DeWalt DW887 User manual

DW887

2
English (original instructions) 2
9
16
23
30
Copyright DEWALT

1
Figure 1
Figure 3 Figure 4
A
B
C

ENGLISH
2
DIE GRINDER
DW887
Congratulations!
You have chosen a DEWALT tool. Years of
experience, thorough product development and
innovation make DEWALT one of the most reliable
partners for professional power tool users.
Technical Data
DW887
Voltage VAC 220~240
Frequency Hz 50/60
Power output W 400
No load speed min-1 25,000
Wheel diameter mm 38
Spindle M14
Collet size mm 6
Weight kg 1.7
WARNING: To reduce the risk of injury,
read the instruction manual.
General Power Tool Safety Warnings
WARNING! Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions may
result in electric shock, fire and/or
serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of electric
shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger
on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating

ENGLISH
3
part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce
dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it
was designed.
b) Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with the switch
is dangerous and must be repaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive safety
measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and
tool bits etc., in accordance with these
instructions taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
5) SERVICE
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
SAFETY INSTRUCTIONS FOR ALL OPERATIONS
Safety Warnings Common for Grinding, Sanding,
Wire Brushing, Polishing or Abrasive, Cutting-Off
Operations
a) This power tool is intended to function
as a grinder, sander, wire brush,
polisher or cut-off tool. Read all safety
warnings, instructions, illustrations and
specifications provided with this power
tool. Failure to follow all instructions listed
below may result in electric shock, fire and/or
serious injury.
b) Operations such as sanding, polishing and
wire brushing are not recommended to be
performed with this power tool. Operations
for which the power tool was not designed
may create a hazard and cause personal
injury.
c) Do not use accessories which are not
specifically designed and recommended
by the tool manufacturer. Just because the
accessory can be attached to your power
tool, it does not assure safe operation.
d) The rated speed of the accessory must
be at least equal to the maximum speed
marked on the power tool. Accessories
running faster than their rated speed can
break and fly apart.
e) The outside diameter and the thickness
of your accessory must be within the
capacity rating of your power tool.
Incorrectly sized accessories cannot be
adequately guarded or controlled.
f) The arbor size of wheels, flanges,
backing pads or any other accessory
must properly fit the spindle of the power
tool. Accessories with arbor holes that do
not match the mounting hardware of the
power tool will run out of balance, vibrate
excessively and may cause loss of control.
g) Do not use a damaged accessory.
Before each use inspect the accessory
such as abrasive wheel for chips and
cracks, backing pad for cracks, tear or
excess wear, wire brush for loose or
cracked wires. If power tool or accessory
is dropped, inspect for damage or
install an undamaged accessory. After
inspecting and installing an accessory,
position yourself and bystanders away

ENGLISH
4
from the plane of the rotating accessory
and run the power tool at maximum
no-load speed for one minute. Damaged
accessories will normally break apart during
this test time.
h) Wear personal protective equipment.
Depending on application, use face
shield, safety goggles or safety glasses.
As appropriate, wear dust mask, hearing
protectors, gloves and workshop apron
capable of stopping small abrasive or
workpiece fragments. The eye protection
must be capable of stopping flying debris
generated by various operations. The
dust mask or respirator must be capable
of filtrating particles generated by your
operation. Prolonged exposure to high
intensity noise may cause hearing loss.
i) Keep bystanders a safe distance away
from work area. Anyone entering the
work area must wear personal protective
equipment. Fragments of workpiece or of a
broken accessory may fly away and cause
injury beyond immediate area of operation.
j) Hold power tool by insulated gripping
surfaces only, when performing an
operation where the cutting accessory
may contact hidden wiring or its own
cord. Cutting accessory contacting a “live”
wire may make exposed metal parts of the
power tool “live” and shock the operator.
k) Position the cord clear of the spinning
accessory. If you lose control, the cord may
be cut or snagged and your hand or arm
may be pulled into the spinning accessory.
l) Never lay the power tool down until the
accessory has come to a complete stop.
The spinning accessory may grab the surface
and pull the power tool out of your control.
m) Do not run the power tool while carrying
it at your side. Accidental contact with the
spinning accessory could snag your clothing,
pulling the accessory into your body.
n) Regularly clean the power tool’s air vents.
The motor’s fan will draw the dust inside
the housing and excessive accumulation
of powdered metal may cause electrical
hazards.
o) Do not operate the power tool near
flammable materials. Sparks could ignite
these materials.
p) Do not use accessories that require
liquid coolants. Using water or other liquid
coolants may result in electrocution or shock.
Causes and Operator Prevention of Kickback
Kickback is a sudden reaction to a pinched
or snagged rotating wheel, backing pad,
brush or any other accessory. Pinching
or snagging causes rapid stalling of the
rotating accessory which in turn causes the
uncontrolled power tool to be forced in the
direction opposite of the accessory’s rotation
at the point of the binding.
For example, if an abrasive wheel is snagged
or pinched by the workpiece, the edge of the
wheel that is entering into the pinch point can
dig into the surface of the material causing
the wheel to climb out or kick out. The wheel
may either jump toward or away from the
operator, depending on direction of the
wheel’s movement at the point of pinching.
Abrasive wheels may also break under these
conditions.
Kickback is the result of tool misuse and/or
incorrect operating procedures or conditions
and can be avoided by taking proper
precautions as given below:
a) Maintain a firm grip on the power tool
and position your body and arm to allow
you to resist kickback forces. Always use
auxiliary handle, if provided, for maximum
control over kickback or torque reaction
during start up. The operator can control
torque reaction or kickback forces, if proper
precautions are taken.
b) Never place your hand near the rotating
accessory. Accessory may kickback over
your hand.
c) Do not position your body in the area
where power tool will move if kickback
occurs. Kickback will propel the tool in
direction opposite to the wheel’s movement
at the point of snagging.
d) Use special care when working corners,
sharp edges etc. Avoid bouncing and
snagging the accessory. Corners, sharp
edges or bouncing have a tendency to snag
the rotating accessory and cause loss of
control or kickback.
e) Do not attach a saw chain woodcarving
blade or toothed saw blade. Such blades
create frequent kickback and loss of control.
Safety Warnings Specific for Grinding and Abrasive
Cutting-Off Operations Operations
a) Use only wheel types that are
recommended for your power tool and

ENGLISH
5
the specific guard designed for the
selected wheel. Wheels for which the power
tool was not designed cannot be adequately
guarded and are unsafe.
b) Wheels must be used only for
recommended applications. For example:
do not grind with the side of cut-off
wheel. Abrasive cut-off wheels are intended
for peripheral grinding, side forces applied to
these wheels may cause them to shatter.
c) Always use undamaged wheel flanges
that are of correct size and shape for
your selected wheel. Proper wheel flanges
support the wheel thus reducing the
possibility of wheel breakage. Flanges for
cut-off wheels may be different from grinding
wheel flanges.
d) Do not use worn down wheels from larger
power tools. Wheel intended for larger
power tool is not suitable for the higher
speed of a smaller tool and may burst.
Additional Safety Warnings Specific for Abrasive
Cutting-Off Operations
a) Do not “jam” the cut-off wheel or apply
excessive pressure. Do not attempt
to make an excessive depth of cut.
Overstressing the wheel increases the loading
and susceptibility to twisting or binding of
the wheel in the cut and the possibility of
kickback or wheel breakage.
b) Do not position your body in line with and
behind the rotating wheel. When the wheel,
at the point of operation, is moving away
from your body, the possible kickback may
propel the spinning wheel and the power tool
directly at you.
c) When wheel is binding or when
interrupting a cut for any reason, switch
off the power tool and hold the power
tool motionless until the wheel comes to a
complete stop. Never attempt to remove
the cut-off wheel from the cut while the
wheel is in motion otherwise kickback
may occur. Investigate and take corrective
action to eliminate the cause of wheel
binding.
d) Do not restart the cutting operation in the
workpiece. Let the wheel reach full speed
and carefully reenter the cut. The wheel
may bind, walk up or kickback if the power
tool is restarted in the workpiece.
e) Support panels or any oversized
workpiece to minimize the risk of wheel
pinching and kickback. Large workpieces
tend to sag under their own weight. Supports
must be placed under the workpiece near
the line of cut and near the edge of the
workpiece on both sides of the wheel.
f) Use extra caution when making a “pocket
cut” into existing walls or other blind
areas. The protruding wheel may cut gas or
water pipes, electrical wiring or objects that
can cause kickback.
Safety Warnings Specific for Polishing Operations
a) Do not allow any loose portion of the
polishing bonnet or its attachment strings
to spin freely. Tuck away or trim any loose
attachment strings. Loose and spinning
attachment strings can entangle your fingers
or snag on the workpiece.
Safety Warnings Specific for Wire Brushing
Operations
a) Be aware that wire bristles are thrown by
the brush even during ordinary operation.
Do not overstress the wires by applying
excessive load to the brush. The wire
bristles can easily penetrate light clothing
and/or skin.
Additional Safety Information
tDo not use Type 11 (flaring cup) wheels
on this tool. Using inappropriate accessories
can result in injury.
tAir vents often cover moving parts and
should be avoided. Loose clothes, jewelry
or long hair can be caught in moving parts.
t Avoid prolonged contact with dust from
power sanding, sawing, grinding, drilling,
and other construction activities. Wear
protective clothing and wash exposed
areas with soap and water. Allowing dust
to get into your mouth, eyes, or lay on the
skin may promote absorption of harmful
chemicals.
WARNING: When not in use, place grinder
on a stable surface where it will not move
inadvertantly, roll or cause a tripping or
falling hazard. Serious personal injury may
result.
CAUTION: To reduce the risk of personal
injury, use extra care when working into a
corner or edge because a sudden, sharp
movement of the tool may be experienced
when the wheel or other accessory contacts
a secondary surface or a surface edge.

