Sartorius BL310 User manual

INSTRUCTIONMANUAL
Balance
Model : BL310
Brand :

SartoriusBasiclite Series
SartoriusGemlite Series
Electronic Precision Balances
and PreciousMetal Scales
Operating Instructions
98648-008-55

2
Practical Use
The Basiclite Seriesand Gemlite Series
fromSartoriusoffer precision balances/
scaleswith capacitiesranging from
0.1 mg to 12 kg.
These balances/ scalesmeet the highest
requirementson the accuracy and
reliability of weighing resultsthrough the
following features:
Efficient filtering-out of unfavorable
ambient conditionssuchasvibrations,
drafts, etc.
Stable and reproducible results
Rugged, durable weighing system
Basiclite balancesand Gemlite scales
save workand speed up simple routine
applicationsthrough:
Ultrafast response times
Easy operation
You can also choose fromthe following
extra functionsfor simple applications:
Toggling between weight units
Net-total formulation (tare memory)
Counting
Weighing in percent
Averaging
Contents
Practical Use .................................. 2
Contents ........................................ 2
Warning and Safety Information ........ 2
Getting Started ................................ 3
Operating theBalance/ Scale
Basic Weighing Function .................... 8
Calibration/ Adjustment ...................... 9
Application Programs
Counting ........................................10
Weighing in Percent ..........................12
Weigh Averaging ............................14
Net-Total Formulation/
Second Tare Memory ........................16
Toggle Between Weighing Units ..........17
Configuring theBalance/ Scale
Setting the Parameters(Menu Codes) ....18
Balance/ Scale Operating Menu
(Overview) ......................................19
Error Codes ....................................20
Careand Maintenance ....................21
Instructionsfor Recycling ....................22
Overview
Specifications....................................23
Accessories(Options) ........................26
CMarking ......................................27
Warning and Safety Information
Read these operating instructions
thoroughly before using your balance/
scale to prevent damage to the equipment.
Keep these instructionsin a safe place.
Follow the instructionsbelow to ensure
safe and trouble-free operation of your
balance/ scale:
!Make sure thatthe voltage rating
printed on the AC adapter isidentical
to your local line voltage
!Use only a commercially available
9-volt battery or rechargeable battery
!Do not use thisbalance/ scale
in a hazardousarea/ location
The only way to turn the power
off completely isto disconnectthe
AC adapter
Connect only Sartoriusaccessoriesand
options, asthese are optimally desi-
gned for use with your balance/ scale.
Protect the AC adapter fromcontact
with liquid.
Do not open the balance/ scale
housing. If the seal isbroken, thiswill result
in forfeiture of all claimsunder
the manufacturer'swarranty.

3
Getting Started
Warranty
Do not missout on the benefitsof our
full warranty. Please contact your local
Sartoriusoffice or dealer for further
information. Complete the warranty
registration card, if available indicating
the date of installation, and return the
card to your Sartoriusoffice or dealer.
Storageand Shipping Conditions
Do not expose the balance/ scale to
shocks, vibration, moisture or extreme
temperatures.
Unpacking theBalance/ Scale
After unpacking the balance/
scale, check it immediately for
any visible damage asa result of
roughhandling during shipment.
$If yousee any signof damage,
proceed asdirected in the chapter
entitled Care and Maintenance,
under the section on Safety
Inspection.
Save the box and all partsof the
packaging until youhave successfully
installed your balance/ scale. Only
the original packaging providesthe
best protection for shipment. Before
packing your balance/ scale, unplug all
connected cablesto prevent damage.
Equipment Supplied
The equipment supplied includesthe
componentslisted below:
BL210S, BL120S, BL60S, GC503
Balance/ scale
Weighing pan
Pan support
Shield ring
Shield plate
Dust cover
AC adapter
Gemtray (only with model GC503)
Calibration weight 100 g, F1
(only with model GC503)
BL150S
Balance/ scale
Weighing pan
Pan support
Glassdraft shield with cover
AC adapter
Balances/ scaleswith a readability of
0.01g
Balance/ scale
Weighing pan
Pan support (only on models
with a round weighing pan)
AC adapter

