Digi Sport Instruments DW2A User manual

OUTDOOR
PEDOMETERS
DW2A
4-functions large-digit pedometer
Features:
§Large LCD digit for easy reading
§Step mode : shows the number of steps moved
§Distance mode : shows the travelled distance
§Calorie mode : shows the amount of calories consumed
§Stopwatch (up to 10h)
§Lithium battery CR2016 3V

INSTRUCTION MANUAL
FEATURES:
- PC105M2,E18M2 with STEP and DISTANCE functions
- PC105M4,E18M4 with STOPWATCH, STEP, CALORIE and DISTANCE functions
- PC105U2,E18U2 with STEP and DISTANCE functions (for DW 2A)
- PC105U4,E18U4 with STOPWATCH, STEP, CALORIE and DISTANCE functions (for DW 2A)
- Large LCD digits for easy reading
OPERATION INSTRUCTIONS:
STEP MODE:
When C is at C2 position as shown in Fig.3 the indicator will be on at the STEP position. In this mode the
display shows the number of steps moved. Depressing A for 1 sec resets the display to zero.
DISTANCE MODE:
When C is moved to the C4 position, the pedometer enters DISTANCE MODE as shown in Fig. 4a, which
shows the distance traveled corresponding to the number of steps moved. Pushing B in this mode changes
the display to as shown in Fig.4b, which is for setting of the stride of the step.
Pushing B once advance the strides by 1 where as push and hold B will advance strides at a rate of 4 Hz.
The range of the presettable stride is 30 to 150cm. The display will return to display of distance if B is not
pushed for 4 seconds.
STOPWATCH MODE:
When the SLIDE SWITCH C is moved to the C1 position, the LCD is as shown in Fig.2, with the indicator
pointing to SW. At this mode depressing PUSH BUTTON B will start or stop stopwatch. When the stopwatch

is running, the indicator blinks on and off. Depressing and holding A for 1 sec when the stopwatch is
stopped resets the stopwatch to zero. The display shows MINUTE’ SECOND. 1/100 SEC for the first 9 min
59.99 sec and then change over to HOUR: MINUTE . SECOND. The stopwatch has a full range of 9 H 59 M
59 S, after which the display will start all over again from zero.
The stopwatch indicator will remain blinking on and off as long as it is running, even if the pedometer is
switch to other modes.
CALORIE MODE:
When C is moved to C3 position, the pedometer enters the CALORIE MODE with display as shown in Fig.5a,
which shows the number of calories consumed corresponding to the number of steps moved.
Pushing B in this mode changes the display to as show in Fig.5b, which is for setting of the user’s weight,
based on which the Calories are calculated. Pushing B once advances the weight by 1 where as push and
hold B will advance weight at a rate of 4 Hz. The range of the presettable weight is 30 to 150 kg.
The display will return to display of calorie if B is not pushed for 4 seconds.
BATTERY REPLACEMENT:
When the display becomes dim or faded out, battery replacement is necessary.
1. Remove the 3 screws at the back of the unit
2. Remove the battery in the direction
3. Replace the old battery with a flesh Lithium battery (CR2025 or equivalent).
4. Reinstall the screws at the back.
REMARK: The user should try hooking the pedometer on Different positions on the waist to attain the most
accurate measurement.
