumables .............................................................................31
Article Numbers and Compatibility ............................................33
Service Part................................................................................36
Appendix.....................................................................................41

3
Product Guide ineo+ 654/754
Product Basic
MODEL DEVELOPMENT CODE Minerva 0 Minerva 1
PROPOSED MODEL NAME ineo+754 ineo+654
SUCCESSOR MODEL FOR N/A ineo+652/652DS
ESTIMATED SALES START 03/2012 03/2012
INFOSOURCE SEGMENT V IV
ALSO AVAILABLE AS KM bizhub C754
Olivetti d-Color MF752 KM bizhub C654 Olivetti d-Color MF652
TYPE Console/Stationary Platen
MAX. (PEAK) MONTHLY PAGE
VOLUME Colour: 63 k
Mono: 215 k
Total: 278 k
Colour: 63 k
Mono: 187 k
Total: 250 k
AVERAGE/PERMANENT MONTHLY
PAGE VOLUME 150 k 125 k
MACHINE LIFE 5.0 Mill or 5 years (whichever
comes first) 5.0 Mill or 5 years (whichever comes first)
EXPOSURE LAMP 1.4 Mill. scans
MCBF (Mean Copies Between Failure)
Total: 113.5 k
Colour: 77.4 k
Monochrome: 134.5 k
Total: 96.5 k
Colour: 65.8 k
Monochrome: 114.4 k
MCBJ (Mean Copies Between Jam) Standard Paper: 15 k
MTTR (Mean Time To Repair) CM: 30 min. or less
PM: 20 min. or less
STANDARD COPY MODE Full colour 6 pages/job
Monochrome 8 pages/job Full colour 6 pages/job Monochrome 7 pages/job
STANDARD ORIGINAL DENSITY Full colour print: CMYK 5 %
Monochrome print: BK 5 %
SAFETY & ENVIRONMENT
English/German Data Sheets
Downloadable in the dbox:
dbox/Support/CSES Download/Open CSES Download/Document/
Safety & Environment
PLEASE NOTICE
Standard paper weight for systems is 80 g/m2for monochrome machines and 90 g/m2for full colour ones. Since using these
standards result in optimum system performance, all specifications on performance, reliability, maintenance and replacement
based on those standard papers. Using thick papers, labels, transfer and polyester films continuously can increase the wear
and tear on replacement parts and consumables – meaning your servicing costs will go up.
Use the bypass or the lower tray from the paper feed unit when working with materials having such characteristics as polyester
films, textile transfer films and labels. Otherwise, you may be faced with double feeding or a higher number of feeding jams.
If possible use subtray when working with materials having such characteristics as polyester films, textile transfer films and
labels. Roller-marks on the copy or print may appear or increased jams can occur. Standard paper weights yield the best
possible copy and print results. Using higher grammage may influence the quality of the output. Using standard paper weights
also guarantees that double sided copies and prints are made reliably. Different characters of films as well as thick, thin and
coated papers may increase the jam rate for double sided copies and prints.

4
Product Guide ineo+ 654/754
Product Configuration
SYSTEM DIMENSIONS

5
Product Guide ineo+ 654/754
SYSTEM CONFIGURATION

6
Product Guide ineo+ 654/754
System Specifications
DOCUMENT FEEDER Standard
Original Size
A6 / max. A3
(Width: 100 – 297 mm, Length: 139.7 – 431.8 mm)
in Fax Mode max length 1,000 mm
Original Weight
35 - 210 g/m² (Simplex) / 50 – 210 g/m² (Duplex)
50 – 128 g/m² Mix Mode
Tray Capacity
150 sheets (80g/m², A4)
Feeding Type
First Page System, Dual Scan
Feeding Speed
SimplexScan: 90 opm (B/W, Colour) 400dpi
Duplex Scan: 180 opm (B/W, Colour) 400dpi
SimplexScan: 75/60 opm (B/W/Colour) 600dpi
Duplex Scan: 150/120 opm (B/W/Colour) 600dpi
Dimensions (WxDxH) mm
618 x 575 x 130
Weight (kg)
18
PAPER CASSETTES Standard
Capacity
1 Tray (Universal): 500 sheets (up to SRA3/A3+ [320 x 457 mm])
2 Tray (Universal): 500 sheets (up to SRA3/A3+ [320 x 457 mm])
3 Tray: 1,500 sheets (A4)
4 Tray: 1,000 sheets (A4)
Paper Format
A5 crosswise – A3 + (max. 320 x457 mm)
(width: 130 – 320 mm, length: 182 – 457 mm)
Paper Weight
1 – 4 Tray: 52 – 256 g/m²
Max. Paper Capacity
6,650 sheets incl. bypass and optional cassettes
BYPASS Standard
Capacity
150-sheet bypass
Paper Format
A5 – A3, A6S Thick Paper, A3+, SRA3, Banner
Paper Size
Width: 90 to 320, Length: 139.7 to 1200 mm
Paper Weight
52 – 300 g/m²
Media Type
OHP, Banner, Tab Sheets, etc.

7
Product Guide ineo+ 654/754
DUPLEX Standard
Capacity
stackless
Paper Format
A5 – SRA3, A3+
Paper Weight
52 – 256 g/m²
BANNER TRAY BT-C1 Option
Function
To support multi banner feeding though manual bypass
LARGE CAPACITY TRAY LU-204 Option
Paper Size
A4 – SRA3/A3+
Paper Weight
52 – 256 g/m²
Paper Capacity
2500 sheets 80 g/m²
1000 sheets 256 g/m²
Dimensions (WxDxH) (mm)
629 x 556 x 405
Weight (kg)
25
LARGE CAPACITY TRAY LU-301 Option
Paper Size
A4 crosswise
Paper Weight
52 – 256 g/m²
Paper Capacity
3000 sheets 80 g/m²
1300 sheets 256 g/m²
Dimensions (WxDxH) (mm)
367 x 528 x 405
Weight (kg)
18

8
Product Guide ineo+ 654/754
100 SHEETS STAPLE FINISHER FS-535 Option
Finishing Modes Non-sort, sort, group, offset sort, offset group, staple, punch
(option)
Tray Capacity
Main Tray: 3,000 sheets (80 g/m²) [non sort]
2,500 sheets when SD-512 is installed
Sub Tray: 200 sheets (80 g/m²)
Stapling Modes
Corner (front/back), centre 2 points
Stapling Capacity
100 sheets (90 g/m²), 50 sheets (up to 105 g/m²),
94 sheets (90 g/m²) + 2 sheets (209 g/m²) as cover
Stapling Format
A3 – A5 lengthwise
Staples
MS-10A, one staple cartridge is packed to the finisher
Shift
30 mm
Dimensions (WxDxH) (mm)
724 x 709.5 x 1,025
Weight (kg)
63.5
Remark
Options for FS-535: PK-521 for Europe/Sweden, SD-512, PI-505,
ZU-606 and JS-602.
JOB SEPARATOR JS-602 Option for FS-535
Function
Additional 3rd bin for the FS-535
Paper Size
A3, B4, A4, B5, A5
Paper Weight
64 – 90 g/m²
Capacity
100 sheets
Dimensions (WxDxH) (mm)
341 x 537 x 149
Weight (kg)
1.75
Remark
Can’t be used together with PI-505

9
Product Guide ineo+ 654/754
SADDLE KIT SD-512 Option for FS-535
Paper Size
A4 lengthwise / A3+
Paper Weight
Centre Staple: 52 to 90 g/m²
Half-Fold: 52 to 209 g/m²
(more than 91 g/m² sheet can be used only as a cover sheet)
Tri-Fold: 52 to 90 g/m²
Stacking Capacity
1 to 5 sheets: 35 sets
6 to 10 sheets: 25 sets
11 to 20 sheets: 15 sets
Tri-Fold (1 sheet): 50 sets
Tri-Fold (2 sheets): 40 sets
Tri-Fold (3 sheets): 30 sets
Max. No. of Folded Sheets
Half-Fold: 5 sheets or Thick (91 to 209 g/m²) 1 sheet
Tri-Fold: 3 sheets
Max. No. of Sheets for Centre Stapling
20 sheets (52 to 90 g/m²) or 19 sheets (90 g/m²) + 1 sheet Thick
Paper (209 g/m²)
Staples
SK-602, one staple cartridge is packed to the Saddle Kit
Dimensions (WxDxH) (mm)
239 x 579 x 534
Weight (kg)
25.5
POST INSERTER PI-505 Option for FS-535
Function
Pre-printed page insertion, manual stapling, half fold and punching
Paper Size
Upper Tray: A5 lengthwise up to A4 (B5)
Lower Tray: A5 lengthwise up to A3+ (311 x 457 mm)
Paper Weight
60 – 209 g/m²
Capacity
Max. stack capacity 200 sheets 80 g/ m²
Dimensions (WxDxH) (mm)
511 x 635 x 220
Weight (kg)
10,5
Remark
Cannot be used together with JS-602

