Diamond Systems ALT1600-2G-XT User manual

ALTAIR Single Board Computer
COM Express Form Factor Intel Atom E-Series SBC with EMX Stackable I/O Expansion
Revision
Date
Comments
A.00
12/6/2012
Initial Release
A.01
9/3/2015
Minor updates
A.02
5/01/2017
Minor updates
Copyright 2015
FOR TECHNICAL SUPPORT Diamond Systems Corporation
PLEASE CONTACT: 555 Ellis Street
Mountain View, CA 94043 USA
[e-mail] Tel [phone]
Fax [phone]
www.diamondsystems.com

Altair User Manual Rev A.02 www.diamondsystems.com Page 2
CONTENTS
Important Safe-Handling Information.....................................................................................................................4
1. Introduction.......................................................................................................................................................5
1.1 Altair SBC Features.......................................................................................................................................6
1.2 Thermal Considerations ................................................................................................................................7
2. Functional Overview.........................................................................................................................................8
2.1 Block Diagram ...............................................................................................................................................8
2.2 Altair Dimensions...........................................................................................................................................9
2.3 Connector Locations................................................................................................................................... 10
2.3.1 Connector Summary.......................................................................................................................... 11
2.4 Configuration Jumpers ............................................................................................................................... 12
2.4.1 Configuration Jumper Summary........................................................................................................ 13
3. Getting Started............................................................................................................................................... 14
3.1 Introducing the Altair Development Kit....................................................................................................... 14
3.1.1 Altair Cable Kit ................................................................................................................................... 15
3.2 System Setup ............................................................................................................................................. 17
3.2.1 Keyboard and Mouse......................................................................................................................... 17
3.2.2 USB Flashdisk Socket ....................................................................................................................... 17
3.2.3 Mass Storage Devices....................................................................................................................... 17
3.2.4 Connecting Power.............................................................................................................................. 17
3.2.5 Display ............................................................................................................................................... 17
3.2.6 Installing Altair in an Enclosure (optional).......................................................................................... 17
3.3 Booting the System .................................................................................................................................... 18
3.3.1 BIOS Setup........................................................................................................................................ 18
3.3.2 Operating System Drivers.................................................................................................................. 18
4. Interface Connector Details.......................................................................................................................... 19
4.1 External Battery (J2)................................................................................................................................... 19
4.2 CAN (J3)..................................................................................................................................................... 19
4.3 SATA (J4)................................................................................................................................................... 20
4.4 Ethernet (J5)............................................................................................................................................... 20
4.5 Serial Ports (J7, J8).................................................................................................................................... 21
4.6 USB Flashdisk (J9)..................................................................................................................................... 21
4.7 USB 0-1 (J10)............................................................................................................................................. 22
4.8 USB 2-3 (J11)............................................................................................................................................. 22
4.9 Utility Signals (J12)..................................................................................................................................... 23
4.10 LCD Backlight (J14).................................................................................................................................... 23
4.11 LCD Panel (LVDS Interface) (J15)............................................................................................................. 24
4.12 EMX Expansion Bus (J20).......................................................................................................................... 25
4.13 Power Input (J24) ....................................................................................................................................... 25
4.14 GPIO (J26).................................................................................................................................................. 26
4.15 PIC Programming (J27).............................................................................................................................. 26
4.16 PCIe MiniCard (J28)................................................................................................................................... 26
4.17 Audio (J29) ................................................................................................................................................. 27
4.18 VGA (J30)................................................................................................................................................... 27
5. Configuration Jumper Details ...................................................................................................................... 28
5.1 Serial Port 1 RS-422/485 Termination (JP1).............................................................................................. 28
5.2 LCD Panel Power Select –LVDS VSEL (JP2)........................................................................................... 28
5.3 LCD Backlight Power Select –INV VSEL (JP4)......................................................................................... 29
5.4 LCD Scan Direction & LVDS Map Select (JP5) ......................................................................................... 29
6. BIOS ................................................................................................................................................................ 30
6.1 Entering the BIOS....................................................................................................................................... 30
6.2 Restoring Default BIOS Settings................................................................................................................ 30
6.3 Setting the Date and Time.......................................................................................................................... 30
6.4 Boot Priority................................................................................................................................................ 30
6.5 Chipset........................................................................................................................................................ 30
6.1 Console Redirection ................................................................................................................................... 30
6.2 Viewing and Modifying the BIOS Settings.................................................................................................. 30
6.3 BIOS Screen Descriptions.......................................................................................................................... 31
7. PIC Microcontroller........................................................................................................................................ 34
7.1 Are you there.............................................................................................................................................. 35
7.2 Configure DIO Port Command ................................................................................................................... 35

