oserio FEP-103 SERIES User manual

www.oserio.com
130-FEP103-001 05/2013
Body Fat Monitor Instrucon Manual – FEP-103 series
Body Fat Monitor
Thank you for selecng oserio series of Health Management Products.
This Instrucon Manual will guide you through the setup procedures and outline the key features.
Made in Taiwan
Please keep the instrucon manual at hand all the me for future reference.
Manufactured by:
Charder Electronic Co., Ltd.
No.103, Guozhong Rd., Dali Dist.,Taichung City, 412 Taiwan (R.O.C.)

Health conscious•Professional•Innovave

1
19
21
22
24
26
27
28
30
32
33
Table of Contents Operang Instrucons
34
35
More Informaon
3.1 Care and Maintenance
3.2 Product Specificaon
FEP-103 series
Body Fat Monitor
6
Front Rear
Reset buon*
Baery Cover
Plaorm
User buons
Seng buons
LCD display
NOTE:
Before Using the Monitor
1.1 Overview
*Aer turning on the unit, press reset buon for 3 seconds to erase all profiles and records.
RESET
1
4
3
2
Before Using the Monitor
1
2
3
4
5
7
8
11
18
1.1 Overview
1.2 User Key / Power Key
1.3 Seng Buons
1.4 Baery Installaon
1.5 Product Features
1.6 Introducon
1.7 Important Safety Notes
1.8 EMC Guidance and
Manufacturer's Declaraon
1.9 Used Symbol Descripon
2.1 Seng Time
2.2 Viewing and Modifying Time
2.3 Seng User Profile
2.4 Measuring Body Composion
2.5 Viewing Measurement Values
2.6 Taking Weight Measurement Only
2.7 Viewing Historical Values
2.8 Modifying User Profile
2.9 Seng Visitor Profile
2.10 Error Message List
6
5

2
1
2
3 4 5
1
3
2
5
4
Before Using the Monitor
1.2 User Key / Power Key
Before Using the Monitor
1.3 Seng Buons
User key1
User key 2
Power key (Taking weight only)
User key 3
User key 4
1. Press power key to turn on the unit for taking weight only.
2. Press user key to turn on the unit for taking body composion.
Note: *Confirm seng
*Modify user profile
*Increase seng values
*Select items
*Change reading items
*Decrease seng values
*Select items
*Change reading items
*Check me by pressing it one me
*Modify me by press it for 1 second
*View the last reading
*View the memorized values
*View the next reading
*Set VISITOR’s profile
3

4
12
5
Before Using the Monitor
1.4 Baery Installaon
Before Using the Monitor
1.5 Product Features
Note:
Please verify if the baeries are installed correctly first
Open the baery cover Install 4 AA size baeries properly
1. Measurements and user’s profile will not be erased during baery replacement.
2. Be sure that the polarity of the baery is set properly.
Body Fat References：Daniel P. Williams, Sco B. Going, Timothy G. Lohman, David W. Harsha, Satharnur R Srinivasan, Larry S.
Webber, Gerald S. Berenson, Body fatness and risk for elevated blood pressure, total cholesterol, and serum lipoprotein raons in
children and adolescents American journal of public health, March 1992, Vol. 82, No.3
1. Measure weight, body fat, BMI, visceral fat, basal metabolic rate, muscle rate and body age.
2. 4 users profile.
3. 7 historical values.
4. Target weight seng.
5. Data reference from Body fatness and risk for elevated blood pressure, total cholesterol, and serum
lipoprotein in children and adolescents American journal of public health. Aer compared measurement
value, indicator will shows “Low, Normal, High, Very High.”

6 7
Before Using the Monitor
1.5 Product Features
6. Slip prevenon design.
7. Large LCD display. (80x60mm)
8. Simple buon design.
9. English interface.
10. User friendly design with colorful and interesng face icons.
Before Using the Monitor
1.6 Introducon
Product descripon: This unit is measuring the user’s body weight and to esmate the value of
the Bio-Impedance body composion.
Product use: Body Fat, Visceral Fat, BMI, BMR, Muscle Rate, Body Age and Body Weight.
Measuring Principle: Biological impedance Analysis (BIA) works together with such as gender,
height, weight, age, other relevant factors, conversion of the user’s body
composion to determine whether the body is obese.
(If input profile is incorrect, it would result in incorrect measurement values.)
Recommended Measurement Times: It is recommended to use this unit in the same
environment and daily circumstances.