ENGLISH
6
t 5IFMBCFMPOZPVSUPPMNBZJODMVEFUIF
following symbols. The symbols and their
definitions are as follows:
V..................volts
A..................amperes
Hz................hertz
W.................watts
min ..............minutes
...............alternating current
...........direct current
...............alternating or direct current
................Class I Construction
no ................no load speed
....................(grounded)
................earthing terminal
................Class II Construction
.................safety alert symbol
....................(double insulated)
BPM
............beats per minute
…/min .........per minute
RPM ............revolutions per minute
IPM..............impacts per minute
sfpm ............surface feet per minute
SAVE THESE INSTRUCTIONS FOR FUTURE USE
Motor
Be sure your power supply agrees with the nameplate
marking. Voltage decrease of more than 10% will
cause loss of power and overheating. All DEWALT
tools are factory tested; if this tool does not operate,
check the power supply.
COMPONENTS (Figure 1)
WARNING: Never modify the power tool or
any part of it. Damage or personal injury
could result.
A. Paddle switch
B. Lock-on button
C. Lock-off lever
INTENDED USE
The DW887 heavy-duty die grinders have been
designed for professional grinding. DO NOT use under
wet conditions or in presence of flammable liquids or
gases.
These heavy-duty die grinders are professional power
tools. DO NOT let children come into contact with
the tool. Supervision is required when inexperienced
operators use this tool.
Switches
WARNING: Before connecting the tool to a
power source depress and release the switch
once without depressing the lock-on button
to ensure that the switch is off. Depress
and release the switch as described above
after any interruption in power supply to
the tool, such as the activation of a ground
fault interrupter, throwing of a circuit breaker,
accidental unplugging, or power failure. If
the switch is locked on, the tool will start
unexpectedly when it is reconnected.
WARNING: Grasp tool firmly with both hands
to maintain control of the tool at start up and
during use and until the wheel or accessory
stops rotating. Make sure the wheel has
come to a complete stop before laying the
tool down.
WARNING: To reduce unexpected tool
movement, do not switch the tool on or off
while under load conditions. Allow the grinder
to run up to full speed before touching the
work surface. Lift the tool from the surface
before turning the tool off.
PADDLE SWITCH – DW887 (Figure 1)
The lock-off lever (C), located on the paddle switch,
is a safety feature that prevents accidental activation
of the grinder.
To turn the tool on, push the lock-off lever (C) toward
the back of the tool, then depress the paddle switch
(A). The tool will run while the switch is depressed. Turn
the tool off by releasing the paddle switch.
WARNING: Do not disable the lock-off lever.
If the lock-off lever is disabled, the tool may
start unexpectedly when it is laid down.
Lock-on Button – DW887
The lock-on button offers increased comfort in
extended use applications. To lock the tool on, push
the lock-off lever (C) then depress the paddle switch.
With the tool running, depress the lock-on button (B).
The tool will continue to run after the paddle switch is
released.
To unlock the tool, depress and release the paddle
switch. This will cause the tool to stop.
WARNING: Allow the tool to reach full speed
before touching tool to the work surface. Lift
the tool from the work surface before turning
the tool off.
OPERATION
WARNING: To reduce the risk of serious
personal injury, turn tool off and
disconnect tool from power source before
making any adjustments or removing/

ENGLISH
7
installing attachments or accessories.
Before reconnecting the tool, depress and
release the switch to ensure that the tool
is off.
Install Grinding Wheels
1. Remove mounting nut by turning it
counterclockwise (when facing outer side of
accesssory). The spindle can be held stationary
by holding a wrench on the flats provided on the
exposed portion of the spindle.
2. Only tighten nut sufficiently to drive the wheel
without slippage.
3. When starting the tool (with a new or replacement
wheel installed) hold the tool in a well protected
area. If the wheel has an undetected crack or
flaw, it should burst in less than one minute.
Never start tool with a person in line with the
wheel. This includes the operator.
WARNING: Grasp tool firmly with both hands
to maintain control of the tool at start up and
during use and until the wheel or accessory
stops rotating. Make sure the wheel has
come to a complete stop before laying the
tool down.
Put the work in a vise or clamp it securely. Use a
face mask over the nose and mouth if the operation
raises dust. Treat the wheel with respect. do not jam
the wheel into the work or use unnecessary pressure.
Grind only on the face of the wheel (Fig. 3), unless
you have a special wheel specifically make to permit
grinding on the side of the wheel.
Precautions To Take When Sanding Paint
1. Sanding of lead based paint is NOT
RECOMMENDED due to the difficulty of
controlling the contaminated dust. The greatest
danger of lead poisoning is to children and
pregnant women.
2. Since it is difficult to identify whether or not a
paint contains lead without a chemical analysis,
we recommend the following precautions when
sanding any paint:
PERSONAL SAFETY
1. No children or pregnant women should enter
the work area where the paint sanding is being
done until all clean up is completed.
2. A dust mask or respirator should be worn by all
persons entering the work area. The filter should
be replaced daily or whenever the wearer has
difficulty breathing.
NOTE: Only those dust masks suitable for
working with lead paint dust and fumes should
be used. Ordinary painting masks do not offer
this protection. See your local hardware dealer
for the proper N.I.O.S.H. approved mask.
3. NO EATING, DRINKING or SMOKING should
be done in the work area to prevent ingesting
contaminated paint particles. Workers should
wash and clean up BEFORE eating, drinking
or smoking. Articles of food, drink, or smoking
should not be left in the work area where dust
would settle on them.
ENVIRONMENTAL SAFETY
1. Paint should be removed in such a manner as to
minimize the amount of dust generated.
2. Areas where paint removal is occurring should be
sealed with plastic sheeting of 4 mils thickness.
3. Sanding should be done in a manner to reduce
tracking of paint dust outside the work area.
CLEANING AND DISPOSAL
1. All surfaces in the work area should be vacuumed
and thoroughly cleaned daily for the duration of
the sanding project. Vacuum filter bags should
be changed frequently.
2. Plastic drop cloths should be gathered up and
disposed of along with any dust chips or other
removal debris. They should be placed in sealed
refuse receptacles and disposed of through
regular trash pick-up procedures.
During clean up, children and pregnant women
should be kept away from the immediate work
area.
3. All toys, washable furniture and utensils used by
children should be washed thoroughly before
being used again.
MAINTENANCE
WARNING: To reduce the risk of serious
personal injury, turn tool off and
disconnect tool from power source before
making any adjustments or removing/
installing attachments or accessories.
Before reconnecting the tool, depress and
release the switch to ensure that the tool
is off.
Cleaning
WARNING: Blowing dust and grit out of
motor and switch actuator using clean,
dry compressed air is a necessary regular
maintenance procedure. Dust and grit
containing metal particles often accumulate
on interior surfaces and could create an
electrical shock or electrocution if not
frequently cleaned out. It is recommended
that a ground fault circuit interrupter (GFCI)
is utilized to further protect the user from
electric shock resulting from the accumulation
of conductive particles. If the tool is
deactivated by the GFCI, unplug the tool and

ENGLISH
8
check and clean the tool before resetting the
GFCI. ALWAYS WEAR SAFETY GLASSES
(ANSI Z87.1) when cleaning or using this tool.
WARNING: Never use solvents or other harsh
chemicals for cleaning the non-metallic parts
of the tool. These chemicals m ay weaken
the plastic materials used in these parts.
Use a cloth dampened only with water and
mild soap. Never let any liquid get inside the
tool; never immerse any part of the tool into
a liquid.
Lubrication
Your power tool requires no additional lubrication.
Motor Brushes
DW887
Please contact your local service center to inspect
brushes.
Accessories
WARNING: Since accessories, other
than those offered by DeWalt, have not
been tested with this product, use of
such accessories with this tool could be
hazardous. To reduce the risk of injury, only
DeWalt, recommended accessories should
be used with this product.
Recommended accessories for use with your tool
are available at extra cost from your local dealer or
authorized service center. If you need assistance
in locating any accessory, please contact DeWalt
Industrial Tool Co., nearest to you or visit our website
www.dewalt.com.
WARNING: To reduce the risk of injury, always
use proper guards when grinding and wear
eye protection.
ACCESSORY FOR DIE GRINDERS
Mounted Stones and Points
Repairs
To assure product SAFETY and RELIABILITY, repairs,
maintenance and adjustments (including brush
inspection and replacement) should be performed by
a DeWalt factory service center, a DeWalt authorized
service center or other qualified service personnel.
Always use identical replacement parts.

࡭เᇗ໛
9
ᆸଐࠗ
DW887
܈༧Ģ
܈༧୥࿒ᄼDEWALT܅hا୕֭ࣤယތል၄֭Ӊ௞
هԿྕ൘DEWALTӶແል၄א׶܅൘Ⴐᆈ ֭ގቜ
ࠌϼᆵ၊h
࠷ඔྦྷග
၊϶א׶܅ࣦ۩
Дܽނ෶Ⴝࣦ۩ތᆿ ၣє࣊޲ҝ
1Dž৔ᔫޝ࢐
a)
b)
c)
א࿪
௜
܇ඃԣ
ᄣሏූ
ೱઅᆸ࣭
ᇾᇨ
๫ࡋԌղ
ᇟ
VAC
Hz
W
min-1
mm
mm
kg
220~240
50/60
400
25,000
38
M14
6
17
DW887
ࣦ۩Ļແࢎֶൻഌڌཊ,౰ስ༭ᄏ؈ၣ༷
૵ඕh
ࣦ۩ᇗ֭“א׶܅”ᆋ၊ඔნᆿ֭൦୥֭ႶאჿҨቜĩփ
אཔ֭Īࠏאԅಂ׶֭ĩ໵אཔ֭Īא׶܅h
ࣦ۩!஺༿ᏞࣗჅᎌڔཝவসᎧᒎฉăೊ໋
େቖ࿞ᆋོࣦ۩ތᆿ଺ĭࢄେ֥ᇉ԰אĭ
ࠍᄡތ/ࠏကᇟഌݥh
ۣߒ৔ᔫޝ࢐༹ஈීೡLjᄞઁࠏႄψׁ֭٢ೀ
ၦႌهൡܫh
ணᒏᏴ ۬ણஹᒦݷᔫ࢟ࣅ৔௥Ljྙᎌ ཮ጘᄏĂ
໮ᄏ૞޺ࡼણஹăא׶܅Ӊ഻֭ࠍ߅߾׌ಟ
ڀӫࠏ࿽༄h
ݷᔑ࢟ࣅ৔௥ဟணᒏᄷ๬ᑗణதăیನେ
߾֥ᇉ୥ҨቜҊ֚h
2Dž࢟໭ڔཝ
a)
b)
c)
d)
a)
b)
c)
d)
e)
f )
࢟ࣅ৔௥ރᄿܘኍᎧᄴৃࡼރᔭࡈ๼ăணᒏጲ
ྀါখᓤރᄿă
ኊገ୻࢐ࡼ࢟ࣅ৔௥ݙถဧ፿ྀᓞ୻ރᄿăჸ
Ӕ෶ۀ֭Ҵ๰ი๥݇۴֭Ҵ቞ࢄࡰച԰א຺֭
ཊh
ܜ඾ཽᄏᎧ୻࢐ܭෂ୻߿-ྙࡸĂྲེ໭Ăഭ
ᐈĂܹረăೊݜ୥֭മเࢬׁĭ԰א຺ཊྦྷ߾ᅁ
ࡎh
༿ᇖ୓࢟ࣅ৔௥۩ഴᏴᎦᒦ૞ޭဘણஹᒦăא׶
܅࣑ණࢄᅁࡎ԰א຺ཊh
༤ᇖಆ፿࢟ሣă༤ᇖဧ፿࢟ᏎሣۃᏥĂ౯ࣅ૞ڰ
ሆ࢟ࣅ৔௥ăۣߒ࢟ᏎሣᏐಭེᏎĂᎉĂྣܟ૞
Ꮵࣅݝୈhൻ෭ࠏӇ಩֭אཔ߾ᅁࡎ԰א຺֭
ཊh
Ᏼ၀ᅪݷᔫ࢟ࣅ৔௥ဟLj༿ဧ፿းઓᅪဧ፿ࡼ
ᅪ୻࢟ሣă൩ގ߄ປ൘Ⴐ֭אཔ߾ࡰച԰א຺֭
ཊh
ྙܘኍࡻᏴޭဘࡼ࢐ݷᔫ࢟ࣅ৔௥Lj༿ဧ፿
ထ᎜࢟ഗᓤᒙDŽRCDDžۣઐࡼ࢟ᏎăRCD ֭൘Ⴐ
ࡰച԰א຺֭ཊh
3Džཽ࿽ڔཝ
ۣߒவ௻Ljݷᔫ࢟ࣅ৔௥ဟᓖፀݷᔫLjۣߒ༹
ታă༤ᇖᏴນ௱૞ᒤ೦ဟ૞Ᏼጇᇕ૞ௌறࡼ፬ሰ
ሆဧ፿࢟ࣅ৔௥ăҨቜא׶܅൐ሇၱ৷Ҋࠪᇗ
େ߾֥ᇉကᇟ֭ಮമഌݥh
ဧ፿ৈཽઐᓤ۸ăဪᒫ๽ࡑઐ෹஻ă൩֚֭๐
ࡹ༷൘Ⴐ٥߁ሕЩࢄࡰചಮമഌݥĭೊ٥ӫ
ᅿg٥߉υಎཿgυಎાg๘৷Д߁ഩЩh
ᒏፀᅪ໪ࣅăᏴೌ୻࢟Ꮞ૞࢟ߔᔝᒄ༄ጲૺ෽
໦૞ቑࡒ৔௥ᒄ༄༿ཀྵۣఎࠀ᎖ܕᆡᒙăྂ
փא׶܅൐Ϥ൵ᆿ٪ᄥܹഐࠏԑא൐ܹԱ
Ⴧս໒ᇊ߾ᄷӶಮമ຺ཊh
ࡌఎ৔௥༄ގሆჅᎌࢯᑳ୆૞ۄ၄ă৽ࢬᄥא׶
܅࿐ሏࡹഐ֭ϵ൵ࠏנᆤࡷେ֥ᇉಮമഌ
ݥh

