DFI C51G-ML User manual

91100605
C51G-ML
System Board
User’s Manual

Copyright
This publication contains information that is protected by copyright.
No part of it may be reproduced in any form or by any means or
used to make any transformation/adaptation without the prior
written permission from the copyright holders.
This publication is provided for informational purposes only. The
manufacturer makes no representations or warranties with respect to
the contents or use of this manual and specifically disclaims any
express or implied warranties of merchantability or fitness for any
particular purpose.The user will assume the entire risk of the use or
the results of the use of this document. Further, the manufacturer
reserves the right to revise this publication and make changes to its
contents at any time, without obligation to notify any person or
entity of such revisions or changes.
© 2006. All Rights Reserved.
Trademarks
Windows®98, Windows®98 SE, Windows®ME, Windows®2000,
Windows NT®4.0 and Windows®XP are registered trademarks of
Microsoft Corporation. VIA is a registered trademark of VIA
Technologies, Inc. Award is a registered trademark of Award Soft-
ware, Inc. Other trademarks and registered trademarks of products
appearing in this manual are the properties of their respective
holders.

FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio TV technician for
help.
Notice:
1. The changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
2. Shielded interface cables must be used in order to comply with
the emission limits.

Table of Contents
About this Manual................................................................................
Warranty.....................................................................................................
Static Electricity Precaution................................................................
Safety Measures.....................................................................................
About the Package...............................................................................
Before Using the System Board.........................................................
Chapter 1 - Introduction....................................................................
Specifications...................................................................................................................................
Special Features of the System Board..................................................................
Chapter 2 - Hardware Installation....................................................
System Board Layout ..........................................................................................................
System Memory..........................................................................................................................
CPU.......................................................................................................................................................
Jumper Settings............................................................................................................................
Rear Panel I/O Ports.............................................................................................................
I/O Connectors..........................................................................................................................
Chapter 3 - BIOS Setup......................................................................
Award BIOS Setup Utility.................................................................................................
NVRAID BIOS............................................................................................................................
Updating the BIOS..................................................................................................................
Chapter 4 - Supported Softwares.....................................................
Chapter 5 - Cool’n’Quiet Technology..............................................
Chapter 6 - RAID.................................................................................
Appendix A - System Error Message...............................................
Appendix B - Troubleshooting..........................................................
5
5
6
6
7
7
8
8
10
16
16
17
19
25
30
40
55
55
99
100
102
115
119
124
126

About this Manual
This user’s manual contains detailed information about the system
board. If, in some cases, some information doesn’t match those
shown in the multilingual manual, the multilingual manual should al-
ways be regarded as the most updated version. The multilingual
manual is included in the system board package.
Warranty
1. Warranty does not cover damages or failures that arised from
misuse of the product, inability to use the product, unauthorized
replacement or alteration of components and product
specifications.
2. The warranty is void if the product has been subjected to
physical abuse, improper installation, modification, accidents or
unauthorized repair of the product.
3. Unless otherwise instructed in this user’s manual, the user may
not, under any circumstances, attempt to perform service,
adjustments or repairs on the product, whether in or out of
warranty. It must be returned to the purchase point, factory or
authorized service agency for all such work.
4. We will not be liable for any indirect, special, incidental or
consequencial damages to the product that has been modified
or altered.

Introduction
1
6
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board,
components or devices even before installing them in your system
unit. Static electrical discharge can damage computer components
without causing any signs of physical damage. You must take extra
care in handling them to ensure against electrostatic build-up.
1. To prevent electrostatic build-up, leave the system board in its
anti-static bag until you are ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of
the components, contacts or connections.
5. Avoid touching the pins or contacts on all modules and
connectors. Hold modules or connectors by their ends.
Important:
Electrostatic discharge (ESD) can damage your processor, disk
drive and other components. Perform the upgrade instruction
procedures described at an ESD workstation only. If such a
station is not available, you can provide some ESD protection
by wearing an antistatic wrist strap and attaching it to a metal
part of the system chassis. If a wrist strap is unavailable,
establish and maintain contact with the system chassis
throughout any procedures requiring ESD protection.
Safety Measures
To avoid damage to the system:
• Use the correct AC input voltage range.....
To reduce the risk of electric shock:
• Unplug the power cord before removing the system chassis
cover for installation or servicing. After installation or servicing,
cover the system chassis before plugging the power cord.
Battery:
• Danger of explosion if battery incorrectly replaced.
• Replace only with the same or equivalent type recommend by
the manufacturer.
• Dispose of used batteries according to the battery
manufacturer’s instructions.

