Digital Equipment DEClaser 1100 Series User manual

DEClaser1100SeriesPrinter
ServiceGuide
EK–DCL11–SV. B01
Digital Equipment Corporation
Maynard, Massachusetts

First Printing, December 1990
Revised, November 1992
The information in this document is subject to change without notice and should not be
construed as a commitment by Digital Equipment Corporation. Digital Equipment Corporation
assumes no responsibility for any errors that may appear in this document.
The software described in this document is furnished under a license and may be used or copied
only in accordance with the terms of such license.
No responsibility is assumed for the use or reliability of software on equipment that is not
supplied by Digital Equipment Corporation or its affiliated companies.
Restricted Rights: Use, duplication, or disclosure by the U.S. Government is subject to
restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer
Software clause at DFARS 252.227-7013.
© Digital Equipment Corporation 1992.
All Rights Reserved.
Printed in U.S.A.
The following are trademarks of Digital Equipment Corporation: A–to–Z, DECnet, DECprint,
DECwindows, DECwrite, MicroVAX, MicroVMS, OpenVMS, PrintServer, Scholar, TK, ULTRIX,
VAX, VAXcluster, VAX DOCUMENT, VAXstation, VMS, VT, and the DIGITAL logo.
The following are third-party trademarks:
PostScript is a registered trademark of Adobe Systems, Incorporated, which may be registered
in certain jurisdictions. AppleTalk, LocalTalk, LaserWriter, and Macintosh are registered
trademarks of Apple Computer, Inc. LaserJet is a registered trademark of Hewlett Packard
Corporation. Centronics is a trademark of Centronics Data Computer Corporation., and
Tektronix is a registered trademark of Tektronix, Inc. S1882
This document was prepared using VAX DOCUMENT, Version 2.1.

FCC NOTICE:
115 Volt model only
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. Any changes or modifications made
to this equipment may void the user’s authority to operate this equipment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
To meet FCC requirements a properly shielded parallel cable is required to connect the device to
a personal computer or other Class B device.
This document was prepared using VAX DOCUMENT, Version 2.1.

Contents
Preface ..................................................... xiii
1 Physical and Functional Description
1.1 Description of the DEClaser 1100 Series Printers . . . . . . . . . . . . 1–1
1.2 PrinterComponents................................... 1–1
1.3 Media Feeders and Paper Paths . . . . . . . . . . . . . . . . . . . . . . . . . 1–10
1.3.1 TrayPaperPath................................... 1–10
1.3.2 Optional Cassette Paper Path . . . . . . . . . . . . . . . . . . . . . . . . 1–11
1.3.3 CassetteSizeSensing .............................. 1–11
1.4 Switches, Sensors, and Solenoids . . . . . . . . . . . . . . . . . . . . . . . . 1–13
1.5 Electronic Block Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–14
1.6 InterfaceBoard ...................................... 1–16
1.7 DEClaser 1100 and 1150 Printer Video Control Board . . . . . . . . . 1–16
1.8 DC Control Board Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–18
1.9 LVPSA, Main Motor, and Interlock Diagram . . . . . . . . . . . . . . . . 1–22
1.10 Fixing Heater Control Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–23
1.11 HVPSADensityCircuits ............................... 1–25
1.11.1 DensityAdjustment................................ 1–25
1.11.2 HVPSACircuits................................... 1–26
2 DEClaser 1100 Printer Control Panel
2.1 ControlPanelModes .................................. 2–1
2.2 DEClaser 1100 Printer Control Panel Keys and Indicators . . . . . 2–2
2.3 Navigating Through the Setup Menu . . . . . . . . . . . . . . . . . . . . . 2–5
2.4 SetupMenuFormat................................... 2–6
2.5 Moving, Selecting, and Saving Values . . . . . . . . . . . . . . . . . . . . . 2–6
2.6 FONT/FEED ........................................ 2–8
2.7 LAYOUT ........................................... 2–9
2.8 COPY/OVERLAY..................................... 2–9
2.9 COMMAND......................................... 2–9
2.10 INITIAL............................................ 2–10
v

