HIGHLYINTEGRATEDEMBEDDEDSBCWITHUSER‐SELECTABLEETXCPUPROCESSORCORE

•Highestlevelofintegrationinasingleboardcomputer:
Replaces6individualboards

•ETXCPUcoreprovidesflexibilityinprice/performance,
reducescostandprotectsagainstobsolescence

•ChoiceofAMDLX800uptoIntelCore2Duoprocessorswith
512MBto2GBsystemmemory

•Best‐in‐classanalogdataacquisitionwithautocalibrationand
softwaresupport

•5V,7‐28VDC/DCpowersupplyforeasiersystemintegration

•EPICformatwithPC/104‐Plusexpansionprovidescompact
sizewithflexibility

DESCRIPTION
Neptuneintroducesanewconceptinsmallformfactor
embeddedSBCs.TheCPUcoreconsistsofanETXmodule
whichmountsonthebottomsideofthebaseboardfor
improvedthermalmanagement.Thistechniqueprovides
moreroomonthetopforI/Ofeatures.Theresultisan
efficient,cost‐effective,reliableandcompactembedded
SBCrichinI/Oandotheruserbenefits.Neptuneisthe
first6‐in‐1embeddedSBCintegratingprocessor,system
I/O,dataacquisitionandevenaDC/DCpowersupply
ontoasingleboardinthecompactEPICformat.

YoucanselectfromawiderangeofETXCPUmodules
fromaworld‐classsuppliertotailorNeptune’spriceand
performancetoyouapplicationandbudget.APC/104‐
Plusexpansionconnectorenablesyoutoaddstillmore
I/Oorfeaturesifneeded,andthebuiltin5Vor7‐28V
inputDC/DCpowersupplyprovidesflexibilityin
integratingtheSBCwithyoursystempowersupply.
ThesefeaturesgiveNeptuneanunsurpassedlevelof
valueandflexibilityinasmallformfactorembeddedSBC.

DATAACQUISITION
NeptuneincludesDiamondSystems’top‐of‐the‐linedata
acquisitioncircuitrywiththeindustry’swidestsetofI/O
features:
•32analoginputs,16‐bitA/D,250KHzsamplerate
•4analogoutputs,12‐bitD/A
•24digitalI/O
•8opto‐isolateddigitalinputs
•8opto‐isolateddigitaloutputs
•2counter/timersforA/Dsampleratecontrol
•UniversalDriversoftwaresupportforCprogramming
underWindowsandLinux
Integratesthefunctionsof6boardsinto1
!
•CPU
•DataAcquisition
•Opto‐isolatedDigitalI/O
•MultiprotocolSerialPorts
•GigabitEthernet
•
DC/DCPowerSu
pp
l
y

NEPTUNE
BENEFITS OF 6‐in‐1INTEGRATION

LESSSPACE:SmallerandthinnerthanastackofPC/104
boards

LOWERCOST:AnintegratedsolutioneliminatesextraPCBs
andconnectorstolowertheunitcost

HIGHERRELIABILITY:Lessinterconnectsandcomponents,
resultinginhigherreliability

MORERUGGED:Theflatterprofileandreductionin
connectorsmakesNeptunefarmoreruggedinmobile
applications

SINGLEVENDOR:Purchasingandstockingareeasierwitha
singleboard



www.diamondsystems.com
BENEFITSOFANETXPROCSSORCORE
ChoiceofPrice/Performance
NeptuneisavailablewithalowpowerAMDLX800upto
anIntelAtomN270soyoucanobtainexactlythe
performanceandpricepointyouneed.

ProtectionfromObsolescence
Easilyswitchprocessormodulesincaseofprocessorend
oflife.

EasyUpgrade
ETXCPUsareinterchangeable,allowingyoutoeasily
upgradeyoursystemwithminimalornoredesign.

LowCost
ETXmodulescostlessthantheirequivalentsingleboard
computer,resultinginalowertotalcostforNeptune.



Undersideof
Neptuneshowing
ETXCPUmodule




AUTOCALIBRATIONFORBEST
MEASUREMENTACCURACY
DiamondSystems’top‐performingautocalibration
circuitryenablesyoutocalibratetheanalogcircuits
undersoftwarecontrolatanytime,maintainingbest
accuracyunderanyconditions.Temperatureandtime
dependentmeasurementdriftiseliminated,astheSBC
canbecalibratedasoftenasdesiredinjustafewseconds
toensureaccuratereadingsinallenvironmental
conditions.














THERMALMANAGEMEN
T

Neptuneplacestheprocessoronthebottomsideofthe
baseboard.Anintegratedheatspreadermakesthermal
contactwiththeheatgeneratingcomponentsontheETX
CPUmoduleandprovidesaflatsurfaceonthebottom
sideformatingtothesystemenclosure.Thistechnique
providesforefficientremovalofheatfromtheCPU
withouttheneedforafan.



