MD711-SU Installation Guide
Package Contents
www.d.com
Note:
The USB 2.0, LAN and COM ports provide galvanic isolation up to 3kVac/4kVdc to prevent damaging
circuitry of the electonic devices connected with each other.
• 1 MD711-SU system unit
• SATA mounting screws
• M.2/Mini PCIe mounting screws
• 1 CD disk includes:
- Drivers / Manual
Front Panel
DFI reserves the right to change the specications at any time prior to the product's release. For the latest revision and details of the
installation process, please refer to the user's manual.
DC-in
Mic-in
Line-out
DVI-D
DP
COM 2
COM 1
USB 2.0
LAN 2
LAN 1
USB 3.0
Rear Panel
Power Button
with LED (blue)
HDD LED
(green)

2
Removing the Chassis Cover
Please observe the following guidelines and follow the procedure to open
the system.
1. Make sure the system and all other peripheral devices connected to it have
been powered off.
2. Disconnect all power cords and cables.
3. The 4 screws on the sides of the system are used to secure the cover to the
chassis. Remove these screws and put them in a safe place for later use.
Chassis screw
Chassis screw

3
Installing a 2.5" SATA Drive
2. Insert the SATA drive into the HDD bracket and secure it in place with the
provided screws. Connect the data and power cables to the drive.
The SATA HDD bracket is included in the product package and can accommodate
two SATA drives. Use the following procedure to install a SATA HDD or SSD:
Mounting screw
SATA cables
1. Remove the thumb screws that secure the drive bay on the mainboard and
then remove the drive bay.
HDD bracket

4
3. Connect the other end of the SATA data cable and the SATA power cable to
the SATA data and SATA power connector on the mainboard respectively.
SATA data connector
SATA power connector
Mounting Screw
Mounting Screw
2. Place the SATA drive with the HDD bracket into the system. Align the
mounting holes on the HDD bracket with the mounting holes on the
mainboard and use the provided screws to secure the drive in place.

5
Installing a SODIMM
Grasp the module by its edges and align the SODIMM’s notch with the socket’s
key; then insert the SODIMM into the socket at an angle and push it forward
until the retaining clips snap behind. Make sure that you have inserted the
module fully into the socket so that the retaining clips will snap into place.
Notes:
1. The system supports dual-channel conguration. To enable dual-channel,
populate both SODIMM sockets.
2. If you plan to install only one SODIMM, install it in the DDR4_1 socket (closer
to the center of the mainboard).
3. The SODIMM sockets can only accept DDR4 memory modules. Please do not
install other types of memory modules.
To remove a SODIMM, gently spread the retaining clips at each end of the SO-
DIMM socket. The SODIMM should pop out of the socket. Lift the SODIMM away
from the socket on the mainboard.
Insert the SODIMM
at an angle
DIMM2
DIMM1
SODIMM is rmly seated
in place with the retaining
clips snapped behind

6
The Mini PCIe socket is located on the mainboard. Remove the HDD bracket rst
to access the socket. Use the following procedure to install a Mini PCIe card:
1. Grasp the Mini PCIe card by its edges and align the notch in the connector of
the Mini PCIe card with the notch in the connector on the mainboard.
2. Insert the Mini PCIe card into the connector.
Installing a Mini PCIe Expansion Card
3. Push down on the other end of the Mini PCIe card and secure the card on the
mainboard with the provided mounting screw (same size as the M.2 screw).
Insert the card at
an angle
Mounting screw
Note:
The Mini PCIe slot provides PCIe and USB signals and can accommodate a Mini
PCIe card.

7
Note:
The M.2 slot provides PCIe, USB, and SATA signals and can accommodate common
mobile broadband and storage modules.
Installing an M.2 Expansion Card
The system is equipped with one M.2 socket, supporting the M.2 22x42mm (key B)
form factor. Remove the HDD bracket rst to access the socket. Use the following
procedure to install an M.2 card:
Insert the card
at an angle
Mounting screw
1. Align the notch at the edge of the M.2 card with the key in the connector.
2. Insert the M.2 card into the connector.
3. Push down on the other end of the M.2 card and secure and card on
the mainboard with the provided mounting screw (same size as the
Mini PCIe screw).

8
2. Insert the expansion card into the PCIe slot on the riser card. Ensure the card
is properly seated into the slot.
PCIe card
Installing a PCIe Expansion Card
The PCIe slot on the riser card inside the system is used to install expansion cards.
Use the following procedure to install a Mini PCIe card:
Slot plate
Mounting screw and bracket
1. Remove the slot plate and bracket by removing the screw on the front chassis.
Note:
The riser card (DFI model: T100-1E) has a x16 PCIe connector (PCIe Gen3 x4 lanes).

9
Front View
PCIe card
167.65mm
3. secure the bracket in place.

10
Board Layout and Jumper Settings
www.d.com
1
SATA 1
1
SATA 0
SATA 3.0
1
4
Front Panel
Clear CMOS Data
(JP1)
Intel
WGI210AT
1
6
SMBus
DVI-D
DP/HDMI
1
2
11
12
1
4
SATA
Power 0
SATA
Power 1
2
113
14
LPC
Standby LED
DDR4_1 SODIMM
DDR4_2 SODIMM
LAN 1 /2
USB 1-4 USB 3.0
USB 5-6 USB 2.0
1
SPI Flash BIOS
USB 2.0 7-8
Auto Power-on
Select (JP4)
Nuvoton
COM 1/2
1
Mic-in
Line-out
PCIe x4
Buzzer
1
2
Battery
9
10
DC-in/Mic-in/Line-out
1
M.2
Mini PCIe
Clear CMOS Data JP1
Normal (default) 1-2 On
Clear CMOS Data 2-3 On
Auto Power-on Select JP4
Power-on via Power Button (default) 1-2 On
Power-on via AC Power 2-3 On
