1 General
1.1 About this Installation and User Guide
This Installation and User Guide refers exclusively to the SCYLAR INT 8 calculator and is part of the
product. It describes how to use this product safely for the intended purpose throughout the product
life cycle.
1.1.1 Target groups
Operators
The operator must ensure that personnel using the calculator read and observe the instructions given
in this guide and all necessary associated documents, particularly the safety instructions and warning
signs.
Trained personnel/users
Trained personnel must read, observe and follow the instructions given in this guide and the
necessary associated documents, particularly the safety instructions and warning signs.
1.1.2 Subject to change, validity
The information contained in this Installation and User Guide is valid at the time of release of this
version. The version number and release date of this Installation and User Guide are shown on the
back of the document. Changes to this guide are possible at any time.
1.1.3 Completeness
This Installation and User Guide is only complete in conjunction with the relevant associated
documents for the respective application.
1.1.4 Storage location
This Installation and User Guide and all relevant associated documents for the respective application
must be readily available and accessible at all times in the vicinity of the calculator or the overriding
system.
1.1.5 Warning signs
The warning levels indicated by the warning signs are explained below.
Signal word
Level of danger
Consequences of non-compliance
DANGER
Direct threat of danger
Death or serious injury
WARNING
Possible threat of danger
Death or serious injury
CAUTION
Possible dangerous situation
Slight injuries

Diehl Metering GmbH
Industriestraße 13
91522 Ansbach
Telefon [phone]
Telefax [phone]
[email protected]
Am Weimarer Berg 3
99510 Apolda
Telefon [phone]
Telefax [phone]
www.diehl.com/metering
Sitz der GmbH: Ansbach
Registergericht:
Ansbach HRB 69
Ust.-IdNr.:
DE 131 940 360
Geschäftsführer:
Frank Gutzeit (Sprecher)
Dr.-Ing. Robert Westphal
Thomas Gastner
Adam Mechel
HypoVereinsbank Ansbach
BLZ: 765 200 71
Konto: 5 503 108
SWIFT-BIC: HYVEDEMM406
IBAN: DE31765200710005503108
Seite 5 von
61
1.1.6 Symbols
The symbols used in this Installation and User Guide are explained below.
Symbol
Meaning
This symbol is the safety sign. All measures marked with the safety sign must be
observed. It is used on warning signs.
This symbol is a safety sign indicating that the ESD (electrostatic discharge)
regulations must be observed. It is used on warning signs.
This symbol draws attention to information.

This symbol indicates a requirement that must be fulfilled before taking action.
1. , 2. , …
These numbers indicate the steps in a sequence of numbered actions.

This symbol shows the instructions for avoiding danger in a warning instruction or an
individual step.
1.2 Marking
1.2.1 CE marking
This product bears the CE marking, the metrology marking and the identification number of the notified
body. See Section 3.
1.2.2 EC declaration of conformity
The calculator complies with the directives and standards for MID-approved meters as stated in the
EC declaration of conformity. The EC declaration of conformity contains the number of the EC type
examination certificate. A copy of the EC declaration of conformity can be found at the end of this
document.
1.3 Copyright
© 2012 Hydrometer GmbH
All rights reserved.
No part of this Installation and User Guide may be reproduced in any form whatsoever (printing,
photocopying or other process) or processed, reproduced or distributed by means of electronic
systems without our written consent. Claims for damages will be asserted in the event of
contravention.
Subject to change.

Diehl Metering GmbH
Industriestraße 13
91522 Ansbach
Telefon [phone]
Telefax [phone]
[email protected]
Am Weimarer Berg 3
99510 Apolda
Telefon [phone]
Telefax [phone]
www.diehl.com/metering
Sitz der GmbH: Ansbach
Registergericht:
Ansbach HRB 69
Ust.-IdNr.:
DE 131 940 360
Geschäftsführer:
Frank Gutzeit (Sprecher)
Dr.-Ing. Robert Westphal
Thomas Gastner
Adam Mechel
HypoVereinsbank Ansbach
BLZ: 765 200 71
Konto: 5 503 108
SWIFT-BIC: HYVEDEMM406
IBAN: DE31765200710005503108
Seite 6 von
61
2 Safety
NOTE
Observe the following requirements before carrying out work of any kind.
2.1 Intended use
The calculator is used for recording all billing data for local and district heating and cooling.
2.1.1 Misuse
Operation of the calculator outside the specified operating and environmental conditions is not
permitted.
2.2 Basic safety instructions
2.2.1 Product safety
The calculator is produced to the latest state of the art and the recognized safety standards, but the
possibility of danger to the user, adverse effects on the calculator itself or on other property cannot be
ruled out.
Use the calculator only for the intended purpose in a fault-free condition with due regard for
safety and hazards and in compliance with this guide.
Keep this guide and all associated documents in a complete and legible state and accessible to
personnel at all times.
Avoid any kind of work that endangers personnel, persons not involved or third parties.
In addition to the complete documentation, observe all legal or other safety and accident
prevention regulations and the applicable standards and directives in the respective country of
operation.
2.2.2 Obligations of operator
Safe working
The operator of the system is responsible for ensuring that the calculator is used only for the intended
purpose with due regard for safety and hazards and in compliance with this Installation and User
Guide.
The operator must ensure and monitor compliance with the following:
that the meter is used for the intended purpose
legal and other safety and accident prevention regulations
applicable standards and directives of the country of operation
The operator must provide safety equipment.
Personnel qualifications
The operator must ensure that personnel working on the calculator have read and understood this
Installation and User Guide and all associated documents, particularly safety and repair instructions,
before commencing work.

