DeWalt DCPH820 User manual

If you have questions or comments, contactus.
Pour toute question ou tout commentaire, nouscontacter.
Si tiene dudas o comentarios,contáctenos.
1-800-4-DeWALT
DCPH820
20V Max* Pole Hedge Trimmer
Taille-haie télescopique 20V max*
Cortasetos de altura de 20 V Máx*
Instruction Manual
Guide D’utilisation
Manual de instrucciones

English (original instructions) 1
Français (traduction de la notice d’instructions originale) 15
Español (traducido de las instrucciones originales) 31

1
ENGLISH
11
12
5
13
9
8
4
10
1
7
6
3
2
15
16
14
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.
(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.
WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any product, call DeWALT toll free at: (1-800-433-9258).
1 On/Off trigger
2 Lock-off lever
3 Handle
4 Auxiliary handle
5 Motor housing
6 Battery pack
7 Battery release button
8 Threaded sleeve
9 Threaded pole
10 Strap mount
11 Trimmer blade
12 Pivoting trimmer head
13 Trimmer head locking
button
14 Trimmer head handle
15 Handle assembly
16 Trimmer head assembly
Fig. A

ENGLISH
2
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personalinjury.
b ) Use personal protective equipment. Always wear
eye protection. Protective equipment such as a dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personalinjuries.
c ) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your
finger on the switch or energizing power tools that
have the switch on invitesaccidents.
d ) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personalinjury.
e ) Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewelry. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewelry or
long hair can be caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-relatedhazards.
h ) Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action can
cause severe injury within a fraction of asecond.
4) Power Tool Use and Care
a ) Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it wasdesigned.
b ) Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrainedusers.
e ) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
GENERAL POWER TOOL SAFETY
WARNINGS
WARNING: Read all safety warnings,
instructions, illustrations and specifications
provided with this power tool. Failure to follow all
instructions listed below may result in electric shock,
fire and/or seriousinjury.
SAVE ALL WARNINGS
AND INSTRUCTIONS FOR
FUTUREREFERENCE.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust orfumes.
c ) Keep children and bystanders away while
operating a power tool. Distractions can cause you
to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electricshock.
f ) If operating a power tool in a damp location
is unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply. Use of a GFCI
reduces the risk of electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
20V Max* Pole Hedge Trimmer
DCPH820

3
ENGLISH
Safety Instructions for Extended-Reach
Hedge Trimmers
• Do not use the extended-reach hedge trimmer in
bad weather conditions, especially when there is a
risk of lightning. This decreases the risk of being struck
bylightning.
• To reduce the risk of electrocution, never use near
any electrical power lines. Contact with or use near
power lines may cause serious injury or electric shock
resulting indeath.
• Always use two hands when operating the extended-
reach hedge trimmer. Hold the extended-reach hedge
trimmer with both hands to avoid loss ofcontrol.
• Always use head protection when operating the
extended-reach hedge trimmer overhead. Falling
debris can result in serious personalinjury. Use a hard hat
compliant with ANSI Z89.1 (CAN/CSA Z94.1).
CAUTION: Do not expose torain.
Important Safety Rules
WARNING: Read and understand all instructions.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious personalinjury.
SAVE THESE INSTRUCTIONS
Hedge Trimmer Safety Warnings
• Use both hands when operating the hedge trimmer.
Using one hand could cause loss of control and result in
serious personalinjury.
• Keep all parts of the body away from the cutter
blade. Do not remove cut material or hold material
to be cut when blades are moving. Make sure
the switch is off when clearing jammed material.
Blades coast after turn off. A moment of inattention
while operating the hedge trimmer may result in serious
personalinjury.
• Carry the hedge trimmer by the switch handle with
the cutter blade stopped. Proper handling of the hedge
trimmer will reduce possible personal injury from the
cutterblades.
• Hold the power tool by insulated gripping surfaces
only, because the cutter blade may contact hidden
wiring. Cutter blades contacting a "live" wire may make
exposed metal parts of the power tool "live" and could give
the operator an electricshock.
• Check the hedge for foreign objects, e.g. wirefences.
DANGER: Keep hands away from blade. Contact
with blade will result in serious personalinjury.
WARNING: Wear eyeprotection.
WARNING: Do not expose torain.
that may affect the power tool’s operation. If
damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained
powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking
into account the working conditions and the
work to be performed. Use of the power tool for
operations different from those intended could result
in a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpectedsituations.
5) Battery Tool Use and Care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury andfire.
c ) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or afire.
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation
orburns.
e ) Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior resulting
in fire, explosion or risk ofinjury.
f ) Do not expose a battery pack or tool to
fire or excessive temperature. Exposure to
fire or temperature above 265 °F (130°C) may
causeexplosion.
g ) Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside the
specified range may damage the battery and increase
the risk of fire.
6) Service
a ) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool ismaintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized serviceproviders.

ENGLISH
4
Before Operating Pole Hedge Trimmer
CAUTION: The unit has not been designed to
provide protection from electric shock in the event
of contact with overhead electric lines, Consult local
regulations for safe distances from overhead electric
power lines and ensure that the operating position is
safe and secure before operating the extended reach
hedgetrimmer.
• For safe operation, read and understand all instructions
before using the Pole Hedge Trimmer. Follow all safety
instructions. Failure to follow all safety instructions listed
below, can result in serious personalinjury.
• Watch what you are doing. Use common sense. Do not
operate Pole Hedge Trimmer when you aretired.
• Only well-instructed adults should operate Pole Hedge
Trimmer. Never allow children tooperate.
• Do not use Pole Hedge Trimmer for any job except that for
which it isintended.
• Do not allow children or untrained individuals to use
thisunit.
• Wear the following safety gear when operating Pole
Hedge Trimmer:
- heavy-duty gloves
- substantial footwear
- safety glasses, goggles or face screen that are marked
to comply with ANSI Z87.1
- face or dust mask (if working in dusty areas)
• Do not wear loose fitting clothing, or jewelry of any kind
that could get caught in the moving blades or parts of the
Pole HedgeTrimmer.
• Secure long hair so it is above shoulder level to prevent
entanglement in any movingparts.
While Operating Pole Hedge Trimmer
• Stay alert. Use common sense while operating theunit.
• Keep work area clean. Cluttered areas inviteinjuries.
• Keep children, animals and bystanders at a safe distance
away from Pole Hedge Trimmer. Only Pole Hedge Trimmer
user should be in workarea.
• Grip Pole Hedge Trimmer securely - one hand on the foam
gripper, the other on the mainhandle.
• Keep finger off trigger until ready touse.
• Before starting Pole Hedge Trimmer, make sure blades are
not touchinganything.
• Keep all parts of body away from blades when Pole Hedge
Trimmer isrunning.
• Carry Pole Hedge Trimmer from one place to another
- with battery removed
- by holding pole at balance point
- with blades to rear
• Do not operate in poorlighting.
• During operation, rest periodically and change working
positions to reducefatigue.
• Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance or exposure to
sharpsurfaces.
• Do not, under any circumstance, use any attachment or
accessory on this product, which was not provided with
the product, or identified as appropriate for use with this
product in this InstructionManual.
Do Not Operate Pole Hedge Trimmer
- While under the influence of alcohol, medication, or
drugs in rain or in damp or wet areas
- Where highly flammable liquids or gases are present
- If Pole Hedge Trimmer is damaged, adjusted wrong, or
not fully and securely assembled
- If trigger does not turn Pole Hedge Trimmer on and off.
Blades must stop moving when you release trigger.
Have faulty switch replaced by authorized service
center. SeeRepairs.
- While in a hurry
- While in tree or on a ladder
- While on aerial booms, buckets or platforms
- During high wind or storming weather
General Safety Rules
WARNING: Shock Hazard. To protect yourself from
electrocution, do not operate within 10 feet (3 m) of
overhead electrical lines. Consult local regulations for
safe distances from overhead electric power lines and
ensure that the operating position is safe and secure
before operating the extended reach hedge trimmer.
Failure to do this could result in severe personalinjury.
• Keep the handles dry, clean, and free ofoil.
• Make sure cutting blades have stopped before setting
unitdown.
DANGER: RISK OF CUT. Keep hands away from
blades. Keep both hands on handles when Pole Hedge
Trimmer ison.
• DO NOT ATTEMPT to remove cut material or hold
material to be cut when blades are moving. Remove
battery when clearing jammed material from blades. Do
not grasp the exposed cutting blades or cutting edges
when picking up or holding the Pole HedgeTrimmer.
CAUTION: Blades coast after turnoff.
• DON’T FORCE POLE HEDGE TRIMMER - It will do the
job better and with less likelihood of a risk of injury at the
rate for which it wasdesigned.
• DISCONNECT BATTERY from the Pole Hedge Trimmer
when not in use or when servicing orcleaning.
• STORE IDLE POLE HEDGE TRIMMER INDOORS -
When not in use, Pole Hedge Trimmer should be stored
indoors in a dry and high or locked-up place out of reach
ofchildren.
• MAINTAIN POLE HEDGE TRIMMER WITH CARE - Keep
cutting blades sharp and clean for best performance and
to reduce the risk of injury. Keep handles dry, clean and
free from oil andgrease.