Altair User Manual Rev A.02 www.diamondsystems.com Page 3
7.3 DIO Read.................................................................................................................................................... 36
7.4 DIO Output.................................................................................................................................................. 36
7.5 EEPROM Read........................................................................................................................................... 37
7.6 EEPROM WRITE........................................................................................................................................ 37
7.7MTBF POWER CYCLE .............................................................................................................................. 38
7.8 Watchdog Timeout Set............................................................................................................................... 39
7.9 Watchdog Trigger....................................................................................................................................... 40
7.10 Watchdog Read.......................................................................................................................................... 40
7.11 MTBF Power Data:..................................................................................................................................... 41
7.12 RTC Read................................................................................................................................................... 42
7.13 RTC Write................................................................................................................................................... 43
7.14 Set COM Mode........................................................................................................................................... 44
7.15 Get COM Mode........................................................................................................................................... 44
7.16 READ ANALOG DATA............................................................................................................................... 45
7.17 BOARD VOLTAGES .................................................................................................................................. 46
7.18 PWM CONTROL ........................................................................................................................................ 47
7.19 READ DIO CONFIG ................................................................................................................................... 48
7.20 CALENDAR WAKEUP ............................................................................................................................... 48
8. FlashDisk Modules ........................................................................................................................................ 49
8.1 Overview..................................................................................................................................................... 49
8.2 Models and Capacities ............................................................................................................................... 49
8.3 Features...................................................................................................................................................... 49
8.4 Flashdisk Installation .................................................................................................................................. 50
8.5 Power Routing............................................................................................................................................ 50
9. Thermal Pad ................................................................................................................................................... 51
10. Specifications................................................................................................................................................. 52
1.1 Operating System Support ......................................................................................................................... 52
1.2 Mechanical, Electrical, Environmental........................................................................................................ 52
All trademarks are the property of their respective owners.

Altair User Manual Rev A.02 www.diamondsystems.com Page 4
IMPORTANT SAFE-HANDLING INFORMATION
WARNING: ESD-Sensitive Electronic Equipment!
Observe ESD-safe handling procedures when working with this product.
Always use this product in a properly grounded work area and wear
appropriate ESD-preventive clothing and/or accessories.
Always store this product in ESD-protective packaging when not in use.
Safe Handling Precautions
Altair contains numerous I/O connectors that connect to sensitive electronic components. This creates many
opportunities for accidental damage during handling, installation and connection to other equipment. The list here
describes common causes of failure found on boards returned to Diamond Systems for repair. This information is
provided as a source of advice to help you prevent damaging your Diamond (or any vendor’s) embedded
computer boards.
ESD damage –This type of damage is almost impossible to detect, because there is no visual sign of failure or
damage. The symptom is that the board simply stops working, because some component becomes defective.
Usually the failure can be identified and the chip can be replaced.
To prevent ESD damage, always follow proper ESD-prevention practices when handling computer boards.
Damage during handling or storage –On some boards we have noticed physical damage from mishandling. A
common observation is that a screwdriver slipped while installing the board, causing a gouge in the PCB surface
and cutting signal traces or damaging components.
Another common observation is damaged board corners, indicating the board was dropped. This may or may not
cause damage to the circuitry, depending on what is near the corner. Most of our boards are designed with at
least 25 mils clearance between the board edge and any component pad, and ground / power planes are at least
20 mils from the edge to avoid possible shorting from this type of damage. However these design rules are not
sufficient to prevent damage in all situations.
A third cause of failure is when a metal screwdriver tip slips, or a screw drops onto the board while it is powered
on, causing a short between a power pin and a signal pin on a component. This can cause overvoltage / power
supply problems described below. To avoid this type of failure, only perform assembly operations when the
system is powered off.
Sometimes boards are stored in racks with slots that grip the edge of the board. This is a common practice for
board manufacturers. However our boards are generally very dense, and if the board has components very close
to the board edge, they can be damaged or even knocked off the board when the board tilts back in the rack.
Diamond recommends that all our boards be stored only in individual ESD-safe packaging. If multiple boards are
stored together, they should be contained in bins with dividers between boards. Do not pile boards on top of each
other or cram too many boards into a small location. This can cause damage to connector pins or fragile
components.
Power supply wired backwards –Our power supplies and boards are not designed to withstand a reverse
power supply connection. This will destroy each IC that is connected to the power supply. In this case the board
will most likely will be unrepairable and must be replaced. A chip destroyed by reverse power or by excessive
power will often have a visible hole on the top or show some deformation on the top surface due to vaporization
inside the package. Check twice before applying power!
Bent connector pins –This type of problem is often only a cosmetic issue and is easily fixed by bending the pins
back to their proper shape one at a time with needle-nose pliers. This situation can occur when pulling a ribbon
cable off of a pin header. Note: If the pins are bent too severely, bending them back can cause them to weaken
unacceptably or even break, and the connector must be replaced.