10
Product Guide ineo+ 654/754
Z-FOLD UNIT ZU-606 Option for FS-535
Hole Punching
Punch Method
On-line, page by page, 2 / 4 hole switching type
Hole Diameter
6.5 mm ± 0,5 mm
Paper Size
2 holes: A3, B4, A4 C/L, B5 C/L, A5 C/L
4 holes: A3, B4, A4 C, B5 C
Paper Weight
60 – 90 g/m²
Folding
Type
Z-fold
Paper Size
A3, B4
Paper Weight
60 – 90 g/m²
Dimensions (WxDxH) (mm)
169 x 1028 x 660
Weight (kg)
45
Remark
Although punching is included, PK-521 can be attached to FS-535 in
addition. This will allow also punching for paper, fed in via the Page
Inserter PI-505
PUNCH KIT PK-521 for
Europe/Sweden Option for FS-535
Punch Method
On-line, page by page, 2 / 4 holes switching type for European
version, 4 holes fixed for Swedish version
Hole Diameter
6.5 mm ± 0,5 mm
Paper Size
2 holes:A3, B4, A4 C / L, B5 C / L, A5 C / L
4 holes: A3, B4, A4 L, B5 L
Paper Weight
60 – 256 g/m²
Dimensions (WxDxH) (mm)
146.2 x 639.2 x 233.8
Weight (kg)
4.5
Remark
Punch mode cannot be used together with the folding mode, stitch
and fold mode or 3-folding mode

11
Product Guide ineo+ 654/754
50 SHEETS STAPLE FINISHER FS-534 Option
Finishing Modes
Non-Sort, Sort, Group, Staple
Tray Capacity
Sub Tray 200 sheets
Main Tray 3000 sheets A4 or 1500 sheets A3
Stapling Modes
Corner front/back, Centre 2 point Booklet (option)
Stapling Capacity
50 sheets (90g/m²)/ 30 sheets (91 – 120gm²) / 15 sheets (121 to
209 g/m²)
Staples
SK-602, one staple cartridge is packed to the finisher
Dimensions (WxDxH) (mm)
528 x 641 x 1023
Weight (kg)
40
Remark
Other options: Punch Kit PK-520, Saddle Kit SD-511
SADDLE UNIT SD-511 Option for FS-534
Paper Size
A4 lengthwise / A3+
Paper Weight
Centre Staple: 52 to 90 g/m²
Half-Fold: 52 to 209 g/m²
(more than 91 g/m² sheet can be used only as a cover sheet)
Tri-Fold: 52 to 90 g/m²
Stacking Capacity
1 to 3 sheets: 20 sets
4 to 10 sheets: 10 sets
11 to 20 sheets: 5 sets
Tri-Fold (1 sheet): 30 sets
Tri-Fold (2 sheets): 10 sets
Tri-Fold (3 sheets): 10 sets
Max. No. of Folded Sheets
Half-Fold: 5 sheets or Thick (91 to 209 g/m²) 1 sheet
Tri-Fold: 3 sheets
Max. No. of Sheets for Centre Stapling
20 sheets (52 to 90 g/m²) or 19 sheets (90 g/m²) + 1 sheet Thick
Paper (209 g/m²)
Staples
SK-602, one staple cartridge is packed to the Saddle Kit
Dimensions (WxDxH) (mm)
210 x 556 x 547
Weight (kg)
24

