DIG 410BT Series User manual

INSTRUCTION MANUAL
410BT Series Bluetooth®
Battery Powered Irrigation Controller
410BT-000 | 410BT-075 | 410BT-100 | 410BT-150 | 410BT-200
FCC certied | Bluetooth® certied | Waterproof | 3-year Limited Warranty

1
1. INTRODUCTION
Thank you for purchasing DIG’s 410BT Single Station Battery Operated
Controller. This manual describes how to get the 410BT series
controller up and running quickly. After reading this manual and
becoming familiar with the basic functionality of the controller, use the
manual as a reference for less common tasks in the future.
2. ABOUT THE 410BT BATTERY OPERATED CONTROLLER
The 410BT series irrigation controller employs the latest in Bluetooth®
technology using the free DIG BTT app for Android™ or iPhone®.
The 410BT is available as a single station battery operated controller
and is powered by two AA batteries that can last up to one year using
name brand alkaline batteries. The controller is enclosed in a compact,
waterproof housing to protect it from degradation.
3. COMPONENT IDENTIFICATION
Two AA batteries
(not included)
One button
for manual
run and reset
Lid
Battery Compartment Cap
Solenoid

2
4. INSTALLING THE BATTERIES
1. Open the battery compartment cap by turning it counterclockwise.
2. Install two fresh, brand name, AA alkaline batteries (not included)
and note the proper direction of the positive and negative
orientation on the underside of the controller.
3. Insert and screw the battery cap clockwise. Make sure to securely
tighten the cover rmly by hand only. The controller will now appear
on the smartphone app and is ready to be connected to and
programmed.
5. VALVE ADAPTER INSTALLATION
The 410BT series controller includes three adapters to retrot Rainbird,
Hunter and Toro valves. Follow the instructions below to install.
1. Shut off the main water supply
2. Remove the existing solenoid if applicable.
NOTE: If adapting to an IRRITROL valve, remove the solenoid but
leave the existing solenoid adapter installed.
3. Select the appropriate solenoid adapter associated with the valve.
(see chart A)
4. Screw the solenoid adapter into the valve bonnet by hand, tighten
with pliers if necessary – but do not over tighten.
5. Thread the 410BT series solenoid into the valve adapter. Hand
tighten only.
6. Turn the main water supply on and pressurize the valve; the valve
may discharge water momentarily but should then shut off.
7. Test the controller and the installation by pressing the button on
the controller or see pages 11-12 on how to perform a manual run
through the app. To turn the valve on via the solenoid, lift the
410BT series controller from the solenoid and turn the solenoid

3
counter clockwise 1/2 to 3/4 of a turn, or until you hear or see water
owing through the valve. To turn the water off, turn the solenoid
clockwise 1/2 to 3/4 of a turn and wait a few seconds for the
valve to close.
8. Program the 410BT series controller (see pages 4-12).
6. IN-LINE VALVE INSTALLATION
Rated operating pressure: 10-125 PSI
Recommended Operating Pressure: 10-80 PSI
Warning: Wrap all ttings with Teon tape! Do not use pipe cement on
ttings or the valve as this will damage the valve and void the warranty!
1. Shut off main water supply.
2. Install a 3/4″ball or gate valve onto the PVC pipe or to the valve
manifold before installing the controller (Figure 6a and 6b).
CHART A
Model Compatible Valves
30-920 BERMAD series 200, HIT series 500,DOROT series 80,
GRISWOLD series2000, DW and BUCKNER series VB valves
30-921
INCLUDED
RAIN BIRD DV, DVF, PGA, PEB (1″only),GB, EFB-C P,
BPE, PESB (1″only)and ASVF valves
30-922
INCLUDED
HUNTER series ASV, HPV, ICV,PGV, SRV, IBV and
ASVF valves
30-923 WEATHERMATIC series 12000, 21000, 8200CR valves
30-924
INCLUDED
IRRITROL series 100, 200B, 205, 217B,
700, 2400, 2500, 2600 and TORO series 220, P220 valves
30-925 SUPERIOR series 950, HUNTER HBV and TORO series
252 valves (1.5″and larger)

