Napoleon SRPH02S User manual
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
DANGER
WARNING
WARNING
For Outdoor Use Only.
CAUTION:
Installer: Leave the instruction manual
with the user for future use.
Consumer: Please keep this manual
for future reference.
Read the instructions before use.
This appliance must be installed in
accordance with such regulations as
are in force.
Owner’s Manual
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
Model#: SRPH02-XXXX
Deluxe Outdoor
Patio Heater
Customer I tem No.: PTH38PSS
PTH38PGM
PTH38PCP
Standard: ANS Z83.26-2007 / CSA 2.37-2007 & ANS Z83.26a-2008/CSA 2.37a-2008
Gas-Fired Outdoor Infrared Patio Heaters
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such
as a camper, tent or home.
DANGER CARBON MONOXIDE HAZARD
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause injury,
death or property damage. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
SPECIFICATION
Certification CSA
Height Overall 2.3m / 90.6’’
Reflector Diameter 85cm / 33.5’’
Rated Heat Input 40000 BTU/HR
Fuel LP
Gas Supply 20Lb (9kg) LP-Gas cylinder
Manifold Pressure 11.0 ” W.C.
Injector Size(diameter) 1.95mm
Safety Features Flame failure device, anti-tilt switch & pilot
Gas Supply Pressure Max. 250PSI, Min. 5PSI
2
The bill of sale or copy will be required together with the serial and model numbers when making any warranty claims.
Do not return parts to our address without first obtaining a return authorization number. The customer service department
is available between 9am and 5pm (EST).
NAC Customer Care
214 Bayview Drive
Barrie, ON
Canada, L4N 4Y8
1-866-820-8686
1-705-727-4282 (fax)
7KH LQVWDOODWLRQ PXVW FRQIRUP ZLWK ORFDO FRGHV
RU LQ WKH DEVHQFH RI ORFDO FRGHV ZLWK WKH
1DWLRQDO)XHO*DV&RGH$16,=1)3$
1)3$ 1DWXUDO *DV DQG 3URSDQH ,QVWDOODWLRQ
&RGH &6$ % RU 3URSDQH 6WRUDJH DQG
+DQGOLQJ&RGH%
7KHKHDWHUZKHQLQVWDOOHGPXVWEHHOHFWULFDOO\
JURXQGHGLQ DFFRUGDQFH ZLWK ORFDOFRGHVRULQ
WKH DEVHQFH RI ORFDO FRGHV ZLWK WKH 1DWLRQDO