2.10.1 macro........................................... 2–10
2.10.2 paint ........................................... 2–11
2.10.3 paper ........................................... 2–11
2.11 INTERFACE ........................................ 2–12
2.11.1 i/f.............................................. 2–12
2.11.2 baud............................................ 2–13
2.11.3 rsmode.......................................... 2–13
2.11.4 dtr ............................................. 2–13
2.11.5 xon/xoff ......................................... 2–13
2.11.6 etx/ack.......................................... 2–14
2.12 SAVE–>RAM ........................................ 2–14
2.13 SAVE–>NVRAM...................................... 2–14
2.14 LOAD<–ROM ....................................... 2–14
2.15 Control Representation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–15
2.16 Tray (Page Format) Size Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 2–16
2.17 Emulation and Video Mode Menu . . . . . . . . . . . . . . . . . . . . . . . . 2–17
3 DEClaser 1152 Printer Control Panel
3.1 DEClaser 1152 Control Panel Keys and Indicators . . . . . . . . . . . 3–2
3.2 Navigating Through the Setup Menus . . . . . . . . . . . . . . . . . . . . . 3–4
3.3 MenuDescriptions.................................... 3–5
3.3.1 InterfaceSelection................................. 3–5
3.3.2 INTERFACEMenu ................................ 3–5
3.3.2.1 I/F: SERIAL (I/F: SERIALB) Menu . . . . . . . . . . . . . . . . . 3–8
3.3.2.2 I/F:PARALLELMenu ........................... 3–12
3.3.2.3 I/F:LocalTalkMenu............................. 3–13
3.3.3 PCL4SETUPMenu................................ 3–13
3.3.3.1 SelectingFonts ................................ 3–17
3.3.4 PAPERHANDLINGMenu........................... 3–19
3.3.5 MISCELLANEOUSMenu ........................... 3–21
3.4 Selecting the Input Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–23
4 DEClaser 1100 Printer Test Prints
4.1 DEClaser 1100 Printer Test Print A . . . . . . . . . . . . . . . . . . . . . . 4–2
4.2 DEClaser 1100 Printer Test Print B . . . . . . . . . . . . . . . . . . . . . . 4–4
4.3 DEClaser 1100 Printer Font List A . . . . . . . . . . . . . . . . . . . . . . . 4–6
4.4 DEClaser 1100 Printer Cleaning Test . . . . . . . . . . . . . . . . . . . . . 4–6
4.5 DEClaser 1100 Printer Engine Test Print . . . . . . . . . . . . . . . . . . 4–8
vi

5 DEClaser 1152 Printer Test Prints
5.1 DEClaser 1152 Printer Test Print . . . . . . . . . . . . . . . . . . . . . . . . 5–2
5.2 DEClaser 1152 Printer PCL Emulator Test Page . . . . . . . . . . . . . 5–4
5.3 DEClaser 1152 Printer Cleaning Test Page . . . . . . . . . . . . . . . . . 5–6
5.4 DEClaser 1152 Printer Engine Test Print . . . . . . . . . . . . . . . . . . 5–8
6 Control Panel Messages FIPs
6.1 ControlPanelMessages ............................... 6–1
6.2 StatusMessages ..................................... 6–1
6.3 OperatorCallFIP .................................... 6–3
6.4 DEClaser 1100 Printer Functional FIP . . . . . . . . . . . . . . . . . . . . 6–13
6.5 ServiceFIP ......................................... 6–17
7 Paper Jam FIPs
7.1 Jams and Paper Misfeeding . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–2
7.1.1 JamEntrySubmenu ............................... 7–3
7.2 Detecting and Clearing Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–4
7.3 Power-UpJams ...................................... 7–5
7.4 TrayAreaPickupJams ................................ 7–6
7.5 Cassette Area Pickup Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–8
7.6 Fixing and Delivery Area Jams . . . . . . . . . . . . . . . . . . . . . . . . . . 7–9
8 Image Defects FIPS
8.1 ImageDefectsFIP.................................... 8–1
8.2 LightPrinting ....................................... 8–4
8.3 DarkPrinting........................................ 8–5
8.4 Sheet Is Completely Blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–5
8.5 SheetIsAllBlack .................................... 8–6
8.6 In-lineVerticalSpots.................................. 8–6
8.7 Toner on Reverse Side of Paper . . . . . . . . . . . . . . . . . . . . . . . . . . 8–6
8.8 VerticalBlackStreaks ................................. 8–7
8.9 Black, Irregular, and Smudged Vertical Bands . . . . . . . . . . . . . . 8–7
8.10 Black, Irregular, and Smudged Horizontal Bands . . . . . . . . . . . . 8–7
8.11 Blank Spots in Dark Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–8
8.12 Solid White Vertical Lines in Dark Areas . . . . . . . . . . . . . . . . . . 8–8
8.13 Bad Leading Edge Registration . . . . . . . . . . . . . . . . . . . . . . . . . . 8–9
8.14 BadFixing ......................................... 8–9
8.15 WrinkledandTornPaper............................... 8–10
8.16 Background Staining on Envelopes . . . . . . . . . . . . . . . . . . . . . . . 8–11
vii