࡭เᇗ໛
10
e)
f )
g)
ணᒏ၄࿼ࡻვޠLjဟరᓖፀ୭ሆ࿽ᄏຳăᆋ
ဪᄥၱປ౮ঋ༷େۿނׁᇍא׶܅h
ࠃᓹࡻࡩăݷᔫ࢟ࣅ৔௥ဟ༤ଓࠃ౑႕ࡼጠ૞
๽ࡑ၅ြăཱུิࡼᄿĂጠ၄ᄁᏐಭᏥࣅࡼ
ഃୈăংෆ֭ၑڣg൶൭ࠏӑهେ߾೎ᄖ׶
ࡹᇗh
ྙᎌᄋ৙ೌ୻๝቞ૹ޺࿸۸ࡼᓤᒙLj༿ཀྵۣᑚ
ቋᓤᒙೌ୻ᅲLjဧ፿ᑵޟă ࠪӫࡰചიڀӫ
Ⴝ຺ܹ֭ݥh
a)
b)
c)
d)
e)
f )
g)
a)
ணᒏ༓ᒜဧ፿࢟ࣅ৔௥ăো௣፿ᅆLjဧ፿ᑵཀྵࡼ
࢟ࣅ৔௥ăᆦಚ֭א׶܅ᄥഩࡁ֭صׯ܇༷
େۿނۿυಎׁຣӶ܅ቜh
ணᒏဧ፿ఎݙถࡌఎܕࡼ࢟ࣅ৔௥ăಱލ
ҊେႰܹᇍ֭א׶܅؃ޛ຺ཊĭщ྾࣑ྣ
ྱৠh
ࢯᑳĂৎધএୈ૞߼ࡀ࢟ࣅ৔௥༄Lj༿୓࢟ࣅ৔
௥࢟Ꮞރᄿ૞࢟ߔᔝࣥఎă ᆋᇝჯ٥ྦྷυಎն
ൈେࡰചၱປఛ׶א׶܅֭ڌཊh
୓࢟ࣅ৔௥߼ࡀᏴᄷݙถ৫ᓹࡼ࢐Ljணᒏݙ
ၚᇨ࢟ࣅ৔௥૞۾ႁීၗࡼཽݷᔫ࢟ࣅ৔௥ăದ
໋ࣤ࿦֭Ⴐ߄Ҩቜא׶܅൦ޛ຺ཊ֭h
ۣዸ࢟ࣅ৔௥ăଶއᏥࣅݝୈဵఌᓕLjဵ࣪
ᓰLjഃୈဵຼႼLjጲૺဵᎌ໚Ⴧభถ፬ሰ࢟
ࣅ৔௥ݷᔫࡼ༽ౚăྙᎌႼડLj༿Ᏼဧ፿༄࣪࢟
ࣅ৔௥஠ቲᆒኀă࿀اൡܫ൦ႶჇא׶܅ໃ
߁Ҋؿه഻֭h
ۣߒ࡮௥ಽ༹ஈLjຐഇДဩڋ৮ౕ֭ཬ܅
ĭ൘ҨቜҊೀၦሆĭ౗ۿೀၦᇍh
༿ো௣ᑚቋݷᔫᒎာဧ፿࢟ࣅ৔௥Ă๼ୈ༤ী
৔௥ࢀLj݀༦ఠ൅৔ᔫᄟୈገᒊቲࡼ৔ᔫăࢄ
א׶܅ႰჇҊ൦ჯఁ֭ҨቜႰ๷େ߾֥ᇉ຺
ཊ౮ঋh
༿ཱུৃࡼᆒኀཽᏋᆒኀิࡼ৔௥Ljໃྱಮჼᇂ
େ൘Ⴐཕ๥֭ۿߘࡹၣಚДא׶܅֭υಎྦྷ
େh
෶ႽҨቜυಎᆿ
4Dž࢟ࣅ৔௥ࡼဧ፿ᓖፀሲ
5Džᇗ
a)
b)
c)
d)
e)
f )
g )
۾࢟ࣅ৔௥Ꮎ໐፿ᔫዐෟ૦Lj࿀ൔ૦LjনႋၮLj
๯૦૞༤ী૦৔௥ă஺༿Ꮮࣗ ۾࢟ࣅ৔௥ᄋ
৙ࡼჅᎌڔཝவসLjᒎฉLjᅄာૺăೊݜ໋
େቖ࿞෶ԣ֭ᆿ଺ĭࢄେ֥ᇉאࠔĭࠍᄡތ/
ࠏကᇟಮമഌݥh
୐ፇᇖ୓۾࢟ࣅ৔௥፿᎖ስዐෟLj๯ጲૺনႋ
ၮᑚಢࡼᔫጓăೊݜࢄЯא׶܅ႰჇഩࡁପ֭
ቜ၄େӉ഻຺ཊތႌగಮമഌݥh
༤ᇖဧ፿ᓜඡ࿸ଐࡼጲૺ۾৔௥ᒜᐆ࿜ᅎୀ
ࡼএୈăࣘܽᆋོۀࡹେܜሕᄥ୥֭א׶܅
ഐĭ෹ѱҊେಚДυಎቜ၄h
এୈࡼࢾႥࣞܘኍᒗ࿩ࢀ᎖Ᏼ۾࢟ࣅ৔௥࿟ܪ
߲ࡼࢾႥࣞăೊݜۀࡹၣәݞصׯූ ᄖྣĭ
෹૔େ௭෭ࠏཧປٮԣh
ิࡼএୈᅪ஼Ꭷࣞܘኍࠀ᎖ิࡼ࢟ࣅ৔௥ࡼ
ࢾྏ೟ดăೊݜۀࡹԌղҊڠĭࢄ໵ٍ֦֬ద֚
֭Д߁ތᇍh
࿀ൔࡼ૦ᒷߛࡁLj౾Ljᑽ߁࢞૞ྀএୈܘኍ
Ꭷ۾࢟ࣅ৔௥ࡼᓍᒷ໵ࡩᆭăೊݜҘႰփႽი
Яא׶܅֭υሕ႟ࡹҊໞގ֭ࠗᇨ֭ۀࡹĭ
ࢄ߾െಈ௤ޡĭᆚ׶ĭ๥൐େ֥ᇉെh
ౕ༇൘Ⴐൻ෭ۀࡹh
ඛࠨဧ፿༄Ljଶއሆ೰এୈǖࡌෟ࿀ൔဵᎌႵ
቞૞ೱᆬLjᑽ߁࢞ဵᎌೱᆬLj౯࿛૞ࣞෟ
ႼLjনႋၮဵᎌ႕ࣅ૞ఎೱনႋăྙݙဇ୓
࢟ࣅ৔௥૞এୈၰൢLjଶއ໚ဵᎌຼႼLj૞ڔ
ᓤጙᒑᆚ၊Ⴜࡼএୈă!
ଶއڔᓤᅲএୈઁLjཱུᔈ଄๬ᑗࠀ᎖কኟ
ᓞএୈࡼຳෂᅪLjᄴဟLjཱུ۾࢟ࣅ৔௥ጲᔢࡍహ
ᏲႥࣞᏥᓞጙᒩăൻ෭Ҏࡹ߾ᄥᆋ၊൳ယ൐࡟
୅ෆຊh
ዐෟ, ࡌෟ, নႋၮ, ๯૞ෟ೯Lj༤ীᔫጓޟ፿ڔ
ཝவস

