User Manual
DA16200 AT GUI Tool

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
2 of 20
© 2020 Dialog Semiconductor
Contents
Contents............................................................................................................................................... 2
Figures.................................................................................................................................................. 3
Terms and Definitions......................................................................................................................... 4
References ........................................................................................................................................... 4
1 Introduction.................................................................................................................................... 5
1.1 Certification mode................................................................................................................. 5
1.2 Network mode....................................................................................................................... 5
2 How to Connect............................................................................................................................. 5
2.1 USB to Serial Driver.............................................................................................................. 5
2.2 Setup Serial Terminal Utility.................................................................................................. 6
3 How to Run GUI for DA16200 Board ........................................................................................... 7
3.1 Board Setup .......................................................................................................................... 7
3.2 Board Connection ................................................................................................................. 8
3.3 RF Certification Mode Setup................................................................................................. 9
3.3.1 TX Test Mode........................................................................................................ 9
3.3.2 RX Test Mode...................................................................................................... 12
3.4 Network Mode Setup........................................................................................................... 12
3.4.1 Station Mode........................................................................................................13
3.4.2 AP Mode.............................................................................................................. 14
3.5 OTP Mode Setup ................................................................................................................16
4 Regulatory Approval................................................................................................................... 17
4.1 Federal Communication Commission Interference Statement ...........................................17
4.1.1 FCC Caution:....................................................................................................... 17
4.1.2 FCC Radiation Exposure Statement: ..................................................................17
4.1.3 End Product Labeling ..........................................................................................17
4.1.4 Manual Information to the End User....................................................................18
4.2 Canada Statement..............................................................................................................18
4.2.1 Caution Exposure: ............................................................................................... 18
4.2.2 The final end product must be labelled in a visible area with the following:........ 18
Revision History ................................................................................................................................ 19

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
3 of 20
© 2020 Dialog Semiconductor
Figures
Figure 1: Terminal Configuration........................................................................................................... 6
Figure 2: Development Kit connections................................................................................................. 7
Figure 3: AT GUI ................................................................................................................................... 8
Figure 4: RS232 Setup - Disconnected................................................................................................. 8
Figure 5: RS232 Setup - Connected ..................................................................................................... 8
Figure 6: Debug Console - Connected.................................................................................................. 8
Figure 7: Certification Mode Configuration............................................................................................ 9
Figure 8: Certification Mote Tab............................................................................................................ 9
Figure 9: Tx Test Mode Configuration................................................................................................... 9
Figure 10: Debug Console - Tx mode................................................................................................. 10
Figure 11: Start & Stop Tx................................................................................................................... 11
Figure 12: Debug Console - Start Tx................................................................................................... 11
Figure 13: Debug Console - Stop Tx................................................................................................... 11
Figure 14: Rx Configuration................................................................................................................. 12
Figure 15: Network Mode Configuration.............................................................................................. 12
Figure 16: Network Mode Tab............................................................................................................. 13
Figure 17: Debug Console - Station Mode.......................................................................................... 13
Figure 18: Station Mode - SCAN......................................................................................................... 13
Figure 19: Station Mode - Choose AP and Connect........................................................................... 14
Figure 20: Debug Console - Connect to AP....................................................................................... 14
Figure 21: Debug Console - AP Mode ............................................................................................... 14
Figure 22: AP Configuration................................................................................................................ 14
Figure 23: Debug Console - AP Configuration................................................................................... 15
Figure 24: DHCP Configuration.......................................................................................................... 15
Figure 25: Debug Console - DHCP Configuration ............................................................................. 15
Figure 26: OTP Mode......................................................................................................................... 16

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
4 of 20
© 2020 Dialog Semiconductor
Terms and Definitions
GUI Graphical User Interface
UART Universal Asynchronous Receiver Transmitter
SSID Service Set IDentifier.
DHCP Dynamic Host Configuration Protocol
AP Access Point
USB Universal Serial Bus
MFC Microsoft Foundation Class
References
[1] DA16200, Datasheet, Dialog Semiconductor
[2] DA16200, SDK_Programmer_guide, User Manual, Dialog Semiconductor
[3] DA16200, EVK_User_Guide, Dialog Semiconductor
[4] DA16200, AT Command User Guide, Dialog Semiconductor