9 Recommended Spares List and Parts Locator
9.1 Recommended Spares List (RSL) . . . . . . . . . . . . . . . . . . . . . . . . 9–1
9.2 PartsLocator........................................ 9–3
10 Removal and Replacement Procedures and RSL
10.1 RearCover ......................................... 10–2
10.2 UpperCover ........................................ 10–3
10.3 Right and Left Side Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–5
10.4 Optional Paper Feeder Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–6
10.5 Front (Multipurpose) Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–7
10.5.1 Front Cover (Door) Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–8
10.6 ControlPanel ....................................... 10–13
10.7 Fan ............................................... 10–16
10.8 Low-Voltage Power Supply Assembly (LVPSA) . . . . . . . . . . . . . . 10–17
10.9 Stepping(Main)Motor ................................ 10–21
10.10 Paper Tray Pickup Roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–22
10.11 SeparationPad ...................................... 10–24
10.12 Handling the Optical Components . . . . . . . . . . . . . . . . . . . . . . . . 10–25
10.12.1 LaserAssembly ................................... 10–28
10.12.2 Handling the Scanner Assembly . . . . . . . . . . . . . . . . . . . . . . 10–31
10.12.2.1 Lens and Scanner Assembly . . . . . . . . . . . . . . . . . . . . . . 10–32
10.13 EP-LCartridge ...................................... 10–36
10.14 Transfer Charging Roller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–38
10.15 FixingUnit ......................................... 10–40
10.16 DriveAssembly ...................................... 10–43
10.16.1 DrumDriveUnit ................................. 10–45
10.17 Density Adjustment Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–46
10.18 InterfaceBoard ...................................... 10–49
10.19 DC Control Unit (DCU) or DC Control Board . . . . . . . . . . . . . . . 10–51
10.20 Video Control Unit (VCU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–56
10.20.1 VideoControlBoard ............................... 10–61
10.20.2 Optional RAM and Expansion Memory . . . . . . . . . . . . . . . . . 10–64
10.21 High-Voltage Power Supply Assembly (HVPSA) . . . . . . . . . . . . . 10–66
10.22 Cassette Paper Feeder Board . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–68
10.23 DoorRodAssembly ................................... 10–70
10.24 Paper Exit and Door/EP-L Sensor . . . . . . . . . . . . . . . . . . . . . . . . 10–73
10.25 Feed Roller and Paper Pickup Sensor (PS13) Assembly . . . . . . . 10–74
viii