࡭เᇗ໛
11
h)
i)
ࠃࡑৈཽઐ࿸۸ăጞ௣ݙᄴࡼ።፿Ljဧ፿ෂ
ᑎLjڔཝઐ෹஻૞ڔཝዛ஻ăᏴ໵ࡩ༽ተሆ๽ࡒ
޺ෂᑎLjઐ໭Ljถ৫ᔜࡪᇼᆈෟ೯૞৔ୈႵ
్ࡼ৔ᔫᆍཫăဌ࣬Д߁ሕᇊщ྾େܜቍᇀႶۺ
ᇝቜ၄Ӊ഻֭ٮࡿ෦h٥ӫ૳ᅿࠏ޳༓ఞщ྾େ
ܜݞ୥֭ቜ၄Ӊ഻ູ֭৴hӑఁКჇۢౄ
֭ᄶႃେ֥ᇉ๘৷೦െh
ཱུ๬ᑗᏐಭᔫጓෂă஠ྜྷᔫጓෂࡼྀཽ࣒ܘ
ኍ๽ࡒৈཽۣઐᓤᒙă܅ࡹ֭෦ྏࠏ௭෭֭ۀࡹ
େཧປٮࡿĭ๥൐ᄥቜ၄ۀ֭ࣕ౽ჟປႌగ෭
ഌh
ᔫጓဟLjྙᔫጓཌᎮࡼএୈ༤ীభถᎧ፜ݶࡼ
࢟ሣ૞໚࢟ሣ୻߿Ljᑚဟᒑถᆻᓕ௾Ꮟࡼڳᆻܭ
ෂăౕ۱ი“փא”֭אཔࢬ԰֭ۀࡹେ൘Яא
׶܅К֭ࣉඓҎٻփאĭ൘Ҩቜᆈᄭൻא
ࠔh
୓࢟Ꮞሣᒙ᎖Ꮠಭኟᓞএୈࡼᆡᒙăೊݜ୥െಈ
ᇍ, ᆋۼאཔେ߾Ь۱ؖࠏӇሆĭ๥൐୥֭
൵ьࠏ൵ᅯେ߾Ьሌ࣑࿐ሏ֭ۀࡹh
۾৔௥এୈᆚᅲཝᄫᒏᒄ༄Ljݙࡻ୓࢟ࣅ৔௥
ሆă࿐ሏ֭ۀࡹେ߾ሊሆў૳ĭঠ׶Яא׶܅
൘ᆵെಈ୥؛ఋ֭ᇍh
ࡩิᏴݾෂۃᏥ۾࢟ࣅ৔௥ဟLj༤ᇖဧᒄᏥᓞă
ი࿐ሏ֭ۀࡹ֭ၱປࢬ԰ĭେӇሆ୥֭ၑ༆ĭ
ᄷӶၱປഌݥh
ࢾ໐༹ஈ۾࢟ࣅ৔௥ࡼᄰాăאࠗڌഉ߾ࢄ߯
ӫ༓࣑ປ୅ĭ๥൐ڀሙࣉඓ֭ݞ ؘࠚେᄷ
Ӷא຺ཊh
༤ᇖᏴ ཮ݢ೯এதݷᔫ۾࢟ࣅ৔௥ăࠍ߅େ
׌ಟᆋོғh
༤ᇖဧ፿ገཇጘზದསଋࡼএୈăೊݜ൘Ⴐණࠏ
ఋ෹၉เৗಗ࠼ĭେ֥ᇉאࠔࠏ԰אh
j )
k)
l )
m)
n)
o)
p)
֭ٙ֘ჸႁތҨቜᆈჯ٥
a)
b)
c)
d)
e)
ٙ֘൦؛୪୞ࠏӇ಩֭࿐ሏೱઅĭᆮӲ׏ĭۙ඼
ඟࠏಱލఋ෹ۀࡹ֭၊۹๴ಞٙ႓h୪୞ࠏӇ಩
ႌగ࿐ሏۀࡹ֭๴ಞ๜ᇀĭᆋ၊౮ྡ߾၏ՙ൘െ
ಈᇍ֭א׶܅ᄥ׌ሏ೎იۀࡹ࿐ሏཕ֭ٙ
٢ཧh
ৰೊĭೊݜଐ௓Ь܅ࡹሆĭେ߾֥ᇉଐ௓ຊ
৞ࠏٮԣhႶჇఋᄖ׶٢ཧҊ๥ĭ෹େ߾Ӝሪ
Ҩቜᆈࠏᄁ৞Ҩቜᆈ֘ԣhᄥଞོ౮ঋ༷ĭଐ௓
ശᇈ߾௭h
ٙ֘ႶষႰތ/ࠏո༊֭Ҩቜӹ࿅ࠏሙঋႌగĭ๥
൐ĭ๡ݞҘ಄༷ۻԣ֭ჯ٥նൈєၣ؛ఋ࣑
ྣ٥ᇀ:
ஜᆻ۾࢟ࣅ৔௥Ljᄴဟ୓ิࡼ࿽ᄏᎧ၄ܛᒙ᎖ิ
ถ৫ࢎᎵࡧೆ೟ࡼᆡᒙăᄰᄋ৙ᓐڳ၄Lj
ᒗဪᒗᒫဧ፿჈LjጲܣᏴ໪ࣅ໐ମ૝ࡻ࣪ࡧ૞
ಿ௪።ࡼᔢࡍ఼ᒜăೊݜҘ಄ద֚֭ჯ٥ն
ൈĭҨቜᆈၣᇍ৷ٙ႓ࠏٙ֘৷h
༤ᇖ୓ิࡼ၄ܛᏴኟᓞࡼএୈ๬ăۀࡹେഌ
ݥ୥֭൵ьh
༤ᇖ୓ิࡼ࿽ᄏᒗ᎖Ᏼ࢟ࣅ৔௥ࡧဟ୓્ጤࣅ
ࡼᆡᒙăٙ֘߾ᄥ୪୞֭ଲ၊ࢄЯ܅Ӝሪი
ೱઅཕ֭ٙ٢ཧಂ׶h
Ᏼ୯ൢLjବྣࡼܟ୯ࢀཌᎮᔫጓဟLjኊገလட
ဇăэ૯൘ۀࡹ֘๓ࠏӇ಩hࢠઓĭ࡝೔ѐࢠࠏ
֘๓າາ߾൘࿐ሏ֭ۀࡹӇ಩ĭѱ౗ႌగെࠏ
ٙ֘h
༤ᇖᓤ࿟௨೔෸ࢩ࡮ຢ૞ߙቯ௨ຢăᆋ৓֟௓߾
ᄷӶ௜ٖ֭ٙ֘იെh

࡭เᇗ໛
12
a)
b)
c)
d)
f ) Ᏼሚᎌࡼܚ࿟૞໚᎜඀ཌᔪጙৈĐ༏ݹ༤ాđဟ
ܘኍလடဇă๲ԣ֭ೱઅେౕؖેటࠏණܽ
֩ĭאཔࠏ༆เେ߾ႌగٙ֘ h
a) ༤ᇖཱུ๯ฌ૞໚এୈࡼဎᔇᔈᎅኟᓞă୓ྀ
႕ࣅࡼএୈဎᔇݶ૞୓໚ኀᑳăෆ׶ތ࿐ሏ
֭ۀࡹിሸେӇሆ୥֭൵ᆿĭࠏӇࢺᄥ܅ࡹ
ഐh
ᆔ؛սଐތခଐࣦ֭۩
༤ীᔫጓ!
ᒑถဧ፿ᆐิࡼ࢟ࣅ৔௥ᅎୀࡼ࿀ൔಢቯጲૺᆐ
Ⴥኡᐋࡼ࿀ൔ࿸ଐࡼઐۇă٬ແЯא׶܅ഩࡁ
֭ೱઅ໵ٍ֦֬ద֚֭٥߁ĭ๥൐၁Ҋυಎh
ᒑถ୓࿀ൔ፿᎖ᅎୀࡼ፿ᅆă!ಿྙLj༤ᇖ፿༤ী
࿀ൔࡼܟ୯஠ቲࡌෟăೊݜϤଐ௓ѐࢠႰቜჇս
ଐĭଲુൈࡎჇೱઅү૳֭৷େ߾൘ଐ௓௭
෭h
ᒗဪᒗᒫኡᐋᅲࡼLjߛࡁࡍቃᎧෟຢປ๼ࡼ
౾ăద֚֭ೱઅٍয฼܊ೱઅ֭ނᆮӲĭ՞ؿ
ࡰചೱઅ௭෭֭େྦྷhႰჇౕ۱ೱઅٍ֭যი
սଐೱઅٍ֭য၁࿀Ⴝ෶Ҋ๥h
༤ᇖဧ፿౶ᔈ୷ࡍࡼ࢟ࣅ৔௥ࡼෟႼࡼ࿀ൔăჯ
ఁႰჇࢨվ֭א׶܅֭ೱઅҊ൩ގࢨུ܅֭
ۢූĭ๥൐େНh
a)
b)
c)
d)
e)
ᆔ؛սଐތခଐࣦ֭۩
༤ীᔫጓ
ᆔ؛஠݃ቜ၄ࣦ֭۩
a) ኊᓖፀ૾ဧᏴ໋ᄰᔫጓᒦLjনႋၮ࣒ᎌభถၲ߲
নႋă༤ᇖᄰ৊নႋၮဗଝࣞࡼኹೆဧন
ႋ၊ೆࡍăۙ඼େܜ౦ၦׁԴ๱В֭ڣሕތ/ࠏ
ோڙh
ᆔ؛ۙ඼ඟቜ၄ࣦ֭۩
༤ᇖᏴࠥ৔௥࿟ဧ፿22ቯDŽᏌᓪᅳቯDž࿀ൔăೊ
ݜ൘ႰҊద֭ۀࡹĭେ֥ᇉൻഌh
ᄰ໮఻ᄰޟ્঄ঙጤࣅݝୈLjፐࠥ።ࡩܜ඾ăং
ෆ֭ၑ༆ĭᇰЗࠏӑهେ߾Ьၕ׶Ҏࡹሆh
ܜ඾Ꭷ౶ᔈࣅೆࡌෟLj௨ᔇLjዐෟLjᔞ఻ጲૺ໚
჈୐ᓔ૚ࣅᒦޘညࡼા޺ޠဟମࡼ୻߿ăࠃ
ઐLjᄴဟ፿ᐇ༹ၺߡᇸ۩ഴࡼཌᎮăೊݜ
߯ӫ࣑೎୥֭ቑҎĭဌҎࠏӮࠚᄥ୥֭ோڙഐĭ
େ߾դ൘Ⴝݥ༆ᇑ֭༓൴h
ࣦ۩: ৔௥ݙဧ፿ဟLj።୓჈ᒙᏴጙৈݙ્ፀ
ᅪጤࣅࡼᆮࢾܭෂLjጲ඾໚ፀᅪࣅ૞፛໦ۏࡱ
૞ၰࡱࡼᆉሙăᆋେ֥ᇉကᇟ֭ಮമഌݥh
۩ࣄ: ແࡰചಮമഌݥ຺֭ཊĭᄥയ೎ࢠઓࠏѐ
ࢠቜ၄൐ྻ۴ປ࣐സĭႁແЯ܅ࠏఋ෹Ҏࡹࢬ
԰֦၊۹ՙ࠱ў૳ࠏ௤૳ѐࢠ൐ĭ෹֭େ߾๴
ಞތᄖ׶h
صປ֭υಎ྘༗
༤ᇖ! Đᔜྭđ! ༤ী࿀ൔ૞ဗଝࡍࡼኹೆă༤
ᇖޞ၂ᔪ࿾ࡼ༤ীăೱઅൻ࿪ݞվ߾ᅁࡎڽ
ᄣĭၣࠫ൘ౕᇗ֭ೱઅೀၦ୭౿ࠏຝᆄĭ๥൐
ߖେ֥ᇉٙ֘ࠏೱઅ௭෭h
ݙገ୓࿽ᄏᆡ᎖ኟᓞෟຢࡼᑵ༄૞ᑵઁăᄥᄖ
ቜ֭၊ĭ֚ೱઅ՞୥മѐၕቄ൐ĭେԣཋ֭
ٙ֘େ߾ࢄ࿐ሏ֭ೱઅތЯא׶܅Ӝཧ୥ಂ
׶h
ࡩ࿀ൔۻఌᓕLj૞ᑗ߲᎖ྀᏇፐᒦࣥ༤ীဟLj
ܕ۾࢟ࣅ৔௥Ljᄴဟஸᆻᓕ۾࢟ࣅ৔௥Ljᒇࡵ
࿀ൔጯளᅲཝᄫᒏኟᓞă༤ᇖ၂ᅄᏴ࿀ൔ྆཭ኟ
ᓞဟ࠭༤ా࿟ގ߹༤ীൔLjᐌ୓્્ည
ࡧă!ଋ౪౮ঋĭѱ౗Ҙ಄࢜ᆦնൈၣ཰ԪೱઅЬ
ཋཨh
༿Ᏼ༤ীᔫጓఎဪᒄ༄ఎ໪૦໭Lj݀Ᏼ༤ীᔫጓ
ᅲ߅ઁLj୓૦໭෽ಭᔫጓܭෂઁܕ૦໭ăದೱ
અպ֦ಎූĭಞ޲ུྗׁᇟྕ࣑೎ౕhೊݜᄥ
܅ࡹᇗᇟྕఛЯא׶܅ĭೱઅେЬሆĭ
ཧഐ๲ԣࠏٙ֘h
࣪ۇୈ૞ྀިࡍࡼ৔ୈኊገᔪᑽ߁Ljጲܣ୓࿀
ൔอჁᎧࡧࡼᆉሙଢ଼ࢅࡵᔢቃăվ܅ࡹେ߾
ᄥሹമ֭ᇟ༷ԣཋϏདྷh
щ྾ࢄᆮӲ༆٪ᇊᄥ܅ࡹ༷Ҏౕ֭۱པۀࣕၣࠫ
ೱઅ஝܅ࡹ֭ѐࢠԱh

