USER’S GUIDE

TABLE OF CONTENTS
About The Slyder Pro 2
Package Contents 2
Using the Slyder Pro 3
Key Features / Specications 4
Cleaning and Maintenance 4
Safety Precautions & Warnings 5
Accessories 6
Return Policy & Limited Warranty 7

Package
Contents
About the
Slyder Pro
2
USER’S GUIDE
Congratulations on your purchase of the Digital Juice Gear Slyder
PRO. It is a heavy-duty portable tracking solution that was
specifically designed to help you create smooth short-run camera
movements, without the hassle of having to transport a large dolly
system. Its durable, attractive and highly versatile design will help
you to capture exactly the shot that you need, when you need it.
Your new Slyder PRO is a portable shooting platform that can be
used on many surfaces— including tabletops and tripods—to
create smooth camera movements known as dolly shots, on a
horizontal, angled or vertical axis. Thanks to the versatile design
of the Slyder PRO, it provides you with the flexibility you need to
capture an almost limitless variety of smooth tracking shots.
Your Slyder PRO package should contain the following parts
• Slyder PRO Unit
• Deluxe Carry Bag & Shoulder Strap

3
4
5
6
Using the
Slyder Pro
3
USER’S GUIDE
Once you remove the Slyder PRO from the deluxe carry bag, you will
undoubtedly appreciate that it is ready to use immediately, no assembly
required! We recommend that you first place the Slyder PRO on a flat sur-
face and take a look at the following information so that you may identify
each of its features for yourself.
(1) Carbon Fiber Rails: Durable and lightweight, allow for smooth move-
ment of the trolley.
(2) Mounting Plate/Trolley: Allows for a wide array of mounting options,
including optional accessories such as a High Hat, Ball Head, and
Articulating Arm. Smooth and stutter-free movement of the trolley is
accomplished through the use of high-performance U-Groove wheels
and bearings. The trolley also contains a built in leveling bubble for
achieving an accurate, leveled setup.
(3) Brake Knob: Allows for precise pressure adjustment for free move-
ment and weighted shots, as well as acting as a brake when fully
engaged for static shots. Simply turn clockwise to tighten the brake,
or counter-clockwise to release the brake to the desired pressure.
Note: Although it can be removed, there is no functional reason to fully
unthread the brake knob to achieve free movement of the trolley.
(4) Built-In Mounting Holes: The central mounting bracket along the
underside of the Slyder PRO contains multiple 3/8” and 1/4” mounting
holes for increased stability along a variety of vertical and horizontal
surfaces and angles, including use with tripods and C-Stands.
The end block mounting holes (5) are are perfect for even more stabilized
mounting on C-Stands using the Digital Juice Gear C-Stand Adapter.
(6) Bumpers: Prevent metal to metal contact when the trolley is in motion.
Please note: The bumpers are not intended as a shock absorber for
weighted shots.
(7) Adjustable Leveling Legs: The built in leveling legs can simply be set
up, by folding them outwards until they lock into place. You can also
adjust the height by screwing/ unscrewing the feet to reach the desired
height.
1
2
7

4
USER’S GUIDE
Key Features &
Specifications
Key Features and Specifications
• The Slyder PRO is constructed from smooth and durable carbon fiber rails,
with stylish matte silver anodized end caps and an anodized body to give it
a long-lasting and smooth finish that is easy to maintain and clean.
• Rail track measures approximately 44 inches in length. Weight: 3.3lbs
• The Slyder Pro has approximately 4 in. of clearance when the legs are
extended perpendicular to a flat surface.
• Versatile mounting plate, allowing for easy & quick installation of a wide-
array of useful accessories (i.e. high-hat, ball head, quick release plate,
articulating arm) Not Included.
• Bubble Level helps ensure accuracy when it matters.
• The Slyder Pro has a 20lb weight limit when used manually. When used
with the optional Slyder Power Motor, the Slyder Pro has an 18.5 lb limit
(when placed on a level surface).
• Using the center cheese plate, The Slyder Pro can be mounted to a light
stand or C-Stand. For greater stability, we recommend mounting both
ends of the Slyder Pro to C-Stands using the Digital Juice Gear C-Stand
Adapter Kit.
• Precise ‘out-of-the-box’ * calibration. Your Slyder PRO is ready to capture
the perfect shot immediately!
Although your new Slyder PRO is calibrated prior to being shipped to you,
we recommend that you first test the movement of the trolley along the rails
to ensure smooth movement. You may need to loosen the brake knob first.
Your new Slyder PRO was specifically designed to be rugged and ready-to-
go, requiring minimal maintenance for proper and smooth performance every
time. The carbon fiber body is attractive, but simple and easy to clean. With
proper care and usage, your Slyder PRO should provide you with a lifetime of
trouble-free use:
• Clean carbon fiber rails with a damp or dry clean cloth to wipe off any
dust or debris that might have accumulated. If the rails are particularly
dirty, you may use a non-harsh / non- abrasive cleaner, making sure
to wipe all excess cleaner off of the rails to ensure continued smooth
movement of the trolley.
• The movement of the trolley is accomplished by precision sealed U-
Groove bearings; therefore the application of lubricants and/or sprays
is not recommended and may in fact hinder the proper movement and
performance of the trolley along the rails.
Cleaning &
Maintenance