4
Installation Instructions
Your balance/ scale isdesigned to
provide reliable weighing resultsunder
normal ambient conditions. When
choosing a locationto set up your
balance/ scale, observe the following
so that youwill be able to work with
added speed and accuracy:
Set up the balance/ scale on
a stable, even surface
Avoid placing the balance/ scale
in close proximity to a heater or
otherwise exposing the balance/
scale to heat or directsunlight
Protect the balance/ scale
fromdraftsthat come from open
windowsor doors
Avoid exposing the balance/ scale
to extreme vibrationsduring
weighing
Protect the balance/ scale from
aggressive chemical vapors
Do not expose the balance/
scale to extreme moisture over long
periods
Conditioning the Balance/ Scale:
Moisture in the air can condense
on the surfacesof a cold balance/
scale whenever it isbrought into a
substantially warmer place. If you
transfer the balance/ scale to a
warmer area, make sure to condition it
for about 2 hoursat roomtemperature,
leaving it unplugged fromAC power.
Information
on Radio Frequency Interference
Warning!
Thisequipment generates, usesand
can radiate radio frequency energy
and, if not installed and used in
accordance with the instruction
manual, may cause interference to
radio communications. It hasbeen
tested and found to comply withthe
limitsfor a ClassA computing device
pursuant to Subpart Jof Part15 of
FCC Rules, which are designed to
provide reasonable protection against
such interference, when operated in a
commercial environment. Operation of
thisequipment in a residential area is
likely to cause interference, in which
case the user, at hisownexpense, will
be required to take whatevermeasures
may be required to correct the
interference.

5
Setting up the Balance/ Scale
Balances/ Scaleswith an Analytical Draft Shield
Chamber:
Place the componentslisted below inside
the chamber in the order given:
Shield plate
Shield ring
Pan support
Weighing pan
Gemtray (only with model GC503)
Balances/ Scaleswith a GlassDraft Shield:
Place the componentslisted below inside
the chamber in the order given:
Draft shield base place it on the balance so that
the edge for fitting the glassdraftshield faces
upwardsand turn it until it isfirmly in place
Pan support
Weighing pan
Glassdraft shield
Draft shield cover place it on the balance so
thatthe edge facesdownwards
Balances/ Scaleswith a Round Weighing Pan
Place the componentslisted below inside
the chamber in the order given:
Pan support
Weighing pan
Balances/ Scaleswith a RectangularWeighing Pan:
Place the weighing pan on the balance/ scale

6
Connecting the Balance/ Scaleto ACPower/
Safety Precautions
Use only original SartoriusAC adapters:
for Europe: 6971948 for the RSA: 6971949
for the U.S.:6971947 for Australia: 6971950
Insertthe right-angle plug into the jack
The AC adapterrated to Class2 can be plugged
into any wall outlet without requiring any
additional safety precautions
The ground isconnected to the balance/ scale
housing, which can be additionally grounded
for operation.
Using a Non-Rechargeable/ Rechargeable Battery
(notfor modelsBL210S, BL120S, BL60S, BL150S,
BL1500S, GC503, GM1502)
$A non-rechargeable or rechargeable battery isnot
included with the equipment supplied
!Use only a commercially available non-
rechargeable or rechargeable 9-volt battery
!When using a rechargeable battery, alwaysuse
an external charger to recharge the battery
Lay the balance/ scale onitsside
Open the battery compartment:
Lift the compartment cover
Insert the 9-volt (rechargeable)battery
in the compartment
$Make sure to connectthe positive and negative
polescorrectly
!All used batteriesare classified aswaste
that requiresspecial handling (not household
waste). Dispose of rechargeable batteriesin
accordance with the applicable special waste
disposal regulations.
Close the battery compartment:
Pressdown on the cover until it clicksinto place

7
Selecting theLineVoltage(MainsVoltage)
Use the following original AC adaptersforselecting
the line voltage:
AC adapterTNG8, order no. 6971951
(universal)
or
AC adapterTNG8, order no. 6971952
(for the U.K.)
Use the switchto toggle between230 Vand 115 V
Leveling theBalance/ Scale
(only for modelsBL210S, BL120S, BL60S, BL150S,
BL1500S, GC503, GM1502)
Level the balance/ scale any time youset
it up ina new location. Use only the 2 front feetof
the balance/ scale for leveling.
Turn the 2 rear feet until they are in position
(only on modelsBL1500Sand GM1502)
Turnthe 2 front feetasshown here in the illustration
until the air bubble iscentered in the level indicator
> In most cases, thiswill require several
adjustment steps
Anti-theft Locking Device
To protectagainst theft, use the mounting lug on the
rear panel of the balance/ scale.
Secure the balance/ scale atthe place of
installation, for example with a chain or a lock

