Diamond Systems EPSILON 8130 Series User manual

EPSILON 8130 SERIES
Managed 8-Port Gigabit Ethernet Switch
User Manual rev 1.0 PRELIMINARY
Revision
Date
Comment
1.0
02/15/2022
Initial Release
©Copyright 2022
FOR TECHNICAL SUPPORT Diamond Systems Corporation
PLEASE CONTACT: www.diamondsystems.com
[e-mail]

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 2
CONTENTS
1. Important Safe Handling Information.....................................................................................................4
2. Introduction...........................................................................................................................................5
2.1 Features ............................................................................................................................................6
2.1.1 Main Feature List........................................................................................................................6
2.1.2 Mechanical and Environmental ....................................................................................................6
2.2 Products............................................................................................................................................6
2.3 Cable List...........................................................................................................................................7
3. Functional Overview..............................................................................................................................8
3.1 Functional Block Diagram....................................................................................................................8
3.2 Board Layout......................................................................................................................................9
4. Connector and Jumper List .................................................................................................................10
4.1 Connector and Jumper List................................................................................................................10
4.2 Jumper Block (J15)...........................................................................................................................10
5. Connector Pinout and Pin Description ................................................................................................11
5.1 Ethernet (J4-J11)..............................................................................................................................11
5.2 Serial Interface (J12).........................................................................................................................11
5.3 Input Power (J14) .............................................................................................................................11
5.4 LED Status Signals (J13) ..................................................................................................................12
6. Thermal Solutions ...............................................................................................................................13
6.1 Heat Sink .........................................................................................................................................13
6.2 Heat Spreader..................................................................................................................................14
7. Command Line Interface .....................................................................................................................15
7.1 Making an Initial Connection..............................................................................................................15
7.2 Login/Logout Procedures ..................................................................................................................15
7.3 Help Utility........................................................................................................................................16
7.4 Entering Commands .........................................................................................................................16
7.5 General Command Groups................................................................................................................16
7.5.1 IP Commands ..........................................................................................................................16
7.5.2 MAC Commands ......................................................................................................................17
7.5.3 VLAN/PVLAN Commands .........................................................................................................17
7.5.4 dot1x (IEEE Standard forport-based Network Access Control)....................................................17
7.5.5 LACP Commands.....................................................................................................................18
7.5.6 LLDP Commands .....................................................................................................................18
7.5.7 Access Management Commands...............................................................................................18
7.5.8 Access-list Commands..............................................................................................................18
7.5.9 Logging Commands..................................................................................................................18
7.5.10 Spanning-tree Commands.........................................................................................................19
7.5.11 Green-Ethernet Commands.......................................................................................................19
7.5.12 Thermal-protect Commands ......................................................................................................19
7.5.13 Loop-protect Commands...........................................................................................................19
7.5.14 QoS Commands.......................................................................................................................19
7.5.15 Privilege Commands.................................................................................................................20
7.5.16 SNMP Commands ....................................................................................................................20
7.5.17 SNTP Commands.....................................................................................................................20
7.5.18 Radius Server Commands.........................................................................................................21
7.5.19 Banner Commands (Defines a login banner) ..............................................................................21
7.5.20 Terminal Commands.................................................................................................................21
7.5.21 Reload .....................................................................................................................................21
7.5.22 Firmware Commands................................................................................................................22
7.5.23 Ping Commands.......................................................................................................................22
7.5.24 Debug Commands....................................................................................................................22
7.5.25 Security Commands..................................................................................................................22
7.5.26 Monitor.....................................................................................................................................22
7.6 Examples.........................................................................................................................................23
7.6.1 IP Configuration........................................................................................................................23
7.6.2 Port Configuration.....................................................................................................................23
7.6.3 Change Switch Password..........................................................................................................23
7.6.4 Set up VLANs...........................................................................................................................23
7.6.5 SNMP configuration..................................................................................................................24

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 3
7.6.6 Mirroring ..................................................................................................................................24
7.6.7 Setup QoS...............................................................................................................................25
7.6.8 Firmware Upgrade....................................................................................................................25
7.6.9 Factory defaults........................................................................................................................25
8. Web Interface.......................................................................................................................................26
8.1 Examples.........................................................................................................................................26
8.1.1 IP Configuration........................................................................................................................26
8.1.2 Port Configuration.....................................................................................................................27
8.1.3 Change Password ....................................................................................................................28
8.1.4 Set-up VLANs ..........................................................................................................................29
8.1.5 SNMP Configuration.................................................................................................................30
8.1.6 Mirroring ..................................................................................................................................31
8.1.7 Setup QoS...............................................................................................................................32
8.1.8 Web Interface Activation / Deactivation......................................................................................33
8.1.9 Firmware Upgrade....................................................................................................................33
8.1.10 Save Startup Configuration........................................................................................................33
8.1.11 Factory Defaults .......................................................................................................................34
8.1.12 Physical Reset..........................................................................................................................35
9. Specifications......................................................................................................................................36
Appendix A Supported MIBs ..................................................................................................................37
Appendix B Upgrading Bootloader & Application Image .......................................................................37
Appendix C Changes from EPS-8100 to EPS-8130.................................................................................40

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 4
1. IMPORTANTSAFEHANDLINGINFORMATION
WARNING!
ESD-Sensitive Electronic Equipment
Observe ESD-safe handling procedures when working with this product.
Always use this product in a properly grounded work area and wear appropriate
ESD-preventive clothing and/oraccessories.
Always store this product in ESD-protective packaging when not in use.
Safe Handling Precautions
The Epsilon-8130 board contains a high density connector with many connections to sensitive electronic
components. This creates many opportunities foraccidental damage during handling, installation and connection
to other equipment. The list here describes common causes of failure found on boards returned to Diamond
Systems forrepair. This informationis provided as asource of advice to help you prevent damaging your Diamond
(or any vendor’s) boards.
ESD damage –This typeof damageis usually almost impossibleto detect, because there is no visual sign of failure
or damage. The symptom is that the board eventually simply stops working, because some component becomes
defective.Usually the failure can be identifiedand thechip can bereplaced. To prevent ESDdamage, always follow
properESD-prevention practices when handling computerboards.
Damage during handling or storage –On some boards we have noticed physical damage from mishandling. A
commonobservation is that a screwdriver slipped while installing the board, causing a gouge in the PCB surface
and cutting signal traces ordamaging components.
Another common observation is damaged board corners, indicating the board was dropped. This may or may not
cause damage to the circuitry, depending onwhat is near the corner. Most of ourboards are designed with at least
25 mils clearance between the board edgeand any component pad, and ground / powerplanes are at least 20 mils
from theedge to avoid possible shorting from this typeof damage. However these design rules are not sufficient to
prevent damage in all situations.
A third cause of failure is when a metal screwdriver tip slips, orascrew drops onto the board while it is powered on,
causing a short between a power pin and a signal pin ona component. This can cause overvoltage/ power supply
problems described below. To avoid this type of failure, only perform assembly operations when the system is
powered off.
Sometimes boards are stored in racks with slots that grip the edge of the board.This is a common practice forboard
manufacturers. However our boards are generally very dense, and if the board has components very close to the
board edge, they can be damaged or even knocked off theboard when the board tilts back in the rack. Diamond
recommends that all our boards be stored only in individual ESD-safe packaging. If multiple boards are stored
together, they should becontained in bins with dividers between boards. Do not pile boards on top of eachotheror
cram too many boards into a small location. This can cause damage to connector pins orfragile components.
Power supply wired backwards –Our powersupplies and boards are not designed to withstand a reverse power
supply connection. This will destroy each IC that is connected to the power supply (i.e. almost all ICs). In this case
the board will most likely will be unrepairable and must be replaced. A chip destroyed by reverse power or by
excessive power will often have a visible hole on the top or show some deformation on the top surface due to
vaporization inside the package. Check twice before applying power!
Overvoltage on analog input –If a voltage applied to an analog input exceeds the design specification of the
board, the input multiplexorand/orparts behind it can bedamaged. Most of ourboards will withstand an erroneous
connection of up to 35V on the analog inputs, even when the board is powered off,but not all boards, and not in
all conditions.
Overvoltage on analog output –If an analog output is accidentally connected to another output signal ora power
supply voltage, the output can be damaged. On most of our boards, a short circuit to ground on an analog output
will not cause trouble.
Overvoltage on digital I/O line –If a digital I/O signal is connected to a voltage above the maximum specified
voltage, the digital circuitry can be damaged. On most of our boards the acceptable range of voltages connected to
digital I/O signals is 0-5V, and they can withstand about 0.5V beyond that (-0.5 to 5.5V) before being damaged.
However logic signals at 12V and even 24V are common, and if one of these is connected to a 5V logic chip, the
chip will be damaged, and the damage could even extend past that chip to others in the circuit.