1
Introduction
7
About the Package
The system board package contains the following items. If any of
these items are missing or damaged, please contact your dealer or
sales representative for assistance.
;The system board
;A user’s manual
;One IDE cable
;One floppy cable
;Two Serial ATA data cables
;Two Serial ATA power cables
;One RAID driver diskette
;One I/O shield
;One “Mainboard Utility” CD
The system board and accessories in the package may not come
similar to the information listed above. This may differ in accordance
to the sales region or models in which it was sold. For more
information about the standard package in your region, please
contact your dealer or sales representative.
Before Using the System Board
Before using the system board, prepare basic system components.
If you are installing the system board in a new system, you will need
at least the following internal components.
•A CPU
•Memory module
•Storage devices such as hard disk drive, CD-ROM, etc.
You will also need external system peripherals you intend to use
which will normally include at least a keyboard, a mouse and a video
display monitor.

Introduction
1
8
Chapter 1 - Introduction
Specifications
Processor
Front Side Bus
Chipset
System Memory
Expansion Slots
BIOS
Power Management
Hardware Monitor
Graphics
Audio
AMD®AthlonTM 64 / SempronTM
Socket 754
1600MT/s HyperTransport interface
NVIDIA®chipset
- North bridge: NVIDIA®GeForceTM 6100 GPU
- South bridge: NVIDIA®nForceTM 410 MCP
Two 184-pin DDR SDRAM DIMM sockets
Supports single channel (64-bit wide) memory interface
Supports up to 2GB system memory
Supports PC2100 (DDR266), PC2700 (DDR333) and PC3200
(DDR400) DDR SDRAM DIMM
Supports x8/x16 ECC/non-ECC unbuffered DIMMs, up to
512Mb DDR devices
1 PCI Express x16 slot
1 PCI Express x1 slot
2 PCI slots
Award BIOS
4Mbit flash memory
ACPI and OS Directed Power Management
ACPI STR (Suspend to RAM) function
Wake-On-PS/2 Keyboard/Mouse
Wake-On-USB Keyboard/Mouse
Wake-On-LAN
Wake-On-Ring
RTC timer to power-on the system
AC power failure recovery
Monitors CPU/system temperature
Monitors 5V/12V/3.3V/5VSB/Vbat/Vcore/Vdimm/Vchip voltages
Monitors the speed of the cooling fans
CPU Overheat Protection function monitors CPU temperature
during system boot-up
Graphics integrated in the GeForceTM 6100 GPU
Includes NVIDIA®PureVideoTM technology that delivers smooth
High-Definition (HD) video in all formats and outstanding picture
clarity
Realtek ALC655 6-channel AC’97 audio CODEC
True stereo line level outputs
S/PDIF-in/out interface

1
Introduction
9
LAN
IDE
Serial ATA with
RAID
Rear Panel I/O
Internal I/O
PCB
Realtek RTL8201CL LAN Phy
Fully compliant to IEEE 802.3 (10BASE-T) and 802.3u
(100BASE-TX) standards
Supports two IDE connectors that allows connecting up to four
UltraDMA 133Mbps hard drives
Supports two Serial ATA ports
SATA speed up to 3Gb/s
RAID 0 and RAID 1
1 mini-DIN-6 PS/2 mouse port
1 mini-DIN-6 PS/2 keyboard port
1 parallel port
1 COM port
1 VGA port
1 RJ45 LAN port
4 USB 2.0/1.1 ports
Line-in, line-out and mic-in jacks
2 connectors for 4 additional external USB 2.0/1.1 ports
1 front audio connector for external line-out and mic-in jacks
1 CD-in internal audio connector
1 coaxial S/PDIF connector
1 IrDA connector
2 Serial ATA connectors
2 IDE connectors
1 floppy connector
1 24-pin ATX main power connector
1 4-pin ATX 12V power connector
1 front panel connector
3 fan connectors
microATX form factor
24.4cm (9.6") x 24.4cm (9.6")

