INSTRUCTION MANUAL
Before installing and using the camera, please read this
manual carefully.
Be sure to keep it handy for future reference.
5436 W Crenshaw Street
Tampa, FL 33634
www.digital-watchdog.com
Technical Support : 1-866-446-3595/813-888-9555
Before installing and using the camera, please read this
manual carefully.
Be sure to keep it handy for future reference.
5436 W Crenshaw Street
Tampa, FL 33634
www.digital-watchdog.com
Technical Support : 1-866-446-3595/813-888-9555

PRECAUTIONS
■Do not open or modify
Do not open the case except during maintenance and installation,
as it may be dangerous and cause damages.
■Do not put objects inside the unit
Make sure that no metal objects or flammable substances
get inside the camera. It could cause fire, short-circuits or damages.
■Be careful when handling the unit
To prevent damage, do not drop the camera or subject it to
strong shock or vibration.
■Install away from electric or magnetic fields
■Protect from humidity and dust
■Protect from high temperature
Be careful when installing close to the ceiling , in a kitchen or boiler
room, as the temperature may rise to high levels.
■Do not open or modify
Do not open the case except during maintenance and installation,
as it may be dangerous and cause damages.
■Do not put objects inside the unit
Make sure that no metal objects or flammable substances
get inside the camera. It could cause fire, short-circuits or damages.
■Be careful when handling the unit
To prevent damage, do not drop the camera or subject it to
strong shock or vibration.
■Install away from electric or magnetic fields
■Protect from humidity and dust
■Protect from high temperature
Be careful when installing close to the ceiling , in a kitchen or boiler
room, as the temperature may rise to high levels.
■Cleaning
Dirt can be removed from the case only by wiping it with a soft cloth
moistened with a soft detergent solution.
■Mounting Surface
The mounting surface material must be strong enough to support
the camera.

TROUBLESHOOTING
Before sending the camera out for repair, check the items below.
If the problem persists after checking these items, contact your service
center.
■If no image appears
Is the coaxial cable attached securely?
Are the power and voltage normal?
Has the iris of the lens inside the camera been
adjusted correctly (with the level volume) ?
Is there adequate illumination?
■If the image is unclear
Is the lens in focus?
Is the lens dirty?
Dirt or fingerprints on the lens can adversely affect the
Before sending the camera out for repair, check the items below.
If the problem persists after checking these items, contact your service
center.
■If no image appears
Is the coaxial cable attached securely?
Are the power and voltage normal?
Has the iris of the lens inside the camera been
adjusted correctly (with the level volume) ?
Is there adequate illumination?
■If the image is unclear
Is the lens in focus?
Is the lens dirty?
Dirt or fingerprints on the lens can adversely affect the
images. Gently wipe any dirt or fingerprints off the lens
with a soft cloth or lens cleaning paper and cleaning
fluid (commercially available).
Is the monitor adjusted correctly?
WARNING:
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.