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 5
2. INTRODUCTION
The Epsilon 8130 series (referred to as EPS-8130) is a rugged, managed, 8-Port Gigabit Ethernet Switch with wide
power supply voltage and positive latching connectors. Epsilon-8130 offers 10/100/1000Mbps coppertwisted pair
ports on a PC/104 format board. A built-in microcontroller runs Layer 2+ managed software to control all switch
functions. Both a web interface and an RS-232 interface are provided to enable user access to the microcontroller
for configurationand monitoring. A wide-range DC power supply is built into the board to allow it to be used with
industrial power sources as well as the typical embedded +5V supply. The Epsilon 8130 family is available with
bothheat sinkand heat spreader configurations.Bothconfigurationssupportfull-40to +85C operating temperature.
EPS-8130 was designed as a compatible replacement for EPS-8100 series due to component end of life and
availability issues. All features and functions of EPS-8100 are retained in EPS-8130. There should be no difficulty
in using the new model in place of the old one. Please refer to Appendix C fordetails on the differences between
the original EPS-8100 to the EPS-8130.
Layer 2+ Managed Switch
Epsilon-8130’s Ethernet switch chip includes a built-in microcontrollerfor configuration and management. It can be
accessed either through the on-board RS-232 port orone of theEthernet ports.
Wide Power DC/DC Power Supply
Epsilon-8130 is powered through a wide voltage +5-34V DC/DC power supply input.
Rugged Design
Extended temperature operation of -40°C to +85°C is tested and guaranteed. Epsilon-8130 was designed with
harsh applications in mind. Latching connectors provide increased reliability over common pin headers or RJ-45
jacks.
Software Support
The switch isready to plug into yourapplicationwithout any driver installation or firmware upgrades. A web interface
and a CLI provide an intuitive GUI forconfiguring and managing the switch. The branding and configurationof the
switch are customizableas a service.
EPS-8130 with heat sink EPS-81300-XT with heat spreader
(EPS-8100-XT shown, 8130 is similar)

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 6
2.1 Features
2.1.1 Main Feature List
8 10/100/1000Mbps copper Ethernet ports with nonblocking wire-speed performance
Dual leaky bucket policers with remarking and statistics
Jum bo frame support at all speeds
8K MAC addresses and 4K VLANs (IEEE 802.1Q), as well as 8K IPv4 and IPv6 multicast group support
Flexible link aggregation support based on Layer-2 through Layer-4 information (IEEE 802.3ad)
Multicast and broadcast storm control, as well as flooding control
Rapid Spanning Tree protocol (RSTP) and MSTP
8 priorities and 8 QoS queues per port with scheduling
Shaping/policing per queue and per port
Multiple protocol support: IEEE 802.1d, IEEE 802.1w, IEEE 802.1s, and IEEE 802.1X
Built-in 416MHz MIPS 24KEC microcontroller for configuration and management
RS-232 serial port provides out-of-band management interface
Direct UART TTL by-passing RS-232 transceiver is also supported
Can operate autonomously or in conjunction with a host SBC
Wide input voltage range: +5 to +36VDC input
PC/104 form factor (3.55 x 3.775 in.)
-40°C to +85°C (-40°F to +185°F) operating temperature
2.1.2 Mechanical and Environmental
PC/104 compliant form factorincluding:
Board dimensions
Mounting holes
Component and heat sink height
-40°C to +85°C ambient operating temperature
2.2 Products
The table below lists the model number and description for the Epsilon-8130 and its associated cable kit.
Model Number
Description
EPS-8130-XT
8-Port Gigabit Ethernet Switch with heat spreader, PC/104
form factor, -40°C to +85°C operating temperature
EPS-8130
8-Port Gigabit Ethernet Switch with heat sink, PC/104 form
factor, -40°C to +85°C operating temperature
C-EPS8000-KIT
Epsilon-8130 Cable Kit

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 7
2.3 Cable List
The contents of the Epsilon-8130 Cable Kit, C-EPS8000-KIT (same as EPS-8100), are shown below.
Number
Part Number
Quantity
Cable Description
1
6981052
8
Ethernet cable (1 per port)
2
6981051
1
Power cable
3
6981050
1
Serial cable
PC/104™ andPC/104-Plus™ aretrademarksofthePC/104EmbeddedConsortium.
All other trademarksaretheproperty oftheirrespectiveowners.