5
USER’S GUIDE
Cleaning &
Maintenance
(continued)
• For increased protection, along with safe transport and storage, we
recommend using the deluxe carry bag designed specifically for your
new Slyder PRO.
• While transporting, storing or mounting a camera and/or accessory
to the Slyder PRO mounting plate, be sure to fully engage the brake to
prevent any unwanted movement.
Always remember that your Slyder PRO is a precision instrument. Any
rough handling or accidental bumps or drops could very well affect its
performance.
• Storing the unit in its carry case is highly recommended when not in
use.
• Be careful when setting up an unbalanced camera. Cameras with
heavy lenses or matte boxes may cause your camera setup to have a
front weight bias.
• A camera with a large battery source would have a rear weight bias.
The use of the built in leveling legs on the Slyder PRO can assist
greatly in creating stability for front- or rear-biased camera setups.
However, even when using the adjustable legs, you should remain
aware of the tipping point of your setup.
• Do not use any abrasive or acidic cleaning products on any part of
the Digital Juice Slyder PRO. A mild all-purpose cleaner is all that is
recommended.
There are no serviceable parts on the Slyder PRO. Please do not attempt to
disassemble for maintenance or repairs. If you’re experiencing trouble with
the unit, please contact the Digital Juice Customer Service Department by
email to: customerser[email protected].
Safety
Precautions &
Warnings

6
USER’S GUIDE
The following accessories are available to you and are sold separately at
www.gear.digitaljuice.com :
(8) Slyder Power Motor: Can be at-
tached to the underside of the Slyder
Pro trolley, with the provided space
plate and thumb screws. This allows
for controlled, variable speeds with the
use of the remote control, when shoot-
ing on the Slyder PRO.
(9) High Hat: The Slyder PRO
mounting plate includes threaded
holes that can accommodate the
Digital Juice High Hat accessory.
The High Hat is able to accom-
modate a 100mm ball head, or
a 75mm ball when used with the
optional adapter ring. All neces-
sary mounting hardware is included.
(10) Ball Head: Can be mounted
with the included 3/8 thread bolt
to the trolley and is adjustable to
achieve quick setup and creative
angles. The plate can be used sepa-
rately from the ball head as a quick
release plate mounted directly to the
trolley plate.
(11) C-Stand Adapter Kit: consists of a set of 2
adapters that let you quickly, easily and securely
attach the Slyder Pro to any 2 C-Stands/Grip
Stands in order to accomplish a variety of more
creative angled shots (slanted, canted, vertical),
not possible with tripod only.
Accessories
10
9
8
11

USER’S GUIDE
7
Unless otherwise noted this warranty agreement is the only war-
ranty agreement between the parties. This agreement states the
limits and association of risk between the two parties. By use of the
Product and accessories the customer acknowledges understanding
of this warranty and agreement and binding to the terms contained
within.
Return Policy
• 30-day money back excluding shipping.
• A receipt dated within 30 days of purchase.
• All returns must be new, unused, and contain all original packag-
ing, labels and accessories.
• The original product must be returned inside your shipping box.
• DJ suggests using a carrier that provides tracking and insurance.
DJ is not responsible for lost shipments.
Warranty
Digital Juice, Inc. warrants all Digital Juice products purchased
new by original owner to be free from defects in the material and
workmanship under normal use for a period of 12 months from the
date of purchase. Warranty is void when misuse or neglect is the
cause. THIS WARRANTY IS VALID ONLY IN THE UNITED STATES
AND CANADA.
Legal Indemnification
No other express warranty or guaranty, except as mentioned
above, given by any person or entity with respect to Digital Juice
products shall bind Digital Juice, Inc. This warranty supersedes all
other warranties expressed or implied. NO IMPLIED WARRANTIES,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE APPLY TO DIGITAL JUICE
PRODUCTS AND ARE HEREBY DISCLAIMED.
In the event of a possible warranty claim, the defective product
must be returned to Digital Juice, Inc (hereafter “Digital Juice”). If
proven to be defective upon inspection, it will be exchanged for a
new or comparable rebuilt product, as determined by Digital Juice
and shipped back to the original purchaser. All shipping costs are the
responsibility of the customer. Warranty replacement shall not extend
the original warranty period of the defective Digital Juice Product.
The customer’s remedies with respect to defective Digital Juice
Product and accessories shall be exclusively limited to the repair or
Slyder Pro
Return Policy &
Limited Warranty

8
USER’S GUIDE
Slyder Pro
Return Policy &
Limited Warranty
(continued)
replacement remedy as above provided and in no event shall Digital
Juice be liable for loss of profits, revenues, savings, inconvenience,
associated costs, expense for equipment or service, use of capital,
facilities, services, storage charges, damage to property, or any
other special, incidental or consequential damages caused by the
use or misuse of, or inability to use, the Digital Juice Product or
accessories, regardless of the legal theory on which the claim is
based, and even if Digital Juice has been advised of such damages.
In no event shall recovery of any kind against Digital Juice be
greater in amount than the purchase price of the Digital Juice
product sold by Digital Juice and causing the alleged damage.
Without limiting the foregoing, the purchaser assumes all risk and
liability for loss, damage or injury to persons, animals or property
arising out of use or misuse of, or inability to use, the Digital Juice
Product and accessories. Digital Juice is not liable for third party
claims. This limited warranty shall not extend to anyone other than
the original purchaser of the Digital Juice product, or the person for
whom it was purchased as a gift, and states your exclusive remedy.
In no event shall Digital Juice be liable for incidental or consequential
damages to the full extent such may be disclaimed by law.
Unless otherwise noted this warranty agreement is the only warranty
agreement between the parties. This agreement states the limits and
association of risk between the two parties. By use of the Product
and accessories the customer acknowledges understanding of this
warranty and agreement and binding to the terms contained within.

9
USER’S GUIDE
NOTES

www.digitaljuice.com