DIMENSION (mm)
D2372TIR SeriesD2372TIR Series

INSTALLATION
E
D
C
F
C
D
E
F
E
A
B
D
C
F
A
B
C
D
E
F

INSTALLATION (cont.)
1. Loosen the fixing screw (A) using a screwdriver.
2. Separate the upper case (B) and the base case (D).
3. Cut a hole in the ceiling for routing the cables.
4. Place the camera horizontally on the ceiling, drill the screw
holes at the marked four positions.
5. Pass the power cable (E) and video cable (F) from the camera
unit through the cable hole in the ceiling.
6. Align the screw holes of the camera unit with the holes in the
ceiling, secure with the four screws.
7. Install and adjust the camera unit.
8. Adjust the dome liner to show the lens through the camera
window fix to the base(D)
A. Loosen the fixing screw using the L-wrench that came with the camera
B. Separate the upper case and the base case.
C. Cut a hole in the ceiling for routing the cables.
D. Place the camera horizontally on the ceiling, drill the screw
holes at the marked four positions.
E Pass the power cable and video cable from the camera
unit through the cable hole in the ceiling.
F. Align the screw holes of the camera unit with the holes in the
ceiling, secure with the four screws.
G. Install and adjust the camera unit.
H. Adjust the dome liner to show the lens through the camera
id
dtt hit
tthb
1. Loosen the fixing screw (A) using a screwdriver.
2. Separate the upper case (B) and the base case (D).
3. Cut a hole in the ceiling for routing the cables.
4. Place the camera horizontally on the ceiling, drill the screw
holes at the marked four positions.
5. Pass the power cable (E) and video cable (F) from the camera
unit through the cable hole in the ceiling.
6. Align the screw holes of the camera unit with the holes in the
ceiling, secure with the four screws.
7. Install and adjust the camera unit.
8. Adjust the dome liner to show the lens through the camera
window, fix to the base(D).
9. Put the upper case (B) and the base (D) together.
10. Tighten the screw (A) for the upper/base cases not to be
separated .
A. Loosen the fixing screw using the L-wrench that came with the camera
B. Separate the upper case and the base case.
C. Cut a hole in the ceiling for routing the cables.
D. Place the camera horizontally on the ceiling, drill the screw
holes at the marked four positions.
E Pass the power cable and video cable from the camera
unit through the cable hole in the ceiling.
F. Align the screw holes of the camera unit with the holes in the
ceiling, secure with the four screws.
G. Install and adjust the camera unit.
H. Adjust the dome liner to show the lens through the camera
window and attach it to the base.
I. Put the upper case and the base together.
J. Tighten the screws with the L-wrench for the upper and base not to be
separated .

CONNECTION
DC12
V
DC12V / AC24V
CAUTION :
Check for polarity when using a DC 12V power supply.
DC12
V
DC12V / AC24V

■LENS ADJUSTMENT
CAMERA SETTINGS
B. Focus lever
A. Zoom Lever
A. Set the zoom lever to the desired position by moving Zoom lever.
B. Set the Focus by moving Focus lever.
B. Focus lever
A. Zoom Lever

REMOTE CONTROL- D2372TIR Series [OPTIONAL]
KEY BUTTON
OSD BUTTON
PAN FOCUS CONTROL BUTTON
Omni‐FocusRemoteControlInstructions
1. ChecktheDipswitch(SW4)forcameraID(Defaultis0)
2. Pointtheremotecontroltowardsthecamera,thenpressand
hold[0]untiltheRedLEDlightstartflashing.
3. PressandholdtheKEYbutton,untilLEDturnsasolidRED.
4. PressthePlussign(+)toZOOMIN,Minussign(‐)toZOOMOUT
5. Pressthe[ENT]buttontoenterthesetupMenuandpress[KEY]
buttontoexit.
KEY BUTTON
OSD BUTTON
PAN FOCUS CONTROL BUTTON
ID BUTTON
Omni‐FocusRemoteControlInstructions
1. ChecktheDipswitch(SW4)forcameraID(Defaultis0)
2. Pointtheremotecontroltowardsthecamera,thenpressand
hold[0]untiltheRedLEDlightstartflashing.
3. PressandholdtheKEYbutton,untilLEDturnsasolidRED.
4. PressthePlussign(+)toZOOMIN,Minussign(‐)toZOOMOUT
5. Pressthe[ENT]buttontoenterthesetupMenuandpress[KEY]
buttontoexit.