8
Operating theBalance/ Scale
BasicWeighing Function
AvailableFeatures
Taring the balance/ scale
Youcan tare the balance/ scale withinthe entire weighing range.
Preparation
Turn on the balance/ scale: Presse
To change configurations: See the chapterentitled
Configuring the Balance/ Scale
To load factory-set configurations:
See Configuring the Balance/ Scale,parameter 9 1
$To tare the balance/ scale: Presst
Additional Functions
To turn off the balance/ scale: Presse
Example
Basic weighing
Menu code settings: Factory-set codes
Step Key (or instruction)Display/ Printout
1. Turn on the balance/ scale e
Self-testisperformed
2. Place container on balance/ +52.0 g
scale (here: 52 g)
3. Tare the balance/ scale t+0.0 g
4. Place sample in container on +150.2 g
balance/ scale (here: 150.2 g)

9
Calibration/ Adjustment*
Alwayscalibrate/ adjust the balance/ scale after setting it up in a new location.
AvailableFeatures
Calibration/ adjustment can only be performed when
there isno load on the balance/ scale,
the balance/ scale istared,
the internal signal isstable.
If these conditionsare not met, an error message isdisplayed.
The weight required for calibration/ adjustment isdisplayed (see Accessoriesfor
calibration weights; for model GC503 see EquipmentSupplied).
On Basiclite balances, calibration/ adjustment can be performed
with any of three weight units: g, kg* * , or lb (menucode 1.4.x)
Factory setting: Grams(menu code 1.4.1)
Example
Calibrate the balance/ scale
Menu code settings: Factory-set codes
Step Key (or instruction)Display/ Printout
1. Turn on the balance/ scale e
2. Tare the balance/ scale t0.0 g
3. Begin calibration t>2 sec. +1000.0
Calibration weight isdisplayed
without weight unit (here: 1000 g)
4. Place the indicated calibration 1000.0
weight on the balance/ scale
After calibration, the calibration +1000.0 g
weight isdisplayed with wt. unit
5. Remove the calibration weight 0.0 g
*Calibrationtechnically meansto determine the difference between the balance/ scale readout and the
actual weight onthe pan to determine the accuracy.
Adjustment meansto bring a balance/ scaleinto the state of accuracy required for itsuse.
Therefore, calibration,as used in thismanual, actually meansadjustment.
* * = not on modelswith a readability of 0.1 mg

10
Application Programs
Counting
Purpose
With the Counting programyou can determine
the number of partsthat each have approximately
equal weight.
AvailableFeatures
Store the current weight value to have it loaded
asthe preset reference sample quantity next time
you initialize the Counting application
The reference sample quantity canbe changed
in the operating menu:
See Configuring the Balance/ Scale
The average piece weight isautomatically
output via the optional data interface port after
initialization, if the menu code for Printout
with data ID codesisset
Pressvto toggle the display between piece
count and weight
Factory Settings
Reference sample quantity: 10 (menucode 3.3.2)
Preparation
Configure the Counting application
in the operating menu:
See Configuring the Balance/ Scale
Menu code 2.1.4 Counting
Reference sample quantity:
Menu code 3.3.1 5 pcs
Menu code 3.3.2 10 pcs
Menu code 3.3.3 20 pcs
Menu code 3.3.4 50 pcs
Menu code 3.3.5 100 pcs
See also Configuring the Balance/ Scale

11
Example
Determine an unknownpiece count; weighthe preset reference sample quantity
Settings(changesin the factory settingsrequired for thisexample):
Menu: Application program: Counting (menu code 2.1.4)
Reference sample quantity: 20 pcs(menu code3.3.3)
Step Key (or instruction)Display/ Printout
11. Turn on the balance/ scale e
12. Tare the balance/ scale t0.0 g
13. Display the reference sample v>2 sec. r ef 20 (briefly)
quantity (here: 20 pcs)
14. Place the reference sample +66.0 g
quantity (20 pcs) on the
balance/ scale (here: 66 g)
15. Start the application; if the v+20 pcs
print format isset to include
data ID codes, the following
isprinted: wRef + 3.300 g
16. Weigh uncounted parts +174 pcs
(here: 174 pcs)
17. Display weight v+574.2 g
18. Display quantity v+174 pcs
19. Unload the balance/ scale 0pcs
10. Delete the reference value c
11. Repeatthe procedure starting
fromstep 6, if desired.