࡭เᇗ໛
13
࢟૦
ಚД ୥֭אჿიଇஏഐ֭ћൕໞގh 10%ၣഐא࿪༷ࢎ
߾֥ᇉ܇೦െތݞಫh෶ႽDEWALT܅ࣤݞԣӔࡧ
ယhೊЯ܅Ҋେᄖቜĭ౰ࡧҸאჿh
Ҏࡹ (๵1)
A. ᅋ૒൜ܹ
B. ෵ׯχ୮
C. ෵ێ
Ꮎ໐፿ᅆ
DW887ᇟྠᆸଐࠗഩࡁႰჇል၄սଐhౕ༇ᄥӞ൉ሙঋ
ࠏႽၦಟ၉เࠏటเ൐൘ႰЯ܅h
ᆋོᇟྠᆸଐࠗແል၄א׶܅hౕ༇ದـ๨ࢬ԰Я܅
h໵ࣤယ֭Ҩቜᆈ൘ႰЯ܅൐ྻ္ࡎၣ࡛؄h
Дܽނᆋོᆿ ၣє࣊޲ҝ
୥֭܅ഐ֭ћమЏছ༷ڠބhᆋོڠބࠫఋ
ݫၴ඲଄ೊ༷!
V .................. ڡำ
A .................. υன
Hz .................. ޔር
W ................. ຘำ
min.................. ٻᇚ
.............. ࢔א
........... ᆸא
.............. ࢔ࠏᆸא
............... ၊࠱ࢁᄷ
no ................ ᄣූ
(փႽࢬׁ)
................ ࢬׁؒሸ
................ م࠱ࢁᄷ
................ υಎࣦ൝ڠބ
(ඨᇟᄀ)
BPM ............
ૌٻᇚԒࠔග
…/min ......... ૌٻᇚ
RPM ............
ૌٻᇚሏග
IPM ............. ૌٻᇚԒࠔග
sfpm ............ ૌٻᇚў૳ႏԌග
ࣦ۩: Ҋ֬ۇሕЯא׶܅ࠏఋಱލҎࡹhᆋ
େ֥ᇉ෭ߒࠏಮമഌݥh
ఎ
Ҩቜ
ࣦ۩: ࢄЯ܅ࢬഐאჿళĭχ༷ಞ޲ෆܹ
၊ՙؿҊ္χ༷෵ׯχ୮ĭၣಚДܹԱჇۢؒ
ሙงh
Я܅֭אჿԣཋಱލᇗؖĭೊࢬׁܫ ؖఞ
֭ఛ׶ĭؖఞቜႰĭၱປ֭ϡԣҴ๰ࠏؖא, ೊ
ഐ෶൝χ༷ތ൬٪ܹhೊݜܹЬ෵ׯᄥఛ
໒ᇊĭ๡א൐Я܅߾ၱປఛ׶h
ࣦ۩: ᄥఛ׶ތ൘Ⴐఁ࡟ĭႰඨ൵࣍໬Я܅ၣ
ໃԃ؛ఋ֭ᇍĭᆸ֦ೱઅࠏۀࡹ๜ᇀሏ׶൐ແ
ᇀhᇂႽᄥಚׯೱઅၠࣤຣಎ๜ᇀሏ׶޲ĭҔେ
ࢄЯ܅٪༷ h
ࣦ۩: ແࡰചၱປ֭܅ᄖ׶ĭౕ༇ ᄥڽᄣ๐
ࡹ༷սࠏܹцЯ܅hࢬ԰ቜ၄૳ᆵవĭದᆸ
ଐࠗᄖሏᇈಎූhࢄЯ܅ܹцవĭ༽ࢄఋ՞ቜ
၄૳ขగh
ᅋ૒൜ܹ – DW887 (๵1)
෵ێ (C), ໒Ⴧᅋ૒൜ܹഐ, ෹൦٥ᇀᆸଐࠗၱປఛ׶
֭၊۹υಎሕᇊh
սЯ܅൐,ࢄ෵ێ (C)ӜЯ܅֭޲Ҏ๿, ಞ޲χ༷
ᅋ૒൜ܹ (A)hᄥܹχ༷൐ĭЯ܅ࢄ߾ᄖሏh൬٪
ۆᅋ૒൜ܹєܹцЯ܅h
Ⴤࢾږ฽ – DW887
෵ׯχ୮ᄥငӑ൘Ⴐ֭႓Ⴐᇗ฼܊ۿا֭අ൩ۓhࢄЯ
܅ս൐ĭ๿׶෵ێ (C) ĭಞ޲χ༷ᅋ૒൜ܹh ᄥ
Я܅ᄖሏ൐ĭχ༷෵ׯχ୮ (B)hЯ܅ࢄ৽࿋࿐ሏᆸ
֦ۆᅋ૒൜ܹЬෆ൐ແᇀh
ࢄЯ܅ܹц൐, χ༷ಞ޲൬٪ᅋ૒൜ܹhᆋࢄ൘Я܅
๜ᇀh
ࣦ۩: ౕ༇ܹц෵ێhೊݜ෵ێЬܹц, ֚
Ь٪༷൐ĭ෹Ⴝେၱປఛ׶h
ࣦ۩: ᄥЯ܅ࢬ԰ቜ၄૳వĭದ෹պ֦ಎූh
ࢄЯ܅ܹцవĭ༽ࢄఋ՞ቜ၄૳ขగh
ࣦ۩: ᆐଢ଼ࢅዏᒮཽ࿽࿛ࡼᆉሙ-!Ᏼᔪྀࢯ
ᑳ૞ގ߹0ڔᓤྀএၢᇕ૞এୈ༄Ljሌ୓۾৔௥
ܕLj୓ރᄿ࠭࢟Ꮞރᔭ࿟ڰ߲ă
ᒮቤೌ୻۾৔௥༄Ljږሆ཭ઁ႕ఎఎጲཀྵۣ۾
৔௥ࠀ᎖ܕᓨზă

