Digital Watchdog DWC-MB45Wi650T User manual

User’s Manual Ver. 12/20
Before installing and using the camera, please read this manual carefully.
Be sure to keep it handy for future reference.
MEGApix® 5MP Long Range Bullet IP Camera
DWC-MB45Wi650T / DWC-MPB45Wi650T

2
WARNING
To prevent damage which may result in fire or electric shock
hazard, do not expose this appliance to rain or moisture.
WARNING
1. Be sure to use only the standard adapter that is
specified in the specification sheet. Using any other
adapter could cause fire, electrical shock, or damage to
the product.
2. Incorrectly connecting the power supply or replacing
the battery may cause an explosion, fire, electric shock,
or damage to the product.
3. Do not connect multiple cameras to a single adapter.
Exceeding the capacity may cause excessive heat
generation or fire.
4. Securely plug the power cord into the power
receptacle. An insecure connection may cause fire.
5. When installing the camera, fasten it securely and
firmly. A falling camera may cause personal injury.
6. Do not place conductive objects (e.g. screwdrivers,
coins, metal items, etc.) or containers filled with water
on top of the camera. Doing so may cause personal
injury due to fire, electric shock, or falling objects.
7. Do not install the unit in humid, dusty, or sooty
locations. Doing so may cause fire or electric shock.
8. If any unusual smells or smoke come from the unit, stop
using the product. Immediately disconnect the power
source and contact the service center. Continued use in
such a condition may cause fire or electric shock.
9. If this product fails to operate normally, contact the
nearest service center. Never disassemble or modify
this product in any way.
10. When cleaning, do not spray water directly onto parts
of the product. Doing so may cause fire or electric
shock.
Precaution
Operating
• Before using, make sure the power supply and all other
parts are properly connected.
• While operating, if any abnormal condition or
malfunction is observed, stop using the camera
immediately and contact your dealer.
Handling
• Do not disassemble or tamper with parts inside the
camera.
• Do not drop the camera or subject it to shock or
vibration as this can damage the camera.
• Clean the clear dome cover with extra care. Scratches
and dust can ruin the quality of the camera image.
Installation and Storage
• Do not install the camera in areas of extreme
temperature, exceeding the allowed range.
• Avoid installing in humid or dusty environments.
• Avoid installing in places where radiation is present.
• Avoid installing in places where there are strong
magnetic fields and electric signals.
• Avoid installing in places where the camera would be
subject to strong vibrations.
• Never expose the camera to rain or water.
Warning
This symbol indicates that dangerous
voltage consisting of a risk of electric
shock is present within this unit.
Precaution
This exclamation point symbol is intended
to alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION :
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE
PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

3
Important Safety Instructions
1. Read these Instructions. - All these safety and operating instructions should be read before the product is installed
or operated.
2. Keep these Instructions. - The safety, operating and use instructions should be retained for future reference.
3. Heed all warnings. - All warnings on the product and in the operating instructions should be adhered to.
4. Follow all instructions. - All operating and use instructions should be followed.
5. Do not use this device near water. - For example: near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement; near a swimming pool; etc.
6. Clean only with a dry cloth. - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners.
7. Do not block any ventilation openings. Install following the manufacturer’s instructions. - Slots and openings
in the cabinet are provided for ventilation, to ensure reliable operation of the product, and to protect it from over-
heating. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surfaces.
This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is
provided and the manufacturer’s instructions have been adhered to.
8. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
Disposal of Old Appliances
1. When this crossed-out wheel bin symbol is attached to a product it means the
product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the
municipal waste stream per laws designated by the government or the local
authorities.
3. The correct disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact
your city office, waste disposal service or the shop where you purchased the product.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.