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 8
3. FUNCTIONAL OVERVIEW
3.1 Functional Block Diagram
Figure 1. Functional Block Diagram
Epsilon-8130 is an 8-Port managed Gigabit Ethernet switch moduleoffering 10/100/1000Mbps copper twisted pair
ports on a PC/104 form factor board. Epsilon-8130 operates standalone, requiring no connection to a single
board computer in the stack. It contains built-in microcontrollerand memory forconfiguration and management.
The Flash memory holds dual application images along with the boot code. The SRAM is used for program
execution and storing MAC addresses and other operational configuration data.
An RS-232 interface is provided to enable communication between the on-board management microcontroller
and a host processorthrough a CLI interface. Direct UART TTL logic is also supported by by-passing RS-232
transceiver based on requirements. The microcontroller is also accessible through one of the Ethernet ports via a
web management interface.
Power is provided through the +5-34VDC wide-range DC power supply built into the board, enabling use with
industrial power sources.

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 9
3.2 Board Layout
The following photo shows the locations forall connectors and jumpers which are described in the next sections.
Figure 2. Epsilon-8130 Connectors and Jumpers
LAN1
LAN3
LAN7
RS-232
LAN5
LAN2
LAN4
LAN6
LAN8
Power In
LED
J15

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 10
4. CONNECTOR ANDJUMPERLIST
4.1 Connectorand Jumper List
The following table summarizes the functions of Epsilon-8130’s interface connectors and jumper. Refer to Figure 2
for the locations of these connectors on Epsilon-8130. Signal functions relating to all of Epsilon-8130’s interf ace
connectors are discussed in greater detail in Section 6 of this document. Other connectors and jumper blocks on
Epsilon-8130 are reserved f or Diamond’s use only.
Connector
Function
LAN1-8
Ethernet (x8)
RS-232
RS-232 Serial Interface
LED
LED Status Signals and Resets
Power In
Wide voltage power input
J15
Jumper Block J15
4.2 Jumper Block (J15)
The following table summarizes the functions of Epsilon-8130’s jumper block, J15. Refer to the Figure 2 for the
location of J15 on Epsilon-8130.
Position
Function
IN
OUT
RST
Board Reset
Reset
Out of reset
DFLT
Default
Restore Factory settings
Save configuration settings
DIS-COM
COM SD
RS-232 Driver disabled
RS-232 Driver enabled
*Default Mode

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 11
5. CONNECTOR PINOUTANDPIN DESCRIPTION
5.1 Ethernet (J4-J11)
Epsilon-8130 contains eight right-angle, locking pin headers for the eight Ethernet ports. Each port has the same
style and pin out. Each signal is associated with a particular colorinside of the Diamond Systems cable part
number 6981052.The color coding forthis cable follows theTIA/EIA 568B standard.
DD+
1
2
DD-
DC+
3
4
DC-
DB+
5
6
DB-
DA+
7
8
DA-
Gnd
9
10
Gnd
Connector Type: JST PUD series 2mm dual row right-angle, locking pin header with tin plating
Mating Connector: JST Sales America PUDP-10V-S housing with SPUD-002T-P0.5 terminals
Mating Cable: DSC part number 6981052 (Note: the ground pins on the board connectorare not used onthis
cable.)
5.2 Serial Interface (J12)
Epsilon-8130 contains an RS-232 connector, J12, which connects the on-board microcontrollerto an external
serial port.
1
Ground
2
TxD Out
3
RxD In
Connector Type: 2mm single row right-angle, locking pin header with tin plating
Mating Connector: Molex Connector 35507-0300 housing with 50212-8100 terminals
Mating Cable: DSC part number 6981052 (Note: the ground pins on the board connectorare not used onthis
cable.)
5.3 Input Power (J14)
Input power is supplied either through the dedicated 4-pin connector (J14). The pin out forJ14is:
1
V In
2
Ground
3
Ground
4
V In
Connector Type: 2mm single row right-angle, locking pin header with tin plating
Mating Connector: Molex Connector 35507-0400 housing with 50212-8100 terminals
Mating Cable: DSC part number 6981052 (Note: the ground pins on the board connectorare not used onthis
cable.)

