1. GENERAL INFORMATION
This manual applies to the units produced starting from September 1st, 2016. Part of the information contained in this manual do not apply to
previously purchased units.
Please follow instructions to ensure proper functioning of the equipment.
The manufacturer declines all responsibility for any malfunctioning caused by failing to follow given instructions.
All packaging materials used are eco-friendly and recyclable. Please dispose properly of the packaging.
2. SAFETY
ELECTRIC SYSTEM
Check carefully that voltage matches the one shown on the product tag located on the last page of this manual and also inside the cabinet, right
side, underneath the panel that covers the technical tank. (Look at the following pictures A3 – A4).
A tolerance of +/- 6 % is allowed. It is very important to check the voltage level also during the appliance operation, keeping in mind that a lower
voltage than the allowed tolerance may cause serious damage to the system. Insert the plug in a monophase grounded socket, this socket must
be permanently accessible to allow the disconnection of the appliance at any time. Grounding is not only a safety standard but is also compulso-
ry by law.
The manufacturer declines all responsibility whenever this safety precaution standard is not observed.
Do not insert more plugs together when using extension cord. The plug must have sucient space from the back of the display and be on sight.
Donotsprayliquidsorammablegasesdirectlyinsideorneartheappliancewhenpluggedin.
Check the power cord for signs of wear or abrasion along the coating and make sure that the plug is not damaged. If the power cable is
damaged, require its immediate replacement to the manufacturer or to the service center. While moving the unit, please pay attention not to
squeeze or damage the power cord.
Do not touch the power plug with wet hands.
Failuretotakesuchaboveprecautionsmaycausedamagetopersonsorpropertiesduefromelectricshockorre.
If the appliance generates a strange noise, a burning smell, or smoke, unplug immediately the power plug and contact the service center.
If extraneous substances, such as water should penetrate in the appliance, unplug the plug from the socket and contact your service center.
Failuretodosomaycauseelectricshockorre.
OTHERSAFETYINFORMATION
This unit was designed and manufactured in compliance to current standards and all safety measures have been employed. However, residual
risk remains:
• Beawareofprotrudingcornersandedgesnearthecompressorandcondenserthatmaycausecuts.
• Allmovingpartsaresafeguardedandautomaticallystartedandstopped.Itishoweverrecommendedtodisconnectpowerbeforeperform-
ing maintenance and cleaning.
• Iftheapplianceisnottobeusedforalongperiod(morethan3weeks)removeallbottlesandswitchito.
• Beforecleaningandmaintenanceisrecommendedtodisconnectedtheapplianceandwaitafewminutes(IncompliancewithE.D.2006/42/EEC)
Theshowcasemustbeinstalledonaevenandlevelledoor,itispossibletoadjustthelevelingfeetuntilitisabsolutelystable.Failuretocomply
withthisprecautioncancausetheoverturnoftheunitsandcausepropertydamageandpersonalinjury.
Do not use the appliance for other purposes than those for which they were designed and produced, and in general, dierently from as shown
in this manual. The appliance should not be used by people with reduced physical, sensory or mental capacity, unskilled persons or who lack
proper knowledge and children unless there is no one person responsible for their safety to provide them with proper supervision and instruc-
tion for use. Cleaning and maintenance must not be performed by children without the supervision of a responsible.
Keep the lock keys away from children and not near to the unit.
Donotleavethedoorsoftherefrigeratedcabinetopenwithoutsupervisionanddonotallowchildrentogetinsideastheymaybeinjuredor
die by suocation.
Keep packaging materials away from children; if a child puts his head in a plastic bag, he risks suocation and death. Do not allow children and
/oradultstositorhangondoors.Otherwisetheunitcouldfall,doorsbeendisengagedandglassbebroken,eventsthatcouldleadtoinjuryor
property damage.
Donotplaceanyobjectunderorabovetheunit,becauseduringtheopeningandclosingofdoors,objectscouldfallandcausepersonalinjury,
property damage, electric shock or re.
Do not make any changes or modications since a dierent conguration could result in damage to property or persons. Expo Srl cannot be
held liable for safety issues and damages resulting from such changes.
The warnings and safety instructions in this manual do not cover all possible conditions and situations that may occur, therefore it is the user’s
responsibility to use the appliance with common sense, paying the utmost attention and care during installation, maintenance and operation.