Diehl Metering GmbH
Industriestraße 13
91522 Ansbach
Telefon [phone]
Telefax [phone]
[email protected]
Am Weimarer Berg 3
99510 Apolda
Telefon [phone]
Telefax [phone]
www.diehl.com/metering
Sitz der GmbH: Ansbach
Registergericht:
Ansbach HRB 69
Ust.-IdNr.:
DE 131 940 360
Geschäftsführer:
Frank Gutzeit (Sprecher)
Dr.-Ing. Robert Westphal
Thomas Gastner
Adam Mechel
HypoVereinsbank Ansbach
BLZ: 765 200 71
Konto: 5 503 108
SWIFT-BIC: HYVEDEMM406
IBAN: DE31765200710005503108
Seite 7 von
61
All work must be performed only by technically trained personnel:
installation and repair work
work on the electronic circuits
Safety equipment
Safety equipment must be provided if required.
E.g. install stop valves before and after the connected flow sensor to simplify removal and
installation.
Warranty
Obtain the manufacturer’s approval before carrying out modifications, repair work or changes
during the warranty period.
Use only genuine parts or parts approved by the manufacturer.
2.2.3 Obligations of trained personnel/user
Observe all instructions in the Installation and User Guide and on the device that are relevant to
handling the calculator.
Use safety equipment if necessary.
Always disconnect the calculator from the electrical supply before carrying out repair work.
2.3 Specific hazards
DANGER
Do not touch live parts during installation work.
Risk of serious injuries or death!
The calculator installation is only to be performed by an installation and/or
electrical contractor.
Personnel must be trained in the installation of medium-voltage electrical
equipment (up to 1000 V).
WARNING
Electrostatic discharge.
Risk of damage to calculator and particularly electronic components, for which
no liability is accepted!
Observe the relevant ESD (electrostatic discharge) regulations.
CAUTION
Electric and magnetic fields.
Risk of interference with electronic components in the calculator!
Do not install the calculator or the input/output cables near heavy electrical loads
or their cables.
Maintain the exact separation. This depends on the magnitude of the voltage and
current of these loads.
Consult a suitable expert in the event of doubt.

Diehl Metering GmbH
Industriestraße 13
91522 Ansbach
Telefon [phone]
Telefax [phone]
[email protected]
Am Weimarer Berg 3
99510 Apolda
Telefon [phone]
Telefax [phone]
www.diehl.com/metering
Sitz der GmbH: Ansbach
Registergericht:
Ansbach HRB 69
Ust.-IdNr.:
DE 131 940 360
Geschäftsführer:
Frank Gutzeit (Sprecher)
Dr.-Ing. Robert Westphal
Thomas Gastner
Adam Mechel
HypoVereinsbank Ansbach
BLZ: 765 200 71
Konto: 5 503 108
SWIFT-BIC: HYVEDEMM406
IBAN: DE31765200710005503108
Seite 8 von
61
3 Product description
3.1 Mechanical design
Fig. A Design of calculator
1 LC display
2 Pushbutton
3 Optical ZVEI interface
4 Laser labelling
3.2 Scope of delivery
The scope of delivery for the standard version includes the following:
Calculator
Wall mounting set incl. fixing material
Installation Guide
Installation kit for temperature sensors
1
3
2
4

