8514-238-001 REV PR page 1
INDUSTRIAL WASHER
MODEL T-400 ON-PREMISE
V-SERIES CONTROL
OPERATOR’S MANUAL
INSTALLATION & OPERATION
INSTRUCTIONS
Please read this information and retain for reference.
WARNING - THIS WASHER IS EQUIPPED WITH DEVICES AND FEATURES RELATING TO ITS SAFE
OPERATION. TO AVOID INJURY OR ELECTRICAL SHOCK, DO NOT PERFORM ANY SERVICING UNLESS
QUALIFIED TO DO SO.
IT IS THE RESPONSIBILITY OF THE OWNER TO CHECK THIS EQUIPMENT ON A FREQUENT
BASIS TO ASSURE ITS SAFE OPERATION.
A machine should NOT be allowed to operate if any of the following occur:
-Excessively high water level.
-If machine is not connected to a properly grounded circuit.
-If the door does not remain securely locked during the entire cycle.
-Vibration or shaking from an inadequate mounting or foundation.
WARNING - SAFETY PRECAUTIONS
-Always shut off power and water supply before servicing.
-Do not overload the washer.
-Do not open door when cylinder is in motion or it contains water.
-Do not bypass any safety devices of this washer.
-Do not use volatile or flammable substances in or near this washer.
-Keep all panels in place. They protect against shock and injury and add rigidity to the washer.
PREVENTIVE MAINTENANCE REQUIREMENTS
DAILY
-Check that the loading door remains securely locked and cannot be opened during an entire
cycle.
-Check the water connections for leaks.
-Clean the top, front, and sides of the cabinet to remove residue.
-Clean the soap dispenser and lid and check that all dispenser mounting screws are in-place and
tight.
-Check the drain valve for leaking and that it opens properly.
-Check the loading door for leaks. Clean the door seal of all foreign matter.
-Leave the loading door open to aerate the washer when not in use.
QUARTERLY
-Make sure the washer is inoperative by switching off the main power supply.
-Check the V-belts for wear and proper tension.
-Clean lint and other foreign matter from around motor.
-Check all water connections for leaks.
-Wipe and clean the inside of the washer and check that all electrical components are free of
moisture and dust.
-Remove and clean water inlet hose filters. Replace if necessary.
-Check anchor bolts. Retighten if necessary
IMPORTANT: Replace any and all panels that were removed to perform daily and/or quarterly
maintenance.

8514-238-001 REV PR page 2
TABLE OF CONTENTS
1INSTALLATION INSTRUCTIONS ..........................................................................3
1.1 FOUNDATION REQUIREMENTS......................................................................3
1.2 MOUNTING ..................................................................................................3
1.3 PLUMBING ...................................................................................................7
1.4 DRAIN .........................................................................................................7
1.5 PROTECTIVE FILM ........................................................................................7
1.6 ELECTRICAL .................................................................................................7
1.6.1 INSTALLING THE ELECTRICAL CONNECTION...........................................7
1.6.2 FUSING REQUIREMENTS.........................................................................8
1.6.3 CONTROLS TRANSFORMER (208-240V models only) ................................8
1.6.4 MAXIMUM SPIN SPEED ADJUSTMENT......................................................9
1.7 INJECTION SOURCE CONNECTIONS ............................................................10
1.8 OPERATION CHECK ....................................................................................10
2OPERATING INSTRUCTIONS.............................................................................11
2.1 STARTING THE WASHER.............................................................................11
2.2 END OF CYCLE ...........................................................................................12
2.3 SAFETY DOOR LOCK...................................................................................12
2.4 VARIABLE FREQUENCY DRIVE INDICATORS ................................................12
3MACHINE PROGRAMMING INSTRUCTIONS ........................................................13
3.1 EDITING AN EXISTING CYCLE.....................................................................13
3.2 DEFAULT WASHER CYCLE PROGRAMS .........................................................15
3.3 RAPID ADVANCE MODE ..............................................................................19
4WASHER ERROR CODES ...................................................................................20
5TROUBLESHOOTING ........................................................................................22
6SERVICE AND PARTS........................................................................................26
MODEL
T-400 30 LB. WASHER
CAPACITY
30 LBS/4 CUBIC FT. (13.6 kg/113 L)
CYLINDER SIZE
25” DIA X 14 1/8” DEEP (63.5cm X 36cm)
ELECTRICAL
208-240 VAC, 60 HZ, 1 OR 3 PHASE
DRIVE SYSTEM
SOFT START REVERSING INVERTER DRIVE, 2 HP MOTOR
WASH SPEED
50 RPM
INTERMEDIATE
EXTRACT
411 RPM (60 G’S)
FINAL EXTRACT
531 RPM (100 G’S)
MACHINE CONTROL
PROGRAMMABLE COMPUTER UP TO 6 CYCLES
WATER INLET
2 SOLENOID OPERATED VALVES
FLOW RATE: 9 GAL/MIN (34 L/MIN) EACH, 30-120 PSI
DRAIN VALVE
3” (76 mm) DIAMETER
Table 1: Washer Specifications