(OHFWULFDO&RGH$16,1)3$RUWKH&DQDGLDQ
(OHFWULFDO&RGH&6$&
&KLOGUHQDQGDGXOWVVKRXOGEHDOHUWHGWR
WKHKD]DUGVRIKLJKVXUIDFHWHPSHUDWXUHV
DQG VKRXOG VWD\ DZD\ WR DYRLG EXUQV RU
FORWKLQJLJQLWLRQ
<RXQJ FKLOGUHQ VKRXOG EH FDUHIXOO\
VXSHUYLVHG ZKHQ WKH\ DUH LQ WKH DUHD RI
WKHKHDWHU
&ORWKLQJ RU RWKHU IODPPDEOH PDWHULDOV
VKRXOG QRW EH KXQJ IURP WKH KHDWHU RU
SODFHGRQRUQHDUWKHKHDWHU
3ULRUWR XVH FKHFN IRU GDPDJHGSDUWVVXFKDV
KRVHVUHJXODWRUVEXUQHU
$OOOHDNWHVWVVKRXOGEHGRQHZLWKDVRDS\VROX
WLRQ 1(9(5 86( $1 23(1 )/$0( 72
&+(&.)25/($.$*(
7KHSURSDQHKRVHZLWKUHJXODWRUDVVHPEO\VKDOO
EH ORFDWHG RXW RI SDWKZD\V ZKHUH SHRSOH PD\
WULSRYHULWRULQDUHDVZKHUHWKHKRVHZLOOQRWEH
VXEMHFWWRDFFLGHQWDOGDPDJH
$Q\ JXDUG RU RWKHU SURWHFWLYH GHYLFH
UHPRYHGIRUVHUYLFLQJWKHKHDWHUPXVWEH
UHSODFHGSULRUWRRSHUDWLQJWKHKHDWHU
,QVWDOODWLRQDQGUHSDLUVKRXOGEHGRQHE\
D TXDOLILHG VHUYLFH SHUVRQ 7KH KHDWHU
VKRXOG EH LQVSHFWHG EHIRUH XVH DQG DW
OHDVW DQQXDOO\ E\ D TXDOLILHG VHUYLFH
SHUVRQ
0RUH IUHTXHQW FOHDQLQJ PD\ EH UHTXLUHG
DVQHFHVVDU\,WLVLPSHUDWLYHWKDWFRQWURO
FRPSDUWPHQWEXUQHUVDQGFLUFXODWLQJDLU
SDVVDJHZD\VRIWKHKHDWHUEHNHSWFOHDQ
.HHS WKH DSSOLDQFH DUHD FOHDU DQG IUHH IURP
FRPEXVWLEOHPDWHULDOVJDVROLQHDQGRWKHUIODP
PDEOHYDSRUVDQGOLTXLGV
'RQRWREVWUXFWWKHIORZRIFRPEXVWLRQDQGYHQWL
ODWLRQDLU
.HHS WKH YHQWLODWLRQ RSHQLQJV RI WKH F\OLQGHU
HQFORVXUHIUHHDQGFOHDUIURPGHEULV
7KLV DSSOLDQFH VKDOO EH XVHG RQO\ LQ D ZHOO
YHQWLODWHGVSDFHDQGVKDOOQRWEHXVHGLQDEXLOG
LQJJDUDJHRUDQ\RWKHUHQFORVHGDUHD
$Q DSSOLDQFH PD\ EH LQVWDOOHG ZLWK VKHOWHU QR
PRUHLQFOXVLYHWKDQ
:LWK ZDOOV RQ DOO VLGHV EXW ZLWK QR RYHUKHDG
FRYHU
:LWKLQ D SDUWLDO HQFORVXUH ZKLFK LQFOXGHV DQ
RYHUKHDG FRYHU DQG QR PRUH WKDQ WZR VLGH
ZDOOV7KHVHVLGHZDOOVPD\EHSDUDOOHODVLQD
EUHH]HZD\RUDWULJKWDQJOHVWRHDFKRWKHU
127(3/($6(5($'7+()2//2:,1*6$)(7<58/(6
:$51,1*
:LWKLQ D SDUWLDO HQFORVXUH ZKLFK LQFOXGHV DQ
RYHUKHDGFRYHUDQGWKUHHVLGHZDOOVDVORQJDV
SHUFHQWRUPRUHRIWKHKRUL]RQWDOSHULSKHU\RI
WKHHQFORVXUHLVSHUPDQHQWO\RSHQ
7KLVDSSOLDQFHUHTXLUHVNJOE/3JDVVXSSO\
F\OLQGHU
7KH/3JDVVXSSO\F\OLQGHUWREHXVHGPXVWEH