5
ENGLISH
Additional Safety Information
WARNING: Never modify the power tool or any part
of it. Damage or personal injury couldresult.
WARNING: ALWAYS use safety glasses. Everyday
eyeglasses are NOT safety glasses. Also use face or dust
mask if operation is dusty. ALWAYS WEAR CERTIFIED
SAFETYEQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3),
• ANSI S12.6 (S3.19) hearing protection,
• NIOSH/OSHA/MSHA respiratoryprotection.
WARNING: Some dust contains chemicals known
to State of California to cause cancer, birth defects
or other reproductive harm. Some examples of these
chemicals are:
• compounds in fertilizers,
• compounds in insecticides, herbicides
andpesticides,
• arsenic and chromium from chemically
treatedlumber.
To reduce your exposure to these chemicals,
wear approved safety equipment such as dust
masks that are specially designed to filter out
microscopicparticles.
WARNING: Use of this tool can generate and/
or disperse dust, which may cause serious and
permanent respiratory or other injury. Always use
NIOSH/OSHA approved respiratory protection
appropriate for the dust exposure. Direct particles
away from face andbody.
• CHECK DAMAGED PARTS  Before further use of the Pole
Hedge Trimmer, a guard or other part that is damaged
should be carefully checked to determine that it will
operate properly and perform its intended function. Check
for alignment of moving parts, binding of moving parts,
breakage of parts, mounting and any other condition
that may affect its operation. A guard or other part that
is damaged should be properly repaired or replaced by
an authorized service center unless otherwise indicated
elsewhere in thismanual.
Service
• Tool service must be performed only by qualified
repair personnel. Service or maintenance performed
by unqualified personnel could result in a risk of injury.
SeeRepairs.
• When servicing a tool, use only identical
replacement parts. Follow instructions in the
Maintenance section of this manual. Use of
unauthorized parts or failure to follow Maintenance
Instructions may create a risk of electric shock orinjury.
Specific Safety Rules
• Hold tool by insulated gripping surfaces when
performing an operation where the cutting tool
may contact hidden wiring. Contact with a “live” wire
will make exposed metal parts of the tool “live” and shock
theoperator.
READ ALL INSTRUCTIONS
Important Safety Instructions for All
Battery Packs
WARNING: Read all safety warnings,
instructions, and cautionary markings for the
battery pack, charger and product. Failure to
follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
BATTERIES AND CHARGERS
The battery pack is not fully charged out of the carton.
Before using the battery pack and charger, read the
safety instructions below and then follow charging
proceduresoutlined. When ordering replacement battery
packs, be sure to include the catalog number andvoltage.
The label on your tool may include the following symbols. The
symbols and their definitions are asfollows:
V.........................volts
Hz .......................hertz
min.....................minutes
or DC......direct current
......................Class I Construction
(grounded)
…/min.............. per minute
BPM.................... beats per minute
IPM.....................impacts per minute
RPM.................... revolutions per
minute
sfpm ...................surface feet per
minute
SPM....................strokes per minute
OPM.................... oscillations per
minute
A.........................amperes
W........................watts
or AC........... alternating current
or AC/DC.... alternating or
direct current
......................Class II
Construction
(double insulated)
no.......................no load speed
n.........................rated speed
......................earthing terminal
..................... safety alert symbol
..................... visible radiation
..................... avoid staring at
light
..................... wear respiratory
protection
..................... wear eye
protection
..................... wear hearing
protection
..................... read all
documentation
IPXX....................IP symbol
WARNING: Always wear proper personal hearing
protection that conforms to ANSI S12.6 (S3.19)
during use. Under some conditions and duration
of use, noise from this product may contribute to
hearingloss.
CAUTION: When not in use, place tool on its
side on a stable surface where it will not cause a
tripping or falling hazard. Some tools with a large
battery pack will stand upright but may be easily
knocked over.
• Air vents often cover moving parts and should be
avoided. Loose clothes, jewelry or long hair can be caught
in movingparts.