4
3. Turn water supply on to ush the line and then shut the water off
using the ball or gate valve.
4. Wrap the male threads of the PVC adapters with 4-6 layers of Teon
tape, then tighten into the valve with a wrench.
5. Glue ttings to PVC main line and allow to dry.
6. Turn water supply on to pressurize the system. The controller will
open momentarily and then will shut off.
7. The unit is now ready to be programmed
7. PROGRAMMING
• Download the DIG BTT app using the iOS App Store, Google Play, or
the QR code on the box.
• Open the DIG BTT app from your smartphone or tablet and use the
instructions in the App Screens Overview to program and operate
the controller.
Figure 6a
Above-ground installation
Below-ground installation
ow
Figure 6b

5
APP SCREENS OVERVIEW
The DIG BTT app automatically scans for nearby controllers after
installation. Any DIG Bluetooth® controllers within 50′(15 meters) line
of sight will appear on screen.
• Your new controller will appear as the BT Controller. Its
default image, status (watering -on- or not watering -off-),
connection strength, and battery life will appear alongside it.
• Tap on the controller to connect to it and start programming.
You can access Connection History and Contact Us through the
information icon in the top right corner of the screen.
• The Connection History allows you to see every controller and
timer connected to from this phone or tablet. It stores the data
it last received from each tap timer, but no editing can be done.
Deleting an entry will remove all the saved data for that unit. Any
passwords and/or pictures need to be reentered. To delete an entry,
tap it and select the trash icon.

6
Information icon
Default image
Controller name
Last run
information
Battery life
Connection
strength
Indicates if
controller is
currently
runnning
or not

7
HOME SCREEN
Once connected, the Home screen will appear. This screen has
everything needed to program the controller.
By default, the controller’s Program is off. To turn it on, push the switch
under the “Program” area. It will turn green and the Program area will
light up indicating that the program is active and can now be modied.
The controller is now ready to be programmed. Simply select the
schedule (weekly, even/odd, or cyclical), set your start date or days, add
times, and set a duration. The controller is updated immediately each
time a button is tapped.

8
Schedule
Overview:
Shows a chart
with current
program run
times. Red
lines indicate
that there is
an overlapping
start time
Activate or
deactivate
the program
Program
schedule
Weekly days
settings
Up to ve start
times. Select an
existing start
time to edit/
delete.
Red start times
are overlapping
and will not run
Run time for
valve
Home
(current page)
Controller
settings
Manual run
Picture of
controller

9
CONTROLLER SETTINGS
The controller’s Settings screen contains everything else needed to
fully control your irrigation system. It can be reached by selecting the
Controller Settings button on the bottom of the screen. On this
screen you can turn on or off the entire system through the System
Active switch, add a rain delay to shut off the controller for a limited
time, budget each month to modify the watering duration based on the
season, set specic dates on which the timer should not run, and view
12-month history of the controller.
Use the settings menu to rename the controller to something
memorable and upload a picture for easy and fast recognition for future
viewing. Set a password to prevent unallowed users from connecting to
your timer. The password is saved to the phone so it will (almost) never
have to be entered again (unless it’s changed or when connecting to the
timer with a new phone).

10
Turn the entire
system on/off.
Controller will
not water when
system is off
Set a rain
delay
Set up to nine
dates where
the controller
will prevent
watering
Set name of
the controller
Set password for controller. Password will only be seen
when entering controller from a new phone. Reset
controller to reset password if forgotten
Budgeting
per month
(affects duration
only)
View monthly
watering
history for the
past 12 months
Set picture for
the controller

11
MANUAL RUN
The Manual Run screen allows for manual operation of the controller. It
can be reached by selecting the Manual Run button on the bottom
right of the screen.
To manually run the controller, tap the button on the right of the
screen. This button can also be used to stop any existing run. The
default manual run time is for ve minutes; this can be changed by
tapping on the time and changing it.
The controller can also manually run from the controller itself by
tapping the water droplet button . The duration of this manual run
is equal to the duration of the scheduled program. The button can also
be used to end any watering.

