DEXAPLAN FA 602 - 10-2006 Quick guide

Operating and safety instructions
Introduction
Please read these operating instructions thoroughly and carefully. They are part of this
product and contain important instructions relating to its operation and handling.
Please always observe all safety instructions. Before initial operation, please check
that all parts are fitted correctly. If you have any questions or are unsure about
handling of the device, please contact the dealer or the service office. Please keep
these instructions in a safe place and pass them on to anyone else intending to use
the device.
Proper use
This mini window alarm is suitable for doors (including cupboard doors, etc.) and
windows. The device is designed exclusively for operation in dry, enclosed spaces.
This product must only be operated by three round cell batteries LR44/ 357A – 1.5 Volt.
Any use other than that described above or alteration of the device is not permitted
and causes damage. Other hazards such as injury and technical malfunctions
(e.g. short circuit, fire, electric shock) may ensue.
This device is only intended for use in private households.
Delivery scope
Please check the contents immediately after unpacking to ensure that the delivery
scope is complete and the device is in perfect condition.
4x Alarm units FA 602
4x Magnets
Adhesive strips for installation
Batteries (inserted in the device)
Equipment
QAlarm unit FA 602
WMagnet
EBattery compartment cover
ROn / Off switch (I / 0)
Technical data
Max. current consumption: approx. 55 mA
Operating voltage: 4.5V DC
Batteries: 3 x round cell, LR44/357A – 1.5 Volt
Alarm volume / sound level: approx. 95 dB (A)/0.30 m
Weight: 42 g
Safety instructions
In the event of damage caused as a result of non-compliance with these operating
instructions, the right to claim under the warranty shall expire. No liability shall be
assumed for consequential damage.
No liability shall be assumed for damage to property or personal injury caused by
improper handling or non - compliance with the safety instructions.
Avoid personal injury:
• Warning! Risk of suffocation! Keep the device, the batteries as well as the
packaging material away from children.
• Warning! Loud alarm! Avoid operating close to ears as this may damage your
hearing!
• Warning! Risk of explosion! Ensure that the batteries do not short circuit or
are thrown into fire. Do not charge the batteries!
• Warning! Risk of burns! Leaking or damaged batteries can burn your skin on
contact. Use protective gloves if the batteries have leaked or are damaged.
Avoid damage to property:
• Avoid bringing the device into contact with moisture as this may cause damage.
• When inserting the batteries, be sure to observe the correct polarity.
• When not using the device for extended periods of time, remove the batteries.
• The device must be battery-operated only. Do not use any other power supply.
• Avoid the following impacts on the device:
- major mechanical stress
- extreme temperatures
- strong vibrations
- strong magnetic or electrical fields
• Refer to the listed service station only for maintenance and repair work.
Installation
Areas of use and function
This mini window alarm can be installed on doors, windows, cupboards and cabinets.
It can be used to deter burglars and for child safety in the home or e.g. in a mobile home.
The adhesive strips supplied with the device are all you will need for installation. The
device is installed without any wiring or electrical connection.
The mini window alarm consists of an alarm unit FA 602 Qand a magnet W. The
alarm unit detects when a door or a window is opened. The alarm unit is fitted on the
frame, while the magnet is mounted on the door leaf or window leaf (or vice versa).
As soon as the magnet is more than approx. 20 mm away from the activated alarm,
a very loud alarm will sound.
Before initial operation
The round cell batteries are already installed in new devices. However, they are
covered by a protective film, which you must remove. To do this:
oSet On / Off switch Rto “0” (off).
oOpen the battery compartment by pushing the battery compartment cover E
down.
oHold the batteries in place and pull the protective film out.
oClose the battery compartment.
oPrior to the final assembly at the desired location (see “Switching alarm on/ off”)
perform a provisional functional test of the device.
Choosing the installation position
oWhen choosing a position for installation of your mini window alarm, avoid direct,
intensive sunlight, vibrations, dust, heat, cold and damp.
Note: The efficiency of the magnet can be reduced on metallic doors or windows. In
this case, reduce the distance between the magnet Wand the alarm unit Q.
Mini window alarm FA 602 Dexaplan
T 52
E
rR max. 10 mm
A
R
Q
W
B C
D
T52_FA602_GB.indd 1-3 24.10.2006 15:55:28 Uhr

Troubleshooting
Fault Cause Remedy
Alarm sounds although
windows / door are
closed.
The distance between the
magnet and the magnet
switch is too large (or the
arrow is pointing in the
wrong direction).
Reduce the distance.
Weak alarm signal. The batteries have run out. Insert new batteries.
The device does not
work or does not work
properly.
- The batteries have run
out.
- The batteries are in-
serted with the wrong
polarity.
- The arrow on the
magnet is not pointing
to the mark on the
alarm unit.
Insert new batteries.
Check that the batteries
have the correct polarity
and make contact.