8 9
1. People with an electronic medical implant, such as a pacemaker, should not use a Body Fat Monitor
as it passes a low-level electrical signal through the body, which may interfere with its operaon.
2. Pregnant women should use weight funcon only. All other funcons are not
intended for pregnant women.
3. Keep out of reach of young children.
4. Do not jumping on the unit plaorm.
5. Do not step on the edge of unit plaorm.
6. Person with disabilies or physically frail should be assisted by another
person when using this unit.
7. Do not disassemble or modify the unit.
8. Using the baeries specify by the product specificaons, polaries match
the polaries of the baery compartment as indicated.
9. Remove the baeries if the unit not be used for three months or longer.
10. If the display not shows, check the baeries.
11. Do not mix old and new baeries or different types of baeries to extend the life of the unit.
12. Do not use the unit on slippery surfaces such as le floors or wet floors.
13. Place the unit in an area free from direct sunlight, heang equipment, high humidity or extreme
temperature change.
14. Avoid excessive impact or vibraon to the unit.
15. Never submerge in water. Use alcohol to clean the electrodes and glass cleaner (applied to a cloth first)
to keep them shiny.
16. Place the unit on a hard, flat surface where there is minimal vibraon
to ensure safe and accurate measurement.
1.7 Important Safety Notes 1.7 Important Safety Notes
Before Using the MonitorBefore Using the Monitor

10
Before Using the Monitor
1.7 Important Safety Notes
11
Before Using the Monitor
1.8 EMC Guidance and Manufacturer's Declaraon
Guidance and manufacturer’s declaraon-electromagnec emissions
The FEP-103 is intended for use in the electromagnec environment specified below. The customer or the user of the
FEP-103 should assure that it is used in such an environment.
Emission test Compliance Electromagnec environment-guidance
RF emissions
CISPR 11
RF emissions
CISPR 11
Group 1
Class B
The FEP-103 uses RF energy only for its internal funcon. Therefore, its
RF emissions are very low and are not likely to cause any interference in
nearby electronic equipment.
The FEP-103 is suitable for use in all establishments, including domesc
establishments and those directly connected to the public low-voltage
power supply network that supplies buildings used for domesc
purposes.
Harmonic
emissions
IEC 61000-3-2
Voltage
fluctuaons/flicker
emissions
IEC 61000-3-3
Not applicable
Not applicable
17. Always remove your socks or stockings, and be sure the soles of your feet are clean before stepping
on the measuring plaorm.
18. Properly dispose of baeries according to applicable local regulaons.
19. Do not use this unit while operaon transmiers (such as a cell phone) as this may affect your results.
20. This unit is intended for home use only. It is not intended for professional use in hospitals or other
medical facilies.
21. These baeries should be kept away from small children.
If swallowed , promptly seek medical assistance.
22. Expected Service Life: 5 years
23. IP (Ingress Protecon) rang: IP21

12 13
Before Using the Monitor
1.8 EMC Guidance and Manufacturer's Declaraon
The FEP-103 is intended for use in the electromagnec environment specified below. The customer or the user of the
FEP-103 should assure that it is used in such an environment.
Guidance and manufacturer’s declaraon-electromagnec immunity Guidance and manufacturer’s declaraon-electromagnec immunity
Immunity test IEC 60601 test level Compliance level Electromagnec environment-guidance
Immunity test IEC 60601 test level Compliance level Electromagnec environment-guidance
Electrostac
discharge(ESD)
IEC 61000-4-2
Electrical fast
transient/burst
IEC 61000-4-4
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, concrete or ceramic
le. If floors are covered with synthec
material, the relave humidity should be at
least 30%.
± 2kV for power supply
lines + 1kV for
input/output lines
± 2kV for power
supply lines
Not applicable
Mains power quality should be that of a
typical commercial or hospital environment.
Surge
IEC 61000-4-5
± 1kV line(s) to line(s)
± 2kV line(s) to earth
± 1kV differenal
mode
Not applicable
Mains power quality should be that of a
typical commercial or hospital environment.
Voltage Dips,
short interrupt-
ions and voltage
variaons on
power supply
input lines
IEC 61000-4-11
<5% UT(>95% dip in UT)
for 0.5 cycle
40% UT(60% dip in UT)
for 5 cycles
70% UT(30% dip in UT)
for 25 cycles
<5% UT(>95% dip in UT)
for 5 s
Mains power quality should be that of a
typical commercial or hospital environment.
If the user of the FEP-103 requires connued
operaon during power mains
interrupons, it is recommended that the
FEP-103 be powered from an uninterrupble
power supply or a baery.
Not applicable
Not applicable
Not applicable
Not applicable
Power frequency
(50/60 Hz)
magnec field
IEC 61000-4-8
3 A/m 3 A/m The FEP-103 power frequency magnec
fields should be at levels characterisc of a
typical locaon in a typical commercial or
hospital environment.
NOTE: UT is the a.c. mains voltage prior to applicaon of the test level.