4
Table of Contents
Introduction
Product and accessories..................................................................................................................................................................5
Parts identification............................................................................................................................................................................6
Installation
Factory reset........................................................................................................................................................................................7
Installation............................................................................................................................................................................................7
Cabling...................................................................................................................................................................................................8
Managing the SD Card..................................................................................................................................................................10
Network Setup
DW IP finder.......................................................................................................................................................................................11
Web Viewer
Login to the camera.......................................................................................................................................................................12
GUI overview.....................................................................................................................................................................................13
Camera Settings
Settings > Video and audio setup.............................................................................................................................................14
Settings > Camera setup > Image adjustment.....................................................................................................................22
Settings > Camera setup > Exposure settings......................................................................................................................23
Settings > Camera setup > Day and night settings............................................................................................................24
Settings > Camera setup > Backlight settings......................................................................................................................25
Settings > Camera setup > White Balance settings............................................................................................................26
Settings > Camera setup > Image enhancement settings...............................................................................................27
Settings > Camera setup > Video enhancement.................................................................................................................28
Settings > Network setup.............................................................................................................................................................29
Settings > Trigger action setup..................................................................................................................................................39
Settings > Event setup...................................................................................................................................................................43
Settings > Record setup................................................................................................................................................................48
Settings > Security setup..............................................................................................................................................................54
Settings > System setup > System information...................................................................................................................61
Settings > System setup > Firmware.......................................................................................................................................63
Settings > System setup > Date and time..............................................................................................................................64
Settings > System setup > DST..................................................................................................................................................65
Settings > System setup > Users...............................................................................................................................................66
Settings > System setup > System log....................................................................................................................................67
Settings > System setup > Factory reset................................................................................................................................68
Settings > System setup > Restart............................................................................................................................................69
Settings > System setup > System open source license...................................................................................................70
Network setup guides...............................................................................................................................71
FAQs............................................................................................................................................................78
Dimensions.................................................................................................................................................79
Specifications.............................................................................................................................................80
Warranty.....................................................................................................................................................81
Limits and exclusions.................................................................................................................................82

5
Introduction -
Product and Accessories
Hex Wrench Test Monitor
Cable
Mounting Template Waterproof Cap and
Gasket
Screws and
Plastic Anchors -
4pcs
Camera
Cables
Please check if all the camera and accessories are included in the package.
Quick Installation and
Download Guide

6
Introduction -
Part Name
Sunshield Adjusting Screws
Pan/Tilt Stopper
Screw
Bracket
Sunshield
Lens
Control Board
Con Cap
RJ-45 Connector
Waterproof Cap
Audio In/Out
DC Power Jack
Alarm In/Out

7
Installation -
Installation
Before installing your camera, you must read the following cautions.
1. The mounting surface must withstand five times the camera weight.
2. Do not let the cables get caught in improper places or the electric line cover can be damaged. This may
cause a short or fire.
3. Using the mounting template or the camera itself, mark and drill the necessary holes in the mounting
surface.
Installing your camera:
1. Pass wires through and make all necessary connections.
See the ‘Cabling’ section for more information.
2. Using the included screws and anchors, secure the camera
to the mounting surface.
3. Loosen the pan/tilt stopper screw and adjust the
camera’s angle as needed.
4. Use the test video cable for a local preview
of the camera’s view.
5. Use the T-W toggles at the bottom of the
camera to adjust the zoom.
Reset to the Factory Default
Press the reset button for 5 seconds to return the
setup to the factory default.
Warning:
If you press the ‘Reset’ button, you will lose all
setting data. If needed, please, make a note for
further installation.
Reset Button
T-W Jog Button SD Card Slot
Test Video Output
WIDE
TELE
Zoom Out
Zoom In

8
Installation -
Cabling
1. Using a PoE-Enabled Switch
The Camera is PoE-compliant, allowing transmission
of power and data via a single Ethernet cable.
PoE eliminates the need for the different cables used
to power, record, or control the camera. Follow the
illustration below to connect the camera to a PoE-
enabled switch using an Ethernet cable.
2. Using a Non-PoE Switch
If a PoE-enabled switch is not used, use a power
adaptor for power transmission and non-PoE switch
for data transmission.
Follow the illustrations below to connect the camera
without a PoE-enabled Switch.
Two Options
Use a PoE-enabled switch to connect data and power through a single cable and begin viewing and recording
images instantly.
A non-PoE switch will require an adaptor for power transmission.
Ethernet Cable Ethernet Cable
Power

9
1Power Connection
Please, check the voltage and current capacity of
rated power carefully.
2Network Connection
Connect the crossover cable into the RJ-45.
Installation -
Cabling
1Power
2Network
4Audio Output
3Audio Input
5Alarm Output
6Alarm Input
6Alarm In
5Alarm Out
Rate Power Power
Consumption PoE
DC 12V 9W
IEEE 802.3af
class3, max
10.5W
DI YELLOW +
DOT
DI COM YELLOW
DO1
COM BLUE
DO1
(N.O.) BLUE + DOT
N.C
N.O In 1
COM
In1
COM
In1
COM
In1
COM
3Audio Output
Connect the ‘audio out’ port of the camera to the
‘line in’ port of the speaker.
If the speaker without the amplifier is connected
to the audio out port, it doesn’t work properly.
Therefore, the speaker with the amplifier or the
separate amplifier is needed.
Audio Out is available via the RTSP backchannel.
4Audio Input
Connect the ‘audio in’ port of the camera to the
microphone directly or 'line out’ port of the
amplifier connected with a microphone.
If the microphone is connected directly, the
microphone with the embedded amplifier such
as condenser mic. needs to be used.
5Alarm/Relay Out (DO)
Connects to the alarm lights, siren or lamps and
the sensor types are normally open and
normally close.
6Sensor/Alarm Input (DI)
The sensor/alarm input device's cable should
connect to + and - of the Terminal Block.

10
Installation -
Managing the SD Card
Micro
The memory card is an external data storage
device that has been developed to offer an
entirely new way to record and share video,
audio, and text data using digital devices.
Recommended SD card specification
(not included)
- Type: Micro SD (SD/SDHC/SDXC)
- Manufacturer: SanDisk, Samsung,
Transcend, Micron
- Capacity: 4GB~128GB
- Class: UHS-I U3 Class 10
New micro SD card over 64GB must be
formatted on the first use.
1Inserting an SD Memory Card
Insert the SD card in the arrow direction.
Don’t insert the SD memory card while it’s
upside down by force. Otherwise, it may
damage the SD memory card.
2Removing an SD Memory Card
Removing an SD Memory Card Gently press down
on the exposed end of the memory card as shown
in the diagram to eject the memory card from
the slot.
Pressing too hard on the SD memory card can
cause the card to shoot out uncontrollably from
the slot when released.
If you have saved data in the SD memory card,
removing the SD memory card before setting
the record to OFF will cause damage to the data
stored in the card.

Network Setup -
DW IP Finder™
1Go to http://www.digital-watchdog.com and search for ‘IP Finder’ on the
quick-search bar at the top of the page.
2The latest IP Finder software will appear in the search results. Click on
the link to download the file to your computer.
3The software will scan your network for all supported cameras and
display the results in the table. Allow up to 5 seconds for the IP Installer
to find the camera on the network.
4You can press the ‘Refresh List’ to search the network again, or filter the
search results by entering a value in the filter box.
5Check the box next to ‘Display Camera Thumbnail’ to view a JPEG image
of the camera’s view next to the camera name on supported models.
The default network type of camera is DHCP mode.
If you have a DHCP server, it will automatically set the Camera IP.
Contact your network administrator for more information.
6To save the changes made to the camera's settings, input the username
and password of the camera for authentication.
7If the camera needs to be rebooted after the settings were changed,
press the 'Reboot' button. The camera will power cycle and will appear back in the search results once
the reboot is complete.
Default username and password: admin/admin.
For security purposes, it is highly recommended to change your password after initial setup.
8Click 'Save' to save changed values.
9To update the camera's firmware from the DW IP Finder™, click on the firmware tab, upload the firmware
file and select the camera to update. You can update multiple cameras at the same time.
11

