Digital Watchdog Star-Light Plus DWC-B6853WTIR User manual

Quick Start Guide Quick Start Guide
WHAT’S IN THE BOX
Star wrench 1Mounting
template 1
Test video
cable 1
Moisture
absorber and
absorber guide
(recommended)
1
Sunshield
cover and
adjusting
screws
1Quick setup
guide 1
Screws
and plastic
anchors
(4pcs)
1 Set DC plug cable 1
Pass the wires through the mount bracket and make all necessary connections. Connect the BNC cable and power cables to the camera.
STEP 1 – PREPARING TO MOUNT THE CAMERA
STEP 2 – CABLING THE CAMERA TO EXTERNAL DEVICES
Power requirements Power consumption
DC12V DC12V (LED o): 3W (250mA)
DC12V (LED on): 4.2W (352mA)
Tel: [phone]
Technical Support Hours:
9:00 AM – 8:00 PM EST, Monday through Friday
digital-watchdog.com
DWC-B6853WTIR
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Torx Wrench DC Plug Cable Test Video Cable
ManualTemplate Sheet Screw & Moisture absorber &
Absorber Guide
Sunshield cover &
Please cut the card type absorber along
a dotted line, overlap and attach them
according to the direction of the arrow.
Please cut the card type absorber along
a dotted line, overlap and attach them
according to the direction of the arrow.
Attention: This document is intended to serve as a quick reference for the
initial setup. It is recommended that the user read the entire instruction
manual for complete and proper installation and usage.
NOTE: Download all your support materials and tools in one place.
1. Go to: http://www.digital-watchdog.com/resources
2. Search your product by entering the part number in
the ‘Search by Product’ search bar. Results for
applicable part numbers will populate automatically
based on the part number you enter.
3. Click ‘Search’. All supported materials, including manuals
and quick start guide (QSGs) will appear in the results.
1. The mounting surface must withstand five times the camera weight.
2. Do not let the cables get caught in improper places or the electric line cover can be damaged. This may cause a short or fire.
3. Install the moisture packet in the base of the camera’s lens.
a. Remove the moisture absorber from the packaging.
b. Cut the card and folder along the dotted line.
c. Place the moisture absorber behind the camera’s lens module. See drawing for more information.
4. Using the mounting template sheet or the camera itself, mark and drill
the necessary holes in the wall or ceiling.
WARNING: It is highly recommended that you install the moisture
absorber when mounting the camera. The moisture
absorber prevents moisture from being captured
inside the camera's housing, which may cause image
performance issues and damage the camera.
NOTE: The camera will generate enough heat to dry moisture
during operation. In most cases it will not need the
moisture absorber for more than the first day. In cases
where the camera can experience a moisture issue,
users must keep the moisture absorber in the camera.
The moisture absorber has an approximately 6-month
life cycle, varying depending on the environment.

Quick Start Guide
1. The camera supports HD-Analog, HD-CVI and HD-TVI signals as
well as CVBS up to 960H. To switch between the signals:
a. Enter the camera’s OSD menu. You can access it locally from
using the camera’s joystick in the body of the camera, or from a
recorder supporting UTC communication.
Go to SETUP > OUTPUT.
b. Set the camera’s resolution from the following options:
- 4K/2160p @15fps.
- 5MP/1440 @30fps.
- 2.1MP/1080p @30fps.
c. Set the camera’s analog signal output from the following options:
- HD-A - HD-Analog
- HD-T - HD-TVI
- HD-C - HD-CVI
- CVBS - legacy analog signal
d. Change CONFIRM to ON to save the changes.
e. Go to the EXIT menu and select SAVE&EXIT to save all changes.
The camera signal automatically.
1. Once all cables have been connected, use the screws included with the
camera to properly mount and secure the camera to the mounting surface.
2. To adjust the camera’s tilt, loosen the screws at the base of the camera’s
bracket. The camera’s max angles are:
Pan: 0°~ 360°
Tilt: 0°~ 90°
STEP 4 – INSTALLING THE CAMERASTEP 3 – CHANGING THE SIGNAL IN
THE CAMERA
Copyright © Digital Watchdog. All rights reserved.
Specifications and pricing are subject to change without notice.Rev: 04/21
NOTE: To use your Star-Light Plus™ 4K cameras at a lower
resolution, you must use a VMAX® A1 4K DVR to access the
camera’s menu due to the cameras being set to 4K as the
default. A DVR that does not support 4K resolution may
recognize the camera, but will not deliver a picture.
