digi-tech JAMMAN STEREO User manual

R
6Removable CompactFlash®Type I memory
card with over 24 minutes of capacity included
(up to 2GB of storage or 6.5 hour*capacity)
6USB port to transfer loops to and from your
computer. Create a library of all your loops
6Balanced XLR mic input with professional-
grade, low impedance input with dedicated
gain control. Perfect for dynamic and self
powered microphones
6CD quality 44.1kHz sampling rate
6Metronome with multiple rhythm sounds
and time signatures
6Rugged metal chassis
6Automatic recording
6Power supply included
6Optional footswitch adds addidtional
Hands-Free™functionality
When we developed the PDS 8000 looper pedal
almost twenty years ago, it stored
eight seconds of audio. Now
we’ve reinvented it using remov-
able CompactFlash®memory to
store up to 6.5 hours*! A wide
range of features combined with
ease of use make the DigiTech®
JamMan®the perfect looper/
phrase sampler for practicing,
composing, and performing.
• Save up to 99
independent loops.
• Store over 24 minutes of
looping time on the included
CompactFlash card. Upgrade
to a 2GB card to store up to 6.5 hours of audio!
• Connect to your computer via USB and
never lose another loop ever again!
• Record rhythm loops and solo over them
on the fly, completely Hands-Free™.
• Load up the JamMan with bass lines, drums,
harmonies, and more; create an entire backup
band, take it with you, and perform anywhere!
• Slow down or speed up any song
without changing pitch.
The JamMan opens up new horizons to your musical explorations. The possibili-
ties are literally endless, endless, endless...!
*With optional 2GB card
Twenty years later, 6 hours, 29 minutes & 52 seconds longer 7 www.digitech.com
TWENTYYEARS LATER
6hours,29 minutes & 52 seconds longer!
THE JamMan®
JAMMAN® LOOPER/PHRASE SAMPLER

JamMan® Provides Endless Possibilities for Creativity:
Whether a skilled journeyman or practicing musician
the JamMan®will open doors for creative solutions.
Above is just one of the many possible configurations that
allows for Hand-Free™flexibility in studio or onstage.
OUTPUT JACK
Connect to
guitar amplifier,
mixer or head-
phones with
plenty of juice
to spare.
FOOTSWITCH JACK
Connect the optional
footswitch to scroll
through 99 loops and
arm the Auto Record
feature, completely
Hands-Free™.
CD/AUX INPUT
Create samples
and play along
with CDs and
MP3s, with or
without the
original vocals!
INSTRUMENT INPUT
Super-quiet, ultra-high
impedance input is
ideal for sensitive
magnetic pickups.
JamMan® CONFIGURATIONS:
BALANCED XLR MIC INPUT
Professional-grade, low
impedance input with
dedicated gain control,
perfect for dynamic
and self-powered
condenser mics.
CompactFlash®
CARD READER
Expandable, swap-
pable, CompactFlash
memory gives you
virtuall unlimited
loop recording time.
AC ADAPTER
The included power
adapter means no
more performance
interruptions.
SPECIFICATIONS:
Included in Box:
JamMan®
CompactFlash® card
Power supply
Manual
Warranty card
Number of Loops Saved:
Up to 99 phrases (restricted
to space on memory card)
Connections:
Instrument Input Jack (¼")
Balanced XLR input
CD/AUX Input
CompactFlash® Type I Storage
Footswitch Jack
Output Jack (¼")
Power Adaptor Jack
USB Jack
Rhythms:
Wood Blocks, Sticks, Click,
Alternative Kick/High Hat,
Studio Kick/High Hat,
Techno Kick/High Hat,
Cowbell, Conga
and Tambourine.
Power Supply:
9V AC
Size:
Width: 6.65 inches 168 mm
Depth: 5.57 inches 141 mm
Height: 2.85 inches 65 mm
Options:
FS3X footswitch
CompactFlash® card
(up to 2 gigabytes in capacity
or 6.5 hours of recording time)
18-0339-A
USB PORT
Transfer loops to and
from your computer.
Create a library of all
your loops!
.0%& %08/ 61
Amplier
Instrument
Footswitch (optional)
switches between loops
CompactFlash®
Storage
MicrophoneCD/MP3 Player
Computer
connectivity
via USB port
INTUITIVE USER INTERFACE AND DISPLAY
High visibility, brightly lit numeric display, buttons,
and LEDs are just right for dark stages and studios.
Make loop changes fast and simple with the Select knob.
Record, play, overdub, undo and more all Hands-FreeTM!
JAMMAN® LOOPER/PHRASE SAMPLER
Twenty years later, 6 hours, 29 minutes & 52 seconds longer 7 www.digitech.com
FEATURES:
Auto-Record:
Start recording the moment
you start playing
Full Range Playback:
Built-in equalizer automatically
optimizes song samples played
through your amp
Minus Center:
Replace the vocals from MP3s
and CDs with your own voice
XLR and ¼" Inputs:
Record and mix your guitar and
vocals at the same time
Time Stretching:
Speed up or slow down loops and
samples, without changing pitch
One-Step Undo:
Instantly erase an unwanted over-
dub (and keep the original loop)
with a single tap of your foot
Tap Tempo:
Easily tap in the tempo with
a button or a footswitch
One-Step Clear:
Erase everything and start over,
without taking your hands off
your guitar