8514-238-001 REV PR page 3
1INSTALLATION INSTRUCTIONS
All washers must be installed in accordance with all local, state and national
building, electrical, plumbing and other codes in effect in the area.
WARNING:
THESE INSTALLATION AND SERVICING INSTRUCTIONS ARE FOR USE
BY QUALIFIED PERSONNEL ONLY. TO AVOID INJURY AND ELECTRICAL
SHOCK, DO NOT PERFORM ANY SERVICING OTHER THAN THAT
CONTAINED IN THE OPERATING INSTRUCTIONS, UNLESS QUALIFIED.
1.1 FOUNDATION REQUIREMENTS
This machine is designed for use on or over bare concrete floor - not to be
used above combustible flooring, such as carpet or wood. The washer
must be securely bolted to a substantial concrete floor, or mounted upon
a suitable base that is securely bolted to a substantial concrete floor.
CARE MUST BE TAKEN WITH ALL FOUNDATION WORK TO ENSURE A
STABLE UNIT INSTALLATION, ELIMINATING POSSIBILITIES OF
EXCESSIVE VIBRATION.
All installations require concrete floors 6 inches (150mm) or thicker.
Anchor bolts or expansion anchors must be of a quality grade and a
minimum of 1/2 inch (14 mm) diameter. Mounting hardware is not
provided with the machine.
1.2 MOUNTING
A concrete pedestal or steel-mounting base that elevates the machine
approximately 6 inches (150 mm) above the floor level is recommended to
provide easy access to the loading door. Allow a minimum 24 inches
(600mm) of clearance behind the rear of the machine to provide access
for motor service. Refer to Figures Figure 1-1 and Figure 1-2 for machine
bolt-down dimensions. Contact a Dexter laundry equipment distributor for
recommended steel mounting bases.
If an elevated concrete pedestal is desired, it should be embedded into
the existing floor. Anchor bolts should be 1/2" x 8" (14 mm x 200 mm),
grade 5 or better, headed by a 4 inch (10 cm) square fish plate and
should protrude 1 7/8” (48 mm) above the finished surface of the
pedestal.
EXPANSION ANCHORS ARE NOT RECOMMENDED FOR USE IN CONCRETE
PEDESTALS BECAUSE THE ANCHORS ARE TOO CLOSE TO AN EDGE,
CAUSING IT TO BREAK OUT.
Refer to Figures Figure 1-1 and Figure 1-3 for recommended concrete
pedestal dimensions. Refer to Figure Figure 1-4 for overall machine
mounting dimensions.

8514-238-001 REV PR page 4
Figure 1-1: Concrete Pedestal Mounting
Figure 1-2: Floor Outline