&RQVWUXFWHGDQGPDUNHGLQDFFRUGDQFHZLWKWKH
6SHFLILFDWLRQVIRU/3JDVF\OLQGHUVRIWKH86
'HSDUWPHQW RI 7UDQVSRUWDWLRQ '27 RU WKH
6WDQGDUGIRU &\OLQGHUV6SKHUHVDQG 7XEHV IRU
7UDQVSRUWDWLRQ RI 'DQJHURXV *RRGV DQG &RP
PLVVLRQ&$1&6$%DVDSSOLFDEOH
3URYLGHG ZLWK D OLVWHG RYHUILOOLQJ SUHYHQWLRQ
GHYLFHDQGSURYLGHGZLWKDF\OLQGHUFRQQHFWLRQ
GHYLFH FRPSDWLEOH ZLWK WKH FRQQHFWLRQ IRU WKH
DSSOLDQFH
7KH F\OLQGHU LV WR EH GLVFRQQHFWHG ZKHQ WKH
DSSOLDQFHLVQRWLQXVH
6WRUDJH RI DQ DSSOLDQFH LQGRRUV LV SHUPLVVLEOH
RQO\LIWKHF\OLQGHULVGLVFRQQHFWHGDQGUHPRYHG
IURPWKHDSSOLDQFH
$ F\OLQGHU PXVW EH VWRUHG RXWGRRUV LQ D ZHOO
YHQWLODWHG DUHD RXW RI WKH UHDFK RI FKLOGUHQ $
GLVFRQQHFWHG F\OLQGHU PXVW KDYH GXVW FDSV
WLJKWO\LQVWDOOHGDQGPXVWQRWEHVWRUHGLQDEXLOG
LQJJDUDJHRUDQ\RWKHUHQFORVHGDUHD
7KHSUHVVXUHUHJXODWRUDQGKRVHDVVHPEO\VXS
SOLHGZLWKWKHDSSOLDQFHPXVWEHXVHGUHSODFH
PHQWSUHVVXUHUHJXODWRUVDQGKRVHDVVHPEOLHV
PXVWEHWKRVHVSHFLILHGE\WKHDSSOLDQFHPDQX
IDFWXUHU
7KHKRVHDVVHPEO\PXVWEHUHSODFHGSULRUWRWKH
DSSOLDQFH EHLQJ SXW LQWR RSHUDWLRQ LI WKHUH LV
HYLGHQFHRIH[FHVVLYHDEUDVLRQRUZHDURULIWKH
KRVHLVGDPDJHG
'R QRW VWRUH D VSDUH /3JDV F\OLQGHU XQGHU RU
QHDUWKLVDSSOLDQFH
1HYHUILOOWKHF\OLQGHUEH\RQGSHUFHQWIXOO
'R QRW FOHDQ WKH KHDWHU ZLWK FOHDQHUV WKDW DUH
FRPEXVWLEOHRUFRUURVLYH
127(3/($6(5($'7+()2//2:,1*6$)(7<58/(6
:$51,1*
3ODFHWKHGXVWFDSRQWKHF\OLQGHUYDOYHRXWOHW
ZKHQHYHUWKHF\OLQGHULVQRWLQXVH2QO\LQVWDOO
WKHW\SHRIGXVWFDSRQWKHF\OLQGHUYDOYHWKDWLV
SURYLGHGZLWKWKHF\OLQGHUYDOYH2WKHUW\SHVRI
FDSVRUSOXJVPD\UHVXOWLQOHDNDJHRISURSDQH
7KLVKHDWHULVGHVLJQHGWRRSHUDWHZLWKDVWDQGDUG,ESURSDQHF\OLQGHUZLWK$SSURYHG&\OLQGHU
&RQQHFWLRQ
127(3/($6(5($'7+()2//2:,1*6$)(7<58/(6
$GMXVWDEOHRSHQLQJZUHQFK
3KLOLSVVFUHZGULYHU
(VWLPDWHGWLPHIRUDVVHPEO\PLQXWHV
%HIRUHEHJLQQLQJDVVHPEO\RISURGXFWPDNHVXUHDOOSDUWVDUHSUHVHQW,IDQ\SDUWLVPLVVLQJRU
GDPDJHGGRQRWDWWHPSWWRDVVHPEOHWKHSURGXFW&RQWDFWFXVWRPHUVHUYLFHIRUUHSODFHPHQWSDUWV
3HUIRUPDOHDNWHVWZLWKDVRDS\VROXWLRQ
7RFKHFNJDVFRQQHFWLRQV
$IWHUFRQQHFWLQJDQHZF\OLQGHU
8SRQUHDVVHPEO\DIWHUGLVDVVHPEO\
722/61(('('127,1&/8'('
3$576/,67(;3/2'('9,(:
+RVH5HJXODWRU
'RXEOH3RLQWHG%ROWV
0'HFRUDWLYH1XW
'RXEOH3RLQWHG%ROW
&RQQHFWRUV
³$$$´%DWWHUU\
+DUGZDUH&RQWHQWV
3ROH
3ROH6XSSRUW
'HFRUDWLYH&DS
%XUQHU+HDG$VVHPEO\
:$51,1*
5HDG$//DVVHPEO\LQVWUXFWLRQV
WKRURXJKO\DQGFDUHIXOO\WRLQVXUH
SURSHUVDIHDVVHPEO\
6WHS
6WHS
$WWDFKWKHSROHWRWKHSROH
VXSSRUWXVLQJVL[0;EROWV
DQGVL[PPZDVKHUV
$WWDFKWKHF\OLQGHUFRYHUWR
WKHSROHVXSSRUWE\VOLGLQJLW
RYHUWKHSRVW
+DUGZDUH8VHG
PPZDVKHU;
0;EROW;
$66(0%/<
6WHS
$66(0%/<
6WHS 6WHS
$WWDFKWKHEXUQHUKHDGDVVHPEO\
WRWKHSROHE\XVLQJ
ILYH0;EROWVDQGILYH
PPZDVKHUV
PPZDVKHU;
0;EROW;
+DUGZDUH8VHG
PPZDVKHU;
0;GRXEOHSRLQWHGEROW;
+DUGZDUH8VHG
$WWDFKWKUHH0;GRXEOH
SRLQWHGEROWVDQGWKUHHPP
ZDVKHUVWRWKHWRSRIWKH
EXUQHUKHDGDVVHPEO\7LJKWHQ
WKHEROWV
6WHS
5HPRYHWKHSODVWLFFRDWLQJIURP
WKHWKUHHUHIOHFWRUSLHFHV
-RLQWKHUHIOHFWRUXVLQJWKH
VXSSOLHGFRQQHFWRUV
)DVWHQWKHFRQQHFWRUVLQSODFH
XVLQJWZR0[EROWV
+DUGZDUH8VHG
0QXW;
0;GRXEOHSRLQWHGEROW;
PPZDVKHU;
$66(0%/<
6WHS
+DUGZDUH8VHG
0[EROW;
UHIOHFWRUFRQQHFWRU;
6WHS
3ODFHWKHUHIOHFWRUDVVHPEO\RQWR
WKHWRSRIWKHEXUQHUKHDGDVVHPEO\
WLJKWHQWKHPDVLOOXVWUDWHGXVLQJ
WKUHH0[GRXEOHSRLQWHGEROWV
VL[PPZDVKHUVDQG
WKUHH0QXWV
$WWDFKFHQWHUGHFRUDWLRQFDSDQG
0GHFRUDWLYHQXWE\0[EROW
0GHFRUDWLYHQXW;
0;GRXEOHSRLQWHGEROW;
3ODFHWKHJDVF\OLQGHUQRWLQFOXGHG
LQWRWKHSROHVXSSRUWDQGIDVWHQLQ
SODFHZLWKVXSSOLHGIL[LQJFKDLQ7KHQ
DWWDFKWKHUHJXODWRUWRWKHF\OLQGHU
7XUQFORFNZLVHWRWLJKWHQLWVHFXUHO\
7KHQSODFHWKHF\OLQGHUFRYHUEDFN
LQWRWKHSRVLWLRQ
1RWH0DNHVXUHWRFKHFNIRUOHDNV
DIWHUUHSODFLQJF\OLQGHUUHIHUWRWKH
VHFWLRQFKHFNIRUOHDNVRQSDJH
WLJKWHQ
IL[LQJ
FKDLQ
6WHS
$66(0%/<
6WHS
6WHS
6WHS
/RZHUWKHF\OLQGHUFRYHURQWRWKH
F\OLQGHUEDVH
6WHS
'LVFRQQHFWF\OLQGHUZKHQVWRULQJRU
WUDQVSRUWLQJ
7XUQRIIWKHKHDWHU
5DLVHWKHF\OLQGHUFRYHURQWRWKH
SRVWPRXQWV
7XUQRIIWKHF\OLQGHUYDOYH
'LVFRQQHFWWKHUHJXODWRUIURPWKH
F\OLQGHU
6WHS
&KHFNIRUOHDNV
<RXUSDWLRKHDWHUKDVEHHQFKHFNHGDWDOO
IDFWRU\FRQQHFWLRQVIRUOHDNDJH7RFKHFNWKH
FRQQHFWLRQDWWKHJDVKRVHUHJXODWRUF\OLQGHU
1RWH
7KHF\OLQGHUVXSSO\V\VWHPPXVWEHDUUDQJHG
IRUYDSRUZLWKGUDZDO
7KHF\OLQGHUXVHGPXVWLQFOXGHDFROODUWR
SURWHFWWKHF\OLQGHUYDOYH
6$)(7<&+(&.