ENGLISH
6
Storage Recommendations
1. The best storage place is one that is cool and dry, away
from direct sunlight and excess heat or cold.
2. For long storage, it is recommended to store a fully
charged battery pack in a cool dry place out of the
charger for optimal results.
NOTE: Battery packs should not be stored completely
depleted of charge.The battery pack will need to be
recharged before use.
Battery Pack Cleaning Instructions
Dirt and grease may be removed from the exterior of the
battery using a cloth or soft non-metallic brush. Do not use
water or any cleaningsolutions.
Fuel Gauge Battery Packs
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
The fuel gauge is an indication of approximate levels of
charge remaining in the battery pack according to the
followingindicators:
75–100% charged
51–74% charged
< 50% charged
Pack needs to be charged
To actuate the fuel gauge, press and hold the fuel gauge
button. A combination of the three green LED lights will
illuminate designating the level of charge left. When the
level of charge in the battery is below the usable limit, the
fuel gauge will not illuminate and the battery will need to
berecharged.
NOTE: The fuel gauge is only an indication of the charge left
on the battery pack. It does not indicate tool functionality
and is subject to variation based on product components,
temperature and end-userapplication.
For more information regarding fuel gauge battery packs,
please contact 1-800-4-DeWALT (1-800-433-9258) or visit
our website www.dewalt.com.
Transportation
WARNING: Fire hazard. Do not store or carry
the battery pack so that metal objects can
contact exposed battery terminals. For example,
do not place the battery pack in aprons, pockets, tool
boxes, product kit boxes, drawers, etc., with loose
nails, screws, keys, etc. Transporting batteries
can possibly cause fires if the battery terminals
inadvertently come in contact with conductive
materials such as keys, coins, hand tools and the
like. The US Department of Transportation Hazardous
Material Regulations (HMR) actually prohibit
transporting batteries in commerce or on airplanes in
carry-on baggage UNLESS they are properly protected
• Do not charge or use the battery pack in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Inserting or removing the battery
pack from the charger may ignite the dust orfumes.
• When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws, or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a fire.
• NEVER force the battery pack into the charger. DO
NOT modify the battery pack in any way to fit into
a non-compatible charger as battery pack may
rupture causing serious personal injury. Consult
the chart at the end of this manual for compatibility of
batteries andchargers.
• Charge the battery packs only in DeWALT chargers.
• DO NOT splash or immerse in water or otherliquids.
• Do not store or use the tool and battery pack in
locations where the temperature may reach or
exceed 104°F (40°C) (such as outside sheds or metal
buildings in summer). For best life store battery packs in
a cool, drylocation.
NOTE: Do not store the battery packs in a tool with
the trigger switch locked on. Never tape the trigger
switch in the ONposition.
• Do not expose battery pack or tool/appliance to
fire or excessive temperature. Exposure to fire or
temperature above 265 °F (130 °C) may cause explosion.
• Do not incinerate the battery pack even if it is
severely damaged or is completely worn out. The
battery pack can explode in a fire. Toxic fumes and
materials are created when lithium-ion battery packs
areburned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open
eye for 15 minutes or until irritation ceases. If medical
attention is needed, the battery electrolyte is composed of
a mixture of liquid organic carbonates and lithiumsalts.
• Contents of opened battery cells may cause
respiratory irritation. Provide fresh air. If symptoms
persist, seek medicalattention.
WARNING: Burn hazard. Battery liquid may be
flammable if exposed to spark orflame.
WARNING: Fire hazard. Never attempt to open the
battery pack for any reason. If the battery pack case
is cracked or damaged, do not insert into the charger.
Do not crush, drop or damage the battery pack. Do
not use a battery pack or charger that has received a
sharp blow, been dropped, run over or damaged in
any way (e.g., pierced with a nail, hit with a hammer,
stepped on). Damaged battery packs should be
returned to the service center forrecycling.

7
ENGLISH
Shipping the DeWALT FLEXVOLT™ Battery
The DeWALT FLEXVOLT™ battery has two modes: Use and
Shipping.
Use Mode: When the FLEXVOLT™ battery stands alone or is
in a DeWALT 20V Max* product, it will operate as a 20V Max*
battery. When the FLEXVOLT™ battery is in a 60V Max* or a
120V Max* (two 60V Max* batteries) product, it will operate
as a 60V Max* battery.
Shipping Mode: When
the cap is attached to
the FLEXVOLT™ battery,
the battery is in Shipping
Mode. Strings of cells are
electrically disconnected within the pack resulting in three
batteries with a lower Watt hour (Wh) rating as compared
to one battery with a higher Watt hour rating. This increased
quantity of three batteries with the lower Watt hour rating
can exempt the pack from certain shipping regulations that
are imposed upon the higher Watt hour batteries.
The battery label indicates two Watt hour ratings (see
example). Depending on how the battery is shipped, the
appropriate Watt hour rating must be used to determine the
applicable shipping requirements. If utilizing the shipping
cap, the pack will be considered 3 batteries at the Watt hour
rating indicated for“Shipping”. If shipping without the cap or
in a tool, the pack will be considered one battery at the Watt
hour rating indicated next to“Use”.
USE: 120 Wh Shipping: 3 x 40 Wh
Example of Use and Shipping Label Marking
The RBRC® Seal
The RBRC® (Rechargeable Battery
Recycling Corporation) Seal on the nickel
cadmium, nickel metal hydride or lithium-
ion batteries (or battery packs) indicates that the costs to
recycle these batteries (or battery packs) at the end of their
useful life have already been paid by DeWALT. In some areas,
it is illegal to place spent nickel cadmium, nickel metal
hydride or lithium-ion batteries in the trash or municipal
solid waste stream and the Call2Recycle® program provides
an environmentally consciousalternative.
Call 2 Recycle, Inc., in cooperation with DeWALT and other
battery users, has established the program in the United
States and Canada to facilitate the collection of spent nickel
cadmium, nickel metal hydride or lithium-ion batteries. Help
protect our environment and conserve natural resources by
returning the spent nickel cadmium, nickel metal hydride or
lithium-ion batteries to an authorized DeWALT service center
or to your local retailer for recycling. You may also contact
your local recycling center for information on where to drop
off the spent battery. RBRC® is a registered trademark of Call
2 Recycle,Inc.
from short circuits. So when transporting individual
battery packs, make sure that the battery terminals are
protected and well insulated from materials that could
contact them and cause a short circuit. NOTE:Li-ion
batteries should not be put in checkedbaggage. Important Safety Instructions for All
Battery Chargers
WARNING: Read all safety warnings,
instructions, and cautionary markings for the
battery pack, charger and product. Failure to
follow the warnings and instructions may result
in electric shock, fire and/or seriousinjury.
• DO NOT attempt to charge the battery pack with
any chargers other than a DeWALT charger. DeWALT
chargers and battery packs are specifically designed to
worktogether.
• These chargers are not intended for any uses other
than charging DeWALT rechargeable batteries.
Any other uses may result in risk of fire, electric shock
orelectrocution.
• Do not expose the charger to rain orsnow.
• Pull by the plug rather than the cord when
disconnecting the charger. This will reduce the risk of
damage to the electric plug andcord.
• Make sure that the cord is located so that it will not
be stepped on, tripped over or otherwise subjected
to damage orstress.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in
risk of fire, electric shock orelectrocution.
• When operating a charger outdoors, always provide
a dry location and use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electricshock.
• An extension cord must have adequate wire size
(AWG or American Wire Gauge) for safety. The smaller
the gauge number of the wire, the greater the capacity
of the cable, that is, 16 gauge has more capacity than
18gauge. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating. When
using more than one extension to make up the total
length, be sure each individual extension contains at
least the minimum wire size. The following table shows
the correct size to use depending on cord length and
nameplate ampere rating. If in doubt, use the next heavier
gauge. The lower the gauge number, the heavier thecord.
Minimum Gauge for Cord Sets
Volts Total Length of Cord in Feet
(meters)
120V 25 (7.6) 50 (15.2) 100 (30.5) 150 (45.7)
240V 50 (15.2) 100 (30.5) 200 (61.0) 300 (91.4)
Ampere Rating
American Wire Gauge
More
Than
Not
More
Than
0 6 18 16 16 14
610 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
For example, Shipping Wh rating might indicate 3 x 40 Wh,
meaning 3 batteries of 40 Watt hours each.The Use Wh
rating might indicate 120 Wh (1 battery implied).