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
5 of 20
© 2020 Dialog Semiconductor
1 Introduction
This section introduces the subject or problem described in this document. The DA16200 GUI tool
(DA16200_GUI_yyyymmdd.exe) lets users control DA16200 EVK in GUI environment. It provides
two modes of operation: Certification mode and Network mode
1.1 Certification mode
This mode is for Wi-Fi RF test (Tx power, Rx sensitivity, etc.) aka “TEST Mode”.
1.2 Network mode
With this mode, you can test Station or AP mode of DA16200
●AP mode
SoftAP test with configurable parameters like SSID, security, DHCP Server, etc.
●Station mode
STA test; search and connect to an Access Point & check / test STA function.
2 How to Connect
2.1 USB to Serial Driver
The DA16200 evaluation board supports both serial port (UART) and USB port (default USB). The
user just needs to connect with a micro USB cable and then two COM ports will be detected
automatically.
●If USB port is used, install the FT232 Driver for windows
●In most cases, it will be installed automatically
The FTDI driver for the FT2232 FTDI chip used on the Pro-DK motherboard can be found at
following download link: http://www.ftdichip.com/Drivers/CDM/CDM21224_Setup.zip
After connecting the PC and the EVB board, two ports will be detected.
●Please see your EVK User Guide to find the UART1 port. GUI tool is using UART1 port.
The other port (UART0) is for debug console connection. This port is used for firmware update.
●If you want to update with a new DA16200 firmware, please refer to “DA16200 EVK User Guide”.
RF certification program was developed by MFC. Therefore, this program may need to install the
MFC library package.
●You can download the Visual Studio Redistributable file in Microsoft soft home page
https://www.microsoft.com/en-us/download/details.aspx?id=48145
●Select windows OS type (32bit or 64bit) and download & install.

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
6 of 20
© 2020 Dialog Semiconductor
2.2 Setup Serial Terminal Utility
Users can control DA16200 by using a serial terminal tool (e.g. Teraterm or SecureCRT) and the
following configurations are required to connect to the console of DA16200.
●Port: Com port number on Windows system
●Baud rate: 115,200 bps
●Data bits: 8 bits
●Parity: None
●Stop bits: 1 bit
●Flow control: None
Figure 1: Terminal Configuration
When the DA16200 board is connected, two COM ports will be detected on the Window machine.
One (UART0) is for console command and the other (UART1) is for AT command. Normally, the
large number COM port is for the AT commands and higher number COM port is for the console.

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
7 of 20
© 2020 Dialog Semiconductor
3 How to Run GUI for DA16200 Board
3.1 Board Setup
DA16200 AT GUI program is a single executable file.
Note: If an error message which tells “a DLL file (e.g. vcruntime140.dll or mfc1400u.dll) is missing”
prompts when running this tool, You need to install Microsoft Visual Studio redistributable package
(https://www.microsoft.com/en-us/download/details.aspx?id=48145) or copy the dll file into the
Windows system folder (C:\Windows\System32 or C:\Windows\SysWOW64).
Here is the program setup sequence.
●DA16200 Development Kit is connected to the host PC over the connector, as shown in Figure 2
Figure 2: Development Kit connections
Note) please refer to EVK User Guide to check the port.
●Execute AT GUI program

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
8 of 20
© 2020 Dialog Semiconductor
Figure 3: AT GUI
3.2 Board Connection
●When AT GUI program runs, connection status is red (not connected). If any COM port is not
detected by the program, press the Rbutton to refresh COM Port
Figure 4: RS232 Setup - Disconnected
●Select a COM port and click the RS232 OPEN button. (Wait for a few seconds). Connection
status will be soon changed to green color and you can see “Connected” status with green color .
It means communication is OK
Figure 5: RS232 Setup - Connected
●“Echo on” message will be shown on the debug window (in the black box).
Figure 6: Debug Console - Connected

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
9 of 20
© 2020 Dialog Semiconductor
3.3 RF Certification Mode Setup
To enable certification mode, check on the mode option on the Chip Setting tab
Figure 7: Certification Mode Configuration
Alternatively, on the Certification Mode tab.
Figure 8: Certification Mote Tab
3.3.1 TX Test Mode
●Move to the Certification Mode tab
Figure 9: Tx Test Mode Configuration

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
10 of 20
© 2020 Dialog Semiconductor
●Check TX Setting parameters and click the Mode Select button. Confirm message will be shown
as Figure 10.This is a normal state
Figure 10: Debug Console - Tx mode
●Have to select Data Rate, Channel, and Power as you want to test.
○Packet mode: Normal test mode with packet generation mode. We can adjust duty of RF
Burst at time domain in this mode.
○Cont mode: Continuous TX out mode.
○This mode is for TX power test and etc.
○In this mode, TX packet is generated continuously over 95% duty cycle.
○CW mode: Only single sinewave tone out mode. This mode is for freq err check.
○Data Rate: Choose modulation type to test.
○Power: Select or tune the power level. (“0” step is Maximum)
○The difference between power steps is about 0.8~1dB/1step
○Size: You can adjust duty rate with this number. However, it is not linear as the number, so it
needs to check with equipment like spectrum analyzer to set exactly. (Equipment setting is to
zero span setting or burst mode setting)
●TX packet generation
○Use the Start TX button and the Stop TX button.
○When you want to change for another condition, you should click “Stop TX” before starting
new test.

