digi-tech AC-1710 User manual

2 Port HDMI Splitter
AC-1710
User manual

1
Introduction
1×2 HDMI splitter distributes 1 HDMI source to 2 HDMI displays simultaneously. It offers HD video
solution for HDTV/STB/DVD/Projector/DVR in homes, retail, conference room presentation, education
and training, etc.
Features
1. 1 HDMI input signal split to 2 HDMI devices.
2. HDCP 1.4 protocol compliant.
3. 3D HDMI 1.4a video format support.
4. 3D video support including Frame packing for all 3D formats up to a 297MHz TMDS clock.
5. Support display resolutions up to 4K x 2K@30Hz,1080P@120Hz,and 1080P 3D@60Hz
6. Support deep color 30bit, 36bit, 48bit per pixel.
7. Digital audio format, as DTS-HD/Dolby-true-HD/LPCM 7.1/DTS/Dolby-AC3/DSD.

2
Package
1. HDMI Splitter ---------------------------------------------------------------------------------- 1PCS
2. 5V1A DC Power Supply adaptor ------------------------------------------------------------ 1PCS
3. Operation Manual ------------------------------------------------------------------------------ 1PCS
Specifications
1. Frequency Bandwidth 2.97Gbps
2. HDMI Splitter Input Ports 1 x HDMI Female input port
3. HDMI Splitter Output Ports 2 x HDMI Female output ports
4. Power Supply DC 5V 1A
5. ESD Protection Human Body Model: ± 8kV (air-gap discharge)
± 4kV (contact discharge)
6. Dimensions (mm) 60(W) X 70 (D) X 20 (H)

3
Operation controls and Functions
Front Panel
1. POWER LED:This red LED illuminates when the device is connected with power supply.
2. DC 5V: Plug the 5V DC power supply into the unit and connect the adaptor to an AC wall outlet.
3. HDMI INPUT:This socket connects to a HDMI source output, i.e. from a DVD player, Game
console, etc.
4. INPUT LED:

4
Rear Panel
1. OUTPUT 2:This socket connects to a HDTV or monitor with a HDMI cable.
2. OUTPUT 2 LED:This red LED illuminates when a TV/monitor is connected to this output.
3. OUTPUT 1 LED:This red LED illuminates when a TV/monitor is connected to this output.
4. OUTPUT 1:This socket connects to a HDTV or monitor with a HDMI cable.

5
Application Example

6
IMPORTANT:
- Never attempt to open, repair or modify any part of this unit or its accessories.
- Never get any part of the device or its accessories wet.
- Failure to adhere to these points will result in a void of warranty.