0DNHOHDNDJHVROXWLRQE\PL[LQJSDUWOLTXLG
GLVKVRDSDQGSDUWVZDWHU
6SRRQRUEUXVKVHYHUDOGURSVRUXVHVTXLUW
ERWWOHRIWKHVROXWLRQRQWRKRVHFRQQHFWLRQ
UHJXODWRUF\OLQGHUFRQQHFWLRQ
7XUQRQJDVF\OLQGHUYDOYH,QVSHFWWKH
FRQQHFWLRQVDQGORRNIRUEXEEOHV
,IQREXEEOHVDSSHDUWKHFRQQHFWLRQLVVDIH
,IEXEEOHVDSSHDUWKHUHLVDOHDN/RRVHQDQG
UHWLJKWHQWKLVFRQQHFWLRQ,IWKHUHLVVWLOOD
OHDNSOHDVHFDOOFXVWRPHUVHUYLFH
UHJXODWRUF\OLQGHU
FRQQHFWLRQ
KRVHFRQQHFWLRQ EUXVK
)
)
2
+
*
,
+
)
)
2
+
*
,
+
12
Instruction For Installing Battery
Remove igniter button by turning
counter-clockwise.Install “AAA” battery
with positive terminal up as indicated in
diagram. Replace igniter button.
IGNITER BATTERY INSTALLATION
Ignition button
Control knob
AAA battery
Ignition button
A
P
P
U
Y
E
Z
P
O
U
R
T
O
U
R
N
E
R
P
I
L
O
T
E
P
U
S
H
T
O
T
U
R
N
P
I
L
O
T
13
OPERATION
Before turning gas supply ON
WARNING: DO NOT ATTEMPT TO OPERATE HEATER UNTIL YOU HAVE READ AND
UNDERSTAND ALL PRECAUTIONS . FAILURE TO DO SO CAN RESULT IN SERIOUS
PERSONAL INJURY, DEATH, OR PROPERTY DAMAGE.
Before Lighting
Heater should be thoroughly inspected before each use, and
by a qualified service person at least annually.
If relighting a hot heater, always wait at least 5 minutes.
This heater is tested for quality assurance. Ignition attempts
should succeed 8 out of 10 attempts.
Lighting instructions
WARNING
WARNING
WARNING
FOR YOUR SAFETY:
DO NOT touch or move heater
for at least 45 minutes after use.
Allow emitter and dome to cool
before touching.
Lighting operations should comply
with Lighting Instruction section.
Improper lighting operations will
cause serious injury and explosion.
Your heater was designed and approved for OUTDOOR
USE ONLY. DO NOT use it inside a building or any other
enclosed area.
Make sure surrounding areas are free of combustible
materials, gasoline, and other flammable vapors or liquids.
Ensure that there is no obstruction to air ventilation.
Be sure all gas connections are tight and there are no
leaks.
Be sure the access panel is clear of debris.
Be sure any component removed during assembly or
servicing is replaced and fastened prior to starting.
FOR YOUR SAFETY:
If at any time you are unable to
light burner and smell gas, wait 5
minutes to allow gas to dissipate
before attempting to light heater.