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 12
5.4 LED Status Signals (J13)
Connector J13 provides access to the Ethernet LED signals foreach of the eight ports. This connectorhas
duplicate connections for Reset control input. LEDs may be directly connected to these signals without requiring
any current-limiting resistors.
The on board activity LED is a green LED (LTST-C190GKT) with a typical forward voltage of 2.1V and a
maximum of 2.6V with a 20mA If. The on board speed LED is a Yellow LED (LTST-C190YKT) with the same
characteristics. The control signal is capable of sinking a maximum of 18mA. The series resistor is 330 ohms,
which gives an If of about 3.6mA. When an LED is connected to connector J13, it is in parallel with the on board
LED. If the external LED has about the same forward voltage, the current will be cut in half. If the external LED
has a lower forward voltage, it will dominate the on-board LED and be brighter. Therefore, if the external LED is
not bright enough use an external LED with a lower forward voltage.
Reset: Causes a reset of theswitch when connected to ground.
SW_GPIO1 and SW_GPIO2 - provide control for user defined LEDs.
Port 2 Activity
1
2
Ground
Ground
3
4
Port 2 Speed
Port 4 Activity
5
6
Port 4 Speed
Port 6 Activity
7
8
Ground
Ground
9
10
Port 6 Speed
Port 8 Activity
11
12
Port 8 Speed
Port 7 Speed
13
14
Ground
Ground
15
16
Port 7 Activity
Port 5 Speed
17
18
Port 5 Activity
Port 3 Speed
19
20
Ground
Ground
21
22
Port 3 Activity
Port 1 Speed
23
24
Port 1 Activity
#Default
25
26
#Reset
SW_GPIO1
27
28
SW_GPIO0
3.3V
29
30
3.3V
31
32
33
34
Connector Type: 2mm dual row right-angle, through hole, 34 circuits, pin header. 877603416 from Molex
Mating Cable: DSC 6981509 cable can be used. This is not a part of cable kit. A common 2mm pitch 2x17 ribbon
cable can also be used.
The following diagram shows how to connect external LEDs to connectorJ13:

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 13
6. THERMALSOLUTIONS
6.1 Heat Sink
Model EPS-8130 contains a heat sink forcooling. The heat sink is positively affixed to theboard with 2 screws,
and it contains a thermal pad to contact the Ethernet switch IC. The total height conforms to the height limitations
for aPC/104 form factorboard (11.2mm / 0.435”above the top surface of the PCB). Although the size of the heat
sink is small, it is capableof enabling the EPS-8130 to operate over the full industrial temperature range of -40 to
+85oC, as long as there is free air above it (no other board should be mounted over the heat sink).

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 14
6.2 Heat Spreader
Model EPS-8130-XT contains a heat spreader which serves as both a cooling method and a mounting method for
the board. The heat spreader is the same size as the board and uses a thermal pad to contact the Ethernet switch
IC. The I/O connectors overhang the board and heat spreader so they can still be accessed. The heat spreader is
intended fordirect mounting to the inner surfaceof thesystem enclosure. Thermal grease may be applied to the
junction if desired. The heat spreader enables the EPS-8130 to operate over the full industrial temperature range
of -40 to +85oC.
Custom heat spreaders can be designed to meet particular application requirements. Examples include a larger
size to enable mounting from theinterior ora different mounting hole pattern.

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 15
7. COMMANDLINEINTERFACE
The command line interface (CLI) is a modal, line-based interface with no screen editing features where commands
are executed immediately upon end-of-line. The CLI can be accessed directly via the serial connection. The user
must log in before CLI commands can be executed.
7.1 Making an Initial Connection
Serial line configuration:
38400 baud
8 bit data
No parity
1 stop bit
Login information
Username: admin
Password: {none}
The board is shipped with an IP address of 192.168.1.60. This allows the WEB interface to be accessed at that
address.
The IP address, mask and gateway must be set according to yourenvironment, or you can enable IP and DHCP if
your environment includes a DHCP server. Forexample:
# configure terminal
(config)# interface vlan 1
(config-if-vlan)# ip address dhcp
(config-if-vlan)# end
Below example depicts configuration of static IP address,
# configure terminal
(config)# interface vlan 1
(config-if-vlan)# ip address 192.168.1.60 255.255.0.0
(config-if-vlan)# end
Display the IP address to confirm:
# show ip interface brief
Vlan Address Method Status
---- -------------------- -------- ------
1 192.168.1.60 Manual UP
#
7.2 Login/Logout Procedures
To get access to the CLI you must login by entering a username and password. You will automatically be queried
about the password.
The password is configurable. You may logout at any time and at any context level using the exit command

