Preface
The Digital PRIORIS MTE Server Service Maintenance Manual is a troubleshooting guide that can be used
for reference when servicing the PRIORIS MTE Server series.
Digital Equipment Corporation reserves the right to make changes to the Digital PRIORIS MTE Server
without notice. Accordingly, the diagrams and procedures in this document may not apply to the computer(s) to
be serviced since many of the diagnostic tests are designed to test more than one product.
CAUTION
Digital recommends that only A+ certified engineers attempt to repair this equipment.
All troubleshooting and repair procedures are detailed to support subassembly/module
level exchange. Because of the complexity of the indivual boards and subassemblies, no
one should attempt to make repairs at component level or to make modifications to any
printed wiring board. Improper repairs can create a safety hazard. Any indications of
component replacement or printed wiring board modifications may voidany warranty or
exchange allowances.

Digital PRIORIS MTE Server Product Description
MCS Logistics Engineering - Nijmegen 9
P
R
I
O
R
I
S
M
T
E
Chapter 1 Product Description
Product Introduction
The Prioris MTE servers are a family of high-performance, i486 processor-based, personal computers equipped
with the latest microprocessor technology. They can be used as stand-alone computers, as clients, or as servers
in a network environment.
Features
♦ Upgradable system comptible P24T ZIF socket
♦ 8 MB system RAM, Upgradable to 128 MB on motherboard
♦ 128 KB external cache memory (direct-mapped), expandable to 256 KB
♦ On-board IDE controller
♦ SVGA video card, 1 MB, ISA included
♦ Supports up to five storage devices
♦ Five full-size, 32 bit EISA slots and one slot which is either a VL-bus VESA slot or an EISA slot (for a
maximum of six EISA slots)
♦ Interfaces: two serial (RS-3232C) and one parallel (Centronics)
♦ Autosensing Power supply, 260 Watt

Product Description Digital PRIORIS MTE Server
10 MCS Logistics Engineering - Nijmegen
P
R
I
O
R
I
S
M
T
E
Product Models Information
Prioris MTE Server
Model CPU RAM Cache FDD HDD CD-ROM
FR-PCT73-BV 486DX2/
66 MHz 8 MB 128 KB 1.44 MB None None
FR-PCT73-BB 486DX2/
66 MHz 16 MB 128 KB 1.44 MB 1 GB SCSI-2 Standard
FR-PCT73-LE 486DX2/
66 MHz 16 MB 128 KB 1.44 MB 535 MB SCSI-2 600 MB double speed
FR-PCT74-BV 486DX4/
100 MHz 8 MB 128 KB 1.44 MB None None

Digital PRIORIS MTE Server Server Utilities & configuration
MCS Logistics Engineering - Nijmegen 11
P
R
I
O
R
I
S
M
T
E
Chapter 2 Server Utilities & Configuration
Before Using the Flash Upgrade Utility
When not familiar with utility programs and their uses, carefully read and understand the information
contained in this chapter before attempting to use the Flash Upgrade utility.
Have the following items available:
♦ Blank formatted diskette.
♦ Utilities diskette (supplied with the system).
♦ System Configuration Utility diskette (supplied with the system).
Recovery Diskette
A recovery diskette should always be prepared before attempting to upgrade the BIOS. This diskette contains a
BIOS image and a program to load the image into flash memory. If a problem occurs during the programming
of BIOS into flash memory, a siren sounds when the Server is turned on. Insert the recovery diskette into drive
A or B and the original BIOS is put back in flash memory.
Using the Flash Upgrade Utility
Perform the following steps to create a recovery diskette, update the BIOS in the flash memory, and compare
the BIOS image file to the flash memory:
1) Insert the Utilities diskette (supplied with the system) into drive A.
2) Turn on the computer.

Server Utilities & configuration Digital PRIORIS MTE Server
12 MCS Logistics Engineering - Nijmegen
P
R
I
O
R
I
S
M
T
E
3) At the MS-DOS prompt, type a:upgrade, and then press [Enter]. This invokes the Flash Upgrade utility.
The following menu items appear on the screen:
Make Recovery Diskette from Flash
Make Recovery Diskette from Image File
Upgrade Flash from Image File
Save Flash to Image File
Compare Flash to Image File
BIOS Information
Exit
For on-line help, press [F1].
4) Select the Make Recovery Diskette from Flash menu option. The message, "Please
select the diskette drive that will be used to create a Flash
Recovery Diskette, or select "Cancel" to abort", appears on the screen.
5) Press the [Tab] or up and down arrow keys to highlight the desired diskette drive, then press [Enter].
Drive A is the default diskette drive. The message, "Insert a formatted diskette into
drive A. The contents of this diskette will be lost! and replaced
with system recovery software and the specified BIOS image. Select
"Continue" to start writing the recovery diskette, or "Cancel" to
abort," appears on the screen.
6) Insert a blank (formatted) diskette in drive A, and select Continue to proceed with the creation of a
recovery diskette. A message window notifies when it completes. Press any key to continue.
7) Remove the recovery diskette from drive A and store it in a safe place.
8) Insert the Utilities diskette in drive A.
9) Select the Upgrade Flash from Image File menu option. You are prompted to select the
BIOS image file to program into flash memory.
10) Press [Enter] to list a directory of .BIN (BIOS image) files. Select the desired image file.
The message, "The old BIOS will now be replaced by the new BIOS image.
Select "Program" to start, or "Cancel" to abort. Keep in mind that
programming a new BIOS into Flash memory requires a fair amount of
power. "If you are running on battery power you should have a full
charge!" appears on the screen.
11) Press [Enter] to proceed with the programming of the new BIOS into flash memory.
The message, "DO NOT TURN OFF THE POWER", appears on the screen.
The flash memory is erased, then the new BIOS is copied. Depending on the size of flash memory, the
programming takes 20-40 seconds. When the programming of the flash BIOS is complete, a message
briefly appears on the screen, then the system attempts to reboot.
12) Remove the Utilities diskette to allow the system to reboot without error. If an error occurs the flash
memory is corrupted and a siren sounds when the computer is rebooted. If this occurs, insert the recovery
diskette into drive A or B and the original BIOS is put back in flash memory.
If the computer does not reboot and the siren does not sound, turn off the computer. Set the main logic
board jumper J53 to recovery mode This procedure forces a BIOS recovery process. Refer to “Main
Logic board Jumper Locations”.
13) Insert the Utilities diskette into drive A, invoke the Flash Upgrade utility and select the Compare
Flash to Image File menu option. The message, "Select BIOS Image File Name
to compare against flash memory," appears on the screen.
14) Press [Enter] to display a list of .BIN (BIOS image) files. Select the .BIN file to be compared with the
flash memory. A message window displays whether the flash memory contains the same BIOS asthe disk
file. Press any key to continue.