Since these instructions cover various product models, the characteristics of the purchased product may dier slightly from the ones described
in this manual.
3. INSTALLATION
If you have purchased the Parete Vino, please proceed with the installation as indicated in the“Installation instructions”delivered together with
the unit. The Teca is a product for free installation therefore do not require special assembly operations.
Forcorrectoperationtheunitshouldbeplacedinaplacefreeofexcessivemoisture,well-ventilatedandawayfromsourcesofheat,theambient
has to be with temperatures between 5 ° C and 30 ° C, avoiding exposure to direct sunlight, keeping it clean from dust or other sediments.
Any damage caused by failure of following these recommendations is not covered by the guarantee and is not in any way the manufacturer’s
responsibility.
ENGLISH

It is also recommended to place the appliance so it can be used under NORMAL lighting conditions(dened as 200 LUX) E.D. 2006/42/EECE
Placethedisplayonaevenandatsurface,ifneededregulatethefourfrontandrearlevelingfeettogetaperfectlevel.Importantforitscorrect
functioning and to allow the doors to close properly it is essential that it is perfectly level.
The installation and any maintenance operation on the equipment must be performed by a qualied technician or a service center.
Never connect the plug to an ungrounded socket and always check that its grounding is conform to the applicable local rules.
Donotinstalltheapplianceinaplacesubjecttogasleaks.
Whenmoving,inordertopreventdamagetotheoor,makesurethelevelingfeetareraised.
The display should not be placed outside or exposed to direct sunlight.
Once placed in the nal position, leave the showcase turned o at least 4 hours, this reduces the possibility of malfunction of the refrigerating
system due to transport and handling.
• Inserttheplugintothewallsocket(seeelectricalsystemsafety)
• Tostartoperatingtheapplianceactonthemainswitchlocatedunderthedisplayontherightside(TECA)oronthefrontlowerside(PARETE)
• Turnonthedisplaybypressingthepowerbuttonofthecontroller( ) (see legend of key symbols)
• Letthemachinerunemptyforatleasttwohoursbeforeinsertingbottles/food
• Atthebeginningtheunitmightbenoisy;gradually,lettingthemachinerun,thenoisewilldecrease
• Thecompressorwillstartautomaticallyafterafewminutes,iftheunitisturnedoandimmediatelyturnedonagainorwhensettingtemper-
ature, the compressor stops and starts automatically after a few minutes
• Toconnectthelightsofthetopunit“B”ofthePareteVino,connectthecablesandbringtheexcessofthecableintothetechnicaltankofthe
lower unit“A”.
The central refrigeration system with which the unit is equipped (5.3) works with a ventilated condensation system. The ventilation - meaning
the hot air expulsion and the suck of the fresh ambient air - is carried out in the lower part of the display, exactly in the space where the 8 cm
feetareinstalled.ITISSTRICTLYFORBIDDENTOCLOSEOROBSTRUCTTHISSPACE.
Not following the above instruction, not only creates a signicant increase of consumption but can lead to serious malfunction or accident and
is considered as improper use, faulty installation or tampering and therefore will INVALIDATE THE PRODUCT WARRANTY.
Theupperunit(P*-VBR10)needsagreaterspacetoensuresucientaircirculation.
Failuretocomplywiththeabovesuggestioncouldaectthegoodoperationoftheunitandincreasetheelectricconsumption.
The showcase must be installed in order to allow easy movement for maintenance and cleaning operations.
4. USE AND MAINTENANCE
Warning: unplug the appliance before performing any maintenance or cleaning.
Do not store in the refrigerated display any product that requires strict controls of temperature such as medicines, scientic material or in general
all those products sensitive to slightest temperature variations.
The units for gastronomy or delicatessen products are showcases designed for refrigerated display and are not suitable for food storage. The
food must be kept inside for the period needed for presentation and sale.
If there is excessive condensation inside the showcase, turn o the appliance, empty it and wait for an hour. Dry the inside excess moisture and
leave the doors open. Leaving to much humidity inside may cause unpleasant odors and mold can develop.
Do not use wet sponges or spray cleaning products directly on the display. To clean, use a slightly moistened soft cloth or paper.
Do not clean the unit spraying water above it. Do not use aggressive chemical products, benzene or solvents as they may damage the unit.
WARNING : the maintenance operation must be performed exclusively by skilled technicians.
The refrigerating gas used are R134a - R404A - R600a.
