FRIEDLAND MA2 User manual

Kit Contents:
1 x Alarm Unit
4 x 1.5V A76 (LR44) Button Cells
(supplied fitted)
1 x Adhesive Pad
1 x Instruction Leaflet
1 x Window Sticker
Tools and Equipment Required:
None
INTRODUCTION
The Window Alarm is a vibration-
activated alarm that is fitted
directly to the glass of windows
(and doors). The vibration
caused by an impact on the
window or by someone forcing
open and breaking the window
will activate the alarm.
Safety: The use of ear protection
is advisable when working in close
proximity to the Siren due to the
high sound level produced.
These instructions should be retained in a safe place for future reference.
MA2 - Window Alarm
Installation and Operating Instructions
Lo
Hi
Off
Battery
Status
Indicator
Sensitivity
Selector
Switch
Battery Compartment
Cover
Battery
Test
Switch
Siren

INSTALLATION
This alarm is suitable for mounting
in dry interior locations only.
1) Fix the alarm in position on
the window glass using the
adhesive pad supplied. Ensure
that the surface is clean and
free from grease and dirt before
applying the adhesive pads.
2) Slide off the battery compart-
ment cover.
3) If fitted, carefully remove the
battery isolation tab from
between the batteries. If the
batteries are dislodged replace
them noting the correct polarity
shown inside the battery
compartment.
4) Replace the battery cover.
SYSTEM OPERATION
Select the operating sensitivity, Hi
or Lo as required using the slide
switch on the side of the alarm.
Lo Alarm active - Low sensitivity
Hi Alarm active - High sensitivity
OFF Alarm inactive /stop siren
Note: Setting the alarm to Low
sensitivity will require a greater
amount of vibration to trigger the
alarm but will make it less prone to
false alarms.
When triggered the alarm will
sound for approx. 30s when the
device will automatically reset or
until the alarm is switched OFF.
TESTING
It is recommended that the alarm
is tested immediately after
installation and at regular
intervals not exceeding 1 month.
To test the alarm, tap the window
next to the alarm to activate the
vibration sensor and trigger the
alarm. To stop the alarm move
the selector switch to the OFF
position. Remember to reset the
selector switch in the original
position after the test.
Note: A cloth can be used to
cover the siren and reduce the
sound output of the alarm during
testing.

To test the battery remove the
battery cover and press the
battery test button, if the battery
status indicator LED does not
illuminate or is dim then the
battery should be replaced.
TROUBLE SHOOTING
Excessive Amount of Vibration
Required to Trigger Alarm
●
Sensitivity too low – select “Hi”
sensitivity on selector switch.
●
Batteries low, flat (see battery
test).
Alarm Triggered by too Little
Vibration
●
Sensitivity too high –select “Lo”
sensitivity on selector switch.
MAINTENANCE
The product may be cleaned
with a soft damp cloth and then
wiped dry. Do not use abrasive,
solvent based or aerosol
cleaners as this may damage
and/or discolour the product. Do
not allow water to enter or
attempt to clean inside the unit.
Batteries:
Do not allow batteries to corrode
and leak as this may cause
permanent damage to the product.
Replacement
Batteries: 4 x 1.5V A76
(LR44) Button Cells
Typical Life: up to 1 year
Take care to insert the batteries
with the correct polarity as shown
inside the battery compartments.
Do not mix new and old batteries
or different types of batteries.
Do not fit rechargeable batteries.
At the end of their
useful life the
batteries should be
disposed of via a
suitable Recycling
Centre. Do not dispose of with
your normal household waste. DO
NOT BURN.

45374PL Ed.1
Friedland, Novar Electrical Devices and Systems
The Arnold Centre, Paycocke Road, Basildon, Essex. SS14 3EA
www.friedlandsecurity.com
GUARANTEE
Novar ED&S undertakes to replace or repair at its discretion goods
(excluding non rechargeable batteries) should they become defective
within 2 years solely as a result of faulty materials and workmanship.
Understandably if the product has not been installed, operated or
maintained in accordance with the instructions, has not been used
appropriately or if any attempt has been made to rectify, dismantle or
alter the product in any way the guarantee will be invalidated.
The guarantee states Novar ED&S entire liability. It does not extend
to cover consequential loss or damage or installation costs arising
from the defective product. This guarantee does not in any way
affect the statutory or other rights of a consumer and applies to
products installed within the UK and Eire only.
If an item develops a fault within the first year, it should be returned to
the point of sale with:
1) Proof of purchase.
2) A full description of the fault.
3) All relevant batteries (disconnected).
In the second year it should be returned direct to Friedland Technical
Sales Services Department at the address shown below.
Friedland is a trademark of Novar ED&S.
HELPLINE
If you have any problems with your
alarm, please call the Helpline on:
01268 563273
(Lines open 9.00am to 5.00pm, Monday to Friday)