12
Product Guide ineo+ 654/754
Punch Kit PK-520 for
EUROPE/SWEDEN Option for FS-534
Punch Method
On-line, page by page, 2 / 4 holes switching type for European
version, 4 holes fixed for Swedish version
Hole Diameter
6.5 mm ± 0,5 mm
Paper Size
A3, B4, A4 L, B5 L
Paper Weight
60 – 300 g/m²
Dimensions (WxDxH) (mm)
61 x 492 x 142
Weight (kg)
2
INNER OUTPUT TRAY OT-503 Option
Remark
If no finisher is attached the OT-503 is always required.
FAX KIT FK-511 Option
Specifications
Please refer to the chapter “Fax Specifications”
Remark
To connect a 2nd Fax Kit no further options are required.
STAMP UNIT SP-501 Option
Function
Attached to the Document Feeder and marks every fax original which
is scanned in for transmission.
SPARE TX MARKER STAMP 2
Remark
Spare stamp for SP-501
FIERY CONTROLLER IC-414 Option
Specifications
Please refer to the chapter “Fiery Specifications”
VIDEO INTERFACE KIT VI-506 Option
Function
Required to connect IC-414

13
Product Guide ineo+ 654/754
USB HOST BOARD EK-604 Option
Function
USB interface for key board
Remark
Speaker included
USB HOST BOARD + BLUETOOTH
EK-605 Option
Function
USB interface for key board & Bluetooth for Mobile Printing
Remark
Speaker included
SECURITY KIT SC-508 Option
Function
Remark
Copy Guard, Password Copy, Security pattern search
2 kits are required for the ineo+654/754
BIOMETRIC AUTHENTICATION UNIT
AU-102 Option
Function
Authentication by finger vein scanner
Remark
The use of WT-506 is recommended in order to place AU-102.
IC CARD AUTHENTICATION UNIT Option
Function
Authentication by contact less IC card
Remark
For details on available card technologies please refer to the price
list. MK-735 is required for inside installation, WT-506 for outside
installation.
WORKING TABLE WT-506 Option
Function
To place the Authentication Unit
MOUNT KIT MK-735 Option
Function
Used for IC Card Authentication installation
LICENSE KEY LK-101v3 Option
Function
Web Browser Function
Remark
Upgrade Kit UK-204 is required in addition

14
Product Guide ineo+ 654/754
LICENSE KEY LK-102 v3 Option
Function
PDF/A, PDF Encryption Function
Remark
Upgrade Kit UK-204 is required in addition
LICENSE KEY LK-105 v3 Option
Function
OCR for searchable PDF/ PPTX / PDF/A 1a
Remark
Upgrade Kit UK-204 is required in addition
LICENSE KEY LK-106 Option
Function
Barcode Font
Remark
Upgrade Kit UK-204 is required in addition
LICENSE KEY LK-107 Option
Function
Unicode Font
Remark
Upgrade Kit UK-204 is required in addition
LICENSE KEY LK-108 Option
Function
OCR Font
Remark
Upgrade Kit UK-204 is required in addition
i-OPTION UPGRADE KIT UK-204 Option
Capacity
2 GB
Remark
Required in addition, when License Keys are to be used
KEY BOARD HOLDER KH-101 Option
Function
To place the optional USB key board (country procurement)
WIRELESS LAN TO LAN ADAPTER
SX-600 Option

15
Product Guide ineo+ 654/754
Copier Specifications
ineo+754 ineo+654
WARM-UP TIME 22 sec or less
FIRST COPY Colour
Monochrome 5.3 sec. or less 3.6 sec. or less 5.3 sec. or less 3.7 sec. or less
COPY SPEED
A4 crosswise colour
(simplex/duplex)
60 ppm 60 ppm
A4 crosswise monochrome
(simplex/duplex)
75 ppm 65 ppm
A3 colour (simplex/duplex)
30 ppm 30 ppm
A3 monochrome (simplex/duplex)
37 ppm 33 ppm
SCAN RESOLUTION 600 x 600 dpi
COPY/PRINT RESOLUTION Copy: 600 x 600dpi
Print: 1800 x 600dpi
MEMORY 2 GB (std.), 4 GB (expansion memory installed)
HDD 250 GB (std.)
GRADATION 256
ZOOM 25 – 400 % adjustable in 0,1 % steps
MULTI COPY 1 – 9999, countup, interruption capability
DENSITY ADJUSTMENT Automatic, Manual (9 steps)
IMAGE LOSS
Leading edge: 4.2 mm or less
Trailing edge: 3 mm or less
Both sides: 3 mm or less
SAR3 max, printable area 307 x 443
POWER REQUIREMENT 220 - 240 V / 50 - 60 Hz / 10 A
POWER CONSUMPTION Max. 2.1 kw or less Max. 2.1 kw or less
COPIER DIMENSIONS (W x D x H) mm
650 x 799 x1155 (incl. ADF)
COPIER WEIGHT 221 kg (incl. ADF &IU)
190 kg Main Body only