To verify the type and quantity of gas used for each unit please check the label located underneath the internal aluminium lid (A4), the label on
the compressor or the lable on the conformity declaration shown at the bottom of this manual.
Regularly it may be necessary to clean the condenser with a brush, vacuum cleaner or blowing compressed air. It might be useful to remove the
fanthatisplacedabovecondenser.Thecleaningfrequencydependsonthesiteconditionsandinparticularbytheregularcleaningoftheoor
and can vary from 6 months to 2 years.
The condenser is located in the bottom base on the right lateral side (A5). To access the technical compartment follow the instructions below:
A5 . Condenser compart-
ment
A1 . Extract the plastic clips
from the right hand side on
the alluminium rods
A2 . Move towards left 3
rows of rods or unscrew
them (Depends on the
model)
A3 . Remove the aluminium
panel
A4 . Remove the lid under-
neath the panel by unscrew-
ing the screws
4.1 USER
4.2 TECHNICAL ASSISTANCE
ENGLISH
CAUTION
DO NOT CLOSE THE 8 CM ( 3,15 IN ) SPACE UNDERNEATH THE BASE. ALSO THE PARTIAL CLOSURE WITH INHIBIT THE VENTILATION.
FAILURE TO COMPLY THESE INSTRUCTIONS INVALIDATE THE WARRANTY.
LEAVE THIS SPACE FREELEAVE THIS SPACE FREE

5. OPERATION
Valid for all models except:
5.1 THERMOREGULATOR AND TEMPERATURE SETTING
Start/Stop appliance
Turn lights on/o
To view / edit the setpoint
 Formanualdefrosting
To decrease temperature
To increase temperature
To turn on the heating element on the frame/ rails
To switch on the inside fan
KEYS FUNCTION ON THE CONTROL PANEL
MEANING OF THE WARNING SYMBOLS ON DISPLAY
Compressor on
Light on
Defrosting on
 Frameheatingon
Inside fans on
Temperature alarm
(ON) Actual temperature
  (FLASHING)Setpointinprogress
+4 / +16 °C +4 / +16 °C
+16 °C +16 °C
+8 °C +12 °C
+12 °C +12 °C
+8 °C +8 °C
+4 °C +4 °C
+4 °C +6 °C
POSSIBLE SETTINGS
SUGGESTED SERVING TEMPERATURES OF WINE
4 °C 4 °C
SET SET
OFF OFF
+14 / +16 °C +14 / +16 °C
14 °C 14 °C
SET SET
ON ON
+4 / +8 °C +6 / +12 °C
4 °C 6 °C
SET SET
ON ON
SETTING THE TEMPERATURE
To set the desired temperature press . The symbol willstartashing.Pressthekeys to set the temperature.
Press again the key to conrm your choice.
The temperature shown on the display is taken by the probe located inside the cabinet at the bottom of the central aluminum panels.
MANUALDEFROST
The product is equipped with an automatic defrost system, therefore no manual intervention is required.
If you wish to perform an additional manual defrost, press and hold for at least three seconds the key in order to stop the cooling for
fteen minutes. After this stop the appliance will run again the normal operation with the previously programmed temperatures.
Structured red wines
Young red wines
White and rosé wines
Sparkling wines
+18 / +20 °C
+14 / +16 °C
+10 / +12 °C
+6 / +8 °C
The temperature controller of wine units can be set to dierent
temperatures with or without ventilation directly by the user,
allowing to choose the right conservation or service temperature
for all types of wine.
Please remember that the bottom part of the showcase is always
few degrees lower than the upper part, fact that has to be
considered when choosing the position of the dierent wines.
Reported temperatures are approximate and may vary by ( + - ) 2 ° C depending on the model chosen (Wine Showcase, Gastronomy, Delicatessen)
PARETE TECA
ENGLISH
TA 30°C TA 25°CTA 35°C TA 30°CTA 30°C TA 25°C

To view / edit the setpoint
To decrease temperature
To increase temperature
KEYS FUNCTION ON THE CONTROL PANEL MEANING OF THE WARNING LIGHTS
Compressor on
Defrosting on
(ON) Actual unit temperature
  (FLASHING)Setpointinprogress
SETTINGS
5.2 HEATED FRAME AND RAIL
Anheatingelementisinstalledonalltheshowcases(Parete->Frame)(Teca->Rail)whichcanbeactivatedwiththeAUXkeyonthe
thermo-regulator (excluding models with )
This technical device solves the problem of condensation on the metal parts due to the dierence of temperature between the
inside of the showcase and the ambient temperature, especially in places with very high temperature and humidity.
It is very important to use this feature in tropical countries and marine locations because even a small presence of condense for long
periods may damage the external decorative coating of the showcase.
In locations with continental climate with normal temperature and humidity conditions it is not necessary to use this device. The
same goes for the showcase set at the storage temperature (+14 +16 °C).
The temperature controllers of all the showcases are blocked so that the user cannot set lower temperatures than those planned PARETE VINO
+3°C(excludingP*VBR10andCAR10-20+12°C)TECA+4°C(excludingTC10-20+12°C).Itisnotallowedtoenterthehiddenparameters
andmodifythesevalues.Theshowcasesarenotdesignedandbuilttooperateatlowtemperatures.Failuretocomplywiththisprovisionwill
invalidate the warranty.
If the display shows the warning light it shows that the temperature detected by the second probe placed on the condenser has exceed-
ed the safety limits set by the manufacturer. The reasons may be as follows:
• Thespaceatthebottomoftheunit(8cm)wasblocked,preventingtheairexchange.
• Theambienttemperatureandhumidityaretoohigh.
• Thecondenseriscompletelyblockedwithdust,compromisingtheventilation.Cleanitasindicatedinsection4.1.
TheunitP*-VBR10canbeusedforstoringwineorforkeepingatservingtemperatureonlyredwines.Youcannotsettemperatureslowerthan
the indicated one.
INSIDE VENTILATION
TheinternalfansofP*-VBR10unitsareconnecteddirectlytothegeneralswitch,theydonotneedtobeoperatedbytheuserandduringtheir
operation no warning light is shown on the display.
TURNING THE LIGHTS ON
Thelightsoftheupperunit“B”lightuptogetherwiththelowerunit“A”bypressingtheKeyoncontrollerofthe“A”unit.Ifyouwanttokeepo
thetopunit“B”whilethe“A”unitisonyoumustactmanuallyontheswitch(I-O)oftheupperunit“B”,placednexttothecontroller.
MINIMUM ADJUSTABLE TEMPERATURE
CONDENSER TEMPERATURE ALARM
P*CAR10 / P*CAR20 / P*CDR20 / TC10 /TC20
PM-VBR10/PC-VBR10/PM-VBR13/PC-VBR13
The refrigerated unit for chocolate always works with ventilated refrigeration and the controller does not have the keys and which
are not needed.
The inside humidity is always less than 45% thanks to the conformation of the aluminum panels covering the serpentine.
The moisture level cannot be set and is only viewable with a special controller OPT-TVU (optional).
+14 / +16 °C
TA 30°C
14 °C
SET
TA 25°C
+14 / +16 °C
14 °C
SET
ENGLISH

5.3 WIRING DIAGRAMS
5.3 CENTRAL COOLING SYSTEM
4
3
5
2
1
inside air ow
ambien air suction
warm air outlet
The cooling serpentine 1and the internal fans 2are located in the middle of the cabinet between the aluminium panels.
The compressor 3, the horizontal condensing unit with the fan with pressing blade 4and the basin for the evaporation of
the condensation water 5are placed in a special lowered tank. With this solution, although installing a standard compressor,
the height of the base is limited (150 mm) since it is used the lower space where feet are located (80 mm). The circulation of the
condensation air is blown through the front bottom part.
OPTIONAL
OPT-EAP
Rear air expulsion ≥ 90 mm
STANDARD
OPTIONAL
OPT-PUR
Unit set for remote compressor connection
E F
reproduction, partielle ou totale, effectuée sans le consentement écrit de la Expò S.r.l. est strictement interdite
EXPO' S.R.L.
10092 BEINASCO ( TO ) ITALY
www. e x p o s r l . c o m
STRADA ANTICA DI NONE, 1 4
PROPRIETA' E RISERVATEZZA
Le informazioni contenute in questo disegno sono di esclusiva proprietà della Expò S.r.l.
Qualsiasi riproduzione parziale o totale effettuata senza il consenso scritto della Expò S.r.l. è vietata
PROPRIETARY AND CONFIDENTIAL
The information contained in this drawing is the sole property of Expò S.r.l.
