Digital Equipment DECserver 700-08 User manual

Part Number: EK-DSRVW-MG. B01
DECserver 700
Site Preparation and Maintenance
(Hardware Owner’s Manual)

NOTICE — Class A Computing Device:
This equipment generates, uses, and may emit radio frequency energy. The equipment
has been type tested and found to comply with the limits for a Class A computing de-
vice pursuant to Subpart J of Part 15 of FCC Rules, which are designed to provide
reasonable protection against such radio frequency interference.
Operation of this equipment in a residential area may cause interference; in which
case, the user at his own expense will be required to take whatever means are neces-
sary to correct the interference.

Part Number: EK-DSRVW-MG. B01
DECserver 700
Site Preparation and Maintenance
(Hardware Owner’s Manual)
February 1993
This manual, in conjunction with the
DECserver 700 Hardware
Installation Card
, describes how to install the DECserver 700
network access server and how to verify its operation. This
manual also describes the controls and indicators. This manual
is intended for the hardware installer and the network manager.
Supersession/Update Information: This is a revised manual.
Software Version: DECserver Network Access Software V1.0
This manual applies to Version 1.0 of the DECserver Network
Access Software and all subsequent maintenance releases up
to the next major product release.

This manual was produced by Telecommunications and Networks Publications.
EK-DSRVW-MG. B01
Theinformationinthisdocumentissubjecttochangewithoutnoticeandshouldnotbeconstruedas
a commitment by Digital Equipment Corporation. Digital Equipment Corporation assumes no re-
sponsibility for any errors that may appear in this document.,
Copyright 1993 by Digital Equipment Corporation
All Rights Reserved
The following are trademarks of Digital Equipment Corporation: DEC, DECconnect, DECnet,
DECserver, DELNI, DEMPR, DESTA, ThinWire, UNIBUS, VAX, and the Digital logo.

iii
Contents
Preface
Hardware Overview
1.1 Models 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Controls, Indicators, and Connectors 1–3. . . . . . . . . . . . . . . . . . . . .
1.3 Understand the Software Loading 1–6. . . . . . . . . . . . . . . . . . . . . . .
1.3.1 Loading from Flash RAM 1–6. . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3.2 Loading from the Network 1–6. . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Site
2.1 Physical Requirements 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Environmental Requirements 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Electrical Requirements 2–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

iv
Cabling the Site
3.1 Preinstallation Checks 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Installing the Ethernet Cables and Devices 3–2. . . . . . . . . . . . . . . .
3.2.1 Installing the Standard Ethernet Cables and Devices 3–2. . . . . .
3.2.2 Installing the 10BaseT Ethernet Cables and Devices 3–4. . . . . .
3.2.3 Installing the ThinWire Ethernet Cables and Devices 3–5. . . . . .
3.3 Installing Serial Cables and Devices on the DECserver 700-16 3–9
3.4 Installing Serial Cables and Devices on the DECserver 700-08 3–11
3.5 Cabling Requirements 3–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5.1 Standard Ethernet Connection 3–13. . . . . . . . . . . . . . . . . . . . . . . .
3.5.2 10BaseT Ethernet Connection 3–14. . . . . . . . . . . . . . . . . . . . . . . .
3.5.3 ThinWire Ethernet Connection 3–14. . . . . . . . . . . . . . . . . . . . . . .
3.6 Installing the DECserver 700 in a Rack 3–15. . . . . . . . . . . . . . . . . . .
Connector and Cable Pin Descriptions
4.1 Connector Pin Descriptions 4–1. . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.1 Standard Ethernet 4–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.2 10BaseT Ethernet 4–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1.3 DECserver 700-08 Serial Line Ports 4–4. . . . . . . . . . . . . . . . . . .
4.1.4 DECserver 700-16 Serial Line Ports 4–5. . . . . . . . . . . . . . . . . . .
4.2 Cable Connections 4–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing and Adding Memory
5.1 Replacing a Faulty Single-In-Line Memory Module 5–1. . . . . . . . .
5.2 Additional Memory Supported 5–2. . . . . . . . . . . . . . . . . . . . . . . . .
5.3 Installing Extra Memory 5–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing and Adding Flash RAM
6.1 Replacing or Adding Flash RAM 6–1. . . . . . . . . . . . . . . . . . . . . . .

v
What to Do If You Have Problems
7.1 Diagnosing DECserver 700 Problems 7–1. . . . . . . . . . . . . . . . . . . .
7.2 Seven-Segment Display Off and System OK LED Off 7–2. . . . . . .
7.3 System OK LED Off/Seven-Segment Display Flashing “C”, “d”,
or “n” 7–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.4 System OK LED Off/Seven-Segment Display Flashing 7–4. . . . . .
7.5 System OK LED Flashing 7–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.5.1 Error Message 952 7–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figures
1–1 DECserver 700-08 Rear View 1–2. . . . . . . . . . . . . . . . . . . . . . . . . .
1–2 DECserver 700-16 Rear View 1–3. . . . . . . . . . . . . . . . . . . . . . . . . .
1–3 DECserver 700 Front End 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–1 Standard Ethernet Coaxial Cable Connection 3–3. . . . . . . . . . . . . .
3–2 10BaseT Ethernet Connection 3–4. . . . . . . . . . . . . . . . . . . . . . . . . .
3–3 Connecting the DECserver 700 to ThinWire Ethernet Cable 3–5. .
3–4 ThinWire Ethernet Standalone Segment 3–7. . . . . . . . . . . . . . . . . .
3–5 DEMPR ThinWire Connection 3–8. . . . . . . . . . . . . . . . . . . . . . . . .
3–6 DEMPR Connections 3–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–7 How to Fit the Brackets to Recess the DECserver 700 3–16. . . . . . .
3–8 Removing the Brackets 3–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4–1 Pin Numbers and Signals for Standard Ethernet Connector 4–2. . .
4–2 Pin Numbers and Signals for 10BaseT Ethernet Connector 4–3. . .
4–3 Pin Numbers and Signals for 25-Pin D-sub Connector 4–4. . . . . . .
4–4 Pin Numbers and Signals for the MJ8 Connector 4–5. . . . . . . . . . .
4–5 Adapters and Connectors Used with the DECserver 700 4–8. . . . .
5–1 Removing the Brackets 5–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5–2 Removing the Covers 5–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5–3 Fitting the Anti-Static Kit 5–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5–4 Locating the SIMs Connectors 5–8. . . . . . . . . . . . . . . . . . . . . . . . . .
5–5 Removing a Sim 5–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5–6 Inserting the Replacement SIM 5–10. . . . . . . . . . . . . . . . . . . . . . . . .
5–7 Adding an Additional SIM 5–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vi
5–8 Replacing the Covers 5–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6–1 Locating the Flash RAM Card Connector 6–3. . . . . . . . . . . . . . . . .
6–2 Inserting the Flash RAM Card 6–4. . . . . . . . . . . . . . . . . . . . . . . . .
Tables
1–1 DECserver 700 Controls 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1–2 DECserver 700 Indicators 1–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1–3 Network Activity LED 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1–4 DECserver 700 Connectors 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–1 Physical Specifications of the DECserver 700 2–1. . . . . . . . . . . . . .
2–2 Acoustics 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–3 Environmental Specifications of the DECserver 700 2–2. . . . . . . .
2–4 Electrical Requirements 2–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–5 Standard Ethernet/IEEE 802.3 Connector Output 2–3. . . . . . . . . . .
3–1 Cables and Adapters for the DECserver 700-16 3–10. . . . . . . . . . . .
3–2 Cables and Adapters for the DECserver 700-08 3–11. . . . . . . . . . . .
3–3 Maximum Communications Distances — Ethernet 3–12. . . . . . . . . .
3–4 Maximum Cable Lengths1 — DECserver 700 to Devices 3–13. . . .
3–5 Installing the DECserver 700 Brackets 3–15. . . . . . . . . . . . . . . . . . .
4–1 Cable Connections 4–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7–1 Display/Indications 7–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7–2 Network Activity LED 7–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vii
Preface
Intended Audience
Thismanual,in conjunctionwiththeDECserver700HardwareInstallationCard,is
intended for the hardware installer. The installer is responsible for ensuring that the
hardware is installed and tested. The DECserver 700 Hardware Installation Card
shows how to install the DECserverTM 700 when the site is verified and the cables
anddevicesareinplace.Thismanual shows how to verifythesite,installcablesand
devices, and troubleshoot the DECserver 700. The person installing the DECserver
700 software can then verify the system installation.
Structure of This Manual
This manual contains the following chapters:
•Chapter 1 — Provides an overview of the DECserver 700 features.
•Chapter 2 — Describes how to verify the site before installing the DECserver
700.
•Chapter 3 — Describes how to cable the site.
•Chapter 4 — Describes connector pins for the various server connectors and
also describes various cables, adapters, and accessories used with the DEC-
server 700.
•Chapter 5 — Shows how to install extra memory and replace faulty memory .
•Chapter 6 — Shows how to update a DS700 with Flash RAM.
•Chapter 7 — Shows how to troubleshoot the DECserver 700.

viii Digital Confidential
Associated Documents
•DECserver 700 Hardware Installation Card
Shows how to install the DECserver 700 when the site is verified and the
cables and devices are in place.
•DECserver Network Access Software Installation (op-sys)
Explains how to install the DECserver 700 distribution software, how to es-
tablish downline load hosts, and how to verify the DECserver 700 system
installation. In the title, (op-sys) is the name of the load host operating sys-
tem.
•Network Access Server Problem Solving
Describes the software tools and techniques available to troubleshoot the
server and also describes all error messages.
•Network Access Server Management
Provides the procedures to perform various DECserver 700
management tasks.
•Network Access Server Commands
Lists and describes all the DECserver 700 software commands.
•DECconnect System Planning and Configuration Guide
Information on cabling and configuring of local area networks and using
DECconnect system products.
•The Ethernet: A Local Area Network: Data Link Layer and Physical Layer
Specification
Lists standard Ethernet connectors and their signal specifications.