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 16
7.3 Help Utility
You may get help by pressing the ? key or entering help. The help info depends on the context:
•At top level, a list of command groups is displayed.
•At group level, a list of thecommand syntaxes for the current group is displayed.
•If the help command is issued for a specific command, the command syntax and a description of the
command are shown.
7.4 Entering Commands
•Commands are not case-sensitive.
•You may use the horizontal arrow-keys ← and → to move the cursor within the command you are entering.
•You may use the backspace key (provided youare using a terminal that sends the BS (8) character when
the backspace key is pressed) to delete chars from the command you are entering.
•You may use the vertical arrow-keys ↑ and ↓ to scroll through a command history buf f er of the latest 20
commands issued.
7.5 General Command Groups
The following groups of general commands are available in the command line interface (CLI).
# ?
clear Reset functions
configure Enter configuration mode
copy Copy from source to destination
debug Debugging functions
delete Delete one file in flash: file system
dir Directory of all files in flash: file system
disable Turn off privileged commands
do To run exec commands in config mode
dot1x IEEE Standard for port-based Network Access Control
enable Turn on privileged commands
exit Exit from EXEC mode
firmware Firmware upgrade/swap
help Description of the interactive help system
ip IPv4 commands
logout Exit from EXEC mode
more Display file
no Negate a command or set its defaults
ping Send ICMP echo messages
reload Reload system.
send Send a message to other tty lines
show Show running system information
terminal Set terminal line parameters
#
7.5.1 IP Commands
(config)#ip http secure-redirect

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 17
(config)#ip http secure-server
(config)#ip igmp snooping
(config)#ip igmp snooping vlan<v_vlan_list>
(config)#ip igmp unknown-flooding
(config)#ip route <v_ipv4_addr> <v_ipv4_netmask> <v_ipv4_gw>
(config)#ip dhcp retry interface vlan <vlan_id>
(config)#no ip http secure-redirect
(config)#no ip http secure-server
(config)#no ip igmp snooping
(config)#no ip igmp snooping vlan [ <v_vlan_list> ]
(config)# no ip igmp unknown-flooding
(config)#no ip route <v_ipv4_addr> <v_ipv4_netmask> <v_ipv4_gw>
# clear ip arp
# clear ip igmp snooping [ vlan <v_vlan_list> ] statistics
# clear ip statistics [ system ] [ interface vlan <v_vlan_list> ] [ icmp ] [ icmp-msg <type> ]
# show ip arp
# show ip http server secure status
# show ip igmp snooping [ vlan <v_vlan_list> ] [ group-database [ interface ( <port_type> [ <v_port_type_list> ] )] [
sfm-information] ] [ detail ]
# show ip igmp snooping mrouter[ detail ]
# show ip interface brief
# show ip route
# show ip statistics [ system ] [ interface vlan <v_vlan_list> ] [ icmp ] [ icmp-msg <type> ]
7.5.2 MAC Commands
(config)# mac address-table aging-time <v_0_10_to_1000000>
(config)# mac address-tablestatic <v_mac_addr> vlan <v_vlan_id> interface ( <port_type> [
<v_port_type_list> ] )
(config)# no mac address-table aging-time
(config)# no mac address-table aging-time <v_0_10_to_1000000>
(config)# no mac address-table static <v_mac_addr> vlan <v_vlan_id> interface ( <port_type> [
<v_port_type_list> ] )
# clear mac address-table
# show mac address-table [ conf |static | aging-time | { { learning | count } [ interface ( <port_type> [
<v_port_type_list> ] )] } | { address <v_mac_addr> [ vlan <v_vlan_id> ] } | vlan <v_vlan_id_1> | interface (
<port_type> [ <v_port_type_list_1> ] )]
7.5.3 VLAN/PVLAN Commands
(config)# interface vlan <vlist>
(config)#no interface vlan <vlist>
(config)#no vlan { { ethertype s-custom-port } | <vlan_list> }
(config)# vlan <vlist>
(config)#vlan ethertype s-custom-port <etype>
# show interface vlan [ <vlist> ]
# show pvlan [ <pvlan_list> ]
# show pvlan isolation[ interface ( <port_type> [ <plist> ] )]
# show vlan [ id <vlan_list> | name <name> | brief ]
# show vlan status [ interface ( <port_type> [ <plist> ] ) ] [ combined | admin | nas | mvr | voice-vlan | mstp | erps |
vcl | evc | gvrp | all | conflicts ]
7.5.4 dot1x (IEEE Standard for port-based Network Access Control)
(config)#dot1x authentication timer inactivity <v_10_to_100000>
(config)# dot1x authentication timer re-authenticate <v_1_to_3600>