Maintenance and cleaning
oCheck the technical safety and function of the mini window alarm regularly.
oRemove the batteries before maintenance or repair of the device.
oTo clean the alarm, use a soft cloth, if necessary with a little mild soap suds.
Never use benzene, thinner or similar chemical substances.
Disposal
Please dispose of the packaging materials in local containers. For details of the
current possibilities for disposing of unwanted electrical appliances, please contact
your local or city council.
Do not dispose of electrical appliances with the household waste!
In accordance with European Directive 2002 / 96 / EC on used electrical and electronic
appliances and its implementation in national law, used electrical devices must be
collected separately and recycled in an ecologically compatible manner.
Remove the batteries before disposing of the device.
Disposal of used batteries / accumulators
As the consumer you are required by law (Battery Ordinance) to return all used batteries
and accumulators. Disposal of batteries in the household waste is prohibited.
oYou can hand in your used batteries / accumulators free of charge at local council
collection points, the point of sale or wherever batteries/accumulators are sold.
By following these requirements you are meeting your legal obligations and making
an important contribution to protecting the environment.
Warranty / Service
Warranty
This device has a warranty of 3 years from the date of purchase. The device was
manufactured with care and inspected thoroughly before delivery. Please keep your
receipt as proof of purchase. If you have a claim under the warranty, please contact
the service office for your country. This is the only way to ensure that your device can
be sent in free of charge.
This warranty is only valid for the first purchaser and is not transferable.
The warranty furthermore covers material or manufacturing defects only. It does not
apply to wear parts or damage to fragile parts, e.g. switches or accumulators. The
product is solely intended for private use and not for commercial use. No claim for
damages may be made in the event of a burglary. An alarm is no substitute for
insurance cover and does not replace your duty of care.
In the event of incorrect and / or improper handling, the use of force or any work on
the device that is not performed by the service office, the warranty shall expire. This
warranty does not restrict your statutory rights.
Service
Information on dealing with problems can be found under www.dexaplan.com. If you have
any questions, please contact our service office by email ([e-mail]) or by
telephone (( T0870 - 241 3029; T 1890 851 851; Monday - Friday between
8.30 and 17.00). Here you will find all necessary information on service questions. Here you will find all necessary information on service questions
such as returns, etc.
Dexaplan GmbH
Paul-Böhringer-Str. 3 · D-74229 Oedheim
Last Information Update 10/2006 · Ident.No.: 10-2006-FA 602-GB / IE
It is important that there are no appliances with electromagnetic fields near to the
alarm, e.g. radio telephone, radio set or electric motor. These could have an effect on
the alarm function.
Installing the alarm unit
Attention! Do not drill or screw any additional screws into the housing of the alarm
unit Qor the magnet Wfor installation purposes.
oUse the supplied adhesive strips to fix the alarm unit Qand the magnets W.
oPlace the alarm unit Qat the edge of the window or door handle side (see also Fig. B).
oPlace the magnets Won the window or door frame (see also Fig C). If the frame
measures more than 12mm, place the magnet to the side of the frame (see Fig D).
Ensure that the side mark of the alarm Qis directly opposite the magnet’s arrow W
(tip of magnet’s arrow Wmust always show in the direction of the alarm Q).
The marking on the alarm and the magnets must also face one another.
Note: Alternatively, the magnets Wcan also be attached using screws (not supplied)
rather than using the adhesive strip. In this case, use a maximum 3.5 mm screws (e.g.
wooden screws 3 x 12 mm or tapping screws 2.9 x 13 mm) – the length of the screws
depends on the material and thickness of the frame. Please be sure not to bore or
screw into glass when attaching to a glass frame.
Important: the distance between the alarm Qand magnet Wmust be max. 10mm
(see Fig. B).
Lefthand installation:
o If you wish to fit the alarm on the lefthand side, turn it by 180° (“on its head”).
Operation
Switching the alarm on and off
oTo activate the alarm, switch the On / Off switch Rto “I” (On).
The alarm is now activated and emits a signal when the door or window is
opened (more than approx. 20mm between the alarm unit and the magnet). The
signal is only switched off when the door / window etc. is closed or by the On/ Off
switch R.
oTo deactivate the alarm or after the alarm signal has been triggered, switch the
On / Off switch Rto “O”.
Changing the batteries
oSet On / Off switch Rto “0” (off).
oOpen the battery compartment by pushing the battery compartment cover E
down (see Fig. A).
oCarefully remove the batteries, e.g. using a screw driver.
oPlace the new batteries in the correct positions. The correct polarity is indicated
in the battery compartment.
oPush the battery compartment cover Eback onto the alarm unit Q.
Note: always change all three batteries at the same time. If possible always use
alkaline batteries, as these guarantee longer service life.
T52_FA602_GB.indd 4-6 24.10.2006 15:55:28 Uhr
