digi-tech AA-0373 User manual




UserManual

Mono Amplifier Module

AA‐0373
Distributed by:
TechBrands by Electus Distribution Pty. Ltd.
320 Victoria Rd, Rydalmere
NSW 2116 Australia
Ph: 1300 738 555
Int’l: [phone]
Fax: [phone]
www.techbrands.com

TechnicalSpecifications:

PowerInput:4‐12V
Output:0.3mW@4ohms(ifinputis<6V)
  or0.5W@8ohms
Dimensions:65(L)x35(W)x20(H)mm

Notes:

Nevergetanypartofthemodulewet.
Neverattempttoopen,modifyorrepairanypartofthe
module.

Instructions:

Testtheunitfirstbeforeinstalling:
Connecta9Vpowersupplytotheamplifiermodule,
withamultimeter(switchedtothe200mArange)in
serieswithoneoftheleads.Donotconnecttoa
loudspeakeryet.Withnoinputsignal,youshould
getaquiescentcurrentofabout8‐10mA.Anymore
thanthisandyoushouldswitchitoffimmediately.
Ifeverythingappearstobeokay,connecta
loudspeakerandperforma‘blurt’test.Todoso,
turnthevolumeuphighandthenputyourfinger
ontheinputaudiosignal.Thiswillinjecta
hum/hashsignalintotheamplifierwhichisheardas
a‘blurt’fromthespeaker.Ifitblurts,itisworking
fine.

Theinstallationofthemoduleisleftuptoyou,
accordingtothediagram,ensuringthatyoukeepitaway
frommainstransformersoranywherelargeamountsof
humarepresent.



WiringDiagram:
