DigitaLinx DL-RMKTC2H-2 User manual

DL-RMKTC2H-W Installaon Guide
The Digitalinx DL-RMKTC2H-W is a mul-funcon AV distribuon system designed to provide
HDMI video switching, system control, video extension and analog audio amplicaon in
a convenient kit. Ulizing the Valens Colligo VS2110 series chips, power, control, video up
to 1080p, and audio are transported over a single 30m (98 ) solid core Category 5e cable
between the wall plate transmier and the receiver. The wall plate control module connects
to the wall plate transmier with a second Category 6 cable. All the power needed for the
system is provided by the receiver. Addionally, the receiver features a built-in web GUI for
control and analog audio de-embedding to a built-in 2x20 wa stereo amplier.
FIRMWARE ON LINK HDCP
DL-RMKTC2H-2
RX / Receiver
OUTPUT CONTROL AUDIO MICINPUTNETWORK
2x20 Watts @ 4Ω24V DC
LINE MIC
MIC
RL
LINE OUT
TX RX
RS232IR OUT REMOTE
MUTE
FROM
TOUCHSCREEN
TO DISPLAYHDBT IN/PoC
TCP/IP
HDMI IN 1SOURCE SELECT
TO PC HDMI IN 2
FIRMWARE
RESET
HDCPLINK
VOLUME
MIC
SOURCE
ON
HDMI 1
IR
HDMI 2
CONFIG
OFF

Included Accessories
Safety Precauons
• DL-RMKTC2H-W Control Keypad, Transmier and Receiver Set
• Locking Power Supply with US Power Cable
• USB Type A to Type B Cable
• IR Emier
• Two Mounng Rails with Screws
• Six Wall Box Screws
• Three 3-pole Removable Terminal Blocks
• One 2-pole Removable Terminal Block
• One 4-pole Removable Terminal Block
• Installaon Guide
To insure the best from the product, please read all instrucons carefully before using the
device. Save this manual for further reference.
• Unpack the equipment carefully and save the original box and packing material for
possible future shipment.
• Follow basic safety precauons to reduce the risk of re, electrical shock and injury to
persons.
• Do not dismantle the housing or modify the module. It may result in electrical shock or
burn.
• Using supplies or parts not meeng the products’ specicaons may cause damage,
deterioraon or malfuncon.
• Refer all servicing to qualied service personnel.
• To prevent re or shock hazard, do not expose the unit to rain, moisture or install this
product near water.
• Do not put any heavy items on the extension cable in case of extrusion.
• Do not remove the housing of the device as opening or removing housing may expose you
to dangerous voltage or other hazards.
• Install the device in a place with good venlaon to avoid damage caused by overheang.
• Keep the module away from liquids.
• Spillage into the housing may result in re, electrical shock, or equipment damage. If an
object or liquid falls or spills on to the housing, unplug the module immediately.
• Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the
device before cleaning.
• Unplug the power cord when le unused for a long period of me.
• Informaon on disposal for scrapped devices: do not burn or mix with general household
waste. Please treat them as normal electrical waste and recycle the devices properly.

Receiver Front Panel
Receiver Rear Panel
FIRMWARE ON LINK HDCP
DL-RMKTC2H-W
RX / Receiver
12 3 4 5
OUTPUT CONTROL AUDIO MICINPUTNETWORK
2x20 Watts @ 4Ω24V DC
LINE MIC
MIC
RL
LINE OUT
TX RX
RS232IR OUT REMOTE
MUTE
FROM
TOUCHSCREEN
TO DISPLAYHDBT IN/PoC
TCP/IP
A B C D E F G H I J K L
1. Firmware Update Port
2. System Power Indicator
3. HDBaseT Link Indicator
4. HDCP Status Indicator
5. Receiver Power Indicator
A. Network Port
B. HDBaseT Input and PoC Output
C. HDMI Output
D. USB Port to Touchscreen Display
E. IR Output to Display
F. RS232 Output to Display
G. Remote Mute Contact Closure
H. Line Level Analog Audio Output
I. Line/Mic Level Selector Switch
J. Microphone Input
K. Speaker Output
L. 24V DC Power Input