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
11 of 20
© 2020 Dialog Semiconductor
Start TX
Stop TX
Figure 11: Start & Stop Tx
●Tested setting is 802.11n MCS7, channel 1, 100 bytes packet and power grade 0.
○When you click the Start TX button, you can see messages as blow.
Figure 12: Debug Console - Start Tx
○When you click the Stop TX button, you can see messages as blow.
Figure 13: Debug Console - Stop Tx

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
12 of 20
© 2020 Dialog Semiconductor
3.3.2 RX Test Mode
●RX Setting
○Channel: Support CH1 ~ CH13
○Test Time: Maximum 3600s (Duration is 1 second fixed)
Figure 14: Rx Configuration
●RX Packet Rate
○FCS + PHY + Overflow packet / Total packet = Error rate
3.4 Network Mode Setup
To enable network mode, check on the mode option on the Chip Setting tab.
Figure 15: Network Mode Configuration

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
13 of 20
© 2020 Dialog Semiconductor
Alternatively, on the Certification Mode tab.
Figure 16: Network Mode Tab
3.4.1 Station Mode
●Choose the Station Mode and click the Select button on the Mode Select option show in Figure
16
●Network mode is changed, DA16200 reboots and the station mode setup window will be shown
as Figure 18
Figure 17: Debug Console - Station Mode
●Scan APs by pressing the Scan button
Figure 18: Station Mode - SCAN
●After scanning finishes, choose one AP in the list and click the Connect button. You may need to
enter password or key index according to security mode of the AP.

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
14 of 20
© 2020 Dialog Semiconductor
Figure 19: Station Mode - Choose AP and Connect
Figure 20: Debug Console - Connect to AP
3.4.2 AP Mode
●Choose the AP Mode and click the Select button on the Mode Select option then network mode
is changed, DA16200 reboots and the AP Mode setup window will be shown as Figure 22.
Figure 21: Debug Console - AP Mode
●Set SSID, password, country, channel and security mode and click the Confirm button.
Figure 22: AP Configuration

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
15 of 20
© 2020 Dialog Semiconductor
Figure 23: Debug Console - AP Configuration
●Configure DHCP server. Set IP addresses and click the Confirm button. When a client is
connected, its MAC address will be shown as Figure 24
Figure 24: DHCP Configuration
Figure 25: Debug Console - DHCP Configuration

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
16 of 20
© 2020 Dialog Semiconductor
3.5 OTP Mode Setup
To enable OTP mode, check on OTP Enable option on the OTP Mode tab then the current OTP data
will be shown in Figure 26.
Figure 26: OTP Mode
●Power calibration and temperature calibration has been completed for the chipset by FCI and
it may not need to be done by the customer.
●Freq Offset cal
The range of frequency offset calibration is 0x0 ~ 0x7F.
●MAC Address setup
DA16200 provides 4 slots to store MAC addresses and the 1st slot is written by FCI. The customer
can use 3 slots to write their own MAC address. The MAC address written in the OTP must be an
even number, it is used for WLAN0 MAC address (for STA interface), and the next number is
automatically used for WLAN1 MAC address (for Soft-AP interface).
To write the MAC address, give a MAC address in the first empty slot and click the Write button then
the new address substitutes for the previous address.

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
17 of 20
© 2020 Dialog Semiconductor
4 Regulatory Approval
4.1 Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
4.1.1 FCC Caution:
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
4.1.2 FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This transmitter module must not be co-located or operating in conjunction with any
other antenna or transmitter.
The module must be installed in WiFi Module.
This End equipment should be installed and operated with a minimum distance of 20cm between the
radiator and your body.
IMPORTANT NOTE:
In the event that these conditions can not be met (for example certain laptop configurations or co-
location with another transmitter), then the FCC authorization is no longer considered valid and the
FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a separate
FCC authorization.
4.1.3 End Product Labeling
The final end product must be labelled in a visible area with the following:
“Contains FCC ID: 2AU49-DA16200MC”, or “Contains FCC ID: 2AU49-DA16200ME”