If after 1 minute, you are unable
to light burner, wait 5 minutes
and allow flammable vapors to
dissipate before attempting to
light heater.
OFF
FERM É
IGNITER
ALLUMEUR
1)
Push and turn the control knob to “OFF” position.
2˅Turn LP cylinder gas valve to fully open position.
A
P
P
U
Y
E
Z
P
O
U
R
T
O
U
R
N
E
R
P
I
L
O
T
E
P
U
S
H
T
O
T
U
R
N
P
I
L
O
T
14
OPERATION
Yellow Tip
Primarily Blue
Flame
Flame Characteristic
The flame pattern at the emitter screen should be visually
checked whenever heater is operated. Normally the burner
flame is blue, but little yellow flame is acceptable.
If the flames extend beyond the surface of the emitter grid, or
the flame is lifting off the burner or flashing back, or there is
black carbon deposits accumulating on the emitter grid or
reflector, the heater should be turned off immediately. The
heater should not be operated again until the unit is serviced
and or repaired.
3) Push and turn the control knob counter-clockwise to
the "PILOT" position. Depress the control knob. Push and
hold the igniter button until the pilot lights.
4) Once the pilot is lit, release the igniter button and
continue to depress the control knob for 30 seconds.
5) After depressing the control knob for 30 seconds, release
the control knob and turn it counter-clockwise to the “LOW”
or “HIGH” position.
Note: If the pilot light will not ignite, turn the control knob to
the off position, and fully close the propane tank valve.
Wait 5 minutes and then repeat steps 2-4.
Alternately, the pilot can be lit using a wand lighter.
Push and turn the control knob to the pilot position.
Depress the control knob. Insert the lit lighter through
the ignition hole on the emitter screen. Once the pilot
lights, remove the lighter and continue to depress the
control knob for 30 seconds.
Whenever the unit is disconnected from the gas supply,
the supply lines fill with air. Expect a delay in lighting
the pilot, if the unit is lit for the first time after
reconnecting.
OFF
FERM É
IGNITER
ALLUMEUR
A
P
P
U
Y
E
Z
P
O
U
R
T
O
U
R
N
E
R
P
I
L
O
T
E
P
U
S
H
T
O
T
U
R
N
P
I
L
O
T
A
P
P
U
Y
E
Z
P
O
U
R
T
O
U
R
N
E
R
P
I
L
O
T
E
P
U
S
H
T
O
T
U
R
N
P
I
L
O
T
15
OPERATION
NOTE:
The burner may be noisy when initially turned on. To eliminate
excessive noise from the burner, turn the Control Knob to the "LOW"
position. Then, turn the knob to the level of heater desired.
When heater is ON:
Emitter screen will become bright red due to intense heat. The color
is more visible at night. Burner will display tongues of blue flame.
These flames should not be yellow or produce thick black smoke,
indicating an obstruction of airflow through the burners.
Operation pressure checked:
If the flame is very small, this is because the supply pressure is not
enough. Please refill gas cylinder.
Re-light:
1) Turn the control knob to "OFF" position.
2) Wait five (5) minutes before attempting to relight pilot.
3) Repeat steps beginning with step 2 of the lighting instruction
above.
Shut down instructions:
1) Push in and turn control knob clockwise to "OFF" position.
2) Turn LP cylinder gas valve clockwise to "OFF" position when
heater is not in use.
Note: After use, some discoloration of the emitter screen is normal.
The Event of Gas Leakage:
1) Turn the control knob to "OFF" position.
2) Turn LP cylinder valve to “OFF” position.
3) Wait 5 minutes to allow gas to dissipate.
4) If odor continues, immediately call gas supplier.
WARNING : Heater will be hot after use.
Handle with extreme care.