14 15
Before Using the Monitor
1.8 EMC Guidance and Manufacturer's Declaraon
Guidance and manufacturer’s declaraon-electromagnec immunity
Immunity test IEC 60601 test level Compliance level Electromagnec environment-guidance
Conducted RF
IEC 61000-4-6
3 Vrms
150 KHz to 80 MHz
Not applicable Portable and mobile RF communicaons equipment should be
used no closer to any part of the FEP-103 including cables, than
the recommended separaon distance calculated from the
equaon applicable to the frequency of the transmier.
NOTE1:
At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2:
These guidelines may not apply in all situaons.
Electromagnec propagaon is affected by absorpon and
reflecon from structures, objects and people.
Field strengths from fixed transmiers, such as base
staons for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast
and TV broadcast cannot be predicted theorecally with
accuracy. To assess the electromagnec environment due
to fixed RF transmiers, an electromagnec site survey
should be considered. If the measured field strength in the
locaon in which the FEP-103 should be observed to verify
normal operaon. If abnormal performance is observed,
addional measures my be necessary, such as re-orienng
or relocang the FEP-103.
Over the frequency range 150 kHz to 80 MHz, field
strengths should be les than 3 V/m.
A.
B.
Radiated RF
IEC 61000-4-3
3 V/m
80MHz to 2.5 GHz
3 V/m
Where P is the maximum output power rang of the transmier in
was (W) according to the transmier manufacturer and d is the
recommended separaon distance in metres (m).
Interference may occur in the vicinity of
equipment marked with the following symbol:
Field strengths from fixed RF transmiers, as determined by an
electromagnec site survey , should be less than the compliance level in
each frequency range .
b
a
Recommended separaon distance:
d = 1.2 P
d = 1.2 P 80MHz to 800 MHz
d = 2.3 P 800MHz to 2.5 GHz

16 17
Before Using the Monitor
1.8 EMC Guidance and Manufacturer's Declaraon
0.01 0.12
0.38
1.2
3.8
12
0.23
0.73
2.3
7.3
23
N/A
N/A
N/A
N/A
N/A
0.1
1
10
100
Recommended separaon distance between portable and mobile RF communicaons equipment and the FEP-103
The FEP-103 is intended for use in an electromagnec environment in which radiated RF disturbances are controlled. The customer or
the user of the FEP-103 can help prevent electromagnec interference by maintaining a minimum distance between portable and
mobile RF communicaons equipment (transmiers) and the FEP-103 as recommended below, according to the maximum output
power of the communicaons equipment.
Rated maximum output
power of transmier
(W)
For transmiers rated at a maximum output power not listed above, the recommended separaon distance d in meters (m) can be
esmated using the equaon applicable to the frequency of the transmier, where p is the maximum output power rang of the
transmier in was (W) according to the transmier manufacturer.
NOTE1:
At 80 MHz and 800 MHz, the separaon distance for the higher frequency range applies.
NOTE2:
These guidelines may not apply in all situaons. Electromagnec propagaon is affected by absorpon and reflecon from
structures, objects and people.
Separaon distance according to frequency of transmier
(m)
150 kHz to 80 MHz
d =1.2 P
80 MHz to 800 MHz
d =1.2 P
800 MHz to 2.5 GHz
d =2.3 P

19
34
1 2
Operang Instrucons
2.1 Seng Time
Press Power key to
turn on the unit.
(1st using)
1. Welcoming
2. Year seng
3. Month seng
4 Date seng
Next Page
Press to modify values and
press to confirm entries.
It will switch to “Time seng mode” automacally if me seng procedure has not been completed.
Date/Time need to be reset during baery replacement.
The unit will shut down automacally if you do not touch any buons within 60 seconds
Note:
Before Using the Monitor
18
1.9 Used Symbol Descripon
Explanaon of the graphic symbols:
SN-135-00001
Designaon of the serial number of every device,
applied at the device.
(Number as an example)
“Please note the accompanying documents“ or
“Observe operang instrucons”
Idenficaon of manufacturer of medical product
including address
Charder Electronic Co., Ltd.
No.103, Guozhong Rd.,
Dali Dist.,Taichung City,
412 Taiwan (R.O.C.)
“Electro-medical appliance“ with aachment for
type BF
Carefully read this operaon manual before
setup and commissioning, even if you are
already familiar with oserio scales.
Dispose of old appliances separately from your
household waste!Instead, take them to
communal collecon points.
Transport and storage temperature limit
indicang the upper and the lower limit.
(Transport and storage temperature on
packaging)
+60˚C
-20˚C