Transmier Front
Transmier Rear
HDMI IN 1SOURCE SELECT
TO PC HDMI IN 2
FIRMWARE
RESET
HDCPLINK
1 2 3
4 5 6
A
B
PoC IN
HDBT OUT
POWER
RS232
DL-RMKTC2H-W
TX / Transmitter
1. Power Indicator and Source Select Buon
2. Link and HDCP Status LEDs and Reset Buon
3. HDMI Input 1 with Acvity Indicator
4. USB Port to Host PC
5. Firmware Update Port
6. HDMI Input 2 with Acvity Indicator
A. HDBaseT Output and PoC Input
B. Power and RS232 to Control Panel

Control Panel Front
Control Panel Rear
VOLUME
MIC
SOURCE
ON
HDMI 1
IR
HDMI 2
CONFIG
OFF
1
5
2
3
4
6
7
8
POWER
RS232
FIRMWARE
DL-RMKTC2H-W
PAD / Control Pad
A B
1. Mic/Source Indicator
2. System/Display On Buon
3. HDMI Input 1 Select Buon
4. IR Receiver
5. Mulfuncon Volume Control with Volume
Level Indicator
6. System/Display O Buon
7. HDMI Input 2 Select Buon
8. Conguraon Port
A. Power and RS232 from Transmier
B. Firmware Update Port

Cabling Requirements
TIA/EIA-568B
Orange/White
Orange
Green/White
Blue
Blue/White
Green
Brown/White
Brown
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
1 8
Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category 6
connecon between send and receive
units.
RS232 Wiring
Connect the display RX signal to Tx on
the DL-RMKTC2H-W receiver Connect
the display TX signal to Rx on the DL-
RMKTC2H-W extender.
To ensure proper performance of the DL-RMKTC2H-W, it is recommended that you use solid
core Category 6 F/UTP cabling at a minimum between control keypad and transmier and
between transmier and receiver. Category 5e F/UTP may perform well but may not support
power over HDBaseT reliably.
When using shielded category cabling ALWAYS...
....use shielded connectors
....properly ground the category cable
Tx RXD
GND
Rx TXD
DL-RMKTC2H
(RX) Display

Speaker Wiring Conguraons
4Ω Load with 4Ω Speakers
+
–
4Ω
+
–
4Ω
4Ω Load with 8Ω Speakers
+
–
+
–
8Ω
8Ω
+
–
+
–
8Ω
8Ω

1. Verify all components included with the DL-RMKTC2H-W are present before installaon.
2. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instrucons.
3. Aach the included rubber feet or mounng ears to the receiver.
4. Connect an HDMI cable between the HDMI output of the Receiver and the HDMI input of
the display. The HDMI cable should not exceed 5 meters (16 feet).
5. Connect a microphone to the microphone input connector.
6. Adjust the microphone input mode selector based on the type of microphone to be
connected to the Receiver.
a. MIC – 48dB gain
b. LINE – 4dB gain
7. Connect the speakers to be used in accordance with the Speaker Wiring Conguraons. If
an external audio amplier is to be used with the system, connect the unbalanced analog
audio output of the Receiver to the input of the amplier.
8. If the display is to be controlled via IR, plug the IR emier to the IR Out port of the Receiver
and mount the IR emier bud to the IR receiver port of the display.
9. If the display is to be controlled via RS232, plug the 3-pole terminal plug end of the
included RS232 cable into the RS232 port on the Receiver and the DE9 end to the display.
10. Connect a USB cable between the displays interacve white board USB port and the USB
port labeled “From Touchscreen” on the rear of the Receiver.
11. Connect a Category 6A or greater cable between the Network TCP/IP port and the
facility’s network.
12. Connect a Category 6A or greater cable between the Input port of the Receiver and the
Output port of the Transmier. This cable cannot exceed 30 meters (98 feet).
13. Connect a Category 6A or greater cable between the Power and RS232 port on the
Transmier and the Power and RS232 port on the Control Panel.
14. Connect the included USB cable between the TO PC port on the front of the Transmier
and the PC to receive the commands from the interacve white board.
15. Plug the power supply into the power input port on the Receiver.
16. Power on the Receiver by plugging the power cable into the power supply.
17. Power on all audio/video devices.
Installaon Instrucons

Web Browser Conguraon
Logging In
The default IP address of the DL-RMKTC2H-W is 192.168.0.178. This can be changed in the
Network sengs.
To change the sengs of the web browser interface or program RS232 commands for the
display, log into the DL-RMKTC2H-W as an administrator. The User Name is admin and the
default Password is admin.

