DeVilbiss PCWB001 User manual

Contents
Important Safeguards
Features
Device Pretest
Operation
Recommended Program
Care and Cleaning
Troubleshooting
Technical Specifications
1
2
2
4
4
5
5
LED Daylight Lamp
2
4
Electromagnetic Compatibility (EMC)
Rev 01

READ ALL INSTRUCTIONS BEFORE USING
Important Safeguards
!DANGER:
!WARNING:
!CAUTION:
To avoid electrocution, do not operate this device near water.
Close supervision is recommended when these lamps are used by or near children, or others
who may not understand the need for these precautions.
Do not operate lamp in close proximity to flammable or combustible vapors, such as aerosol
spray products, or where oxygen is being administered.
To prevent risk of shock or personal injury when cleaning lamp, make sure you have turned
off and unplugged the lamp and allowed sufficient time for the lamp to cool.
Do not shorten or cut the power cord.
Certain medications(e.g., anti-depressants) and diagnosed mental health conditions may
induce light sensitivity, which may result in discomfort, hyperactivity, or hypomania.
Consult with your health care provider before using this product.
If you have a pre-existing eye condition or are at risk of developing Age-related macular
degeneration or other eye related conditions,it is recommended that you consult with your
healthcare provider before using this product.
Some people experience light sensitivity to bright strong light or upon an over-exposure to
bright strong light. Discontinue use immediately if you experience any discomfort.
This product is intended for indoor use only.
Avoid placing this product in areas that are exposed to direct sunlight or in close proximity to
heat-radiating products. Do not place this product on the top of other appliances which
radiate heat. Protect the power cord of this product,in all of its parts from being damaged in
any way.
Do not use this product if it has been damaged in any way. For example, the power supply
cord or plug have been damaged; liquid has been spilled on any of its surfaces; objects have
fallen onto this product; the product itself has sustained damage due to external forces such
as being hit or dropped, been exposed to rain or moisture etc.
Do not disassemble this product. There are no user-serviceable parts in this lamp.
Only use the power plug adaptor, cord and connector supplied with your LED daylight lamp.
If other power sources, plugs, adapters, cords and connectors are used, damage to your
product or its power supply may occur.
This product may cause interference with radios, cordless telephones or other devices that
use a wireless remote control, such as television sets. If any interference occurs, move the
product away from those devices and connect it to a different power outlet, out of sight from
the remote control receiver.
Unplug this product during lighting storms or when it has been in use for long periods of time.
Avoid placing this product in areas that are dusty; humid/moist ; lack ventilation; are places
where constant vibration occurs.
This product is not to be used with any kind of light dimmers, timers, motion detectors,
voltage transformers or extension cords.
Do not leave this product unattended during use.
Never cover this product or place anything on the top of it when it is in operation.
Do not run the power cord of this product on objects or the top of it. Always place it behind
this product.
Do not use solvents or cleaners containing any abrasive materials, or ammonia-based
cleaners on this product.
After cleaning the lamp, all moisture should be properly wiped away and dried completely
before it is connected to the power supply.
1

Features
Delivers natural light to your home, office, dorm room or apartment.
Has up to 10,000 LUX bright Full Spectrum light.
Is designed with a compact shape and small holder to make it easy to place in a convenient
location, or hang on the wall.
Permits a customized session, with light intensity settings, stepless colour
temperature setting from 3000K to 6500K , and four timer settings.
Your new daylight lamp is an remarkable product with various features and benefits. lt:
2
Device Pretest
Operation
Insert the power jack connector end of the AC/DC adaptor into the power cord receptacle
located on the back of the lamp. Then,connect the AC/DC adaptor to an AC outlet.
Note: Do not run the power cord of this product over or place objects on top of it.
Always place it behind this product.
The LED Daylight Lamp may cause discomfort to those with greater sensitivity to light. It is
Step 1- Turn on the lamp and position it within arm’s reach (do not look directly into the lamp).
Step 2- Operate the lamp for approximately 10 minutes and turn it off. If the light has caused
any discomfort (e.g. headache, irritability, etc. ), stop using the product and
consult a doctor.
1. Set up your LED Daylight Lamp
The LED Daylight Lamp provides a bright, colour adjustable light that can be used to imitate
sunlight exposure during darker winter months. Feel free to engage in regular activities such as
reading, writing,hobbies and crafts, sewing, needlepoint, applying make-up or working at
your computer or desk.
recommended that you perform a pretest before frequent use of the LED Daylight Lamp.