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 18
(config)# dot1x re-authentication
(config)# dot1x system-auth-control
(config)# dot1x timeout quiet-period <v_10_to_1000000>
(config)# dot1x timeout tx-period <v_1_to_65535>
(config)# no dot1x authentication timer inactivity
(config)# no dot1x authentication timer re-authenticate
(config)# no dot1x re-authentication
(config)# no dot1x system-auth-control
(config)# no dot1x timeout quiet-period
(config)# no dot1x timeout tx-period
# clear dot1x statistics [ interface (<port_type> [ <v_port_type_list> ] ) ]
# dot1x initialize [ interface ( <port_type> [ <plist> ] ) ]
# show dot1x statistics { eapol | radius | all } [ interface ( <port_type> [ <v_port_type_list> ] )]
# show dot1x status [ interface ( <port_type> [ <v_port_type_list> ] ) ] [ brief ]
7.5.5 LACP Commands
(config)# lacp system-priority <v_1_to_65535>
(config)#no lacp system-priority <v_1_to_65535>
# clear lacp statistics
# show lacp { internal | statistics |system-id | neighbour }
7.5.6 LLDP Commands
(config)# lldp holdtime <val>
(config)# lldp reinit <val>
(config)# lldp timer<val>
(config)# lldp transmission-delay <val>
(config)#no lldp holdtime
(config)#no lldp reinit
(config)#no lldp timer
(config)# no lldp transmission-delay
# clear lldp statistics
# show lldp eee [ interface ( <port_type> [ <v_port_type_list> ] )]
# show lldp neighbors [ interface ( <port_type> [ <v_port_type_list> ] ) ]
# show lldp statistics [ interface ( <port_type> [ <v_port_type_list> ] ) ]
7.5.7 Access Management Commands
(config)#access management <access_id> <access_vid> <start_addr> [ to <end_addr> ] { [ web ] [ snmp ] [
telnet ] | all }
(config)# no access management
(config)# no access management <access_id_list>
# clear access management statistics
# show access management [ statistics |<access_id_list> ]
7.5.8 Access-list Commands
(config)#access-list rate-limiter [ <rate_limiter_list> ] { pps <pps_rate> | 100pps <pps100_rate> | kpps
<kpps_rate> | 100kbps <kpbs100_rate> }
(config)# default access-list rate-limiter [ <rate_limiter_list> ]
(config)# no access-list ace <ace_list>
# clear access-list ace statistics
# show access-list [ interface [ ( <port_type> [ <v_port_type_list> ] )] ] [ rate-limiter [ <rate_limiter_list> ] ] [ ace
statistics [ <ace_list> ] ]
# show access-list ace-status [ static ] [ link-oam ] [ loop-protect ] [ dhcp ] [ ptp ] [ upnp ] [ arp-inspection ] [ evc ] [
mep ] [ ipmc ] [ ip-source-guard ] [ ip-mgmt ] [ conflicts ] [ switch<switch_list> ]
7.5.9 Logging Commands
(config)# logging host <v_word45>
(config)#logging level { info |warning | error }

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 19
(config)# logging on
(config)#no logging host
(config)#no logging on
# clear logging [ info ] [ warning ] [ error ] [ switch <switch_list> ]
# show logging <log_id> [ switch <switch_list> ]
# show logging [ info ] [ warning ] [ error ] [ switch <switch_list> ]
7.5.10 Spanning-tree Commands
(config)# spanning-tree aggregation
(config)# spanning-tree edge bpdu-filter
(config)# spanning-tree edge bpdu-guard
(config)# spanning-tree mode{ stp | rstp | mstp }
(config)# spanning-tree recovery interval <interval>
(config)# spanning-tree transmit hold-count <holdcount>
(config)#no spanning-tree edge bpdu-filter
(config)#no spanning-tree edge bpdu-guard
(config)# no spanning-tree mode
(config)# no spanning-tree recovery interval
(config)# no spanning-tree transmit hold-count
# clear spanning-tree { { statistics [ interface( <port_type> [ <v_port_type_list> ] )] } | { detected-protocols [
interface ( <port_type> [ <v_port_type_list_1> ] ) ] } }
# show spanning-tree [ summary | active | { interface ( <port_type> [ <v_port_type_list> ] )} | { detailed [ interface
( <port_type> [ <v_port_type_list_1> ] ) ] } | { mst [ configuration |{ <instance> [ interface ( <port_type> [
<v_port_type_list_2> ] ) ] } ] } ]
7.5.11 Green-Ethernet Commands
(config)# green-ethernet eee optimize-for-power
(config)# green-ethernet led interval <v_0_to_24> intensity <v_0_to_100>
(config)#green-ethernet led on-event { [ link-change <v_0_to_65535> ] [ error ] }*1
(config)# no green-ethernet eee optimize-for-power
(config)# no green-ethernet led interval <0~24>
(config)#no green-ethernet led on-event [ link-change ] [ error ]
# show green-ethernet [ interface ( <port_type> [ <port_list> ] ) ]
# show green-ethernet eee [ interface ( <port_type> [ <port_list> ] )]
# show green-ethernet energy-detect [ interface ( <port_type> [ <port_list> ] ) ]
# show green-ethernet short-reach [ interface ( <port_type> [ <port_list> ] ) ]
7.5.12 Thermal-protect Commands
(config)# no thermal-protect prio <prio_list>
(config)# thermal-protect prio <prio_list> temperature <new_temp>
# show thermal-protect [ interface ( <port_type> [ <port_list> ] ) ]
7.5.13 Loop-protect Commands
(config)# loop-protect
(config)# loop-protect shutdown-time <t>
(config)# loop-protect transmit-time <t>
(config)# no loop-protect
(config)# no loop-protect shutdown-time
(config)# no loop-protect transmit-time
# show loop-protect [ interface ( <port_type> [ <plist> ] )]
7.5.14 QoS Commands
(config)# no qos qce <qce_id_range>
(config)#no qos storm { unicast | multicast | broadcast }

Epsilon-8130 User Manual Revision 1.0 PRELIMINARY www.diamondsystems.com Page 20
(config)# qos storm {unicast | multicast | broadcast } { { <rate> [ kfps ] } | { 1024 kfps }}
# show qos [ { interface [ ( <port_type> [ <port> ] ) ] } | wred | { maps [ dscp-cos ] [ dscp-ingress-translation] [
dscp-classify] [ cos-dscp ] [ dscp-egress-translation] } | storm | { qce [ <qce> ] } ]
7.5.15 Privilege Commands
(config)# privilege { exec | configure | config-vlan | line | interface | if-vlan | ipmc-profile | snmps-host | stp-aggr |
dhcp-pool | rfc2544-profile } level <privilege> <cmd>
(config)# no privilege { exec | configure | config-vlan | line | interface | if-vlan | ipmc-profile | snmps-host | stp-aggr |
dhcp-pool | rfc2544-profile } level <0-15> <cmd>
# show privilege
7.5.16 SNMP Commands
(config)# snmp-server
(config)#snmp-server access <group_name> model { v1 | v2c | v3| any } level { auth | noauth | priv } [ read
(config)# <view_name> ] [ write <write_name> ]
(config)# snmp-server community v2c <comm> [ ro | rw ]
(config)# snmp-server community v3 <v3_comm> [ <v_ipv4_addr> <v_ipv4_netmask> ]
(config)# snmp-server contact <v_line255>
(config)# snmp-server engine-id local <engineID>
(config)# snmp-server host <conf_name>
(config)# snmp-server location <v_line255>
(config)# snmp-server security-to-group model { v1 | v2c | v3 } name <security_name> group <group_name>
(config)# snmp-server trap
(config)# snmp-server user <username> engine-id <engineID> [ { md5 <md5_passwd> | sha <sha_passwd> } [
priv { des | aes } <priv_passwd> ] ]
(config)#snmp-server version { v1 | v2c | v3 }
(config)#snmp-server view <view_name> <oid_subtree> { include | exclude }
(config)# no snmp-server
(config)#no snmp-server access <group_name> model { v1 | v2c | v3 | any } level { auth | noauth | priv }
(config)# no snmp-server community v2c
(config)# no snmp-server community v3 <community>
(config)# no snmp-server contact
(config)# no snmp-server engined-id local
(config)# no snmp-server host <conf_name>
(config)# no snmp-server location
(config)# no snmp-server security-to-group model { v1 | v2c | v3 } name <security_name>
(config)# no snmp-server trap
(config)#no snmp-server user <username> engine-id <engineID>
(config)# no snmp-server version
(config)# no snmp-server view <view_name> <oid_subtree>
# show snmp
# show snmp access [ <group_name> { v1 | v2c | v3 | any } { auth | noauth | priv } ]
# show snmp community v3 [ <community> ]
# show snmp host [ <conf_name> ] [ system ] [ switch ] [ interface ] [ aaa ]
# show snmp mib context
# show snmp mib ifmib ifIndex
# show snmp security-to-group [ { v1 | v2c | v3 } <security_name> ]
# show snmp user [ <username> <engineID> ]
# show snmp view [ <view_name> <oid_subtree> ]
7.5.17 SNTP Commands
(config)# sntp
(config)# sntp server ip-address { <ipv4_var> }
(config)# no sntp