1–1
1
Hardware Overview
The DECserver 700 connects devices (such as printers, terminals, PCs, and mo-
dems) to local area networks (LANs). The DECserver 700 is Ethernet/IEEE
802.3-based and supports standard Ethernet/IEEE 802.3 and 10BaseT Ethernet/
IEEE 802.3 directly, and ThinWireTM Ethernet/IEEE 802.3 through an adapter. The
DECserver 700 can be installed on a desktop or in a 19-inch rack. The DECserver
700 supports Flash RAM capability and other nonvolatile forms of memory. This
capability can be ordered separately and installed on the DECserver 700 in the field.
The DECserver 700 can download the software image from the network or from the
Flash RAM option if installed. The Flash RAM option allows for a boot/power up
withouthavingtodownloadtheimagethroughthenetwork.TheDECserver700will
support up to 8 Mbytes of memory with the use of two single-in-line modules
(SIMs). These SIMs can be installed as memory updates by the customer.
There are two DECserver 700 models:
•DECserver 700-08
•DECserver 700-16
1.1 Models
TheDECserver 700-08 supports EIA-232-D/V.24/V.28full modem control oneight
25-pin male D-connectors. Use this model to connect devices that require full du-
plex, asynchronous control (for example: modems).

1–2 Site Preparation and Maintenance
Figure 1–1showsarearviewoftheDECserver700-08.TheDECserver700-16sup-
ports EIA-423-A and DEC 423 data-leads on 16 MJ8 connectors. Use this model to
connectdevices requiring data-leads for operation (for example: terminals,printers,
and personal computers in terminal emulation mode). You can connect the DEC-
server to modems that do not require the full complement of signals provided by the
DECserver 700-08, using special adapters (Section 3.3).
NOTE
Adapters H8585-AB and H8585-AC are not for con-
nection to public networks in Sweden, Germany, or Ja-
pan.
Figure 1–1: DECserver 700-08 Rear View
LKG-5569-91I
Power
receptacle
Seven-segment
display Ethernet select
switch
Standard
Ethernet
connector
System
OK LED
10BaseT
Ethernet
connector
System reset
switch
Network
activity LED
Serial ports

1–3Hardware Overview
Figure 1–2 shows a rear view of the DECserver 700-16.
Figure 1–2: DECserver 700-16 Rear View
LKG-5568-91I
Power
receptacle
Seven-segment
display Ethernet
select
switch
Standard
Ethernet
connector
System
OK LED
10BaseT
Ethernet
connector
System reset
switch
Network
activity LED
Serial ports
1.2 Controls, Indicators, and Connectors
AlloftheDECserver700controls,indicators,and connectors are located on the rear
of the DECserver700 as shown in Figure 1–1 and Figure 1–2, with the exception of
the System OK LED, which is duplicated on the front of the DECserver 700
(Figure 1–3).
Figure 1–3: DECserver 700 Front End
LKG–6008–91I
System OK LED

1–4 Site Preparation and Maintenance
Table 1–1 describes the DECserver 700 controls. Table 1–2 and Table 1–3 describe
the indicators, and Table 1–4 describes the connectors. For more information on the
connectors, refer to Chapter 4.
Table 1–1: DECserver 700 Controls
Control Description
System reset switch On power up, press this switch until E appears on the
seven-segment display. This reloads the factory set pa-
rameters. During Flash load, pressing and holding the
system reset switch will abort the Flash RAM load and
force a network boot. Refer to Chapter 7 for more informa-
tion.
Ethernet select switch This switch selects either standard or 10BaseT Ethernet.
Table 1–2: DECserver 700 Indicators
Indicator Display
System OK LED Lights (green) when the DECserver 700 has passed self-
test. Blinks when a nonfatal error occurs on self-test.
When off, indicates that the DECserver 700 has failed
self-test.
Network activity LED Refer to Table 1–3.
Seven-segment display Provides error and status information.