࡭เᇗ໛
14
ࣦ۩: ᄥఛ׶ތ൩Ⴐఁ࡟ĭႰඨ൵࣍໬Я܅
ၣໃԃ؛ఋᇍĭᆸ֦ೱઅࠏۀࡹ๜ᇀሏ׶ແ
ᇀhࢄЯ܅٪༷వĭಚДೱઅၠࣤຣಎ๜ᇀሏ
׶h
ࢄ܅ࡹ٪࣑၊ᇂ޿๰ఴĭࠏࢄఋࡋ࣍hೊݜቜ၄ဠగӫ
ζĭ౰ᄥиሸҎ໒൘Ⴐᅿh္ഇֈೱઅhౕ༇ࢄೱઅ
ࡋᄥ܅ࡹᇗĭࠏൈࡎҊщ္֭࿪৷hᇂେᄥೱઅў૳ခ
ଐ( ๵3), Ԫ٬୥ႢႽ၊ᇂำᇍ֭ĭᄕ࿀ᄥఋү૳ခଐ֭
ำඁೱઅh
඲଄: ᇂେܜ൘Ⴐ൩ႰჇఫྦྷႺఈ߯ӫތ࿽༄֭٥ӫ
ᅿh௼๡֭ႺఈᅿҊେ฼܊ᆋᇝД߁h౰֦୥ׁ֚֭
໼ࣉד࿡ᅻద֚֭N.I.O.S.H.௃ሡ֭֭ᅿh
ࣦ۩: ᆐଢ଼ࢅዏᒮཽ࿽࿛ࡼᆉሙ-!ᔪྀࢯᑳ
૞ގ߹0ڔᓤএၢອ૞এୈ༄Ljܕ۾৔௥݀༦༤
ࣥ໚࢟Ꮞăᒮቤೌ୻۾৔௥༄Lj!ږሆ݀႕ఎ࢟Ꮞ
ఎLjጲཀྵۣ۾৔௥ጯளࢬă
1.
2.
3.
ڔᓤࡌෟൔ
ᎉ໗ࡌෟဟࡼᓖፀူሲ
ણஹڔཝ
ĩ֚૳؛ۀࡹ֭ປү൐Īࢄυሕઌඥဉ୑൐ᆔ࿐
ሏࢄఋҿԪhᇂྻႰ၊ᇂϵ൵໬ሆᄥᇾᇨ֭К
Ҏٻ฼܊֭௤ϸĭє൘ᇾᇨДԃࣩᇀh
ࢄઌඥ୪࣍ᇈቈၣ൘ೱઅҊս߉࿐ሏແᇀh
ĩᄥυሕ၊ᇝྕ֭ࠏแօೱઅ൐Īఛ׶Я܅
ĭᄥ၊۹ൻ֦ނД߁֭౽ჟ໬ሆЯ܅hೊ
ݜೱઅႽ၊۹໋ࡧұԣ֭ໝࠏಔདྷĭ෹႓֚߾
ᄥҊ֦၊ٻᇚ֭൐࡟୅Нhౕ༇ᄥೱઅ؛ሪ၊
۹ಮ֭౮ঋ༷ࢄఋఛhЏছҨቜᆈЯമh
1.
2.
Ҋ๿ࡱႰჇսଐఫࠖႺఈĭႁແൻ֦໲ಡ֭߯ӫ
଼ၣᇍhఫ؛ـ๨იᄛہ຺֭ཊ վh
ႶჇҊࣤݞߌ࿘ٻ།є଼ჇஙؖଞᇝႺఈ൦ږݫ
ႽఫĭႁՖ࣑ྣಱލႺఈ֭սଐ൐ĭ໩૔๿ࡱ༷
ሇၱൡལh
ཽ࿽ڔཝ
1.
2.
࣑ྣႺఈսଐĭᄥ෶Ⴝ౪ࢹຣӶᆵవĭҊ֬ದـ
๨ࠏᄛہ࣑೎ቜ၄૳h
࣑೎ቜ၄૳֭෶Ⴝಮჼ؃щ྾மփ٥ӫ૳ᅿࠏ޳
༓ఞhݞఞщ྾ૌ็ĭࠏᆈᄥமւᆈۓ֦޳༓
চ଼൐࣑ྣۿߘh
3. Ҋ֬ᄥቜ၄૳ႊ൒ĭއණࠏ༓࿽ၣ٥ᇀሇ೎ൻ֦
໲ಡູ֭৴hᄥႊ൒ĭއණࠏ༓࿽ᆵవĭ܅ಮщ
྾࣑ྣ౪༩ތ౪ࢹhҊ֬ࢄႊ൒ĭއණࠏ༓࿽֥
ᇉູ֭৴ᄥ߯ӫେӮࠚ֭ቜ၄૳ഐh
1.
2.
3.
౪ԪႺఈ֭٢൜႓ቛ֦ࣘେചׁӉ഻ӫζh
႓֚Ⴐ4૩فෙҋࢄԪఈቜ၄֭౽ჟڇцh
սଐ٢൜႓ቛ֦ࣘେࡰചቜ၄૳ປ֭Ⴚఈӫζ
֭ޚࠞh
༹ஈᎧࠀಯ
ໃྱ
ࣦ۩: ৮Ⴐ౪ࢹĭیᄺ֭࿪ෲటࢄ߯ӫიӫζ
՞אࠗތܹᇉ׶ఞഐՀቄ൦၊۹щ္֭ׯఁໃ
߁ӹ࿅hݫႽࣉඓྏ֭߯ӫიӫζ๡Ӑ߾ᄥ୅Ҏ
ў૳ؘࠚĭ๥൐ĭೊݜ໋େ࣑ྣ௜ٖ֭౪ࢹĭ
େ߾Ӊ഻אࠔࠏ԰אhࢁၸҘႰ၊ᇂ“ࢬׁܫ ؖ
ఞĩGFCIĪĭ؛Я܅࣑ྣࡧҸތ౪ࢹĭಞ޲
ᄤᇟྕഩᇊGFCIh౪ࢹތ൘ႰЯ܅൐ĭᇈ൛ᇈ
ᇜւഐ߁ପ࣬ĩANSIZZ87.1)h
༹ஈ
1.
2.
3.
ᄥսଐལପఁ࡟ĭૌ็щ྾؛ቜ၄૳෶Ⴝ֭ў૳
Ӧ׀ׁ࣑ྣ༓ӫތ౪ࢹh༓ӫఞݞև႓֚௜ٖ
ۿߘh
႓֚ࢄַෙҋ൴ࠪగধĭѱ౗იಱލࣉඓ෦ྏࠏ
ఋჍ౪Ԫ֭෦ྏ၊֩Աৠh႓֚ࢄ෹૔٪ᇊᄥ૩
ڇ൜টࠕܿ୅ĭѱ౗๡ݞᆦӐ֭টࠕ൴ࠪӹ࿅ࡎ
ၣԱৠh
౪ࢹఁ࡟, ౕ༇ದـ๨იᄛہࢬࣕቜ၄૳h
ـ๨൘Ⴐ֭෶Ⴝຟĭ༩ּ֭ࡍიႰщ྾
ࡎၣӦ׀౪༩Ҕେᄤՙ൘Ⴐh

࡭เᇗ໛
15
ࣦ۩: ౕ༇൘Ⴐಿ࠼ࠏఋ෸ྦྷߌ࿘ᇍ௞ধ౪
ࢹ܅֭٬ࣉඓࡹhᆋོߌ࿘༆ᇑେ߾ཬ೘
ᆋོҎ໒൘Ⴐ֭ෙғh౰Ⴐҋᅣ໙ތ֭ٯᄸ
ණҐൢhౕ༇ದಱލ၉เ࣑೎܅ĭࣔᇀದ܅
֭ಱލҎٻᄥ၉เᇗࣗ஦h
ྥઘ
୥֭א׶܅໵ྻྣೖ߉h
՞୥ׁ֚൦ࣤ཯഍ࠏࣤݞ൹ಋ֭ڣ༈ᇗྗĭၣ๡ݞص
ປڹٶࠎ֬๿ࡱი୥֭ۼ၊֩൘Ⴐ֭ۀࡹhೊݜ୥ᄥ
ۀࡹ࿡ᅻ٢૳ྻ္ಱލྀሁĭ࣫౰৻༪୥ ֭ࣕ
DEWALT܅၄܅܌රĭࠏְ໩૔֭ັᅧ:
http://www.dewalt.com.
ࣦ۩: ႶჇ٬DEWALT฼܊֭ۀࡹແᄥЯӉ௞ഐ
ቛݞ൳ယĭᆋ৓ۀࡹେႽ຺ཊh ແࢎֶൻഌ
຺֭ཊĭᇂେࢄDEWALT๿ࡱ֭ۀࡹႰჇЯӉ
௞h
ࣦ۩: ແࢎֶൻഌ຺֭ཊ ĭսଐ൐ᇈ൛ᇈᇜ൘
Ⴐద֚֭٥߁ϸĭѱ౗ւഐ߁ପ࣬h
ሕނ֭ೱઅތࡸ๰
࢟૦ၮ
DW887
౰৻༪୥ׁ֚֭ڣ༈ᇗྗࡧҸאࠗh
এୈ
ᆸଐࠗۀࡹ
ኀಯ
ແಚДӉ௞υಎތྦྷ, ྱৠ, ໃྱތנᆤ (Џছאࠗඟ
ࡧҸიۿߘ)႓֚ႶDEWALT܅Ӕڣ༈ᇗྗĭDEWALT൹
ಋ֭ڣ༈ᇗྗࠏఋ෸Ⴝሯ৭֭ໃྱಮჼ࣑ྣh ᇈ൛ᇈᇜ
൘Ⴐཕ๥֭แߘҎࡹh

㐕储Ё᭛
16
Ⳉ⺼″
DW887
ᙁ୰ʽ
ᙁ୰ᙼ䙌᪛њDEWALTᎹ݋DŽ໮ᑈⱘ㍧倫ᇜὁⱘ⫶ક䭟
ⱐࡉᮄՓDEWALT៤⚎ᇜὁ䳏ࢩᎹ݋Փ⫼㗙᳔ৃ䴴ⱘড়
԰໹ԈПϔDŽ
ᡔ㸧ᗻ䊛᭭
ϔ㠀䳏ࢩᎹ݋䄺
ֱㅵད᠔᳝䄺ᣛҹ֓Ҟᕠগ㗗
1DžᎹ԰จഄ
a)
b)
c)
䳏ວ
丏⥛
ࡳ⥛䔌ߎ
ぎ䓝䔝䗳
ⷖ䓾Ⳉᕥ
Џ䓌
ㄦ༒ሎᇌ
䞡䞣
VAC
Hz
W
min-1
mm
mm
kg
220~240
50/60
400
25,000
38
M14
6
17
DW887
䄺: ⚎䰡Ԣফڋ乼䱾,䂟Ҩ㌄䮅䅔ҹϟᦣ
䗄DŽ
䄺Ёⱘ“䳏ࢩᎹ݋”䗭ϔ㸧䁲ᣛⱘᰃᙼⱘ⬅䳏⑤᪡԰˄ᐊ
䳏㎮ⱘ˅៪䳏∴候ࢩⱘ˄⛵䳏㎮ⱘ˅䳏ࢩᎹ݋DŽ
ࣦ۩!ᭀ䂟䮅䅔᠔᳝ᅝܼ䄺㟛ᣛDŽབ᳾
㛑䙉ᕾ䗭ѯ䄺ᣛˈᇛৃ㛑ᇢ㟈㿌䳏ˈ
☿♑/៪ಈ䞡ڋᆇDŽ
ֱᣕᎹ԰จഄ⏙┨ᯢ҂ˈ䲰і៪䱄ᱫⱘഄᮍᆍ
ᯧᓩⱐџᬙDŽ
⽕ℶ೼ᯧ⟚⪄๗Ё᪡԰䳏ࢩᎹ݋ˈབ᳝ᯧ➗⎆
储ǃ⇷储៪㉝้ⱘ⪄๗DŽ䳏ࢩᎹ݋⫶⫳ⱘ☿㢅᳗
咲➗㉝้៪✭䳻DŽ
᪡㐅䳏ࢩᎹ݋ᰖ⽕ℶܦスᮕ㾔㗙䴴䖥DŽᑆ󰩳ৃ
㛑᳗ᇢ㟈ᙼ᪡԰ϡ⭊DŽ
2Dž䳏఼ᅝܼ
a)
b)
c)
d)
a)
b)
c)
d)
e)
f )
䳏ࢩᎹ݋ᦦ丁ᖙ䷜㟛ৠ㽣Ḑⱘᦦᑻᨁ䜡DŽ⽕ℶҹ
ӏԩᮍᓣᬍ㺱ᦦ丁DŽ
䳔㽕᥹ഄⱘ䳏ࢩᎹ݋ϡ㛑Փ⫼ӏԩ䔝᥹ᦦ丁DŽ
ᒴ᠔䰘ⱘᦦ丁㟛ৠ㽣Ḑⱘᦦᑻᇛ⏯ᇥ㿌䳏ⱘ
䱾DŽ
䙓ܡҎ储㟛᥹ഄ㸼䴶᥹㿌,བㅵ䘧ǃᬷ➅఼ǃ⟤
♊ǃބㆅDŽབᵰᙼⱘ䑿储᥹ഄˈ㿌䳏䱾ᗻ᳗๲
ࡴDŽ
䂟࣓ᇛ䳏ࢩᎹ݋ᲈ䴆೼䲼Ё៪╂▩⪄๗ЁDŽ䳏ࢩ
Ꮉ݋䘆∈ᇛ๲ࡴ㿌䳏䱾DŽ
ߛ࣓▿⫼䳏㎮DŽߛ࣓Փ⫼䳏⑤㎮ᨀ䘟ǃᢝࢩ៪ᢨ
ϟ䳏ࢩᎹ݋DŽֱᣕ䳏⑤㎮䘴䲶➅⑤ǃ⊍ǃ䢇䙞៪
䘟ࢩ䚼ӊDŽফ᧡៪㑣㐲ⱘ䳏㎮᳗๲ࡴ㿌䳏ⱘ
䱾DŽ
೼ᅸ໪᪡԰䳏ࢩᎹ݋ᰖˈ䂟Փ⫼䘽ড়᠊໪Փ⫼ⱘ
໪᥹䳏㎮DŽ䘽ড়᠊໪Փ⫼ⱘ䳏㎮᳗⏯ᇥ㿌䳏ⱘ
䱾DŽ
བᵰᖙ䷜ᕫ೼╂▩ⱘഄᮍ᪡԰䳏ࢩᎹ݋ˈ䂟Փ⫼
࠽们䳏⌕㺱㕂˄RCD˅ֱ䅋ⱘ䳏⑤DŽ RCD ⱘՓ
⫼⏯ᇥњ㿌䳏ⱘ䱾DŽ
3DžҎ䑿ᅝܼ
ֱᣕ䄺㾎ˈ᪡԰䳏ࢩᎹ݋ᰖ⊼ᛣ᪡԰ˈֱᣕ⏙
䝦DŽߛ࣓೼⮆׺៪⊏Ⱆᰖ៪೼㮹⠽៪䜦㊒ⱘᕅ䷓
ϟՓ⫼䳏ࢩᎹ݋DŽ᪡԰䳏ࢩᎹ݋ᰖ⊼ᛣ࡯ϡ䲚Ё
ৃ㛑᳗ᇢ㟈ಈ䞡ⱘҎ䑿ڋᆇDŽ
Փ⫼ןҎ䰆䅋㺱٭DŽྟ㌖Խ᠈䅋Ⳃ䦵DŽ䘽⭊ⱘṱ
ӊϟՓ⫼䰆䅋㺱٭ᇛ⏯ᇥҎ䑿ڋᆇˈབ䰆้ষ
㔽ǃ䰆⒥ᅝܼ䵟ǃᅝܼᐑǃ㙑࡯ֱ䅋䀁٭DŽ
䰆ℶᛣ໪ଳࢩDŽ೼䗷᥹䳏⑤៪䳏∴㌘Пࠡҹঞᣓ
䍋៪󰪑ᐊᎹ݋Пࠡ䂟⺎ֱ䭟䮰㰩ᮐ䮰䭝ԡ㕂DŽ󰪑
ᐊ䳏ࢩᎹ݋ᰖᡞ᠟ᣛᬒ೼䭟䮰Ϟ៪ܙ䳏ᰖ䭟䮰㰩
ᮐᠧ䭟ԡ㕂᳗䗴៤Ҏ䑿䱾DŽ
ᠧ䭟Ꮉ݋ࠡᢚϟ᠔᳝䂓ᭈ䥉៪ᡇ᠟DŽ䗷᥹೼䳏ࢩ
Ꮉ݋ᮟ䔝䳊ӊϞⱘᡇ᠟៪䂓ᭈ䥉ৃ㛑ᇢ㟈Ҏ䑿ڋ
ᆇDŽ