20
65 7
21
23 4
5
1
Operang Instrucons
2.1 Seng Time
Operang Instrucons
2.2 Viewing and Modifying Time
Press to modify values and press to
complete me seng.
Note:
When me seng is completed please restart the unit to take measurement.
Note:
Show today’s date
8
Show the me now
9
Shut down automacally
5. Hour seng
6. Minute seng
7. Show the date
8. Show the me
9 The unit will shut down automacally aer seng procedure is completed.
1. Press user key to turn on
2. Geng Started
3. Show the date
4. Show the me
5. Switch to Time seng mode
Back
Show 1 sec.
Press
Press 1 sec.
Show 1 sec.
If you press power key to turn on and enter “Weight Measurement Mode,”
you are able to view or modify me as well by pressing .

2322
321 5 76 48
910 11
2.3 Seng User Profile
Operang Instrucons
Note:
1. Press user key to turn on
2. Welcoming
3. Show the date
4. Birthday seng- Year
5. Birthday seng- Month
6. Birthday seng- Date
7. Gender select
8. Specify the height
9. Set target weight
10. Seng completed and the display will show the entries of age and height.
11. Seng completed while 0.0kg is shown.
The unit will shut down automacally aer you turn on it and do not operate the unit within 20 seconds.
The unit will shut down automacally if you do not touch any buons within 60 seconds.
The unit is running calibraon procedure while the display shows the date. Please do not step on the unit.
Press
1 second to
change the
value quickly
Press
1 second to
change the
value quickly
Press to set birthday - year Press to set birthday - month Press
1 second to
change the
value quickly
Press to set birthday - day Press
1 second to
change the
value quickly
Press to set heightPress to set gender
Press to set target weight User profile seng is completed.
Press to
confirm entries
Press to
confirm entries
Press to
confirm entries
Press to
confirm entries
Remain sll and do
not move unl the
measurement is
completed.
STEP ON

24
45
21 3
25
7 86
Operang Instrucons
2.4 Measuring Body Composion
1. Press user key to turn on
2. Welcoming
3. Show the date
4. Show user’s profile (age and height)
5. Get ready to take measurement while 0.0kg is shown
Remain sll and do
not move unl the
measurement is
completed.
STEP ON
Note:
The unit will shut down automacally aer you turn on it and do not operate the unit within 20 seconds.
The unit is running calibraon procedure while the display shows the date. Please do not step on the unit.
(DO NOT step on the plaorm) No.2 user profile has been set
Measuring body composion
Press to view historical values,
please refer to page 20.
6. Show weight
7. Measure body composion
8. Show measurement values
Step off and view
the values.
請不要下秤!!
DO NOT Step off
and remain sll
unl body fat %
is shown.
STAY

3 seconds
27
2 3 4 51
26
Operang Instrucons
2.5 Viewing Measurement Values
Operang Instrucons
2.6 Taking Weight Measurement Only
Remain sll and do
not move unl the
measurement is
completed.
STEP ON
Note:
The unit will shut down automacally aer you turn on it and do not operate the unit within 20 seconds.
The unit is running calibraon procedure while the display shows the date. Please do not step on the unit.
(DO NOT step on the plaorm)
Press to show the next/previous measurement value
View user’s reading aer measuring body composion
641 3 5 72
Note:
Each measurement value last for 3 seconds.
The unit will shut down automacally if you do not touch any buons within 60 seconds.
1. Body Fat
2. Weight
3. Body Mass Index (BMI)
4. Body Age
5. Visceral Fat Level
6. Basal Metabolic Rate (BMR)
7. Muscle Rate
1. Press power key to turn on
2. Welcoming
3. Show the date
4. Ready to take measurement while 0.0kg is shown
5. Show weight reading

29 28
2nd
3rd
.
.
.
Operang Instrucons
2.7 Viewing Historical Values
Press to show the next/previous measurement value
While viewing user’s reading aer measuring body composion, press to view historical values.
View user’s reading aer measuring body composion
No historical values are memorized for visitor.
Press
Recurrence
1st memorized measurement
Press to toggle
through last 7 memorized
measurements.
1. 1st memorized body fat
2. 1st memorized weight
3. 1st memorized BMI
4. 1st memorized body age
5. 1st memorized visceral fat
6. 1st memorized BMR
7. 1st memorized muscle rate
Up to last 7 measurements
5 6 71 2 3 4