12
Weighing in Percent
Purpose
Thisapplication programallowsyouto obtain weight
readoutsin percent which are in proportion to a
reference weight.
AvailableFeatures
Store the current weight value to have it loaded
asthe preset reference percentage next time you
initialize the Weighing in Percent application
The reference percentage can be changed
in the operating menu:
See Configuring the Balance/ Scale
The reference percentage isautomatically
output via the optional data interface port after
initialization, if the menu code for Printout
with data ID codesisset
Pressvto toggle the display between
percentage and weight
Factory Settings
Reference percentage: 10 (menu code 3.3.2)
Preparation
Configure the Weighing in Percent application
in the operating menu:
See Configuring the Balance/ Scale
Menu code 2.1.5 Weighing in percent
Reference percentage:
Menu code 3.3.1 5 %
Menu code 3.3.2 10 %
Menu code 3.3.3 20 %
Menu code 3.3.4 50 %
Menu code 3.3.5 100 %
See also Configuring the Balance/ Scale

13
Example
Determine an unknown percentage; store the weight on the balance/ scale
asa reference percentage
Settings(changesin the factory settingsrequired for thisexample):
Menu: Application program: Weighing in percent (menu code2.1.5)
Menu: Reference percentage 100 %(menucode3.3.5)
Step Key (or instruction)Display/ Printout
11. Turn on the balance/ scale e
12. Tare the balance/ scale t0.0 g
13. Display the reference
percentage v > 2 sec. r ef 100
14. Place the reference weight +222.50g
for 100%on the balance/ scale
(here: 222.5 g)
15. Start application; if the print v+100.00 %
format issetto include data
ID codes,
the following isprinted: Wxx% + 222.500 g
16. Place an unknown weight +144.94 %
on the balance/ scale
(here: 322.5 g)
17. Display weight v+322.5 g
18. Display percentage v+144.94 %
19. Unload the balance/ scale 0.00 %
10. Delete the reference percentage c
11. Repeatthe procedure starting
fromstep 6, if desired.

14
Weigh Averaging
Purpose
Use thisprogramto determine weightsunder
unstable ambient conditions. In thisprogram, the
balance/ scale calculatesthe weight asthe average
value froma defined number of individual weighing
operations. These weighing operationsare also
known assubweighing operationsor subweighs.
AvailableFeatures
The measured resultdisplayed isthe arithmetic
mean shown in the selected weight unit;
a triangle indicatesthat thisisa calculated value
Youcan set the number of subweighing
operationsperformed inthe operating menu:
See Configuring the Balance/ Scale
Pressvfor at least 2 sec. to display
the preset number of subweighing operations
Pressvto toggle the display between
the calculated resultand the weight
Factory Settings
Number of subweighsfor averaging: 10 (3.3.2)
Preparation
Configure the Weigh Averaging application
in the operating menu:
See Configuring the Balance/ Scale
Menu code 2.1.12 Averaging
Number of subweighsfor weigh averaging:
3.3.1 5 subweighs
3.3.2 10 subweighs
3.3.3 20 subweighs
3.3.4 50 subweighs
3.3.5 100 subweighs
See also Configuring the Balance/ Scale

15
Example
Determine the weight of a sample in extremely unstable ambient conditions
by calculating the average of 10 subweighing operations.
Settings(changesin the factory settingsrequired for thisexample):
Menu: Application program: Weigh Averaging (menu code 2.1.12)
Step Key (or instruction)Display/ Printout
1. Turn on the balance/ scale e
2. Tare the balance/ scale t0.0 g
3. Display the number
of subweighs(here: 10) v>2 sec. r ef 10 (briefly)
4. Place sample on the balance/ +8888
scale (weight readout fluctuates;
here: about 275 g)
5. Start measurement v+8888
10
9
8
...
1
After 10 subweighs +275.5 g G
If the print formatisset
to include data ID codes,
the following isprinted: RES + 275.5 g
6. Unload the balance/ scale +275.5 g G
(stable display)
7. Delete the result c
8. Repeat the procedure starting
fromstep 4, if desired.

16
Net-Total Formulation/ Second TareMemory
With thisapplication program you can weigh in components
for formulation of a mixture.
Preparation
Configure the Net-Total Formulation/ Second Tare Memory application
in the operating menu: See Configuring the Balance/ Scale
Menucode 2.1.3
Example
Step Key (or instruction)Display/ Printout
1. Turn on the balance/ scale e
2. Place an empty container on +65.0 g
the balance/ scale
3. Tare the balance/ scale t
4. Add the firstcomponent +120,5 g
5. Store the first componentweight v0.0 gNET
If the print formatisset
to include data ID codes,
the following isprinted: N1 + 120.5 g
6. Add the next component +70,5 g
7. Store the 2nd component weight v0.0 gNET
8. Add further components, Asdescribed
if desired for steps5 and 6
9. Display total weight c+191,0 g
and fill to desired final weight