㐕储Ё᭛
17
e)
f )
g)
⽕ℶ᠟Ԍᕫ໾䭋ˈᰖࠏ⊼ᛣ㝇ϟ䑿储ᑇ㸵DŽ䗭
ῷ೼ᛣ໪ᚙ⊕ϟ㛑᳈དഄ᥻ࠊ䳏ࢩᎹ݋DŽ
こ㨫ᕫ⭊DŽ᪡԰䳏ࢩᎹ݋ᰖߛᖠこᇀ僚ⱘ㸷᳡៪
Խ᠈佪仒DŽ䅧ᙼⱘ丁僂ǃ㸷᳡᠟༫䘴䲶䘟ࢩⱘ
䳊ӊDŽᇀ僚ⱘ㸷᳡ǃ佪仒៪䭋僂ৃ㛑᳗᥆ܹ䘟ࢩ
䳊ӊЁDŽ
བᵰ᳝ᦤկ䗷᥹ᥦሥ䲚้䀁٭ⱘ㺱㕂ˈ䂟⺎ֱ䗭
ѯ㺱㕂䗷᥹ᅠདˈՓ⫼ℷᐌDŽ䲚้ৃ⏯ᇥ㟛㉝้
᳝䮰ⱘᆇDŽ
a)
b)
c)
d)
e)
f )
g)
a)
⽕ℶᔋࠊՓ⫼䳏ࢩᎹ݋DŽḍ᪮⫼䗨ˈՓ⫼ℷ⺎ⱘ
䳏ࢩᎹ݋DŽℷ⺎ⱘ䳏ࢩᎹ݋೼䀁㿜ⱘ両ᅮࡳ⥛ϟ
㛑᳈ད᳈ᅝܼഄᅠ៤Ꮉ԰DŽ
⽕ℶՓ⫼䭟䮰ϡ㛑ᠧ䭟䮰䭝ⱘ䳏ࢩᎹ݋DŽӏԩ
ϡ㛑⫼䭟䮰᥻ࠊⱘ䳏ࢩᎹ݋䛑ᕜ䱾ˈᖙ䷜䘆㸠
ׂ⧚DŽ
䂓ᭈǃ᳈᦯䰘ӊ៪܆ᄬ䳏ࢩᎹ݋ࠡˈ䂟ᇛ䳏ࢩᎹ
݋䳏⑤ᦦ丁៪䳏∴㌘ᮋ䭟DŽ䗭。䷤䰆ᗻᅝܼ᥾
ᮑ㛑⏯ᇥᛣ໪ଳࢩ䳏ࢩᎹ݋ⱘ乼䱾DŽ
ᇛ䳏ࢩᎹ݋܆ᄬ೼ܦスϡ㛑໴㨫ⱘഄᮍˈ⽕ℶϡ
❳ᙝ䳏ࢩᎹ݋៪ᴀ䁾ᯢ᳌ⱘҎ᪡԰䳏ࢩᎹ݋DŽ䅧
᳾㍧㿧㏈ⱘ⫼᠊᪡԰䳏ࢩᎹ݋ᰃᕜ䱾ⱘDŽ
ֱ仞䳏ࢩᎹ݋DŽ⁶ᶹ䘟ࢩ䚼ӊᰃ৺ԣˈᰃ৺ᇡ
⑪ˈ䳊ӊᰃ৺⸈᧡ˈҹঞᰃ৺᳝݊Ҫৃ㛑ᕅ䷓䳏
ࢩᎹ݋᪡԰ⱘᚙ⊕DŽབ᳝᧡າˈ䂟೼Փ⫼ࠡᇡ䳏
ࢩᎹ݋䘆㸠㎁ׂDŽ䀅໮џᬙህᰃ⬅ᮐ䳏ࢩᎹ݋㎁
䅋ϡ㡃㗠ⱐ⫳ⱘDŽ
ֱᣕߔ݋䢦߽⏙┨ˈཹ୘ֱ仞䢦߽ⱘߛࠞᎹ
݋ˈৃՓ᪡԰ϡᆍᯧԣˈϨ᳈ᆍᯧ᥻ࠊDŽ
䂟ḍ᪮䗭ѯ᪡԰ᣛ⼎Փ⫼䳏ࢩᎹ݋ǃ䜡ӊߛࡆ
Ꮉ݋ㄝˈϺϨ㗗ᝂᎹ԰ṱӊ㽕෋㸠ⱘᎹ԰DŽᇛ
䳏ࢩᎹ݋⫼ᮐϡᰃ䷤ᳳⱘ᪡԰⫼䗨ৃ㛑᳗ᇢ㟈
䱾ᚙ⊕DŽ
䂟䅧ড়Ḑⱘ㎁ׂҎવ㎁ׂᙼⱘᎹ݋ˈ㎁ׂҎવা
㛑Փ⫼Ⳍৠⱘ᳈᦯䳊ӊҹ⺎ֱ䳏ࢩᎹ݋ⱘᅝܼᗻ
㛑DŽ
᠔᳝᪡԰ᅝܼᣛ
4Dž䳏ࢩᎹ݋ⱘՓ⫼⊼ᛣ䷙
5Dž᳡ࢭ
a)
b)
c)
d)
e)
f )
g )
ᴀ䳏ࢩᎹ݋䷤ᳳ⫼԰ⷨ⺼″ˈⷖ䓾″ˈ䣐㍆ࠋˈ
ᢟܝ″៪ߛࡆ″Ꮉ݋DŽᭀ䂟䮅䅔䱼ᴀ䳏ࢩᎹ݋ᦤ
կⱘ᠔᳝ᅝܼ䄺ˈᣛˈ೪⼎ঞ㽣㆘DŽ བᵰ᳾
㛑䙉ᕾ᠔߫ߎⱘᣛˈᇛৃ㛑ᇢ㟈䳏᪞ˈ☿♑/
៪ಈ䞡Ҏ䑿ڋᆇDŽ
ᓎ䅄࣓ᇛᴀ䳏ࢩᎹ݋⫼ᮐڣⷨ⺼, ᢟܝҹঞ䣐㍆ࠋ
䗭串ⱘ԰ὁDŽབᵰᇛᴀ䳏ࢩᎹ݋⫼ᮐ䀁㿜Ⳃⱘ԰
ὁৃ㛑⫶⫳䱾ᓩ䍋Ҏ䑿ڋᆇDŽ
ߛ࣓Փ⫼䴲ᇜ䭔䀁㿜ⱘҹঞ䴲ᴀᎹ݋㻑䗴ଚ᥼㭺
ⱘ䰘ӊDŽ۬ㅵ䗭ѯ䰘ӊ㛑໴㺱೼ᙼⱘ䳏ࢩᎹ݋
ϞˈᅗϺϡ㛑⺎ֱᅝܼ԰ὁDŽ
䰘ӊⱘ両ᅮ䗳ᑺᖙ䷜㟇ᇥㄝᮐ೼ᴀ䳏ࢩᎹ݋Ϟ῭
ߎⱘ両ᅮ䗳ᑺDŽབᵰ䰘ӊҹ䍙䘢両ᅮ䗳ᑺ䘟㸠ˈ
ᅗץৃ㛑⸈᧡៪৥໪亯ߎDŽ
ᙼⱘ䰘ӊ໪ᕥ㟛ᑺᖙ䷜㰩ᮐᙼⱘ䳏ࢩᎹ݋ⱘ両
ᅮᆍ䞣ܻDŽབᵰ䰘ӊሎᇌϡヺˈᇛ⛵⊩ᕫࠄᙄ⭊
ⱘֱ䅋᥻ࠊDŽ
ⷖ䓾ⱘ″䓌ሎᇌˈ⊩㰁ˈᬃᩤ๞៪ӏԩ䰘ӊᖙ䷜
㟛ᴀ䳏ࢩᎹ݋ⱘЏ䓌ᙄ⭊ড়DŽབᵰ᥵⫼ᐊ᳝㟛
ᴀ䳏ࢩᎹ݋ⱘᅝ㺱⹀储ϡড়ⱘ″䓌ᄨⱘ䰘ӊˈ
ᇛ᳗༅এᑇ㸵ˈ࡛⚜ᤃࢩˈৠᰖৃ㛑ᇢ㟈༅᥻DŽ
ߛ࣓Փ⫼ফ᧡䰘ӊDŽ
↣󱂖Փ⫼ࠡˈ⁶ᶹϟ߫䰘ӊ˖ᠧ⺼ⷖ䓾ᰃ৺᳝⹢
ሥ៪㺖㋟ˈᬃᩤ๞ᰃ৺᳝㺖㋟ˈᢝڋ៪䘢ᑺ⺼
᧡ˈ䣐㍆ࠋᰃ৺᳝僚ࢩ៪䭟㺖䣐㍆DŽབᵰϡᜢᇛ
䳏ࢩᎹ݋៪䰘ӊᨨ㨑ˈ⁶ᶹ݊ᰃ৺᳝⸈᧡ˈ៪ᅝ
㺱ϔ䲏᳾ফ᧡ⱘ䰘ӊDŽ
⁶ᶹᅝ㺱ᅠ䰘ӊᕠˈ䅧㞾Ꮕᮕ㾔㗙㰩ᮐ䁆ᮟ
䔝䰘ӊⱘᑇ䴶໪ˈৠᰖˈ䅧ᴀ䳏ࢩᎹ݋ҹ᳔໻ぎ
䓝䗳ᑺ䘟䔝ϔߚ䧬DŽফ᧡䚼ӊ᳗೼䗭ϔ䀺倫ᰖ䭧
ܻᵒ㛿DŽ
ⷨ⺼ᠧ⺼䣐㍆ࠋᢟܝ៪⺼᭭ˈߛࡆ԰ὁᐌ⫼
ᅝܼ䄺

