DIG GRWKIT-12 User manual

3. Connect the micro tubing to the converter
barbs by forcing the barb into the end of
the micro tubing. Then, run each length of
micro tubing to the desired location and
insert the brown side of the dripper into
the micro tubing. If insertion is difficult, heat
the end of the micro tubing with warm water
to make it more pliable.
4. Secure the micro tubing near the plants by
attaching a V-stake towards the end of
the micro tubing, taking care to space the
drippers appropriately.
Please see below for additional products to be used with the included 12-outlet
manifold.
Model # B38 1/4”, 50’ micro tubing
B38100 1/4”, 100’ micro tubing
B38500 1/4”, 500’ micro tubing
1/4” BARB OR ELBOW CONVERTER
A 1/4” converter barb or elbow is used only with the 1/4” micro tubing. The converter
barb has a compression side that is inserted into the drip manifold body. The other side
is a 1/4” barb for 1/4” micro tubing. Depending on your system setup, elbows may be
more effective than straight barbs. Please see below for information needed to order
1/4” converter barbs and elbows.
Model # 10-012 Red converter barb to be used with 1/4” micro tubing
10-013 Green converter barb to be used with 1/4” micro tubing
10-014 Purple converter barb to be used with 1/4” micro tubing
10-017 Black converter barb to be used with 1/4” micro tubing
25-007 Black converter elbow to be used with 1/4” micro tubing
Pressurize the system and verify that the 12-outlet manifold is functioning properly.
Make any necessary corrections if needed.
When designing a system, we recommend that the maximum length of micro tubing
from each outlet should not exceed 8’-10’. Longer lengths may certainly be achieved,
but please consider the factor of maintenance and aesthetics.
3. OPTIONAL ACCESSORIES
Use the rubber caps provided to close all
unused outlets. Do this by unscrewing
the cover and removing the Mini-Disk
filter. Then, press the rubber caps into the
unused outlets, and re-install the Mini-
Disk filter and cover. Tighten the cover
by hand.
6.
Cover
"O" Ring
Mini-Disk Filter
Caps
Body
Converter Barbs for
1/4” Micro Tubing
We at DIG Corporation understand that most stores do not carry spare parts. For your
convenience, if you need any of these parts, please visit:
www.digcorp.com/rparts.
Parts will be sent within seven days.
5. TO ORDER PARTS
1/4” Micro Tubing
1-GPH PC Drippers
V-Stake
5.

INSTALLATION INSTRUCTIONS
12-Outlet
Home Grow Kit
For indoor growing
in any medium
Thank you for purchasing the DIG 12-Outlet Home Grow Kit. Please take the time to
read through the enclosed instructions and follow them step by step. If you have any
questions, please call our customer service line 1-800-322-9146.
DIG’s 12-outlet drip irrigation manifolds are designed to adapt to any 1/2” riser. They
may be incorporated into a new system, or used to convert existing sprinkler risers into
12-outlet drip systems. This kit includes 12, 1-GPH pressure compensating drippers with
a check valve. The 12-outlet manifolds may be used with DIG’s 1/4” micro tubing.
1. First, insert the converter barbs into the openings.
Make sure that the barbed end is facing out.
2. After the riser has been flushed,
thread the 12-outlet manifold onto the riser.
DIG CORPORATION warrants these products to be free from defects in material and workmanship for a period
of two years from date of purchase. This warranty does not cover damage resulting from accident, misuse,
neglect, modification, improper installation or subjection to line pressure in excess of 80 PSI per square
inch. This warranty shall extend only to the original purchaser of the product for use by the purchaser. The
obligation of DIG CORPORATION under this warranty is limited to repairing or replacing at its factory this
product which shall be returned to the factory within one year after the original purchase and which on
examination is found to contain defects in material and workmanship.
DIG CORPORATION SHALL IN NO EVENT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY KIND; THE SOLE OBLIGATION OF DIG IS LIMITED TO REPAIR OR REPLACEMENT OF DEFECTIVE
PRODUCTS. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
Unattended use for prolonged periods without inspection to verify proper operation is beyond the
intended use of this product, and any damage resulting from such use shall not be the responsibility of DIG
CORPORATION. There are no warranties which extend beyond the description on the face hereof. In the case
of purchase of the product for use other than, for irrigation purposes, DIG CORPORATION hereby disclaims any
implied warranties including any warranties of merchantability and fitness for a particular purpose. In the case
of the purchase of the product for personal, family or household purposes, DIG CORPORATION disclaims any
such warranties to the extent permitted by law. To the extent that any such disclaimer or implied warranties
shall be ineffectual, then any implied warranties shall be limited in duration to a period of one year from the
date of the original purchase for use by the purchaser. Some states do not allow limitation on how long an
implied warranty lasts, so the above limitation may not apply to you.
In order to obtain performance under this warranty, the unit must be returned to the factory, along with proof
of purchase indicating original date of purchase, shipping prepaid, addressed as follows:
DIG CORPORATION, 1210 Activity Drive, Vista, CA 92081. Repaired or replaced units will be shipped prepaid
to the name and address supplied with the unit returned under warranty. Allow four weeks for repairs and
shipping time. Repair of damaged units not otherwise within warranty may be refused or done at a reasonable
cost or charge at the option of DIG CORPORATION.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
CUSTOMER SERVICE:
1.800.344.2281 FAX: [phone]
1210 Activity Drive • Vista, CA 92081-8510, USA
www.digcorp.com
e-mail: [email protected]
26-033 REVA 052417
Printed in the USA
1. 12-OUTLET MANIFOLD
2. HOW TO INSTALL
INTRODUCTION
DIG CORPORATION 3 YEAR LIMITED WARRANTY
KIT CONTAINS:
(1) 12-Outlet Manifold
(1) 100’ Roll of 1/4” Black
Vinyl Micro Tubing
(1) Strip of Eight Zone Caps
(12) 1/4” Converter Barbs
(12) 1-GPH PC Drippers
with Check Valves
(12) V-Stakes for 1/4” Tubing