Any reproduction in part or as whole without the written permission of Expò S.r.l. is prohibited
PROPRIÉTÉ ET INFORMATION CONFIDENTIELLE
Les informations contenues dans ce dessin font parties exclusivement de la propriété de Expò S.r.l. Toute
L
N
T
A
B
D
DA
E
F
H
HA
M
P
R
Linea
Neutro
Terra
Interruttore generale
Termoregolatore
Ventilatori assiali
Alimentatore
Compressore
Ventilatore condensatore
Strisce led
Alimentatore
Sonda
Interruttore luci
Connessione terra
Phase
Neutral
Ground
Main switch
Thermoregulator
Axial fan
Power supply
Compressor
Condenser fan
Led strips
Power supply
Probe
Ground connector
Ligne
Neutre
Terre
Interrupteur général
Thermoregulateur
Ventilateur axial
Transformateur
Compresseur
Ventilateur condensateur
Bandes led
Transformateur
Sonde
Connecteur de terre
Linie
Neutral
Erdung
Generalschalter
Thermoregler
Axial Lüfter
Zuführer
Kompressor
Ventilator Kondensator
Led Streifen
Zuführer
Sonde
Masseanschluss
Linea
Neutral
Masa
Interruptor general
Termorregulador
Ventiladores axiales
Unidad de alimentación
Compresor
Ventilador condensador
Tiras de Led
Unidad de alimentación
Sonda
Connexión a masa
OBJECT: SCHEMA ELETTRICO
ELECTRIC DIAGRAM
CODE: P* VBR10 (SE)
DESIGNER: P 03 REV: 22.06.2016
DIXELL - XW60L
DIXELL - XR02CX
B
9 8 7 6 4 123
B
112 11
T1
T1
T2
T3
T3
HA
M
L
A
D
X
N
T
H
220V
240V
50Hz
R
P
L
X
N
T
DA
ValidforallmodelsexceptPM-VBR10/PC-VBR10 PM-VBR10/PC-VBR10
reproduction, partielle ou totale, effectuée sans le consentement écrit de la Expò S.r.l. est strictement interdite
EXPO' S.R.L.
10092 BEINASCO ( TO ) ITALY
www. e x p o s r l . c o m
STRADA ANTICA DI NONE, 1 4
PROPRIETA' E RISERVATEZZA
Le informazioni contenute in questo disegno sono di esclusiva proprietà della Expò S.r.l.
Qualsiasi riproduzione parziale o totale effettuata senza il consenso scritto della Expò S.r.l. è vietata
PROPRIETARY AND CONFIDENTIAL
The information contained in this drawing is the sole property of Expò S.r.l.
Any reproduction in part or as whole without the written permission of Expò S.r.l. is prohibited
PROPRIÉTÉ ET INFORMATION CONFIDENTIELLE
Les informations contenues dans ce dessin font parties exclusivement de la propriété de Expò S.r.l. Toute
L
N
T
A
B
C
D
DA
E
F
H
HA
M
P
Q
R
Linea
Neutro
Terra
Interruttore generale
Termoregolatore
Resistenza telaio
Ventilatori assiali
Alimentatore
Compressore
Ventilatore condensatore
Strisce led
Alimentatore
Sonda
Sonda condensatore
Pressostato
Connessione terra
Phase
Neutral
Ground
Main switch
Thermoregulator
Frame resistance
Axial fan
Power supply
Compressor
Condenser fan
Led strips
Power supply
Probe
Condenser probe
Pressure switch
Ground connector
Ligne
Neutre
Terre
Interrupteur général
Thermoregulateur
Résistance du châssis
Ventilateur axial
Transformateur
Compresseur
Ventilateur condensateur
Bandes led
Transformateur
Sonde
Sonde condenseur
Interrupteur de pression
Connecteur de terre
Linie
Neutral
Erdung
Generalschalter
Thermoregler
Rahmen Widerstand
Axial Lüfter
Zuführer
Kompressor
Ventilator Kondensator
Led Streifen
Zuführer
Sonde
Kondensatorsonde
Druckschalter
Masseanschluss
Linea
Neutral
Masa
Interruptor general
Termorregulador
Resistencia marco
Ventiladores axiales
Unidad de alimentación
Compresor
Ventilador condensador
Tiras de Led
Unidad de alimentación
Sonda
Sonda condensador
Interruptor de presión
Connexión a masa
OBJECT: SCHEMA ELETTRICO
ELECTRIC DIAGRAM
CODE: TV-PV 115 (SE)
DESIGNER: P 03 REV: 22.06.2016
DIXELL - XW60L
B
19 18 17 16 15 14 13 134567812 91011
T1
T1
HA
M
L
A
C D
X
N
T
H
115 - 120 V
60 Hz
R
PQ
E F
DA
solo
modelli
115 V
ENGLISH

6. DISPOSAL OF END-OF-LIFE EQUIPEMENT
In accordance with art.13 of Legislative Decree of 25 July 2005, n.151“Implementing Directives 2002/95/CE, 2002/96/CE and 2003/108/CE, concerning the
reduction of the use of hazardous substances in electrical and electronic equipment, as well as waste disposal”.