Web Viewer Screen -
Basic Screen (Default)
Password change is required at the initial connection in a factory reset state.
1You cannot see the image, and the setup button is disabled.
2Change the password with the CHANGE PASSWORD button.
3After changing the password, login again by pressing the RE-LOGIN button.
•Internet Explorer: After three failed attempts or the cancel button is clicked, you will experience a login fail.
•Other Browsers: After the Cancel button is clicked, you will experience a login fail.
Password Hint Page
•If you need help remembering the password for your user, input the username in the username field and
press the hint button. If you added a hint for your password when setting it up, it will appear then.
12

13
The web viewer is optimized with Internet Explorer 10 (or above) and Mozilla Firefox.
“If VLC is not installed or the VLC plugin is not supported (Chrome), ‘Live Buffering’ and ‘Channel Select’
(subjects 3 and 4 in the diagram) will display as ‘Live Viewer’. If so, select HTML5 (MJPEG) from the Live
Viewer menu to view the video.
1Live video display. This is the region for the live video stream from the camera.
2Setup a popup button. Click it to open the Setup page to setup details of IP camera like Video, Network,
Events, System, etc. See the section ‘Setup’.
3When the image is not smooth due to a bad network connection, it stored image during setup time and
shows the image on the live view screen.
Users will see the delayed images based on the set delay time.
4Channel Select button. Select a stream produced from the camera between Stream 1 ~ 3 to display it in the live
view screen.
Refer the ‘Setup > Video & Audio > Video’ to setup the Video Stream.
5Below “Menu” is supported per models.
6Motion - Shows the motion event status.
Event Alert Icon ( ) appears if ‘Motion Detection’ is activated.
7Camera Time - Display the camera time.
Web Viewer Screen -
Basic Screen
PTZ Control - This camera model does not support the zoom and focus.
Preset - Not supported.
Speaker Control - Enable/disable the audio stream from the camera and adjust the volume accordingly.
Alarm Input - If an alarm is triggered, the corresponding input number will be changed from dark gray to red.
Relay Out - Using this checkbox, read the relay output status and set or reset it manually.
2
3
4
5
6
7
1

14
Setup - Video & Audio Setup
Video Configuration
1
2
1Detail Page - When you select an item from the menu, you can set the details for the selected item.
2Setup Constitution
Video & Audio
[ VIDEO, OSD, ROI, AUDIO, PRIVACY MASK ]
Camera
[ IMAGE ADJUSTMENT, EXPOSURE, DAY&NIGHT, BACKLIGHT, WHITE BALANCE, IMAGE, VIDEO ]
Network
[ STATUS, NETWORK SETTING, AUTO IP, ONVIF, UPNP, DDNS, FTP, SMTP, SNMP, RTSP INFORMATION ]
Trigger Action
[ ACTION RULES, IMAGE TRANSFER, RELAY OUT ]
Events
[ EVENT RULES, MOTION, TEMPERATURE, ALARM ]
Record
[ MANAGEMENT, RECORD LIST, STORAGE ]
Security
[ IP ADDRESS FILTER, RTSP AUTHENTICATION, IEEE 802.1x, HTTPS, CERTIFICATES, SERVICE ]
System
[ INFORMATION, DIAGNOSTICS, FIRMWARE UPDATE, DATE&TIME, DST, USER MANAGEMENT, LOG,
LANGUAGE, FACTORY RESET, RESTART, OPEN SOURCE ]
NOTE: See MEGApix IVA Rules manual for more information on the IVA and IVA+ rules, setup and
configuration