3130
67
910
Operang Instrucons
2.8 Modifying User Profile
45
21 3
(DO NOT step on the plaorm) No.2 user profile has been set
Press
1. Press user key to turn on
2. Welcoming
3. Show the date
4. Show user’s profile ( age and height)
5. Press set buon to modify user’s rpofile while the display appears 0.0kg
6. Press to choose “MODIFY” or “DELETE”
7. Modify birthday, gender, height, target weight item by item.
8. Delete user’s profile
9. Confirm your selecon to delete user’s profile
10. Deleon is completed
Note:
The unit will shut down automacally aer you turn
on it and do not operate the unit within 60 seconds.
8
“MODIFY” flickers
“DELETE” flickers Delete?
If not, press to back
to stage 8
Press to
confirm entries
Press to
confirm entries
Press to
confirm entries
Press to
choose “Delete”
Enter user profile seng
aer 2 seconds.
Note:
Delete: Delete all memorized values of stated user.
Modify: Modify staed user’s profile only and keep all the memorized values.
Refer to page 22 for modifying user profile.

32
2 3 54
1
33
Operang InstruconsOperang Instrucons
2.9 Seng Visitor Profile 2.10 Error Message List
Note:
The unit will shut down automacally aer you turn on it and do not operate the unit within 20 seconds.
The unit will shut down automacally if you do not touch any buons within 60 seconds.
The unit is running calibraon procedure while the display shows the date. Please do not step on the unit.
1. Press to turn on
2. Welcoming
3. Show the date
4. Set visitor’s birthday, gender and height
5. Get ready to take measurement while 0.0kg is shown
Refer to page 22 for
user profile sengs
Remain sll and do
not move unl the
measurement is
completed.
STEP ON
The product is low power but sll
workable while flickers.
Replace baeries immediately while
“LO” appears.
Overloading or loading is unbalanced
within 1 minute. Please stand sll
during measurement.
The value of body fat is beyond the
product specificaon.
The value of muscle rate is beyond
the product specificaon.
The value of BMR is beyond the
product specificaon.
The value of visceral fat is beyond
the product specificaon.
Please restart the unit and run
calibraon procedure again.
The date or birthday seng is incorrect,
please modify the date or birthday .

34 35
More Informaon
3.1 Care and Maintenance
1. Store the unit in a safe and dry locaon.
2. Avoid place on the aisle, to avoid accidentally tripped over
pedestrians.
3. Never submerge in water.
4. Do not expose the unit to direct sunlight, extreme hot or cold temperatures
or high humidity.
5. Avoid contact with corrosive chemicals or gas.
6. Clean the unit with a so dry cloth for daily use.
7. Wipe the plaorm and display using clean so cloth.
8. Do not use benzene, detergents or gasoline to clean the unit.
9. Avoid rough, scking cloth, to prevent scratching the plaorm and screen panels.
10. Prevent water infiltraon affecng the measurement accuracy.
5~150kg：±1%
More Informaon
3.2 Product Specificaon
Model Body Fat Monitor FEP-103
Note: 1. Body fat measurement is for users age 10~80.
2. Specificaons may be changed without prior noce.
External Dimensions Main unit: 300mm(d) x 310mm(w) x 42mm(h) LCD: 80mm(d) x 60mm(w)
Weight Accuracy Memory 4 users and 1 visitor, 7 historical values
Seng Range Birthday:1930~2030 Gender: Male/Female Height: 100~199.5cm Target weight: 10~150kg
Power Supply Weight Approx. 1.3kg4 AA baeries
Operang Environment
Limit
Storage Environment
Limit
Temperature 5˚C to 35˚C
Humidity 30% to 85% RH
Temperature -20˚C to 60˚C
Humidity 10% to 95% RH
Display Content Weight: 5 ~ 150kg, Graduaon: 0.1kg
Body Fat: 5.0 ~ 50.0%, Graduaon: 0.1%
Body Fat Status Category: Low/Normal/High/Very High
Visceral Fat Status Category: 1~3(Normal)/4~6(High)/7~9(Very High)
BMI: 0.0~150.0, Graduaon: 0.1
Muscle Rate: 0.0~100.0%, Graduaon: 0.1%
BMR: 385~3999 kcal, Graduaon: 1 kcal
Body Age: 18~80
Visceral Fat Level: Level 1~9 with 1 level increment
Manual, Warranty card
Accessories