CAUTION : AVOID INHALING FUMES EMITTED FROM THE HEATER'S FIRST USE. SMOKE AND
ODOR FROM THE BURNING OF OILS USED IN MANUFACTURING WILL APPEAR. BOTH
SMOKE AND ODOR WILL DISSIPATE AFTER APPROXIMATELY 30 MINUTES. THE HEATER
SHOULD NOT PRODUCE THICK BLACK SMOKE.
OFF
FERM É
IGNITER
ALLUMEUR
OFF
FERM É
IGNITER
ALLUMEUR
16
LOCATING HEADER FOR USE
CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT, ABOVE, BESIDE OR UNDER
THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE
SERIOUSLY DAMAGED.
This heater is primarily used for the heating of
outdoor patios, decks, spas, pools and open
working areas.
Always make sure that adequate fresh air
ventilation is provided. Follow the spacing
tolerances shown in Figure 1 at all times.
This heater must be placed on level, firm
ground.
Never operate in an explosive atmosphere.
Keep away from areas where gasoline or other
flammable liquids or vapors are stored or used.
17
MAINTENANCE/STORAGE
Yellow Tip
Primarily Blue
Flame
DO NOT touch or move heater for
at least 45 minutes after use. Allow
all burner elements to cool before
touching.
FOR YOUR SAFETY ;
WARNING:
Check for cracks or worn sections
NOTE:
In a salt-air environment (such as
near an ocean). corrosion occurs
more quickly than normal.
Frequently check for corroded
areas and repair them promptly.
NOTE:
Wait until heater is cool before
covering.
CLEANING AND MAINTENANCE :
To enjoy years of outstanding performance from your
heater make sure you perform the following maintenance
activities on a regular basis:
Keep exterior surfaces clean.
Use warm soapy water for cleaning. Never use
flammable of corrosive cleaning agents.
While washing your unit, be sure to keep the area
around the burner and pilot assembly dry at all times. If
the gas control is exposed to water in any way, do NOT
try to use it. It must be replaced.
Keep the appliance area free and clean from combustible
materials, gasoline and other flammable vapors and
liquids; not obstructing the flow of combustion and
ventilation air; keeping the ventilation opening(s) of the
cylinder enclosure free and clear from debris.
Gas odor with extreme yellow tipping of flame.
Heater does NOT reach the desired temperature.
Heater glow is excessively uneven.
Heater makes popping noises.
Visually check burner flames.
Screw down the screws on pole, take out the burner
head assembly.
Check if there are cracks or worn sections on hose. If
yes, please call our customer service to replace hose.
At least once a year, the unit should be inspected for
the presence of spiders, spider webs or other insects.
Air flow must be unobstructed. Keep controls, burner,
and circulating air passageways clean. Signs of possible
blockage include:
18
MAINTENANCE/STORAGE
NOTE:
Wait until heater is cool before
covering.
Turn the control knob to "OFF" position.
Turn LP cylinder to "OFF" position.
Store heater upright in an area sheltered from direct
contact with inclement weather (such as rain, sleet, hail,
snow, dust and debris).
If desired, cover heater to protect exterior surfaces and
to help prevent build up in air passages.
Spiders and insects can nest in the burner or orifices. This
dangerous condition can damage heater and render it
unsafe for use. Clean burner holes by using a heavy-duty
pipe cleaner. Compressed air may help clear away
smaller particles.
Carbon deposits may create a fire hazard. Clean dome
and engine with warm soapy water if any carbon
deposits develop.
STORAGE:
Between uses:
During periods of extended inactivity or when
transporting;
Turn the control knob to "OFF" position.
Disconnect the regulator from the LP Cylinder by turning
counter-clockwise and move to a secure, well-ventilated
location outdoors. DO NOT store in a location that will
exceed 125 degrees F.
Store heater upright in an area sheltered from direct
contact with inclement weather (such as rain, sleet, hail,
snow, dust and debris).
If desired, cover heater to protect exterior surfaces and to
help prevent build up in air passages.