A General Information
A.1 Extended Service Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–1
A.2 MacroNumbers...................................... A–2
A.2.1 Examples Using the Macro Feature . . . . . . . . . . . . . . . . . . . . A–4
A.3 Interface Interconnections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–4
A.3.1 ParallelPort ..................................... A–4
A.3.2 SerialPort....................................... A–7
A.3.3 DEClaser 1100 Video Port . . . . . . . . . . . . . . . . . . . . . . . . . . . A–8
A.3.4 DEClaser 1152 LocalTalk Interface Specifications . . . . . . . . . A–9
A.3.5 DEC423 Interface Specifications . . . . . . . . . . . . . . . . . . . . . . A–9
A.4 Interface Cables and Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . A–10
B DEClaser 1100 Series Printers Specifications
B.1 PrintMedia ......................................... B–1
B.1.1 Paper Handling and Storage . . . . . . . . . . . . . . . . . . . . . . . . . B–1
B.1.2 Available Standard Size Cassettes . . . . . . . . . . . . . . . . . . . . . B–2
B.1.3 Envelopes........................................ B–3
B.1.4 Transparencies.................................... B–4
B.2 Labels ............................................. B–5
B.3 Operating Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B–5
C Total Call Concept
C.1 Performing Total Call Concept . . . . . . . . . . . . . . . . . . . . . . . . . . . C–1
C.2 MaintenanceLog ..................................... C–1
C.3 Preventive Maintenance Procedure . . . . . . . . . . . . . . . . . . . . . . . C–1
C.4 TCCProcedure....................................... C–2
C.4.1 Cleaning and Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C–2
D Training, Tools, and Documentation
D.1 DEClaserTraining.................................... D–1
D.2 Tools .............................................. D–2
D.3 Documentation Ordering Information . . . . . . . . . . . . . . . . . . . . . D–2
ix

Index
Figures
1–1 Components: Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2
1–2 Components: External Rear View . . . . . . . . . . . . . . . . . . . . . 1–4
1–3 Components: Internal Rear View . . . . . . . . . . . . . . . . . . . . . 1–6
1–4 Components: Internal View . . . . . . . . . . . . . . . . . . . . . . . . . . 1–8
1–5 TrayPaperPath................................... 1–10
1–6 CassettePaperPath ............................... 1–11
1–7 Switches, Sensors, and Solenoids . . . . . . . . . . . . . . . . . . . . . 1–13
1–8 1100 Overall Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . 1–15
1–9 The DEClaser 1100 and 1150 Video Control Board . . . . . . . . 1–17
1–10 DC Control Board Input Signals . . . . . . . . . . . . . . . . . . . . . . 1–19
1–11 DC Control Board Output Signals . . . . . . . . . . . . . . . . . . . . . 1–20
1–12 LVPSABlockDiagram ............................. 1–22
1–13 Fixing Heater Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–23
1–14 DensityAdjustment................................ 1–25
1–15 HVPSAImageCircuits ............................. 1–26
2–1 DEClaser 1100 Printer Control Panel Indicators . . . . . . . . . 2–2
2–2 DEClaser 1100 Printer Keypad Operation . . . . . . . . . . . . . . 2–5
2–3 Setup Menu Display Text . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–6
3–1 DEClaser 1152 Printer Control Panel Indicators . . . . . . . . . 3–2
3–2 DEClaser 1152 Keypad Operation . . . . . . . . . . . . . . . . . . . . . 3–4
4–1 DEClaser 1100 Printer Test Print A . . . . . . . . . . . . . . . . . . . 4–3
4–2 DEClaser 1100 Printer Test Print B . . . . . . . . . . . . . . . . . . . 4–5
4–3 DEClaser 1100 Printer Cleaning Test Print . . . . . . . . . . . . . . 4–7
4–4 DEClaser 1100 Printer Engine Test Print . . . . . . . . . . . . . . . 4–9
5–1 DEClaser 1152 Printer Test Print . . . . . . . . . . . . . . . . . . . . . 5–3
5–2 DEClaser 1152 Printer PCL Emulator Test Page . . . . . . . . . . 5–5
5–3 DEClaser 1152 Printer Cleaning Test Print . . . . . . . . . . . . . . 5–7
5–4 DEClaser 1152 Printer Engine Test Print . . . . . . . . . . . . . . . 5–9
8–1 Image Defect Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–3
9–1 PartsLocator1 ................................... 9–3
9–2 PartsLocator2 ................................... 9–5
9–3 FeederPartsLocator ............................... 9–7
10–1 Optical Cavity Components . . . . . . . . . . . . . . . . . . . . . . . . . . 10–27
x