Altair User Manual Rev A.02 www.diamondsystems.com Page 5
1. INTRODUCTION
Altair is a high performance, highly integrated small form factor single board computer in the COM Express form
factor. Altair incorporates a wealth of standard PC-style I/O plus on-board digital I/O and accepts EMX add-on I/O
modules. An integrated, bottom-mounted heatspreader dissipates heat efficiently to the system enclosure. This
configuration leaves the SBC’s top side free for easy access to memory, on-board I/O, and expansion sockets.
Key feature highlights include:
Compact, low-power, high-performance, stackable SBC
Intel Atom E-Series CPU at 1.6GHz
(1.3GHz and 600MHz special order options)
1GB or 2GB soldered DDR2 DRAM
Comprehensive set of I/O interfaces:
- 4 USB 2.0 ports
- 1 RS-232/422/485 and 3 RS-232 serial ports
- 1 Gigabit Ethernet port
- 1 SATA port
- LVDS and VGA display interfaces
- ALC262 Codec based High Definition Audio with Stereo Line-Out, Stereo Line-In and Microphone
- USB keyboard and mouse support
- 10 programmable general purpose I/O lines
- Watchdog timer
Optional on-board USB flashdisk up to 8GB
COM Express form factor (125mm x 95mm)
System expansion flexibility
- EMX stackable I/O
- PCIe MiniCard
-40°C to +85°C operating temperature
Altair’s features are summarized on the next page.
Figure 1: Edge View of the Altair SBC

Altair User Manual Rev A.02 www.diamondsystems.com Page 6
Altair Models
Processor Type
Processor Clock
SO-DIMM RAM
ALT1600-2G-XT
Intel Atom E680T CPU
1.6GHz
2GB DDR2 DRAM
ALT1600-1G-XT
Intel Atom E680T CPU
1.6GHz
1GB DDR2 DRAM
ALT1300-2G-XT *
Intel Atom E660T CPU
1GHz
2GB DDR2 DRAM
ALT1300-1G-XT *
Intel Atom E660T CPU
1GHz
1GB DDR2 DRAM
ALT600-2G-XT *
Intel Atom E620T CPU
600MHz
2GB DDR2 DRAM
ALT600-1G-XT *
Intel Atom E620T CPU
600MHz
1GB DDR2 DRAM
* Special Order Option
1.1 Altair SBC Features
Altair is a compact, rugged, single board computer that features the “Tunnel Creek” Atom E-series processors in
the COM Express form factor. It provides multiple I/O expansion options by means of the EMX expansion
connector.
Functions
Intel Atom “Tunnel Creek” processors (Queensbay platform), clocked at 1.6GHz standard, 1.3GHz and
600MHz special order options
Cooling: Fanless design incorporates heatspreader and conduction cooling to the enclosure
Memory: 1GB or 2GB DDR2 memory soldered on board
Display options:
- LVDS flat panel interface
- One on-board SDVO-to-VGA converter to a VGA connector. SDVO-to-DVI converter option also
provided.
- LVDS backlight power: +5V or +12V jumper selectable
4 USB 2.0 ports on headers (Additionally an USB Hub is implemented to facilitate three ports for the EMX
expansion connector and one port for the PCIe MiniCard socket)
4 serial ports; Port 1 supports TX, RX, RTS and CTS with RS-232/422/485 capability and Ports 2, 3, 4
support TX/RX RS-232 only
Networking: One Intel 82574IT based Gigabit Ethernet port on pin header, with on-board magnetics
Mass storage:
- One SATA port
- USB flashdisk mounting location supporting up to 8GB
Keyboard/Mouse: support for USB
ALC262 Codec based High Definition Audio with Stereo Line-Out, Stereo Line-In and Microphone.
10 GPIOs from the PIC Microcontroller
1 CAN port
Programmable watchdog timer
Expansion buses: EMX stackable I/O; PCIe MiniCard
Input power: 5VDC ±5%
Power consumption: 15W fully loaded

