Digital Solutions FIB1-1000MG User manual

Installation Instructions for
FIB1-1000MG Gigabit Series
Single Mode to Multi-mode
1000BASE-SX / 1000BASE-LX
Fiber Transceiver Media Converters
Description
The FIB1-1000MG single-mode to multi-mode fiber converter gives you the most
popular gigabit multi-mode connectors, SC or LC.
The FIB1-1000MG-GBIC matches the industry standard GBIC module interface
with a standard gigabit multi-mode SC transceiver. Three LED indicators linking
status of single mode, multi-mode and the power status of the converter.
-
-1-
Specifications
Standard
Fiber IEEE802.3z 1000Base-SX/LX, Gigabit Standards
Supports Full Duplex Ethernet mode (2000Mbps)
Fiber Optic Connectors
Depending on model, a fixed SC or LC, GBIC socket with SC, or SFP socket with LC is provided
Environment Dimensions Power
Temperature 0℃- 50℃(operating) 122.6mm x 85.6mm x 20mm AC Input : 90~264VAC
0℃- 70℃(storage) (L x W x H) Frequency : 47~63 Hz
Humidity 20-80% non condensing (operating) Output : DC12V+/- 5%, 1A
10-90% (storage) Consumption : <4W
Weight
340g (110z )
Installation
Connect the fiber interface cable to the FIB1-1000MS. Follow the connection examples below. Install the
fiber converter with the DC power adapter provided (+12VDC) and connect the adapter to an AC outlet.
Connections
The following example illustrates the fiber connection scheme when connecting from a 1000BASE-SX
port of one Gigabit Ethernet Switch port to a 1000BASE-SX port of another switch through a pair of fiber
converters and single mode fiber cable.
V.1.1
-2-
S/M Fiber Connections
(1000Base-LX)
M/M Fiber Connections
(
1000Base-SX
)
DC Jack LEDs

LED Indicators
GBIC Module Type Led Indications
LED Function State Status
PWR Power indicator On Converter has power.
Off Converter has no power.
M/M Link mode display On The multi-mode link is ok
Multimode Link Off No link or the link is faulty
S/M Link mode display On The multi-mode link is ok
Single mode Link Off No link or the link is faulty
-3-
Transceiver Connector Specification
SC LC GBIC SCPower Sensitivity Power Sensitivity Power Sensitivity
M/M, 850nm,
550M
-9.5dBm -18dBm -9.5dBm -18dBm X
S/M, 1310nm,
10Km
X X
-9.5dBm -20dBm
S/M, 1550nm,
30Km
X X
-4dBm -22dBm
S/M, 1550nm,
50Km
X X
-4dBm -23dBm
S/M, 1550nm,
80Km
X X -0dBm -23dBm
