Diamond Products HS-20-F-15 User manual

`
Flush Cut Hydraulic Hand Saw
HS-20-F-15 20.00”- 1.61in³ (15GPM)
Parts Manual
October 2014
Part Number 1803021
www.DiamondProducts.com

Table Of Contents
Saw Dimensions…………………………………………………………………………………………1
Blade Flange……………………………………………………………………………………………..2
General Safety…………………………………………………………………………………………...3
Hand Saw Operation……………………………………………………………………………………4
Saw Parts List…………………………………………………………………………………………5-6
Bearing Block Assembly………………………………………………………………………………7
Metro Valve Assembly…………………………………………………………………………………8
Trigger Assembly……………………………………………………………………………………….9
Hydraulic Motor………………………………………………………………………………………..10
Saw Maintenance & Record………………………………………………………………………….12
Warranty Info…………………………………………………………………………………………...13

7.750
21.875
NOTE: STANDARD 20.00" DIAMETER BLADE
8.875
HS-20-F-15 - 20.00" 1.61in³ (15GPM Rated)
Flush Cut Hydraulic Hand Saw
* NO BLADE INCLUDED
HYDRAULIC RECOMMENDATION
BLADE RPM
HYDRAULIC CONNECTIONS
MAXIMUM CUTTING DEPTH
SAW WEIGHT
BLADE FLANGE
2500psi - 15 gpm
2150 rpm @ 15 gpm
Parker No Spill 1/2"
7.75"
39lbs, No Blade, No Cover
Flush Cut, 6 on 3.50" 5/16-18 x 82° CS

4.125
1.000 Arbor
60.000° TYP.
3.500
5/8-16 x 82° x 6
.125
2502545 - Blade Flange
Flush Cut Hydraulic Hand Saws