Altair User Manual Rev A.02 www.diamondsystems.com Page 7
Operating temperature: -40°C to +85°C (-40°F to +185°F)
COM Express form factor: 125mm x 95mm (4.92” x 3.74”)
Weight: 10.8oz (306.2grams) with heatspreader
RoHS: Compliant
Operating System Support
Windows Embedded Standard 7
Windows Embedded CE
Linux 2.6.xx
1.2 Thermal Considerations
All models of Altair are specified for a -40oC to +85oC operating range, the temperature being measured at the
outside surface of the heatspreader. Diamond Systems provides a heatspreader attached to the Altair single
board computer as a conductive cooled thermal layer. However, this heatspreader by itself does not constitute
the complete thermal solution necessary for any specific implementation, but provides a common interface
between the single board computer and the customer’s implementation-specific thermal solution.
The outside surface of the Altair heatspreader must be kept at a temperature not to exceed +85oC. If your
environment causes the temperature on the outside surface of the heatspreader to exceed this temperature, you
are responsible for removing the additional heat from the system through either an additional passive thermal
solution or fan solution.

Altair User Manual Rev A.02 www.diamondsystems.com Page 8
2. FUNCTIONAL OVERVIEW
2.1 Block Diagram
Figure 2 shows Altair’s functional blocks.
Figure 2: Altair SBC Functional Block Diagram

Altair User Manual Rev A.02 www.diamondsystems.com Page 9
2.2 Altair Dimensions
Figure 3 shows the overall dimensions of the Altair SBC measured in thousandths of inches.
.
Figure 3: Altair Dimensions, thousandths of inches

Altair User Manual Rev A.02 www.diamondsystems.com Page 10
2.3 Connector Locations
Figure 4 illustrates the position of interface and bus connectors jumpers located on the top side of the Altair SBC,
which features EMX stackable I/O and an EMX connector. The connector for the EMX expansion bus is located
on the top side of the board.
Figure 4: Altair SBC Connector Locations
LCD
Backlight
EMX
Expansion
LVDS
VGA
USB1 and 2
USB3 and 4
Serial1 and 2
Serial3 and 4
Ethernet
PCIe MiniCard
CAN
PIC GPIO /
Analog / PWM
Audio
Utility
SATA
Power In
SSD
PIC
programming
header
External Battery
al b
te
y
n

Altair User Manual Rev A.02 www.diamondsystems.com Page 11
2.3.1 Connector Summary
The following table summarizes the functions of Altair’s interface, utility, and power connectors. Signal functions
relating to all of Altair’s interface connectors are discussed in greater detail in Section 4 of this document.
Diamond offers an optional Altair Cable Kit (number C-ALT-KIT), which provides mating cable assemblies for
most of Altair’s I/O interface connectors.
Connector Function
Silkscreen Label
External Battery
J2
CAN
J3
SATA
J4
Ethernet
J5
Serial Ports
J7, J8
USB Flashdisk
J9
USB Ports
J10, J11
Utility Signals
J12
LCD Backlight
J14
LCD (LVDS) Panel
J15
EMX I/O
J20
Power Input
J24
GPIO
J26
PIC Programming
J27
PCIe MiniCard
J28
Audio
J29
VGA
J30

Altair User Manual Rev A.02 www.diamondsystems.com Page 12
2.4 Configuration Jumpers
Figure 5 shows the configuration jumper groups that are located on the topside of the Altair SBC. Refer to Section
5 for details on the functions and configuration options associated with each jumper group.
Figure 5: Altair SBC Configuration Jumper Groups
LCD Backlight
LCD
Scan /
Map
LCD
Power
Serial Ports