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
18 of 20
© 2020 Dialog Semiconductor
4.1.4 Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to
install or remove this RF module in the user’s manual of the end product which integrates this
module.
4.2 Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
4.2.1 Caution Exposure:
This device meets the exemption from the routine evaluation limits in section 2.5 of RSS102 and
users can obtain Canadian information on RF exposure and compliance.
Le dispositif répond à l'exemption des limites d'évaluation de routine dans la section 2.5 de RSS102
et les utilisateurs peuvent obtenir des renseignements canadiens sur l'exposition aux RF et le
respect.
4.2.2 The final end product must be labelled in a visible area with the
following:
The Industry Canada certification label of a module shall be clearly visible at all times when installed
in the host device, otherwise the host device must be labelled to display the Industry Canada
certification number of the module, preceded by the words “Contains transmitter module”, or the word
“Contains”, or similar wording expressing the same meaning, as follows:
Contains transmitter module IC: 25650-DA16200MC, or 25650-DA16200ME.
The module must be installed in WiFi Module.
This End equipment should be installed and operated with a minimum distance of 20cm between the
radiator and your body.
Cet équipement devrait être installé et actionné avec une distance minimum de 20cm entre le
radiateur et votre corps.
The end user manual shall include all required regulatory information/warning as show in this
manual.

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
19 of 20
© 2020 Dialog Semiconductor
Revision History
Revision
Date
Description
1.0
03-Jul-2019
Preliminary DRAFT Release

DA16200 AT GUI Tool
User Manual
Revision 1.0 DRAFT
03-Jul-2019
CFR0012
20 of 20
© 2020 Dialog Semiconductor
Status Definitions
Status
Definition
DRAFT
The content of this document is under review and subject to formal approval, which may result in modifications or
additions.
APPROVED
or unmarked
The content of this document has been approved for publication.
Disclaimer
Unless otherwise agreed in writing, the Dialog Semiconductor products (and any associated software) referred to in this document are not
designed, authorized or warranted to be suitable for use in life support, life-critical or safety-critical systems or equipment, nor in applications
where failure or malfunction of a Dialog Semiconductor product (or associated software) can reasonably be expected to result in personal injury,
death or severe property or environmental damage. Dialog Semiconductor and its suppliers accept no liability for inclusion and/or use of Dialog
Semiconductor products (and any associated software) in such equipment or applications and therefore such inclusion and/or use is at the
customer’s own risk.
Information in this document is believed to be accurate and reliable. However, Dialog Semiconductor does not give any representations or
warranties, express or implied, as to the accuracy or completeness of such information. Dialog Semiconductor furthermore takes no
responsibility whatsoever for the content in this document if provided by any information source outside of Dialog Semiconductor.
Dialog Semiconductor reserves the right to change without notice the information published in this document, including, without limitation, the
specification and the design of the related semiconductor products, software and applications. Notwithstanding the foregoing, for any automotive
grade version of the device, Dialog Semiconductor reserves the right to change the information published in this document, including, without
limitation, the specification and the design of the related semiconductor products, software and applications, in accordance with its standard
automotive change notification process.
Applications, software, and semiconductor products described in this document are for illustrative purposes only. Dialog Semiconductor makes
no representation or warranty that such applications, software and semiconductor products will be suitable for the specified use without further
testing or modification. Unless otherwise agreed in writing, such testing or modification is the sole responsibility of the customer and Dialog
Semiconductor excludes all liability in this respect.
Nothing in this document may be construed as a license for customer to use the Dialog Semiconductor products, software and applications
referred to in this document. Such license must be separately sought by customer with Dialog Semiconductor.
All use of Dialog Semiconductor products, software and applications referred to in this document is subject to Dialog Semiconductor’s Standard
Terms and Conditions of Sale, available on the company website (www.dialog-semiconductor.com) unless otherwise stated.
Dialog, Dialog Semiconductor and the Dialog logo are trademarks of Dialog Semiconductor Plc or its subsidiaries. All other product or service
names and marks are the property of their respective owners.
© 2020 Dialog Semiconductor. All rights reserved
Contacting Dialog Semiconductor
United Kingdom (Headquarters)
Dialog Semiconductor (UK) LTD
Phone: [phone]
Germany
Dialog Semiconductor GmbH
Phone: [phone]
The Netherlands
Dialog Semiconductor B.V.
Phone: [phone]
North America
Dialog Semiconductor Inc.
Phone: [phone]
Japan
Dialog Semiconductor K. K.
Phone: [phone]
Taiwan
Dialog Semiconductor Taiwan
Phone: [phone]
Hong Kong
Dialog Semiconductor Hong Kong
Phone: [phone]
Korea
Dialog Semiconductor Korea
Phone: [phone]
China (Shenzhen)
Dialog Semiconductor China
Phone: [phone]
China (Shanghai)
Dialog Semiconductor China
Phone: [phone]
Email:
[email protected]
Web site:
www.dialog-semiconductor.com