17
ToggleBetween Weight Units
With thisapplication programyoucantoggle the display of a weightvalue back
and forth between two weight units.
Configure the Toggle Weight Unitsapplication in the operating menu:
See Configuring the Balance/ Scale,menu code 2.1.2 Toggle weight units
(Factory setting on Gemlite models)
Menu code Unit Conversionfactor Abbr. on
printout
1.7.1 3.1.1 Taiwanese taels4) 0.02666666000 o
(only selectable on Gemlite scales)
1.7.2 o3.1.2 o Grams 1.00000000000 g
1.7.3 1)3.1.3 1) Kilograms 0.00100000000 kg
1.7.4 2)3.1.4 Carats 5.00000000000 ct
1.7.5 3.1.5 Pounds 0.00220462260 lb
1.7.6 3.1.6 Ounces 0.03527396200 oz
1.7.7 3.1.7 3) Troy ounces 0.03215074700 ozt
1.7.8 3.1.8 Hong Kong taels 0.02671725000 tlh
1.7.9 3.1.9 Singapore taels 0.02645544638 tls
1.7.10 3.1.10 Taiwanese taels 0.02666666000 tlt
1.7.11 3.1.11 Grains 15.43235835000 GN
1.7.12 3.1.12 Pennyweights 0.64301493100 dwt
1.7.13 3.1.13 Milligrams 1000.00000000000 mg
1.7.14 3.1.14 Partsper pound 1.12876677120 / lb
1.7.15 3.1.15 Chinese taels 0.02645547175 tlc
1.7.16 3.1.16 Mommes 0.26670000000 mom
1.7.17 3.1.17 Austriancarats 5.00000000000 K
1.7.18 3.1.18 Tola 0.08573333810 tol
1.7.19 3.1.19 Baht 0.06578947437 bat
1.7.20 3.1.20 Mesghal 0.21700000000 MS
1.7.22 3.1.22 lb/ oz Gemlite scalesonly 0.03527396200 o
= Factory setting
1)= not for modelswith a readability of 0.2 mg
2)= Factory setting only formodel GC503
3)= Factory setting only forGM models
4)= Readability in increments of 1 digit
Function
To toggle the display betweenthe 1st and 2nd weight units:
Pressthe vkey

18
Configuring theBalance/ Scale
Setting theParameters(Menu Codes)
Youcan configure your Basiclite balance or Gemlite scale to meet individual requi-
rementsby selecting fromthe parametersavailable in the menu.
Example: Adapt the balance/ scale to unstable ambient conditions:
Menucode 1 1 4
Step Key (or instruction)Display
1. Turn off the balance/ scale e
2. Turn the balance/ scale backon; e
while all segments
are displayed: tbriefly 1.
$To navigate within a menu t2.
level; the last menu option is repeatedly ...
followed by the first option 9.
1.
3. Select the 2nd menu level p1. 1.
4. Select the 3rd menu level p1. 1. 2 o
5. In Menu Level 3: t
Select the desired option repeatedly 1. 1. 4
6. Confirmnew setting;
the oindicatesthe currently set p
option for 2 sec. 1. 1. 4 o
$Select the next menu level
(here: move fromthe 3rd to
the 1st level) p1.
$Set other menu codes, if desired p, t
7. Store parameter settings t
and exitoperating menu for 2 sec.
or
$Exit operating menu without
storing changes e
> Restartthe application 0.0 g

19
Balance/ Scale Operating Menu (Overview)
Factory setting
User setting
Menu 1. Balance/ 1.1. Adapt filter 1.1.1 Minimum vibration
scale functions 1.1.2 Normal vibration
1.1.3 Strong vibration
1.1.4 Extreme vibration
1.3. Stability range 1.3.1 1/ 4 digit
1.3.2 1/ 2 digit
1.3.3 1 digit
1.3.4 2 digits
1.3.5 4 digits
1.4. Weight unit for 1.4.1 Grams
calibrationweight* 1.4.2 Kilograms* *
1.4.3 Pounds
1.6. Auto zero 1.6.1 On
1.6.2 Off
1.7. Weight unit 1 See Toggle betweenWeightUnits
2. Application 2.1. Programselection see the desired applicationprogram
programs description
3. Application 3.1. Weight unit 2 see Toggle betweenWeight Units
parameters 3.3. Reference qty or % see the desired application program
description
5. through 7. appliesonly if an interface isinstalled; see the corresponding instructions
8. Extra functions 8.1. Menu 8.1.1 Parameter settings: alterable
8.1.2 Parameter settings: read only
8.2. External switch function appliesonly if an interface isinstalled;
see the corresponding instructions
8.3. Power-on mode 8.3.1 Off/ on (battery shutsoff
automatically after 3 min)
8.3.2 Standby/ on
9. Resetmenu 9.Factory settings 9.1 Reset
9.2 Do notreset
* = only for BLmodels
* * = not for modelswith a readability of 0.1 mg
Menulevel1
Menulevel2
Menulevel3
Factorysetting
Menulevel4