ETXCPUMODULEOPTIONS

Processor0/+60°C ‐30/+85°C
AMDLX800500MHzYesYes
IntelPentiumM1.4GHzYesYes
IntelAtomN2701.6GHzYesYes



SYSTEMI/OFEATURES
AllNeptunemodelsincludethefollowingstandardCPU
I/OfeaturesinadditiontothedataacquisitionandDC/DC
powersupply.


SerialPorts2RS‐232,4RS‐232/422/485
USB4ports,1.1or2.0dependingonETX
module
PS/2Keyboardandmouseinterfaces
Ethernet
110/100MbpsfromETXmodule
1GigabitEthernetusingIntel82541and
on‐boardRJ‐45jack
Paralleland
Floppy
UserselectablethroughETXmodule
configuration
AudioAC’97(Micin,Linein,Lineout)
IDE144‐pinconnectorforsolidstateflashdisk
144‐pinconnectorforharddiskinterface
CompactFlash1socketforTypeI/IIdevice
VGA,LCDPerformancedependsonETXmodule



www.diamondsystems.com
ACCESSORIES
PanelI/OBoard
ThepanelI/Oboardplugsontothefrontrowofpin
headerstoprovidecable‐freeaccesstothestandard
systemI/O:serialports,USB,Ethernet,PS/2,VGAand
powerinput.ThepanelI/Oboardisdesignedtowork
withtheTritonenclosureasacompleteenclosure
system,orinastandaloneconfiguration.



CableKit
AcablekitprovidescablesforalltheI/Ofeatureson
NeptuneincludingthoseonthepanelI/Oboard.All
cablesareavailableseparatelyaswell.


Memory
NeptuneusesDDRSODIMMmoduleswithcapacities
rangingfrom512MGto1GBdependingonthechoiceof
ETXCPUmodule.

DevelopmentKits
AquickstartDevelopmentKitincludeseverythingyou
needtogetstartedwithyourapplicationdevelopment
including:
•NeptuneSBCwithETXCPUmoduleofyourchoice
•1GBofSODIMMRAMinstalled
•Heatspreaderinstalled
•128MBflashdiskmodulewithembeddedLinux
•PanelI/Oboard
•CableKit
•ACpoweradapter
•FastStartGuideandsoftwareonCD

FORMOREINFORMATION

DiamondSystemsCorporation
1255TerraBellaAvenue
MountainView,CA94043
Tel:650‐810‐2500
Fax:650‐810‐2525
[email protected]
OPERATINGSYSTEMSUPPOR
T

Neptunesupportsthefollowingoperatingsystems:
WindowsXP/XPe,WindowsCE,Linux
Optionaluponrequest:VxWorks,QNX


ORDERINGINFORMATION

PartNumberDescription
NPT‐LX8A‐512ANeptuneSBC,500MHzLX800CPU,512MB
RAM,on‐boarddataacquisition
NPT‐LX8A‐512NNeptuneSBC,500MHzLX800CPU,512MB
RAM,noDAQ,noGigabitEthernet
NPT‐LX8A‐1GANeptuneSBC,500MHzLX800CPU,1GB
RAM,on‐boarddataacquisition
NPT‐LX8A‐1GNNeptuneSBC,500MHzLX800CPU,1GB
RAM,noDAQ,noGigabitEthernet
NPT‐PM14‐512ANeptuneSBC,1.4GHzPentiumMCPU,
512MBRAM,on‐boarddataacquisition
NPT‐PM14‐512NNeptuneSBC,1.4GHzPentiumMCPU,
512MBRAM,noDAQ,noGigabitEthernet
NPT‐PM14‐1GANeptuneSBC,1.4GHzPentiumMCPU,1GB
RAM,on‐boarddataacquisition
NPT‐PM14‐1GNNeptuneSBC,1.4GHzPentiumMCPU,1GB
RAM,noDAQ,noGigabitEthernet
DK‐NPTLX8‐01
NeptuneLX800DevelopmentKit:
SBCwithdataacquisition,cable,flashdisk
withLinux,documentation&softwareCD
DK‐NPTPM14‐01
NeptunePentiumMDevelopmentKit:
SBCwithdataacquisition,cable,flashdisk
withLinux,documentation&softwareCD
DK‐LNX‐NPT512NeptuneLinuxDevelopmentKitwith
512MBflashdisk
C‐NPT‐KITNeptuneCableKit
TRI‐NPT‐KITTritonEPICEnclosureKitincluding
NeptunePanelI/OBoardandCableKit
TRI‐NPT‐KTritonEPICEnclosureforNeptune
PNL‐NPT‐KITNeptunePanelI/OBoardKitincluding
cables
PNL‐NPT‐01NeptunePanelI/OBoard