12
Start/Stop
Manual Run
Set
Manual Run
duration
Manual Run

13
RESET TO FACTORY DEFAULTS
• Press and hold the button on the 410BT for 15 seconds. This will
remove all app settings, historical information, and any set passwords.
This is the only way to remove a password so try not to forget it!
TECHNICAL ASSISTANCE
Should you encounter any problem(s) with this product or if you do
not understand its many features, please refer to this operating manual
rst. If further assistance is required, DIG offers the following customer
support:
• DIGPRO Technical Service USA: DIG’s Technical Service Team is
available to answer questions in English and Spanish from 8:00 AM to
5:00 PM (PST) Monday-Friday (except holidays) at 1.800.344.2281 or
1.760.727-0914.
• Questions also can be e-mailed to [email protected] or faxed to
760.727.0282.
• Specication documents and manuals are available for download at
www.digcorp.com.
• Customer Assistance Outside the USA: Contact your local distributor

14
FCC
This device complies with FCC and IC radiation exposure limits set forth for an
uncontrolled environment. The device should be installed and operated with
a minimum distance of 20cm between the radiator and your body. This device
must not be collocated or operating in conjunction with any other antenna or
transmitter.
I. Changes or modications not expressly approved by DIG Corporation could
void the user’s authority to operate the equipment.
II. This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:Reorient or relocate the receiving antenna. Increase the
separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected. Consult the dealer or an experienced radio/TV
technician for help.

III. Industry Canada
This device complies with Industry Canadalicence-exemptRSSstandard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme auxCNRd’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et
(2) l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.

E
www.digcorp.com
e-mail: [email protected]
26-304 REVA 102020
Printed in the USA
DIG is a Registered Service Mark of DIG Corp.
1210 Activity Drive
Vista, CA 92081-8510, USA
WARRANTY
DIG CORPORATION warrants these products to be free from defects in material and workmanship
for a period of three years from date of purchase. This warranty does not cover damage resulting
from accident, indoor uses, misuse, neglect, modication, improper installation or subjection to
line pressure more than 125 lbs. per square inch for anti-siphon valves, in-line valves and from an
actuator. This warranty shall extend only to the original purchaser of the product for use by the
purchaser. The obligation of DIG CORPORATION under this warranty is limited to repairing
or replacing at its factory this product which shall be returned to the factory within three years
after the original purchase and which on examination is found to contain defects in material
and workmanship. DIG CORPORATION SHALL IN NO EVENT BE LIABLE FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES OF ANY KIND; THE SOLE OBLIGATION OF DIG BEING LIMITED
TO REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCTS. SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. Unattended use for prolonged periods
without inspection to verify proper operation is beyond the intended use of this product, and any
damage resulting from such use shall not be the responsibility of DIG CORPORATION. There are no
warranties, which extend beyond the description on the face hereof. In the case of purchase of the
product for use other than, for irrigation purposes, DIG CORPORATION hereby disclaims any implied
warranties including any warranties of merchantability and tness for a particular purpose. In the
case of the purchase of the product for personal, family or household purposes, DIG CORPORATION
disclaims any such warranties to the extent permitted by law. To the extent that any such disclaimer
or implied warranties shall be ineffectual, then any implied warranties shall be limited in duration to
a period of three years from the date of the original purchase for use by the purchaser. Some states
do not allow limitation on how long an implied warranty lasts, so the above limitation may not apply
to you. In order to obtain performance under this warranty, the unit must be returned to the factory,
along with proof of purchase indicating original date of purchase, shipping prepaid, addressed as
follows: DIG CORPORATION, 1210 Activity Drive, Vista, CA 92081. Repaired or replaced units will be
shipped prepaid to the name and address supplied with the unit returned under warranty. Allow four
weeks for repairs and shipping time. Repair of damaged units not otherwise within warranty may be
refused or done at a reasonable cost or charge at the option of DIG CORPORATION. This warranty
gives you specic legal rights, and you may also have other rights, which vary from state to state.
