DEXAPLAN TA 603 - 10-2006 Quick guide

Area of use
The door alarm is designed to monitor closed doors and emits an
acoustic signal when the door is opened.
It is installed inside the house and is suitable for doors opening to the
right or the left.
The door alarm is switched on and off with a key.
2 different operating modes can be selected with a function switch:
- “Immediate alarm” mode (when house is occupied)
- “Delayed alarm” mode (when house is unoccupied)
This allows you enough time to leave or enter your home with-
out triggering the alarm.The alarm emits a loud signal.
Pack contents
1 x Door alarm
1 x Magnet
2 x Switching keys
1 x Fixing material
1 x Operating instructions
1 x Drilling template
Description
On the front of the casing (see Fig. A)
QDoor alarm
WSwitching lock
EFunction switch
RSwitching key
TMarking showing right-hand magnetic switch
YBattery compartment cover
UFastening screw for the battery compartment cover
IMarking showing left-hand magnetic switch
OMagnet
PLight-emitting diode (LED)
On the rear of the casing (see Fig. B)
{Upper mounting surface
}Lower mounting surface
qUpper screw mounting
wLower screw mounting
On the rear of the magnet casing (see Fig. B)
eBase plate
rScrew mounting
tScrew mounting
Fastening material
yAdhesive tape 2x
uFixing screws 4x
iAdhesive tape 1x
Technical data
Operating voltage: 3 V DC
Current consumption: max. 200 mA
Power supply: 2 x batteries of type LR03 –
1.5 V (AAA)
Sensors: 2 x magnetic switches in the side
areas of the device casing
Switching distance: approx.15 mm
Alarm signal sound level: approx. 95 dB(A) at 1 meter distance
Alarm duration: max. 90 sec
Operating modes: (immediate alarm)
(delayed alarm)
Casing material: ABS plastic
Dimensions of door alarm casing: 54 x 104x 26 mm (wxhxd)
Dimensions of magnet casing: 12 x 40x 13 mm (wxhxd)
Safety instructions
The following instructions are provided for your safety and satisfaction
when the device is in operation. Please remember that failure to follow
these safety instructions can lead to significant risk of accident.
To avoid mortal danger and personal injury:
• Warning! Danger of suffocation! Never leave small children
with packing materials or small parts without supervision.
• Danger of electric shock! Always ensure that the device is kept
away from dampness and is never submerged under water!
• Warning! Danger of explosion! Never bring the device close to
fire, heat or long exposure to temperatures over 50 °C!
• Always ensure that the batteries are not short-circuited or thrown
into fire. The batteries must also never be recharged.
• Warning! Take care to prevent all damage to pipes and connections
for gas, electricity, water or telecommunications. Damage to gas
pipes can lead to explosion and risk to life and limb. Damage to
electrical connections can lead to mortal danger from electric shock.
Damaged water pipes can result in material damage from leaked
water. To identify any such damage use suitable detectors or con-
sult a specialist.
• Warning! The alarm signal is very loud! Avoid operating the
device close to ears and do not expose yourself to the loud alarm
signal over a longer period, as this could lead to serious damage
to your hearing!
• Never have the device operate close to sick or handicapped peo-
ple or animals! The state of shock resulting from the loud alarm
signal could cause mortal danger and risk of injury!
• Warning! Danger of chemical burns! Leaking or damaged bat-
teries can cause acid burns if they come in contact with skin.
Therefore always use suitable protective gloves when handling.
To avoid material damage:
• Use the device only with batteries LR03 1.5 V (AAA) batteries!
• Always ensure the correct + and - alignment when inserting the
batteries.
• Protect the device against strong magnetic or electrical fields!
• Before assembling and starting the device, always check the
delivery for damage and completeness!
• Make sure no glass or mirror surfaces of the door leaf are dam-
aged during assembly!
• Remove the batteries when the device is not in use over a longer
period.
• Use always new and never used batteries.
• If the alarm device is faulty, always have it repaired only by
authorised specialists!
Tip: Test the function of the door alarm at the planned assembly
location before final assembly.
Positioning
You can fit the door alarm for use on doors with the stop on the left or right.
Affix the device with the adhesive tape or fastening screws.The efficiency
of the magnet may be reduced on metallic doors. In this case reduce the
distance between the magnet and the door alarm to below 10 mm.
You will need a pen with removable ink to mark the mounting points.
oPlace the magnet Overtically at a level of approx. 150 cm on the
door frame, directly next to the edge of the door leaf.
oMake sure that the arrow symbol on the magnet is pointing to-
wards the door leaf (see also Fig. A).
oMake sure that the magnet does not touch the door leaf.
oMark the outline of the magnet casing on the door frame.
oClose the door completely.
oPlace the door alarm at a max. 10 mm distance from the magnet on
the edge of the door leaf.
oMake sure that the marking on the magnetic sensor Tor Iis
directly next to the arrow symbol on the magnet (see also Fig. A).
oMake sure that the door alarm does not touch the magnet.
oMark the outlines of the casing of the door alarm on the door leaf.
