DIG 5006-IP User manual

23
• Irrigation window allows for propagation at a defined part of the
day
• Open window:AM or PM
• Close window:AM or PM
ELECTRICAL SPECIFICATIONS
• Transformer input: 120VAC,60 Hz
• Station output: 24VAC,0.27 amps per station
• Maximum output: 24VAC, 0.83 amps
• Battery backup: 9 volt alkaline battery (not included)
DIMENSIONS
• Height: 6" (15 cm)
• Width: 4" (10 cm)
• Depth: 2" (5 cm)
MOUNTING CONTROLLER TO WALL
• Select an indoor location near a 120 VAC
outlet.The location should be protected from
moisture and sunlight
• Remove the mounting bracket from the back
of the controller
• Place the mounting bracket slightly below
eye level. Secure the bracket with #5 or #6
1" screws (Note: If installing on drywall,
install screw anchors).
• Align controller housing with mounting
bracket. Slide the controller down into
position on the bracket.
DO NOT PLUG TRANSFORMER INTO POWER SOURCE UNTIL
THE CONTROLLER IS MOUNTED AND ALL VALVES HAVE BEEN
CONNECTED.
BACK-UP BATTERY INSTALLATION
Rotate the battery compartment cover handle to the 11 o’clock
position to remove the cover (see drawing). Insert battery. All
controller display elements will briefly appear on the display,
followed by the blinking time “12”– the controller is now ready to
be programmed.
IMPORTANT: To replace the battery compartment cover, insert
it with the handle in the “11”o’clock position to avoid
possible cover guide pin breakage.
The battery is intended for irrigation program backup only.During
electrical outages the program will not be erased, however, valves
will not operate.
CONNECTING VALVES AND TRANSFORMER
1. Install control wire between valve location and controller
2. At the valve, connect a common wire to either solenoid wire of
all valves. Connect a separate wire to remaining wire of each
valve.Waterproof all wire splice connections.
3. Remove cover from controller to access the terminal strip area.
4. Connect valves common wire to “C”(common) and individual
valve wire to appropriate valve # on the controller terminal (see
Figure 1).
5. Insert transformer wire through the hole in the bottom of the
controller and connect the wire to the two screws marked
“AC”. (Polarity does not matter.)
Do not plug transformer into power source until the controller
is mounted.
Model 5006-IP – 6 station controller
M = Master valve or pump controller
CONNECTING A MASTER VALVE OR PUMP START RELAY
The controller must be mounted 10 to 15 feet away from pump
start relay and the pump.When a controller is used to operate a
pump, a pump start relay must be used.
Connect either wire from pump start relay to controller terminal
“M”, connect other wire to the“C”(common) terminal.
Do not connect controller directly to pump start, it can
damage the controller.
Connecting the controller to a pump is to be performed by a
qualified electrician only.
CONNECTING A RAIN SENSOR
An interrupt type rain sensor can be connected to the controller.
The sensor connects directly to the controller sensor connection.
Connect either wire from sensor to the two sensor terminals on
the controller (see figure 1).
PROGRAMMING THE CONTROLLER
DIG controllers are programmed with the aid of four buttons:
Programming step selector – used to select the desired
programming mode (includes clock setting mode)
Next step button – used to
select the parameter to be
changed (hour, minute,etc.). Only
a blinking parameter can be
changed.
Data increment button
(Increase) – Raises the value of
the selected parameter (e.g.,
when time selected from 06:00 to
07:00).
Data increment button
(Decrease) – Lowers the value of
the selected parameter (e.g.,
when time selected from 06:00 to
05:00).
PROGRAMMING CURRENT TIME AND DATE
Press a number of times until
icon appears. Press .The
hour digit will flash. Use the or
buttons, to set the current time
(note: use ofAM and PM).A further
press of will make the minutes
digit flash. Use the or to set
the current time. Press .A flashing arrow will appear in the
upper portion of the display. Use the or to set the current
day. Press to move to the next step.
If the last data entered stops flashing, press the again to
resume programming.
VALVE SELECTION
Press until icon appears.
Press .A flashing arrow appears.
Use the or to position the
arrow opposite the valve number
that you wish to program.
Press to move to the next step.
PROGRAMMING WATERING TIME:
HOURS, MINUTES AND SECONDS
Press until icon appears.Use
and or to set the desired
watering time.
Press to move to the next step.
PROGRAMMING WATERING
SCHEDULE
Press until icon appears.At
this stage you can select one of two
program options:
A) Watering schedule according to
the days of the week.
B) Cyclical schedule watering – once,minutes, hours and days.
A. Watering schedule according to the days of the week.
Press , a flashing arrow appears opposite the days of the
week. Use the or buttons for the desired day.A non-
flashing arrow shows the Watering Day selected.In this way, move
along the days of the week and set
any day of the week required.
To cancel a Watering Schedule:
Press when the arrow is flashing
beside that day.
B.Cyclical, , minutes,
hours and days watering
For operating the watering schedule cyclically or press
the a number of times (pass over every day of the week) until
the word appears. for single watering if
required.