ENGLISH
8
continuously indicating that the charging process
hasstarted.
3. The completion of charge will be indicated by the light
remaining ON continuously. The battery pack is fully
charged and may be removed and used at this time or
left in the charger.
NOTE: To remove the battery pack, some chargers require
the battery pack release button to bepressed.
Indicators
Charging
Fully Charged
Hot/Cold Pack Delay*
*DCB107, DCB112, DCB113, DCB115, DCB118,
DCB132: The red light will continue to blink, but a yellow
indicator light will be illuminated during this operation.
Once the battery pack has reached an appropriate
temperature, the yellow light will turn off and the charger
will resume the charging procedure.
A charger will not charge a faulty battery pack. The charger
refusing to light could indicate a problem with the charger
or a faulty battery pack.
NOTE: If the charger refuses to light, take the charger and
battery pack to be tested at an authorized servicecenter.
Leaving the Battery Pack In the Charger
The charger and battery pack can be left connected with
the charge indicator showing pack charged.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot
or too cold, it automatically starts a Hot/Cold Pack Delay,
suspending charging until the battery pack has reached an
appropriate temperature. The charger then automatically
switches to the pack charging mode. This feature ensures
maximum battery packlife.
A cold battery pack may charge at a slower rate than a
warm batterypack.
The DCB118 charger is equipped with an internal fan
designed to cool the battery pack. The fan will turn on
automatically when the battery pack needs to be cooled.
Never operate the charger if the fan does not operate
properly or if ventilation slots are blocked. Do not permit
foreign objects to enter the interior of the charger.
Electronic Protection System
Li-Ion tools are designed with an Electronic Protection
System that will protect the battery pack against
overloading, overheating or deep discharge.
The tool will automatically turn off if the Electronic
Protection System engages. If this occurs, place the lithium-
ion battery pack on the charger until it is fully charged.
Important Charging Notes
1. Longest life and best performance can be obtained if
the battery pack is charged when the air temperature
is between 65°F – 75°F (18°C– 24°C). DO NOT charge
WARNING: If the plug or power cord is damaged,
it must be replaced by the manufacturer or its
representative or by an equally qualified person to
avoiddanger.
• Do not place any object on top of the charger or
place the charger on a soft surface that might block
the ventilation slots and result in excessive internal
heat. Place the charger in a position away from any heat
source. The charger is ventilated through slots in the top
and the bottom of thehousing.
• Do not operate the charger with a damaged cord
orplug–have them replaced immediately.
• Do not operate the charger if it has received a sharp
blow, been dropped or otherwise damaged in any
way. Take it to an authorized servicecenter.
• Do not disassemble the charger; take it to an
authorized service center when service or repair
is required. Incorrect reassembly may result in a risk of
electric shock, electrocution orfire.
• Disconnect the charger from the outlet before
attempting any cleaning. This will reduce the risk of
electric shock. Removing the battery pack will not reduce
thisrisk.
• NEVER attempt to connect 2 chargerstogether.
• The charger is designed to operate on standard
120V household electrical power. Do not attempt to
use it on any other voltage. This does not apply to the
vehicularcharger.
WARNING: Shock hazard. Do not allow any liquid to
get inside the charger. Electric shock mayresult.
WARNING: Burn hazard. Do not submerge the
battery pack in any liquid or allow any liquid to enter
the battery pack. Never attempt to open the battery
pack for any reason. If the plastic housing of the
battery pack breaks or cracks, return to a service center
for recycling.
CAUTION: Burn hazard. To reduce the risk of injury,
charge only DeWALT rechargeable battery packs.
Other types of batteries may overheat and burst
resulting in personal injury and propertydamage.
CAUTION: Under certain conditions, with the charger
plugged into the power supply, the charger can be
shorted by foreign material. Foreign materials of a
conductive nature, such as, but not limited to, grinding
dust, metal chips, steel wool, aluminum foil or any
buildup of metallic particles should be kept away from
the charger cavities. Always unplug the charger from
the power supply when there is no battery pack in the
cavity. Unplug the charger before attempting toclean.
Charging a Battery
NOTE: To ensure maximum performance and life of lithium-
ion battery packs, charge the battery pack fully before
firstuse.
1. Plug the charger into an appropriate outlet before
inserting batterypack.
2. Connect the charger and battery pack, making sure
the battery is fully seated. The (charging) light will blink

9
ENGLISH
Joining Trimmer Head Assembly to
Handle Assembly (Fig. A, B)
Combining the handle assembly15 to the trimmer head
assembly16 creates a pole trimmer that is approximately
7' (2.1m) long.
1. Align the groove on the outside of the coupling end of
the handle assembly15 with the tongue on the inside
of the coupling end of the trimmer head assembly16 .
2. Slide the threaded sleeve8 on the trimmer head
assembly down as far as possible and rotate the
sleeve clockwise until it stops and completely covers
thethreads.
WARNING: Always check to make sure that the sleeve
is completely threaded on and that the threads are no
longer visible. Not threading the sleeve completely on
could result in the assemblies becoming disconnected
creating a hazardous condition. Periodically check the
connections to ensure that no threads arevisible.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start-up can causeinjury.
Intended Use
This pole hedge trimmer is designed for professional
landscapingapplications.
DO NOT use under wet conditions or in presence of
flammable liquids orgases.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
when the battery pack is below +40°F (+4.5°C), or
above +104°F (+40°C). This is important and will
prevent serious damage to the batterypack.
2. The charger and battery pack may become warm to the
touch while charging. This is a normal condition, and
does not indicate a problem.To facilitate the cooling of
the battery pack after use, avoid placing the charger or
battery pack in a warm environment such as in a metal
shed or an uninsulatedtrailer.
3. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp
or other appliance;
b. Check to see if receptacle is connected to a light
switch which turns power off when you turn out
the lights;
c. Move the charger and battery pack to a location
where the surrounding air temperature is
approximately 65°F –75°F (18°C – 24°C);
d. If charging problems persist, take the tool, battery
pack and charger to your local servicecenter.
4. The battery pack should be recharged when it fails to
produce sufficient power on jobs which were easily
done previously. DO NOT CONTINUE to use under these
conditions. Follow the charging procedure. You may also
charge a partially used pack whenever you desire with
no adverse effect on the batterypack.
5. Foreign materials of a conductive nature such as, but
not limited to, grinding dust, metal chips, steel wool,
aluminum foil, or any buildup of metallic particles
should be kept away from charger cavities. Always
unplug the charger from the power supply when there
is no battery pack in the cavity. Unplug the charger
before attempting toclean.
6. Do not freeze or immerse the charger in water or any
otherliquid.
Charger Cleaning Instructions
WARNING: Shock hazard. Disconnect the charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using
a cloth or soft non-metallic brush. Do not use water or
any cleaningsolutions.
Wall Mounting
DCB107, DCB112, DCB113, DCB115, DCB118, DCB132
These chargers are designed to be wall mountable or to
sit upright on a table or work surface. If wall mounting,
locate the charger within reach of an electrical outlet,
and away from a corner or other obstructions which may
impede air flow. Use the back of the charger as a template
for the location of the mounting screws on the wall. Mount
the charger securely using drywall screws (purchased
separately) at least 1”(25.4 mm) long, with a screw head
diameter of 0.28–0.35”(7–9mm), screwed into wood to an
optimal depth leaving approximately 7/32”(5.5 mm) of the
screw exposed. Align the slots on the back of the charger
with the exposed screws and fully engage them in theslots.
Fig.B
16 815

ENGLISH
10
Fig.E
OPERATION
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start-up can causeinjury.
Fig.D
13
14
Attaching and Adjusting the Shoulder
Strap (Fig. C)
The pole hedge trimmer comes with an adjustable
shoulderstrap.
1. Snap the shoulder strap latch17 onto the strap
mount 10located on the unit, just in front of the on/
off trigger as shown in Figure C. Adjust the strap so it fits
over yourshoulder.
Pivoting the Trimmer Head (Fig. A, D, E, G)
The trimmer head pivots 180° and can be locked into
7 different positions within that range. To avoid being
pinched, do not grab the blades. Wear gloves and hold unit
as shown in FigureG.
WARNING: Before connecting the battery to the unit,
be sure the trimmer head is locked intoposition.
To Pivot the Trimmer Head
1. With one hand firmly gripping the trimmer head,
use the other hand to press the locking button13
and rotate the trimmer head handle14 to pivot the
trimmer head as shown in FigureE.
2. Lock the trimmer head into one of the seven operating
positions. To lock the trimmer head into place, release
your grip on the trimmer head handle. Check to make
sure that trimmer head is locked into position by trying
to move the motor housing. If it is not locked, rotate it to
the nearest lockposition.
Fig.C
17
10
Proper Hand Position (Fig. G)
WARNING: To reduce the risk of serious personal
injury, ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Installing and Removing the Battery Pack
(Fig. F)
NOTE: For best results, make sure your battery pack is
fullycharged.
To install the battery pack 6 into the tool handle, align the
battery pack with the rails inside the tool’s handle and slide
it into the handle until the battery pack is firmly seated in
the tool and ensure that it does notdisengage.
To remove the battery pack from the tool, press the release
button 7 and firmly pull the battery pack out of the tool
handle. Insert it into the charger as described in the charger
section of thismanual
Fig.F
7
6