Introduction
1
10
Features
The system board supports the AMD AthlonTM 64 proc-
essor. AMD AthlonTM 64 provides superior computing for
many software applications by allowing both 32-bit and
64-bit applications to run simultaneously on the same
platform. The operating system and software are able to process
more data and access a tremendous amount of memory which im-
proves the overall system performance.
2T timing which provides better system stability is supported in CG
or later revisions of the AMD AthlonTM 64 processor. You can select
the memory timing in the Genie BIOS Setting submenu (“DRAM
Timing and Config” section) of the BIOS.
The AMD Cool‘n’QuietTM technology allows
the system to detect the CPU’s tasks and
utilization status. When the CPU’s task slows down, the system effec-
tively lowers power consumption by lowering its CPU speed and
voltage, subsequently decreasing its noise level.
PCI Express is a high bandwidth I/O infrastructure
that possesses the ability to scale speeds by forming
multiple lanes. The system board currently supports
the physical layer of x1 and x16 lane widths. The x1 PCI Express
lane supports transfer rate of 2.5 Gigabytes (250MBbps) per sec-
ond. The PCI Express architecture also provides a high performance
graphics infrastructure by enhancing the capability of a x16 PCI Ex-
press lane to provide 4 Gigabytes per second transfer rate.
Cool‘n’QuietTM

1
Introduction
11
The graphics integrated in the GeForceTM 6100 GPU
(Graphics Processing Unit) supports Microsoft®
DirectX®9.0 Shader Model 3.0 and NVIDIA®
PureVideoTM technology that delivers realistic effects
and multimedia functionality for an incredible PC performance on
popular games and multimedia applications.
NVIDIA®PureVideoTM technology is a combination of
high-definition video processors and video decoding
software that delivers HD (High-Definition) video to
your PC.
CPU Overheat Protection has the capability of moni-
toring the CPU’s temperature during system boot up.
Once the CPU’s temperature exceeded the tempera-
ture limit pre-defined by the CPU, the system will automatically shut-
down.This preventive measure has been added to protect the CPU
from damage and insure a safe computing environment.
Double Data Rate SDRAM (DDR SDRAM) is a type of
SDRAM that doubles the data rate through reading and
writing at both the rising and falling edge of each clock.
This effectively doubles the speed of operation therefore
doubling the speed of data transfer.
The onboard Realtek ALC655 is an AC’97 compatible
audio codec that will support 6-channel audio only
when the audio utility is configured to support this func-
tion. The mic-in at the rear will be disabled. Use the
front audio’s mic-in jack.
CPU
Overheat
Protection

Introduction
1
12
S/PDIF is a standard audio file transfer format that trans-
fers digital audio signals to a device without having to be
converted first to an analog format. This prevents the
quality of the audio signal from degrading whenever it is
converted to analog. S/PDIF is usually found on digital audio equip-
ment such as a DAT machine or audio processing device. The S/
PDIF connector on the system board sends surround sound and 3D
audio signal outputs to amplifiers and speakers and to digital re-
cording devices like CD recorders.
Serial ATA is a storage interface that is compli-
ant with SATA 1.0 specification. nForceTM 410
MCP (Media and Communications Processor) supports Serial ATA
speed of up to 3Gb/s. Serial ATA improves hard drive performance
faster than the standard parallel ATA whose data transfer rate is
100MB/s.
nForceTM 410 MCP allows configuring RAID on the Serial
ATA drives. It supports RAID 0 and RAID 1.
The onboard Realtek RTL8201CL LAN Phy supports up
to 100Mbps.
The system board is equipped with an IrDA connector
for wireless connectivity between your computer and
peripheral devices.The IRDA (Infrared Data Association) specification
supports data transfers of 115K baud at a distance of 1 meter.
IrDA

1
Introduction
13
The system board supports USB 2.0 and USB 1.1
ports. USB 1.1 supports 12Mb/second bandwidth
while USB 2.0 supports 480Mb/second bandwidth
providing a marked improvement in device transfer
speeds between your computer and a wide range of simultaneously
accessible external Plug and Play peripherals.
This feature allows the system that is in the
Suspend mode or Soft Power Off mode to
wake-up/power-on to respond to calls coming from an external mo-
dem or respond to calls from a modem PCI card that uses the PCI
PME (Power Management Event) signal to remotely wake up the
PC.
Important:
If you are using a modem add-in card, the 5VSB power source
of your power supply must support a minimum of ≥ 720mA.
This feature allows the network to remotely
wake up a Soft Power Down (Soft-Off) PC.
It is supported via the onboard LAN port or via a PCI LAN card
that uses the PCI PME (Power Management Event) signal. However,
if your system is in the Suspend mode, you can power-on the system
only through an IRQ or DMA interrupt.
Important:
The 5VSB power source of your power supply must support
≥ 720mA.
This function allows you to use the PS/2 key-
board or PS/2 mouse to power-on the sys-
tem.
Important:
The 5VSB power source of your power supply must support
≥ 720mA.
Wake-On-Ring
Wake-On-LAN
Wake-On-PS/2