1–5Hardware Overview
Table 1–3: Network Activity LED
Ethernet
Selected Connection Status LED Display
10BaseT Open/incorrectly terminated
Correctly terminated / no network activity
Correctly terminated / network activity
OFF
ON
Flashing (rate independent of
network activity)
Standard Ethernet Open
Correctly connected / no network activity
Correctly connected / network activity
OFF
OFF
Flashing or ON, depending
on network activity
Table 1–4: DECserver 700 Connectors
Connector Description
Serial port connectors
(DECserver 700-08) These eight 25-pin male D-connectors connect EIA-232-D devices to the DECserver 700.
Serial port connectors
(DECserver 700-16) These 16 female MJ8 connectors connect data-lead de- vices to the DECserver 700.
Standard Ethernet connector This single 15-pin female D-connector connects to a stan-
dard Ethernet/IEEE 802.3 local area network using a
transceiver cable.
10BaseT Ethernet connector This single female MJ8 connector connects to a 10BaseT
Ethernet/IEEE 802.3 local area network.
Power cord receptacle The DECserver 700 power cord plugs into this receptacle.

1–6 Site Preparation and Maintenance
1.3 Understand the Software Loading
This section describes the two methods that the DECserver 700 access to load the
software.
1.3.1 Loading from Flash RAM
Once the DECserver 700 completes self-tests, the DECserver 700 checks for Flash
RAM.Ifthere is a valid FlashRAM,the DECserver 700 beginsthebootsequence to
load the software from Flash RAM. The seven-segment display will display three
horizontal segments during this loading process.
If the DECserver 700 does not have Flash RAM, the DECserver 700 proceeds to a
network load.
If a device is connected to the console port, the DECserver 700 can display status
messageswhilethe boot sequence is running. Statusmessages indicate theEthernet
address of the DECserver 700, the name of the load image it is looking for, and the
stage of the boot process it is in.
1.3.2 Loading from the Network
If you do not want to load the software from Flash RAM, you can press the system
reset switch during load from Flash RAM. When the system reset switch is pressed,
theFlash RAM loadwill be abortedand the softwareis downline loadedfrom a load
host.
When the DECserver 700 notices the system reset switch depressed during load
from Flash RAM, it will rapidly blink the LED to acknowledge the pressed system
reset switch (this may take several seconds). Once the LED begins rapidly blinking,
you may release the system reset switch and the firmware will go on to a network
boot sequence. For more information on display codes for Flash RAM, refer to sec-
tion 7.7.

2–1
2
Checking the Site
The DECserver 700 can operate in an office environment and in a standard equip-
ment rack located in a computer room or satellite equipment room. Regardless of
where you install the DECserver 700, verify that all of the requirements in this sec-
tion are met before beginning the installation.
2.1 Physical Requirements
Allow for 15 cm (6 in) of airspace around the DECserver 700 air vents. Table 2–1
shows the size and weight of the DECserver 700. Table 2–2 shows the acoustic pa-
rameters.
Table 2–1: Physical Specifications of the DECserver 700
Dimension Measurement
Height 44 mm (1.73 in)
Width 442 mm (17.4 in)
Depth 282 mm (11.1 in)
Weight 2.5 kg (5.51 lbs)

2–2 Site Preparation and Maintenance
Table 2–2: Acoustics
Parameter Measurement
LWAd14.1 bels (LWA = 3.8 bels)
LpAm (bystander)127 dBA
1Preliminary declared values per ISO 9296 and ISO 7779. Current values are available from
Digital representatives.
2.2 Environmental Requirements
Environmental requirements for temperature and humidity must be within the
ranges shown in Table 2–3.
Table 2–3: Environmental Specifications of the DECserver 700
Parameter Minimum Maximum
Temperature1
Operating 5°C (41°F) 50°C (122°F)
Nonoperating – 40°C (– 40°F) 66°C (151°F)
Maximum rate of
temperature change per hour 20°C (36°F)
Altitude
Operating 2438 m (8000 ft)
Nonoperating 4876 m (16000 ft)
Relative humidity
Operating (noncondensing) 10% 95%
Nonoperating (noncondensing) 10% 95%
1For high altitude sites, decrease the operating temperature specification by 1.8°C for each
1000 m (1°F for each 1000 ft) above sea level.

2–3Checking the Site
2.3 Electrical Requirements
The power at the electrical outlet must match the requirements shown in Table 2–4.
TheinstructionsassumethatanappropriateACpower source is within 1.8 m (6.0 ft)
of the DECserver 700.
Table 2–4: Electrical Requirements
Parameter DECserver 700
Line voltage1100 – 120 V rms/220 – 240 V rms
Frequency 50/60 Hz
Line current 1.4 A rms/.75 A rms
Power 92 W
1The DECserver 700 automatically selects the voltage range.
Table 2–5 shows the electrical output from the standard Ethernet/IEEE 802.3
connector.
Table 2–5: Standard Ethernet/IEEE 802.3 Connector Output
Parameter DECserver 700
Voltage + 12 V DC
Current .5 A Max