At the end of its life cycle the product must be disposed separately from other waste.
Illegal disposal of the product by the owner involves the application of administrative sanctions provided by law.
This product complies with D.E. 2002/96/CEE RAEE e 2002/95/CEE RoHS
The symbol on the product and manuals indicates that the product at the end of the life cycle should not be disposed with other waste.
To prevent possible harm to the environment or human health caused by the incorrect disposal of waste, the user is encouraged to give this product to
authorized persons in accordance with local regulations.
Foralltheinformationaboutseparatecollectionofthistypeofmaterials,thehouseholdusersshouldcontacteitherthedealerfromwhomtheyacquired
the product or the competent authority.
Professional users (companies and professionals) should contact their supplier and check the terms and conditions of the purchase contract. This product
and its electronic accessories should not be disposed with other commercial wastes
Problem Potential cause Solution
The unit display does not
turn on
The unit is disconnected Check the connection to the wall socket
Check the power supply on the socket
General switch deactivated Turn on the main switch
Faultythermoregulator Contact the technical assistance center
The unit does not cool
enough
The ambient temperature is too high Eliminate the cause
The doors get frequently opened Eliminate the cause
The doors are not completely well closed Pay attention to complete and correctly close the doors
The showcase is exposed to sunlight Place in a cool and well-ventilated room
The thermoregulator isn’t set correctly Check the set-point of the thermoregulator
An excessive amount of products is kept in the display Do not ll excessively the showcase
AU2 Alarm – The space under the unit has been blocked Freethisspacetoallowaproperventilation
AU2 Alarm – The ambient temperature is too high Eliminate the cause
The cooling system is broken Contact the technical assistance center
Badsmellinsidethedisplay Presence of rotten food or food with strong odors Clean the display internally and remove food residues
Placing food in airtight containers
Hearing some noise
The display does not stand on an even surface Carry out a proper installation
Something dropped behind or underneath the showcase Checkandremovetheobject
Clicking sound coming from the inside It is normal, it is due to the expansion of some elements
The upper part is not cold Inside fans are o Switch on the internal fan button on the thermo-regulator
Inside fans are broken Contact the technical assistance center
Condensation on doors,
rails or frame
Ambient humidity is very high Eliminate cause or switch on the frame heating
The set temperature is too low Raise the temperature
The door was left open Carefully check that the doors are closed
The doors do not close properly The display does not stand on an even surface Leveltheshowcasebyadjustingthelevellingfeet
Any led lights turns on The lights key is o Switch on the lights key
Power supply or controller are faulty Contact the technical assistance center
A single led strip or a part
of it does not work The led strip is faulty Contact the technical assistance center
Maintenance and repair work must be performed by qualied personnel.
Beforecarryingoutanyoperationdisconnecttheshowcasefromthesocket
The following documents are available on the internet website www.exposrl.com
Document type Browser link File name
Exploded view www.exposrl.com >> technical area >> Spare parts and exploded views
PARETE1(EV)
PARETE2(EV)
TECA1(EV)
TECA2(EV)
Wiring diagram www.exposrl.com >> technical area >> electric wiring PARETE-A (SE)
PARETE-B(SE)
User instructions www.exposrl.com >> technical area >> user instructions PARETE-TECA (MI)
Assembling instructions www.exposrl.com >> technical area >> assembly instructions PARETE-A (IM)
PARETE-AB(IM)
6. PROBLEM SOLUTION GUIDE
Forinformationorassistancerelatedtotheuseoftheproductwriteanemailto:[email protected]
ENGLISH