Assembly with adhesive strip
Use the adhesive tape y +
ito affix the door alarm and the magnet
to e.g. glass and plastic doors.
Assembly of the door alarm
oRemove the protective film from one side of the adhesive tape.
oStick the adhesive tape yflush and fully onto the mounting surfaces
of the door alarm casing { +
}.
oRemove the protective film from the other side of the adhesive tape.
oAffix the door alarm at the marked position on the door leaf.
oRemove the marked outline of the casing.
Assembly of the magnet
oRemove the protective film from one side of the adhesive tape i.
oStick the adhesive tape flush and fully onto the base plate eof
the magnet.
oRemove the protective film from the other side of the adhesive tape.
oAffix the magnet at the marked position on the door frame with
the arrow pointing at the door alarm.
oRemove the marked outline of the casing.
Assembly with fastening screws
Tip: you will need a crosstip screwdriver for inserting/removing
screws and a slotted screwdriver for levering work.
Tip: A drilling template is enclosed with the original packing.
Use the fastening screws uto affix the door alarm and the magnet to
e.g. wooden doors. Holes are provided on the back of the door alarm
casing for screw mounting q +
w. These holes must be marked in-
side the marking of the outline of the casing.
Assembly of the door alarm
oRelease the fastening screw Ufor the battery compartment cover Y
in anticlockwise direction.
oRemove the battery compartment cover from the casing of the
door alarm and take out the batteries.
oMark the holes inside the marking on the door leaf.
oScrew one fastening screw approx. 9 mm into the door leaf at the
position marking the hole for the upper screw mounting q.
oMount the door alarm on the head of the upper fastening screw
through the hole for the upper screw mounting.
oScrew a fastening screw approx. 9 mm into the door leaf through
the lower screw mounting hole w.
oReplace the batteries.
oFasten the battery compartment cover on the door alarm casing.
oTighten the fastening screw on the battery compartment cover in
clockwise direction.
oRemove the marked outline of the casing.
Assembly of the magnet
The holes for screw mounting r +
tare located on the underside of
the magnet casing. These holes must be marked inside the marking of
the outline of the casing.
oLever the base plate e carefully out of the magnet casing.
oMark the holes inside the marking on the door frame.
oScrew one fastening screw approx. 9 mm into the door frame through
each hole for screw mounting r +
tof the base plate.
oMake sure that the base plate is screwed flush onto the door frame.
oPress the casing of the magnet completely onto the base plate.
oRemove the marked outline of the casing.
Initial operation
Inserting the batteries
oBefore inserting the batteries make sure that the alarm function is
deactivated.
oInsert the switching key Rinto the switching lock Wand turn it
to OFF position.
oPull the switching key out of the switching lock. The arrow marking
points to the OFF position. The door alarm is switched off.
Door alarm TA 603 Dexaplan
AQWE
R
T
Y
U
I
O
P
y
i
u
max. 10 mm
C
Y
U
B
{
r
}
w
q
t
e
Operating and safety instructions
Introduction
Please read these operating instructions thoroughly and carefully. They
are part of this product and contain important instructions relating to
its operation and handling.
Please always observe all safety instructions. Before initial operation,
please check that all parts are fitted correctly. Please contact your
service centre if you have any questions or are uncertain regarding
correct handling of the device. Keep these instructions in a safe place
and provide them to any third party who may require the information.
Proper use
This door alarm is suitable for monitoring doors.The device is designed ex-
clusively for operation in dry, enclosed spaces in private households.This
product is only licensed for operation with two batteries of type LR03 – 1.5
Volt (AAA). Any other use or modification of the device constitutes improper
use and poses a serious risk of accident.The manufacturer is not liable for
damage caused by improper use or incorrect operation of the device.
T 82
KOE362_T82_GB.indd 1-5 25.10.2006 13:27:20 Uhr

oPlace the switching key Rin the switching lock Wand turn it to
ON position.
oPull the switching key out of the switching lock. The arrow mark
points towards the ON position and the LED lights up green for
approx. 12- 18 sec. During this time you may leave the room.
The alarm function is activated as soon as the illuminating diode is
switched off. During the delay time after the door has been opened,
the illuminating diode lights red for 12 - 18 seconds. If the door alarm
is not deactivated within this period, the alarm signal will sound and
the illuminating diode will switch off. The alarm signal sounds for up to
90 seconds. During this period, the alarm signal can be switched off
only with the switch key.
- Deactivating the alarm function
oPlace the switching key in the switching lock and turn it to OFF
position. The alarm is switched off.
oPull the switching key out of the switching lock. The arrow mark-
ing points towards OFF position.
Overview of LED indications
Green LED 12- 18 sec: the period when the delayed alarm is activated ..
Red LED 12 - 18 sec: the period for deactivation of the delayed ala rm
Flashing green: alarm has responded.
Flashing red: if the alarm function is deactivated:
the batteries must be replaced.