㐕储Ё᭛
18
h)
i)
こ᠈དןҎ䰆䅋䀁٭DŽ
ձ᪮ϡৠⱘឝ⫼ˈՓ⫼䴶㔽ˈᅝܼ䅋Ⳃ䦵៪ᅝܼ
ⴐ䦵DŽ ೼ᙄ⭊ᚙᔶϟ Խᐊ䰆้䴶㔽, 䅋㘇఼, 㛑
໴䰏᪟㌄ᖂ⺼᭭៪Ꮉӊ⹢พⱘᎹ԰ೡ㺭DŽⴐ䦵ֱ
䅋㺱㕂ᖙ䷜㛑໴䰏ℶ⬅৘。԰ὁ⫶⫳ⱘ亯◎⹢DŽ
䰆้䴶㔽៪఼ᖙ䷜㛑໴䘢◒ᙼⱘ԰ὁ⫶⫳ⱘ
ᖂ㉦DŽ䭋ᳳᲈ䴆ᮐ催ᔋᑺⱘా䷇ৃ㛑ᇢ㟈㙑࡯୾
༅DŽ
䅧ᮕ㾔㗙䘴䲶԰ὁ䴶DŽ䘆ܹ԰ὁ䴶ⱘӏԩҎ䛑ᖙ
䷜ԽᐊןҎֱ䅋㺱㕂DŽᎹӊ ⱘ⹢ሥ៪⸈᧡ⱘ䰘ӊ
ৃ㛑৥໪亯◎ˈৠᰖ೼԰ὁ䰘䖥ⱘඳ໪ᓩ䍋᧡
ڋDŽ
԰ὁᰖˈབᵰ԰ὁඳⱘ䰘ӊߛࡆৃ㛑㟛䲅㮣ⱘ
䳏㎮៪݊䳏㎮᥹㿌ˈ䗭ᰖা㛑ᦵԣ㌩㎷ⱘᡞᦵ㸼
䴶DŽߛࡆ㟛“ᐊ䳏”ⱘ䳏㎮᥹㿌ⱘ䰘ӊৃ㛑Փᴀ䳏
ࢩᎹ݋ᲈ䴆ⱘ䞥ቀ䚼ߚᐊ䳏ˈՓ᪡԰㗙䙁ফ䳏
᪞DŽ
ᇛ䳏⑤㎮㕂ᮐ䘴䲶ᮟ䔝䰘ӊⱘԡ㕂DŽབᵰᙼ༅এ
᥻ࠊ, 䗭ḍ䳏㎮ৃ㛑᳗㹿ࡆᮋ៪ 㑣ԣˈৠᰖᙼⱘ
᠟㞖៪᠟ᥠৃ㛑᳗㹿ᣑ䘆ᮟ䔝ⱘ䰘ӊDŽ
ᴀᎹ݋䰘ӊ᳾ᅠܼذℶПࠡˈϡᕫᇛ䳏ࢩᎹ݋ᬒ
ϟDŽᮟ䔝ⱘ䰘ӊৃ㛑᳗ᡧԣ㸼䴶ˈᢝࢩᴀ䳏ࢩᎹ
݋ՓП༅এᙼᇡ݊ⱘ᥻ࠊDŽ
⭊ᙼ೼و䴶ᨀ䘟ᴀ䳏ࢩᎹ݋ᰖˈߛ࣓ՓП䘟䔝DŽ
㟛ᮟ䔝ⱘ䰘ӊⱘᛣ໪᥹㿌ˈৃ㛑㑣ԣᙼⱘ㸷⠽ˈ
ᇛ䰘ӊᢪܹᙼ䑿储DŽ
ᅮᳳ⏙┨ᴀ䳏ࢩᎹ݋ⱘ䗮乼ষDŽ
䳏″乼᠛᳗ᇛ♄้䘆໪←ܻˈৠᰖ㉝⢔䞥ቀⱘ
䘢ᑺේ〡ৃ㛑䗴៤䳏䱾DŽ
ߛ࣓೼ᯧ➗ᴤ᭭䰘䖥᪡԰ᴀ䳏ࢩᎹ݋DŽ☿㢅ৃ㛑
咲➗䗭ѯᴤ᭭DŽ
ߛ࣓Փ⫼㽕∖⎆ᜟދࡥⱘ䰘ӊDŽབᵰՓ⫼∈៪
݊Ҫ⎆储ދࡥˈৃ㛑ᇢ㟈䳏᪞៪㿌䳏DŽ
j )
k)
l )
m)
n)
o)
p)
ডᔜⱘ಴᪡԰㗙䷤䰆
a)
b)
c)
d)
e)
ডᔜᰃᇡ󰩥ᤣ៪㑣㐲ⱘᮟ䔝ⷖ䓾ˈᬃᩤ๞ˈ䣐㍆
ࠋ៪ӏԩ݊Ҫ䰘ӊⱘϔןさ✊ডឝDŽ󰩥ᤣ៪㑣㐲
ᓩ䍋ᮟ䔝䰘ӊⱘさ✊ذℶˈ䗭ϔᚙᔶ᳗ձ󱂖Փ༅
এ᥻ࠊⱘ䳏ࢩᎹ݋೼咲䔝ܹ㟛䰘ӊᮟ䔝Ⳍডⱘ
ᮍ৥DŽ
՟བˈབᵰϔ䲏ᠧ⺼ⷖ䓾 㹿Ꮉӊ󰩥ᤣ៪㑣㐲ˈキ
೼䘆ܹ󰩥ᤣ咲ⱘⷖ䓾䙞㎷ৃ㛑ᦦ䘆䁆ᴤ᭭ⱘ㸼
䴶ˈᇢ㟈ⷖ䓾⠀ߎ៪ᔜߎDŽձ✻೼󰩥ᤣ咲ⷖ䓾ⱘ
䘟ࢩᮍ৥ϡৠˈⷖ䓾ৃ㛑᳗ᳱ৥៪䘴䲶᪡԰㗙ᔜ
ߎDŽ೼䗭ѯ⢔⊕ϟˈᠧ⺼ⷖ䓾ৠᰖгৃ㛑⸈㺖DŽ
ডᔜ⬅▿⫼/៪䤃䁸ⱘ᪡԰⿟ᓣ៪⢔⊕ᓩ䍋ˈৠ
ᰖˈ䗮䘢᥵পϟ߫㌺ߎⱘ䷤䰆᥾ᮑ֓ৃҹᇡ݊䘆
㸠䰆ℶ:
㎞ᦵᴀ䳏ࢩᎹ݋ˈৠᰖᇛᙼⱘ䑿储㟛᠟㞖㕂ᮐᙼ
㛑໴ᢉ⽺ডᔜ࡯䞣ⱘԡ㕂DŽ 䗮䘢ᦤկ䓨ࡽᡞ᠟ˈ
㟇ྟ㟇㌖Փ⫼ᅗˈҹ֓೼ଳࢩᳳ䭧⥆ᕫᇡডᔜ៪
՟হডឝⱘ᳔໻᥻ࠊDŽབᵰ᥵পњᙄ⭊ⱘ䷤䰆᥾
ᮑˈ᪡԰㗙ৃҹ᥻ࠊ՟হডឝ៪ডᔜ࡯䞣DŽ
ߛ࣓ᇛᙼⱘ᠟㞖ᬒ೼ᮟ䔝ⱘ䰘ӊᮕDŽ 䰘ӊৃ㛑ড
ᔜ䘢ᙼⱘ᠟㞖DŽ
ߛ࣓ᇛᙼⱘ䑿储㟇ᮐ೼䳏ࢩᎹ݋ডᔜᰖᇛ᳗⿏ࢩ
ⱘԡ㕂DŽ ডᔜ᳗೼󰩥ᤣⱘ䙷ϔࠏᇛᴀᎹ݋ᳱ㨫㟛
ⷖ䓾Ⳍডⱘᮍ৥候ࢩDŽ
೼㾦㨑ˈᇪ䢇ⱘ䙞㾦ㄝඳ԰ὁᰖˈ䳔㽕ߚ䄍
ᜢDŽ䙓ܡՓ䰘ӊᔜ䏇៪㑣㐲DŽ 㾦㨑ˈᇪ䢇䙞㾦៪
ᔜ䏇ᕔᕔ᳗Փᮟ䔝ⱘ䰘ӊ㑣㐲ˈϺϨᓩ䍋༅᥻៪
ডᔜDŽ
ߛ࣓㺱Ϟ䣌䦜᳼䲩ߔ⠛៪唦ൟ䣌⠛DŽ 䗭串ߔ⠛᳗
䗴៤丏㐕ⱘডᔜ㟛༅᥻DŽ