15
1Live Video Channel Setup - The video can be configured to various settings with a combination of codec and
resolution. The camera performance should be considered when setting multiple channels, as the performance
of the camera will be affected.
H.265 (HEVC) codec with higher bitrate may cause unstable live streaming or reload the webpage.
2Codec - Choose the video codec. Depending on the selected codec, the subcategories may be changed
accordingly.
3Description - Input the additional description of the selected channel. Max. 30 alpha-numeric characters may
be used, including spaces.
4Resolution - Select video resolution.
Available Frame Rate may differ even if the same codecs are in use.
<Resolution of Video Format>
5Frame Rate - Select the maximum Frame Rate.
Available Frame Rate can be different although the same codecs were set up.
Setup - Video & Audio Setup
Video Configuration
2
3
4
5
1
5MP
(QSXGA) 4MP 2.1MP/
1080p 720p/i SVGA 768x432
(0.3M) 4CIF D1 VGA 640x360
(0.2M) CIF SIF / 240P
2592x1944 2560x1440 1920x1080 1280x720 800x600 768x432 704x576 704x480 640x480 640x360 352x288 352x240

16
6GOP(Group of Pictures) Size - Set up the number of frames (P-frame) which contain only changed information
based on the basic frame (I-frame). Regarding videos with lots of movement, if you set GOP size bigger, only
the number of P-frames is bigger.
As a result, the video resolution will be low but ‘File size’ and ‘Bit-rate can be decreased.
GOP(Group of Pictures) Size -
I-frame and P-frame creation for MPEG4, H.264, and H.265 (HEVC) video compression. ‘I-frame’, also known
as ‘key-frame’, refers to the complete image data for a specific video frame. ‘P-frame’ refers to the changes
in the image in comparison to the previous video frame. As a result, the GOP consists of one I-frame and
several P-frames. For improved video quality, use a lower number of P-frames for this setting.
7Profile - The profile defines the subset of bitstream features in H.264, H.265 (HEVC) stream, including color
reproduction and additional video compression.
H.264: Main, High / H.265 (HEVC): Main
8Bitrate Mode - Select the bit rate control scheme of video compression from CBR (Constant Bit Rate) or VBR
(Variable Bit Rate).
This category will not appear if you select the codec.
Setup - Video & Audio Setup
Video Configuration
6
7
8
Main - An intermediate profile with a medium compression ratio. Supports I-frames, P-frames, and B-frames.
High - A complex profile with a high compression ratio. Supports I-frames, P-frames, and B-frames.
CBR - To guarantee the designated constant bit rate, the quality of the video is controlled in this
mode. Therefore, the quality of the video is likely to be varying when network traffic is changing.
VBR - To guarantee the designated quality, the bit rate of the video stream is changed in this mode.
Therefore, the frame rate of the video is likely to be varying when network traffic is changing.

17
Setup - Video & Audio Setup
Video Configuration
9
10
11
12
13
9Target Bitrate - If Bitrate Control is set to be CBR, you can set the Target Bitrate.
10 Quality - For VBR control mode, The Target Quality of video can be setup.
11 Smart Core - Off / Smart.RC
12 Extension Option
13 Click ‘Apply’ to save all settings.
Off - You cannot use the Extension Option.
SVC-T On - The H.264, H.265 (HEVC) SVC (Scalable Video Coding) is a video compression algorithm
that enables effective and efficient transmission of video files over low bandwidth networks.

18
Setup - Video & Audio Setup
OSD Configuration
1
2
3
1Date / Time - Display the current time.
2User Text - Output the TEXT entered by the user. Support a maximum of 30 characters.
3Click ‘Apply’ to save all settings.

19
1
2
3
4
The region of interest function gives a more efficient picture quality for the indicated area to improve the
qualities of movement in the scene without compromising the bandwidth.
1Stream - Select the Stream.
Currently supports only H.264, H.265 (HEVC).
The function is not supported in the MJPEG codec.
2Activation - Enable or disable the region of interest function.
3Quality - Set the quality of the set area.
4Click ‘Save’ to save all settings.
Click 'Cancel' to return to the previous setting.
Setup - Video & Audio Setup
Region of Interest Configuration

20
1Codec - Select the Audio Codec.
Currently, the camera supports codec G.711.
2Volume - Select the Audio Volume from 0 to 10.
3Sample Rate - Select the Audio Sample Rate.
Currently, the camera supports 8000 Hz.
4Click ‘Save’ to save all changes.
Setup - Video & Audio Setup
Audio Configuration
1
2
3
4
