Diamond Multimedia All in Wonder HD3650PM User manual

SPECIFICATION SHEET
SKU : AIWHD3650PM
August 10, 2011 - 2:16 pm
ENG APVD - LK 2008-06-18
MRKTG APVD - LL 2008-07-10
SKU AIWHD3650PM
PRODUCT DIAMOND All in Wonder Premium Graphics w/ I/O Connector Board, Green Button remote and HDTV Tuner
PRODUCT SHORT DESCRIPTION INTERFACE PCI Express x16
GPU HD 3650
CORE CLOCK 725 MHZ
MEMORY CLOCK 600 MHz
MEMORY CONFIGURATION 16Mx32
MEMORY TYPE GDDR2
MEMORY BANDWIDTH 80.6 GB/sec
MEMORY SIZE 512MB
MEMORY CONTROLLER INTERFACE 128-Bit
PORTS Dual Link DVI , HDMI , F-Type Coax Input
DUAL LINK DVI Hydravision 4
PRODUCT DETAILED DESCRIPTION With the DIAMOND All-in-WonderTM HD, your PC and your TV "play nice". It is now easy to create the ultimate digital
entertainment center. With the DIAMOND All-in-Wonder Premium HD graphics and video card, your PC is transformed
into the ultimate high-definition PVR and 1080p Blu-ray and DVD movie showcase. Enter the realm of high-def gaming
and experience life-like graphics or use your PC to create your own custom video and entertainment library. It is highly
immersive, extremely versatile, and undeniably entertaining. It is your PC, and It is waiting to do more. With the DIAMOND
All-in-Wonder Premium HD, you can watch or record live TV. Choose between analog TV, free-to-air HDTV and
ClearQAM unencrypted digital cable. The All-In-Wonder Premium inlcudes the Microsoft certified Green Button remote
control for one button launch of Windows Media Player. It also includes the I/O connector board for easy connections to
devices such as DVDs and VCRs.
ATI Avivo HD Video & Media
The Diamond All-in-Wonder HD GPU allows you to experience the power of HD with graphics processing designed for
how you work and play. The Diamond All-in-Wonder HD delivers outstanding performance at a great price. Advance to the
next generation of HD game performance and life-like realism thanks to DirectX® 10.1 capabilities . Watch the latest
Blu-Ray videos in full 1080p HD and upscale beyond - without placing huge demands on your CPU. Enjoy break-through
efficiency with more processing performance per watt and energy-saving features to help save you money.
PC TV Parental Control Notice
PRODUCT FEATURES ●GPU: RV635
●Bus Type: PCI-Express
●Core Clock: 725Mhz
●Memory Size: 512MB
●Memory Configuration: 8Mx32 GDDR2
●Memory Interface: 128-Bit
●Memory Speed: 800 Mhz
●Dual Link DVI + HDMI + F Type Coax Input
●HD AIW Adapter: HDTV Component - Composite Video I/O - S Video I/O - Stereo Audio Input
SYSTEM REQUIREMENT EXTERNAL POWER REQUIREMENT NONE
CPU Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or
higher
CPU SPEED 2.0 Ghz or faster
MEMORY 1024MB
HARD DISK 480MB available hard disk space
SYSTEM BUS PCI Express
SLOT SINGLE
CHASSIS
MONITOR Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor
INTERNET ACCESS
USB NO
CD DVD YES
POWER SUPPLY 400 Watt or greater power supply recommended– Certified
power supplies are recommended. Refer to
http://ati.amd.com/certifiedPSU for a list of Certified products
OPERATING SYSTEM WINXP WINVISTA32 WINVISTA64
FORM FACTOR Standard Profile Full-Height
DIMENSIONS [PRODUCT] : 11.75 X 9.5 X 3 [RETAIL BOX] : 11.75 X 9.5 X 3 [S BUILDER] : 11.75 X 7.25 X 2
WEIGHT [PRODUCT WEIGHT] : 3.0 LBS [PRODUCT WITH CONTENT WEIGHT] : 3.80 LBS
UPC RETAIL PACKAGE UPC : 757448006476
PACKAGE CONTENT
●DIAMOND ALL-IN-WONDER - PREMIUM GRAPHICS
VIDEO CARD WITH HDTV TUNER
●QUICK START GUIDE
●INSTALL CD
●DVI-TO-VGA ADAPTER
●1 AIW AV I/O CONNECTOR BOARD
●RCA TO 3.5MM STEREO PLUG AUDIO
CONNECTOR
●S-VIDEO-TO-RCA ADAPTER
●S-VIDEO-TO-RCA ADAPTER
●REMOTE CONTROL WITH RECIEVER
PRODUCT WEBPAGE http://www.diamondmm.com/AIWHD3650PM.php

PRODUCT NOTES California Health & Safety Notice : The solder used in this product contains lead, a chemical known to the State of California to cause birth
defects and other reproductive harm. Please wash hands after handling internal components and circuit boards and avoid inhalation of fumes if
heating the solder.
The information presented in this document is for information purposes only. The information contained herein is subject to change and may be rendered inaccurate for many reasons, including, but not limited to product and specification
changes, new model and/or product releases, product differences between differing manufacturers, software changes, BIOS flashes, firmware upgrades, or the like. Diamond Multimedia assumes no obligation to update or otherwise correct or
revise this information. Diamond Multimedia makes no representations or warranties with respect to the contents hereof and assumes no responsibility for any inaccuracies, errors or omissions that may appear in this information. However,
Diamond Multimedia reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Diamond Multimedia to notify any person of such revisions or changes. Please see your Diamond
Multimedia sales representative for any questions regarding this product information.
Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.
AMD,ATI, Graphics by ATI, Graphics by AMD, and Radeon are trademarks of Advanced Micro Devices, Inc.
All other trademarks are property of their respective owners.
© 2009 Diamond Multimedia. All rights reserved.