11
ENGLISH
Before Operating Pole Hedge Trimmer
WARNING: The unit has not been designed to
provide protection from electric shock in the event
of contact with overhead electric lines, Consult local
regulations for safe distances from overhead electric
power lines and ensure that the operating position is
safe and secure before operating the extended reach
hedgetrimmer.
• For safe operation, read and understand all instructions
before using the pole hedge trimmer. Follow all safety
instructions. Failure to follow all safety instructions listed
below, can result in serious personalinjury.
• Watch what you are doing. Use common sense. Do not
operate pole hedge trimmer when you aretired.
• Only well-instructed adults should operate pole hedge
trimmer. Never allow children tooperate.
• Do not use unit for any job except that for which it
isintended.
• Do not allow children or untrained individuals to use
thisunit.
• Always use an ANSI/CSA approved hard hat when
operating the pole hedge trimmer overhead. Falling
debris can result in seriousinjury.
• Wear the following safety gear when operating pole
hedge trimmer:
-head protection marked to comply with ANSI Z89.1
-heavy-duty gloves
-substantial footwear
Switching Pole Hedge Trimmer On and Off
(Fig.A)
Ensure the trimmer head is locked into one of the seven
operating positions. Refer to Pivoting the Trimmer
Headsection.
To turn the tool ON pull the lock-off lever2 back with your
thumb and then squeeze the trigger1 . (Once the tool is
running you can release the lock-off lever.)
To turn the tool OFF, release the trigger.
Fig.G
Proper hand position requires one hand on the main
handle3 and one hand on the auxiliary handle4.
43
-safety glasses, goggles or face screen that are
marked to comply with ANSI Z87.1
-face or dust mask (if working in dusty areas)
• Do not wear loose fitting clothing, or jewelry of any kind
that could get caught in the moving blades or parts of
the pole hedgetrimmer.
• Secure long hair so it is above shoulder level to prevent
entanglement in any movingparts.
While Operating Pole Hedge Trimmer
• Stay alert. Use common sense while operating theunit.
• Keep work area clean. Cluttered areas inviteinjuries.
• Keep children, animals and bystanders at a safe
distance away from unit. Only the user should be in the
workarea.
• Grip unit securely, one hand on the trigger handle, the
other hand on the polehandle.
• Keep finger off trigger until ready touse.
• Before starting unit, make sure blades are not
touchinganything.
• Keep all parts of body away from blades when Pole
Hedge Trimmer isrunning.
• Carry unit from one place to another
-with battery removed
-by holding pole at balance point
-with blade cover in place
• Do not operate in poorlighting.
• During operation, rest periodically and change working
positions to reducefatigue.
• Keep firm footing and balance. Do not overreach.
Overreaching can result in loss of balance or exposure to
sharpsurfaces.
• Do not, under any circumstance, use any attachment or
accessory on this product, which was not provided with
the product, or identified as appropriate for use with this
product in this InstructionManual.
Do Not Operate Pole Hedge Trimmer
• while under the influence of alcohol, medication,
ordrugs
• in rain or in damp or wet areas
• where highly flammable liquids or gases are present
• if unit is damaged, adjusted wrong, or not fully and
securely assembled
• if trigger does not turn unit on and off. Blades must stop
moving when you release trigger. Have faulty switch
replaced by an authorized service center. SeeRepairs.
• while in a hurry
• while in tree or on a ladder
• while on aerial booms, buckets or platforms
• during high wind or storming weather

ENGLISH
12
Side Trimming Hedges (Fig.L)
Orient the trimmer as shown and begin at the bottom and
sweepup.
Fig.L
Fig.K
Trimming New Growth (Fig.J)
Using a wide, sweeping motion and feeding the blade teeth
through the twigs, is most effective. A slight downward
tilt of the blade in the direction of motion gives the
bestcutting.
Fig.J
Level Hedges (Fig.K)
To obtain exceptionally level hedges a piece of string can be
stretched along the length of the hedge as aguide.
Fig.H
Fig.I
Trimming Instructions (Fig. H–L)
DANGER: Keep hands away fromblade.
WARNING: To guard against injury, observe the
following:
• Read instruction manual before using. Save
instructionmanual.
• Check the hedge for foreign objects such as wires
or fences before eachuse.
• Keep hands on handles. Don’toverreach.
• Do not use under wetconditions.
CAUTION: Blade may coast after turnoff.
Working Position (Fig.H, I)
Maintain proper footing and balance and do not overreach.
Wear safety goggles, non-skid footwear and rubber gloves
when trimming. Hold the tool firmly in both hands and turn
the tool ON. Always hold the trimmer, as shown in Fig. H,
with one hand on the switch handle and one hand on the
auxiliary handle. Never hold the unit by the trimmerhead.

13
ENGLISH
Lubrication (Fig.A)
Blades
1. After use, carefully clean the blade11 with a
resinsolvent.
2. After cleaning, apply a light film of lubrication to the
exposedblade.
3. Turn the trimmer vertical with the blades toward the
ground and run the trimmer for a few seconds to fully
disperse thelubrication.
MAINTENANCE
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start-up can causeinjury.
Fig.M
Maintaining Blade (Fig. M)
The cutting blades are made from high quality, hardened
steel and with normal usage, they will not require
resharpening. However, if you accidentally hit a wire fence,
stones, glass, or other hard objects as shown in Figure M you
may put a nick in the blade. There is no need to remove this
nick as long as it does not interfere with the movement of
the blade. If it does interfere, remove the battery and use a
fine toothed file or sharpening stone to remove the nick. If
you drop the trimmer, carefully inspect it for damage. If the
blade is bent, housing cracked, handles broken or if you see
any other condition that may affect the trimmer’s operation
contact your local DeWALT authorized service center for
repairs before putting it back intouse.
Fertilizers and other garden chemicals contain agents which
greatly accelerate the corrosion of metals. Do not store the
unit on or adjacent to fertilizers orchemicals.
With the battery removed, use only mild soap and a damp
cloth to clean the unit. Never let any liquid get inside
the unit; never immerse any part of the unit into a liquid.
Prevent the blades from rusting by applying a film of light
machine oil aftercleaning.
Sharpening Blade (Fig.N)
• Keep blade sharp for best performance. A dull
blade does not cutcleanly.
• When sharpening blade, ensure that battery
isremoved.
• Replace bent or damaged
bladeimmediately.
It is recommended that sharpening of blades be performed
by a DeWALT factory service center. However, blade edges
may be sharpened by using a fine tooth file18.
1. Run trimmer until cutting blades19 areoffset.
2. Be sure the lock-off lever is engaged, the blade has
stopped, and the battery has been removed before
sharpeningblade.
3. Wear proper eye protection and gloves, and be careful
not to cutyourself.
4. Carefully file the cutting edges of the blade with a
fine tooth file. File toward the cutting edge20 at the
original cutting angle (38° from horizontal). File only
the straight cutting edges20 of the blades. Do not
file where the cutting edge curves into the center of
theblade.
5. Flip the trimmer over to sharpen the bottomblade.
6. Repeat steps to sharpen the opposite side of eachblade.
Fig.N 18
19
20
Cleaning
WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
of eye injury, always wear ANSI Z87.1 approved eye
protection when performingthisprocedure.
WARNING: Never use solvents or other harsh
chemicals for cleaning the non-metallic parts of
the tool. These chemicals may weaken the plastic
materials used in these parts. Use a cloth dampened
only with water and mild soap. Never let any liquid
get inside the tool; never immerse any part of the tool
into aliquid.