Introduction
1
14
This function allows you to use a USB key-
board or USB mouse to wake up a system
from the S3 (STR - Suspend To RAM) state.
Important:
If you are using the Wake-On-USB Keyboard/Mouse function for
2 USB ports, the 5VSB power source of your power supply
must support ≥ 1.5A. For 3 or more USB ports, the 5VSB
power source of your power supply must support ≥ 2A.
The RTC installed on the system board allows your
system to automatically power-on on the set date and
time.
The system board is designed to meet the ACPI (Ad-
vanced Configuration and Power Interface) specification.
ACPI has energy saving features that enables PCs to implement
Power Management and Plug-and-Play with operating systems that
support OS Direct Power Management. Currently, only Windows®®
®®
®
2000/XP supports the ACPI function. ACPI when enabled in the
Power Management Setup will allow you to use the Suspend to
RAM function.
With the Suspend to RAM function enabled, you can power-off the
system at once by pressing the power button or selecting “Standby”
when you shut down Windows®®
®®
®2000/XP without having to go
through the sometimes tiresome process of closing files, applications
and operating system. This is because the system is capable of stor-
ing all programs and data files during the entire operating session
into RAM (Random Access Memory) when it powers-off. The oper-
ating session will resume exactly where you left off the next time you
power-on the system.
Important:
The 5VSB power source of your power supply must support
≥ 1A.
Wake-On-USB
rtc
str

1
Introduction
15
power failure
recovery
When power returns after an AC power fail-
ure, you may choose to either power-on the
system manually, let the system power-on au-
tomatically or return to the state where you left off before power
failure occurs.

16
2Hardware Installation
System Board Layout
Chapter 2 - Hardware Installation

17
2
Hardware Installation
System Memory
Warning:
When the DRAM Power LED lit red, it indicates that power is
present on the DDR sockets. Power-off the PC then unplug the
power cord prior to installing any memory modules. Failure to do so
will cause severe damage to the motherboard and components.
Warning:
Electrostatic discharge (ESD) can damage your system board,
processor, disk drives, add-in boards, and other components. Perform
the upgrade instruction procedures described at an ESD workstation
only. If such a station is not available, you can provide some ESD
protection by wearing an antistatic wrist strap and attaching it to a
metal part of the system chassis. If a wrist strap is unavailable,
establish and maintain contact with the system chassis throughout
any procedures requiring ESD protection.
The system board supports DDR SDRAM DIMM. Double Data
Rate SDRAM (DDR SDRAM) is a type of SDRAM that doubles the
data rate through reading and writing at both the rising and falling
edge of each clock. This effectively doubles the speed of operation
therefore doubling the speed of data transfer. Refer to chapter 1
(System Memory section) for detailed specification of the memory
supported by the system board.
.
.
.
.
.
.
.
.
DDR 1
DDR 2
.
.
.
.
.
.
.
.
DRAM Power
LED

18
2Hardware Installation
BIOS Setting
Configure the system memory in the Genie BIOS Setting submenu
(“DRAM Timing and Config” section) of the BIOS.
Installing the DIM Module
A DIM module simply snaps into a DIMM socket on the system
board. Pin 1 of the DIM module must correspond with Pin 1 of the
socket.
1. Pull the “tabs” which are at the ends of the socket to the side.
2. Position the DIMM above the socket with the “notch” in the
module aligned with the “key” on the socket.
3. Seat the module vertically into the socket. Make sure it is
completely seated.The tabs will hold the DIMM in place.
Pin 1
Notch
Key
Tab Tab

19
2
Hardware Installation
CPU
Overview
The system board is equipped with a surface mount 754-pin CPU
socket.This socket is exclusively designed for installing an AMD CPU.
Installing the CPU
1. Make sure the PC and all other peripheral devices connected to
it has been powered down.
2. Disconnect all power cords and cables.
3. Locate the 754-pin CPU socket on the system board.
X

20
2Hardware Installation
5. Position the CPU above the socket. The gold mark on the CPU
must align with the corner of the CPU socket (refer to the en-
larged view) shown below.
Important:
Handle the CPU by its edges and avoid touching the pins.
4. Unlock the socket by pushing the lever sideways, away from the
socket, then lifting it up to a 90oangle. Make sure the lever is lifted
to at least this angle otherwise the CPU will not fit in properly.
Lever
Gold mark