Altair User Manual Rev A.02 www.diamondsystems.com Page 13
2.4.1 Configuration Jumper Summary
The Altair SBC contains jumper blocks for configuring the following features. The board also contains locations for
installation of 0-ohm resistors in place of all valid jumper positions for a rugged configuration. The 0-ohm resistors
are oriented and labeled in a way that provides easy understanding of their use and easy interpretation of their
settings.
Altair’s configuration jumpers are listed below. Refer to Section 5 of this document for details regarding the
configuration of these jumper groups.
Jumper Group Function
Silkscreen Label
Array Size
Serial Port 1 RS-422/485 mode differential termination
resistor: Enable or Disable
(default: Disable)
JP1
2 X 2
LCD panel supply voltage: 3.3V or 5V
(default: 3.3V)
JP2
1 X 3
LCD backlight power: 5V or 12V
(+12V provided through the input power connector)
(default: 5V)
JP4
1 X 3
LCD Panel Scan Direction: Normal Scan or Reverse Scan
(default: Normal)
JP5
2 X 2
LVDS Mapping: Map-A or Map-B
(default: Map-A)
-

Altair User Manual Rev A.02 www.diamondsystems.com Page 14
Important Safe-Handling Information
WARNING: ESD-Sensitive Electronic Equipment!
Observe ESD-safe handling procedures when working
with this product.
Always use this product in a properly grounded work area
and wear appropriate ESD-preventive clothing and/or
accessories.
Always store this product in ESD-protective packaging
when not in use.
Please refer to page 4 of this manual (“Important Safe-Handling Information”) for further
details.
3. GETTING STARTED
First-time Altair users normally receive the product as part of Diamond’s Altair Development Kit, which provides
everything needed to ensure rapid application development. This section of the Altair User Manual covers basic
hardware setup, power connection, system boot-up, and initial software configuration. After Altair is up and
running, refer to the later sections of this manual for the detailed hardware and software reference information
needed to adapt the product to specific applications.
3.1 Introducing the Altair Development Kit
The Altair Development Kit (DK-ALT-xxx) provides everything required for Altair-based rapid application
development. The table on the next page lists the boards, cables, and other items included. The xxx denotes the
operating system of choice, either Linux (LNX) or Windows Embedded Standard 7 (WE7).

Altair User Manual Rev A.02 www.diamondsystems.com Page 15
Item
Diamond P/N
Description
1
ALT1600-1G-XT
Altair SBC with 1.6GHz Atom E680T CPU, 1GB SDRAM
2
889061x
8GB USB flashdisk with bootable OS pre-loaded
3
C-ALT-KIT
Altair Cable Kit
4
7461611
Altair Quick Start Guide (not shown)
5
671061x
DVD with backup image and software files
6
DOC-PKG
Diamond Systems Document Package (not shown)
3.1.1 Altair Cable Kit
The Altair Cable Kit (number C-ALT-KIT) provides convenient access to most of Altair’s I/O features. The kit’s
cable assemblies are shown in the photo below, and identified in the table that follows.
Item
Qty
Description
Diamond P/N
Connects to…
1
1
Gigabit Ethernet cable to RJ45
6981315
J5
2
2
Dual serial cable
6981316
J7 and J8
3
2
Dual USB cable
6981317
J10 and J11
4
1
Utility cable
6981318
J12
5
1
Power input cable
6981321
J24
6
1
Digital I/O cable
6981322
J26
7
1
HD Audio cable
6981323
J29
8
1
VGA cable
6981324
J30

Altair User Manual Rev A.02 www.diamondsystems.com Page 16
Note: On each interface cable, the end of the cable connector that has a red wire going to it
should be oriented toward the end of the board connector that is labeled “pin 1” (typically the pin
with a square pad on the PCB).