ENGLISH
14
Register Online
Thank you for your purchase. Register your product nowfor:
• WARRANTY SERVICE: Registering your product will
help you obtain more efficient warranty service in case
there is a problem with yourproduct.
• CONFIRMATION OF OWNERSHIP: In case of
an insurance loss, such as fire, flood or theft, your
registration of ownership will serve as your proof
ofpurchase.
• FOR YOUR SAFETY: Registering your product will
allow us to contact you in the unlikely event a safety
notification is required under the Federal Consumer
SafetyAct.
• Register online at www.dewalt.com
Accessories
WARNING: Since accessories, other than those
offered by DeWALT,have not been tested with this
product, use of such accessories with this tool could be
hazardous. To reduce the risk of injury, only DeWALT
recommended accessories should be used with
thisproduct.
Recommended accessories for use with your tool are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact DeWALT call 1-800-4-DeWALT
(1-800-433-9258) or visit our website: www.dewalt.com.
Repairs
The charger and battery pack are notserviceable. There are
no serviceable parts inside the charger or battery pack.
WARNING: To assure product SAFETY and
RELIABILITY, repairs, maintenance and adjustment
(including brush inspection and replacement, when
applicable) should be performed by a DeWALT factory
service center or a DeWALT authorized service center.
Always use identical replacementparts.
Three Year Limited Warranty
DeWALT will repair or replace, without charge, any defects
due to faulty materials or workmanship for three years
from the date of purchase (two years for batteries). This
warranty does not cover part failure due to normal wear
or tool abuse. For further detail of warranty coverage and
warranty repair information, visit www.dewalt.com or
call 1-800-4-DeWALT (1-800-433-9258). This warranty does
not apply to accessories or damage caused where repairs
have been made or attempted by others. THIS LIMITED
WARRANTY IS GIVEN IN LIEU OF ALL OTHERS, INCLUDING
THE IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, AND EXCLUDES ALL
INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do
not allow limitations on how long an implied warranty lasts
or the exclusion or limitation of incidental or consequential
damages, so these limitations may not apply to you. This
warranty gives you specific legal rights and you may have
other rights which vary in certain states orprovinces.
In addition to the warranty DeWALT tools are covered byour:
1 YEAR FREE SERVICE
DeWALT will maintain the tool and replace worn parts
caused by normal use, for free, any time during the first year
afterpurchase.
2 YEARS FREE SERVICE ON DeWALT BATTERY PACKS
DC9071, DC9091, DC9096, DC9182, DC9280, DC9360,
DCB120, DCB122, DCB124, DCB127, DCB201, DCB203BT,
DCB207,DCB361
3 YEARS FREE SERVICE ON DeWALT BATTERY PACKS
DCB200, DCB203, DCB204, DCB204BT, DCB205, DCB205BT,
DCB206, DCB230, DCB606, DCB609, DCB612
NOTE: Battery warranty voided if the battery pack is
tampered with in any way. DeWALT is not responsible for any
injury caused by tampering and may prosecute warranty
fraud to the fullest extent permitted bylaw.
90 DAY MONEY BACK GUARANTEE
If you are not completely satisfied with the performance of
your DeWALT Power Tool or Nailer for any reason, you can
return it within 90 days from the date of purchase with a
receipt for a full refund – no questionsasked.
LATIN AMERICA: This warranty does not apply to products
sold in Latin America. For products sold in Latin America,
see country specific warranty information contained in
the packaging, call the local company or see website for
warrantyinformation.
FREE WARNING LABEL REPLACEMENT: If your warning
labels become illegible or are missing, call 1-800-4-DeWALT
(1-800-433-9258) for a freereplacement.

FRANÇAIS
15
Définitions: symboles et termes d'alarmessécurité
Ces guides d'utilisation utilisent les symboles et termes d'alarmes sécurité suivants pour vous prévenir de situations
dangereuses et de risques de dommages corporels ou matériels.
DANGER : indique une situation dangereuse imminente qui, si elle n’est pas évitée, entraînera la mort ou des
blessuresgraves.
AVERTISSEMENT : indique une situation potentiellement dangereuse qui, si elle n’est pas évitée, pourrait entraîner la
mort ou des blessuresgraves.
ATTENTION : indique une situation potentiellement dangereuse qui, si elle n’est pas évitée, pourrait entraîner des
blessures légères oumodérées.
(Si utilisé sans aucun terme) Indique un message propre à la sécurité.
AVIS : indique une pratique ne posant aucun risque de dommages corporels mais qui par contre, si rien n’est fait pour
l’éviter, pourrait poser des risques de dommages matériels.
Français (traduction de la notice d’instructions originale)
AVERTISSEMENT : lire tous les avertissements
de sécurité et toutes les directives. Le non-respect
des avertissements et des directives pourrait se
solder par un choc électrique, un incendie et/ou une
blessuregrave.
AVERTISSEMENT : afin de réduire le risque de
blessures, lire le mode d’emploi del’outil.
Pour toute question ou remarque au sujet de cet outil
ou de tout autre outil DeWALT composez le
numéro sans frais : (1-800-433-9258).
11
12
5
13
9
8
4
10
1
7
6
3
2
15
16
14
Fig. A
1 Gâchette
2 Levier de verrouillage
3 Poignée
4 Poignée auxiliaire
5 Boîtier du moteur
6 Bloc-piles
7 Bouton de libération du
bloc-piles
8 Manchon fileté
9 Manche fileté
10 Support de la courroie
11 Lame du taille-haie
12 Tête du taille-haie
pivotante
13 Bouton de verrouillage
de la tête du taille-haie
14 Bouton de verrouillage
de la tête du taille-haie
15 Assemblage de la
poignée
16 Assemblage de la tête
du taille-haie