Cyclical schedule watering – press and the word will
flash. Use or to set the desired watering cycle,up to 45
minutes, up to 23 hours and up to 30 days.When you leave the
icon on, program will operate one time only, and the
controller needs to be programmed again.
Press to move to the next step.
PROGRAMMING A WEEKLY START
TIME
(For watering according to the days
of the week.) Programming the
controller by day of the week allows
4 start times per day. Press for
start no. 1.The word will appear (or the last start time
entered).Press the word flashes. Use the or to
set the desired start time (note AM and PM).Press to program
start no. 2 and repeat the same steps for starts no.3 and 4.To
cancel one of the start times, press .The hour digit flashes.
Use the or to display .
PROGRAMMING A CYCLICAL OR
START TIME WITH START
TIME DELAY
Programming a start time with these
programs will allow the use of an
additional function defined as
“number of days”.You will be able to set the first start time today
(day 0), tomorrow (day 1) or any number of days required (up to
30 days). Press .Use or to set the desired start time,
and day. (Only one start time in this mode).
MANUAL OPERATION
Press the .The icon appears.
Use and to open or close the
valves.
• In this position, it is not possible
to change the valve number. (In
order to change the valve, you
must return to the “valve”
position.)
• If the controller is not connected
to the main power supply, the
word “AC OFF”will appear and
the valve may not be opened.
• In manual operation, the valve will close automatically after the
programmed watering time.
INTRODUCTION
THANK YOU for purchasing a DIG Controller.
Please take the time to read through the enclosed instructions and
follow them step by step. If you have any questions, please call
our customer service line 1-800-344-6641.
CONTROLLER MAIN FEATURES
• Operates up to 6 valves and master valve (or booster pump)
• Simultaneously operates up to two valves
• Independent program for each valve
• Operates 24 VAC valves
• Up to four start times per day per each
valve in calendar mode
• Simple, four button programming
• Optional manual operation
• Identifies short circuits, disconnects
shorted valve, and gives visible alarm
• Operates off 120 VAC transformer
• Program backup with 9V battery
• Can be programmed under backup
battery power,without AC power
connection
• Up to 30 days rain delay
SPECIFICATIONS
OPERATING SPECIFICATIONS
• Programs: Independent program for each valve
• Station run time: In 1-second increments up to 24 hours
• Watering Schedule:In 1-minute increments up to 5 minutes
In 5-minute increments up to 15 minutes
In 15-minute increments up to 45 minutes
In 1-hour increments up to 23 hours
In 1-day increments up to 30 days
7 days calendar
• Start time in irrigation mode: up to 4 start times per day
• Start time in propagation mode: one start time every minute
• Sensor: on and off
OWNERS MANUAL
INSTALLATION INSTRUCTIONS
5006-IP SIX STATION AC PROPAGATION
AND IRRIGATION CONTROLLER
M
C
C
AC
AC
S
S
1
2
3
4
5
6
Transformer
120 VAC
Sensor
Valves
M 1 2 3 4 5 6
BAT
1-800-344-2281
1 2 3 4 5 6 M
Bracket
Figure 1

”RAIN OFF” (SHUTDOWN)
Press .The sprinkler icon
appears.Press and icon
will appear.The controller is shut
down. Press to return to the
original programming. (The icon will disappear.)
The shutdown mode causes all of the valves controlled by the
computer to be suspended.The programming, however, is
preserved.
SENSOR OPERATION
1. Select the valve to which the
sensor is to be associated.
2.Press until appears next
to SENSOR.
3. Press to activate the sensor
in the irrigation program for the
selected valve.
* With the sensor circuit closed (i.e.,
the sensor detects the existence
of a defined program lockout
condition) the symbol blinks
on the display. In this situation,
irrigation will not take place
through valves associated with
the sensor.
4. Press to disable the sensor.
The word “OFF”appears on the
display.
IRRIGATION WINDOW IN THE CYCLICAL PROGRAM MODE
The irrigation window is an advanced feature which enables
cyclical irrigation program operations (see Section B) to take place
only during a defined part of the day (window).The irrigation
window is defined as a part of a day (up to 23 hours), in the
cyclical irrigation mode only.
This function is useful when irrigation is only required during the
hot hours of the day. For example,open window 9 am, closed
window 4 pm.
Make sure that appears on
the display
1. Press until appears on
the display next to W.OPEN,with
the word OFF or last OPEN
WINDOW time setting displayed.
2. Press .The word OFF blinks on the display.
3. Press and to set the desired OPENWINDOW time (pay
attention to the AM/PM designation).
4. Press until appears on
the display next to W.CLOSE,with
the 12 am or the last close
window time setting displayed.
5. Press .The 12 am blinks on
the display.
6. Press and to set the desired CLOSE WINDOW time
(pay attention to the AM/PM designation).
To disable the irrigation window function
1.Press until appears
next to OPEN WINDOW,with the
last OPEN WINDOW time setting
displayed.
2. Press .The irrigation window
open time blinks on the display.