Press the switch on the side to turn on the lamp.
The lamp is recommended to be positioned between
15 and 60cm (6-24”) from your face and should be
slightly off-center (see diagram).
Note: Do not look directly into the lamp.
2.Light Intensity, Colour Temperature and Timer Setting
3
Colour temperatureTimer Light intensity
ON/OFF
Adjusting the colour temperature of lamp:
Stepless mode: Touch and hold the switch until the desired colour temperature
is achieved between 3000k warm light colour to 6500k white light colour. When the lamp
Adjusting the brightness of lamp:
5 levels :Press the switch to select the colour temperature from 900lux, 2860lux,
5000lux, 7200lux, 10000lux.
Setting the timer:
Tap the switch to select time 15min, 30min, 45min, 60min.
Note: The LED Daylight Lamp will remain on if the timer switch is not activated.
achieves the 6500K white light colour, repress the switch to cycle in the opposite direction.

Care and Cleaning
Recommended Program
It is recommended to use the LED Daylight Lamp for 30 to 60 minutes per day. The
recommended program may be used in one session or split into multiple shorter sessions.
Use of the lamp may be timed before or after natural sunlight is available, especially during darker
winter months.
Your product is made from high-quality materials that will last for many years with minimum
care. You may want to periodically clean the lamp using a mildnonabrasive cleaner and soft
cloth. When cleaning, always make sure you have turned off and unplugged the unit and
allowed sufficient time for the unit to cool.
WARNING: To prevent risk of shock or any personal injury when cleaning your product, always
make sure you have turned off, unplugged it from the power sources and allowed sufficient
time for the product to cool down.
CAUTION:Clean only with a soft dry cloth - do not use solvents or cleaners containing abrasives
or ammonia.
After cleaning this product, all moisture should be properly wiped away and dried completely
before it is connected to the power supply.
30 Minutes
to
1hour/day
4
Electromagnetic Compatibility (EMC)
The LED Daylight Lamp has been designed to meet the requirements of Directive 2014/30/EU,
however it may still be affected by or emit harmful radio frequency (RF) energy. The RF emissions
from the lamp are very low and are not likely to cause any interference to nearby electronic
equipment, however interference to sensitive equipment is still possible. Likewise, if the
immunity limits of the lamp are exceeded, it may be seen to operate abnormally. If this occurs,
turn off the lamp and/or alternative equipment to identify the cause.

Make sure all power connectors, cords, and plugs are inserted fully and securely.
Make sure there is power to the wall outlet, or try another outlet-one that is not connected
to a dimmer.
Model:
Size:
Adapter:
Power:
Light Intensity:
Colour Temperature:
Timer:
PCWB001
240*146*17mm
Input:110-240V
5.9W
900/2860/5000/7200/10000LUX
3000~6500K
15min, 30min, 45min, 60min
5
Trouble shooting
Technical Specifications
Manufactured by: ANA Incorporation Ltd
B1-1807 Guangda We Vally, No.2,Zongbu No.2 Road,
Songshan Lake Hi-tech Industrial Development Zone,Donguan 523808 China
Imported by: Drive DeVilbiss Healthcare Ltd.,
Holmfield, Halifax, West Yorkshire, HX2 9TN, Great Britain
Drive DeVilbiss Sidhil Ltd.
4 Trench Road, Mallusk, Newtownabbey, BT36 4TY, Northern Ireland