FRANÇAIS
16
cette application. L’utilisation d’une rallonge conçue
pour l’extérieur réduira les risques de chocélectrique.
f ) S’il est impossible d’éviter l’utilisation d’un
outil électrique dans un endroit humide,
brancher l’outil dans une prise ou sur un circuit
d’alimentation dotés d’un disjoncteur de fuite à
la terre (GFCI). L’utilisation de ce type de disjoncteur
réduit les risques de chocélectrique.
3) Sécurité personnelle
a ) Être vigilant, surveiller le travail effectué et faire
preuve de jugement lorsqu’un outil électrique
est utilisé. Ne pas utiliser d’outil électrique en
cas de fatigue ou sous l’influence de drogues,
d’alcool ou de médicaments. Un simple moment
d’inattention en utilisant un outil électrique peut
entraîner des blessures corporellesgraves.
b ) Utiliser des équipements de protection
individuelle. Toujours porter une protection
oculaire. L’utilisation d’équipements de protection
comme un masque antipoussière, des chaussures
antidérapantes, un casque de sécurité ou des
protecteurs auditifs lorsque la situation le requiert
réduira les risques de blessurescorporelles.
c ) Empêcher les démarrages intempestifs. S’assurer
que l’interrupteur se trouve à la position d’arrêt
avant de relier l’outil à une source d’alimentation
et/ou d’insérer un bloc-piles, de ramasser ou de
transporter l’outil. Transporter un outil électrique
alors que le doigt repose sur l’interrupteur ou brancher
un outil électrique dont l’interrupteur est à la position
de marche risque de provoquer unaccident.
d ) Retirer toute clé de réglage ou clé avant de
démarrer l’outil. Une clé ou une clé de réglage
attachée à une partie pivotante de l’outil électrique
peut provoquer des blessurescorporelles.
e ) Ne pas trop tendre les bras. Conserver
son équilibre en tout temps. Cela permet
de mieux maîtriser l’outil électrique dans les
situationsimprévues.
f ) S’habiller de manière appropriée. Ne pas porter
de vêtements amples ni de bijoux. Garder les
cheveux, les vêtements et les gants à l’écart des
pièces mobiles. Les vêtements amples, les bijoux ou
les cheveux longs risquent de rester coincés dans les
piècesmobiles.
g ) Si des composants sont fournis pour le
raccordement de dispositifs de dépoussiérage
et de ramassage, s’assurer que ceux-ci sont bien
raccordés et utilisés. L’utilisation d’un dispositif de
dépoussiérage peut réduire les dangers engendrés par
lespoussières.
h ) Ne pas laisser votre connaissance acquise suite
l’utilisation fréquente des outils vous permettre
de baisser la garde et ignorer les principes de
sécurité de l’outil. Un acte irréfléchi peut causer une
blessure grave en une fraction de seconde.
AVERTISSEMENTS GÉNÉRAUX SUR LA
SÉCURITÉ DES OUTILS
AVERTISSEMENT : lisez tous les avertissements
de sécurité, toutes les instructions, les
illustrations et les caractéristiques fournis
avec cet outil électrique. Ne pas suivre toutes
les instructions comprises aux présentes peut
conduire à un choc électrique, un incendie et/ou des
blessuresgraves.
CONSERVER TOUS LES
AVERTISSEMENTS ET TOUTES
LES DIRECTIVES POUR UN
USAGEULTÉRIEUR
Le terme « outil électrique » cité dans les avertissements se
rapporte à votre outil électrique à alimentation sur secteur
(avec fil) ou par piles (sans fil).
1) Sécurité du lieu de travail
a ) Tenir l’aire de travail propre et bien éclairée.
Les lieux encombrés ou sombres sont propices
auxaccidents.
b ) Ne pas faire fonctionner d’outils électriques
dans un milieu déflagrant, tel qu’en présence de
liquides, de gaz ou de poussières inflammables.
Les outils électriques produisent des étincelles qui
pourraient enflammer la poussière ou lesvapeurs.
c ) Éloigner les enfants et les personnes à proximité
pendant l’utilisation d’un outil électrique.
Une distraction pourrait en faire perdre la maîtrise
àl’utilisateur.
2) Sécurité en matière d’électricité
a ) Les fiches des outils électriques doivent
correspondre à la prise. Ne jamais modifier la
fiche d’aucune façon. Ne jamais utiliser de fiche
d’adaptation avec un outil électrique mis à la
terre. Le risque de choc électrique sera réduit par
l’utilisation de fiches non modifiées correspondant à
laprise.
b ) Éviter tout contact physique avec des surfaces
mises à la terre comme des tuyaux, des
radiateurs, des cuisinières et des réfrigérateurs.
Le risque de choc électrique est plus élevé si votre corps
est mis à laterre.
c ) Ne pas exposer les outils électriques à la pluie ou
à l’humidité. La pénétration de l’eau dans un outil
électrique augmente le risque de chocélectrique.
d ) Ne pas utiliser le cordon de façon abusive. Ne
jamais utiliser le cordon pour transporter, tirer
ou débrancher un outil électrique. Tenir le
cordon éloigné de la chaleur, de l’huile, des bords
tranchants et des pièces mobiles. Les cordons
endommagés ou enchevêtrés augmentent les risques
de chocélectrique.
e ) Pour l’utilisation d’un outil électrique à
l’extérieur, se servir d’une rallonge convenant à
Taille-haie télescopique 20V max*
DCPH820

FRANÇAIS
17
Avertissements de sécurité concernant
letaille-haie
• Utilisez les deux mains lorsque vous faites
fonctionner le taille-haie. Utiliser une main pourrait
causer une perte de contrôle et entraîner une blessure
corporellegrave.
• Gardez toutes les parties de votre corps loin de la
lame de coupe. Ne pas retirer la matière coupée ou la
matière maintenue à être coupée lorsque les lames
sont en mouvement. Assurez-vous que la gâchette
est fermée lorsque vous enlevez la matière coincée.
Les lames glissent une fois l’outil éteint. Un moment
d’inattention pendant l’utilisation du taille-haie peut
entraîner une blessure corporellegrave.
• Transportez le taille-haie par la poignée de
la détente avec la lame de coupe arrêtée. Une
c ) Lorsque le bloc-piles n’est pas utilisé, le tenir
éloigné des objets métalliques, notamment
des trombones, de la monnaie, des clés, des
clous, des vis ou autres petits objets métalliques
qui peuvent établir une connexion entre les
deux bornes. Le court-circuit des bornes du bloc-piles
risque de provoquer des brûlures ou unincendie.
d ) En cas d’utilisation abusive, le liquide peut gicler
hors du bloc-piles; éviter tout contact avec ce
liquide. Si un contact accidentel se produit, laver
à grande eau. Si le liquide entre en contact avec
les yeux, obtenir également des soins médicaux.
Le liquide qui gicle hors du bloc-piles peut provoquer
des irritations ou desbrûlures.
e ) Ne pas utiliser de bloc-piles ou outil qui
a été endommagé ou modifié. Les unités
endommagées ou modifiées peuvent avoir une
réaction imprévisible résultant en un incendie,
une explosion ou un potentiel de blessure.
f ) Ne pas exposer de bloc-piles ou l’outil aux
flammes ou à des températures excessives.
L’exposition aux flammes ou à une température
au-dessus de 129°C (265°F) pourrait causer
uneexplosion.
g ) Suivre toutes les instructions de recharge et
ne rechargez pas le bloc-piles ou l’outil à des
températures hors de la plage de température
indiquée dans les instructions. Une recharge
non conforme ou à une température hors des limites
spécifiées peut endommager les piles et augmenter le
risque d’incendie.
6) Réparation
a ) Faire réparer l’outil électrique par un réparateur
professionnel en n’utilisant que des pièces de
rechange identiques. Cela permettra de maintenir
une utilisation sécuritaire de l’outilélectriques.
b ) Ne jamais réparer des blocs-piles endommagés.
La réparation de blocs-piles doit seulement être
effectuée par le fabricant ou les fournisseurs de
serviceautorisé.
4) Utilisation et entretien d’un
outilélectrique
a ) Ne pas forcer un outil électrique. Utiliser l’outil
électrique approprié à l’application. L’outil
électrique approprié effectuera un meilleur travail,
de façon plus sûre et à la vitesse pour laquelle il a
étéconçu.
b ) Ne pas utiliser un outil électrique dont
l’interrupteur est défectueux. Tout outil électrique
dont l’interrupteur est défectueux est dangereux et
doit êtreréparé.
c ) Débranchez la fiche de la prise électrique et, si
amovible, retirez le bloc-piles de l’outil avant
d’effectuer tout ajustement, changement et
entreposage de celui-ci. Ces mesures préventives
réduisent les risques de démarrage accidentel de
l’outilélectrique.
d ) Ranger les outils électriques hors de la portée
des enfants et ne permettre à aucune personne
n’étant pas familière avec un outil électrique ou
son mode d’emploi d’utiliser cet outil. Les outils
électriques deviennent dangereux entre les mains
d’utilisateursinexpérimentés.
e ) Gardez les poignées et surfaces d’emprise
propres et libres de tout produit lubrifiant.
Vérifier si les pièces mobiles sont mal alignées ou
coincées, si des pièces sont brisées ou présentent
toute autre condition susceptible de nuire au
bon fonctionnement de l’outil électrique. En
cas de dommage, faire réparer l’outil électrique
avant toute nouvelle utilisation. Beaucoup
d’accidents sont causés par des outils électriques
malentretenus.
f ) S’assurer que les outils de coupe sont aiguisés et
propres. Les outils de coupe bien entretenus et affûtés
sont moins susceptibles de se coincer et sont plus
faciles àmaîtriser.
g ) Utiliser l’outil électrique, les accessoires, les
forets, etc. conformément aux présentes
directives en tenant compte des conditions de
travail et du travail à effectuer. L’utilisation d’un
outil électrique pour toute opération autre que celle
pour laquelle il a été conçu estdangereuse.
h ) Garder vos mains et les surfaces de prise sèches,
propres et libres de graisse et de poussière. Les
mains et les surfaces de prise glissante ne permettent
pas la manutention et le contrôle sécuritaires de l’outil
dans les situationsimprévues.
5) Utilisation et entretien du bloc-piles
a ) Ne recharger l’outil qu’au moyen du chargeur
précisé par le fabricant. L’utilisation d’un chargeur
qui convient à un type de bloc-piles risque de
provoquer un incendie s’il est utilisé avec un autre type
de b loc-piles.
b ) Utiliser les outils électriques uniquement avec
les blocs-piles conçus à cet effet. L’utilisation de
tout autre bloc-piles risque de causer des blessures ou
unincendie.