D2372TIR
(1) Ad
j
ustin
g
level volume
(
VR
)
If the entire image is too dark or bright, or the backlight compensation is not correct
CAMERA SETTING FOR SIDE OSD CONTROL BOARD
2'nd Video
Omni Focus Lens
(Zoom in/Zoom out)
Joy Stick Key
VR
ID Number
even after LENS is set to "DC", you need to adjust the level volume.
CCW (Low) Close the lens iris, making the entire image darker
CW(High) Open the lens iris, making the entire image brighter
(2) Second Video Out Connector
(
2'ND VIDEO
)
If installer uses a portable monitor, this connector should be connected.
(3) Omni Focus Lens
The focus is always set correctly during the change of angle of view.
Zoom In The lens focal length goes to max 8.5mm
Zoom out The lens focal length goes to max 2.9mm
(4) ID number
(※1,2,4,8(BCD code) means ID number, and ID contains 10 numbers from 0 to 9.)
2'nd Video
Omni Focus Lens
(Zoom in/Zoom out)
Joy Stick Key
VR
ID Number

OSD MENU SETTINGS - D2372TIR
SETUP FUNCTION SUMMARY
LENS MANUAL.DC - DC : bright level
SHUTTER FIXED,MANUAL,FLK - MANUAL : Manual shutter adjust.
- BLC AREA
- BLC RA TIO
AGC ON,OFF - AGC GAIN: Min~ Max
- MA NUA L : RED,BLUE
- FIXED : MODE 1,2,3,4
- CONTRA ST adjus t.
- SHARPNESS adjust.
- CB_GAIN adjust.
- CR_GAIN adjust.
FUNCTION ☜
- CA MERA ID
- POSITION
MIRROR ON,OFF - Mirror image on/off
- AUTO: DELAY
START LEVELDA Y NIGHT A UTO,B/W,COLO
R
ADJUST CONTRA ST,SHA RPNESS
CB_GA IN,CR_GA IN
CAMERA ID ON,OFF
BLC ON,OFF
WHITE BAL ATW,AWB,FIXED,MA NUAL
SETUP FUNCTION SUMMARY
LENS MANUAL.DC - DC : bright level
SHUTTER FIXED,MANUAL,FLK - MANUAL : Manual shutter adjust.
- BLC AREA
- BLC RA TIO
AGC ON,OFF - AGC GAIN: Min~ Max
- MA NUA L : RED,BLUE
- FIXED : MODE 1,2,3,4
- CONTRA ST adjus t.
- SHA RPNESS adjust.
- CB_GAIN adjust.
- CR_GAIN adjust.
FUNCTION ☜
- CA MERA ID
- POSITION
MIRROR ON,OFF - Mirror image on/off
- AUTO: DELAY
START LEVEL
END LEVEL
- AREA
- MOTION TH
- MOTION TRA CE ON/OFF
- AREA SEL
- AREA STATE
GAMMA USER, 0.05~1.0 - GAMMA set.
LA NGUA GE ENGLISH,Korean,Chinese1,Chinese
2,日本語 - Language set.
RESET YES,NO - Returns to the level
EXIT - Save out
PRIVACY ON.OFF
DA Y NIGHT A UTO,B/W,COLOR
MOTION ON,OFF
ADJUST CONTRA ST,SHA RPNESS
CB_GA IN,CR_GA IN
CAMERA ID ON,OFF
BLC ON,OFF
WHITE BAL ATW,AWB,FIXED,MA NUAL

WARRANTY INFORMATION
Digital Watchdog (referred to as “the Warrantor”) warrants the Camera Series
against defects in materials or workmanship as follows:
LABOR: For the initial five (5) years from the date of original purchase, if the
camera is determined to be defective, the Warrantor will repair or replace the
unit, with
new or refurbished product at its option, at no charge.
PARTS: In addition, the Warrantor will supply replacement parts for the initial
five (5) years.
To obtain warranty or out of warranty service, please contact a Technical
Support Representative at 1-866-446-3595 Monday through Friday from 9:00
AM to 5:00 PM Eastern.
A purchase receipt or other proof of the date of the original purchase is required
before warranty service is rendered. This warranty only covers failures due to
df t i t il d k hi hih i d i l Thi
Digital Watchdog (referred to as “the Warrantor”) warrants the Camera Series
against defects in materials or workmanship as follows:
LABOR: For the initial five (5) years from the date of original purchase, if the
camera is determined to be defective, the Warrantor will repair or replace the
unit, with
new or refurbished product at its option, at no charge.
PARTS: In addition, the Warrantor will supply replacement parts for the initial
five (5) years.
To obtain warranty or out of warranty service, please contact a Technical
Support Representative at 1-866-446-3595 Monday through Friday from 9:00
AM to 5:00 PM Eastern.
A purchase receipt or other proof of the date of the original purchase is required
before warranty service is rendered. This warranty only covers failures due to
defects in materials and workmanship which arise during normal use. This
warranty does not cover damage which occurs in shipment or failures which are
caused by products not supplied by the Warrantor or failures which result from
accident, misuse, abuse, neglect, mishandling, misapplication, alteration,
modification, faulty installation, set-up adjustments, improper antenna,
inadequate signal pickup, maladjustment of consumer controls, improper
operation, power line surge, improper voltage supply, lightning damage, rental
use of the product or service by anyone other than an authorized repair facility or
damage that is attributable to acts of God.