16
Product Guide ineo+ 654/754
FEATURE LIST
Dual Scan
Yes
2in1/4in1/8in1
Yes
AMS/APS
Yes
Book Copy
Yes
Booklet Creation
Yes
Chapter Insertion
Yes
Continuous Number Stamping
Yes
Cover Mode
Yes
X/Y Independent Zoom
Yes
Department Control
Yes (1000)
Distribution Numbering
Yes
Edge / Frame / Fold Line Erase
Yes
Image Insertion
Yes
Image Repeat
Yes
Image Shift
Yes
Image Rotation
Yes
2in1/4in1/8in1
Yes
Program Job
Yes
Non-Image Area Erase
Yes
OHP Interleaving
Yes
Overlay
Yes
Page Insertion
Yes

17
Product Guide ineo+ 654/754
FEATURE LIST cont.
Positive-Negative-Mode
Yes
Date Stamp / Page Stamp
Yes / Yes
Program Memory
Yes (30)
Proof Copy
Yes
Separate Scanning
Yes
Stamp
Yes
Watermark
Yes
Gloss Copy
Yes

18
Product Guide ineo+ 654/754
Printer Specifications
ineo+754 ineo+C654
CPU MPC8536, 1,2 GHz
PRINT SPEED
A4 crosswise colour
(simplex/duplex) 60 ppm 60 ppm
A4 crosswise monochrome
(simplex/duplex) 75 ppm 65 ppm
A3 colour (simplex/duplex) 30 ppm 30 ppm
A3 monochrome simplex/duplex) 37 ppm 33 ppm
PRINT RESOLUTION 1,800 x 600 dpi
High quality mode 1,200 x 1,200dpi
PDL PCL5e/c Emulation, PCL6 ( XL Ver. 3.0) Emulation,
PostScript 3 Emulation (3016), XPS Ver. 1.0, OOXML
MEMORY Shared with the copier
HDD 250 GB (shared with the copier)
FONTS
PS3: AgfaMicro type (137 fonts)
PCL AgfaMicro type (80 fonts)
INTERFACE
10BaseT/100BaseTX/1000 BaseT
Yes (standard)
USB 1.1, USB 2.0, USB Host
Yes (standard)
SUPPORTED OS Windows XP/XP 64bit/Vista/Vista64bit/7/7 64bit/
Server 2003 R2/Server 2003 64bit/Server 2008/
Server 2008 64bit/Mac OS 9.2 or later/Mac OS X 10.4 (Intel) or
later/Linux
PROTOCOL TCP/IP, IPX/SPX (NDS support), SMB (NetBEUI), LPD, IPP1.1,
SNMP, HTTP

19
Product Guide ineo+ 654/754
FEATURE LIST
Booklet Creation
Yes
Chapter Insertion
Yes
Continuous Number Stamping
Yes
Cover Mode
Yes
Date Stamp
Yes
Distribution Numbering
Yes
Edge / Frame Erase
Yes
Image Insertion
Yes
Image Repeat
Yes (2 repeats)
Image Shift
Yes
Image Rotation
Yes
Job Accounting
Yes
Non-Image Area Erase
Yes
OHP Interleaving
Yes
Overlay
Yes
Page Insertion
Yes
Page Stamp
Yes
Proof Print
Yes
Stamp
Yes
Watermark
Yes
MixPlex
Yes
Tab Print
Yes

20
Product Guide ineo+ 654/754
FINISHING
Sorting
Yes
Stapling
Yes (Settings: auto, left, top, right)
Punching
Yes
Folding
Yes
Page Order Output
Yes