3. Press until OFF appears next to .
VALVE IN OPERATION
A icon will appear over the
valve in operation. If the
flashes, the valve has not
opened, the possibilities are:
• The valve is in standby mode
(WAIT). icon will flash once every two seconds (30 times
every minute).
• Valve is in “short mode”.The icon will flash once every
1/2 second (120 times every minute).
VALVE IS IN STANDBY MODE (WAIT)
When two valves are currently open,
and a third valve is scheduled to
open, the third valve will enter into a
wait mode.A blinking O will appear
above the number of the valve
which is on wait.
To check that the valve is in (WAIT) mode, select the flashing valve
and return to the manual position. If the appears, then the
valve is in (WAIT) mode.
NO POWER
“AC Off” appears on the display
during controller irrigation program
execution, or during“manual”
irrigation system operation via the
irrigation controller when no power
is delivered.
In this situation, the controller can be programmed,but cannot
operate the valve.
VALVE IN MODE
(A short-circuit in the
solenoid or wiring.)
To check if the valve is
short-circuited, select the
flashing valve and move to
the manual position. If
appears, then the
valve is short-circuited.
Check the wiring and the solenoid.
WEAK BACKUP BATTERY
When the backup battery is
weak, a flashing
icon will appear on the
display.
The battery should be
replaced.The programming
will not be deleted if the
fresh battery is inserted within 30 seconds of removing the weak
battery.
NO PROGRAM
During“manual” irrigation
system operation via the
irrigation controller,
“no prog” appears on the
display, meaning that no
irrigation period has been
set for the current valve. In
this case, the irrigation controller“does not know” when to close
the valve.
In this situation valve opening is disabled.
MAINTENANCE AND TROUBLESHOOTING
Check the wiring on the controller’s terminal strip and on the
valves, at the beginning of a new season.
PROBLEM: Valve does not open
CAUSE: One of the following not entered:Watering time,
watering days, start time
SOLUTION: Check and program as required
CAUSE: Selector on“RAIN OFF” position
SOLUTION: Cancal RAIN OFF
CAUSE: No main electric power
SOLUTION: Check transformer and socket
CAUSE:Valve or connection faulty
SOLUTION: Check the valve or replace it
PROBLEM: Valve does not close
CAUSE: Dirt or stones in the valve.
SOLUTION: Clean the valve
CAUSE:Valve was opened manually
SOLUTION: Move to automatic position
CAUSE:Valve faulty (torn diaphragm)
SOLUTION: Replace valve or part
PROBLEM: Display“disappears”
CAUSE: Backup batteries are dead and there is no power from
the transformer
SOLUTION: Check the batteries and the transformer.
DIG CORPORATION 3 YEAR WARRANTY
DIG CORPORATION warrants these products to be free from defects in material and
workmanship for a period of three years from date of purchase.This warranty does
not cover damage resulting from accident, misuse,neglect, modification, improper
installation or subjection to line pressure in excess of 150 lbs. per square inch.This
warranty shall extend only to the original purchaser of the product for use by the
purchaser. This warranty shall not cover batteries or any malfunction of the product
due to battery failure. The obligation of DIG CORPORATION under this warranty is
limited to repairing or replacing at its factory this product which shall be returned to
the factory within one year after the original purchase and which on examination is
found to contain defects in material and workmanship.
DIG CORPORATION SHALL IN NO EVENT BE LIABLE FORANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND;THE SOLE OBLIGATION OF DIG BEING
LIMITED TO REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCTS. SOME STATES DO
NOT ALLOWTHE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SOTHE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TOYOU.
Unattended use for prolonged periods without inspection to verify proper operation is
beyond the intended use of this product, and any damage resulting from such use
shall not be the responsibility of DIG CORPORATION.There are no warranties which
extend beyond the description on the face hereof. In the case of purchase of the
product for use other than, for irrigation purposes,DIG CORPORATION hereby
disclaims any implied warranties including any warranties of merchantability and
fitness for a particular purpose. In the case of the purchase of the product for
personal, family or household purposes,DIG CORPORATION disclaims any such
warranties to the extent permitted by law.To the extent that any such disclaimer or
implied warranties shall be ineffectual, then any implied warranties shall be limited in
duration to a period of one year from the date of the original purchase for use by the
purchaser. Some states do not allow limitation on how long an implied warranty lasts,
so the above limitation may not apply to you.
In order to obtain performance under this warranty,the unit must be returned to the
factory,along with proof of purchase indicating original date of purchase, shipping
prepaid, addressed as follows:
DIG CORPORATION,130 Bosstick Blvd., San Marcos,CA 92069. Repaired or replaced
units will be shipped prepaid to the name and address supplied with the unit returned
under warranty.Allow four weeks for repairs and shipping time. Repair of damaged
units not otherwise within warranty may be refused or done at a reasonable cost or
charge at the option of DIG CORPORATION.
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
789
TO ORDER PARTS:
1-800-322-9146 FAX: [phone]
130 Bosstick Blvd.
San Marcos, CA 92069 E
www.digcorp.com/asdig
e-mail:[email protected]
© 1999 DIG CORP 26-035