Flashing green / red
alternately: The period for deactivating the delayed alarm
Alarm was signalled.
Troubleshooting
Fault Cause Remedy
The alarm functions
cannot be deacti-
vated.
The switching keys
are missing.
Remove the batteries
from the battery com-
partment and contact
the service office for
your country.
The alarm function
is activated but
does not respond
when the door is
opened.
The distance between
the magnet and the
magnet switch is too
large (or the arrow is
pointing in the wrong
direction).
Reduce the distance.
The alarm signal
is weak and the
LED flashes red.
The batteries have
run out.
Insert new batteries.
Fault Cause Remedy
The device does
not work or does
not work properly.
- The batteries
have run out.
- The batteries are
inserted with the
wrong polarity.
- The arrow on the
magnet is not
pointing to the
mark on the
alarm unit.
Insert new batteries.
Check that the batter-
ies have the correct
polarity and make
contact.
Maintenance and cleaning
oCheck the technical safety and function of the device regularly.
oRemove the batteries before cleaning the device.
oUse a fluff-free cloth and a mild agent (no solvents) to clean the
plastic and metal surfaces.
Disposal
Dispose of packaging materials, used batteries and worn out devices
at a local authority approved disposal facility.
In accordance with European Directive 2002/96/EC (covering waste
electrical and electronic equipment) and its transposition into national
legislation, worn out electrical devices must be collected separately
and recycled. Take out the batteries before you dispose of electrical
devices. As the end user you have a duty to recycle or properly dispose
of your used batteries. Batteries must not be disposed of with the
household refuse.
Warranty
This device has a warranty of 3 years from the date of purchase. The
device was manufactured with care and inspected thoroughly before
delivery. Please keep your receipt as proof of purchase. If you have a
claim under the warranty, please contact the service office for your
country. This is the only way to ensure that your device can be sent in
free of charge.
This warranty is only valid for the first purchaser and is not transferable.
The warranty furthermore covers material or manufacturing defects
only. It does not apply to wear parts or damage to fragile parts, e.g.
switches or batteries. The product is solely intended for private use
and not for commercial use. No claim for damages may be made in
the event of a burglary. An alarm is no substitute for insurance cover
and does not replace your duty of care.
In the event of incorrect and / or improper handling, the use of force or
any work on the device that is not performed by the service office, the
warranty shall expire.This warranty does not restrict your statutory rights.
Service
Information on dealing with problems can be found under
www.dexaplan.com.
If you have any questions, please contact our service office by email
([e-mail]) or by telephone ( T0870 - 241 3029;
T 1890 851 851; Monday - Friday between 8.30 and 17.00).Here
you will find all necessary information on service questions such as returns,
etc.
Dexaplan GmbH
Paul-Böhringer-Str. 3 · D- 74229 Oedheim
Last Information Update 10 / 2006 · Ident.-No.: 10-2006-TA 603-GB / IE
oRemove the fastening screw Uof the battery compartment lid I
in an anti-clockwise direction.
oDraw the battery compartment lid from the door alarm.
oInsert two new LR03 1.5 V (AAA) batteries into the battery com-
partment with correct + and - alignment.
oPin the battery compartment lid on the door alarm.
oTighten the battery compartment lid fastening screw U by turning
it clockwise.
Activating / deactivating alarm functions
You can set two different alarm functions on the door alarm:
Immediate alarm and delayed alarm ..
The magnetic sensors of the activated door alarm react as soon as
the distance to the magnet becomes greater than approx. 15 mm.
When the alarm responds, the loud alarm signal is emitted for approx.
90 sec. After the alarm has been triggered, the LED Plights up green.
As soon as the door is closed completely again, the alarm function is
reactivated.
oTo change the operating mode, first switch the key to the “OFF”
position and then to “ON” to activate the function.
oDo not leave the switching key in the switching lock when the
alarm function has been activated.
-Activating the alarm function
Use the - alarm function so that the door alarm emits the alarm
signal immediately when the door is opened.
oClose the door completely.
oSwitch the function switch Eto position .
oPlace the switching key Rin the switching lock W and turn it to
ON position.
oPull the switching key out of the switching lock. The arrow mark
points towards the ON position.
oThe illuminating diode is switched off.
The alarm signal is triggered when the door is opened. The alarm sig-
nal sounds for up to 90 seconds. During this period, the alarm signal
can be switched off only with the switch key.
- Deactivating the alarm function
oPlace the switching key in the switching lock and turn it to OFF
position. The alarm function is deactivated.
oPull the switching key out of the switching lock. The arrow mark
points towards OFF position. The LED is switched off.
- Activating the alarm function
Use the alarm function so that the door alarm can be deactivatedalarm function so that the door alarm can be deactivated
with the switching key approx. 12-18 sec after the door has been
opened. If the door alarm is not deactivated within this period of time,
the alarm signal is emitted to indicate that the door has been opened.
oClose the door completely.
oSet the function switch Eto position ..
KOE362_T82_GB.indd 6-10 25.10.2006 13:27:21 Uhr