19
PROBLEM PROBABLE CAUSE SOLUTION
Pilot will not light Gas valve may be OFF Turn the gas valve ON
Tank fuel empty Refill LP gas tank
Air in supply system Purge air from lines
Loose connection
Loose connection
Check all fittings
Pilot will not stay on Debris around pilot Clean dirty area
Tighten connection
Thermocouple Contact customer service
Gas leak in line Check connections
Lack of fuel pressure Fuel tank is near empty
Pressure is low Fuel tank is near empty
Control valve not ON Turn valve to ON
Thermocouple broken Contact customer service
Contact customer servicePilot light assembly bent or
not in correct location
Burner will not light
TROUBLESHOOTING
20
This product has a six month limited warranty, which covers workmanship and material quality.
NAC warrants to the original purchaser only, that when this product is subject to normal residential
use, it is free from defects in workmanship and materials for a period of six months from the original
date of purchase. This warranty does not cover damage caused by use in commercial or rental
applications, misuse, lack of maintenance, hostile environments, improper fuel/gas supply,
wind/weather damage, damage or repairs related to spider or insect nesting, accidents or altera-
tions. This warranty is non-transferable and may not be extended what so ever by any of our repre-
sentatives. The limited warranty further does not cover any scratches, dents, corrosion or discolor-
ing due to heat or damage from abrasive or chemical cleaners. NAC is not liable for any transporta-
tion costs, labor costs, or export duties relating to the delivery or installation of replacement parts.
NAC reserves the right to have its representative inspect any product or part prior to honouring any
warranty claim. Warranty is limited to providing a replacement part or a repair part, at our option,
during the warranty period. Any work or repair of this product must be performed by qualified
service personnel. The warranty period is not extended by the repair or replacement. NAC is not
responsible for the installation, labor or any other expenses associated with the re-installation of a
warranted part.
The bill of sale or copy will be required together with the serial and model numbers when making
any warranty claims. Do not return parts to our address without first obtaining a return authorization
number. The customer service department is available between 9am and 5pm (EST).
NAC Customer Care
214 Bayview Drive
Barrie, ON
Canada, L4N 4Y8
1-866-820-8686
1-705-727-4282 (fax)
This warranty may give you specific legal rights that vary by state or province.
LIMITED PRODUCT WARRANTY
This manual suits for next models
1
Table of contents
Other Napoleon Patio Heater manuals
Napoleon
Napoleon PTHC38PK User manual
Napoleon
Napoleon PTH31GT User manual
Napoleon
Napoleon PTH38PSS, PTH38PCP, PTH38PGM User manual
Napoleon
Napoleon PTH31GT User manual
Napoleon
Napoleon PTH31GT User manual
Napoleon
Napoleon Tabletop Patio Heater User manual
Napoleon
Napoleon PTH-103-3G Manual
Napoleon
Napoleon SkyFire Bellagio PTH31GTSS User manual
Napoleon
Napoleon BELLAGIO PTH31GTSSP User manual
Napoleon
Napoleon Patioflame User manual
Napoleon
Napoleon SRPH02-XXXX User manual
Napoleon
Napoleon PATIOFLAME GPFR40 User manual
Napoleon
Napoleon PTH55PSS-1 Operating instructions
Napoleon
Napoleon PATIOFLAME HAMP2 User manual
Napoleon
Napoleon PATIOFLAME GPFS40 User manual
Napoleon
Napoleon PTHC38PK User manual
Napoleon
Napoleon PTH10PSS User manual
Napoleon
Napoleon PTH40PGM User manual
Napoleon
Napoleon PTH31GT User manual
Napoleon
Napoleon TERRACE AND PATIO HEATER Operating instructions
Popular Patio Heater manuals by other brands
HomComfort
HomComfort HCPHSSQ user guide
Firesense
Firesense KLD7003SB Assembly / care & use instructions
MrHeater
MrHeater MHRP37GL Operating instructions and owner's manual
Silvercrest
Silvercrest SSH 1200 A1 Operation and safety instructions
Zanussi
Zanussi ZHPTH1 MANUAL & SAFETY INSTRUCTIONS
Herschel
Herschel FLORIDA 2000 Installation & operating instructions