Diehl Metering GmbH
Industriestraße 13
91522 Ansbach
Telefon [phone]
Telefax [phone]
[email protected]
Am Weimarer Berg 3
99510 Apolda
Telefon [phone]
Telefax [phone]
www.diehl.com/metering
Sitz der GmbH: Ansbach
Registergericht:
Ansbach HRB 69
Ust.-IdNr.:
DE 131 940 360
Geschäftsführer:
Frank Gutzeit (Sprecher)
Dr.-Ing. Robert Westphal
Thomas Gastner
Adam Mechel
HypoVereinsbank Ansbach
BLZ: 765 200 71
Konto: 5 503 108
SWIFT-BIC: HYVEDEMM406
IBAN: DE31765200710005503108
Seite 9 von
61
3.3 Labelling
The meter is labelled using a laser.
Fig. B Labelling (example)
1 Conformity mark
2 Year of declaration of conformity
3 EC type examination certificate number
4 Year of manufacture
5 Calculator serial number
6 Calculator article number
7 Calculator data
8 Product name
3.4 Functional description
The calculator is a fully electronic measuring instrument. It is equipped with a data memory that
enables comparison of the previous months’ readings with the current readings. The data measured
by the calculator are shown in the display. The display is provided with various windows as loop
functions that can be called up in succession to display the system information assigned to each
window (e.g. energy amounts, water amounts, current temperatures, maximum values).
The calculator has 6 display loops: main loop, accounting date loop, info loop, pulse input loop, tariff
loop and monthly value loop. The individual loops are described in Section 8 “Operation”. Some
windows in a loop and whole display loops can be deactivated separately to make the window
structure clearer.
Various display windows comprise up to seven displays that change at intervals of 2 –4 s.
The loops in the display are numbered from 1 to 6 to help the user find his way around quickly.
The main loop is programmed with the current data as default setting, e.g. for energy, volume, flow
rate and other parameters. It is not possible to change the order of the available data.
3
1
2
5
7
4
6
8

Diehl Metering GmbH
Industriestraße 13
91522 Ansbach
Telefon [phone]
Telefax [phone]
[email protected]
Am Weimarer Berg 3
99510 Apolda
Telefon [phone]
Telefax [phone]
www.diehl.com/metering
Sitz der GmbH: Ansbach
Registergericht:
Ansbach HRB 69
Ust.-IdNr.:
DE 131 940 360
Geschäftsführer:
Frank Gutzeit (Sprecher)
Dr.-Ing. Robert Westphal
Thomas Gastner
Adam Mechel
HypoVereinsbank Ansbach
BLZ: 765 200 71
Konto: 5 503 108
SWIFT-BIC: HYVEDEMM406
IBAN: DE31765200710005503108
Seite 10 von
61
3.5 Power supply
Possible power supplies:
A cell, 3.6 V DC lithium battery, with a lifetime of 11 years (standard version, with radio)
D cell, 3.6 V DC lithium battery, with a lifetime of 20 years
Mains unit 24 V AC
Mains unit 230 V AC
Fig. C Power supplies
1 A or D cell, 3.6 V DC lithium battery
2 Mains unit 24 V AC / 230 V AC
The various power supplies can be changed in the field.
NOTE
The calculator switches automatically to power save mode if the button is not
pressed for approx. 4 minutes. The display is also switched off in this case, but can
be switched on again by pressing the button. Communication is maintained, e.g.
over the M-Bus or the optical interface. The calculator does not switch to power save
mode if an error exists. The error is shown in the display as an error code.
Never connect between two phases if a mains unit is used, as this would destroy the
mains unit. The protective safety cover must be installed at all times. The cable is to
be fused at max. 6 A and protected against manipulation.
Used batteries must be disposed of at suitable collection points.
1
2

Diehl Metering GmbH
Industriestraße 13
91522 Ansbach
Telefon [phone]
Telefax [phone]
[email protected]
Am Weimarer Berg 3
99510 Apolda
Telefon [phone]
Telefax [phone]
www.diehl.com/metering
Sitz der GmbH: Ansbach
Registergericht:
Ansbach HRB 69
Ust.-IdNr.:
DE 131 940 360
Geschäftsführer:
Frank Gutzeit (Sprecher)
Dr.-Ing. Robert Westphal
Thomas Gastner
Adam Mechel
HypoVereinsbank Ansbach
BLZ: 765 200 71
Konto: 5 503 108
SWIFT-BIC: HYVEDEMM406
IBAN: DE31765200710005503108
Seite 11 von
61
3.5.1 Battery
A 3.6 V DC lithium battery is fitted in the standard version. The battery is not to be charged or short-
circuited. Ambient temperatures below 40 °C extend the life of the battery.
DANGER
There is a risk of explosion if the battery is replaced with the wrong type of
battery.
3.5.2 Overview of the measuring rates
The following table shows the lifetime of the batteries depending on the standard measuring rates.
Customer versions can differ from the standard measuring rates in the measuring rate and battery
lifetime.
1: Specification in the data sheet, calculation of the value in brackets
2: Specification in the data sheet, calculation of the value in brackets, 20 years for radio off, 18 years
for radio on
Battery
lifetime
[Years]
Radio sending
interval
Measuring rate
(independent of radio)
A-Cell
Measuring rate
without radio/without modules
12
-
Volume
Temperature
1s
16s
868MHz
11
120s
434MHz
11
120s
D-Cell
Measuring rate
without radio
161(20)
-
Volume
Temperature
1s
4s
868MHz
161(20)
12s
434MHz
161(20)
12s
Mains unit
Measuring rate
without radio
unlimited
12s
Volume
Temperature
1/8s
2s
868MHz
unlimited
12s
434MHz
unlimited
12s