8514-238-001 REV PR page 5
Figure 1-3: Machine Mounting Detail

8514-238-001 REV PR page 6
Figure 1-4: T-400 Industrial Washer Mounting Diagram

8514-238-001 REV PR page 7
1.3 PLUMBING
Two 48 inch (1.22 m) water supply hoses are provided with each machine.
The threaded connections on the hoses are ¾-11 ½ NHT.
Separate hot and cold water lines must be supplied to the machine,
maintaining 30 psi to 120 psi (207 kPa to 827 kPa) water flow pressure. A
140°F (60°C) hot water supply is recommended for best washing results.
Do not exceed 180°F (82°C) water temperature.
1.4 DRAIN
The drain outlet tube at the rear of the machine is 3” (76 mm) in
diameter. Any drain hose used must be lower than the drain valve to
assure proper draining.
1.5 PROTECTIVE FILM
The machine may have protective adhesive film on the front control panel
label area and on the front, top, and side stainless steel panels. The film
may be peeled off before putting the machine into service.
1.6 ELECTRICAL
The Dexter T-400 single/three-phase 208-240VAC 60 Hz washing
machines are intended to be permanently installed appliances. No power
cord is provided. The machine should be connected to an individual
branch circuit not shared by lighting or other equipment. The connection
should be sheathed in liquid tight flexible conduit, or equivalent, with
conductors of the proper size and insulation. A qualified technician should
make such connections in accordance with the wiring diagram with a
minimum 12 gauge wire.
WARNING:
SHUT OFF POWER AND WATER BEFORE OPENING ANY SERVICE
PANELS.
1.6.1 INSTALLING THE ELECTRICAL CONNECTION
1.6.1.1 Disconnect all power to the washer.
1.6.1.2 Remove the top panel of the washer and locate the
power terminal block near the back of the control
compartment.
1.6.1.3 If power is 208-240-3PH-60Hz, connect L1, L2, L3
and Ground. If there is a high leg, it must be
connected to L3.
1.6.1.4 If power is 208-240-1PH-60Hz, connect L1, L2 and
Ground.
NOTE: It is important that the grounding screw next to the power
terminal block TB-1 be connected to a good external ground.

8514-238-001 REV PR page 8
1.6.2 FUSING REQUIREMENTS
Single- and Three -phase 208-240VAC models:
15 AMP TIME-DELAY (DUAL ELEMENT) FUSE (or equivalent circuit
breaker)
1.6.3 CONTROLS TRANSFORMER (208-240V models only)
The controls transformer is located inside the control trough and
steps a range of 208 to 240 volts down to 115 volts. There are two
terminals on the controls transformer for the primary (incoming)
power. Use the terminal marked “208V” for power supplies
between 208 and 219 volts. Use the terminal marked “240V” for
power supplies between 220 and 240 volts. Refer to Figure 1-5 for
control transformer connections.
Figure 1-5: Control Transformer Connections

8514-238-001 REV PR page 9
1.6.4 MAXIMUM SPIN SPEED ADJUSTMENT
If desired, the washer can be adjusted to limit the maximum
extract spin speed for all wash cycles.
To make this adjustment, a jumper wire must either be installed or
removed on the Variable Frequency Drive (VFD), depending on the
washer model and desired speed. This Dexter jumper part number
8220-057-036 (qty 1) is factory supplied on terminal points “10V”
and “RC”. Remove this jumper to make new jumper connections if
necessary. Refer to Figure 1-6 for the approximate location of the
control terminations on the Variable Frequency Drive (VFD) and
Table 2 for appropriate jumper connection points indicated with an
“X” for the desired maximum spin speed setting. If no adjustment
to default spin speed is desired, do not remove or add any wires on
VFD.
Figure 1-6: Control Terminations on Variable Frequency Drive
MI1 MI2 MI3 MI4 MI5 MI6
DCM
(Left)
DCM
(Right)
24V ACM AVI ACI 10V M01
60 G X X
80 G X X
100 G
60 G X X
100 G X X
140 G X X
200 G
100 G X X
140 G
200 G
Max Spin
Speed
V Series Washer
Model
REMOVE Brown Jumper between MI5/M01
Default Setting (With Factory Installed Brown Jumper)
Default Setting (No Jumper Required)
Default Setting (No Jumper Required)
Jumper Terminal Locations on Variable Frequency Drive (VFD)
T-300, T-400,
T-600, T-900,
T-1200
T-350, T-450,
T-750
T-950, T-1450
Table 2: Spin Speed Adjustment Jumper Locations