10–2 LaserAssembly ................................... 10–28
10–3 ScannerAssembly ................................. 10–31
Tables
1–1 Printer Components: Front View . . . . . . . . . . . . . . . . . . . . . . 1–3
1–2 Printer Components: External Rear View . . . . . . . . . . . . . . . 1–5
1–3 Printer Components: Internal Rear View . . . . . . . . . . . . . . . 1–7
1–4 Printer Components: Internal View . . . . . . . . . . . . . . . . . . . . 1–9
1–5 Cassette Size-Sensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–12
2–1 DEClaser 1100 Printer Control Panel Indicators and
Keys............................................ 2–2
2–2 MenuScrollingKeys ............................... 2–6
2–3 Setup, Feature, and Value Menus . . . . . . . . . . . . . . . . . . . . . 2–7
3–1 DEClaser 1152 Control Panel Indicators and Keys . . . . . . . . 3–2
3–2 MenuScrollingKeys ............................... 3–4
3–3 INTERFACEMenu ................................ 3–6
3–4 I/F: SERIAL (I/F: SERIALB) Menu . . . . . . . . . . . . . . . . . . . . 3–8
3–5 Restrictions on the Interaction Between Communications
Options ......................................... 3–11
3–6 I/F:PARALLELMenu .............................. 3–12
3–7 I/F:LocalTalkMenu................................ 3–13
3–8 PCL4SETUPMenu................................ 3–14
3–9 SelectingFonts ................................... 3–17
3–10 PAPERHANDLINGMenu........................... 3–19
3–11 MISCELLANEOUSMenu ........................... 3–21
4–1 DEClaser 1100 Test Print Block . . . . . . . . . . . . . . . . . . . . . . . 4–2
5–1 DEClaser 1152 Printer Test Print . . . . . . . . . . . . . . . . . . . . . 5–2
6–1 DEClaser 1100 Printer Status Messages . . . . . . . . . . . . . . . . 6–1
6–2 DEClaser 1152 Status Messages . . . . . . . . . . . . . . . . . . . . . . 6–2
6–3 Operator Call Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–4
6–4 DEClaser 1100 Printer Functional Messages . . . . . . . . . . . . 6–13
6–5 ServiceMessages ................................. 6–17
7–1 TrayandPickupJams.............................. 7–6
7–2 Fixing and Delivery Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–10
8–1 Image Defect Lookup Table . . . . . . . . . . . . . . . . . . . . . . . . . . 8–2
xi

9–1 DEClaser 1100/1152 Printers Recommended Spares List
(RSL)........................................... 9–1
9–2 PartsLocator1 ................................... 9–4
9–3 PartsLocator2 ................................... 9–6
9–4 FeederPartsLocator ............................... 9–8
10–1 OpticalCavity .................................... 10–26
A–1 ServiceMessages.................................. A–1
A–2 User Preference Character Set . . . . . . . . . . . . . . . . . . . . . . . . A–3
A–3 Initialization Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–3
A–4 DeviceIdentification ............................... A–4
A–5 Macro Feature Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–4
A–6 DEClaser 1100 Parallel Interface Pin Assignment . . . . . . . . . A–5
A–7 DEClaser 1152 Parallel Interface Pin Assignments . . . . . . . . A–6
A–8 DEClaser 1100 Serial Interface . . . . . . . . . . . . . . . . . . . . . . . A–7
A–9 DEClaser 1152 Serial Interface . . . . . . . . . . . . . . . . . . . . . . . A–7
A–10 DEClaser 1100 Video Interface Pin Assignments . . . . . . . . . . A–8
A–11 DEClaser 1152 LocalTalk Interface Pin Assignments . . . . . . A–9
A–12 DEC423 Interface Pin Assignments . . . . . . . . . . . . . . . . . . . . A–9
A–13 DEClaser 1100 Cables and Adapters . . . . . . . . . . . . . . . . . . A–10
A–14 DEClaser 1152 Printer Cables and Adapters . . . . . . . . . . . . . A–12
B–1 AvailableCassettes ................................ B–2
B–2 PaperSpecifications................................ B–2
B–3 TransparencySizes ................................ B–4
B–4 Transparency Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . B–4
D–1 Tools............................................ D–2
D–2 Documentation.................................... D–2
xii