Device Control Screen
HDMI
Switch between HDMI 1 and HDMI 2.
Display
Turn the display on or o.
System
Turn the system on or o.
Volume
Mute and unmute audio sources. Volume may be changed by pressing the “+” or “-“ buons
or by dragging the volume slider.
To enter the conguraon sengs, click on the gear icon on the lower le corner of the
Control interface.

Seng Tab
Password
Change the password for the admin and user login screen.
Display Control Select
Select whether the display will be controlled via IR or RS232.
Display/Power Sync
Select whether the display and system will be powered on and o simultaneously. This opon
is only acve if the display is controlled via RS232.
I/O Mode Select
Select whether the contact closures need to be normally open (N.O.) or normally closed
(N.C.) to mute the audio output for integraon with a mass nocaon system.
Floor
Assign a oor designaon to the system.
Label
Rename the label at the top of the Control screen.
Audio Delay
Sets up the audio delay to sync the audio with the video on the display. The delay me is 0 to
340 ms. Click the GO buon the acvate the new value.
Save/Cancel
Saves or cancels changes made to this screen.

Command Tab (RS232 Display Control)
This tab denes the RS232 display control commands. If a display requires hex commands, make sure
the Hex box is checked.
Display On / Display O
Enter the RS232 command to turn ON or OFF the display.
Input Select
Enter the RS232 command to switch to the display or projector input which is connected to the DL-
RMKTC2H-W Receiver.
Input Select Delay
Enter the delay me in seconds between the Display ON and Input Select commands. This delay may be
between 1 and 100 seconds. The default me is 5 seconds.
Baud Rate
Select the baud rate necessary to communicate with the display. Available baud rates are: 2400, 4800,
9600, 14400, 19200, 38400, 56000, 57600, and 115200 baud.
Parity
Select the parity bit seng for your RS232 strings. Available parity sengs are NULL, ODD or EVEN.
No Acvity Timeout
Set the No Acvity Timeout as needed in hours and minutes, the system will enter standby mode and
the display will automacally shutdown when no input video signal is detected aer the specied
meout.
Save/Cancel
Saves or cancels changes made to this screen.

Network Tab
DHCP/Stac IP
Select whether the system will use a stac IP or will be provided an IP via DHCP.
IP Address
Enter the IP address for the system.
Subnet Mask
Enter the subnet mask for the system.
Gateway
Enter the gateway address for the system.
Save/Cancel
Saves or cancels changes made to this screen.
Note: The rmware versions for each devices is also shown on this screen located at the
boom right.

Transmier Operaon
Control Keypad Operaon
Plugging in an HDMI source will automatically switch to that input. Pressing the
Source Select button will switch sources.
The DL-RMKTC2H-W systems control keypad can control the systems power status as well as
the displays power status by either RS232 or IR.
When RS232 is used to control the display, the DL-RMKTC2H-W system can be congured to
synchronize with the power of the display simultaneously or can be programmed so system
power and display power can be controlled separately.
By default the DL-RMKTC2H-W is set to control the connected display by IR. The adjustment
in the web GUI for this seng is under the SETTING tab.
When using IR control of a connected display the DISPLAY POWER SYNC opon in the GUI is
not available and system and display power status must be controlled separately.
To turn the DL-RMKTC2H-W systems power ON or OFF using the default IR display control
seng, press and hold the keypads ON / OFF buon to power system ON / OFF. To power
display ON or OFF simply quick press the keypad ON / OFF buon.
IR Display Control