8514-238-001 REV PR page 10
1.7 INJECTION SOURCE CONNECTIONS
The washer control may be programmed to send six 120V output signals
for a chemical injection system of up to four chemical sources. The
signals are not intended as a power source and must be limited to less
than 100 milliamps of current. There is a separate terminal block for
connection of the external injection signals. For the injection sources,
program codes 0 through 6 and their respective terminal block
connections are as shown in Table 3.
Dexter
Recommended
Connections
Controller
Programmed
Signals
Injection
Terminal Block
Circuits
Detergent
1
A
Bleach
2
B
Starch
3
C
Sour/Softener
4
D
5
A and B
6
C and D
0
None
Table 3: Injection Signal and Circuit Identification
Chemical Injection hoses are to be inserted into the injection inlet at the
upper right rear of the washer. These hoses should be inserted into the
round PVC pipe a minimum of 14" (35.5 cm) and a maximum of 18" (45.7
cm) to eliminate chemical buildup in the pipe and/or restrict water flow to
the tub. Secure the hoses as required.
1.8 OPERATION CHECK
After all mounting, plumbing and electrical work is completed, select any
desired wash cycle and run the machine through a complete wash cycle.
Check for water leaks and verify proper operation.
During intermediate spin and final spin, the cylinder should turn in a
counterclockwise direction when viewed from the front of the machine.
If spin is clockwise, the T1 and T2 motor wires connecting to terminal T1
and T2 on the variable frequency drive should be swapped. Remove
power to the machine before opening service panels and swapping wires.

8514-238-001 REV PR page 11
2OPERATING INSTRUCTIONS
2.1 STARTING THE WASHER
2.1.1 Turn on power to the washer.
2.1.2 Ensure washer is in “RUN” mode.
Locate the “RUN/PROGRAM” key switch and key. The current
mode is indicated by the alignment of the key slot. If washer is not
in “RUN” mode, insert and turn the key to the “RUN” position.
2.1.3 Load the laundry.
Place laundry loosely into the cylinder and latch the door securely.
Be sure laundry does not get caught between the door gasket and
tub front when closing the door. Maximum load is 30 pounds
clothes, dry weight. Do not load the washer with more than 30
pounds.
NOTE: To begin closing the door, the handle must be in the
horizontal position. After moving the door to the closed position,
the handle must be turned down to the vertical position in order to
latch the door for machine operation.
2.1.4 Select wash cycle.
Select the appropriate cycle number (1 through 6) for the type of
load being washed. See the default cycle descriptions in section
3.2. Use the “UP”and “DOWN”keys to change the two digit cycle
number on the display to the desired cycle.
2.1.5 Add washing chemicals.
If not using a chemical injection system, add low sudsing powdered
detergent into the “DETERGENT” compartment of the automatic
dispenser on the top of the washer.
If liquid wash products are used in the “DETERGENT”
compartment, they must be added at the beginning of the wash
cycle.
If desired, add fabric softener to the “FABRIC SOFTENER”
compartment. Use the amount of fabric softener as recommended
by the manufacturer.
If the machine is set for pre-wash, washing products can be added
to the round opening of the dispenser or put in with the clothes
when loading the washing machine.
If bleach is desired, DO NOT place into dispenser until bleach light
blinks during the wash cycle.
2.1.6 Press “START”.
The display will go blank for a moment and then display the cycle
time in minutes. The door will lock and remain locked until the end
of the cycle.

8514-238-001 REV PR page 12
2.2 END OF CYCLE
When the cycle is complete, the time will display “0” and a 5-second tone
will sound. The door can now be opened. Immediately remove contents
of washer. Leave the door open when the machine is not in use.
2.3 SAFETY DOOR LOCK
This machine is equipped with a safety door lock that locks the door when
the cycle is started until the cycle is complete. The door lock prevents
opening the door for up to 3 minutes if the power is interrupted during
the cycle.
2.4 VARIABLE FREQUENCY DRIVE INDICATORS
There are three small red LEDs located on the upper Variable Frequency
Drive (VFD) cover. They are labeled as “READY”, “RUN”, and “FAULT”
and can be used for troubleshooting. The definitions of the LEDs are
listed in Table 4 below.
Table 4: Variable Frequency Drive Indicators
Washer Condition
“READY”
LED
Status
“RUN”
LED Status
“FAULT”
LED
Status
Idle Mode
(No Cylinder Movement)
ON
OFF
OFF
Tumbling
ON
ON
OFF
Stop from Tumble
ON
FLASHING
OFF
Ramp to Intermediate or
Final Extract Spin
ON
ON
OFF
Spinning
(Intermediate or Final)
ON
ON
OFF
Stop from Spin
(Intermediate or Final)
ON
FLASHING
OFF
Faulted
ON
OFF
ON