Preface
This book is intended to assist the service engineer to repair and service the
DEClaser 1100 series printer in the field environment. Before attempting to
use the book, you must attend the specific DEClaser Educational Services
training course and all other prerequisite training courses. Section D.1 lists all
recommended courses.
Conventions
The following conventions are used throughout this service guide:
Convention Description
Note: Notes provide additional information.
Caution: Cautions emphasize information for preventing damage to
equipment or software.
Warning: Warnings emphasize information for prevention of personal
injury.
FIP Note: FIP notes serve as place markers within the fault isolation
procedures (FIPs)
Feeder Select A box is used when referring to control panel keys. All control
panel keys are described in Chapter 2.
1.
2.
3.
Numbered steps indicate the recommended sequence of each step
within a procedure.



Bulleted steps allow you to determine which step to do first.
a.
b.
c.
Alphabetized steps indicate a series of substeps under a bulleted
or numeric main step.
xiii

About This Service Guide
This service guide contains the following information:
This Chapter Describes
Chapter 1 The physical and functional components of the printer and all
available printer options.
Chapter 2 The DEClaser 1100 control panel operation and setup menus.
Chapter 3 The DEClaser 1152 printer features and control panel.
Chapter 4 The DEClaser 1100 test prints.
Chapter 5 The DEClaser 1152 test prints.
Chapter 6 Control Panel messages, Operator Call messages, and Service
messages.
Chapter 7 How to clear paper jams.
Chapter 8 How to fix image defects.
Chapter 9 The recommended spares list and where the parts are located on the
machine.
Chapter 10 How to locate, remove, and replace the major assemblies within the
DEClaser 1100 series printer.
Appendix A Technical and functional information.
Appendix B Print media and operational specifications.
Appendix C The Total Call Concept (TCC) procedure for the DEClaser 1100
series printer.
Appendix D Training, tools, and related documentation.
Safety Warnings
Note: The DEClaser 1100 series printers comply with all United States
government safety regulations applicable to ozone gas emissions and laser beam
light exposure.
Laser Safety: The DEClaser 1100 series printer complies with 21 CFR
Chapter 1, Subchapter J, as a Class 1 laser product under the U.S. Department
of Health and Human Services (DHHS) Radiation Performance Standard,
according to the Radiation Control for Health and Safety Act of 1968. The
DEClaser 1100 series printers do not emit hazardous light since the laser beam
is totally enclosed during all modes of customer operation and maintenance.
Warning: Use of controls or adjustment procedures other than those specified
in this manual may result in hazardous laser light exposure.
xiv

1
Physical and Functional Description
This chapter provides a physical and functional description of the DEClaser
1100 series printer.
1.1 Description of the DEClaser 1100 Series Printers
The DEClaser 1100 series printers are compact, low-cost, desktop printers
capable of printing high-quality text or graphics at speeds up to 4 pages
per minute on a variety of typical media, including paper, envelopes, and
transparencies. Appendix B contains printer and media specifications.
Media can be fed into the printer from the standard input tray or from an
optional feeder cassette that attaches to the bottom of the printer. The printer
and cassette are customer installable.
A unique feature of this printer is rollers used in place of ozone-producing
charge wires. The operation of the control panel is similar to the DEClaser
2000 series printers.
1.2 Printer Components
Figure 1–1 has numbered callouts to identify the location of the operational
components visible from the right side of the printer. For a description of each
component refer to Table 1–1.
Physical and Functional Description 1–1

1.2 Printer Components
Figure 1–1 Components: Front View
1–2 Physical and Functional Description

1.2 Printer Components
Table 1–1 Printer Components: Front View
Component Function

Control panel The control panel has a message display, indicator
lights, and a keypad. See Chapter 2 for additional
information on using the control panel.

Font cartridge slots These two slots accept the optional font or program
cartridges. For example, the PostScript cartridge
is a program cartridge. See Section 2.17 for more
information.
Caution: Before inserting or removing a card, turn
off the printer power. The printer will cease to operate
and damage may occur if the font or program card is
inserted or removed while the printer power is on.

