DigitaLinx DL-1H1A1U-WPKT-W User manual

11675 Ridgeline Drive
Colorado Springs, CO
80921
Rev 181219 Phone: [phone]
Toll-Free: 800-530-8998
Fax: [phone]
DL-1H1A1U-WPKT-W Install Guide

DL-1H1A1U-WPKT-W Install Guide
2
The Digitalinx DL-1H1A1U-WPKT-W HDBaseT 2.0 extender set transmits HDMI, audio
, USB High Speed (up to 190Mbps) and RS232 over single category 6 twisted pair
cable. The DL-1H1A1U-WPKT-W can transmit 4K resoluons up to 4K@60Hz, 4:2:0 up
to 40m / 120’ and 1080P up to 70m / 230’. The audio circuit is completely separate
and is not dependent on the HDMI or USB input source to be acve. The Digitalinx
DL-1H1A1U-WPKT-W is HDMI 1.4b and HDCP 2.2 compliant and supports CEC pass
through.
The DL-1H1A1U-WPKT-W HDBaseT receiver powers wall plate transmier via HDBaseT
so there is no need for an external power supply for the wall plate.
The DL-1H1A1U-WPKT-W is sold only as a set. The individual transmier and receiver
are not compable with other HDBaseT devices due to proprietary PoE circuitry.
Product Overview
Package Contents
• DL-1H1A1U-WPKT-W Wall plate extender set
• Quick Install Guide
• (1) Decora cover plate
• (1) 3 Pin phoenix connector
• (1) 2 Pin phoenix connector
• (1) DC24V 1A power supply with US, UK, EU and AU power adapter plugs
• (2) Mounng ears with mounng screws

DL-1H1A1U-WPKT-W Install Guide
3
Transmier / Receiver View
Transmier
1
34
2
5
6 7
23
1
1. HDMI IN - Video source input
2. ACTIVE LED
• When LED is green, unit is received acve HDMI signal
• When LED is o, no acve HDMI signal is present
3. AUDIO IN- 3.5 mm analog audio source input
4. USB - USB host port
5. RS232 - Serial port for transming / receiving RS232 signals
6. HDBaseT OUT - HDBaseT output port
7. DC24V - Phoenix connector for connecng external power supply
Note: The DL-1H1A1U-WPKT-W-TX can receive power via HDBaseT from the receiver when
connected together with a Category 6 F/UTP cable

DL-1H1A1U-WPKT-W Install Guide
4
345 6 7 8
2
1
1. ACTIVITY LED’S
• When POWER LED is ON, unit is receiving power
• When LINK LED is ON, the TX and RX is connected properly
• When HDCP LED is ON, unit is receiving HDCP encrypted content
• When FW LED is ON, unit is receiving power
2. SERVICE - For rmware updates
3. HDBaseT IN - HDBaseT input port
4. HDMI OUT - HDMI output to connect to display technology
5. USB- USB Client side ports
6. AUDIO OUT - 3.5mm analog audio output port
7. RS232 - Serial port for transming / receiving RS232 signals
8. DC24V - Locking connector for connecng external power supply
Receiver

DL-1H1A1U-WPKT-W Install Guide
5
Connecvity Instrucons
1. Verify all components included with the extender set are present before installaon.
2. If the extenders are going to be permanently mounted to a surface, aach the
included mounng brackets with the supplied screws.
3. Turn o power and disconnect the audio/video equipment by following the
manufacturer’s instrucons.
4. Connect Category 6 or greater twisted pair cable with RJ45 connectors between the
transmier (DL-1H1A1U-WPKT-W-TX) and the receiver (DL-H1A1U-WPKT-W-RX). TIA/
EIA-568B straight-through wiring connecons must be used with all HDBaseT extenders.
5. Connect an HDMI cable and any desired control accessories between the display and
the receiver (DL-H1A1U-WPKT-W-RX).
6. Connect an HDMI cable and any desired control accessories between the source and
the transmier (DL-1H1A1U-WPKT-W-TX).
7. Connect a computer USB port to the transmier (DL-1H1A1U-WPKT-W-TX) USB host
port.
8. Connected USB peripherals such as white-boards and USB cameras the to USB client
ports of the receiver (DL-1H1A1U-WPKT-W-RX) USB ports.
9. Connect the included power supply to the DL-1H1A1U-WPKT-W receiver and lock
the power supply to the power connector by twisng the locking collar clockwise.
10.Power on aached audio/video devices.

DL-1H1A1U-WPKT-W Install Guide
6
Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category 6
connecon between send and receive
units.
Cabling Requirements
HDBaseT Cabling
To ensure proper performance of the DL-1H1A1U-WPKT-W, it is recommended that you
use solid core, shielded Category 6 F/UTP cabling at a minimum. Category 5e F/UTP may
perform well but may not support power over HDBaseT reliably.
For opmized HDBaseT performance use the following Liberty Wire and Cable branded
cabling;
Category 6 plenum; 24-4P-P-L6SH
Category 6A plenum; 24-4P-P-L6ASH
Category 6 NON-plenum; 24-4P-L6SH
Category 6A NON-plenum; 24-4P-L6ASH
When using shielded category cabling A LWAY S ...
....use shielded connectors
....properly ground the category cable
RS232 Wiring
Connect the controller or device RX signal
to TX on the DL-1H1A1U-WPKT-W extender.
Connect the controller or device TX signal to
Rx on the DL-1H1A1U-WPKT-W extender.
RS232 Port
Connected RS232
Device Pins
TX G RX
RX G TX

DL-1H1A1U-WPKT-W Install Guide
7
Technical Specicaons
VIDEO
Video Inputs (TX) (1) HDMI
Video Input Connector (TX) (1) HDMI type A
Input Video Signal HDMI
Video Output (RX) (1) HDMI
Video Output Connector (RX) (1) HDMI type A
Output Video Signal HDMI
Input Resoluons Supported Up to 3840 x 2160 @ 60Hz, 4:2:0, 8bit color depth
Standards Compliant with HDMI 1.4b & HDCP2.2
USB
Supported USB Standard USB 2.0 High Speed
USB Data Transfer Bandwidth 190Mbps
USB Port Type (1) USB Type B (TX)
(2) USB Type A (RX)
AUDIO
Supported output formats (HDMI) LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS,
DTS-EX,DTS-96/24, DTS High Res, DTS-HD Master
Audio, DSD
Supported output formats (Analog) PCM 2.0
Audio Input / Output Stereo analog
Audio Input / Output Connector (1) 3.5mm TRS audio jack
Audio Output Impedance 70 Ohms
Frequency Response 20Hz~20K Hz
CONTROL
Control Port / Connector (1) RS232 (TX) / 3 phoenix connector
(1) RS232 (RX) / 3 phoenix connector
OTHER
System Bandwidth 10.2Gbps
Operang Temperature 0C ~ +40C
Storage Temperature -20C ~ +60C
Humidity 20% ~ 90%
Power Supply Input:100V~240V AC; Output: 24V DC 1A
Power Consumpon 9 was
Dimension (W*H*D) TX:103.5mm * 30mm * 46mm / 4” * .1.2” * 1.8”
RX:140mm * 23mm * 75mm / 5.5” * .9” * 2.9”
Weight TX:163g / .36 lbs
RX:200g / .44 lbs
Warranty 5 years
Cercaon CE, FCC, RoHS