FRANÇAIS
18
Directives de sécurité propres aux taille-
haies télescopiques
• Ne pas utiliser le taille-haie télescopique par
mauvais temps, particulièrement lorsqu’il y a risque
d’orage. Cela permettra de réduire les risques d’être
touché par lafoudre.
• Pour réduire tout risque d’électrocution, ne pas
utiliser l’outil à proximité de lignes électriques. Tout
contact ou utilisation à proximité de lignes électriques
pose des risques de dommages corporels graves et
d’électrocution pouvant entrainer lamort.
• Utiliser systématiquement les deux mains lors de
l’utilisation du taille-haie télescopique. Maintenir
le taille-haie télescopique à deux mains pour éviter d’en
perdre lecontrôle.
• Porter systématiquement un casque de protection
pendant l’utilisation du taille-haie télescopique
au-dessus de la tête. La chute de débris pose des
risques de dommages corporelsgraves. Porter un casque
de sécurité conforme à la norme ANSI Z89.1 (CAN/
CSAZ94.1).
ATTENTION : ne pas l’exposer à lapluie.
Consignes de sécurité importantes
AVERTISSEMENT : lire et comprendre toutes les
directives. Le non-respect des directives suivantes
pose des risques de décharges électriques, d’incendie
et/ou de dommages corporelsgraves.
CONSERVER CES DIRECTIVES
Avant d’utiliser le taille-haie télescopique
ATTENTION : l’appareil n’a pas été conçu pour
protéger l’individu contre les décharges électriques en
cas de contact avec des lignes électriques aériennes.
Consulter la réglementation locale en vigueur relative
aux distances sécuritaires quant aux lignes électriques
et s’assurer que l’on pourra travailler en toute sécurité
avant d’utiliser le taille-haietélescopique.
manutention appropriée du taille-haie réduira une
possible blessure corporelle due aux lames decoupe.
• Tenez l’outil électrique seulement les surfaces de
prise isolées puisque la lame de coupe peut entrer
en contact avec les câbles cachés. Les lames de
coupe entrant un contact avec un câble «sous tension»
peuvent exposer les pièces métalliques de l’outil électrique
«sous tension» et pourraient donner un choc électrique
àl’utilisateur.
• Vérifiez la haie pour tout objet étranger, par ex., les
clôtures engrillage.
DANGER:gardez vos mains hors de portée de
la lame. Tout contact avec la lame entraînera une
blessure corporellegrave.
AVERTISSEMENT: porter une
protectionoculaire.
AVERTISSEMENT: ne pas exposer à lapluie.
• Pour votre sécurité, lire et comprendre toute instruction
avant toute utilisation du taille-haie télescopique. Suivre
toutes les directives de sécurité. Tout manquement
aux directives de sécurité suivantes pose des risques de
dommages corporelsgraves.
• Travailler prudemment. Faire preuve de bon sens. Ne pas
utiliser le taille-haie télescopique en cas defatigue.
• Le taille-haie télescopique ne doit être utilisé que par des
adultes expérimentés. Ne jamais permettre son utilisation
par desenfants.
• Ne pas utiliser le taille-haie télescopique pour tout travail
autre que celui pour lequel il a étéconçu.
• Ne permettre à aucun enfant ou individu non expérimenté
d’utiliser cetoutil.
• Porter les dispositifs de protection suivants pendant
l’utilisation du taille-haie télescopique:
- gants épais;
- chaussures robustes;
- protection oculaire, lunette ou masque de
protection portant le label d’homologation
ANSIZ87.1;
- masque ou masque antipoussières (en présence
depoussières);
• Ne pas porter des vêtements amples, des bijoux ou tout
autre objet similaire qui pourraient se prendre dans les
organes de coupe en mouvement ou dans les pièces du
taille-haietélescopique.
• Attacher les cheveux au-dessus des épaules pour qu’ils ne
se prennent pas dans les piècesmobiles.
Pendant l’utilisation du taille-
haie télescopique
• Rester vigilant. Faire preuve de bon sens pendant
l’utilisation de l’appareil.
• Maintenir l’aire de travail propre. Les lieux encombrés sont
propices auxaccidents.
• Maintenir les enfants, les animaux et tout autre individu
à une distance sécuritaire du taille-haie télescopique. Seul
l’utilisateur du taille-haie télescopique devrait se trouver
sur l’aire detravail.
• Maintenir le taille-haie télescopique solidement, une main
sur la poignée auxiliaire et l’autre sur la poignéeprincipale.
• Maintenir le doigt loin de la gâchette tant que l’on n’est
pas prêt àtravailler.
• Avant de démarrer le taille-haie télescopique, s’assurer que
l’organe de coupe ne touche aucunesurface.
• Maintenir toute partie du corps éloignée de l’organe
de coupe pendant le fonctionnement du taille-
haietélescopique.
• Retirer le bloc-piles du taille-haie télescopique
- avant de le transporter d’un lieu à un autre
- et le maintenir fermement en équilibre
- avec son organe de coupe vers l’arrière
• Ne pas utiliser l’appareil en cas d’éclairageinsuffisant.
• Pendant l’utilisation, se reposer périodiquement et
changer la position de travail pour réduire lafatigue.
• Maintenir son équilibre et les pieds solidement ancrés
au sol. Ne pas effectuer de travaux hors de portée. Il y a