Altair User Manual Rev A.02 www.diamondsystems.com Page 17
Caution! Be sure the PS-5V-04 AC power adapter is disconnected from
its AC power source prior to performing the following step.
3.2 System Setup
This section outlines a simple process for preparing Altair for first-time operation using the Altair Development Kit.
Additional details regarding Altair’s interface functions and connections may be found in Section 4 of this
document (Interface Connector Details).
3.2.1 Keyboard and Mouse
Altair supports operation using a USB-based keyboard and mouse devices. Plug the USB keyboard connector
and USB mouse cable into the Altair Cable Kit cable number 6981317 and the end of the cable into connector J10
on Altair.
3.2.2 USB Flashdisk Socket
Altair provides a location for on-board installation of an optional USB flashdisk on connector J9. Plug the USB
flashdisk module in the Development Kit into connector J9 on Altair. Remove the screw from the mounting stand-
off before installing the flashdisk. Secure the flashdisk to Altair with the screw once the flashdisk is installed.
3.2.3 Mass Storage Devices
If desired, connect SATA hard drives to Altair by connecting a SATA cable to SATA connector J4 and then to the
SATA drive. Altair can operate with a combination of SATA and CD-ROM drives, and can boot from either of
them.
3.2.4 Connecting Power
Connect cable 6981321 to the PS-5V-04 AC power adapter or an ATX power supply. Connect the other end of
the 6981321 cable to connector J24 on the Altair SBC.
3.2.5 Display
Altair provides interfaces for both LVDS flat panel displays and SDVO output. VGA CRTs can also be used, as
the board includes an SDVO to VGA converter.
Connect the VGA cable, 6981324, between the VGA connector, J30, and a VGA-compatible display.
3.2.6 Installing Altair in an Enclosure (optional)
Install the Altair single board computer in an enclosure that has an appropriate mounting-hole pattern (2.8”
square).
Altair’s heatspreader has four #6-32 threaded holes on 2.8” centers for mounting. Select four #6-32 threaded
screws of the proper length and head type to work with your enclosure. Allow a minimum of 0.25” and maximum
of 0.40” screw length for insertion into Altair’s heatspreader. The total screw length will depend on the thickness
of your enclosure wall.

Altair User Manual Rev A.02 www.diamondsystems.com Page 18
3.3 Booting the System
Power-up the VGA video monitor. Then plug the PS-5V-04 AC power adapter to an AC outlet. Altair should begin
its boot-up sequence immediately, as evidenced by BIOS messages on the connected VGA display. You can run
the BIOS Setup utility and proceed to install an operating system on the boot drive just as you would on a normal
desktop PC.
3.3.1 BIOS Setup
Altair’s BIOS provides a wide range of configuration options. When you power up Altair for the first time, you
should immediately enter the BIOS “Setup” utility in order to adjust BIOS settings to match your system’s
peripheral devices and other requirements, and to configure various other hardware and software parameters.
Options configurable via Setup typically include:
Number and type of mass storage devices
Boot device priority
Video display type and resolution
IDA, SATA, serial, and parallel interface modes and protocols
PCI and PnP configuration
Power management setup
Automatic power-up after LAN connection, RTC alarm, power resumption, etc.
System monitoring and security functions
3.3.2 Operating System Drivers
Altair will boot and run the operating system from the USB flashdisk. Altair should now be fully operational.
If you desire to run a different operating system, depending on the operating system to be installed, it may be
necessary to install software drivers for on-board interface controllers. Drivers for Windows Embedded Standard
7, Windows Embedded CE, and Linux 2.6, if required, are included on the Software and Documentation CD that
is included in the Altair Development Kit.

Altair User Manual Rev A.02 www.diamondsystems.com Page 19
4. INTERFACE CONNECTOR DETAILS
This section describes the functions associated with the Altair EMX SBC, EMX bus expansion, utility, I/O
interfaces, and power connectors in greater detail. Section 3.1.1 contains a list of ready-to-use interface cables
included in Diamond’s Altair Cable Kit.
4.1 External Battery (J2)
Altair has provision for an external battery connection via J2, a two-pin connector.
A connector and jumper are provided to disable the on-board battery and enable use of an external battery
instead. The external battery voltage requirement is 3.3V +/-10%. The jumper also clears the CMOS RAM when it
is removed and no external battery is connected.
1
Ground
2
Battery+
Connector type: HIROSE, DF13-2P-1.25DSA(50)
4.2 CAN (J3)
The CAN signals from the Intel Topcliff I/O Hub are available at this 1X4 1.25mm connector.
1
CAN_H
2
CAN_L
3
+5V
4
GND
Connector type: MOLEX, 532610471

Altair User Manual Rev A.02 www.diamondsystems.com Page 20
4.3 SATA (J4)
The SATA connector is an industry-standard right-angle connector. It is mounted flush with the edge of the board
so as to plug the SATA cable to an external hard drive.
1
Ground
2
Transmit+
3
Transmit-
4
Ground
5
Receive-
6
Receive+
7
Ground
Connector type: SAMTEC
4.4 Ethernet (J5)
This connector provides access to the board's Gigabit Ethernet port.
DA+
1
2
DB+
DA-
3
4
DB-
DC+
5
6
DD+
DC-
7
8
DD-
NC
9
10
NC
Connector type: JST, SM10B-ZPDSS-TF