LIMITS AND EXCLUSIONS
There are no express warranties except as listed above. The Warrantor will
not be liable for incidental or consequential damages (including, without
limitation, damage to recording media) resulting from the use of these
products, or arising out of any breach of the warranty. All express and implied
warranties, including the warranties of merchantability and fitness for
particular purpose, are limited to the applicable warranty period set forth
above.
Some states do not allow the exclusion or limitation of incidental or
consequential
damages, or limitations on how long an implied warranty lasts, so the above
exclusions or limitations may not apply to you. This warranty gives you
specific legal rights and you may also have other rights that vary from state to
state.
If the problem is not handled to your satisfaction, then write to the Address
LIMITS AND EXCLUSIONS
There are no express warranties except as listed above. The Warrantor will
not be liable for incidental or consequential damages (including, without
limitation, damage to recording media) resulting from the use of these
products, or arising out of any breach of the warranty. All express and implied
warranties, including the warranties of merchantability and fitness for
particular purpose, are limited to the applicable warranty period set forth
above.
Some states do not allow the exclusion or limitation of incidental or
consequential
damages, or limitations on how long an implied warranty lasts, so the above
exclusions or limitations may not apply to you. This warranty gives you
specific legal rights and you may also have other rights that vary from state to
state.
If the problem is not handled to your satisfaction, then write to the Address
above.
Service calls which do not involve defective materials or workmanship as
determined by the Warrantor, in its sole discretion, are not covered. Costs of
such service calls are the responsibility of the purchaser.

Model No. D2372TIR
Camera TYPE Color/BW Plastic 18IR-LED Day/Night Digital Dome Camera
Mount Surface
Image Device Super HAD II CCD
Size 1/3"
Pixels-Total 811(H) x 508(V)
Pixels-Effective 768(H) x 494(V)
Scanning System 525 line, 2:1Interlace
Horizontal Frequency Internal Mode 15,734Hz
Vertical Frequency Internal Mode 59.94Hz
Min. Scene Illumination IR-LED on 0 Lux
Functions BLC ON/OFF (Area Setting)
AGC ON/OFF (Gain Adjust)
AWB ATW / AWB / Fixed / Manual
Mirror ON/OFF
Motion Detection ON/OFF (Area / Sensitivity / Trace ON/OFF)
Privacy Zone 4 Programmable Zone / Size
Lens Focal Lenght Omni Focus Lens [2.9 ~ 8.5mm (3x Optical)]
Resolution Horizontal 540 TV Lines [at TDN (B/W) :570 TV Lines]
Video Output VBS 1.0Vp-p VBS 1.0Vp-p(75 Load)
S/N Ratio S/N Ratio 48dB
OSD OSD YES
Environmental Conditions Operating Temperature -10℃~ +55℃(14℉~ 131℉)
Humidity Less than 90%
Power Power Requirement 12VDC / 24VAC
Power Consumption 12VDC: 138mA (LED OFF), 423mA (LED ON)
24VDC: 152mA (LED OFF), 302mA (LED ON)
Physical Specification Dimensions(φx H) 134.9 x 110.3mm