8514-238-001 REV PR page 13
3MACHINE PROGRAMMING INSTRUCTIONS
This Dexter washer is programmed with 6 factory default programs available for
use immediately after installation. Any of these cycles, listed and detailed in
section 3.2, can be customized to include up to 8 baths with various defined
settings including Cycle Time, Water Temperature, Water Level, Type of Fill, Spin
Time, and Injection Source. Programming can be accomplished manually using
the machine controls or by connecting to the machine control using a PDA
(Personal Digital Assistant). For instructions on using a PDA with this washer
control, please contact your local Dexter laundry equipment distributor. Please
read below for manual programming instructions.
3.1 EDITING AN EXISTING CYCLE
3.1.1 Turn on the power to the washer.
Washer must be in idle mode to program.
3.1.2 Ensure washer is in “PROGRAM” mode.
Locate the “RUN/PROGRAM” key switch and key. The current
mode is indicated by the alignment of the key slot. If washer is not
in “PROGRAM” mode, insert and turn the key to the “PROGRAM”
position.
The display will show “C__0”. The “ADD BLEACH” light will blink
and will continue to blink during the programming mode.
3.1.3 Select cycle to alter.
Press the “DOWN” or “UP” buttons on the keypad, as shown in
Figure 3-1, until the desired cycle number, 01 through 06, is
displayed.
Figure 3-1: Washer Control Keypad Layout
3.1.4 Press “START” to enter the cycle.
The display should now show a “b”.
3.1.5 Select a bath to alter.
Press the “UP” and “DOWN” buttons to select a bath. The mode
indicator lights, as shown in Figure 3-2, illuminate to indicate which
bath is being selected.
FINAL
RINSE
PRE
WASH
FLUSH WASH RINSE SPIN
Figure 3-2: Washer Mode Lights
There are 8 available baths to program: FLUSH, PREWASH, WASH,

8514-238-001 REV PR page 14
RINSE1, RINSE 2, RINSE 3, RINSE 4, and FINAL RINSE.
When “RINSE” is illuminated, up to 4 rinses may be programmed.
Each rinse is shown on the display as “b r1” through “b r4”.
3.1.6 Press “START” to display the settings.
Available settings to alter in each bath are Cycle Time, Water
Temp, Water Level, Type of Fill, Spin Time, and Injection Source.
3.1.7 Input settings.
The first setting to alter is the Cycle Time, shown on the display as
“Ct**” where ** is a placeholder for the options digits. Use the
“DOWN” and “UP” keys to set the desired time in minutes and
press “START” to advance to the next setting. If no change is
desired, press “START” to advance to the next setting. Repeat
process for each setting. Each bath setting can be programmed
with the options shown in Table 5.
SETTING
DISPLAY
OPTIONS
Cycle Time
Ct**
Two-digit amount of time for bath in minutes.
-00 to 15 minutes for Flush, Prewash, Wash,
Rinse 1, 2, 3 and 4. If the time is set to 00,
then the bath will be eliminated from the
cycle.
-01 to 15 minutes for Final Rinse.
Water
Temperature
t_**
HH for hot water
CH for warm water
CC for cold water
EE for no water2
Water Level
L_**
Lo for low level
HI for high level
Type of Fill1
dF_*
d for delayed fill (default)
t for timed fill
Spin Time
S_**
Two-digit amount of time for spin in minutes.
-00 to 10 minutes for Flush, Prewash, Wash,
Rinse 1, 2, 3 and 4
-01 to 10 minutes for Final Rinse
Injection
Source2
IS_*
Single-digit code indicating injector signal(s), 0 to 6.
Table 5: Bath Program Settings
1 A delayed fill will pause the cycle time countdown until the selected low level is
reached. A timed fill will allow the cycle time countdown to continue regardless
of water level reached.
2Codes for injections sources are defined in Table 3. When “EE” is selected in
the Water Temperature setting, the electronic controller prohibits injection
signals. The programmed injection source value is ignored.
3.1.8 To exit the programming of a bath, press the “STOP” button.
If desired, repeat steps 3.1.5 through 3.1.7 to program another
bath.