Power switch Powers the printer on or off. To ensure data is not
lost, always be sure the display reads 00 READY or PS
READY/IDLE before powering off the printer.

Paper feeder
and cassette The paper feeder is an optional assembly that holds the
cassette and feeds paper up into the feeder rollers. You
may see DEClasers with or without a paper feeder unit
in the field.
See Section 1.3 for more information about the cassette.

Front door release Opens the front door of the DEClaser 1100 series
printer.

Stack selector Directs paper from the fixing rollers exit to the faceup
or facedown stack.

Front paper tray
and extension plate The front paper tray holds up to 50 sheets of paper.
The image size is adjusted by selecting a paper size
from the page format menu. See Section 2.16 for more
on the format menu.

Adjustable and fixed
paper guides The left guide can be adjusted for standard size paper,
envelopes, or for nonstandard size sheets.

Faceup stack
exit roller The faceup tray that attaches here is not shown. Use
the faceup stack when printing on stiff media, for
example, envelopes or labels.

Fixing door Open this door to clear paper jams that occur at the
exit of the fixing unit. When open, the message
12 PRINTER OPEN is displayed.

Front door Open this door to clear media jams, remove and replace
the EP-L cartridge, or to access the density adjustment.
Physical and Functional Description 1–3

1.2 Printer Components
Figure 1–2 identifies the components on the back of the DEClaser 1100 series
printers. The DEClaser 1152 printer has a DEC423 serial and LocalTalk
connector; it does not have a video interface. Table 1–2 describes each
numbered component.
Figure 1–2 Components: External Rear View
1–4 Physical and Functional Description

1.2 Printer Components
Table 1–2 Printer Components: External Rear View
Component Function

Facedown tray and
adjustable paper stop Paper is stacked in facedown orientation.

Rear cover Remove the access cover to install the optional 1- or
2-Mb RAM expansion memory.

Power cord
connector This receptacle accepts the ac line power cord.

Parallel (Centronics)
interface connector Accepts a 32-pin cable and is used for parallel
interfacing to a host computer system. The connector is
physically and electrically compatible to the Centronics
protocol.

Serial number This is the location of the external serial number
template. The location of the internal serial number
template can be found in Table 1–4. Both templates
show the same serial number.

Video interface (1100,
1150) and
DEC423 serial interface
(1152)
On the DEClaser 1100 or 1150 printer, the video
interface accepts a 37-pin cable that connects an
external video controller to the printer.
On the DEClaser 1152 printer, this interface is used as
a DEC423 serial connector.

Serial (RS232)
interface cable
connector
Accepts the standard, 25-pin interface connector that
is mechanically and electrically compatible with EIA-
232-D/CCITT V.24 specifications. The terms RS232 and
EIA-232-D are interchangeable.

SerialB/LocalTalk
interface connector Can be used as a serial RS-422 communication device
on the DEClaser 1152 only.
For more information about the cables or cable installation refer to Appendix A, DEClaser 1100
Printer Installation Guide, or DEClaser 1152 Printer Installation/Operator’s Guide.
Physical and Functional Description 1–5

1.2 Printer Components
Figure 1–3 has numbered callouts to identify the location of the operational
components that are visible when the rear cover is open. For a description of
each component, see Table 1–3.
Figure 1–3 Components: Internal Rear View
Note: The interface board shown here is for the DEClaser 1100 printer.
1–6 Physical and Functional Description

1.2 Printer Components
Table 1–3 Printer Components: Internal Rear View
Component Function

TEST PRINT button This button prints the Engine Test print. Use a
pencil or suitable tool to press it. See Section 5.4
for information about the Engine Test print.

Interface board On the DEClaser 1100 and 1150 printers, this panel
holds the interface board and the parallel, video, and
serial input ports. On the DEClaser 1152 printer,
the interface board is similar in form and function.
However, the DEC423 serial port replaces the video
port and the LocalTalk connector has been added.
Customers must remove the interface board to install
optional memory.

CB101 circuit
breaker Using a suitable tool, you can reset the CB101 circuit
breaker through this hole in the LVPSA.
Physical and Functional Description 1–7
