Digiop NVR 2U User manual

1
Congratulations on your new DIGIOP® Video and Data Management System
This guide provides setup instructions for your server hardware.
For more information, contact DIGIOP®Support at
800.968.3606 Toll Free • [e-mail] • www.digiop.com
www.digiop.com
DIGIOP®NVR 2U Chassis for Di32 Series Systems
DO_NVR-FlexVR-2U-H_CoQ
4/14/15
DIGIOP® NVR 2U Hardware
Quick Start Guide
Video and Data Management Systems

2
1. Getting Started
Unpacking the Contents
The following are included with your system. Please inspect these and the other system
components while unpacking.
• Quick Start Guide
• Surge Protection Notice
• USB Flash Drive loaded with backup image
• Power cord
Choose a Proper Location
Select a location for the system that meets the following requirements.
NOTICE: Excessive heat can shorten the life of electronics.
• Adequate ventilation to avoid excessive heat (climate-controlled environment)
• Uninterrupted Power Supply (UPS)
• Moisture-free environment
• A place away from direct sunlight
• An area with minimal dust or debris
Site Installation
Hardware Setup – Connect all input devices and external peripherals to the system. Follow the order of connections displayed in Step 3.
• Indoor & Outdoor Camera(s)
• VGA Monitor
• Spot Out Monitor
• PTZ Camera(s) - Optional
• Speakers - Optional
• Ethernet
• Mouse
• Keyboard
• Power Cord
NOTICE: For proper indoor and outdoor cameras an in-line surge suppressor or equivalent should be used to reduce exposure to surges and lightning strikes.
2. About Your System
Front View HDD activity LEDRail bracket and handle Rail bracket and handlePower on LED
Maintenance access
door knob (with lock)
Maintenance access door (2)*
* Front panel Power and Reset switches are located behind the right door.
www.digiop.com

3
Back
View
Power On / O switch
Back panel Power cable connectorExpansion cards
Back
Panel
USB 3.0 (SS)
ports (2)
USB 2.0)
ports (2)
USB 2.0 ports (2)
Ethernet RJ-45 ports (2)
Line-in,
Line-out,
Mic-in
connectors
DVI-D*
monitor
port
VGA
monitor port
Keyboard/
mouse
connector
Display
Port**
HDMI
monitor
port
* DVI-D port with a DVI to VGA adapter can connect to a VGA monitor.
** Using the DisplayPort for video may require an optional adapter to connect to older monitors which only support VGA and/or DVI. When connecting to
a DisplayPort monitor or adapter, multi-monitor capability of the system is not available during boot or when running DOS. Output will be limited to the
DisplayPort monitor only. When the system is booted to Windows and the graphics driver is loaded, multi-monitor support will be fully functional.
Setting Up Your System
1. Connect the monitor using one of four connectors 2. Connect the network cable to the Ethernet port.
a. Using the DVI-D or VGA port. b. Using the HDMI port or DisplayPort.
www.digiop.com

4
3. Setting Up Your System (cont.)
Copyright © 2015 DIGIOP, Inc. • Indianapolis, IN • email: [e-mail] • tel: [phone] • www.digiop.com
DIGIOP is a registered trademark of DIGIOP, Inc. All rights reserved.
3. Connect the keyboard and mouse to the
USB 2.0 connectors
4. Connect the power cable
5. Press the power button on the monitor and computer.
NOTE: A chassis power switch is also located behind the maintenance access door.
System information
•Input Power Rating: 100 ~ 240 Vac, 50/60 Hz, 6 ~ 3A
•Maximum Ambient Operating Temperature: 104 degrees F (40 degrees C)