8514-238-001 REV PR page 15
3.1.9 To select a different cycle to program, press the “STOP” button
again.
If desired, repeat steps 3.1.3 through 3.1.8 to program another
cycle.
3.1.10 To end programming, turn the key to “RUN” position.
It is recommended when changes are made to one or more of the
preset programs that the cycle number and the changes be
documented for later reference. Blank cycle tables have been
provided at the end of section 3.2.
NOTE: The Wash Cycle programming mode will automatically exit and
return to the Idle mode if no buttons are pressed for one minute.
3.2 DEFAULT WASHER CYCLE PROGRAMS
The factory default cycles pre-programmed into the washer are listed with
each bath and setting option in this section.
Cycle #
Recommended Use
1
Sheets & Pillowcases (Health Care)
2
Towels / Pads / Diapers (Health Care)
3
White Towels (Hotel / Motel)
4
Guest Laundry (Hotel / Motel or Health Care)
5
Rags & Mops (Hotel / Motel)
6
Colored Cotton Linen (Food & Beverage)

8514-238-001 REV PR page 16
Cycle 1 Sheets & Pillowcases (Health Care)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Delay
Fill
Spin Time
(min.)
Injection Source
Flush
3
CH
HI
d
Prewash
2
CH
HI
d
Wash
7
HH
LO
d
1 (Detergent)
Rinse 1
7
HH
LO
d
2 (Bleach)
Rinse 2
2
CH
HI
d
1
Rinse 3
2
CH
HI
d
Rinse 4
Final Rinse
4
CH
LO
d
4
4 (Sour/Soft)
Cycle 2 Towels / Pads / Diapers (Health Care)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Delay
Fill
Spin Time
(min.)
Injection Source
Flush
3
CH
HI
d
Prewash
2
CH
HI
d
Wash
7
HH
LO
d
1 (Detergent)
Rinse 1
1
HH
HI
d
Rinse 2
7
HH
LO
d
2 (Bleach)
Rinse 3
2
CH
HI
d
1
Rinse 4
2
CH
HI
d
Final Rinse
4
CH
LO
d
5
4 (Sour/Soft)
Cycle 3 White Towels (Hotel / Motel)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Delay
Fill
Spin Time
(min.)
Injection Source
Flush
Prewash
Wash
7
HH
LO
d
1 (Detergent)
Rinse 1
1
HH
HI
d
Rinse 2
7
HH
LO
d
2 (Bleach)
Rinse 3
2
CH
HI
d
1
Rinse 4
2
CH
HI
d
Final Rinse
4
CH
LO
d
5
4 (Sour/Soft)

8514-238-001 REV PR page 17
Cycle 4 Guest Laundry (Hotel / Motel or Health Care)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Delay
Fill
Spin Time
(min.)
Injection Source
Flush
3
CH
HI
d
Prewash
Wash
7
HH
LO
d
5 (Detergent/Bleach)
Rinse 1
2
HH
HI
d
Rinse 2
2
CH
HI
d
Rinse 3
2
CH
HI
d
Rinse 4
Final Rinse
4
CH
LO
d
4
4 (Sour/Soft)
Cycle 5 Rags & Mops (Hotel / Motel)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Delay
Fill
Spin Time
(min.)
Injection Source
Flush
3
CH
HI
d
Prewash
2
CH
HI
d
Wash
2
CH
HI
d
Rinse 1
7
HH
LO
d
1 (Detergent)
Rinse 2
2
HH
HI
d
Rinse 3
7
HH
LO
d
2 (Bleach)
Rinse 4
2
CH
HI
d
1
Final Rinse
2
CH
LO
d
5
Cycle 6 Colored Cotton Linen (Food & Beverage)
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Delay
Fill
Spin Time
(min.)
Injection Source
Flush
2
CH
HI
d
Prewash
Wash
10
HH
LO
d
1 (Detergent)
Rinse 1
7
HH
LO
d
2 (Bleach)
Rinse 2
2
CH
HI
d
1
Rinse 3
2
CH
HI
d
Rinse 4
Final Rinse
4
CH
LO
d
4
6 (Sour/Starch)

8514-238-001 REV PR page 18
Cycle _____ Description _________________________________
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Delay
Fill
Spin Time
(min.)
Injection Source
Flush
Prewash
Wash
Rinse 1
Rinse 2
Rinse 3
Rinse 4
Final Rinse
Cycle _____ Description _________________________________
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Delay
Fill
Spin Time
(min.)
Injection Source
Flush
Prewash
Wash
Rinse 1
Rinse 2
Rinse 3
Rinse 4
Final Rinse
Cycle _____ Description _________________________________
Bath
Bath Cycle
Time (min.)
Water
Temp.
Water
Level
Delay
Fill
Spin Time
(min.)
Injection Source
Flush
Prewash
Wash
Rinse 1
Rinse 2
Rinse 3
Rinse 4
Final Rinse

8514-238-001 REV PR page 19
3.3 RAPID ADVANCE MODE
Rapid Advance mode is a key-controlled override to interrupt the current
cycle, drain the water, and advance to the next mode of the wash cycle,
including Pre Wash, Wash, Rinse, Final Rinse, Spin. The indicator lights
will show to which segment the cycle has been advanced.
To enter the Rapid Advance mode, turn the key counter-clockwise (CCW).
The Rapid Advance setting is not marked next to the key, but turning the
key CCW until it stops selects this mode. The Rapid Advance mode can
be entered from either the Idle mode or during the cycle. If the cycle has
not yet started, press the “START” button. To rapid advance to the next
step in the wash cycle, push both the “UP” and “START” buttons at the
same time. The display will show “Ad” (advance) in the display. The
washer will advance to the next bath segment only after the water is
drained from the washer.
Note:
-The time displayed may not be accurate.
-The cycle will continue in rapid advance mode even if the key is
turned to “RUN” and/or removed.
-Rapid advance cannot skip the final 1-minute tumble of the cycle,
and the door lock may remain activated for a couple minutes after
the cycle has been completed.
-The chemical injection signals will NOT operate in Rapid Advance
mode.
To end the cycle and exit the Rapid Advance mode without waiting for the
time to count down, push and hold the STOP button for 5 seconds or
more.

8514-238-001 REV PR page 20
4WASHER ERROR CODES
Fault #
(F #)
Description
Customer Action
1
The door failed to close and lock or the door
failed to remain locked after three tries of
latching the door and starting during the cycle.
Turn off the power to the washer. Check wire connections to door /lock switches. Check
wire connections from switches to controller. If necessary door lock mechanism should be
adjusted by a qualified person. Turn on the power to the washer. (See Note)
2
The washer tub does not fill with water within 7
minutes. The wash cycle will continue. The F
2 will flash three times, then wait for 30
seconds. The error will clear at the end of the
cycle.
Turn of the power to the washer. Check the operation of the water valves. Check the
incoming water pressure. Check for blocked or restricted water flow. Check to ensure the
drain valve is functioning properly. Turn on the power to the washer. (See Note)
3
Memory error in controller.
Turn off the power to the washer. Wait one minute. Turn power back on to the washer. If
the problem returns, clear the fault with the Palm. If the problem returns again, replace the
washer controller.
4
Washer controller communication error
Turn off the power to the washer. Wait one minute. Turn power back on to the washer. If
the problem returns, replace the washer controller.
5
Pressure Switch error ( only OPL )- when the
high level sensor indicates full but the lower
one indicates empty. The wash cycle will
continue. The F 5 will flash three times, then
wait for 30 seconds. The error will clear at the
end of the cycle.
Turn off the power to the washer. Replace the pressure switch. Turn on power to the
washer. (See Note)
6
Wrong washer size for drive type.
Turn off the power to the washer. Check to ensure all the harnesses are properly connected
to the controller. Check to ensure the drive horsepower is proper for this size of washer.
Turn on power to the washer. (See Note) If problem reappears, contact your Dexter
representative.
7
Wrong size drive installed
Turn off the power to the washer. Check to ensure all the harnesses are properly connected
to the controller. Check to ensure the drive horsepower is proper for this size of washer.
Contact your Dexter representative.
8
The washer tub does not empty within 7
minutes. The wash cycle will continue. The F 8
will flash three times, then wait for 30 seconds.
The error will clear at the end of the cycle.
Turn off the power to the washer. Check to ensure the drain valve is operating properly.
Check to ensure the pressure switch tube is clear of blockage. Check to ensure the pressure
switch is operating proper. Correct any located problems. Turn on power to the washer.
(See Note)
9
The washer tub does not reach the spin target
frequency within 200 seconds. The wash cycle
will continue. The F 9 will flash three times,
then wait for 30 seconds. The error will clear
at the end of the cycle.
Turn off the power to the washer. Inspect the washer to ensure the tub spins freely. If
restricted, then clear the blockage. Test washer. If tub spins freely, the drive needs to be
replaced.
10
After a spin the washer tub does not stop
within 150 seconds.
Turn off the power to the washer. Inspect the braking resistors and the connecting wiring to
the drive braking resistors mounted in the top of the washer. If the resistors and wiring is
correct, then replace the drive.