Control Keypad Operaon (connued)
Exit IR Learning Mode
Enter IR Learning Mode
Programming the Display On and Display O Keypad Funcons
Press and hold the HDMI 1 buon on the Control Panel for three seconds. The ON and OFF
buons will light up.
Follow the instrucons below to enter IR learning mode to program IR ON / OFF commands so
the DL-RMKTC2H-W keypad can control display power.
Press and hold the HDMI 2 buon on the Control Panel for three seconds. The ON and OFF
buons will go dark.
1. Press the ON buon, and it will start to ash.
2. Point the display remote at the Control Panel IR sensor and the press the Power On buon
on the remote. The ON buon on the Control Panel will stop ashing.
3. Press the OFF buon, and it will start to ash.
4. Point the display remote at the Control Panel IR sensor and the press the Power O
buon on the remote. The OFF buon on the Control Panel will stop ashing.
Tesng Display On / O IR Control on Control Pad
To test the IR On and O control funcons for your display or projector simply quick press
the ON and OFF buons on the control pad. Your display or projector should respond to the
stored IR commands appropriately, if not repeat steps 1-4 from ‘Programming the Display On
and Display O Funcons’.
IR Display Control - IR Learning Mode Conguraon

To program RS232 display control so the display and DL-RMKTC2H-W power status can be
controlled simultaneously with the DL-RMKTC2H-W control keypad ON / OFF operaon,
navigate to the SETTING page in the web GUI and change the DISPLAY CONTROL SELECT
opon to RS232 and then change the DISPLAY POWER SYNC opon to ON.
RS232 Display Control
Programming System and Display Simultaneous Power Control
When RS232 is used to control the display, the DL-RMKTC2H-W system can be congured to
synchronize with the power of the display simultaneously or can be programmed so system
power and display power can be controlled separately.
Aer the RS232 sengs are all in place, you can now turn the DL-RMKTC2H-W systems
power and display power ON or OFF by quick pressing the ON / OFF status buons on the
DL-RMKTC2H-W control keypad.
To load the connected displays RS232 ON or OFF command sets into the DL-RMKTC2H-W,
navigate to the COMMAND page and enter in the command sets and proper RS232 sengs
according to the display manufacturers suggesons. See Command Tab (RS232 Display
Control) in this manual for reference.

To program RS232 display control so the display and DL-RMKTC2H-W power status can be
controlled separately with the DL-RMKTC2H-W control keypad ON / OFF operaon, navigate
to the SETTING page in the web GUI and change the DISPLAY CONTROL SELECT opon to
RS232 and then change the DISPLAY POWER SYNC opon to OFF.
Programming System and Display Power Control Separately
To load the connected displays RS232 ON or OFF command sets into the DL-RMKTC2H-W,
navigate to the COMMAND page and enter in the command sets and proper RS232 sengs
according to the display manufacturers suggesons. See Command Tab (RS232 Display
Control) in this manual for reference.
Control Keypad Operaon (connued)
Once all RS232 sengs and commands are in place, turn the DL-RMKTC2H-W systems power
ON or OFF by pressing and holding the keypads ON / OFF buon to power system ON / OFF.
To power display ON or OFF separately, simply quick press the DL-RMKTC2H-W keypad ON /
OFF buons.

Select Input Sources
Volume Control Funcons
Press the HDMI 1 or HDMI 2 buons on the Control Panel to select the appropriate source
device.
Turning the Volume knob clockwise will raise the volume; counterclockwise will lower the
volume.
Pressing the Volume knob will mute or unmute the current audio source.
Pressing and holding the Volume knob for three seconds will switch to the other audio source.
If the audio source is muted, this acon will unmute the source.
Control Keypad Operaon (connued)

Web Browser Control Operaon
Logging In
The web browser control interface is an alternave method to control the system without
having to interact with the Control Panel.
The default IP address of the DL-RMKTC2H-W is 192.168.0.178. This can be changed in the
Network sengs by an administrator.
The User Name is user and the default Password is user.

Device Control Screen
HDMI
Switch between HDMI 1 and HDMI 2.
Display
Turn the display on or o.
System
Turn the system on or o.
Volume
Mute and unmute audio sources. Volume may be changed by pressing the “+” or “-“ buons
or by dragging the volume slider.
