DEVOLA DVPH16PFSB User manual

INSTRUCTION MANUAL
Models:
DVPH16PFSB
DVPH16PFSSL
DVPH20PFSB
DVPH20PFSSL
Parts Descriptions:
No.
Part Name
No.
Part Name
1
Main Body
5
Screw M4*28
2
Base Cover
6
Washer
3
Base
7
Screw M6*35
4
Cord Clip
8
Remote controller

Cautions:
1. Children of less than 3 years should be kept away unless continuously supervised.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
CAUTION -- Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
2. Children aged from 3 years and less than 8 years shall only switch on/off the appliance if it has
been placed or installed in its intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate,
and clean the appliance or perform user maintenance.
3. The heater must not be located immediately below a socket-outlet.
4. Do not use this heater with a programmer, timer or any other device that switches the heater on
5. automatically, since a fire risk exists if the heater is covered or positioned incorrectly.
6. Do not use this heater in the immediate surroundings of a bath, a shower or a swimming pool.
7. Do not place the unit close to curtain and/or other flammable objects otherwise there will be a
danger of catching fire.
8. Do not cover the unit with anything during operation or a short time after it has shut down.
9. Do not wrap the power supply cord on the unit.
10. Do not use this unit in place where causticity or volatile air exists, i.e. dust, steam, gas, etc.
11. Do not use this unit as a cloth drier or towel drier.
12. Do not use this unit as a sauna heater.
13. Do not use this unit as a room heater of heat storing.
14. Do not use this unit in place of animal propagating and raising.
15. Do not use this unit in heating system of hot air center.
16. Do not immerse this unit into water for cleaning.
17. The unit must be placed with the clearance of 150cm at least to the wall.
18. The unit must be securely placed on a horizontal and flat surface.
19. The unit is at high temperature during operation. It keeps hot for a period of time after shutting
down. Potential danger would occur when touching it during this period.
20. The unit must be handled with care and avoid of vibration or hitting.
21. The unit must be securely grounded during operation.
22. When damaged, the unit must be repaired by professional repairing team.
23. If the supply cord is damaged, it must be replaced by a qualified engineer.
24. When assembling, keep clear from any board or flammable material.
25. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for their
safety.
26. The unit is for outdoor use only. It's not allowed to use in building site, greenhouses, barn or
stable where there's flammable dust.
27. The head of the unit is at high temperature during operation. Unplug the unit and wait till it's cool
before cleaning.
28. The unit should be plugged in a socket, which is easily visible and reachable.
WARNING:
This heater is not equipped with a device to control the room temperature. Do not use this heater in
small rooms when they are occupied by persons not capable of leaving the room on their own, unless
constant supervision is provided.
Preparation
1. Prepare a cross head screwdriver.
2. Read this instruction manual carefully before installation and use. Keep this instruction manual
and warranty card in a proper and safe place for future use in case needed.
Accessories Pack Check List:
Accessory Name
Qty
Accessory Name
Qty
Allen Key
1
Cord Clip
1
Screw M4*28
2
Washer
2
Screw M6*35
2
Remote Controller
1
Disposal of appliances and batteries
After the implementation of the European Directive 2002/96/EU in the national legal
system, the following applies:
Electrical and electronic devices may not be disposed of with domestic waste.
Consumers are obliged by law to return electrical and electronic devices at the end of
their service lives to the public collecting points set up for this purpose or point of sale.
Details to this are defined by the national law of the respective country. This symbol on
the product, the instruction manual or the package indicates that a product is subject to
these regulations. By recycling, reusing the materials or other forms of utilising old
devices, you are making an important contribution to protecting our environment.

Installation:
1. Put the main body up-side-down. Put the plug and power supply cord through the holes
on the center of Base Cover (#2) and Base (#3). Then slide Base Cover (#2) , Base (#3)
and Washer (#6) onto Main body respectively.
2. Fix Washer (#6), Base (#3), Base Cover (#2) with Screw M6*35 (#7). Clip the power
supply cord with Cord Clip (#4) and fix it onto Base (#3) with Screw (#5).
Operations:
3. Plug in the unit to a socket, making sure the power supply is the same as rated.
4. Press the Main Switch on the top of the control box.
5. When the mark ”-”in the digital display starts flashing, it’s showing the that heater is on
standby.
6. Press the MODE button on the control panel or remote control to switch the heater on
or to a higher power.
7. The power setting level 1, level 2, level 3 will show on the digital display.
8. Press TIMER “+/-”button on control panel or remote control to choose the timer
between 0-9 hours. “0”means the timer is off. The digits of the power settings and
timer will be displayed as cycled: power settings for ten seconds, timer flashing for five
seconds.
9. To shift the heater to standby mode, press OFF button on control panel or remote
control. The mark ”-”in the digital display will start flashing again (See Step 3).
10. To switch off the heater, press the Main Switch on left side of the heater accordingly.
Cleaning:
Unplug the unit before cleaning. It should be wiped with wet cloth. Do not use too much
water.
Warranty
Guarantee and Service Policy
This product is covered by a standard parts or replacement warranty for a period of 12
months from the date of purchase.
Extend your warranty for 12 months for free by visiting www.devola.co.uk/warranty.
Incorrect installation and failure to follow correct operating instructions are excluded.
Consequential costs such as labour charges or damage to surroundings are expressly
excluded.
Contact Us
If you experience a problem with this product you should first contact us on 0121 250 2180
before taking any further action.
